Casio QT-2100 User manual

QT-2100
Versatile IntelligentTerminal
❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧❧
User's Manual
Version 1.0 January 2002
C
7
4
1
0
8
5
2
00
9
6
3
•
QT-2100
www.cashregisters.net

2
1. Equipment care
In order to prolong the life of your equipment, please observe the following precautions:
• Location and condition
1) Avoid places which receive prolonged periods of direct sunlight, places in close proximity to heaters, and
places that are humid and/or dusty. Your equipment should be placed on a flat, stable surface.
2) Do not place equipment on an unstable cart, stand, or table. The equipment may fall, causing serious injury
to a child or adult, and serious damage to the equipment. Use only with a stand recommended by the
manufacturer.
3) Slots and openings in the cabinet are provided for ventilation. To insure reliable operation of this equipment,
and to protect it from overheating, these openings must not be blocked or covered.
4) Neverpushobjectsofanykindintotheequipmentthroughcabinetslotsastheymaytouchdangerousvoltage
points or short out parts that could result in a fire or electrical shock.
5) If liquid has been spilt onto the equipment, just wipe it up.
• Electrical connection
1) Your equipment must be connected to an electrical service that is dedicated exclusively to the system
equipment.
2) The AC plug should be securely plugged in at all times and the AC cord situated so that it is not tripped over.
Do not allow anything to rest on the power cord. Do not locate any equipment where the cord will be abused
by persons working on it. The socket outlet shall be near the equipment and shall be easily accessible.
3) The electrical service shall be a three-wire, isolated-ground system, taking its power from any phase of the
storemainservicethatisfreeofheavydutyinductiveloads,e.g.,refrigerationmotors,conveyermotors,floor
waxing machines, etc.
4) Thisdedicatedservicemustrunfromthestoremainpaneltoadedicatedsub-panel,andmustfeedequipment
service outlets on branch circuits that are protected by circuit breakers.
5) Under no circumstances should an overloaded AC outlet be utilized. Current loading must not exceed 75%
of the circuit breaker rated capacity.
• Cleaning your equipment
1) When your equipment becomes dirty, a soft cloth dipped in a mild detergent and wrung out can be used to
wipe the machine.
2) Avoid using paint thinner, benzine, and other volatile solvents since they may damage the equipment case.
• Service requirements
1) Do not attempt to service any equipment yourself since opening or removing covers may expose you to
dangerous voltage or other hazards. Refer all servicing to qualified service personnel.
2) Unplugtheequipmentfromthewalloutletandreferservicingtoqualifiedservicepersonnelunderthefollowing
conditions.
a) When a power cord or plug is damaged or frayed.
b) If the equipment does not operate normally by following the operating instructions. Adjust only those
controls that are covered by the operating instructions, as improper adjustment of other controls may
resultindamageandwilloftenrequireextensiveworkbyaqualifiedtechniciantorestoretheequipment
to normal operation.
c) If any equipment has been dropped or the cabinet has been damaged.
www.cashregisters.net

3
QT-2100 User's Manual
GUIDELINES LAID DOWN BY FCC RULES FOR USE OFTHE UNIT INTHE U.S.A.
(Not applicable to other areas)
WARNING: This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules.These limits are designed to provide reasonable protec-
tion against harmful interference when the equipment is operated in a commercial environment.This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own expense.
FCC WARNING: Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
The main plug on this equipment must be used to disconnect main power.
Please ensure that the socket outlet is installed near the equipment and shall be easily accessible.
Zur Trennung vom Netz ist der Netzstecker aus der Steckdose zu zielen, welche sich in der Nähe des
Gerätes befinden muß und leicht zuganglich sein soll.
Please keep all information for future reference.
Contents
1.Equipment care.............................................................................................. 2
2.QT-2100 overview........................................................................................... 4
3.How to remove/replace the sheet holder..................................................... 5
4.How to install a menu sheet in the sheet holder......................................... 6
5.Tilt the LCD panel .......................................................................................... 8
6.Troubleshooting............................................................................................. 9
7.List of options .............................................................................................. 10
8.Specifications .............................................................................................. 11
○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○○
www.cashregisters.net

4
C
7
4
1
0
8
5
2
00
9
6
3
•
QT-2100
LCD panel
Rear display (option)
Main power switch
(bottom)
Contrast control knob
Brightness control knob
Sheet holder (1st. ~ 4th.)
(keyboard)
ConfigurationoftheQT-2100isveryflexible,allowingyoutoselectfromavarietyofequipmentoptionstomeet
your system requirements. The drawing below shows QT-2100 terminal. Please contact your dealer for
details.
2. QT-2100 overview
Contents of the package
In-line connector/Terminator/
Clerk keys (only for German)
Fixing screws to drawer
Menu sheet (plain sheet)
User's manual (this manual)
QT-2100 with sheet holder for 1st. ~ 4th.
Key sheet and character sheet are enclosed.
{
www.cashregisters.net

5
QT-2100 User's Manual
C
7
4
1
0
8
5
2
00
9
6
3
•
3
4
QT-2100
3. How to remove/replace the sheet holder
Remove the sheet holder (keyboard)
Follow steps 1~ 2.
Replace the sheet holder
Follow steps 3~ 4.
C
7
4
1
0
8
5
2
00
9
6
3
•
1
2
QT-2100
www.cashregisters.net

6
Locking slide
Locking slide
Top piece
LOCK →
← OPEN
Unlock
Small Hooks
Bottom piece
Top piece
4. How to install a menu sheet in the sheet holder
Open the sheet holder
Follow steps 1~ 3.
1Slide both sides locking slide to unlock.
2Open the sheet holder as shown
in the illustration.
3The sheet holder (keyboard) can
now be divided into two pieces by
tearing off the top and bottom
pieces.
LOCK →
← OPEN
www.cashregisters.net

7
QT-2100 User's Manual
Menu sheet
Top piece
4Insertmenusheet(s)between
the two sections of the sheet
holder.
LOCK →
← OPEN
Lock
Set a menu sheet in the sheet holder
Follow steps 4~ 7.
Top piece
snap
snap
snap
snap
Top piece
5Replace the top piece,
press both sides and snap
all hooks around the sheet
holder to close.
6Slide both sides locking slide to lock.
7Complete
www.cashregisters.net

8
C
7
4
1
0
8
5
2
00
9
6
3
•
QT-2100
5. Tilt the LCD panel
www.cashregisters.net

9
QT-2100 User's Manual
6. Troubleshooting
Perform the following check whenever the terminal enter an error condition as soon as you switch it on.
The results of this check are required by service personnel, so be sure to perform this check before you contact
your authorized service personnel.
Start
Is QT-2100 plugged in?
Is power on?
Do figures appear on the display?
Do key function?
Plug in the power cord.
Check the power switch turning on.
Is the electrical outlet active?
Contact
CASIO authorized
service personnel.
Is the mode position correct?
Contact
CASIO authorized
service personnel.
Use other outlet.
Set to correct position.
No
No
No No
NoNo
Yes
Yes
Yes
Yes
Yes
In any other cases, if you can not find the cause of a problem, please contact your authorized service
personnel.
www.cashregisters.net

10
7. List of options
emaNnoitacificepSskrameR
redlohteehS
8TIK-HStikredlohteehS )ht4~ts1(redlohenO steehsunemnialpowthtiw
9TIK-HStikredlohteehS )ht8~ht5,ht4~ts1(sredlohowT steehsunemnialpruofhtiw
revocteehS
18-TW
retnirppilS
0031-PS
C8-BC-TRP0031-PSrofelbacretnirPm5.1:htgnelelbaC
retnirpetomeR
053-PUretnirpnoitats1etomeRretnirplamrehT
052-PUretnirpnoitats1etomeRretnirptcapmI
5103-ASretnirpnoitats5.2etomeRretnirptcapmI
081-SPretnirpetomerrofrotpadaCA.dedulcnitonsidrocrewoP
A8-BC-TRPretnirpetomerrofelbacretnirPm3:htgnelelbaC
B8-BC-TRPretnirpetomerrofelbacretnirPm5:htgnelelbaC
yalpsiD
D0612-TQtesyalpsidraeR.S.Uehtroftpecxe
D3612-TQtesyalpsidremotsuC
S1602-TQD3612-TQrofeloP
S2612-TQD3612-TQrofelbacnoisnapxEm5:htgnelelbaC
rewarditluM
11-LDMtikrewarditluMrewardenolanoitiddA
noisnapxeyromeM
MAR0312-TQ pukcabyrettabhtiw
RCM
CM6402-TQredaerdraccitengaM
yekkrelC
22K-KLCtesyekkrelCeborpdnasyeksallaD6
rennacsdlehdnaH
51-SHH
elbacknilCP
2-BC-LRP
www.cashregisters.net

11
QT-2100 User's Manual
8. Specifications
QT-2100 unit
Input method: 10-key system (2-key roll over)
Display: Monochrome LCD 320 ×240 dots (Main)
Digitron: Alphanumeric 20 digits ×2 lines (Customer) (only for the U.S.)
CPU: SH-3/133MHz
RAM: 4 MB, Max. 8 MB
Memory protection: 48-hour full charged batteries protect memories for approximately 30 days.
Batteries should be replace every five years.
Interface: 6 ×RS232C, 1 ×drawer, 1 × in-line, 1 ×CF card, (1 ×Dallas key, 1 ×MCR)
Power supply: } As noted on the plate affixed to the right side of the unit.
Power consumption:
Operating temperature: 0 ˚C ~ 40 ˚C
Humidity: 10 ~ 90 %
Dimension and weight : 270 mm (W) ×116 mm (H) ×406 mm (D)/4.4 kg
The CE marking below applies to the EU region. Declarer of conformity is as follows:
Casio Electronics Co., Ltd.
Unit 6, 1000 North Circular Road
London NW2 7JD, U.K.
Warning
This is a Class A product. In a domestic environment this product may cause radio interference in
which case the user may be required to take adequate measures.
Apparaten skall anslutas till jordat nätuttag.
* Specifications and design are subject to change without notice.
www.cashregisters.net

CASIO COMPUTER CO., LTD.
6-2, Hon-machi 1-chome, Shibuya-ku,
Tokyo 151-8543, Japan MO0202-C Printed in Japan
QT-2100*E
