Carmanah Go Power! GP-RV-80E User manual

Owner’s Manual
powered by
RV Solar Power Kits:
GP-RV-80
GP-RV-95
GP-RV-160
Weekender SW
Weekender HD
Solar Elite
Solar Extreme
Expansion Kits:
GP-RV-80E
GP-RV-95E
GP-RV-160E
Solar Extreme shown here

2gpelectric.com
GP-RV-80
GP-RV-95
GP-RV-160
GP-RV-80E
GP-RV-95E
GP-RV-160E
Weekender SW
Weekender HD
Solar Elite
Solar Extreme

3
gpelectric.com
GP-RV-80
GP-RV-95
GP-RV-160
GP-RV-80E
GP-RV-95E
GP-RV-160E
Weekender SW
Weekender HD
Solar Elite
Solar Extreme
Table of Contents
RV Installation Parts and Checklist 3
1.0 Installation Overview 4
1.1 How Does the Go Power! RV Solar Kit Work 4
1.2 Warnings 4
1.3 Tools Required (Additional tools may be required) 4
1.4 Weekender SW / Weekender HD / Solar Elite / Solar Extreme Installation 5
2.0 Wiring the Solar Module and Power Cable 5
3.0 Wiring Modules with MC4 Cables 5
3.1 GP RV-80/95/160/Weekender HD/Weekender SW -
Single Module System/MC4 Junction Box
5
3.2 Solar Elite - Multimodule System/MC4 Junction Box 5
3.3 Solar Extreme - Multimodule System/MC4 Junction Box
3.4 GP RV-80E/95E/160E - Expanding to a Multimodule System/MC4 Junction Box 5
3.5 Modules with MC4 Connectors Wired to a Non-Potted Junction Box 5
4.0 Routing Power Cable through the Fridge Vent 6
4.1 Method 1 – Hole in Side of Vent 6
4.2 Method 2 – Through Screen Grid 6
5.0 Mounting the Solar Module 6
5.1 Using the Mounting Feet 6
6.0 Installing The GP-PWM Controller 6
6.1 Mounting The GP-PWM Controller 7
7.0 Connecting to the Battery & Solar Array 7
7.1 Typical Battery Connection 7
8.0 Limited Warranty 7
8.1 General Warranty Issues 8
8.2 Warranty Return Procedure 8
8.3 Additional Information 8
8.4 Out of Warranty Items 9
9.0 System Glossary 9
10.0 Diagrams 11

4gpelectric.com
GP-RV-80
GP-RV-95
GP-RV-160
GP-RV-80E
GP-RV-95E
GP-RV-160E
Weekender SW
Weekender HD
Solar Elite
Solar Extreme
Standard Kits Expansion Kits
PART
01. Ring Terminal Battery Connector
02. MC4 Cable with Male and Female MC4 Connectors
03. Tie Wrap
04. Positive MC4 Parallel Connector
05. Negative MC4 Parallel Connector
06. #10/32 Well Nut
07. #10/32 Well Nut Bolt
08. #10/32 Well Nut Flat Washer
09. #10/32 Well Nut Lock Washer
10. #6 Self-tapping Screws
11. Cable clamp
12. ¼” Bolt
13. ¼” Flat Washer
14. ¼” Lock Washer
15. ¼” Nut
16. Mounting Feet
17. Solar Module
18. GP-PWM Controller
19. ARM-UNI Mount (Optional)
20. # 10 1” Wood Screws
* The Solar Elite includes: GP-SW2000-12, GP-SWR-B-12, GP-DC Kit4, GPC-45-MAX and GP-TS.
* The Weekender SW includes: GP-SW1500-12, GP-SW-Remote, GP-DC Kit3 and GP-TS.
* The Solar Extreme includes: GP-SW3000-12, GP-SWR-B, GP-DC Kit 5, GPC-75-MAX and GP-TS
01
02
03
07
08
09
10
11
12
13
14
16
17 Solar Module
GP-PWM
Controller
18
Parts Checklist
Battery
(not included)
15
06
04
05
2
1
6
0
0
6
6
6
6
6
6
6
6
6
6
6
1
1
0
4
2
1
6
1
1
12
12
12
12
12
12
12
12
12
12
12
2
1
0
8
0
0
0
1
1
6
6
6
6
0
0
6
6
6
6
6
1
0
0
4
2
1
6
0
0
4
4
4
4
6
6
4
4
4
4
4
1
1
0
4
GP-RV-80/95/160
*Weekender HD or SW
*Solar
Elite
GP-RV-80E/95E/
160E
19
(Optional)
2
1
6
2
2
18
18
18
18
18
18
18
18
18
18
18
4
1
0
12
*Solar
Extreme
20

5
gpelectric.com
GP-RV-80
GP-RV-95
GP-RV-160
GP-RV-80E
GP-RV-95E
GP-RV-160E
Weekender SW
Weekender HD
Solar Elite
Solar Extreme
1.0 Installation Overview
Congratulations on your purchase of a Go Power!TM RV Solar Power Kit. You have chosen a clean, quiet and
sustainable way to provide power to your recreational vehicle. A Go Power!TM RV Solar Power Kit gives you
the ability to dry camp while ensuring your batteries remain fully charged. The Go Power!TMRV Solar Power
Kit allows you to enjoy the luxuries that electricity provides, without a campsite hookup. For simple battery
maintenance or full-time live-aboard power, Go Power!TM RV Solar Power Kits are available in a variety of
sizes and can be installed on RVs, campers, trailers, fth wheels and motor homes.
1.1 How Does the Go Power!TM RV Solar Power Kit Work
The solar module converts the sun’s energy into DC electricity and this electricity charges the battery. The
battery stores the electricity, similar to a water tank storing water. The battery power may be used at any
time to operate devices connected to the battery. To stop the battery from being overcharged by the solar
module, a solar controller is connected between the two. The GP-PWM-30 controller will disconnect power
from the solar module when the battery is fully charged.
Please read and understand all instructions before installing your new product for the easiest and safest
installation. Before installing the kit, please review the installation diagram included in this Installation
Manual. If you have any doubts as to this kit’s compatibility with your RV, please contact your authorized
Go Power!TM RV Dealer. It is advisable to retain this manual for future reference.
1.2 Warnings
Electrical Safety. Disconnect all power sources before attempting installation. Electricity can be very
dangerous. Installation should be performed only by a licensed electrician or qualied personnel.
Solar Module Safety. Photovoltaic modules generate DC electricity when exposed to sunlight or other light
sources. Contact with the electrically active parts of the module, such as terminals, can result in burns,
sparks and lethal shock whether the module is connected or disconnected.
When modules are connected in parallel, amperages are additive. Consequently, a system assembled from
photovoltaic modules can produce high amperages, which constitute an increased hazard.
Do not touch terminals while module is exposed to light. Cover the module face completely with opaque
material to halt the production of electricity when installing or working with modules or wiring.
Battery Safety. Observe all safety precautions of the battery manufacturer when handling or working around
batteries. When charging, batteries may produce explosive hydrogen gas. Work in a well ventilated area
and use caution when making or removing electrical connections. Ensure wires are disconnected from
their power sources when wiring. Do not expose battery to open ame, cigarettes or sparks. Shield skin
and eyes from battery acid.
Wiring Safety Ensure all connections are tight and secure. Loose connections may generate sparks.
Work safely. Wear protective eyewear and appropriate clothing during installation. Use extreme caution when
working with electricity and when handling and working around batteries. Use properly insulated tools only.
Observe correct polarity at all times. Any contact in reverse polarity, however brief, will cause the regulator
and/or inverter fuse to blow and may damage the unit.
Do not exceed the voltage and current ratings of the regulator. The total current of the solar system is
the sum of the short circuit current of the solar modules in parallel, multiplied by a safety factor of 1.25. The
resulting system current is not to exceed the amperage rating of the regulator. The voltage of the array is
the rated open circuit voltage of the solar modules and is not to exceed 26 volts for a 12 volt system. The
current rating of the solar system is the sum of the Maximum Power Current (lmp) of the solar PV strings in
parallel. The resulting system lmp current is not to exceed 30 A. The voltage of the array is the rated open
circuit voltage (Voc) of the PV array and is not to exceed 56 V. If your solar system exceeds these ratings,
contact your dealer for a suitable regulator alternative.
1.3 Tools Required (Additional tools may be required)
a. Slot Screwdriver
b. # 2 Robertson Square Head Screwdriver
c. Keyhole saw
d. Punch or Awl
e. Pliers
f. Wire Strippers
g. Wire crimpers
h. Electric hand drill
i. 1/16 and 3/8 inch drill bit
j. 5/16 and 7/16 inch wrench
k. Sealant

6gpelectric.com
GP-RV-80
GP-RV-95
GP-RV-160
GP-RV-80E
GP-RV-95E
GP-RV-160E
Weekender SW
Weekender HD
Solar Elite
Solar Extreme
Note:
This installation guide
does not list all possible
variations of available
solar modules. This
installation guide will
address the assembly of
standard Go Power! RV
Solar Power Kits, which
contain one, two or three
solar modules connected
in parallel for a 12 volt
system. Expander Kits
are available to add solar
modules to an existing
system.
1.4 Weekender SW / Weekender HD / Solar Elite/ Solar Extreme Installation
Refer to specic product manuals included in kits for correct product installation (ex. inverters, chargers and remotes).
2.0 Wiring the Solar Module and Power Cable
Please follow the directions in the appropriate section, depending on which kit you are about to install.
Kit Model Manual Section
GP-RV-80/95/155/Weekender HD/Weekender SW Section 3.1
Solar Elite Section 3.2
Solar Extreme Section 3.3
GP-RV-80E/95E/155E Section 3.4
Wiring Diagrams (located at the end of the manual)
MC4 Power Cables for RV Kits Diagram-1
Wiring Parallel Modules with MC4 Parallel Connectors Diagram-2
Parallel Wiring Between Standard and MC Junction Boxes Diagram-3
RV System Electrical Layout - RV/Off Grid Diagram-4
RV System Electrical Layout - Manual Power Switching Diagram-5
RV System Electrical Layout - Automatic Power Switching Diagram-6
3.0 Wiring Modules with MC4 Cables
RV Kits with MC4 cables contain a potted or sealed junction box with a positive and negative MC4 connector. This is
referred to as an MC4 junction box. MC4 connectors are either positive or negative and each connector has its
polarity symbol embossed close to the connection point. To extend a cable from an MC4 junction box, a polarity
opposite connector must be used. E.G. a negative connector must plug into a positive connector in order to extend
it. Please remember, the polarity of an MC4 cable wire run is the polarity symbol on the connector closest to the MC4
junction box. It is advisable to attach a polarity sticker to the positive extension cable in order to avoid confusion.
3.1 GP-RV-80/95/155/Weekender HD/Weekender SW
Single Module System/MC Junction Box
RV Kits containing a single module with MC4 cables will be equipped with a single MC4 power cable that has both a male
and female MC4 connection. This cable is meant to be cut in half leaving you with a 25’ cable with a male MC4 and a 25’
cable with a female MC4 connection. Refer to Diagram-1, “MC4 Power Cables for RV Kits.”
3.2 Solar Elite
Multi Module System/MC4 Junction Box
RV Kits containing two modules with MC4 cables via an expansion kit will be equipped with a 50’ MC4 power cable, a
negative MC4 parallel connector and a positive MC4 parallel connector. Refer to Diagram-2, “Wiring Parallel Modules
with MC4 Cables.”
3.3 Solar Extreme
Multi Module System/MC4 Junction Box
RV Kits containing three modules with MC4 cables via two expansion kit will be equipped with a 50’ MC4 power cable, two
negative MC4 connectors and two positive MC4 connectors. Refer to Diagram-2, “Wiring Parallel Modules with MC Cables.”
3.4 GP-RV-80E/95E/155E
Expanding to a Multi Module System/MC4 Junction Box
RV Kits containing two modules with MC4 cables via an expansion kit will be equipped with a 50’ MC4 power cable, a
negative MC4 parallel connector and a positive MC4 parallel connector. Refer to Diagram-2, “Wiring Parallel Modules
with MC4 Cables.”
3.5 Modules with MC4 Connectors Wired to a Non-Potted Junction Box
Please be aware that some modules are equipped with MC4 cables and a fully functioning non-potted Junction Box. In
this case, it is recommended that the MC4 cables be used as described in Section 3. Do not connect the positive and
negative MC4 cables from the same junction box together; this will short circuit the module.

7
gpelectric.com
GP-RV-80
GP-RV-95
GP-RV-160
GP-RV-80E
GP-RV-95E
GP-RV-160E
Weekender SW
Weekender HD
Solar Elite
Solar Extreme
4.0 Routing Power Cable through the Fridge Vent
Locate the refrigerator vent on the roof of the RV. Remove vent cover to gain access to the duct opening.
Refer to Figure 1. Retain vent-fastening hardware.
4.1 Method 1 – Hole in Side of Vent
Drill a hole through the side of the vent (5/8” hole). Insert a rubber grommet (not included) into the hole.
Insert the power cable (already wired to the solar module) through the hole and carefully route it to the
battery. Be certain to leave enough slack to allow cable routing from module to vent along desired path.
4.2 Method 2 – Through Screen Grid
1. Thread power cable (already wired to solar module) carefully through the screen and into opening.
Enlarge screen grid hole if necessary.
2. Avoid strapping the power cable to existing wire between the module and the battery. Allowing a few
inches of space between the power cable and existing wire will lessen the chance of voltage loss
through thermal conduction. Use cable clamps with the # 6 self-tapping screw and/or tie wraps every
few feet along RV roof and interior route to battery.
3. Ensure all penetrations into the RV roof are watertight. Use an appropriate sealant as recommended
by your RV Dealer to seal holes wherever necessary.
4. Replace vent cover.
5.0 Mounting the Solar Module
The solar modules may be horizontally mounted to the roof using the included mounting feet. An optional
adjustable roof mount (ARM-UNI) is also available from Go Power!.
5.1 Using the Mounting Feet
1. Assemble the mounting feet onto the ends of the solar module using the 1/4” bolts, washers and nuts
as shown in Figure 2.
2. Tighten nuts securely using a 7/16” wrench.
3. Place the module in a location that follows the criteria listed here:
• Select a location where the mounting surface is at least 1/2” thick and strong
enough to support mounting hardware, the solar module and wind loads
• Minimize distance between the location of the solar module and the location
where the power cable will enter the vehicle to connect to the battery
• Place the module lengthwise along the roof to reduce wind loading on vehicles
(if applicable)
• Avoid internal wiring when selecting the spots for drilling the four mounting
holes
• Ensure obstacles, such as air conditioners, will not shade the solar module
Note: Place module so that you have room to expand the current system if needed.
4. Mark the mounting hole locations by using a pencil to trace through the holes in the mounting feet.
Drill mounting holes only one inch deep with a 3/8” drill bit.
5. Use the appropriate sealant as recommended by your RV Dealer to ensure a watertight installation.
6. Gently insert the well-nuts into the drill holes so that only the topmost ange part remains above the
rooine. Be careful not to push well-nuts through the holes.
7. Insert screws with lock washers and tighten. Do not overtighten.
8. If you are installing on a rubber roof with plywood underneath, it is acceptable to use wood screws
instead of the well-nuts that are provided.
6.0 Installing The GP-PWM-30 Solar Controller
The GP-PWM -30 is included in all Go Power! RV Kits mentioned in this manual except for the
Expansion Kits.
Caution:
The screen may have sharp edges or
burrs.
Figure 1
Vent
Screen
Refrigerator
Vent Cover
Solar
Module
Cable
Clamps
Method 2
Method 1
Solar
Module
1/4” Flat
Washer
1/4’ Lock
Washer
1/4’ Bracket
Bolt
Mounting
Foot
RV
Roof
Figure 2
1/4” Nut
Figure 3
RV
Roof
Solar
Module
Mounting
Foot

8gpelectric.com
GP-RV-80
GP-RV-95
GP-RV-160
GP-RV-80E
GP-RV-95E
GP-RV-160E
Weekender SW
Weekender HD
Solar Elite
Solar Extreme
The GP-PWM-30 provides the necessary protection for the RV battery system. A condensed version
of the installation instructions appear below. However, please read the full installation manual included
with the GP-PWM-30 Solar Controller.
1. Disconnect or cover the solar modules and disconnect the batteries before commencing the GP-
PWM-30 wiring.
2. Run the solar module power cable to the location of The GP-PWM-30. Do not connect the wires
to the controller or the batteries. Identify the polarity of the wires located on the battery and
solar module (positive and negative). Use coloured tape or mark wire ends with tags. Contacting
the leads of the controller in reverse polarity, however brief, will cause the controller to go into lock
out mode and the solar controller will need to be reset.
3. Wire the controller according to the terminal identication on the back of controller starting with the
battery connections. Tighten the connections and then set the battery type on the controller (see
controller manual for instruction). Then connect the solar module and tighten the connections.
4. Read The GP-PWM-30 Manual prior to installing.
6.1 Mounting The GP-PWM-30 Controller
The GP-PWM-30 should be mounted in a location relatively close to the battery, but easily seen for
monitoring system operation. Wires must be run from the solar module to the controller and then to the
battery. The GP-PWM-30 is designed to be ush mounted on the side of a cabinet or wall where the
wiring can be accessed from the back. Allow two to three inches behind the unit. The controller should
be mounted indoors, in a dry location.
1. Select a suitable location for the installation of the controller. Run the power cable from the solar
module to the location selected.
2. Use the template included in the GP-PWM-30 Manual to mark the four mounting holes and the “cutting
line for ush mounting”. Drill the mounting holes. Use a keyhole or jig saw to cut along the rectangular
outline you marked.
3. Wire the controller as shown in the GP-PWM-30 Manual. Use the leftover power cable to connect the
controller to the batteries.
4. Mount the controller to the wall using the four wood screws provided. Ensure the back of the controller
is protected from damage by any object.
7.0 Connecting to the Battery & Solar Array
It is recommended to connect directly to the battery wherever possible. You can also connect to the
converter charger where the battery positive and negative wires connect to the converter.
1. Clean all corrosion from battery terminals before proceeding. Crimp ring terminals onto the negative
and positive wires of the power cable to be attached to the battery.
2. Attach the negative (black) wire’s 3/8” ring terminal to the RV battery. Check all electrical connections
and apply a protective coating to battery terminals.
7.1 Typical Battery Connection
1. Single 12 Volt battery connection (See Figure 5)
2. Parallel 12 Volt battery connection (See Figure 6)
3. 6 Volt series battery connection (See Figure 7)
8.0 Disclaimer of Liability & Warranty
1. Go Power! warrants the Go Power!TM RV Solar Power Kit for a period of one (1) year from the date
of shipment from its factory. This warranty is valid against defects in materials and workmanship for
the one (1) year warranty period. It is not valid against defects resulting from, but not limited to:
• Misuse and/or abuse, neglect, or accident
• Exceeding the unit’s design limits
• Improper installation, including, but not limited to, improper environmental
Figure 5
Single 12 Volt Battery
12 Volt Conguration
Solar
Controller
Negative
Connection
Positive
Connection
Figure 6
Solar
Controller
Solar
Controller
Positive
Connection
Negative
Connection
Two 12 Volt Batteries
12 Volt Parallel Conguation
Figure 7
Positive
Connection
Negative
Connection
Two 6 Volt Batteries
12 Volt Series Conguation

9
gpelectric.com
GP-RV-80
GP-RV-95
GP-RV-160
GP-RV-80E
GP-RV-95E
GP-RV-160E
Weekender SW
Weekender HD
Solar Elite
Solar Extreme
protection and improper hook-up
• Acts of God, including lightning, oods, earthquakes, re, and high winds
• Damage in handling, including damage encountered during shipment
2. This warranty shall be considered void if the warranted product is in any way opened or altered. The
warranty will be void if any eyelet, rivets, or other fasteners used to seal the unit are removed or
altered, or if the unit’s serial number is in any way removed, altered, replaced, defaced or rendered
illegible.
3. The one (1) year term of this warranty does not apply to equipment where another limited warranty is
available. This may include but is not limited to, the solar controller ve (5) years, the solar modules
twenty-ve (25) years and the inverter: modied sine wave inverter one (1) year, pure sine wave
inverter two (2) years.
8.1 General Warranty Issues
Please visit gpelectric.com for our up-to-date General Warranty Issues
8.2 Warranty Return Procedure
Visit gpelectric.com to read the “frequently asked questions” section of our website to troubleshoot the
problem. If trouble persists:
1. Call your Go Power!™ Technical Support team (1-866-247-6527)
2. Return defective product to place of purchase
8.3 Additional Information
Unless approved by Go Power! management, all product shipped collect to Go Power! will be refused.
Test items or items that are not under warranty, or units that are not defective, will be charged a minimum
bench charge of ($50.00 US) plus taxes and shipping. A 15% restocking charge will be applied on goods
returned and accepted as “new” stock.
8.4 Out of Warranty Items
Go Power! electronic products are non-repairable, Go Power!TM does not perform repairs on its
products nor does it contract out those repairs to a third party. Go Power!TM does not supply schematics
or replacement parts for any of its electronic products.
9.0 System Glossary
Visit gpelectric.com for our Glossary of Terms
10.0 Diagrams
MC4 Power Cables for RV Kits Diagram-1
Wiring Parallel Modules with MC4 Parallel Connectors Diagram-2
Parallel Wiring Between Standard and MC4 Junction Boxes Diagram-3
RV System Electrical Layout - RV/Off Grid Diagram-4
RV System Electrical Layout - Manual Power Switching Diagram-5
RV System Electrical Layout - Automatic Power Switching Diagram-6

10 gpelectric.com
GP-RV-80
GP-RV-95
GP-RV-160
GP-RV-80E
GP-RV-95E
GP-RV-160E
Weekender SW
Weekender HD
Solar Elite
Solar Extreme
Diagram 1
Negative MC4 Junction
Box Connection - Female
MC4 Power Cabels For RV Kits
The MC4 power cable is usually the nal connection
between the solar array and the solar controller. If it has
not already been done, cut the MC power cable into two
pieces so that there is a positive conductor cable and
negative conductor cable.
1. Cover the solar module(s) with an opaque material.
Attach the appropriate MC4 power cable conductor to the
positive and negative connectors of the MC4 junction box.
If you have more than one module, refer to the specic
diagram for wiring a parallel MC4 connection.
2. Run the positive and negative MC4 cable conductors
from the solar array to the solar controller. Attach a positive
polarity label to the end of the positive conductor. If the
positive conductor needs to be shortened and the polarity
label is removed, remember to re-label it as both positive
and negative conductors look exactly the same. Leave a
few feet of cable at the solar controller in case of future
adjustment.
Note: solar module junction box and MC4 cables many not
be exactly as shown.
Positive Polarity Label
Positive MC4
Junction Box
Connection - Male
Negative MC4
Cable Conductor
Positive MC4
Cable Conductor
Cut 50’ wire in
half to make
two 25’ cables

11
gpelectric.com
GP-RV-80
GP-RV-95
GP-RV-160
GP-RV-80E
GP-RV-95E
GP-RV-160E
Weekender SW
Weekender HD
Solar Elite
Solar Extreme
Diagram 2
Negative MC4 Parallel Connector - Female
Wiring Parallel (2) Modules with MC4 Parallel Connectors
Positive MC4 Parallel Connector - Male
Note: solar module junction box and MC4 cables many not
be exactly as shown.
MC4 Extension Cable to Solar Controller or Combiner Box
MC4 Cable Connections for 2 Parallel Modules
E.G. Two 12V modules at 12V
MC4 Parallel - Male MC4 Parallel - Female

12 gpelectric.com
GP-RV-80
GP-RV-95
GP-RV-160
GP-RV-80E
GP-RV-95E
GP-RV-160E
Weekender SW
Weekender HD
Solar Elite
Solar Extreme
Diagram 3
Parallel Wiring Between a Standard Junction Box and an MC4 Cable Junction Box
Negative MC4 Parallel Connector - Female
Positive MC4 Parallel Connector - Male
MC4 Extension Cable
(MC4 Output 10)
Existing MC Power Cable
to Solar Controller
Parallel Wiring Between a Standard Junction Box and an Existing MC4 Cable Junction Box
Note: solar module junction box and MC4 cables many not
be exactly as shown.
MC4 Parallel - Male MC4 Parallel - Female
MC4 Extension Cable (MC4 Output 10)
Existing Power
Cable to Solar
Controller

13
gpelectric.com
GP-RV-80
GP-RV-95
GP-RV-160
GP-RV-80E
GP-RV-95E
GP-RV-160E
Weekender SW
Weekender HD
Solar Elite
Solar Extreme
Diagram 4
RV Electrical Layout - RV / Off Grid
All positive conductors connected to the battery
should be equipped with the circuit protection rated
to the wire size used.
If the inverter supplies power to the AC panel which provides
power to a converter, the resulting battery loop will quickly drain
the batteries.
Disconnect the converter entirely from the system via a breaker or
physically disconnecting the wires.
Usually the converter with circuit protection is rewired to connect to
the utility power side of the system, if utility power is available.
Diagram is recommended wiring only. Compliance
with governing electrical code is assumed.
Shore Power Cable
Inverter
Battery
Solar
Module
Loads
Charge
Controller
Converter
AC
Panel
In no event will Carmanah be liable to any party or
for any direct, indirect, special or other consequential
damages resulting from use of this diagram.

14 gpelectric.com
GP-RV-80
GP-RV-95
GP-RV-160
GP-RV-80E
GP-RV-95E
GP-RV-160E
Weekender SW
Weekender HD
Solar Elite
Solar Extreme
Diagram 5
RV Electrical Layout - Two AC Power Sources
No Transfer Switch - Manual Switching
If the inverter supplies power to the AC panel which provides
power to a converter, the resulting battery loop will quickly
drain the batteries.
Disconnect the converter entirely from the system via a
breaker or physically disconnecting the wires.
Usually the converter with circuit protection is rewired to
connect to the utility power side of the system, if utility power
is available.
Inverter
Battery
Solar
Module
Loads
Charge
Controller
Converter/
Battery
Charger
Shore Power Cable
In the absence of a transfer switch, the AC panel
connection is physically unplugged from inverter
and plugged into utility power and vice versa.
Utility Power or
Generator
Diagram is recommended wiring only. Compliance
with governing electrical code is assumed.
In no event will Carmanah be liable to any party or
for any direct, indirect, special or other consequential
damages resulting from use of this diagram.
All positive conductors connected to
the battery should be equipped with
the circuit protection rated to the
wire size used.
AC
Panel

15
gpelectric.com
GP-RV-80
GP-RV-95
GP-RV-160
GP-RV-80E
GP-RV-95E
GP-RV-160E
Weekender SW
Weekender HD
Solar Elite
Solar Extreme
Diagram 6
Inverter
Battery
Solar
Module
Loads
Charge
Controller
Converter/
Battery
Charger
Utility Power or
Generator
AC
Panel
Transfer
Switch
Diagram is recommended wiring only. Compliance
with governing electrical code is assumed.
In no event will Carmanah be liable to any party or
for any direct, indirect, special or other consequential
damages resulting from use of this diagram.
If the inverter supplies power to the AC panel which provides
power to a converter, the resulting battery loop will quickly drain
the batteries.
Disconnect the converter entirely from the system via a breaker
or physically disconnecting the wires.
Usually the converter with circuit protection is rewired to connect
to the utility power side of the system, if utility power is available.
RV Electrical Layout - Two AC Power Sources
with Automatic Transfer Switch
All positive conductors connected
to the battery should be equipped
with the circuit protection rated to
the wire size used.

16 gpelectric.com
powered by
© 2013 GO POWER!™ By Carmanah Technologies
MOBI_MAN_GP-RV Install Kit and Systems_160.indd
GP-RV-80
GP-RV-95
GP-RV-160
GP-RV-80E
GP-RV-95E
GP-RV-160E
Weekender SW
Weekender HD
Solar Elite
Solar Extreme
