Carrier WEATHERMASTER 50HJQ004 Dimensions and installation guide

1
50HJQ004---007
50HEQ003---006
Single---Package Rooftop Heat Pump Units
Installation, Start---Up and
Service Instructions
CONTENTS
PAGE
SAFETY CONSIDERATIONS 1........................
INSTALLATION 1-52................................
Provide Unit Support 1.............................
Roof Curb 1..................................
Slab Mount 3..................................
Alternate Unit Support 3.........................
Field Fabricate Ductwork 3..........................
Install Condensate Drain Line and External Trap 3........
Rig and Place Unit 3...............................
Positioning 4..................................
Make Electrical Connections 5.......................
Field Power Supply 5...........................
Field Control Wiring 21.........................
Defrost Board 22...............................
Adjust Factory--Installed Options 22...................
Disconnect Switch 22...........................
Convenience Outlet 22..........................
Novar Controls 22..............................
Manual Outdoor--Air Damper 22..................
PremierlinktControl 23........................
Optional Economi$er IV and Economi$er2 26........
Economi$er IV Standard Sensors 28................
Economi$er IV Control Modes 29.................
Adjust Indoor--Fan Speed 34.........................
Belt--Drive Motors 34...........................
PRE--STARTUP 53...................................
STARTUP 53........................................
SERVICE 56........................................
TROUBLESHOOTING 61.............................
START--UP CHECKLIST 66...........................
SAFETY CONSIDERATIONS
Installation and servicing of air-conditioning equipment can be
hazardous due to system pressure and electrical components.
Only trained and qualified service personnel should install, repair,
or service air-conditioning equipment.
Untrained personnel can perform basic maintenance functions of
cleaning coils and filters and replacing filters. All other operations
should be performed by trained service personnel. When working
on air-conditioning equipment, observe precautions in the
literature, tags and labels attached to the unit, and other safety
precautions that may apply.
Follow all safety codes. Wear safety glasses and work gloves. Use
quenching cloth for unbrazing operations. Have fire extinguisher
available for all brazing operations.
Before performing service or maintenance operations
on unit, turn off main power switch to unit, and install
lockout tag. Electrical shock could cause personal
injury.
!WARNING
NOTE: Ensure that the voltage listed on the unit information
plate agrees with the electrical supply to the unit.
INSTALLATION
Unit is shipped in the vertical discharge configuration. To convert
to horizontal configuration, remove horizontal duct opening
covers. Using the same screws, install covers on duct openings in
basepan of unit with the insulation-side down. Seals around duct
openings must be tight.
STEP 1 —PROVIDE UNIT SUPPORT
ROOF CURB
Assemble and install the accessory roof curb in accordance with
the instructions shipped with the curb. (See Fig. 1.) Install
insulation, cant strips, roofing felt, and counter flashing as shown.
Ductwork must be attached to the curb, not to the unit. If electric
or control power will be routed through the basepan, attach the
accessory thru-the-bottom service connections to the basepan and
roof curb in accordance with the accessory installation
instructions. Install connections before the unit is set on the roof
curb.
IMPORTANT: The gasketing of the unit to the roof curb is critical
for water--tightness. Install the gasket supplied with the roof curb as
showninFig.1.Animproperlyappliedgasketcanalsoresultinair
leaks and poor unit performance.
The roof curb should be level to ensure that the unit drain
functions properly. Unit leveling tolerances are shown in Fig. 2.

2
ROOF CURB
ACCESSORY A UNIT SIZE
CRRFCURB001A01 1 -2
[356] 50HJQ
004-007
CRRFCURB002A01 2 -0
[610]
NOTES:
1. Roof curb accessory is shipped disassembled.
2. Insulated panels.
3. Dimensions in [ ] are in millimeters.
4. Roof curb: galvanized steel.
5. Attach ductwork to curb (flanges of duct rest on
curb).
6. Service clearance: 4 ft on each side.
7. Direction of airflow.
8. Connector packages CRBTMPWR001A01 and
002A01 are for thru-the-curb type gas. Packages
CRBTMPWR003A01 and 004A01 are for thru-the-
bottom type gas connections.
CONNECTOR
PKG. ACCY. BC
DALT
DRAIN
HOLE
GAS POWER CONTROL ACCESSORY
POWER
CRBTMPWR001A01
1 -9
11
/
16
[551]
1 -4
[406]
1
3
/
4
[44.5]
3
/
4
[19] NPT
3
/
4
[19] NPT
1
/
2
[12.7]
NPT
1
/
2
[12.7]
NPT
CRBTMPWR002A01 1
1
/
4
[31.7]
CRBTMPWR003A01
1
/
2
[12.7] NPT
3
/
4
[19] NPT
CRBTMPWR004A01
3
/
4
[19] NPT 1
1
/
4
[31.7]
C06001
Fig. 1 --- Roof Curb Details
50HJQ,HEQ

3
MAXIMUM ALLOWABLE
DIFFERENCE (in.)
A-B B-C A-C
0.5 1.0 1.0
C06002
Fig. 2 --- Unit Leveling Tolerances
Refer to Accessory Roof Curb Installation Instructions for
additional information, as required.
SLAB MOUNT (HORIZONTAL UNITS ONLY)
Provide a level concrete slab that extends a minimum of 6 in.
beyond the unit cabinet. Install a gravel apron in front of the
condenser coil air inlet to prevent grass and foliage from
obstructing airflow.
NOTE: Horizontal units may be installed on a roof curb, if
required.
ALTERNATE UNIT SUPPORT
When the curb or adapter cannot be used, support unit with
sleepers using unit curb or adapter support area. If sleepers cannot
be used, support the long sides of the unit with a minimum of 3
equally spaced 4-in. x 4-in. pads on each side.
STEP 2 —FIELD--FABRICATED DUCTWORK
Secure all ducts to the roof curb and building structure on vertical
discharge units. Do not connect ductwork to the unit. For
horizontal applications, attach field-supplied flanges to the
horizontal discharge openings and attach all ductwork to the
flanges. Insulate and weatherproof all external ductwork, joints,
and roof openings with counter flashing and mastic in accordance
with applicable codes.
Ducts passing through an unconditioned space must be insulated
and covered with a vapor barrier.
If a plenum return is used on a vertical unit, duct the return
through the roof deck to comply with applicable fire codes.
A minimum clearance is not required around ductwork. Cabinet
return-air static pressure (a negative condition) should not exceed
0.35 in. wg with economizer, or 0.45 in. wg without economizer.
STEP 3 —INSTALL CONDENSATE DRAIN LINE
AND EXTERNAL TRAP
Condensate drain connections are located at the bottom and side
of the unit. Unit discharge connections do not determine the use
of drain connections; either drain connection can be used with
vertical or horizontal discharge units.
When using the standard side drain connection, make sure the
plug (red) in the alternate bottom connection is tight before
installing the unit.
To use the bottom drain connection for a roof curb installation,
relocate the factory-installed plug (red) from the bottom
connection to the side connection. The center drain plug looks
like a star connection, but can be removed with a 1/2-in. socket
drive extension. (See Fig. 3.) Complete the piping for the
condensate drain and external trap after the unit is in place.
All units must have an external trap for condensate drainage.
Install a trap at least 4 in. deep and protect it against freeze-up. If
drain line is installed downstream from the external trap, pitch the
line away from the 50HJQ unit at 1/4in. per ft of run. Do not use
a pipe size smaller than the unit connection (3/4-in.). (See Fig. 4.)
DRAIN PLUG
CONDENSATE PAN (SIDE VIEW)
HORIZONTAL
DRAIN OUTLET
NOTE: Drain plug is shown in factory-installed position.
C06003
Fig. 3 --- Condensate Drain Connection
(Side View)
NOTE: Trap should be deep enough to offset maximum unit static
difference. A 4-in. trap is recommended.
C06004
Fig. 4 --- Condensate Drain Piping Details
STEP 4 —RIG AND PLACE UNIT
Inspect the unit for transportation damage, and file any claim with
the transportation agency. Keep the unit upright and do not drop.
Spreader bars are not required if top crating is left on the unit, and
rollers may be used to move the unit across a roof. Level by using
the unit frame as a reference. See Table 1 and 2 and Fig. 5 for
additional information. Operating weight is shown in Table 1 and
2 and Fig. 5.
Lifting holes are provided in the base rails as shown in Fig. 5 and
6. Refer to rigging instructions on the unit.
50HJQ,HEQ

4
NOTES:
1. Dimension in ( ) is in millimeters.
2. Hook rigging shackles through holes in base rail, as shown in detail ‘‘A.’’
Holes in base rails are centered around the unit center of gravity. Use
wooden top skid when rigging to prevent rigging straps from damaging unit.
3. Unit weights do not include economizer. See Table 1 for economizer weights.
C06005
50HJQ
UNIT
SIZE
OPERATING WEIGHT DIMENSIONS
“A” “B” “C”
lb kg in. mm in. mm in. mm
004 550 227 73.69 1872 35.50 902 33.31 847
005 550 249 73.69 1872 35.50 902 33.31 847
006 630 268 73.69 1872 35.50 902 33.31 847
007 630 268 73.69 1872 35.50 902 41.33 1050
50HEQ
UNIT
SIZE
OPERATING WEIGHT DIMENSIONS
“A” “B” “C”
lb kg in. mm in. mm in. mm
003 550 227 73.69 1872 35.50 902 33.31 847
004 550 227 73.69 1872 35.50 902 33.31 847
005 550 249 73.69 1872 35.50 902 33.31 847
006 630 268 73.69 1872 35.50 902 33.31 847
Fig. 5 --- Rigging Details
All panels must be in place when rigging. Unit is not designed
for handling by fork truck. Damage to unit may result.
CAUTION
!
POSITIONING
A properly positioned unit will have the following
clearances: 1/4-in. clearance between the roof curb and the base
rails on each side and duct end of the unit; 1/4-in. clearance
between the roof curb and the condenser end of the unit. (See Fig.
1, section C-C.)
Do not install the unit in an indoor location. Do not locate the
unit air inlets near exhaust vents or other sources of contaminated
air.
Although the unit is weatherproof, guard against water from
higher level runoff and overhangs.
After the unit is in position, remove the polyethylene shipping
wrapper and top crating.
50HJQ,HEQ

5
STEP 5 —MAKE ELECTRICAL CONNECTIONS
Failure to follow this warning could result in the installer
being liable for personal injury of others.
Unit cabinet must have an uninterrupted, unbroken
electrical ground to minimize the possibility of personal
injury if an electrical fault should occur. This ground may
consist of electrical wire connected to unit ground lug in
control compartment, or conduit approved for electrical
ground when installed in accordance with NEC (National
Electrical Code), ANSI/NFPA (American National
Standards Institute/National Fire Protection Association)
70 (latest year), and local electrical codes.
!WARNING
FIELD POWER SUPPLY
All units (except 208/230-v units) are factory wired for the
voltage shown on the nameplate. If the 208/230-v unit is to be
connected to a 208-v power supply, the transformer must be
rewired by disconnecting the black wire from the 230-v 1/4-in.
male spade terminal on the transformer and connecting it to the
208-v 1/4-in. male spade terminal from the transformer. Refer to
the unit label diagram for additional information. Pigtails are
provided for field wire connections. Use factory-supplied splices
or a UL (Underwriters’ Laboratories) approved copper/aluminum
connector.
When installing units, provide a disconnect per the NEC. All field
wiring must comply with the NEC and local
requirements.
Install field wiring as follows:
1. Install conduit through the side panel openings. For units
without electric heat, install conduit between the
disconnect and control box.
2. Install power lines to the terminal connections as shown in
Fig. 7.
3. For units with electric heat, refer to Table 3 and Accessory
Electric Heat Installation Instructions.
During operation, voltage to compressor terminals must be within
the range indicated on the unit nameplate (also see Tables 4A-4D
and 5A--5D). On 3-phase units, voltages between phases must be
balanced within 2% and the current within 10%. Use the formula
shown in Tables 4A-4D and 5A--5D, Note 2, to determine the
percentage of voltage imbalance. Operation on improper line
voltage or excessive phase imbalance constitutes abuse and may
cause damage to electrical components. Such operation
invalidates any applicable Carrier warranty.
NOTE: If the unit is mounted on a roof curb and electrical
power will be run up “thru-the-bottom,” be sure to use the proper
connection kit listed in Fig. 1. This kit, available from your local
distributor, ensures a reliable watertight connection. Refer to the
thru-the-bottom accessory installation instructions for information
on wiring the unit.
50HJQ,HEQ

6
C06006
Fig. 6 --- 50HJQ Base Unit Dimensions
50HJQ,HEQ

7
C06058
Fig. 7 --- 50HEQ Base Unit Dimensions
50HJQ,HEQ

8
Table 1—Physical Data 50HJQ004--007
50HJQ UNIT SIZE 004 005 006 007
NOMINAL CAPACITY (tons) 3 4 5 6
OPERATING WEIGHT (lb)
Unit 550 560 630 630
EconoMi$er IV 50 50 50 50
Roof Curb 115 115 115 115
COMPRESSOR Scroll
Quantity 1 1 1 1
Oil (oz) 42 42 53 80
REFRIGERANT TYPE R-22
Operating Charge (lb) 12.0 12.0 18.3 17.7
OUTDOOR FAN Propeller Type
Quantity...Diameter (in.) 1...22 1...22 1...22 1...22
Nominal Cfm 3500 3500 3500 3500
Motor Hp...Rpm 1/8...825 1/8...825 1/4...1100 1/4...1100
OUTDOOR COIL Enhanced Copper Tubes, Aluminum Fins, Acutrol™Metering Device
Rows...Fins/in. 2...17 2...17 2...17 2...17
To t a l F a c e A r e a ( s q f t ) 16.53 16.53 21.25 21.25
INDOOR FAN Centrifugal Type
Quantity...Size (in.) Std 1...10 x 10 1...10 x 10 1...10 x 10 1...10 x 10
High-Static 1...10 x 10 1...10 x 10 1...10 x 10 1...10 x 10
Ty p e D r i ve Std Belt Belt Belt Belt
High-Static Belt Belt Belt Belt
Nominal Cfm 1200 1600 2000 2400
Maximum Continuous Bhp Std 1.20 1.20 1.30/2.40* 2.40
High-Static 2.40 2.40 2.90 2.90
Motor Frame Size Std 48 48 56 56
High-Static 56 56 56 56
Nominal Rpm High/Low Std 1620 1620 1725 —
High-Static 1725 1725 1725 1725
Fan Rpm Range Std 680-1044 770-1185 1035-1460 1119-1585
High-Static 1075-1455 1075-1455 1300-1685 1300-1685
Motor Bearing Type Ball Ball Ball Ball
Maximum Allowable Rpm 2100 2100 2100 2100
Motor Pulley Pitch Diameter Min/Max (in.) Std 1.9/2.9 1.9/2.9 2.4/3.4 2.4/3.4
High-Static 2.8/3.8 2.8/3.8 3.4/4.4 3.4/4.4
Nominal Motor Shaft Diameter (in.) Std 1/21/25/85/8
High-Static 5/85/85/85/8
Fan Pulley Pitch Diameter (in.) Std 4.5 4.0 4.5 3.7
High-Static 4.5 4.5 4.5 4.5
Belt, Quantity...Type...Length (in.) Std 1...A...34 1...A...34 1...A...39 1...A...40
High-Static 1...A...39 1...A...39 1...A...40 1...A...40
Pulley Center Line Distance (in.) Std 10.0-12.4 10.0-12.4 14.7-15.5 14.7-15.5
High-Static 10.0-12.4 10.0-12.4 14.7-15.5 14.7-15.5
Speed Change per Full Turn of
Movable Pulley Flange (rpm)
Std 48 70 80 80
High-Static 65 65 60 60
Movable Pulley Maximum Full Turns
From Closed Position
Std 5 5 6 5
High-Static 6 6 5 5
Factory Setting Std 3 3 3 3
High-Static 31/231/231/231/2
Factory Speed Setting (rpm) Std 826 936 1214 1259
High-Static 1265 1265 1416 1416
Fan Shaft Diameter at Pulley (in.) 5/85/85/85/8
INDOOR COIL Enhanced Copper Tubes, Aluminum Double-Wavy Fins, Acutrol Metering Device
Rows...Fins/in. 2...15 3...15 4...15 4...15
To t a l F a c e A r e a ( s q f t ) 5.5 5.5 7.33 7.33
HIGH-PRESSURE SWITCH (psig)
Standard Compressor Internal Relief 625
Cutout 428
Reset (Auto.) 320
LOSS OF CHARGE
(Liquid Line) (psig)
Cutout 7±3
Reset (Auto.) 22 ±5
FREEZE PROTECTION THERMOSTAT
Opens (F) 30
Closes (F) 45
OUTDOOR-AIR INLET SCREENS Cleanable.
Screen quantity and size varies with option selected.
RETURN-AIR FILTERS Throwaway
Quantity...Size (in.) 2...16 x 25 x 2
BHP --- Brake Horsepower
* Single phase/three phase
50HJQ,HEQ

9
Table 2—Physical Data 50HEQ003--006
50HEQ UNIT SIZE 003 004 005 006
NOMINAL CAPACITY (tons) 23 4 5
OPERATING WEIGHT (lb)
Unit 550 550 560 630
EconoMi$er IV 50 50 50 50
Roof Curb 115 115 115 115
COMPRESSOR Scroll
Quantity 11 1 1
Oil (oz) 80 42 42 53
REFRIGERANT TYPE R-22
Operating Charge (lb) 5.2 12.0 12.0 18.3
OUTDOOR FAN Propeller Type
Quantity...Diameter (in.) 1...22 1...22 1...22 1...22
Nominal Cfm 3000 3500 3500 3500
Motor Hp...Rpm 1/8...760 1/8...825 1/8...825 1/4...1100
OUTDOOR COIL Enhanced Copper Tubes, Aluminum Fins, AcutroltMetering Device
Rows...Fins/in. 1...17 2...17 2...17 2...17
To t a l F a c e A r e a ( s q f t ) 14.58 16.53 16.53 21.25
INDOOR FAN Centrifugal Type
Quantity...Size (in.) Std 1...10 x 10 1...10 x 10 1...10 x 10 1...10 x 10
High-Static --- 1...10 x 10 1...10 x 10 1...10 x 10
Ty p e D r i ve Std Belt Belt Belt Belt
High-Static --- Belt Belt Belt
Nominal Cfm 800 1200 1600 2000
Maximum Continuous Bhp Std .58 1.20 1.20 1.30/2.40*
High-Static --- 2.40 2.40 2.90
Motor Frame Size Std 39 48 48 56
High-Static --- 56 56 56
Nominal Rpm High/Low Std 1620 1620 1620 1725
High-Static --- 1725 1725 1725
Fan Rpm Range Std 639--- 936 680-1044 770-1185 1035-1460
High-Static --- 1075-1455 1075-1455 1300-1685
Motor Bearing Type Ball Ball Ball Ball
Maximum Allowable Rpm 2100 2100 2100 2100
Motor Pulley Pitch Diameter Min/Max (in.) Std 1.9/2.9 1.9/2.9 1.9/2.9 2.4/3.4
High-Static --- 2.8/3.8 2.8/3.8 3.4/4.4
Nominal Motor Shaft Diameter (in.) Std 1/2 1/21/25/8
High-Static --- 5/85/85/8
Fan Pulley Pitch Diameter (in.) Std 5.2 4.5 4.0 4.5
High-Static --- 4.5 4.5 4.5
Belt, Quantity...Type...Length (in.) Std 1...A...36 1...A...34 1...A...34 1...A...39
High-Static --- 1...A...39 1...A...39 1...A...40
Pulley Center Line Distance (in.) Std 10.0---12.4 10.0-12.4 10.0-12.4 14.7-15.5
High-Static --- 10.0-12.4 10.0-12.4 14.7-15.5
Speed Change per Full Turn of
Movable Pulley Flange (rpm)
Std 60 48 70 80
High-Static --- 65 65 60
Movable Pulley Maximum Full Turns
From Closed Position
Std 5 5 5 6
High-Static --- 6 6 5
Factory Setting Std 3 3 3 3
High-Static --- 31/231/231/2
Factory Speed Setting (rpm) Std 756 826 936 1249
High-Static --- 1233 1233 1416
Fan Shaft Diameter at Pulley (in.) 5/85/85/85/8
INDOOR COIL Enhanced Copper Tubes, Aluminum Double---Wavy Fins, AcutroltMetering Device
Rows...Fins/in. 2...15 2...15 3...15 4...15
To t a l F a c e A r e a ( s q f t ) 5.5 5.5 5.5 7.33
HIGH-PRESSURE SWITCH (psig)
Standard Compressor Internal Relief 625
Cutout 428
Reset (Auto.) 320
LOSS OF CHARGE
(Liquid Line) (psig)
Cutout 7±3
Reset (Auto.) 22 ±5
FREEZE PROTECTION THERMOSTAT
Opens (F) 30
Closes (F) 45
OUTDOOR -- AIR INLET SCREENS Cleanable
Screen quantity and size varies with option selected
RETURN-AIR FILTERS Throwaway
Quantity...Size (in.) 2...16 x 25 x 2
BHP --- Brake Horsepower
* Single phase/three phase
50HJQ,HEQ

10
Table 3—Electric Heating Capacities
UNIT SIZE VOLTAGE
(60 Hz)
ACCESSORY
(kW)
ACCESSORY HEATER
PART NUMBER
C R H E A T E R --- --- A 0 0
( o r --- --- B 0 0 w h e r e i n d i c a t e d )
SINGLE POINT BOX
PACKAGE NO.
C R S I N G L E --- --- A 0 0
003
(2 Tons)
208/230
(single phase)
3.3/4.4
4.9/6.5
6.5/8.7
7.9/10.5
001
002
003B00
004B00
--- ---
--- ---
004
004
004
(3 Tons)
208/230/240
(single phase)
3.3/ 4.0/ 4.4
4.9/ 5.8/ 6.5
6.5/ 8.0/ 8.7
7.9/ 9.6/10.5
9.8/11.6/13.0*
001
002
003B00
004B00
002 & 002
--- ---
--- ---
004
004
005
208/230/240
(3 phase)
3.3/ 4.0/ 4.4
4.9/ 5.8/ 6.5
6.5/ 8.0/ 8.7
7.9/ 9.6/10.5
12.0/14.7/16.0
001
002
003B00
004B00
005
--- ---
--- ---
--- ---
--- ---
002
460/480
(3 phase)
5.5/ 6.0
8.1/ 8.8
10.6/11.5
12.9/14.0
006
007
008
009
--- ---
--- ---
--- ---
--- ---
005
(4 Tons)
208/230/240
(single phase)
3.3/ 4.0/ 4.4
6.5/ 8.0/ 8.7
9.8/11.6/13.0*
13.1/16.0/17.4*
15.8/19.3/21.0*
001
003B00
002 & 002
003B00 & 003B00
004B00 & 004B00**
--- ---
004
005
005
005
208/230/240
(3 phase)
4.9/ 5.8/ 6.5
6.5/ 8.0/ 8.7
12.0/14.7/16.0
15.8/19.3/21.0*
002
003
005
004B00 & 004B00**
--- ---
--- ---
002
003
460/480
(3 phase)
5.5/ 6.0
10.6/11.5
12.9/14.0
21.1/23.0*
006
008
009
008 & 008
--- ---
--- ---
--- ---
--- ---
006
(5 Tons)
208/230/240
(single phase)
4.9/ 5.8/ 6.5
6.5/ 8.0/ 8.7
9.8/11.6/13.0*
13.1/16.0/17.4*
15.8/19.3/21.0*
002
003B00
002 & 002
003B00 & 003B00
004B00 & 004B00
004
004
005
005
005
208/230/240
(3 phase)
4.9/ 5.8/ 6.5
7.9/ 9.6/10.5
12.0/14.7/16.0
15.8/19.3/21.0*
19.9/24.3/26.5*
002
004B00
005
004B00 & 004B00
004 & 005
--- ---
002
002
003
002
460/480
(3 phase)
5.5/ 6.0
10.6/11.5
12.9/14.0
21.1/23.0*
23.4/25.5*
006
008
009
008 & 008
008 & 009
--- ---
--- ---
--- ---
--- ---
--- ---
007
(6 Tons)
208/230/240
(3 phase)
4.9/ 5.8/ 6.5
7.9/ 9.6/10.5
12.0/14.7/16.0
15.8/19.3/21.0*
19.9/24.3/26.5*
002
004B00
005
004B00 & 004B00
004B00 & 006
--- ---
002
002
003
003
460/480
(3 phase)
5.5/ 6.0
10.6/11.5
12.9/14.0
21.1/23.0*
23.4/25.5*
006
008
009
008 & 008
008 & 009
--- ---
--- ---
--- ---
--- ---
--- ---
*Two heater packages required to provide kW indicated.
** Minimum airflow is 350 cfm/ton (1400 cfm) when two CRHEATER004B00 heaters are installed on a 4 ton, 230v heat pump.
NOTES:
1. The rated heater voltage is 240 and 480 v. If power distribution voltage varies from rated heater voltage, heater kW will vary accordingly.
2. To determine heater kW at voltages other than those shown in table, use the following formula:
Heater kWnew = Heater kW rated x (unit power distribution voltage/rated heater voltage)2
As an example:
For a 16 kW heater rated at 240 v with a power distribution voltage of 215 v
kWnew = 16 kW (215/240)2
kWnew = 12.8 kW (rating at 215 v)
50HJQ,HEQ

11
Table 4A — 50HJQ Electrical Data — Standard Motor Units Without Electrical Convenience Outlet
UNIT
SIZE
NOMINAL
VOLTAGE
V-PH-Hz
VOLTAGE
RANGE COMPRESSOR OFM IFM ELECTRIC HEAT*
POWER
SUPPLY
MINIMUM UNIT
DISCONNECT
SIZE
Min Max RLA LRA FLA FLA kW† FLA MCA MOCP** FLA LRA
004
(3 Tons)
208/230-1-60 187 254 16.0 88.0 0.7 4.9
—/— —/— 25.6/ 25.6 30/ 30 25/ 25 101/101
3.3/ 4.4 15.9/18.3 45.5/ 48.5 50/ 50 43/ 46 117/120
4.9/ 6.5 23.6/27.1 55.1/ 59.5 60/ 60 52/ 56 125/128
6.5/ 8.7 31.3/36.3 64.7/ 71.0 70/ 80 61/ 67 133/138
7.9/10.5 38.0/43.8 73.1/ 80.4 80/ 90 69/ 75 139/145
9.8/13.0 47.1/54.2 84.5/ 93.4 90/100 79/ 87 148/155††
208/230-3-60 187 254 10.3 77.0 0.7 4.9
—/— —/— 18.5/ 18.5 20/20 18/ 18 90/ 90
3.3/ 4.4 9.2/10.6 30.0/ 31.7 30/35 29/ 30 99/101
4.9/ 6.5 13.6/15.6 35.5/ 38.0 40/40 34/ 36 104/106
6.5/ 8.7 18.0/20.9 41.0/ 44.6 45/45 39/ 42 108/111
7.9/10.5 21.9/25.3 45.9/ 50.1 50/60 43/ 47 112/116
12.0/16.0 33.3/38.5 60.1/ 66.6 70/70 57/ 63 124/129
460-3-60 414 508 5.1 39.0 0.4 2.2
— — 9.0 15 946
6.0 7.2 18.0 20 17 53
8.8 10.6 22.2 25 21 57
11.5 13.8 26.2 30 25 60
14.0 16.8 30.0 30 28 63
005
(4 Tons)
208/230-1-60 187 254 18.3 109.0 0.7 4.9
—/— —/— 28.5/ 28.5 30/ 30 27/ 27 122/122
3.3/ 4.4 15.9/18.3 48.4/ 51.4 50/ 60 46/ 49 138/141
6.5/ 8.7 31.3/36.3 67.6/ 73.9 70/ 80 63/ 69 154/159
9.8/13.0 47.1/54.2 87.4/ 96.2 90/100 82/ 90 169/176††
13.1/17.4 63.0/72.5 107.2/119.1 110/125 100/111 185/195††
15.8/21.0 76.0/87.5 123.5/137.9 125/150 115/128 198/210††
208/230-3-60 187 254 12.4 88.0 0.7 4.9
—/— —/— 21.1/21.1 25/25 21/ 21 101/101
4.9/ 6.5 13.6/15.6 38.1/40.6 40/45 36/ 39 115/117
6.5/ 8.7 18.0/20.9 43.6/47.2 45/50 41/ 45 119/122
12.0/16.0 33.3/38.5 62.7/69.2 70/70 59/ 65 135/140
15.8/21.0 43.9/50.5 76.0/84.2 80/90 71/ 79 145/152
460-3-60 414 508 6.4 44.0 0.4 2.2
— — 10.6 15 10 51
6.0 7.2 19.6 20 19 58
11.5 13.8 27.9 30 26 65
14.0 16.8 31.6 35 30 68
23.0 27.7 45.2 50 42 79
006
(5 Tons)
208/230-1-60 187 254 25.0 150.0 1.5 7.6
—/— —40.4/ 40.4 45/ 45 39/ 39 188/188
4.9/ 6.5 23.6/27.1 69.9/ 74.2 70/ 80 66/ 70 211/215
6.5/ 8.7 31.3/36.3 79.5/ 85.7 80/ 90 75/ 81 219/224††
9.8/16.0 47.1/54.2 99.2/108.1 100/110 93/102 235/242††
13.1/17.4 63.0/72.5 119.1/131.0 125/150 112/123 251/260††
15.8/21.0 76.0/87.5 135.4/149.7 150/150 127/140 264/275††
208/230-3-60 187 254 17.3 123.0 1.5 5.8
—/— —/— 28.9/ 28.9 30/ 30 28/ 28 168/168
4.9/ 6.5 13.6/15.6 45.9/ 48.4 50/ 50 44/ 46 181/183
7.9/10.5 21.9/25.3 56.3/ 60.6 60/ 70 53/ 57 190/193
12.0/16.0 33.3/38.5 70.6/ 77.1 80/ 80 67/ 73 201/208
15.8/21.0 43.9/50.5 83.8/ 92.1 90/100 79/ 86 212/218††
19.9/26.5 55.2/63.8 97.9/108.7 100/110 92/102 223/232††
460-3-60 414 508 9.0 62.0 0.8 2.6
— — 13.9 15 14 92
6.0 7.2 22.9 25 22 100
11.5 13.8 31.2 35 29 106
14.0 16.8 34.9 35 33 109
23.0 27.7 48.5 50 45 120
25.5 30.7 51.5 60 48 123
007
(6 Tons)
208/230-3-60 187 254 20.5 156.0 1.4 5.8
—/— —/— 32.8/ 32.8 35/ 35 32/ 32 200/200
4.9/ 6.5 13.6/15.6 49.8/ 52.3 50/ 60 47/ 50 214/216
7.9/10.5 21.9/25.3 60.2/ 64.5 70/ 70 57/ 61 222/225
12.0/16.0 33.3/38.5 74.5/ 81.0 80/ 90 70/ 76 233/239
15.8/21.0 43.9/50.5 87.7/ 96.0 90/100 82/ 90 244/251††
19.9/26.5 55.2/63.8 101.8/112.6 110/125 95/105 255/264††
460-3-60 414 508 9.6 70.0 0.6 2.6
— — 15.2 20 15 92
6.0 7.2 24.2 25 23 99
11.5 13.8 32.5 35 31 106
14.0 16.8 36.2 40 34 109
23.0 27.7 49.8 50 47 120
25.5 30.7 53.6 60 50 123
See Legend on page 15
50HJQ,HEQ

12
Table 4B — 50HJQ Electrical Data — High-Static Motor Units Without Electrical Convenience Outlet
UNIT SIZE
NOMINAL
VOLTAGE
V-PH-Hz
VOLTAGE
RANGE COMPRESSOR OFM IFM ELECTRIC HEAT*
POWER
SUPPLY
MINIMUM UNIT
DISCONNECT
SIZE
Min Max RLA LRA FLA FLA kW† FLA MCA MOCP** FLA LRA
004
(3 Tons)
208/230-3-60 187 254 10.3 77.0 0.7 5.8
—/— —/— 19.4/ 19.4 20/20 19/ 19 120/120
3.3/ 4.4 9.2/10.6 30.9/ 32.6 35/35 30/ 32 129/130
4.9/ 6.5 13.6/15.6 36.4/ 38.9 40/40 35/ 37 133/135
6.5/ 8.7 18.0/20.9 41.9/ 45.5 45/50 40/ 43 138/141
7.9/10.5 21.9/25.3 46.8/ 51.0 50/60 45/ 48 142/145
12.0/16.0 33.3/38.5 61.0/ 67.5 70/70 58/ 64 153/158
460-3-60 414 508 5.1 39.0 0.4 2.6
— — 9.4 15 960
6.0 7.2 18.4 20 18 68
8.8 10.6 22.6 25 22 71
11.5 13.8 26.6 30 25 74
14.0 16.8 30.4 35 29 77
005
(4 Tons)
208/230-3-60 187 254 12.4 88.0 0.7 5.8
—/— —/— 22.0/ 22.0 25/ 25 22/ 22 131/131
4.9/ 6.5 13.6/15.6 39.0/ 41.5 40/ 45 37/ 40 144/146
6.5/ 8.7 18.0/20.9 44.5/ 48.1 45/ 50 42/ 46 149/152
12.0/16.0 33.3/38.5 63.6/ 70.1 70/ 80 60/ 66 164/169
15.8/21.0 43.9/50.5 76.9/ 85.1 80/ 90 72/ 80 175/181††
460-3-60 414 508 6.4 44.0 0.4 2.6
— — 11.0 15 11 65
6.0 7.2 20.0 20 19 73
11.5 13.8 28.3 30 27 79
14.0 16.8 32.0 35 30 82
23.0 27.7 45.6 50 43 93
006
(5 Tons)
208/230-3-60 187 254 17.3 123.0 1.5 7.5
—/— —/— 30.6/ 30.6 35/ 35 30/ 30 187/187
4.9/ 6.5 13.6/15.6 47.6/ 50.1 50/ 60 46/ 48 200/202
7.9/10.5 21.9/25.3 58.0/ 62.3 60/ 70 55/ 59 209/212
12.0/16.0 33.3/38.5 72.3/ 78.8 80/ 80 69/ 75 220/225
15.8/21.0 43.9/50.5 85.5/ 93.8 90/100 81/ 88 231/237**
19.9/26.5 55.2/63.8 99.6/110.4 100/125 94/104 242/251**
460-3-60 414 508 8.4 70.0 0.8 3.4
— — 14.7 15 14 102
6.0 7.2 23.7 25 23 109
11.5 13.8 32.0 35 30 116
14.0 16.8 35.7 40 34 119
23.0 27.7 49.3 50 46 130
25.5 30.7 52.3 60 49 132
007
(6 Tons)
208/230-3-60 187 254 20.5 156.0 1.4 7.5
—/— —/— 34.5/ 34.5 35/ 35 34/ 34 219/219
4.9/ 6.5 13.6/15.6 51.5/ 54.0 60/ 60 49/ 52 233/235
7.9/10.5 21.9/25.3 61.9/ 66.2 70/ 70 59/ 63 241/244
12.0/16.0 33.3/38.5 76.2/ 82.7 80/ 90 72/ 78 252/258
15.8/21.0 43.9/50.5 89.4/ 97.7 90/100 84/ 92 263/270**
19.9/26.5 55.2/63.8 103.5/114.3 110/125 97/107 274/283**
460-3-60 414 508 9.6 70.0 0.6 3.4
— — 16.0 20 16 107
6.0 7.2 25.0 25 24 114
11.5 13.8 33.3 35 32 120
14.0 16.8 37.0 40 35 123
23.0 27.7 50.6 60 47 134
25.5 30.7 54.4 60 51 137
See Legend on page 15
50HJQ,HEQ

13
Table 4C — 50HJQ Electrical Data — Standard Motor Units With Electrical Convenience Outlet
UNIT SIZE
NOMINAL
VOLTAGE
V-PH-Hz
VOLTAGE
RANGE COMPRESSOR OFM IFM ELECTRIC HEAT*
POWER
SUPPLY
MINIMUM UNIT
DISCONNECT
SIZE
Min Max RLA LRA FLA FLA kW† FLA MCA MOCP** FLA LRA
004
(3 Tons)
208/230-1-60 187 254 16.0 88.0 0.7 4.9
—/— — 30.4/ 30.4 35/ 35 30/ 30 106/106
3.3/ 4.4 15.9/18.3 50.3/ 53.3 60/ 60 49/ 51 122/124
4.9/ 6.5 23.6/27.1 59.9/ 64.3 60/ 70 58/ 62 130/133
6.5/ 8.7 31.3/36.3 69.5/ 75.8 70/ 80 66/ 72 137/142
7.9/10.5 38.0/43.8 77.9/ 85.2 80/ 90 74/ 81 144/150††
9.8/13.0 47.1/54.2 89.3/ 98.2 90/100 85/ 93 153/160††
208/230-3-60 187 254 10.3 77.0 0.7 4.9
—/— —/— 23.3/ 23.3 25/ 25 24/ 24 95/ 95
3.3/ 4.4 9.2/10.6 34.8/ 36.5 35/ 40 34/ 36 104/106
4.9/ 6.5 13.6/15.6 40.3/ 42.8 45/ 45 39/ 42 109/111
6.5/ 8.7 18.0/20.9 45.8/ 49.4 50/ 50 45/ 48 113/116
7.9/10.5 21.9/25.3 50.7/ 54.9 60/ 60 49/ 53 117/120
12.0/16.0 33.3/38.5 64.9/ 71.4 70/ 80 62/ 68 128/134
460-3-60 414 508 5.1 39.0 0.4 2.2
— — 11.2 15 11 48
6.0 7.2 20.2 25 20 55
8.8 10.6 24.4 25 24 59
11.5 13.8 28.4 30 27 62
14.0 16.8 32.2 35 31 65
005
(4 Tons)
208/230-1-60 187 254 18.3 109.0 0.7 4.9
—/— —/— 33.3/ 33.0 35/ 35 33/ 33 127/127
3.3/ 4.4 15.9/18.3 53.2/ 56.2 60/ 60 51/ 54 143/145
6.5/ 8.7 31.3/36.3 72.4/ 78.7 80/ 80 69/ 75 158/163††
9.8/13.0 47.1/54.2 92.2/101.0 100/110 87/ 95 174/181††
13.1/17.4 63.0/72.5 112.0/123.9 125/125 105/116 190/200††
15.8/21.0 76.0/87.5 128.3/142.7 150/150 120/134 203/215††
208/230-3-60 187 254 12.4 88.0 0.7 4.9
—/— —/— 25.9/ 25.9 30/ 30 26/ 26 106/106
4.9/ 6.5 13.6/15.6 42.9/ 45.4 45/ 50 42/ 44 120/122
6.5/ 8.7 18.0/20.9 48.4/ 52.0 50/ 60 47/ 50 124/127
12.0/16.0 33.3/38.5 67.5/ 74.0 70/ 80 65/ 71 139/145
15.8/21.0 43.9/50.5 80.8/ 89.0 90/ 90 77/ 84 150/157††
460-3-60 414 508 6.4 44.0 0.4 2.2
— — 12.8 15 13 53
6.0 7.2 21.8 25 21 60
11.5 13.8 30.0 35 29 67
14.0 16.8 33.8 35 32 70
23.0 27.7 47.4 50 45 81
006
(5 Tons)
208/230-1-60 187 254 25.0 150.0 1.5 7.6
—/— — 45.2/ 45.2 50/ 50 45/ 45 193/193
4.9/ 6.5 23.6/27.1 74.7/ 79.0 80/ 80 72/ 76 216/220††
6.5/ 8.7 31.3/36.3 84.3/ 90.5 90/100 81/ 86 224/229††
9.8/16.0 47.1/54.2 104.0/112.9 110/125 99/107 240/247††
13.1/17.4 63.0/72.5 123.9/135.8 125/150 117/128 256/265††
15.8/21.0 76.0/87.5 140.2/154.5 150/175 132/145 269/280††
208/230-3-60 187 254 17.3 123.0 1.5 5.8
—/— —/— 33.7/ 33.7 35/ 35 34/ 34 173/173
4.9/ 6.5 13.6/15.6 50.7/ 53.2 60/ 60 49/ 52 186/188
7.9/10.5 21.9/25.3 61.1/ 65.4 70/ 70 59/ 63 194/198
12.0/16.0 33.3/38.5 75.4/ 81.9 80/ 90 72/ 78 206/211
15.8/21.0 43.9/50.5 88.6/ 96.9 90/100 84/ 92 216/223††
19.9/26.5 55.2/63.8 102.7/113.5 110/125 97/107 228/236††
460-3-60 414 508 9.0 62.0 0.8 2.6
— — 16.1 20 16 95
6.0 7.2 25.1 30 24 102
11.5 13.8 33.3 35 32 108
14.0 16.8 37.1 40 35 111
23.0 27.7 50.7 60 48 122
25.5 30.7 53.7 60 51 125
007
(6 Tons)
208/230-3-60 187 254 20.5 156.0 1.4 5.8
—/— —/— 37.6/ 37.6 40/ 40 37/ 37 205/205
4.9/ 6.5 13.6/15.6 54.6/ 57.1 60/ 60 53/ 55 219/221
7.9/10.5 21.9/25.3 65.0/ 69.3 70/ 70 63/ 66 227/230
12.0/16.0 33.3/38.5 79.3/ 85.8 80/ 90 76/ 82 238/243††
15.8/21.0 43.9/50.5 92.5/100.8 100/110 88/ 95 249/255††
19.9/26.5 55.2/63.8 106.6/117.4 110/125 101/111 260/269††
460-3-60 414 508 9.6 70.0 0.6 2.6
— — 17.4 20 17 99
6.0 7.2 26.4 30 26 106
11.5 13.8 34.6 35 33 113
14.0 16.8 38.4 40 37 116
23.0 27.7 52.0 60 49 127
25.5 30.7 55.8 60 53 130
50HJQ,HEQ

14
Table 4D — 50HJQ Electrical Data — High-Static Motor Units With Electrical Convenience Outlet
UNIT SIZE
NOMINAL
VOLTAGE
V-PH-Hz
VOLTAGE
RANGE COMPRESSOR OFM IFM ELECTRIC HEAT*
POWER
SUPPLY
MINIMUM UNIT
DISCONNECT
SIZE
Min Max RLA LRA FLA FLA kW† FLA MCA MOCP** FLA LRA
004
(3 Tons)
208/230-3-60 187 254 10.3 77.0 0.7 5.8
—/— —/— 24.2/ 24.2 25/ 25 25/ 25 124/124
3.3/ 4.4 9.2/10.6 35.7/ 37.4 40/ 40 35/ 37 134/135
4.9/ 6.5 13.6/15.6 41.2/ 43.7 45/ 45 40/ 43 138/140
6.5/ 8.7 18.0/20.9 46.7/ 50.3 50/ 60 46/ 49 142/145
7.9/10.5 21.9/25.3 51.6/ 55.8 60/ 60 50/ 54 146/150
12.0/16.0 33.3/38.5 65.8/ 72.3 70/ 80 63/ 69 158/163
460-3-60 414 508 5.1 39.0 0.4 2.6
— — 11.6 15 12 63
6.0 7.2 20.6 25 20 70
8.8 10.6 24.8 25 24 73
11.5 13.8 28.8 30 28 76
14.0 16.8 33.6 35 31 79
005
(4 Tons)
208/230-3-60 187 254 12.4 88.0 0.7 5.8
—/— —/— 26.8/ 26.8 30/ 30 27/ 27 135/135
4.9/ 6.5 13.6/15.6 43.8/ 46.3 45/ 50 43/ 45 149/151
6.5/ 8.7 18.0/20.9 49.3/ 52.9 50/ 60 48/ 51 153/156
12.0/16.0 33.3/38.5 68.4/ 74.9 70/ 80 66/ 72 169/174
15.8/21.0 43.9/50.5 81.7/ 89.9 90/ 90 78/ 85 179/186††
460-3-60 414 508 6.4 44.0 0.4 2.6
— — 13.2 15 13 68
6.0 7.2 22.2 25 22 75
11.5 13.8 28.9 30 28 80
14.0 16.8 34.2 35 33 84
23.0 27.7 47.8 50 45 95
006
(5 Tons)
208/230-3-60 187 254 17.3 123.0 1.5 7.5
—/— —/— 35.4/ 35.4 40/ 40 36/ 36 192/192
4.9/ 6.5 13.6/15.6 52.4/ 54.9 60/ 60 51/ 54 205/207
7.9/10.5 21.9/25.3 62.8/ 67.1 70/ 70 61/ 65 213/217
12.0/16.0 33.3/38.5 77.1/ 83.6 80/ 90 74/ 80 225/230††
15.8/21.0 43.9/50.5 90.3/ 98.6 100/100 86/ 94 235/242††
19.9/26.5 55.2/63.8 104.4/115.2 110/125 99/109 247/255††
460-3-60 414 508 8.4 70.0 0.8 3.4
— — 16.9 20 17 104
6.0 7.2 25.9 30 25 111
11.5 13.8 34.1 35 33 118
14.0 16.8 37.9 40 36 121
23.0 27.7 51.5 60 49 132
25.5 30.7 54.5 60 52 134
007
(6 Tons)
208/230-3-60 187 254 20.5 156.0 1.4 7.5
—/— —/— 39.3/ 39.3 40/ 40 39/ 39 224/224
4.9/ 6.5 13.6/15.6 56.3/ 58.8 60/ 60 55/ 57 238/240
7.9/10.5 21.9/25.3 66.7/ 71.0 70/ 80 65/ 68 246/249
12.0/16.0 33.3/38.5 81.0/ 87.5 90/ 90 78/ 84 257/262††
15.8/21.0 43.9/50.5 94.2/102.5 100/110 90/ 97 268/274††
19.9/26.5 55.2/63.8 108.3/119.1 110/125 103/113 279/288††
460-3-60 414 508 9.6 70.0 0.6 3.4
— — 18.2 20 18 109
6.0 7.2 27.2 30 26 116
11.5 13.8 35.4 40 34 123
14.0 16.8 39.2 40 37 126
23.0 27.7 52.8 60 50 136
25.5 30.7 56.6 60 53 139
See Legend on page 15
50HJQ,HEQ

15
LEGEND
F L A --- Fu l l L o a d A m ps
HACR --- Heating, Air Conditioning and Refrigeration
IFM --- Indoor---Fan Motor
LRA --- Locked Rotor Amps
MCA --- Minimum Circuit Amps
MOCP --- Maximum Overcurrent Protection
NEC --- National Electrical Code
OFM --- Outdoor---Fan Motor
RLA --- Rated Load Amps
*Heater capacity (kW) is based on heater voltage of 208 v, 240 v, or 480 v.
If power distribution voltage to unit varies from rated heater voltage,
heater kW will vary accordingly.
†Heaters are field installed only.
**Fuse or HACR circuit breaker.
††Electrical disconnect cannot be used if electric heater is installed.
NOTES:
1. In compliance with NEC requirements for multimotor and combina-
tion load equipment (refer to NEC Articles 430 and 440), the overcur-
rent protective device for the unit shall be fuse or HACR breaker.
2. Unbalanced 3-Phase Supply Voltage
Never operate a motor where a phase imbalance in supply voltage is
greater than 2%. Use the following formula to determine the percent-
age of voltage imbalance.
%VoltageImbalance
= 100 x max voltage deviation from average voltage
average voltage
Example: Supply voltage is 460-3-60
AB = 452 v
BC = 464 v
AC = 455 v
Average Voltage
=
452 + 464 + 455
3
=1371
3
=457
Determine maximum deviation from average voltage.
(AB) 457 – 452 = 5 v
(BC) 464 – 457 = 7 v
(AC) 457 – 455 = 2 v
Maximum deviation is 7 v.
Determine percent of voltage imbalance.
% Voltage Imbalance = 100 x 7
457
= 1.53%
This amount of phase imbalance is satisfactory as it is below the maxi-
mum allowable 2%.
IMPORTANT: If the supply voltage phase imbalance is more
than 2%,contact your local electric utility company immediately.
50HJQ,HEQ

16
Table 5A — 50HEQ Electrical Data — Standard Motor Units Without Electrical Convenience Outlet
UNIT SIZE
NOMINAL
VOLTAGE
V-PH-Hz
VOLTAGE
RANGE COMPRESSOR OFM IFM ELECTRIC HEAT*
POWER
SUPPLY
MINIMUM UNIT
DISCONNECT
SIZE
Min Max RLA LRA FLA FLA kW† FLA MCA MOCP FLA LRA
003
(3 Tons) 208/230-1-60 187 254 10.9 63.0 0.7 2.0
—/— —/— 16.3/ 16.3 20/ 20** 16/ 16 69/69
3.3/ 4.4 15.9/18.3 36.2/ 39.2 40/ 40** 34/ 37 84/87
4.9/ 6.5 23.6/27.1 45.8/ 50.2 50/ 60** 43/ 47 92/96
6.5/ 8.7 31.3/36.3 55.5/ 61.7 60/ 70 52/ 57 100/105
7.9/10.5 38.0/43.8 63.8/ 71.1 70/ 80 59/ 66 107/112
004
(3 Tons)
208/230-1-60 187 254 16.0 88.0 0.7 4.9
—/— —/— 25.6/ 25.6 30/ 30** 25/ 25 101/101
3.3/ 4.4 15.9/18.3 45.5/ 48.5 50/ 50** 43/ 46 117/120
4.9/ 6.5 23.6/27.1 55.1/ 59.5 60/ 60** 52/ 56 125/128
6.5/ 8.7 31.3/36.3 64.7/ 71.0 70/ 80 61/ 67 133/138
7.9/10.5 38.0/43.8 73.1/ 80.4 80/ 90 69/ 75 139/145
9.8/13.0 47.1/54.2 84.5/ 93.4 90/100 79/ 87 148/155††
208/230-3-60 187 254 10.3 77.0 0.7 4.9
—/— —/— 18.5/ 18.5 20/20** 18/ 18 90/ 90
3.3/ 4.4 9.2/10.6 30.0/ 31.7 30/35** 29/ 30 99/101
4.9/ 6.5 13.6/15.6 35.5/ 38.0 40/40** 34/ 36 104/106
6.5/ 8.7 18.0/20.9 41.0/ 44.6 45/45** 39/ 42 108/111
7.9/10.5 21.9/25.3 45.9/ 50.1 50/60** 43/ 47 112/116
12.0/16.0 33.3/38.5 60.1/ 66.6 70/70 57/ 63 124/129
460-3-60 414 508 5.1 39.0 0.4 2.2
— — 9.0 15** 946
6.0 7.2 18.0 20** 17 53
8.8 10.6 22.2 25** 21 57
11.5 13.8 26.2 30** 25 60
14.0 16.8 30.0 30** 28 63
005
(4 Tons)
208/230-1-60 197 254 21 115.0 0.7 4.9
—/— —/— 31.9/ 31.9 35/ 35** 31/ 31 128/128
3.3/ 4.4 15.9/18.3 51.7/ 54.7 60/ 60** 49/ 52 144/147
6.5/ 8.7 31.3/36.3 71.0/ 77.2 80/ 80 67/ 72 160/165
9.8/13.0 47.1/54.2 90.7/ 99.6 100/100 85/ 93 175/182††
13.1/17.4 63.0/72.5 110.6/122.5 125/125 103/114 191/201††
15.8/21.0 76.0/87.5 126.9/141.2 150/150 118/131 204/216††
208/230-3-60 187 254 14.1 95.0 0.7 4.9
—/— —/— 23.2/23.2 25/25** 23/ 23 108/108
4.9/ 6.5 13.6/15.6 40.2/42.7 45/45** 38/ 41 122/124
6.5/ 8.7 18.0/20.9 45.7/49.4 50/50** 43/ 47 126/129
12.0/16.0 33.3/38.5 64.9/71.4 70/80 61/ 67 142/147
15.8/21.0 43.9/50.5 78.1/86.4 80/90 73/ 81 152/159
460-3-60 414 508 7.1 45.0 0.4 2.2
— — 11.5 15** 11 52
6.0 7.2 20.5 25** 19 59
11.5 13.8 28.7 30** 27 66
14.0 16.8 32.5 35** 30 69
23.0 27.7 46.1 50** 43 80
006
(5 Tons)
208/230-1-60 187 254 25.0 150.0 1.5 7.6
—/— —40.4/ 40.4 45/ 45** 39/ 39 188/188
4.9/ 6.5 23.6/27.1 69.9/ 74.2 70/ 80 66/ 70 211/215
6.5/ 8.7 31.3/36.3 79.5/ 85.7 80/ 90 75/ 81 219/224††
9.8/16.0 47.1/54.2 99.2/108.1 100/110 93/102 235/242††
13.1/17.4 63.0/72.5 119.1/131.0 125/150 112/123 251/260††
15.8/21.0 76.0/87.5 135.4/149.7 150/150 127/140 264/275††
208/230-3-60 187 254 17.3 123.0 1.5 5.8
—/— —/— 28.9/ 28.9 30/ 30** 28/ 28 168/168
4.9/ 6.5 13.6/15.6 45.9/ 48.4 50/ 50** 44/ 46 181/183
7.9/10.5 21.9/25.3 56.3/ 60.6 60/ 70 53/ 57 190/193
12.0/16.0 33.3/38.5 70.6/ 77.1 80/ 80 67/ 73 201/206
15.8/21.0 43.9/50.5 83.8/ 92.1 90/100 79/ 86 212/218††
19.9/26.5 55.2/63.8 97.9/108.7 100/110 92/102 223/232††
460-3-60 414 508 8.4 70.0 0.8 2.6
— — 13.9 15** 14 92
6.0 7.2 22.9 25** 22 100
11.5 13.8 31.2 35** 29 106
14.0 16.8 34.9 35** 33 109
23.0 27.7 48.5 50** 45 120
25.0 30.1 51.5 60** 48 123
See Legend on page 20
50HJQ,HEQ

17
Table 5B — 50HEQ Electrical Data — High-Static Motor Units Without Electrical Convenience Outlet
UNIT
SIZE
NOMINAL
VOLTAGE
V-PH-Hz
VOLTAGE
RANGE COMPRESSOR OFM IFM ELECTRIC HEAT*
POWER
SUPPLY
MINIMUM UNIT
DISCONNECT
SIZE
Min Max RLA LRA FLA FLA kW† FLA MCA MOCP** FLA LRA
004
(3 Tons)
208/230-3-60 187 254 10.3 77.0 0.7 5.8
—/— —/— 19.4/ 19.4 20/20 19/ 19 120/120
3.3/ 4.4 9.2/10.6 30.9/ 32.6 35/35 30/ 32 129/130
4.9/ 6.5 13.6/15.6 36.4/ 38.9 40/40 35/ 37 133/135
6.5/ 8.7 18.0/20.9 41.9/ 45.5 45/50 40/ 43 138/141
7.9/10.5 21.9/25.3 46.8/ 51.0 50/60 45/ 48 142/145
12.0/16.0 33.3/38.5 61.0/ 67.5 70/70 58/ 64 153/158
460-3-60 414 508 5.1 39.0 0.4 2.6
— — 9.4 15 960
6.0 7.2 18.4 20 18 68
8.8 10.6 22.6 25 22 71
11.5 13.8 26.6 30 25 74
14.0 16.8 30.4 35 29 77
005
(4 Tons)
208/230-3-60 187 254 14.1 95.0 0.7 5.8
—/— —/— 24.1/ 24.1 25/ 25 24/ 24 138/138
4.9/ 6.5 13.6/15.6 41.1/ 43.6 45/ 45 39/ 42 151/153
6.5/ 8.7 18.0/20.9 46.6/ 50.3 50/ 60 44/ 48 159/159
12.0/16.0 33.3/38.5 65.8/ 72.3 70/ 80 62/ 68 171/176
15.8/21.0 43.9/50.5 79.0/ 87.3 80/ 90 74/ 82 182/188††
460-3-60 414 508 7.1 45.0 0.4 2.6
— — 11.9 15 12 66
6.0 7.2 20.9 25 20 74
11.5 13.8 29.1 30 27 80
14.0 16.8 32.9 35 31 83
23.0 27.7 46.5 50 43 94
006
(5 Tons)
208/230-3-60 187 254 17.3 123.0 1.5 7.5
—/— —/— 30.6/ 30.6 35/ 35 30/ 30 187/187
4.9/ 6.5 13.6/15.6 47.6/ 50.1 50/ 60 46/ 48 200/202
7.9/10.5 21.9/25.3 58.0/ 62.3 60/ 70 55/ 59 209/212
12.0/16.0 33.3/38.5 72.3/ 78.8 80/ 80 69/ 75 220/225
15.8/21.0 43.9/50.5 85.5/ 93.8 90/100 81/ 88 231/237**
19.9/26.5 55.2/63.8 99.6/110.4 100/125 94/104 242/251**
460-3-60 414 508 8.4 70.0 0.8 3.4
— — 14.7 15 14 102
6.0 7.2 23.7 25 23 109
11.5 13.8 32.0 35 30 116
14.0 16.8 35.7 40 34 119
23.0 27.7 49.3 50 46 130
25.5 30.1 52.3 60 49 132
See Legend on page 20
50HJQ,HEQ

18
Table 5C — 50HEQ Electrical Data — Standard Motor Units With Electrical Convenience Outlet
UNIT SIZE
NOMINAL
VOLTAGE
V-PH-Hz
VOLTAGE
RANGE COMPRESSOR OFM IFM ELECTRIC HEAT*
POWER
SUPPLY
MINIMUM UNIT
DISCONNECT
SIZE
Min Max RLA LRA FLA FLA kW† FLA MCA MOCP** FLA LRA
003
(3 Tons) 208/230-1-60 187 254 10.9 63.0 0.7 2.0
—/— — 21.1/ 21.1 25/ 25 21/ 21 73/73
3.3/ 4.4 15.9/18.3 41.0/ 44.0 45/ 45 39/ 42 89/92
4.9/ 6.5 23.6/27.1 50.6/ 55.0 60/ 60 48/ 52 97/100
6.5/ 8.7 31.3/36.3 60.3/ 66.5 70/ 70 57/ 63 105/110
7.9/10.5 38.0/43.8 68.6/ 75.9 70/ 80 65/ 72 111/117
004
(3 Tons)
208/230-1-60 187 254 16.0 88.0 0.7 4.9
—/— — 30.4/ 30.4 35/ 35 30/ 30 106/106
3.3/ 4.4 15.9/18.3 50.3/ 53.3 60/ 60 49/ 51 122/124
4.9/ 6.5 23.6/27.1 59.9/ 64.3 60/ 70 58/ 62 130/133
6.5/ 8.7 31.3/36.3 69.5/ 75.8 70/ 80 66/ 72 137/142
7.9/10.5 38.0/43.8 77.9/ 85.2 80/ 90 74/ 81 144/150††
9.8/13.0 47.1/54.2 89.3/ 98.2 90/100 85/ 93 153/160††
208/230-3-60 187 254 10.3 77.0 0.7 4.9
—/— —/— 23.3/ 23.3 25/ 25 24/ 24 95/ 95
3.3/ 4.4 9.2/10.6 34.8/ 36.5 35/ 40 34/ 36 104/106
4.9/ 6.5 13.6/15.6 40.3/ 42.8 45/ 45 39/ 42 109/111
6.5/ 8.7 18.0/20.9 45.8/ 49.4 50/ 50 45/ 48 113/116
7.9/10.5 21.9/25.3 50.7/ 54.9 60/ 60 49/ 53 117/120
12.0/16.0 33.3/38.5 64.9/ 71.4 70/ 80 62/ 68 128/134
460-3-60 414 508 5.1 39.0 0.4 2.2
— — 11.2 15 11 48
6.0 7.2 20.2 25 20 55
8.8 10.6 24.4 25 24 59
11.5 13.8 28.4 30 27 62
14.0 16.8 32.2 35 31 65
005
(4 Tons)
208/230-1-60 197 254 21.0 115.0 0.7 4.9
—/— —/— 36.7/ 36.7 40/ 40 36/ 36 133/133
3.3/ 4.4 15.9/18.3 56.5/ 59.5 60/ 60 54/ 57 149/151
6.5/ 8.7 31.3/36.3 75.8/ 82.0 80/ 90 72/ 78 164/169††
9.8/13.0 47.1/54.2 95.5/104.4 100/110 90/ 98 180/187††
13.1/17.4 63.0/72.5 115.4/127.3 125/150 109/119 196/206††
15.8/21.0 76.0/87.5 131.7/146.0 150/150 124/137 209/221††
208/230-3-60 187 254 14.1 95.0 0.7 4.9
—/— —/— 28.0/ 28.0 30/ 30 28/ 28 113/113
4.9/ 6.5 13.6/15.6 45.0/ 47.5 50/ 50 44/ 46 127/129
6.5/ 8.7 18.0/20.9 50.5/ 54.2 60/ 60 49/ 52 134/134
12.0/16.0 33.3/38.5 69.7/ 76.2 70/ 80 66/ 72 146/152
15.8/21.0 43.9/50.5 82.9/ 91.2 90/ 100 79/ 86 157/164††
460-3-60 414 508 7.1 45.0 0.4 2.2
— — 13.7 15 14 54
6.0 7.2 22.7 25 22 61
11.5 13.8 30.9 35 30 68
14.0 16.8 34.7 35 33 71
23.0 27.7 48.3 50 46 82
006
(5 Tons)
208/230-1-60 187 254 25.0 150.0 1.5 7.6
—/— — 45.2/ 45.2 50/ 50 45/ 45 193/193
4.9/ 6.5 23.6/27.1 74.7/ 79.0 80/ 80 72/ 76 216/220††
6.5/ 8.7 31.3/36.3 84.3/ 90.5 90/100 81/ 86 224/229††
9.8/13.0 47.1/54.2 104.0/112.9 110/125 99/107 240/247††
13.1/17.4 63.0/72.5 123.9/135.8 125/150 117/128 256/265††
15.8/21.0 76.0/87.5 140.2/154.5 150/175 132/145 269/280††
208/230-3-60 187 254 17.3 123.0 1.5 5.8
—/— —/— 33.7/ 33.7 35/ 35 34/ 34 173/173
4.9/ 6.5 13.6/15.6 50.7/ 53.2 60/ 60 49/ 52 186/188
7.9/10.5 21.9/25.3 61.1/ 65.4 70/ 70 59/ 63 194/198
12.0/16.0 33.3/38.5 75.4/ 81.9 80/ 90 72/ 78 206/211
15.8/21.0 43.9/50.5 88.6/ 96.9 90/100 84/ 92 216/223††
19.9/26.5 55.2/63.8 102.7/113.5 110/125 97/107 228/236††
460-3-60 414 508 8.4 70.0 0.8 2.6
— — 16.1 20 16 95
6.0 7.2 25.1 30 24 102
11.5 13.8 33.3 35 32 108
14.0 16.8 37.1 40 35 111
23.0 27.7 50.7 60 48 122
25.0 30.1 53.7 60 51 125
See Legend on page 20
50HJQ,HEQ

19
Table 5D — 50HEQ Electrical Data — High-Static Motor Units With Electrical Convenience Outlet
UNIT SIZE
NOMINAL
VOLTAGE
V-PH-Hz
VOLTAGE
RANGE COMPRESSOR OFM IFM ELECTRIC HEAT*
POWER
SUPPLY
MINIMUM UNIT
DISCONNECT
SIZE
Min Max RLA LRA FLA FLA kW† FLA MCA MOCP** FLA LRA
004
(3 Tons)
208/230-3-60 187 254 10.3 77.0 0.7 5.8
—/— —/— 24.2/ 24.2 25/ 25 25/ 25 124/124
3.3/ 4.4 9.2/10.6 35.7/ 37.4 40/ 40 35/ 37 134/135
4.9/ 6.5 13.6/15.6 41.2/ 43.7 45/ 45 40/ 43 138/140
6.5/ 8.7 18.0/20.9 46.7/ 50.3 50/ 60 46/ 49 142/145
7.9/10.5 21.9/25.3 51.6/ 55.8 60/ 60 50/ 54 146/150
12.0/16.0 33.3/38.5 65.8/ 72.3 70/ 80 63/ 69 158/163
460-3-60 414 508 5.1 39.0 0.4 2.6
— — 11.6 15 12 63
6.0 7.2 20.6 25 20 70
8.8 10.6 24.8 25 24 73
11.5 13.8 28.8 30 28 76
14.0 16.8 32.6 35 31 79
005
(4 Tons)
208/230-3-60 187 254 14.1 95.0 0.7 5.8
—/— —/— 24.1/ 24.1 25/ 25 24/ 24 138/138
4.9/ 6.5 13.6/15.6 41.1/ 43.6 45/ 45 39/ 42 151/153
6.5/ 8.7 18.0/20.9 46.6/ 50.3 50/ 60 44/ 48 156/159
12.0/16.0 33.3/38.5 65.8/ 72.3 70/ 80 62/ 68 171/176
15.8/21.0 43.9/50.5 79.0/ 87.3 80/ 90 74/ 82 182/188††
460-3-60 414 508 7.1 45.0 0.4 2.6
— — 14.1 15 14 69
6.0 7.2 23.1 25 22 76
10.5 12.6 29.8 30 29 81
14.0 16.8 35.1 40 33 85
23.0 27.7 48.7 50 46 96
006
(5 Tons)
208/230-3-60 187 254 17.3 123.0 1.5 7.5
—/— —/— 35.4/ 35.4 40/ 40 36/ 36 192/192
4.9/ 6.5 13.6/15.6 52.4/ 54.9 60/ 60 51/ 54 205/207
7.9/10.5 21.9/25.3 62.8/ 67.1 70/ 70 61/ 65 213/217
12.0/16.0 33.3/38.5 77.1/ 83.6 80/ 90 74/ 80 225/230††
15.8/21.0 43.9/50.5 90.3/ 98.6 100/100 86/ 94 235/242††
19.9/26.5 55.2/63.8 104.4/115.2 110/125 99/109 247/255††
460-3-60 414 508 8.4 70.0 0.8 3.4
— — 16.9 20 17 104
6.0 7.2 25.9 30 25 111
11.5 13.8 34.1 35 33 118
14.0 16.8 37.9 40 36 121
23.0 27.7 51.5 60 49 132
25.0 30.1 54.5 60 52 134
See Legend on page 20.
50HJQ,HEQ

20
LEGEND
F L A --- Fu l l L o a d A m ps
HACR --- Heating, Air Conditioning and Refrigeration
IFM --- Indoor---Fan Motor
LRA --- Locked Rotor Amps
MCA --- Minimum Circuit Amps
MOCP --- Maximum Overcurrent Protection
NEC --- National Electrical Code
OFM --- Outdoor---Fan Motor
RLA --- Rated Load Amps
*Heater capacity (kW) is based on heater voltage of 208 v, 240 v, or 480 v.
If power distribution voltage to unit varies from rated heater voltage,
heater kW will vary accordingly.
†Heaters are field installed only.
**Fuse or HACR circuit breaker.
††Electrical disconnect cannot be used if electric heater is installed.
NOTES:
1. In compliance with NEC requirements for multimotor and combina-
tion load equipment (refer to NEC Articles 430 and 440), the overcur-
rent protective device for the unit shall be fuse or HACR breaker.
2. Unbalanced 3-Phase Supply Voltage
Never operate a motor where a phase imbalance in supply voltage is
greater than 2%. Use the following formula to determine the percent-
age of voltage imbalance.
%VoltageImbalance
= 100 x max voltage deviation from average voltage
average voltage
Example: Supply voltage is 460-3-60
AB = 452 v
BC = 464 v
AC = 455 v
Average Voltage
=
452 + 464 + 455
3
=1371
3
=457
Determine maximum deviation from average voltage.
(AB) 457 – 452 = 5 v
(BC) 464 – 457 = 7 v
(AC) 457 – 455 = 2 v
Maximum deviation is 7 v.
Determine percent of voltage imbalance.
% Voltage Imbalance = 100 x 7
457
= 1.53%
This amount of phase imbalance is satisfactory as it is below the maxi-
mum allowable 2%.
IMPORTANT: If the supply voltage phase imbalance is more
than 2%,contact your local electric utility company immediately.
50HJQ,HEQ
