Carson Phantom User manual

Please read this manual before installing and using the
projection screen. Retain this manual for future reference.
Phantom
Instruction manual for Phantom

Items listed here may change without prior notice.
The company reserves the right to all of the listed items.
Screen (1pc)
Remote control (1pc)
Ceiling brackets (2 pcs)
Screen brackets (2 pcs)
Spirit bubble (1 pcs)
Threaded mounting rod (4 pcs)
Anchor bolt (8 pcs)
Hexagon nuts (12 pcs)
Adjustment tool (1 pc)

Important Safety Tips
 WARNING: Incorrect installation and improper use may lead to mechanical
failure or personal injury.
Considerations for installing / using this product
1. Handle with care to avoid damage.
2. Do not expose the product to rainwater or any other form of moisture.
3. Keep away from heat sources, such as radiators and other items that may
emit heat
4. Do not attempt to service or modify this unit without professional assistance.
5. Check whether the voltage is consistent with the required voltage.
6. Do not fold or touch the screen directly with your hands, tools or any other
abrasive/sharp objects.
7. When not in use, retract the screen to protect the optical surface.
8. Do not run the screen continuously as the motor has an anti-overheating
function and will shut down.
9. Keep the screen horizontal at all times.
The company will not be liable for any damages or injuries caused by a faulty
installation or operation.
 Do not adjust the limit by yourself
Cleaning
AVOID using detergents or harsh chemicals to clean the screen. A soft cloth and
mild soap can clean dust and dirt o the screen material. To get dirt o the
screen, use a soft cloth with mild soap. To just wipe o, a cotton cloth will
suce.

Hanging installation
1. Install the threaded mounting rods on
top of the screen casing
2. Attach the rods to the ceiling brackets
with the hex nuts provided
3. Drill holes for anchor bolts in the ceiling
4. Attach ceiling bracket to the ceiling
where desired
5. Hand tighten all nuts, then adjust the
screen position as needed
Note: This installation method is best
suitable for concrete or wooden ceiling. To
avoid the screen falling o, conrm before
installing that the ceiling is able to sustain
the weight of the screen.
Anchor bolt
Mounting Rod
Ceiling bracket
threaded

1. Fit the screen brackets on the top of
the screen casing.
2. Draw an outline on where the 4
Anchor Bolts would go on the
ceiling.
3. Drill the holes for the Anchor Bolts
through the outline drawn in step 2.
Note: To avoid the screen falling o,
conrm before installing that the
ceiling is able to sustain the weight of
the screen.
Concealed installation
Anchor bolt
Screen bracket
Trim panel
Magnet

4. Detach the trim panels, then attach
the screen to the ceiling with the
anchor bolts
5. Re-attach the trim panels.
The trim panel can be taken o while
installing Anchor Bolts for ease of
installation

Up
Down
Stop
Remote Control
Built-in RF remote control/external RF
remote control/IR control optional
The remote control has been
programmed before dispatch and is
ready to use straight out of the box.
If you do need to program the remote,
the steps are outlined below:
1. Press the “Up” button for 3 seconds
and plug in the receiver.
2. Once the receiver buzzer rings, stop
pressing the “Up” button. Pairing
mode is now active.
3. Press the “Up”button once and
release.
4. When the buzzer rings 3 times in a
row, the remote pairing function is
complete.
Programming the remote control

Nature of fault
Screen not fully closing
Probable cause Solution
Low battery in remote Replace battery
Power cable not
connected
Motor in thermal
protection mode after
extended period of use
Adjust the height of the
screen
Let motor cool for 15
minutes, then retry
Refer to the user
manual or contact the
factory. DO NOT
attempt to fix yourself
Connect the power
cable
Screen does not go
up or down, non
responsive
Troubleshooting
Nature of fault
Remote control is not
responsive
The remote control and
receiver work well, but
the motor doesn't run
Likely incorrect wiring
of the motor
Correct the wiring
according to
instructions
Remote control battery
is dead
Get a new battery
Probable cause Solution
- Receiver wiring likely
incorrect;
- Code pairing likely
incomplete
- Correct the wiring
according to
instructions
- Correct code matching
between remote and
receiver
The indicator on the
remote is on but the
receiver is
unresponsive
Screen
Remote
