Casio BOULDER GzOne User manual

V CAST PHONE with PUSH TO TALK
KN9230-AVZW-5 ver1.0
TELÉFONO V CAST con PUSH TO TALK
User Guide
User Guide
Guía del Usuario

Contents
Getting Started with Your Phone 7
Phone Overview 7
Menus Overview 15
The Battery 18
Charging the Battery 20
Battery Level 22
Turning the Phone On and Off 22
Making Calls 23
Redialing Calls 23
Receiving Calls 23
Screen Icons 24
Menu Access 25
Using a Memory Card 27
Quick Access to Convenient Features 31
Using the Headset Adapter/2.5mm Splitter 31
Vibrate Mode 31
Lock Mode 32
Mute Function 32
Volume Quick Adjustment 32
Call Waiting 33
Caller ID 33
Voice Commands 34
Speed Dialing 34
Entering and Editing Information 35
Text Input 35
Text Input Modes 36
Contacts in Your Phone’s Memory 39
The Basics of Storing Contacts Entries 39
Options to Customize Your Contacts 40
Editing Contacts Entries 44
Deleting 47
Phone Numbers with Pauses 49
1

Searching Your Phone’s Memory 51
Making a Call from Your Phone’s Memory 52
MEDIA CENTER 56
Music & Tones 57
V CAST Music with Rhapsody®58
Get New Ringtones 59
My Ringtones 60
My Music 61
My Sounds 62
Sync your music from your PC to your V CAST
Music with Rhapsody®wireless device 64
Picture & Video 65
V CAST Videos 66
Get New Pictures 69
My Pictures 70
My Videos 73
Take Picture 75
Record Video 77
Online Album 78
Games 78
Mobile Web 79
Browse & Download 82
Extras 83
Info 83
MESSAGING 84
New Message 85
Inbox 92
Sent 94
Drafts 96
Voicemail 97
Mobile IM 98
Email 98
2

Contents
Chat 99
Message Settings 99
Message Erase 101
CONTACTS 103
New Contact 104
Contact List 105
Groups 105
New PTT Contact 108
PTT Contact List 108
PTT Groups 109
Speed Dials 110
In Case of Emergency (ICE) 111
My Name Card 113
RECENT CALLS 114
Missed 115
Received 116
Dialed 117
Blocked 118
All 119
View Timers 120
Push to Talk 121
PTT Settings 121
PTT Contact List 121
New PTT Contact 122
Erasing a PTT Contact 123
PTT Groups 123
Temp PTT Group 125
Making a PTT Call 127
Incoming PTT Call 131
PTT Screen Icons 132
3

SETTINGS & TOOLS 135
My Verizon 135
Tools 136
Voice Commands 136
Calculator 140
Calendar 141
Alarm Clock 142
Stop Watch 143
Countdown Timer 144
World Clock 145
Notepad 146
Electronic Compass 146
Bluetooth Menu 149
Power 150
Add New Devices 150
Options 154
Sending and Receiving Name Cards 156
Sending and Receiving Images 158
Sounds Settings 159
Call Sounds 159
Alert Sounds 160
Keypad Volume 162
Service Alerts 162
Power On/Off 163
Folder On/Off 163
Display Settings 164
Banner 164
Backlight 165
Contrast 166
Wallpaper 166
Display Themes 167
Main Menu Settings 167
Dial Fonts 168
4

Contents
Clock Format 168
Power Saver 169
Phone Settings 169
Airplane Mode 170
Set Shortcuts 171
Voice Commands 173
Language 174
Location 174
Security 175
System Select 180
NAM Selection 181
Call Settings 182
Answer Options 182
Auto Retry 183
TTY Mode 183
One Touch Dial 184
Voice Privacy 185
PC Connections 185
DTMF Tones 186
Memory 186
Save Options 187
Phone Memory 187
Card Memory 189
Phone Info 190
My Number 191
SW/HW Version 191
Icon Glossary 192
Software Update 193
Included Items 195
Safety 196
TIA Safety Information 196
Safety Information for FCC RF Exposure 200
5

FDA Information 203
Emergency Calls 212
Compliance with Other FCC Regulations 215
General Safety 215
Games 222
Camera 224
Accessibility 224
RECYCLE YOUR CELL PHONE! 229
12 MONTH LIMITED WARRANTY 231
Index 235
6

Getting Started with Your Phone
Phone Overview
1. Earpiece
2. LCD Screen
3. Left Soft Key
4. Camera/
Video Key
5. Send Key
6. Voicemail Key
7. Clear Key
8.Voice
Command Key
(when flip is open)
9. International
Dialing Code Key
10. Next Key
11. Directional Key
12. Center Select Key
13. Right Soft Key
14. Speaker/Flashlight Key
15. End/Power Key
16. Alphanumeric Keypad
17. Vibrate Mode Key
21. Microphone
18. Memory Card Slot 19. PTT Key
20. Volume Keys
22. Accessory Connector
Port 8. Electronic Compass, Countdown Timer,
Stop Watch (when flip is closed)
7

25. Internal Antenna
Area*
23. Camera Flash/ 26. Camera Lens
Flashlight
24. Outside Display
27. Customizable
Ring
30. Speaker
28. Screw Type
Battery Lock
31. Battery
29. Charging
Terminals
22. Accessory
Connector Port
* For best performance, do not touch this area when using your phone.
8

Getting Started with Your Phone
1. Earpiece
2. LCD Screen
Displays messages and indicator icons.
3. LLeft Soft Key
Press to display the Message menu or access the
function listed above the key.
4. VCamera/Video Key
Press for quick access to Camera/Video.
5. Send Key
Press to place or answer calls. In standby mode,
press to access your All Calls list.
6. 1Voicemail Key
Press and hold to call Voicemail.
7. CClear Key
When entering a phone number or text, press to
delete a single space or character. Press and hold
to delete entire words. Press this key once in a
menu to go back one level.
8. .Voice Command Key
When the phone is open, press to access the
Voice Commands/Voice Recorder function.
When the phone is closed, press and hold to
change between the Watch, Electronic Compass,
Countdown Timer, and the Stop Watch functions
on the external display.
9

9. *International Dialing Code Key
Press and hold to enter a plus “+”. A “+” is
reserved for international dialing code.
10. 0Next Key
In T9 mode, press to display other matching
words.
11. aDirectional Key
Press the Directional Key aleft to access My
Verizon, down to access the Calendar, up to
access Mobile Web, and right to access My
Shortcuts.
12. cCenter Select Key
Press to select a function.
13. RRight Soft Key
Press to display Contacts or to access the function
listed above the key.
14. FSpeaker/Flashlight Key
Press to turn Speakerphone on/off. You can
switch from the earpiece to the speaker by turning
on Speakerphone before starting a call or while a
call is in progress. Press and hold to toggle the
flashlight on/off when the phone is in idle mode.
15. End/Power Key
Press to toggle power on/off and to end a call.
Also, press to return to the standby screen.
10

Getting Started with Your Phone
16. Alphanumeric Keypad
Press to enter numbers and characters and to
select menu items.
17. #Vibrate Mode Key
Press and hold to turn Vibrate Mode on/off. In
Vibrate Mode, all phone sounds including
ringtones and keypad tones are silenced.
18. Memory Card Slot
You can insert a microSD™ memory card here to
increase memory capacity.
19. ,PTT Key
Press and hold to utilize Push to Talk (PTT) when
the phone is in PTT mode.
20. <> Volume Keys
Press to set or reset Volume Up/Down/Electronic
Compass/Stopwatch/Countdown Timer.
Press while the phone is ringing to stop it.
21. Microphone 22. Accessory Connector
Port
23. Camera Flash/ 24. Outside Display
Flashlight
25. Internal Antenna 26. Camera Lens
Area
27. Customizable Ring 28. Screw Type Battery
Lock
29. Charging Terminals 30. Speaker
31. Battery
11

kDevice Lock Tool
For Customizable Ring removal For battery removal
(see below) (see page 19)
For memory card removal
(see page 30)
kRemoving the Customizable Ring
Insert the corner of the Device Lock Tool marked
with the ring icon under the Customizable Ring as
illustrated below and then pry up the Customizable
Ring.
Warning! Be sure to use only the Device Lock Tool that comes
with the phone when replacing the Customizable Ring.
Warning!
When attaching a Customizable Ring, press it down
with uniform pressure with your fingers. Check to
make sure it is attached securely.
12

Getting Started with Your Phone
kBluetooth®Wireless Technology
The G’zOne Boulder™ is compatible with devices that
support the Bluetooth®Headset (HSP), Hands-Free
(HFP), Dial-Up Networking (DUN), Stereo (A2DP,
AVRCP), Phonebook Access (PBAP), and Object
Push (OPP) Profiles.
NOTE
Your phone is based on the Bluetooth®specification,
but it is not guaranteed to work with all devices
enabled with Bluetooth®wireless technology. This
phone does not support all Bluetooth®OBEX Profiles.
* For vehicle/accessory (sold separately) compatibility
go to www.verizonwireless.com/bluetoothchart.
NOTE For details, see page 149.
kWater Resistance
The G’zOne Boulder™ is water resistant. It provides
reliable performance for outdoor life, in such
conditions as driving rain or high humidity.
For additional information, see 12 MONTH LIMITED
WARRANTY section (from page 231).
NOTE
To maintain water resistance:
• Securely fasten the Accessory Connector Port cover.
• Install the battery and secure the battery lock.
13

kShock Resistance
The rugged construction of the G’zOne Boulder™
provides outstanding shock and vibration resistance.
kDust Resistance
For additional peace of mind, the G’zOne Boulder™ is
also dust resistant. The device was tested using silica
flour at a temperature of 95F and meets the MIL-STD-
810F (Dust) standard.
NOTE
The phone can be rinsed with clean water when dirty.
To ensure water resistance, make sure that all covers
are securely closed before rinsing.
NOTE
Periodically, clean the Charging Terminals with a dry
cloth or cotton swab. Dust may cause some electrical
connection problems. Avoid wiping with excessive
force, which can disfigure the terminals.
Battery
Charging Terminals Charging Terminals Charging
(external) (internal) Terminals
14

Getting Started with Your Phone
MEDIA CENTER
1. Music & Tones
1. V CAST Music
2. Get New Ringtones
3. My Ringtones
4. My Music
5. My Sounds
6. Sync Music
2. Picture & Video
1. V CAST Videos
2. Get New Pictures
3. My Pictures
4. My Videos
5. Take Picture
6. Record Video
7. Online Album
3. Games
4. Mobile Web
5. Browse & Download
6. Extras
MESSAGING
1. New Message
2. Inbox
3. Sent
4. Drafts
5. Voicemail
6. Mobile IM
7. Email
8. Chat
CONTACTS
1. New Contact
2. Contact List
3. Groups
4. New PTT Contact*
5. PTT Contact List*
6. PTT Groups*
7. Speed Dials
8. In Case of Emergency
9. My Name Card
RECENT CALLS
1. Missed
2. Received
3. Dialed
4. Blocked
5. All
6. View Timers
Menus Overview
*These options are available only when the PTT feature is turned on.
15

SETTINGS & TOOLS
1. My Verizon
2. Tools
1. Voice Commands
2. Calculator
3. Calendar
4. Alarm Clock
5. Stop Watch
6. Countdown Timer
7. World Clock
8. Notepad
9. Electronic Compass
3. Bluetooth Menu
1. Add New Devices
4. Sounds Settings
1. Call Sounds
1.1. Call Ringtone
1.2. Call Vibrate
2. Alert Sounds
2.1. TXT Message
2.2. Pic-Video Message
2.3. Voicemail
2.4. PTT Alert*
2.5. Emergency Tone
3. Keypad Volume
4. Service Alerts
4.1. ERI
4.2. Minute Beep
4.3. Call Connect
5. Power On/Off
5.1. Power On
5.2. Power Off
6. Folder On/Off
5. Display Settings
1. Banner
1.1. Personal Banner
1.2. ERI Banner
2. Backlight
2.1. Display
2.2. Keypad
3. Contrast
4. Wallpaper
4.1. My Picture List
4.2. My Video List
4.3. Fun Animations
5. Display Themes
6. Main Menu Settings
7. Dial Fonts
8. Clock Format
8.1. Main Clock
8.2. Front Clock
9. Power Saver
*This option is available only when the PTT feature is turned on.
16

Getting Started with Your Phone
6. Phone Settings
1. Airplane Mode
2. Set Shortcuts
2.1. Set My Shortcuts
2.2. Set Directional
Keys
3. Voice Commands
4. Language
5. Location
6. Security
6.1. Edit Codes
6.2. Restrictions
6.3. Phone Lock Setting
6.4. Lock Phone Now
6.5. Emergency #s
6.6. Restore Phone
7. System Select
8. NAM Selection
7. Call Settings
1. Answer Options
2. Auto Retry
3. TTY Mode
4. One Touch Dial
5. Voice Privacy
6. PC Connections
7. DTMF Tones
8. PTT Mode
8. Memory
1. Save Options
2. Phone Memory
3. Card Memory
9. Phone Info
1. My Number
2. SW/HW Version
3. Icon Glossary
4. Software Update
17

The Battery
Warning! Use only approved batteries for the G’zOne Boulder™.
NOTE Fully charge the battery before using the phone for the
first time.
The phone comes with a rechargeable battery. Keep
the battery charged while not in use in order to
maximize talk and standby time.
Warning! Failure to follow the below directions for installing/
removing the battery could result in product failure.
kInstalling the Battery
1. Insert the battery into the
opening on the back of the
handset using the guides. Push
the battery into the cavity.
Guides
18

Getting Started with Your Phone
2. Insert the tip of the corner of
the Device Lock Tool marked
with the battery lock icon into
the groove of the screw type
battery lock and rotate in the
direction indicated by the arrow
in the illustration to the left.
Rotate the battery lock as far
as it will go towards the LOCK
position.
kRemoving the Battery
1. Insert the tip of the corner of
the Device Lock Tool marked
with the battery lock icon into
the groove of the screw type
battery lock and rotate in the
direction indicated by the arrow
in the illustration to the left.
Rotate the battery lock as far
as it will go towards the FREE
position.
2. Remove the battery by pulling
up on the tab.
WARNING! Do not twist the battery as
shown in the illustration to the left. Doing
so can damage the phone and the battery.
1.
2.
19
