Casablanca CEILING FAN User manual

www.CasablancaFanCo.com 1.888.227.2178
Table of Contents
PAGE
21
Troubleshooting
PAGE
15
Light Kit
?
?
?
Operation
PAGE
18
Maintenance
& Cleaning
PAGE
20
PAGE
14
Blades
PAGE
5
30 inches
7 feet
PAGE
2
What to Expect with
Your Installation
Ladder
PAGE
3
Tools Needed
Canopy
PAGE
7
PAGE
10
PAGE
6
WiringDownrodPreparation
PAGE
13
PAGE
4
Mounting Options Ceiling Bracket
PAGE
12
Wall Control
Congratulations on purchasing your new Casablanca®
ceiling fan! It will provide comfort and performance in
your home or ofce for many years. This installation and
operation manual contains complete instructions for
installing and operating your fan.
To register your fan, please visit:
www.CasablancaFanCo.com/register
Save your receipt for proof of purchase.
We are proud of our work and
appreciate the opportunity
to supply you with the best
ceiling fan available anywhere
in the world.
1
M8505-01 • 10/30/14 • © Casablanca Fan Company

www.CasablancaFanCo.com 1.888.227.2178
www.CasablancaFanCo.com 1.888.227.2178
www.CasablancaFanCo.com 1.888.227.2178
What to Expect with Your Installation
Know your wiring
If you are unfamiliar
with wiring, use a
qualied electrician.
You may need a
friend to help you.
Check box to see
fan weight
Assess location
30 inches
from blade tip to
nearest wall or
obstruction 7 feet
from bottom
edge of blade
to the oor
Select a downrod length
w.1 - To reduce the risk of re, electrical shock, or personal
injury, mount fan directly from building structure and/or an
outlet box marked acceptable for fan support of 70 lbs (31.8 kg)
and use the mounting screws provided with the outlet box.
w.2 - To avoid possible electrical shock, before installing or
servicing your fan, disconnect the power by turning off the
circuit breakers to the outlet box and associated wall switch
location. If you cannot lock the circuit breakers in the off
position, securely fasten a prominent warning device, such as a
tag, to the service panel.
w.3 - To reduce the risk of re, electrical shock, or motor damage,
use only Casablanca Solid State Speed Controls.
w.4 - To reduce the risk of personal injury, do not bend the blade
brackets when installing the blade brackets, balancing the blades,
or cleaning the fan. Do not insert foreign objects in between
rotating fan blades.
c.1 - All wiring must be in accordance with national and local
electrical codes ANSI/NFPA 70. If you are unfamiliar with wiring,
use a qualied electrician.
c.2 - Use only Casablanca replacement parts.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and if not
installed and used in accordance with the instructions may cause
harmful interference to radio communications.
Assess ceiling angle
Read and Save These Instructions
This product conforms to UL Standard 507.
WARNINGS
CAUTIONS
Must be able to
secure the fan to
building structure or
fan-rated outlet box
1
2
Standard Downrod
for ceilings 8-10 feet high
Longer Downrod
for ceilings 10 feet or higher
Ceiling angles greater
than 34° will require an
Angled Mounting Kit.
See page 4 for details.
2
M8505-01 • 10/30/14 • © Casablanca Fan Company
2

www.CasablancaFanCo.com 1.888.227.2178
3
M8505-01 • 10/30/14 • © Casablanca Fan Company
Tools Needed
Ladder
Power Drill
(optional)
9/64” Drill Bit
(optional)
Screwdrivers
Pliers Wire Strippers
If mounting to a support structure, you will also need these tools.

www.CasablancaFanCo.com 1.888.227.2178
4
M8505-01 • 10/30/14 • © Casablanca Fan Company
If you have an angled ceiling:
1. You will need a longer downrod (sold separately).
2. If your ceiling angle is greater than 34°, you will
also need an Angled Mounting Kit (sold separately).
Guide Touches
BOTH Ceiling & Wall
S
I
T
U
A
T
I
O
N
1
Guide Touches Wall
but NOT Ceiling
S
I
T
U
A
T
I
O
N
2
You need BOTH
a Longer
Downrod &
an Angled
Mounting Kit
You need ONLY
a Longer
Downrod
*most common
If you have a at ceiling:
Hang your fan by a standard downrod (included).
Mounting Options
Support
Structure
Ceiling
Outlet Box
(required)
Angled
Mounting
Style
Standard
Mounting
Style
Support
Structure
Ceiling
Outlet Box
(required)
Use Standard Mounting
to hang the fan from a at ceiling.
Use Angled Mounting
to hang the fan from a
vaulted or angled ceiling.
4
34OCEILING
WALL
OPTION
1
Standard
Mounting
OPTION 2
Angled
Mounting
2 3
SLIDE
toward ceiling
PLACE
against wall
1
FOLD
on dotted line
34°
Use the three steps below to determine if your ceiling angle is greater than 34°
1.888.227.2178
M8505-01 • 10/30/14 • © Casablanca Fan Company

www.CasablancaFanCo.com 1.888.227.2178
5
M8505-01 • 10/30/14 • © Casablanca Fan Company
Ceiling Bracket
OFF
Make sure all four bumpers are
still attached.
For angled ceilings, point
opening toward peak.
Refer to warning w.1 on pg. 2
To avoid possible electrical shock, before
installing your fan, disconnect the power by
turning off the circuit breakers to the outlet
box associated with the wall switch location.
If you are unable to do this,
call Technical Support at
1-888-227-2178.
Use wood screws
(included) when securing
to support structure with
approved electrical outlet
box. Drill 9/64” pilot holes
in support structure to aid
in securing ceiling bracket
with hardware found in
the hardware bag.
Use machine screws
(provided with outlet
box) when securing to
existing ceiling fan-rated
outlet box. Make sure
it is securely installed
and is acceptable for fan
support of 31.8 kg (70 lbs)
or less.
Turn Power

www.CasablancaFanCo.com 1.888.227.2178
Ceiling Bracket (continued) Preparation
D
I
S
C
A
R
D
D
I
S
C
A
R
D
Remove the shipping blocks from the
motor. Discard the screws.
Note: Some fans will have a shipping ring
instead of shipping blocks. Please remove
the ring and discard the screws.
6
M8505-01 • 10/30/14 • © Casablanca Fan Company

www.CasablancaFanCo.com 1.888.227.2178
Downrod
Slide
Slide
1 2 3 4 5
678910
Sold Separately
Longer
Downrod
for angled
ceilings or
ceilings 10’ or
higher
Standard
Downrod
for ceilings 8-10’ high
Option 1
Option 2
skip to next page
If you need a different downrod length follow these steps:
Steps 1-5 to remove standard downrod pipe
Steps 6-10 to reassemble with new pipe
Included (pre-assembled)
7
M8505-01 • 10/30/14 • © Casablanca Fan Company

www.CasablancaFanCo.com 1.888.227.2178
Downrod (continued)
KEEP!
8”
3/8”
C
U
T
&
S
T
R
I
P
(not to scale)
Remove the pre-installed
setscrew so that the downrod
can be inserted.
Slide the adapter cover onto
the downrod, then hand
tighten the downrod (at least
4-5 full turns) until it stops.
The wires can be cut, but
leave at least 8” extending
from the top of the
downrod.
8” 3/8”
Tighten the setscrew
with pliers. DO NOT
HAND TIGHTEN.
If the setscrew is not tightened
securely, the fan may fall.
K
E
E
P
!
8
M8505-01 • 10/30/14 • © Casablanca Fan Company

www.CasablancaFanCo.com 1.888.227.2178
9
M8505-01 • 10/30/14 • © Casablanca Fan Company
Downrod (continued)
Put the wires and downrod
through the canopy. Let the
canopy sit loosely on top of
the fan.
DO NOT PICK THE FAN UP BY
THE CANOPY OR WIRES. Place
the downrod ball into the slot
in the ceiling bracket.
Lower the adapter cover until it rests
ush against the motor housing.
Align the screw holes on the adapter
cover with the screw holes on the
motor housing and install the
three adapter cover screws found in
the hardware bag.

www.CasablancaFanCo.com 1.888.227.2178
10
M8505-01 • 10/30/14 • © Casablanca Fan Company
Wiring
Turn the splices upward and push them carefully back through the hanger bracket
into the outlet box. Spread the wires apart, with the grounded wires on one side of
the outlet box and the ungrounded wires on the other side of the outlet box.
Refer to CAUTION c.1 on pg. 2
Place the receiver on top of the downrod
assembly as shown.
Receiver
F
R
O
M
C
E
I
L
I
N
G
F
R
O
M
C
E
I
L
I
N
G
B
R
A
C
K
E
T
green/yellow stripe (grounding)
green/yellow stripe
green/yellow stripe
Note: To connect the wires, hold
the bare metal leads together and
place a wire connector over them,
then twist clockwise until tight.
Using an orange wire connector
from the hardware bag:
Connect the 3 grounding wires
(green, green/yellow stripe, or bare
copper) coming from the ceiling,
downrod, and ceiling bracket.
F
R
O
M
F
A
N

www.CasablancaFanCo.com 1.888.227.2178
11
M8505-01 • 10/30/14 • © Casablanca Fan Company
Use wire strippers to remove the
crimp connector from the end of the
red wire on the receiver.
Using the wire connectors from the
remote control hardware bag:
• Connect the white wire from the
receiver (marked “common out”)
to the white wire from fan.
• Connect the black wire from the
receiver (marked “fan out”) to
the black wire from the fan.
• Connect the blue wire from the
receiver (marked ”light 1 out”) to
the blue wire from the fan
• Connect the red wire from the
receiver (marked ”light 2 out”) to
the red wire from the fan.
F
R
O
M
R
E
C
E
I
V
E
R
Using an orange wire connector from
the hardware bag:
• Connect the black wire
(ungrounded) from the ceiling to
the black wire from the receiver
(marked “live in”).
• Connect the white wire (grounded)
from the ceiling to the white wire
from the receiver (marked “neutral
in” or “common in”).
F
R
O
M
C
E
I
L
I
N
G
black (ungrounded) white (grounded) white (neutral in)
black (live in)
Turn the splices upward and push them carefully back through the hanger bracket
into the outlet box. Spread the wires apart, with the grounded wires on one side of
the outlet box and the ungrounded wires on the other side of the outlet box.
Refer to CAUTION c.1 on pg. 2
Wiring (continued)
F
R
O
M
R
E
C
E
I
V
E
R
white black
blue
white (common out) black (fan out) blue (light 1 out)
F
R
O
M
F
A
N
red
red (light 2 out)

www.CasablancaFanCo.com 1.888.227.2178
12
M8505-01 • 10/30/14 • © Casablanca Fan Company
1. Using a 9/64 drill bit, drill a hole
in each screw cut-out on the wall
control template.
2. Using a hammer, tap a drywall
anchor found in the wall control
hardware bag into each hole
until the drywall anchor is ush
with the wall.
1. Using a drywall punch saw,
cut out the interior shape of
the template using one of
the four drilled corners as a
starting point.
2. Remove the template and the
cut-out section of drywall.
1. Insert the wall control into the
dry wall cut out.
2. Align the screw holes in the wall
control with the drywall anchors.
3. Install the cover plate using
a Phillips Head screwdriver
to secure the two cover plate
screws found in the wall control
hardware bag through the wall
control and into the drywall
anchors.
Wall Control
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
If you are using a outlet box for wall control installation, the wires coming from the wall
control must be grounded using the attached green wire. If not placed in an outlet box, cap
the green wire coming from the wall control with an included wire nut.
1. Tape the provided wall control
template with painter’s tape at
the desired installation area.
2. Drill holes inside the four
corners of the template.
Note: Make sure the wall
control template is level before
proceeding to the next step.
Template
Drywall
Before
After
Cover Plate
Template
Drill Holes
Painter’s
Tape Template
Drywall
Anchors
Screw
Cut-Out

www.CasablancaFanCo.com 1.888.227.2178
13
M8505-01 • 10/30/14 • © Casablanca Fan Company
Canopy
Note: Fan style may vary.
Position the canopy so that, when
lifted into place, the canopy ts into
the hanging bracket as shown.
Insert the two canopy screws
found in the hardware bag.
Lift the canopy into place so that
the screw holes are aligned.
Screw
Holes

www.CasablancaFanCo.com 1.888.227.2178
M8505-01 • 10/30/14 • © Casablanca Fan Company
Blades
14
Your blades are shielded with Dust Armor® which
is a nanotechnology coating that repels dust. For
cleaning the fan, use soft brushes or cloths to prevent
scratching. Cleaning agents may damage the nishes.
Once the blade and medallion are
attached, insert the blade iron into
the slot on the blade ring and install
the blade iron armature screws, found
in the hardware bag.
Once all ve blades have been
assembled, lift the blade assembly
and align the screw holes and
rubber grommets on the blade ring
with the screw holes on the motor.
Install the blade ring screws, found
in the hardware bag.
Place each blade between a blade iron
and blade medallion. Install the blade
screws, found in the hardware bag,
to attach the medallion to the blade
iron. Repeat for all blades.

www.CasablancaFanCo.com 1.888.227.2178
Light Kit
Make sure the light kit is securely attached to the
motor housing. Failure to properly secure all three
assembly screws could result in the light kit falling.
Screw three housing assembly screws
from the hardware bag halfway into
the motor housing.
Feed the wires from the bottom of the
fan through the center hole of the light
kit, then wrap keyhole slots around
the screws and twist counterclockwise.
Tighten all three screws securely.
15
M8505-01 • 10/30/14 • © Casablanca Fan Company

www.CasablancaFanCo.com 1.888.227.2178
Tuck the wires into the light kit, then lift the
light xture and align the screw holes in
the light xture with the screw holes in the
light kit. Install the three light xture screws,
found in the hardware bag.
Install a halogen bulb in each socket.
When necessary, replace with bulbs of
the same type and wattage.
Light Kit (continued)
Make sure the light xture is securely attached to the light kit.
Failure to properly secure all 3 assembly screws could result
in the light xture falling.
Using the ceramic wire connectors, connect
the blue wire from the fan to the blue wire
from the light kit. Connect the white wire from
the fan to the white wire from the light kit.
Note: Be sure to use the CERAMIC wire
connectors to avoid re hazard.
M8505-01 • 10/30/14 • © Casablanca Fan Company
16

www.CasablancaFanCo.com 1.888.227.2178
Light Kit (continued)
Carefully lift the globe so the threaded rod
on the light xture goes through the hole
in the globe. With the other hand, install
the nial cap and nial onto the threaded
rod and tighten securely.
Install an E12 bulb in each upper socket.
Note: Do not use CFL bulbs to replace your light
bulbs. Your lights may icker or fail to work.
CONGRATULATIONS!
YOU’RE DONE!
See next page for fan
operation instructions.
Note: Glass shade style and number of lights may vary.
Globe
Finial Cap
Finial
17
M8505-01 • 10/30/14 • © Casablanca Fan Company

www.CasablancaFanCo.com 1.888.227.2178
18
M8505-01 • 10/30/14 • © Casablanca Fan Company
Operation
Fan
Power
4
Before operating the wall control, press on the
battery door to eject it. Unscrew the battery
holder. Insert the battery, found in the control
hardware bag, with the positive (+) side facing
downward. Reinstall the battery holder and
reinsert the battery door into the wall control.
Battery
Battery
Holder
Battery
Door
ON
Turn Power
The remote transmitter should already be
paired to the receiver and ready to use.
Note: If your need to pair your remote, turn
fan power off and back on at the circuit
breaker. Within three minutes, press and
hold both the Fan Off button and the 4
button for four seconds to pair the remote.
To prevent faulty operation, please
disconnect power from all other ceiling
fans within range while pairing.

www.CasablancaFanCo.com 1.888.227.2178
Operation (continued)
Quickly press the uplights or
downlights button to turn the lights off
and on. Press and hold the appropriate
button to raise or dim the light level of
the uplights or downlights. The reverse
button changes the direction that the
blades turn. The power button turns
the fan off and on.
Downlights
Fan
Speed
Reverse
Battery
Holder
Fan
Power
Uplights
Fan
Speed
(Low)
(High)
The reverse button on the wall
control changes the air ow
pattern. In warm weather, use
(a) downward air ow pattern.
In cold weather, use (b) upward
air ow pattern.
(a)
(b)
Reverse
Button
• Press the fan power button
off for at least three seconds to
initiate the Safe-Exit Mode.
• The lights will ash for visual
conrmation.
• The lights will stay on 50%
brightness for 20 seconds and
then begin to dim. After a total
of 30 seconds, the lights will be
completely off.
Note: For CFL lighting, the lights
will stay on 100% brightness
for 30 seconds. After a total of
30 seconds, the lights will be
completely off.
The Safe-Exit Program gives
you about thirty seconds of
light when you turn the lights
off to exit the room before the
lights go out.To use Safe-Exit:
19
M8505-01 • 10/30/14 • © Casablanca Fan Company

www.CasablancaFanCo.com 1.888.227.2178
Maintenance & Cleaning
Cleaning the fan - use soft brushes or cloths
to prevent scratching. Cleaning products may
damage the nishes.
Be sure to turn off
power to the fan
before performing
any maintenance or
relamping.
OFF
Turn Power
Changing the bulbs - unscrew the nial and
remove it from the threaded rod. Remove the
nial cap while supporting the globe with your
other hand. Carefully remove the globe. Unscrew
bulbs and replace with bulbs of the same type
and wattage. Reinstall the globe assembly.
Globe
Finial Cap
Finial
20
M8505-01 • 10/30/14 • © Casablanca Fan Company
