Case 845B VHP User manual

845B VHP
865B VHP
885B VHP
Graders
Operator’s Manual
84498434
Replaces p/n. 84300297
1st Edition
English 03/12

II
Any use of editorial or pictorial content is strictly prohibited without express written permission from
CNH Latin America LTDA. – Av. Gal. David Sarnoff, 2237 – 32210-900 – Contagem MG – Brazil.
CNH Latin America LTDA.
reserves the right to make improvements in design or changes in specications at any time without
incurring any obligation to install them on units previously sold.
All data given in this publication is subject to production variations.
Dimensions and weights are only approximate.
Illustrations do not necessarily show products in standard condition.
For exact information about any particular product, please consult your Dealer.
GRADERS
845B VHP / 865B VHP / 885B VHP
84498434
1st Edition
English 03/12
This operation manual covers the following models:
845B VHP Graders, equipped with Tier 3 engine and ZF Transmission – Starting with NAAF12000 series
845B VHP Graders, equipped with Tier 3 engine and FUNK Transmission – Starting with NAAF13000 series
865B VHP Graders, equipped with Tier 3 engine and ZF Transmission – Starting with NAAF14000 series
865B VHP Graders, equipped with Tier 3 engine and FUNK Transmission – Starting with NAAF15000 series
885B VHP Graders, equipped with Tier 3 engine and ZF Transmission – Starting with PCAF00871 series
885B VHP Graders, equipped with Tier 3 engine and FUNK Transmission – Starting with NAAF16000 series
READ, UNDERSTAND, AND FOLLOW ALL PRECAUTIONS
AND SAFETY INSTRUCTIONS CONTAINED IN THIS MANUAL
BEFORE OPERATING THE MACHINE.

III
ATTENTION: THIS WARNING SYMBOL INDICATES AN IMPORTANT SAFETY MESSAGE CONTAI-
NED IN THIS MANUAL. WHEN YOU SEE THIS SYMBOL, READ THE FOLLOWED MESSAGE CARE-
FULLY AND BE AWARE TO THE POSSIBILITY OF PERSONAL INJURY OR DEATH.
The alert symbol indicated on this machine use the words Danger, Warning or Caution, which are dened
in the following way
DANGER:
• indicates an immediate danger situation which, if not avoided, will cause death of seve-
re injuries. The color associated to the Danger is RED.
WARNING:
• indicates a potential danger situation which, if not avoided, will cause severe injuries.
The color associated to Warning is ORANGE.
CAUTION:
• indicates a potential danger situation which, if not avoided, may cause a minor or mo-
derate injury. It can also be used to warn against unsafe practices. The color associated to Caution
is YELLOW.
In case the Safety Decals of this machine are ISO two graphic panels type, the decals are dened as follows:
The rst plate indicates the nature of danger.
•
The second plate indicates the proper actions to prevent the danger. •
The background color is YELLOW. •
Symbols of prohibition such as • and
PARE
if used, are in RED.
!
WARNING
THE UNDUE OPERATION OF THIS MACHINE MAY CAUSE INJURY OR DEATH. BEFORE USING
THIS MACHINE, MAKE SURE EACH OPERATOR:
Has been instructed on the safety and proper use of the machine.
•
Has read and understood the manual(s) which is (are) related to the machine. •
Has read and understood ALL alert symbol indicated on the machine. •
Has emptied the area. •
Learn and practice the safety information for this machine in an isolated area before opera- •
ting it at a working place.
The operator is responsible for observing the corresponding laws and regulations, and following the
instructions given by CASE on the operation and maintenance of the machine.

IV

V
TABLE OF CONTENTS
Chapter 1
GENERAL INFORMATION
TO THE OWNER ................................................................................................................................................... 1-1
OPERATOR MANUAL STORAGE COMPARTMENT ............................................................................................ 1-3
RIGHT, LEFT, FRONT AND REAR SIDES OF THE MACHINE ............................................................................. 1-3
IDENTIFICATION NUMBERS ................................................................................................................................ 1-4
MACHINE COMPONENTS .................................................................................................................................... 1-7
Chapter 2
SAFETY / DECALS / HAND SIGNALS
SAFETY RULES .................................................................................................................................................... 2-1
BEFORE OPERATION .......................................................................................................................................... 2-2
MACHINE OPERATION ......................................................................................................................................... 2-3
ADDITIONAL SAFETY RULES .............................................................................................................................. 2-5
PARKING THE MACHINE AND STOPPING THE ENGINE ................................................................................... 2-6
BURN PREVENTION ............................................................................................................................................. 2-6
FIRE EXTINGUISHER ........................................................................................................................................... 2-6
FIRE OR EXPLOSION PREVENTION .................................................................................................................. 2-7
MAINTENANCE ..................................................................................................................................................... 2-8
WHEEL AND TIRE MAINTENANCE ...................................................................................................................... 2-9
ROLL-OVER PROTECTIVE STRUCTURE (ROPS) .............................................................................................. 2-9
MAINTENANCE ................................................................................................................................................... 2-10
READ OPERATORS MANUAL ............................................................................................................................ 2-13
SAFETY RULES .................................................................................................................................................. 2-13
SYMBOLS ............................................................................................................................................................ 2-14
SAFETY DECALS ................................................................................................................................................ 2-16
HAND SIGNALS .................................................................................................................................................. 2-22
Chapter 3
INSTRUMENTS AND CONTROLS
OPERATOR’S COMPARTMENT ........................................................................................................................... 3-1
FRONT CONSOLE ................................................................................................................................................ 3-2
GRADERS OPERATIONS WITH ZF POWER-SHIFT TRANSMISSION ............................................................. 3-36
GRADERS OPERATIONS WITH FUNK TRANSMISSION .................................................................................. 3-39
PARKING BRAKE (845B / 865B / 885B MODELS WITH ZF TRANSMISSION) .................................................... 3-41
AIR CONDITIONING, HEATING AND AIR CIRCULATING SYSTEM .................................................................. 3-42
OPERATORS SEAT ............................................................................................................................................. 3-44
SEAT BELT .......................................................................................................................................................... 3-46
PARKING BRAKE (845B / 865B / 885B MODELS WITH FUNK TRANSMISSION) ............................................. 3-46
CAB ...................................................................................................................................................................... 3-47

TABLE OF CONTENTS
VI
Chapter 4
OPERATING INSTRUCTIONS
BEFORE STARTING THE ENGINE ....................................................................................................................... 4-1
FIRST SERVICE INTERVALS ............................................................................................................................... 4-3
AFTER FIRST 100 HOURS OF OPERATION ....................................................................................................... 4-3
SEAT BELT ............................................................................................................................................................ 4-3
DIFFERENTIAL LOCK ........................................................................................................................................... 4-3
RUN-IN ................................................................................................................................................................... 4-4
BOOSTER BATTERY CONNECTIONS ................................................................................................................. 4-5
JUMP START ......................................................................................................................................................... 4-6
OPERATION .......................................................................................................................................................... 4-7
TYPICAL OPERATION ........................................................................................................................................ 4-13
TRANSPORTING AN OUT OF SERVICE MACHINE .......................................................................................... 4-16
Chapter 5
WHEELS AND TIRES
WHEELS AND TIRES ............................................................................................................................................ 5-1
Chapter 6
LUBRICATION / FILTERS / FLUIDS
GENERAL SAFETY BEFORE YOU SERVICE ...................................................................................................... 6-1
ENGINE HOURMETER ......................................................................................................................................... 6-2
TRANSPORT AND MAINTENANCE SERVICE PIN .............................................................................................. 6-3
ENGINE HOOD ...................................................................................................................................................... 6-3
MAINTENANCE ..................................................................................................................................................... 6-4
SYSTEMGARD LUBRICATION ANALYSIS PROGRAM ....................................................................................... 6-4
FLUIDS AND LUBRICANTS .................................................................................................................................. 6-5
LUBRICATION & MAINTENANCE CHART ........................................................................................................... 6-6
ACCESS DOORS .................................................................................................................................................. 6-8
FLUID LEVELS ...................................................................................................................................................... 6-9
HYDRAULIC TANK AND ENGINE FUEL FILTER ................................................................................................. 6-11
GREASE FITTINGS ............................................................................................................................................. 6-12
ENGINE ............................................................................................................................................................... 6-17
AIR FILTER SYSTEM .......................................................................................................................................... 6-20
ENGINE COOLING SYSTEM .............................................................................................................................. 6-22
FUEL SYSTEM .................................................................................................................................................... 6-25
HYDRAULIC / BRAKE SYSTEM ......................................................................................................................... 6-29
TRANSMISSION .................................................................................................................................................. 6-32
REAR AXLE ......................................................................................................................................................... 6-37
TANDEM .............................................................................................................................................................. 6-39
SWING / CIRCLE TURN GEAR BOX .................................................................................................................. 6-40
WINDSHIELD WASHER RESERVOIR (OPTIONAL) .......................................................................................... 6-40

TABLE OF CONTENTS
VII
Chapter 7
MAINTENANCE AND ADJUSTMENT
CHECKING OF THE PARKING BRAKE ................................................................................................................ 7-1
ROLL-OVER PROTECTIVE STRUCTURE (ROPS) .............................................................................................. 7-3
TORQUE SPECIFICATIONS FOR SEAT AND SEAT BELTS ................................................................................ 7-5
CAB HEADLINER .................................................................................................................................................. 7-6
DOORS HINGES ................................................................................................................................................... 7-6
HOSES AND WIRING ............................................................................................................................................ 7-6
FIRE EXTINGUISHER MOUNTING (IF EQUIPPED) ............................................................................................ 7-6
ALTERNATOR BELT AND AIR CONDITIONING COMPRESSOR BELT .............................................................. 7-7
CIRCLE GUIDES ................................................................................................................................................... 7-8
Chapter 8
ELECTRICAL SYSTEM
BATTERY SAFETY ................................................................................................................................................ 8-1
BATTERY SERVICE .............................................................................................................................................. 8-2
STARTING THE ENGINE USING BOOSTER BATTERIES ................................................................................... 8-3
TRANSMISSION AUXILIARY SYSTEM ................................................................................................................ 8-4
PRECAUTIONS TO BE TAKEN BEFORE PERFORMING ANY WELDING PROCEDURE ON THE MACHINE .. 8-6
FUSE BOX ............................................................................................................................................................. 8-8
RADIO .................................................................................................................................................................. 8-13
Chapter 9
MACHINE STORAGE
MACHINE STORAGE ............................................................................................................................................ 9-1
Chapter 10
SPECIFICATIONS
ENGINE ............................................................................................................................................................... 10-1
TRANSMISSION .................................................................................................................................................. 10-4
TIRES ................................................................................................................................................................... 10-5
BRAKES ............................................................................................................................................................... 10-5
TANDEM .............................................................................................................................................................. 10-5
FRONT AXLE ....................................................................................................................................................... 10-5
REAR AXLE ......................................................................................................................................................... 10-5
STEERING ........................................................................................................................................................... 10-6
ELECTRICAL SYSTEM ....................................................................................................................................... 10-6
OPERATING WEIGHTS ...................................................................................................................................... 10-7
CIRCLE .............................................................................................................................................................. 10-10
DRAW BAR ........................................................................................................................................................ 10-10
FRAME ............................................................................................................................................................... 10-10
BLADE (MOLDBOARD) ...................................................................................................................................... 10-11
HYDRAULIC SYSTEM ....................................................................................................................................... 10-12
ACCESSORIES ................................................................................................................................................. 10-13
OPERATING DATA AND DIMENSIONS ............................................................................................................ 10-14

TABLE OF CONTENTS
VIII
Chapter 11
ALPHABETICAL INDEX
ÍNDICE .................................................................................................................................................................. 11-1
Chapter 12
WARRANTY
TERM OF WARRANTY ........................................................................................................................................ 12-1
AFTER DELIVERY CHECK ................................................................................................................................. 12-3

1-1
Chapter 1
GENERAL INFORMATION
TO THE OWNER
Graders CASE
845B VHP / 865B VHP / 885B VHP
Read this manual before you start the engine or operate the machine. If you need more information, see your dealer.
Your dealer can give you help with CASE approved service parts. Your dealer has specially trained technicians who
know the best methods of repair and maintenance for your machine.
Use this manual as a guide. Your Grader will remain a reliable working tool as long as it is kept in working condition
and serviced properly.

CHAPTER 1 - GENERAL INFORMATION
1-2
DO NOT operate or permit anyone to operate or service this machine until you or the other persons have read and
understand the safety, operation and maintenance instructions in this manual. Use only trained operators who have
demonstrated the ability to operate and service this machine correctly and safely.
This motorgrader, with standard equipment and attachments, is intended to be used for above ground level general
earth moving purpose such as land leveling and material rehandling.
DO NOT use this machine for any application or purpose other than those described in this manual. If the mo-
torgrader is to be used in an application that involves special attachments or equipment, such as forestry, etc., consult
an authorized dealer or the CASE. Consult an authorized dealer or CASE on changes, additions or modications that
can be required for this machine to comply with various country regulations and safety requirements.
Unauthorized modications can cause serious injury or death. Anyone making such unauthorized modications is res-
ponsible for the consequences.
This Operators Manual is to be stored in the manual compartment equipped on this machine. Make sure this manual
is complete and in good condition. Contact you dealer to obtain additional manuals. Contact your dealer for any further
information or assistance about your machine. Your dealer has CASE approved service parts. Your dealer has techni-
cians with special training that know best methods of repair and maintenance for your motorgrader.
Before permitting a new operator on this machine, make sure:
That the operator has received the necessary training on how to operate the machine correctly and safely in one of1.
our training centers or from an approved organization.
That the operator has read and understood the instructions given in this manual.2.
Call your dealer if you need any assistance or information.

CHAPTER 1 - GENERAL INFORMATION
1-3
OPERATOR MANUAL STORAGE COMPARTMENT
READ THIS MANUAL COMPLETELY and make sure
you understand the controls. All equipment has a limit.
Make sure you understand the speed, brakes, steering,
stability and other characteristics of this machine before
you start to operate.
DO NOT remove this manual from the machine. See your
dealer for additional manuals.
OPERATORS MANUAL STORAGE COMPARTMENT
RIGHT, LEFT, FRONT AND REAR SIDES
OF THE MACHINE
Right-hand and left-hand, when used in this manual, indicate the right and left sides of the machine as seen from the
operators seat.
REAR
RIGHT SIDE
LEFT SIDE
FRONT

CHAPTER 1 - GENERAL INFORMATION
1-4
IDENTIFICATION NUMBERS
Write your machine Product Identication Number (P.I.N.) and Serial numbers on the lines provided below. If needed,
give these numbers to your dealer when you need parts or information for your machine. Make a record of the numbers.
Keep the record in a safe place. If the machine is stolen, report the numbers to your local law enforcement agency.
MACHINE MODEL NUMBER _____________________________________________________________________
PRODUCT IDENTIFICATION NUMBER ____________________________________________________________
ENGINE SERIAL NUMBER ______________________________________________________________________
TRANSMISSION MODEL AND SERIAL NUMBER ____________________________________________________
ROPS CAB OR CANOPY SERIAL NUMBER ________________________________________________________
FRONT AXLE MODEL AND SERIAL NUMBER _______________________________________________________
REAR AXLE MODEL AND SERIAL NUMBER ________________________________________________________


CHAPTER 1 - GENERAL INFORMATION
1-5
Transmission Number
ZF TRANSMISSION FOR 845B / 865B / 885B MODELS FUNK TRANSMISSION FOR 845B / 865B / 885B MODELS
Engine Number

CHAPTER 1 - GENERAL INFORMATION
1-6
Rear Axle Number
REAR AXLE FOR 845B MODELS REAR AXLE FOR 865B / 885B MODELS
ROPS Cab and Canopy

CHAPTER 1 - GENERAL INFORMATION
1-7
MACHINE COMPONENTS
11
12
13
HAND RAILS1.
ROPS CAB2.
BLADE LIFT CYLINDER3.
BLADE CIRCLE4.
ARTICULATION CYLINDER5.
STEPS6.
ENGINE ACCESS HOOD7.
FRONT BRADE8.
REAR RIPPER9.
DRAWBAR CIRCLE AND BLADE10.
CIRCLE SIDE SHIFT CYLINDER11.
BLADE PITCH CYLINDER12.
BLADE SIDE SHIFT CYLINDER13.
TRANSPORT SERVICE PIN14.
2
3
1
4
5
6
7
8
9
10
14

CHAPTER 1 - GENERAL INFORMATION
1-8
LIFT AND TIE EYES (IF EQUIPPED)15.
AIR CONDITIONING CONDENSER16.
(FOR 845B / 865B / 885B MODELS WITH FUNK TRANSMISSION)
FAN HYDRAULIC FLUID COOLER17.
(FOR 845B / 865B / 885B MODELS WITH FUNK TRANSMISSION)
HYDRAULIC FILTER18.
RADIATOR AND FAN19.
TRANSMISSION FLUID COOLER20.
(FOR 845B / 865B / 885B MODELS WITH ZF TRANSMISSION)
AIR CONDITIONING CONDENSER21.
(FOR 845B / 865B / 885B MODELS WITH ZF TRANSMISSION)
FAN HYDRAULIC FLUID COOLER AND AIR CONDITIONING CONDENSER22.
(FOR 845B / 865B / 885B MODELS WITH ZF TRANSMISSION)
15 15
17 16
18
19
20
21
22

2-1
SAFETY RULES
Chapter 2
SAFETY / DECALS / HAND SIGNALS
Most accidents involving machine operating and mainte-
nance can be avoided by following basic safety rules and
precautions. Read and understand all the safety messa-
ges in this manual, and the safety signs on the machine
before you operate or service the machine. See your de-
aler if you have any questions.
READ THIS MANUAL COMPLETELY and make sure you
understand the controls. All equipment has a limit. Make
sure you understand the speed, brakes, steering, stability
and other characteristics of this machine before you start
to operate.
DO NOT remove this from the machine. See your dealer
for additional manuals. Also see the manual information
on the inside of the rear cover of this manual.
The safety information given in this manual does not replace
safety codes, insurance needs, federal, state or local laws.
Make sure that your machine has the correct equipment ac-
cording to these rules or laws.
IMPORTANT: Safety messages in this section point out
situations which can happen during the normal operation
and maintenance of your machine. These safety messa-
ges also give possible ways of dealing with these condi-
tions.
Additional safety messages are used in the text of the
manual to show specic safety hazards.
ATTENTION: THIS SAFETY ALERT SYM-
BOL INDICATES IMPORTANT SAFETY
MESSAGES IN THIS MANUAL. WHEN YOU
SEE THIS SYMBOL, CAREFULLY READ
THE MESSAGE THAT FOLLOWS AND BE
ALERT TO THE POSSIBILITY OF PERSO-
NAL INJURY OR DEATH.
OPERATORS MANUAL STORAGE COMPARTMENT

CHAPTER 2 – SAFETY / DECALS / HAND SIGNALS
2-2
BEFORE OPERATION
Different jobs will require different protective equip- •
ment. Items such as hard hats, protective shoes, hea-
vy gloves, reector type vests, respirators, ear protec-
tion, and eye protection can be required. Before you
start the job, determine what protective equipment is
required. Use this equipment at all times.
Be prepared for emergencies. Always have a rst aid •
kit and a working re extinguisher with you and know
how to use each.
Know the hand signals used on your job. Follow the •
instructions of the agman, signs, etc. See Hand Sig-
nals for more information.
Know the rules, laws, and safety equipment necessa- •
ry for transporting this machine on a road or highway.
Rotating beacon, backup alarm, slow moving vehicle
emblem and other safety equipment items are availa-
ble from your dealer CASE.
Avoid loose tting clothing, loose or uncovered long •
hair, and jewelry.
Check that all doors, guards, and covers are installed •
correctly or closed.
Foreign material or grease on the steps and hand rails •
can cause an accident. Keep the steps and hand rails
clean.
To avoid falling, always face the machine and use •
the hand rails and steps when getting on or getting
off. This will provide greater security in the movement
of the feet and hands, thereby helping to avoid acci-
dents.
Remove all loose objects from the cab. Loose objects •
can jam controls and cause accidents.
Operate the machine controls from the operators seat •
only.
Before you start the engine, always fasten the seat •
belt. Securely fasten your seat belt. Your machine is
equipped with a ROPS cab or canopy for your protec-
tion. The seat belt can help insure your safety if it is
used correctly and maintained. Never wear a seat belt
loosely or with slack in the belt system. Never wear
the seat belt in a twisted condition.
1
1
2
HAND RAILS1.
STEPS2.
Before you start each day, walk around the machine •
and check for oil or uid leaks. Replace all broken
or missing parts and do the required lubrication and
maintenance as shown in this manual. Clean all trash
and debris from the machine, especially from the en-
gine area.
Make sure all persons are away from the machine be- •
fore you start the engine.
Before starting the engine make sure that the parking •
brake is applied and all controls are in NEUTRAL po-
sition.
The horn must be activated to alert the people present •
in the working area.
Before you operate at night, check that all lamps illu- •
minate.
If your machine has a cab make sure that all win- •
dows are clean and that the windshield wipers work
correctly.

CHAPTER 2 – SAFETY / DECALS / HAND SIGNALS
2-3
MACHINE OPERATION
Do not steer the steering wheel if any person is pre- •
sent next to the machine and the center articulation.
Check all controls in a clear area and make sure the •
machine is operating correctly.
A frequent cause of accidents with injuries or death •
is people falling from the machine and subsequent
trampling. DO NOT allow other persons to ride on
the machine. Other persons can fall or can cause
an accident. This is a one person machine with one
operator’s seat.
Engine exhaust fumes can cause death. If you operate •
this machine in an enclosed area, make sure there is
ventilation to replace the exhaust fumes with fresh air.
Dust, fog, smoke, etc., can decrease your vision and •
cause an accident. Stop the machine or decrease the
speed until you can see everything around you in the
work area.
Contact with high voltage power lines, underground •
cables, etc., can cause serious injury or death from
electrocution. Make sure there is enough space be-
tween the machine and ohigh voltage power lines.
Before you drive or operate in an area with high volta-
ge lines, cables, or a power station, tell the power or
utility company what you are going to do. You MUST
HAVE THE POWER DISCONNECTED OR KEEP A
SAFE WORKING DISTANCE from the lines, cables,
or power station. Keep all parts of the machine at least
15 feet (5 m) away from the power source. You must
also know any federal, state / provincial, or local safe-
ty codes or regulations that apply to the job site.
If a part of the machine touches high voltage power: •
Warn other workers NOT TO TOUCH THE MA- •
CHINE and to stay away from the machine.
If you can break contact, reverse the operation that •
caused contact with the high voltage power, and
move the machine away from the danger area. If
you cannot break contact, stay in the machine until
the utility company de-energizes the line and tells
you that the power is off.
If you have extreme conditions, such as a re, etc., •
and you are forced to leave the machine, do not
step off the machine. Jump as far from the machi-
ne as possible with your feet together and do not
touch the ground with your hands.
Then, hop away with your feet together until you •
are a safe distance from the machine and the elec-
trical current. Do not take large steps. Because of
the voltage differential across the ground, one foot
can be in a higher voltage area than the other foot.
This difference can kill you.
Digging through underground cables, pipes, lines, •
etc., can cause injury or death. Learn the location of
all underground hazards before you operate your ma-
chine in any area.
If this machine roll over, you may hurt yourself or die. •
You must make a judgment if weather, road, or earth
conditions will permit safe operation on a hill, ramp, or
rough ground.
Stay away from hazardous areas such as ditches, •
overhangs, etc. Walk around the work area before you
start and look for hazards.
Be alert and always know the location of all workers •
in your area. Keep all other persons completely away
from your machine. Injury or death can result if you do
not follow these instructions.
When working in areas where trafc is heavy always •
have a person direct the trafc and direct other per-
sons for you. Have guard rails, warning signs, etc., as
required for your job.
Stop operating the machine if a malfunction occurs. •
Watch the indicator and warning lamps in the machi-
ne. Listen and smell for things that are not normal on
your machine.
Drive around large objects such as large rocks or trees. •
Operate the machine within the specied capacities •
and limits. See Specications section of this manual.
Operate the machine controls from the operators •
seat only.
DO NOT operate this machine if under alcohol or drug •
effect.

CHAPTER 2 – SAFETY / DECALS / HAND SIGNALS
2-4
Start Up
Do not start or operate an unsafe machine. Before •
working the machine, be sure that any unsafe condi-
tion has been satisfactorily remedied.
Check brakes and steering and attachment controls •
before moving. Advise the proper maintenance autho-
rity of any malfunction part or system.
Before starting machine, check, adjust and lock the •
operator’s seat for maximum comfort and control of
the machine.
Be sure all people in the area are clear of the unit •
before releasing the parking brake or moving the ma-
chine or its attachments. Walk completely around ma-
chine before mounting. Sound horn.
Obey agman, safety signals and signs. •
Due to the presence of ammable uid, never check or •
ll fuel tanks, storage batteries, or use starter uid near
lighted smoking materials or open ame or sparks.
Operating
Do not run the engine of this machine in closed area •
without proper ventilation to remove deadly exhaust
gases.
Do not use machine to carry loose objects by means •
other than attachments designed for such objects.
Do not carry riders unless the machine is equipped for •
carrying people to reduce personal exposure to being
thrown off.
Observe and know the mechanics of alternate exit •
routes.
Do not attempt to climb on or off machine while it is •
in motion.
When operating always look at the direction of the •
movement of the machine. Be sure exposed person-
nel in the area of operation are clear of the unit before
moving the machine or its attachments, mainly chil-
dren. If someone arrives in operation area, stop the
machine immediately.
Maintain a safe distance from other machines. Provi- •
de sufcient clearance for ground and visibility con-
ditions.
Shut Down
Never leave the machine unattended with the engi- •
ne running. Always before leaving the operator’s seat
and after making certain all people are clear of the
machine, slowly lower attachments or tools at to the
ground in a positive ground support position. Move
any multipurpose tool or attachment to positive closed
position. Return the controls to hold. Place transmis-
sion control in neutral and move engine controls to off
position. Engage all control locks, set parking brake,
and open and lock the master (key) switch.
Park in a nonoperating and non-trafc area or as ins- •
tructed.
Park on rm level ground if possible. Where not pos- •
sible, position machine at a right angle to the slope,
making sure there is no danger of uncontrolled sliding
movement. Set the parking brake. If parking in trafc
lanes cannot be avoided, provide appropriate ags,
barriers, ares and warning signals in the trafc lane
for approaching trafc.
Never lower attachments or tools from any position •
other than seated in operator’s seat.
