Casall 1.1T Quick start guide

Dear Customer,
We are pleased, that you have a chosen Casall Fitness Equipment. This quality product has been designed
for in-home use and has been tested and certified according to the European Norm EN 9 7-1/6. Please
carefully read the instructions prior to assembly and first use and be sure to keep the instructions for
reference and maintenance.
We wish you lots of success and fun while training,
Warranty
Casall quality products have been designed and tested to meet the needs and requirements of a committed
Fitness-Training of in-home use. This product is tested to the Standard EN 9 7.
Casall warrants to the original purchaser 1 Years against possible defects in material.
Excluded from warranty are wearing parts and damages caused by misuse of the product. In the case of
claim please contact your specialist dealer.
The warranty period starts at the date the product was purchased (please carefully retain your sales
receipt).
For more info contact: kund[email protected]

Customer Service
To best possible support you in the case of problems with your product, we would ask you to please quote
the product Model Name and Serial Number.
These can be found on the sticker underside your product.
Model name:
Serial number:
Waste Disposal
Contact
If you have questions you cannot resolve with the help of this manual, or need to order replacement parts
please call the outlet from where you purchased this machine or email
[e-mail]
Please have the product model name, number and serial number ready when you call.
Casall products are recyclable. At the end of its useful life please dispose of this
article correctly and safely (local refuse sites).
Batteries and accumulators do not belong in the domestic waste. Please,
dispose this article correctly (local refuse sites).

Advice
The owner’s manual is only for the customer reference. Casall cannot guarantee for mistakes occurring due
to translation or change in technical specification of the product.
Precautions
Before assembling or using the treadmill, please read the following instructions carefully. They contain
important information for use and maintenance of the equipment as well as for your personal safety.
Keep these instructions in a safe place for maintenance purposes or for ordering spare parts.
 Product Scope: This product is made for home use only and tested up to a maximum body
weight of 100 kilograms.
 Product Performance: This treadmill is tested to the European Standard EN 957 1/6 HB. The
equipment is not suitable for therapeutic training.
 Product Scope: Noise compliance: This treadmill meets the requirements of the noise pollution
standards.
 Product Performance: The noise creation of treadmill is under 70db.
 Product Maintenance: For keeping the run quality use the provided silicon spray every month or
after a working time of 100 kilometers between the belt and the running surface.
 Product Maintenance: Search for noisy parts: If you should notice unusual noises, such as
grinding, clacking etc. try to locate it and have it repaired by a professional. Make sure the
treadmill is not used until after repairs have been made.
 Product Feature: The speed can be changed by the computer.
 Use Safety Key System: Insert the safety key in safety key base then fold up safety key to light
up the screen of console and fold down safety key to turn off the screen of console. If such
actions cannot be performed it means safety key is malfunctioning.
 Use Safety key: When the safety key is lifted up, it means the treadmill is powered. When the
safety key is pulled down, the treadmill is not powered.
 Use Safety: The function of the emergency stop: The Safety Key functions as the emergency
stop. In an emergency situation, remove the Safety Key from the console and the treadmill will
come to a stop.
 Note: The exerciser may not be used by persons with a weight of over 100 kg.
 Note: This product is designed for the physical exercise by adults. Please ensure that children only
use it under adult supervision
 Note: Ensure that those present are aware of possible hazards, e.g. movable parts during training.
 Note: Ensure that sufficient space is available to use the home exerciser with 2m long x 1m wide of
clearance behind it and 1m of clearance for its flanks.
 Note: Place the home exerciser on an even, non-slippery surface.
 Note: Please ensure that liquids or perspiration never enter the electronic components.

 Note: Keep the equipment indoors and away from moisture and dust. Do not put the equipment in
a garage, covered patio or near water. If stored in these locations your warranty will be affected.
 Note: The product is made for home use only. Warranty and manufacturer's liability do not extend to
any product or damage to the product caused by commercial use.
 Note: Consult your physician before starting with any exercise programs to receive advice on the
optimal training technique.
 Note: Incorrect/excessive training can cause health issues and injuries.
 Note: If you feel sickness, chest pain, fits of dizziness or breathlessness during your training, stop
training immediately and consult your physician.
 Note: Ensure that training only starts after correct assembly, adjustment and inspection of the home
exerciser.
 Note: Follow the steps of the assembly instruction carefully.
 Note: Only use suitable tools for assembly and ask for assistance if necessary.
 Note: Only use original Casall parts as delivered (see checklist).
 Note: Tighten all adjustable parts to prevent sudden movement while training.
 Note: We suggest using an equipment mat to prevent damage on the ground.
 Note: Please follow the advice as per correct training technique as detailed in the instructions.
 Note: Do not use the home exerciser without shoes or with loose fitting footwear.
Note: Be aware of the position and proper fixation of adjustable or moving parts while mounting or
dismounting the home exerciser.
 Note: Allow the belt to fully stop before dismounting.
 Note: never insert any part of your body or clothes into the body of the treadmill while it is running
or ready for use.
 Note: Attach the emergency stop cord to your clothing before starting the treadmill. The Treadmill
has an emergency stop mechanism for your safety. Before starting your workout, fasten the cord
of the safety key to your clothing. If the treadmill has been shut down by removing the safety key,
restart it by reinserting the key. An automatic restart of the treadmill belt does not occur. An
unmonitored use of the treadmill by other people can be prevented by removing the safety key and
keeping it safely hidden. In case of any emergency, hold on tightly to the handrail or handle bar with
both hands and leave the treadmill by means of the anti-slipping surface of the lateral platform.
Activate the emergency stop mechanism (safety cut-out).
 Note: Please keep the safety key in a safe place and ensure that it is kept out of reach of children!
 Note: The unit requires a power supply of 220V – 240V / 0Hz. It should be connected to a safety
socket with a dedicated 10A fuse. Before powering on and using the unit confirm that the unit is
plugged into the appropriate power supply (observe markings) has been connected properly.
 Note: If the equipment is in regular use, check all its components thoroughly every 1 – 2 months. Pay
particular attention to the tightness of bolts and nuts. This applies especially to the securing bolts for
saddle and handlebars.
 Note: Incorrect repairs and structural modifications (e.g. removal or replacement of original parts)
may endanger the safety of the user.

 Note: Damaged components may endanger your safety or reduce the lifetime of the equipment. For
this reason, worn or damaged parts should be replaced immediately and the user should refrain
from using the equipment until this has been done.
 Note: Only use original Casall replacement parts.
 Note: Do not under any circumstances carry out electrical repairs or alterations yourself. Always
ensure that such work is done by a properly qualified electrician/mechanic or from the advice of the
Technical Support team.
 Note: Disconnect the apparatus from the mains before doing repair, maintenance or cleaning work.
 Note: Heart rate monitoring systems may be inaccurate. Over exercising may result in serious
injury or death. If you feel any sort of discomfort stop exercising immediately.

Handle
pulse sensor
Safety key
iPad holder
Upright
Motor Cover
upper
Side rail
Running belt

Assembly

Unfold
1.
2.

3.
4.
11
2

5.
Connecting the power cord for treadmill and turning on the power switch(observe
markings).
Insert the safety key in safety key base then fold up safety key to light up the screen of console
and fold down safety key to turn off the screen of console.
Power plug
Power switch
Power socket
Safety key

6. How to assemle the mediaport housing and play music
USB Power charge
MP3 audio input
Audio input connection cable and USB connection cable need to pull out form mediaport housing

Press down
Play music

Folding
1.
2.
1
2

3.
4.

5.
6.

7.

Transport

Correct Use
Correct biomechanical position: Please refer to left picture. Running straight on the treadmill is
made easier by focusing on a fixed object in front of you in the room. Run as if you wanted to
approach the object. Always keep a distance which you can reach the front handle bar.
Major exercise type: This equipment focuses on your lower body, and it can train your thigh and
shank muscles
Important: Incorrect/excessive training can cause health issues and injuries.

GB: DECK LUBRICATION:
The walking belt has been pre-lubricated at the factory. However, it is recommended that the walking
board be checked periodically for lubrication to ensure optimal treadmill performance. Please ensure
the lubrication of the running belt is checked every 4-6 weeks after the initial 1 miles/kilometers of use.
Every 3 days or 3 hours of operation lift the sides of the walking belt and feel the top surface of the
walking board as far as you can reach. If you feel signs of silicone, no further lubrication is required. If it
feels dry to the touch, follow the instructions below. Please use a non-petroleum based silicone.
To apply lubricant to the walking belt:
1. Position the walking belt so that the seam is located on top and in center of the walking board.
2. Insert the spray nozzle into the spray head of the lubricant can if a nozzle is required.
3. While lifting the side of the walking belt, position the spray nozzle between the walking belt and the
board approximately 6" from the front of the treadmill. Apply the silicone spray to the walking board,
moving from the front of the treadmill to the rear. Repeat this on the other side of the belt. Spray
approximately 4 seconds on each side.
4. Allow the silicone to "set" for 1 minute before using the treadmill.
