What to Expect with
Your Installation
Ladder
PAGE
3
Preparation
Wall Control Maintenance
& Cleaning TroubleshootingGlass
PAGE
5
Hanging the Fan
?
?
?
PAGE
13
PAGE
18
Table of Contents
PAGE
4
Ceiling Plate
PAGE
7
Wiring Canopy
PAGE
9
PAGE
8
Wall Control
PAGE
11
Blades
1
M8546-01 • 03/23/17 • © 2017 Casablanca Fan Company

www.CasablancaFanCo.com 1.888.227.2178
2
M8546-01 • 03/23/17 • © 2017 Casablanca Fan Company
What to Expect with Your Installation
Know your wiring
If you are unfamiliar
with wiring, use a
qualied electrician.
You may need a
friend to help you.
Check box to see
fan weight
Assess location
30 inches
from blade tip to
nearest wall or
obstruction 7 feet
from bottom
edge of blade
to the oor
Must be able to
secure the fan to
building structure or
fan-rated outlet box
w.1 - To reduce the risk of re, electrical shock, or personal injury,
mount fan directly from building structure and/or an outlet box marked
acceptable for fan support of 70 lbs (31.8 kg) and use the mounting
screws provided with the outlet box.
w.2 - To avoid possible electrical shock, before installing or servicing your
fan, disconnect the power by turning off the circuit breakers to the outlet
box and associated wall switch location. If you cannot lock the circuit
breakers in the off position, securely fasten a prominent warning device,
such as a tag, to the service panel.
w.3 - To reduce the risk of re, electrical shock, or motor damage, use only
Hunter Solid State Speed Controls.
w.4 - To reduce the risk of personal injury, do not bend the blade brackets when
installing the blade brackets, balancing the blades, or cleaning the fan. Do not
insert foreign objects in between rotating fan blades.
c.1 - All wiring must be in accordance with national and local electrical codes
ANSI/NFPA 70. If you are unfamiliar with wiring, use a qualied electrician.
c.2 - Use only Casablanca replacement parts.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses and can radiate
radio frequency energy and if not installed and used in accordance with the
instructions may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution: modications not approved by the party responsible for compliance
could void user’s authority to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference,
and (2) this device must accept any interference received, including
interference that may cause undesired operation.
Read and Save These Instructions
This product conforms to UL Standard 507.
WARNINGS
CAUTIONS

www.CasablancaFanCo.com 1.888.227.2178
3
M8546-01 • 03/23/17 • © 2017 Casablanca Fan Company
Preparation
Tools Needed
Ladder
Power Drill
(optional)
9/64” Drill Bit
(optional)
Pliers Wire Strippers
If mounting to a support structure, you
will also need these tools.
Do not discard the hardware
bags or mix parts from different
bags. Make note of the symbol
printed on each hardware
bag. The symbols can be used
to identify the appropriate
hardware for each step.
Screwdriver
(included)

www.CasablancaFanCo.com 1.888.227.21781.888.227.2178 www.CasablancaFanCo.com
Ceiling Plate
Refer to warning w.1 on pg. 2
To avoid possible electrical shock, before installing your fan,
disconnect the power by turning off the circuit breakers to the
outlet box associated with the wall switch location.
OFF
Turn Power
Use wood screws
(included) when securing
to support structure with
approved electrical outlet
box. Drill 9/64” pilot holes
in support structure to aid
in securing ceiling plate
with hardware found in
the hardware bag.
Use machine screws
(provided with outlet
box) when securing to
existing ceiling fan-rated
outlet box. Make sure
it is securely installed
and is acceptable for fan
support of 31.8 kg (70
lbs) or less.
Make sure all four bumpers are
still attached.
Bumper
4
M8546-01 • 03/23/17 • © 2017 Casablanca Fan Company

www.CasablancaFanCo.com 1.888.227.2178
Unlock the canopy cover from the canopy ring
tabs to loosen the canopy ring and lower it down
to the fan body as shown.
Note: Remove the canopy screws from the shipping
plate inside the canopy. Discard the shipping plate
but save the screws for canopy installation.
Align the at side of the control receiver with the
at side of the triangular seat. Lower the control
receiver on the triangular seat. Ensure the posts on
the bottom of the control receiver are seated in the
holes in the triangular seat.
Note: Wiring not shown for visual clarity.
Connect the larger plug connectors together.
Make sure to line up the colored markings on the
connectors. Ensure that the plugs latch together.
Hanging the Fan
ALIGN
5
M8546-01 • 03/23/17 • © 2017 Casablanca Fan Company

www.CasablancaFanCo.com 1.888.227.2178
DO NOT PICK THE FAN UP BY THE
WIRES. Use the hanging hole on the
body of the fan to hang the fan on the
hook of the ceiling mounting plate.
Hanging the Fan
Locate the single-pin connectors that are taped
together. Connect the single-pin connectors
from the control receiver to the connectors
from the fan. Connect the white wires together.
Connect the blue wires together. The third, loose
wire will not be used for your installation. It is
capped to prevent usage.
Connect
6
M8546-01 • 03/23/17 • © 2017 Casablanca Fan Company

www.CasablancaFanCo.com 1.888.227.2178
Turn the splices upward and push them carefully back through the hanger bracket
into the outlet box. Spread the wires apart, with the grounded wires on one side of
the outlet box and the ungrounded wires on the other side of the outlet box.
Refer to CAUTION c.1 on pg. 2
Note: To connect the wires, hold
the bare metal leads together and
place a wire connector over them,
then twist clockwise until tight.
Using an orange wire connector
from the hardware bag:
Connect the 3 grounding wires
(green, green/yellow stripe, or bare
copper) coming from the ceiling,
fan, and ceiling plate.
F
R
O
M
C
E
I
L
I
N
G
F
R
O
M
C
E
I
L
I
N
G
P
L
A
T
E
green/yellow stripe (grounding)
green
green
F
R
O
M
F
A
N
Using an orange wire connector:
• Connect the black (ungrounded)
wire from the ceiling to the black
wire from the fan/receiver.
• Connect the white (grounded)
wire from the ceiling to the white
wire from the fan/receiver.
• Cap the blue wire from the fan.
You will not need it for single
switch wiring.
F
R
O
M
F
A
N
F
R
O
M
C
E
I
L
I
N
G
black (ungrounded) white (grounded)
black blue white
Wiring: Single Switch
Have a single switch?
Follow these steps:
Dual Switch
Instructions
7
M8546-01 • 03/23/17 • © 2017 Casablanca Fan Company

www.CasablancaFanCo.com 1.888.227.2178
Turn the splices upward and push them carefully back through the hanger bracket
into the outlet box. Spread the wires apart, with the grounded wires on one side of
the outlet box and the ungrounded wires on the other side of the outlet box.
Refer to CAUTION c.1 on pg. 2
Note: To connect the wires, hold
the bare metal leads together and
place a wire connector over them,
then twist clockwise until tight.
Using an orange wire connector
from the hardware bag:
Connect the 3 grounding wires
(green, green/yellow stripe, or bare
copper) coming from the ceiling,
fan, and ceiling plate.
F
R
O
M
C
E
I
L
I
N
G
F
R
O
M
C
E
I
L
I
N
G
P
L
A
T
E
green/yellow stripe (grounding)
green
green
F
R
O
M
F
A
N
Using an orange wire connector:
• Connect the black (ungrounded)
wire from the ceiling to the black
wire from the fan/receiver.
• Connect the white (grounded)
wire from the ceiling to the white
wire from the fan/receiver.
• Connect the second ungrounded
(light) wire from the ceiling to the
blue wire from the fan.
F
R
O
M
F
A
N
F
R
O
M
C
E
I
L
I
N
G
black (ungrounded) white (grounded)
white (grounded)
black blue white
Wiring: Dual Switch
Have dual switches?
Follow these steps:
8
M8546-01 • 03/23/17 • © 2017 Casablanca Fan Company

www.CasablancaFanCo.com 1.888.227.2178
Canopy
Partially install two of the canopy screws
into screw holes on opposite corners of
the ceiling plate as shown. Choose the
two screw holes that are aligned with the
hanging slots in the fan body.
Using both hands, lift the fan body from the
hook and align the hanging slots on both sides
of the fan body with the two partially installed
canopy screws. Slide the two slots on both
sides of the fan body between the head of the
screws and rotate the fan body clockwise so the
screws hold the fan body rmly in place.
Install the remaining two canopy screws
by holding the fan body cover to the
ceiling mounting plate. Tighten all four
screws securely.
Hanging Slot
Canopy Screw
9
M8546-01 • 03/23/17 • © 2017 Casablanca Fan Company

www.CasablancaFanCo.com 1.888.227.2178
Canopy
To install the canopy ring, lift the
canopy, then rotate clockwise until
the tabs are held in place by the
tab holders, locking the canopy
ring into place.
To check your work, make sure
there is an even gap all the way
around between the ceiling and
the canopy ring.
Before going to the next step, locate
the two sets of canopy ring tabs that
are on the top edge of the canopy
and the two sets of canopy tab
holders found at the top of the fan
body near the ceiling.
Canopy
Ring
Tabs
Canopy
Tab
Holders
10
M8546-01 • 03/23/17 • © 2017 Casablanca Fan Company

www.CasablancaFanCo.com 1.888.227.2178
Install the blade using three blade screws
and washers, found in the hardware bag.
Repeat this process for all ve blades.
Blades
11
Slide a blade into a slot located on the blade ring.
Note: The blades will only t properly over the
screws holes one way. If the holes do not line up,
remove the blade and turn it over.
11
M8546-01 • 03/23/17 • © 2017 Casablanca Fan Company

www.CasablancaFanCo.com 1.888.227.2178
CONGRATULATIONS!
YOU’RE DONE!
See next page for fan
operation instructions.
Align the notches in the globe assembly with the tabs in the light kit tter.
Carefully lift the globe assembly as far as it will go, then rotate it counter-
clockwise until it is held into place by the three tabs.
Glass
Notch
Tab
12
M8546-01 • 03/23/17 • © 2017 Casablanca Fan Company

www.CasablancaFanCo.com 1.888.227.2178
13
M8546-01 • 03/23/17 • © 2017 Casablanca Fan Company
3Installing the Wall Plate Bracket
Snap the Wall Control into the
Wall Plate Bracket.
4Wiring the Wall Control
1. Connect the grounding wire
from the wall control to the
ground control from the switch
box using the provided wire
nuts.
2. Connect the “LIVE IN” from
the switch box to the “~VAC”
from the wall control using the
provided wire nuts.
3. Connect the “LIVE OUT” from
the switch box to the “FAN” out
from the wall control using the
provided wire nuts.
4. Push all wires into the switch
box.
Wall Control For Single Switch
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
Ensure the power is OFF at the outlet
box and wall switch location before
proceeding with installation.
Turn Power
OFF
1Turning off the power
2Installing the baery
To access the baery compartment,
slide the baery door up.
Replace the used baery with two AAA
baeries when needed.
Battery
Door
If you have a dual switch setup, go to page 18
for dual switch installation instructions.

www.CasablancaFanCo.com 1.888.227.2178
14
M8546-01 • 03/23/17 • © 2017 Casablanca Fan Company
6Installing the Wall Plate
Push the wall plate onto the
Wall Plate Bracket. It should
snap into place.
Turning on the power
Reference the included remote function card
for information on how to use your wall control!
ON
Turn Power
IMPORTANT
7
8
5Installing the Wall Control
Install the longer screws
through the slots in the wall
control into the switch box
screw holes.
Wall Control For Single Switch

www.CasablancaFanCo.com 1.888.227.2178
15
M8546-01 • 03/23/17 • © 2017 Casablanca Fan Company
Wall Control For Dual Switches
Ensure the power is OFF at the outlet
box and wall switch location before
proceeding with installation.
Turn Power
OFF
3Turn off the power
1Installing the baery
To access the baery compartment,
slide the baery door up.
Replace the used baery with two AAA
baeries when needed.
1. Turn on power for the fan.
2. Push both existing wall switches to
the on position.
3. Press the Fan and Light buon on
the Casablanca Wall Control.
4. Your fan’s light and fan should be
on.
5. Push each of your existing wall
switches into the off position one at
a time to determine which switch
controls the Light.
6. The Light switch will not be
replaced when installing the
Casablanca Wall Control. You may
find it helpful to mark the Light
switch with a pencil or some other
non-permanent mark.
Battery
Door
Verify which switch controls the fan light.
ON
Turn Power
2
To install the Casablanca Wall Control into a dual switch location,
you will need a wall plate with both a standard switch and rocker
switch cut-out (sold separately).
IMPORTANT
If you are unfamiliar or
uncomfortable with wiring, please
contact a qualified electrician.
(Sold Separately)

www.CasablancaFanCo.com 1.888.227.2178
16
M8546-01 • 03/23/17 • © 2017 Casablanca Fan Company
Wall Control For Dual Switches
7Install the Wall Plate
Install the wall plate that fits
your setup (sold separately).
The existing light switch still
controls the light on/off.
Turn on the power
Installation complete
Reference the included remote function card
for information on how to use your wall control!
ON
Turn Power
IMPORTANT
9
8
10
4
5
Remove the existing wall plate
Remove the Casablanca Wall
Control frame.
Remove the existing wall plate.
Save the screws. You will need
them for the existing, marked
light switch.
Remove the frame from the
Casablanca Wall Control. You
will not need it for the dual
switch installation process.
6Wiring the Casablanca Wall
Control
1. Connect the grounding wire
from the wall control to the
ground control from the switch
box using the provided wire
nuts.
2. Connect the “LIVE IN” from
the switch box to the “~VAC”
from the wall control using the
provided wire nuts.
3. Connect the “LIVE OUT” from
the switch box to the “FAN” out
from the wall control using the
provided wire nuts.
4. Push all wires into the switch
box.
1. Use the screws you saved to
reinstall into the light switch.
2. Use the screws included

www.CasablancaFanCo.com 1.888.227.2178
17
M8546-01 • 03/23/17 • © 2017 Casablanca Fan Company
Wall Control
Light Dimming
Control
Dimming Mode
On/Off
+
Light On/Off
Light High
Light Low
Long
Press
Long
Press
Long
Press
Fan On/Off
+
+
+
+
Fan High
Fan Low
Fan Reverse
Fan Updraft
Fan Downdraft
Pair Function
Reset
(For WiFi enabled fans ONLY)
Power On/Off
Long
Press
Long
Press
Long
Press
Long
Press
Long
Press
Long
Press
Long
Press
Fan Speed
Control
LIGHTFUNCTIONS FANFUNCTIONS
KEYPRESS KEYPRESS
FUNCTION FUNCTION

www.CasablancaFanCo.com 1.888.227.2178
Maintenance & Cleaning
Cleaning the fan - use soft brushes or cloths
to prevent scratching. Cleaning products may
damage the nishes.
Be sure to turn off
power to the fan
before performing
any maintenance or
relamping.
OFF
Turn Power
18
M8546-01 • 03/23/17 • © 2017 Casablanca Fan Company

www.CasablancaFanCo.com 1.888.227.2178
Troubleshooting
Fan doesn’t work
• Press a fan speed button (up or
down arrow.
• Check the circuit breaker to
ensure the power is turned on.
• Check the wall control battery.
• Make sure the blades spin freely.
• Turn off power from the circuit
breaker, then loosen the canopy
and check all the connections
according to the wiring diagram
on pages 9, 10, and 18.
Excessive wobbling
• Turn the power off, support
the fan carefully, and check
that the hanger ball is
properly seated.
• Use the provided balancing
kit and instructions to balance
the fan.
Remote does not work
• Make sure the battery is installed
correctly.
• Install a new battery.
• If the remote still does not
work, you may need to pair
your remote. To prevent faulty
operation, please disconnect
power (at the wall switch,
breaker, or fan) from all other
ceiling fans within range while
pairing. To pair: cycle power
to the fan by turning power off
and back on at the wall switch
(or circuit breaker if necessary).
Within three minutes, press and
hold both the Fan and Light
button for four seconds to pair
the remote. If applicable, the
fan will turn on and the lights
will ash and stay on to indicate
successful pairing.
AUTHORIZED SERVICE
CENTERS
For the most updated list of
Casablanca Authorized Service
Centers, visit
www.CasablancaFanCo.com or
call toll free 1-888-227-2178.
LED lights will not dim
• To enable dimming, you
must rst set your remote to
Dimming Mode. To toggle
Dimming Mode on or off, long
press the up and down button
together.
Fan keeps spinning after power
is turned off
• The blades may take a few
minutes to come to a complete
stop. The powerful Casablanca
motor combined with the
unique blade design on this fan
allows for great air movement,
but this may cause the blades
to keep spinning for longer
than expected after power is
turned off.
19
M8546-01 • 03/23/17 • © 2017 Casablanca Fan Company

www.CasablancaFanCo.com 1.888.227.2178
Troubleshooting (continued)
Installing Multiple Fans with Independently Operating Remote Controls
Installing Multiple Fans Operating on a Single Remote Control
Installing One Fan Operating on Multiple Remote Controls
“Unpairing” Procedure for Faulty Operation of Remote Controls
X
To install multiple fans with independently operating remote controls, there is no need to
perform any pairing procedures. Each set of receiver/transmitter is already paired. Simply
install each receiver into a fan and use the appropriate transmitter to operate each fan.
If your remote is not working, see the “Remote does not work” section on the previous page.
To have multiple remote controls operate one fan, you must pair each additional transmitter
to the receiver in the fan. The transmitter that shipped with your fan is already paired.
Note: To prevent faulty operation, please disconnect power (at the wall switch,
breaker, or fan) from all other ceiling fans within range while pairing.
For each additional transmitter, cycle power to the fan by turning power off and back on at
the wall switch (or circuit breaker if necessary). Within three minutes, press and hold both
the Fan Off button and the 4 button for four seconds to pair the remote. If applicable, the
fan will turn on and the lights will ash and stay on to indicate successful pairing.
To have multiple fans operated by a single remote control, you must pair the transmitter to each
additional receiver. The receiver that shipped with your fan is already paired to the transmitter.
Note: To prevent faulty operation, you MUST disconnect power (at the wall switch,
breaker, or fan) from all other ceiling fans within range while pairing each fan.
For each additional fan, ensure that a compatible receiver is installed. Disconnect power from all
other fans while pairing. To pair: cycle power to the fan by turning power off and back on at
the wall switch (or circuit breaker if necessary). Within three minutes, press and hold both
the Fan Off button and the 4 button for four seconds to pair the remote. If applicable, the
fan will turn on and the lights will ash and stay on to indicate successful pairing.
If a transmitter is mistakenly operating a fan, you need to “unpair” the transmitter from that
fan’s receiver. The “unpairing” procedure is the same as the pairing procedure.
Note: To prevent faulty operation, you MUST disconnect power (at the wall switch,
breaker, or fan) from all other ceiling fans within range while “unpairing” a fan.
Disconnect power from all other fans while “unpairing.” Then, cycle power to the fan you
wish to “unpair” by turning power off and back on at the wall switch (or circuit breaker
if necessary). Within three minutes, press and hold both the Fan Off button and the 4
button for four seconds to “unpair” the remote. If applicable, the fan will turn off and the
lights will ash and turn off to indicate successful “unpairing.”
20
M8546-01 • 03/23/17 • © 2017 Casablanca Fan Company
