Casablanca MA038-01 User manual

Compatible with:
2xxxx Types A - Z
51000-58999 fan series
59500-59999 fan series
Select Casablanca Fans
Models 99258, 99259, 99260
MA038-01 • 04/27/15
Ceiling Fan Light KitCeiling Fan Light Kit
Installation Manual
Low ProleLow Prole

MA038-01 • 04/27/15
1.888.830.1326
2
Your light kit is compatible with most ceiling fans. The light kit will attach to the fan’s
switch housing. Begin on page 3 where you will choose the type of switch housing that
most closely resembles the one on your fan. From there, you will be directed to the set of
assembly instructions that are appropriate for installing the light kit to your fan.
Read entire installation instructions carefully before
beginning installation and save these instructions.
BEFORE YOU BEGIN
Switch
Housing
READ AND SAVE THESE INSTRUCTIONS
This product conforms to UL Standard 507.
WARNINGS
w.1 - To reduce the risk of re, electrical shock, or personal injury,
mount fan directly from building structure and/or an outlet box marked
acceptable for fan support of 70 lbs. (31.8 kg) and use the mounting screws
provided with the outlet box.
w.2 - To avoid possible electrical shock, before installing or servicing your
fan, disconnect the power by turning off the circuit breakers to the outlet
box and associated wall switch location. If you cannot lock the circuit
breakers in the off position, securely fasten a prominent warning device,
such as a tag, to the service panel.
c.1 - All wiring must be in accordance with national and local electrical codes
ANSI/NFPA 70. If you are unfamiliar with wiring, use a qualied electrician.
CAUTIONS
Turn Power
OFF

MA038-01 • 04/27/15
1.888.830.1326
3
If your fan’s switch housing cap resembles
this one, remove the whole switch
housing by removing the switch housing
screws with a Phillips head screwdriver.
Remove the two cap screws from the
inside of the switch housing. Reinstall
the switch housing. Tighten the switch
housing screws. Then follow the TYPE-A
ASSEMBLY INSTRUCTIONS on pages 4-5.
If your fan’s switch housing cap
resembles this one, remove the cap
screws with a Phillips head screwdriver.
Then follow the TYPE-A ASSEMBLY
INSTRUCTIONS on pages 4-5.
Switch
Housing
Cap
Cap
Screw
WHICH ASSEMBLY METHOD WILL I USE?
Switch
Housing
Cap
Switch
Housing
Screw
If your fan’s switch housing cap resembles
this one, remove the whole switch
housing by removing the switch housing
screws with a Phillips head screwdriver.
Remove the plug button using a standard
screwdriver. Then follow the TYPE-C
ASSEMBLY INSTRUCTIONS on pages 8-9.
Switch
Housing
Screw
Plug
Button
If your fan’s switch housing cap
resembles this one, remove the whole
switch housing by removing the switch
housing screws with a Phillips head
screwdriver. Remove the plug button.
Then follow the TYPE-B ASSEMBLY
INSTRUCTIONS on pages 6-7.
Switch
Housing
Screw
Plug
Button
Choose one of the four images below that most closely resembles the switch
housing on your fan; then follow the instructions under the image.

MA038-01 • 04/27/15
1.888.830.1326
4
Lift the light kit up to meet the lower
switch housing. Attach the light kit to
the switch housing using the keyhole
slots to engage the light kit screws.
Rotate clockwise. Tighten screws securely
through the access holes.
If necessary, attach the extension chain
provided to the fan pull chain coming
from the switch housing. Then feed the
end of the extension chain through the
grommeted hole in the light kit.
Screw the two light kit screws halfway into
the switch housing. Using the single pin
connectors, connect the black or blue wire
from the fan to the black wire from the
light kit. Connect the white wire from the
fan to the white wire from the light kit.
TYPE-A ASSEMBLY INSTRUCTIONS
Do not allow the light kit to hang
only by the wire connections!
If your fan does not have pin connectors on
the wires coming from the switch housing,
install the wiring harness provided. Using
the provided wire connectors connect the
white wire from the fan to the white wire
from the wire harness and connect the
black or blue wire from the fan to the black
wire from the wire harness.
Wire
Connector
Switch
Housing
Light Kit
Screw
1 2
3
Grommeted
Hole
Light Pull
Chain
Fan Pull
Chain
4
Access
Hole

MA038-01 • 04/27/15
1.888.830.1326
5
Installing the Pull chain pendant -
Attach the pull chain pendants to the
end of the short chains coming from the
switch housing and the light kit. Turn on
power. Your installation is complete!
Installing the bulb - Install a bulb into each
socket. When necessary, replace bulbs with
bulbs of same type and wattage.
Installing the globe - Press the globe
ush against the metal plate. Thread
the light pull chain through the hole in
the center of the nial cap and thread
the fan pull chain through the hole in
the side of the cap. Finally, thread only
the light pull chain through the hole in
the nial and screw the nial onto the
threaded rod.
TYPE-A ASSEMBLY INSTRUCTIONS (CONTINUED)
Globe
Finial
Cap
Finial
6
7
Socket
5

MA038-01 • 04/27/15
1.888.830.1326
6
TYPE-B ASSEMBLY INSTRUCTIONS
Using the single pin connectors, connect
the black or blue wire from the fan to the
black wire from the light kit. Connect the
white wire from the fan to the white wire
from the light kit.
If your fan does not have pin connectors on
the wires coming from the switch housing,
install the wiring harness provided. Using
the provided wire connectors connect the
white wire from the fan to the white wire
from the wire harness and connect the
black or blue wire from the fan to the black
wire from the wire harness.
Screw the two light kit screws halfway
into the switch housing. Feed the light kit
wires through the center hole in the switch
housing. Lift the light kit up to meet the
lower switch housing. Attach the light kit
to the switch housing using the keyhole
slots to engage the light kit screws.
Rotate clockwise. Tighten screws securely
through the access holes.
Lift the light kit assembly up so that the
screw holes in the lower switch housing
line up with the holes in the upper switch
housing. Install the switch housing
screws and tighten securely.
Switch
Housing
Screw
Wire
Connector
Switch
Housing
Do not allow the light kit to hang
only by the wire connections!
Light Kit
Screw
Switch
Housing
1 2
34
Access
Hole

MA038-01 • 04/27/15
1.888.830.1326
7
Installing the bulb - Install a bulb
into each socket. When necessary,
replace bulbs with bulbs of same
type and wattage.
If necessary, attach the extension chain
provided to the fan pull chain coming
from the switch housing. Then feed the
end of the extension chain through the
grommeted hole in the light kit.
TYPE-B ASSEMBLY INSTRUCTIONS (CONTINUED)
Installing the pull chain pendant -
Attach the pull chain pendants to the
end of the short chains coming from the
switch housing and the light kit. Turn
power on. Your installation is complete.
8
Installing the globe - Press the globe
ush against the metal plate. Thread the
light pull chain through the hole in the
center of the nial cap and thread the fan
pull chain through the hole in the side of
the cap. Finally, thread only the light pull
chain through the hole in the nial and
screw the nial onto the threaded rod.
Globe
Finial Cap
Finial
7
Socket
6
Grommeted
Hole
Light Pull
Chain
Fan Pull
Chain
5

MA038-01 • 04/27/15
1.888.830.1326
8
Lift the light kit assembly up so that the
screw holes in the lower switch housing
line up with the holes in the upper switch
housing. Install the switch housing
screws and tighten securely.
Upper
Switch
Housing
Using the single pin connectors, connect
the black or blue wire from the fan to the
black wire from the light kit. Connect the
white wire from the fan to the white wire
from the light kit.
Feed the wires through the switch
housing cap, washer, and nut. Then
install the switch housing cap by twisting
clockwise onto the threaded rod. Install
the washer and nut onto threaded rod
and tighten securely.
Threaded
Rod
Washer
and Nut
TYPE-C ASSEMBLY INSTRUCTIONS
If your fan does not have pin connectors on
the wires coming from the switch housing,
install the wiring harness provided. Using
the provided wire connectors connect the
white wire from the fan to the white wire
from the wire harness and connect the
black or blue wire from the fan to the black
wire from the wire harness.
Wire
Connector
Switch
Housing
Do not allow the light kit to hang
only by the wire connections!
1 2
34

MA038-01 • 04/27/15
1.888.830.1326
9
TYPE-C ASSEMBLY INSTRUCTIONS (CONTINUED)
If necessary, attach the extension chain
provided to the fan pull chain coming
from the switch housing. Then feed the
end of the extension chain through the
grommeted hole in the light kit.
Installing the pull chain pendant -
Attach the pull chain pendants to the
end of the short chains coming from the
switch housing and the light kit. Turn
power on. Your installation is complete.
8
Installing the globe - Press the globe
ush against the metal plate. Thread the
light pull chain through the hole in the
center of the nial cap and thread the fan
pull chain through the hole in the side of
the cap. Finally, thread only the light pull
chain through the hole in the nial and
screw the nial onto the threaded rod.
Globe
Finial
Cap
Finial
7
Installing the bulb - Install a bulb
into each socket. When necessary,
replace bulbs with bulbs of same
type and wattage.
Socket
6
Grommeted
Hole
Light Pull
Chain
Fan Pull
Chain
5

MA038-01 • 04/27/15
1.888.830.1326
10
ONE YEAR WARRANTY
This product is warranted to the original purchaser by Casablanca Fan Company/
Hunter Fan Company against defects in material and workmanship for one (1)
year from date of purchase. During the warranty period, we will repair or, at our
option, replace a defective product at no charge. For information on how to obtain
service, contact the Casablanca/Hunter Service Department by calling our toll-
free number at 888-830-1326. Damage to the product caused by mishandling,
improper installation or modication is not covered by this warranty. This warranty
is given in lieu of all other warranties expressed or implied. Some states do not allow
limitations of time on an implied warranty, therefore the above limitations may not
apply in every case. This warranty states specic legal rights which may vary from
state to state.
TROUBLESHOOTING
Lights don’t come on.
• Make sure that the bulbs are properly installed.
• Make sure power switch is on.
• Pull the pull chain to make sure it is on.
• Check the circuit breaker to ensure the power is turned on.
• Check the pin connections in the light kit.
• Refer to the fan manual for locating the fan’s wiring. Verify that the light and power
wires are correctly connected to the ceiling and the light kit.
If you have problems installing or operating your light kit, do not return this product
to the dealer. Call our Consumer Affairs Hotline.
888-830-1326
