Casio 1583 Configuration guide

1583/1584-1
Module No. 1583/1584
▼
•If the digital display of your watch is continually changing, see
“AboutAuto Display” for information on how to stop it.
•Except for the Bbutton operation in the Timekeeping Mode, the operational
procedures for Module 1583 and 1584 are identical.All of the illustrations in
this manual show Module 1583.
•Press Cto change from mode to mode. After you perform an operation in
any mode, pressing Creturns to the Timekeeping Mode.
A
CD
L
B
CountdownAlarm Mode Stopwatch Mode
Timekeeping Mode
Telememo Mode Alarm Mode
Press C
(Light)
A
CD
L
B
[Module 1583][Module 1584]
▼
▼
▼
▼
GENERAL GUIDE
•In the Timekeeping Mode, press Lto illuminate the display. Pressing L
illuminates the display even while you are setting the time and date.
•Thebattery power indicatorshows currentremaining battery capacity.Certain
functions of this watch may be temporarily disabled when battery power is
low. For details, see “Battery Power Indicator”.
To set the time and date
1. Hold down Awhile in the Timekeeping Mode until the seconds digits start
to flash on the display. The seconds flash because they are
selected .
2. Press Cto change the selection in the following sequence.
Hour
Seconds
Day
Minutes 12/24-Hour
Format
Year
Month
3. Whilethe secondsdigits areselected (flashing),pressDto resetthe seconds
to 00.
•If you press Dwhile the seconds count is in the range of 30 to 59, the
seconds are reset to00 and 1 is added to the minutes. If the seconds count
is in the range of 00 to 29, the minutes count is unchanged.
In addition to normal timekeeping, use the Timekeeping Mode to set the current
time and date.
•The operation of button Bdepends on the module number of your watch.
See the watch’s back cover to determine the model number of your watch.
Module 1583: Holdingdown Binthe TimekeepingMode displaysthe dataitem
thatwas onthe displaywhen you lastexited theTelememoMode.
Module 1584: PressingBintheTimekeeping Modeswitches tothe Countdown
AlarmMode.Youcan returnto the TimekeepingMode bypressing
C.
A
CD
L
B
L
Hold downB
Day of week Month – Day
Year
Hour : Minutes
Seconds
PM indicator
Battery power
indicator
Telememo Mode ScreenTimekeeping Screen
[Module 1583]
A
CD
L
B
Countdown Alarm ModeTimekeeping Screen
[Module 1584]
Press B
Battery
power
indicator
TIMEKEEPING MODE
A
CD
L
B
The backlight uses an EL (electro-luminescent)
panel that cause the entire display to glow for
easy reading in the dark. The watch’s auto light
switchautomatically turns onthe backlight when
you angle the watch towards your face.
•The auto light switch must be turned on
(indicatedby theauto light switchon indicator)
for it to operate.
Note
•The electro-luminescent panel loses
illuminating power after very long use.
•The illumination provided by the backlight may be hard to see when viewed
under direct sunlight.
•The watch will emit an audible sound whenever the display is illuminated.
This is caused by vibration of the EL panel when it is lit. It does not indicate
malfunction of the watch.
•The backlight automatically turns off whenever an alarm sounds.
To manually turn on the backlight
Depending on the mode, pressing Lor Dturns on the backlight for about two
seconds. See the sections that cover each mode for information on whether
you should press Lor D.
•The backlight remains lit for about two seconds from the point you press the
button, even if it is already lit when you press the button. If you keep the
button depressed for five seconds or more, the backlight automatically turns
off.
•The above operation turns on the backlight regardless of the current auto
light switch setting.
About the Auto Light Switch
Turning on the auto light switch causes the backlight to turn on whenever you
position your wrist as described below. Note that the auto light switch of this
watch will operate only when available light is below a certain level. It does not
turn on the backlight under bright light.
•Avoid wearing the watch on the inside of your wrist. Doing so causes the
auto light switch to operate when it is not needed, which shortens battery life.
Auto light switch
on indicator
BACKLIGHT
4. While hour, minutes, year, month, or day is selected (flashing), press Dto
increase theselection or Btodecrease it.The 12/24-hoursetting isselected
(flashing), press Dto switch between the 12-hour (12H) and 24-hour
(24H) formats.
•Holding down either button changes the current selection at high speed.
•With the 12-hour format, the P(PM) indicator appears to the left of the hour
digits for times in the range of noon to 11:59 pm and the A(AM) indicator
appearstothe left of thehour digits for timesin the range ofmidnight to 11:59
am.
•The 24-hour format is indicated by 24 on the display.Times are shown in the
range of 00:00 to 23:59.
5. Afteryou setthetimeand date, press Atoreturn to theTimekeepingMode.
•The day of the week is automatically set in accordance with the date.
•The date can be set within the range of January 1, 1995 to December 31,
2039.
•Ifyou do notoperate anybutton for afew minutes whilea selectionis flashing,
the flashing stops and the watch goes back to the Timekeeping Mode
automatically.

1583/1584-2
Moving the watch to a position that is parallel to the ground and then tilting it
towards you more than 40 degrees causes the backlight to light.
•The backlight turns off in about two seconds, even if you keep the watch
pointed towards your face.
•The backlight may not light if the face of the watch is more than 15 degrees
off the parallel as shown below. Make sure that the back of your hand is
parallel to the ground.
Parallel to
ground
More
than
40°
More than 15 degrees
too high More than 15 degrees too low
Parallel to ground
•Static electricity or magnetic force can interfere with proper operation of the
auto light switch. If the backlight does not light, try moving the watch back to
the starting position (parallel with the ground) and then tilt it back toward you
again. If this does not work, drop your arm all the way down so it hangs at
your side, and then bring it back up again.
•Under certain conditions the backlight may not light until about one second
orless after turn theface of thewatchtowards you.Thisdoes notnecessarily
indicate malfunction of the backlight.
Warning!
•Never try to read your watch when mountain climbing or hiking in areas
that are dark or in areas with poor footing. Doing so is dangerous and
can result in serious personal injury.
•Never try to read your watch when running where there is danger of
accidents, especially in locations where there might be vehicular or
pedestrian traffic. Doing so is dangerous and can result in serious
personal injury.
•Never try to read your watch when riding on a bicycle or when operating
a motorcycle or any other motor vehicle. Doing so is dangerous and
can result in a traffic accident and serious personal injury.
•When you are wearing the watch, make sure that its auto light switch is
turned off before riding on a bicycle or operating a motorcycle or any
other motor vehicle. Sudden and unintended operation of the auto light
switch can create a distraction, which can result in a traffic accident
and serious personal injury.
To turn the auto light switch on and off
In the Timekeeping Mode, hold down Dfor one second to turn the auto light
switch on (
AUTO
displayed) and off (
AUTO
not displayed).
•Frequentuse of theauto lightswitch greatly reducesthe chargeof the storage
battery. If you use the auto light switch often, be sure to leave the watch
where it is exposed to sunlight during the day time so it can recharge the
storagebattery.10 minutes exposureto sunlight providesenough of acharge
for about 10 to 20 auto light switch operations.
•The
AUTO
indicator is onthe display inall modeswhilethe autolight switch
is turned on.
A
CD
L
B
A
CD
L
B
The Telememo Mode lets you store up to 30
pairs of name and telephone number data.
Data is automatically sorted based on the
characters of the name. You can recall data
by scrolling through it on the display.
•See the “CHARACTER LIST” at the back
ofthis manual fordetails onhow the watch
sorts data.
•If there is no data stored in the Telememo
Mode, the message NO-DATA
appears following the remaining memory
screen.
•Thedata item onthe displaywhen you exit
theTelememo Modeappears first thenext
time you enter the Telememo Mode.
•In the Telememo Mode, press Lto
illuminate the display. Pressing L
illuminates the display even while you are
inputting data.
To input new Telememo data
1. In the Telememo Mode, press Band Dat
thesame timeto displaythe newdata screen.
•The new data screen is the one that is blank
(contains no name and telephone number).
•If the message FULL appears in the text
area of the display, it means that memory is
full. To store more data, you will first have to
delete some of the data stored in memory.
2. Hold down Auntil the flashing cursor
appears in the text area of the display.
3. Use Band Dto change the character at
the cursor position in the text area. The
characterchanges inthe followingsequence.
. -/
:
Press DPress B
(space) (Japanese) 0to 9
to (alphabet)
Ato Z
•Holding down either button changes the character at high speed.
•You can inputJapanese characters(
katakana ),English alphabeticcharacters,
numbers, and symbols in the text area. For a complete list of characters you
can input, see “Character List” at the back of this manual.
4. When the character you want is at the cursor position, press Cto move the
cursor to the right.
5. Repeat the steps 3 and 4 until your text is complete.
•You can input up to eight characters for the name.
6. After you input a name, use Cto move the cursor to the number area.
•The text area can hold up to eight characters. When the cursor is located at
the eighth space of the text area, moving the cursor to the right causes it to
jump down to the first digit in the number area. When the cursor is at the 12th
digit of the number area, moving it to the right causes it to jump back up to
the first character of the text area.
7. Use Band Dto change the character (hyphen, number, or space) at the
cursor position in the number area. The character changes in the following
sequence.
x(space)
0to 9
•Holding down either button changes the character at high speed.
8. When the character you want is at the cursor position, press Cto move the
cursor to the right.
9. Repeat steps 7 and 8 until you complete number input.
•You can input up to 12 digits for the number.
10.After inputting your data, press Ato store it.
•When you press Ato store data, the message SORT appears on the
display for a few seconds. After the sort operation is complete, the cursor
appears in the text area, ready for input a new Telememo data item.
11.Input more data (staring from step 3) or press Aagain to return to the
Telememo Mode data screen (without the cursor).
•If you do not perform any button operation for few minutes while the cursor is
on the display, the watch automatically returns to the Telememo Mode data
screen.
•The text area of the display can show only five characters at a time, so longer
text scrolls continuously from right to left.
To recall Telememo data
In the Telememo Mode, press Dto scroll forward through stored data items or
Bto scroll in reverse.
•Holding down either button scrolls through the data at high speed.
To edit Telememo data items
1. In the Telememo Mode, scroll through the data items and display the one
you want to edit.
2. Hold down Auntilthe flashing cursorappears in thetext area ofthe display.
3. Use Cto move the flashing cursor to the character you want to change.
4. Use Band Dto change the character.
•For details on inputting characters, see “To input new Telememo data” (steps
3 for name input and 7 for number).
5. After making the changes that you want, press Ato store them and return
to the Telememo Mode data screen.
To delete Telememo data
1. In the Telememo Mode, scroll through the data items and display the one
you want to delete.
2. Hold down Auntilthe flashing cursorappears in thetext area ofthe display.
3. Press Band Dat the same time to delete the data item.
•At this time the cursor appears in the text area, ready for input.
4. Input data or press Ato return to the Telememo Mode data screen.
Name
Mode indicator
Telephone number
Remaining
memory
Cursor
Text Area
NumberArea
[New Data Screen]
TELEMEMO MODE
Press D
Press B

1583/1584-3
A
CD
L
B
A
CD
L
B
You can set up to five independent alarms with
hour, minutes, month, and day. When an alarm
is turned on, an alarm tone sounds for 20
seconds when the time is reached. Press any
button to stop the alarm after it starts to sound.
When the Hourly Time Signal is turned on, the
watch beeps every hour on the hour.
•In theAlarm Mode, press Lto illuminate the
display. Pressing Lilluminates the display
even while you are setting an alarm.
Alarm Types
Thealarm type isdetermined bythe settings you
make, as described below.
•To set a Daily alarm
Set the hour and minutes for the alarm time. Set xx for the month and day (see
step 4 under “To set an alarm time”). This type of setting causes the alarm to
sound everyday at the time you set.
•To set a Date alarm
Set the month, day, hour and minutes for the alarm time. This type of setting
causes the alarm to sound at the specific time, on the specific date you set.
•To set a 1-Month alarm
Set the month, hour and minutes for the alarm time. Set xx for the day (see
step 4 under “To set an alarm time”). This type of setting causes the alarm to
sound everyday at the time you set, only during the month you set.
•To set a Monthly alarm
Set the day, hour and minutes for the alarm time. Set xx for the month (see
step 4 under “To set an alarm time”). This type of setting causes the alarm to
sound every month at the time you set, on the day you set.
To set an alarm time
1. Press Dwhile in theAlarm Mode to select the alarm whose time you want
to set.
Hourly Time Signal
Alarm 1 Alarm 2 Alarm 3 Alarm 4
Alarm 5
2. After you select an alarm, hold down Auntil the hour digits start to flash on
the display. The hour digits flash because they are
selected .
•This operation automatically turns on the alarm.
3. Press Cto change the selection in the following sequence.
Hour Minutes Month Day
4. PressDto increase the selection or Bto decrease it. Holding down either
button changes the selection at high speed.
•To set an alarm that does not include a month (Daily alarm, Monthly alarm),
set xx for the month. Press Bor Duntil the xx mark appears (between
12 and 1) while the month digits are flashing.
•To set an alarm that does not include day (Daily alarm, 1-Month alarm), set
xx for the day. Press Bor Duntil the xx mark appears (between 31 and
1) while the day digits are flashing.
•The format (12-hour and 24-hour) of the alarm time matches the format you
select for normal timekeeping.
•When setting an alarm time using the 12-hour format, take care to set the
time correctly as morning (Aindicator) or afternoon (Pindicator).
5. After you set the alarm, press Ato return to theAlarm Mode.
•Ifyou do notoperate anybutton for afew minutes whilea selectionis flashing,
the flashing stops and the watch goes back to theAlarm Mode automatically.
To turn an alarm and Hourly Time Signal on and off
1. In theAlarm Mode, press Dto select an alarm or the Hourly Time Signal.
2. When the alarm or Hourly Time Signal you want to is selected, pressBto
turn it on and off.
Indicates alarm is ON.
Indicates Hourly Time Signal is ON.
•The alarm on indicator ( ) and the Hourly Time Signal on indicator ( ) are
shown on the display in all modes while these functions are turned on.
•An “ ” mark next to the alarm on indicator or Hourly Time Signal on indicator
means that battery power is too low to produce the alarm tone or signal. The
alarm tone or signal will sound again after normal battery power is restored.
To test the alarm
Hold down Dwhile in the Alarm Mode to sound the alarm.
Mode indicator – Alarm No.
AM indicator
Alarm on
indicator Month – Day
Hour : Minutes
ALARM MODE
TheStopwatch Mode lets youmeasure elapsed
time, split times, and two finishes. You also get
Auto-Start function. The range of the stopwatch
is 23 hours, 59 minutes, 59.99 seconds.
•Inthe StopwatchMode, pressDto illuminate
the display.
To measure elapsed time
1. Press Lto start the stopwatch.
2. Press Lto stop the stopwatch.
•You can resume the measurement operation
by pressingLagain.
3. Press Bto clear the stopwatch to all zeros.
To record split times
1. Press Lto start the stopwatch.
2. Press Bto display the timing up to that point. Stopwatch timing continues
internally.
3. Press Bto clear the split time and to continue time measurement on the
display.
•You can repeat steps 2 and 3 as many times as you want.
4. Press Lto stop the time measurement.
5. Press Bto clear the stopwatch to all zeros.
To time first and second place finishes
1. Press Lto start the stopwatch.
2. Press Bwhen the first finisher crosses the line, and record the time.
3. Press Lwhen the second finisher crosses the line.
4. Press Bto display the finishing time of the second finisher.
5. Press Bagain to clear the stopwatch to all zeros.
About the Auto-Start function
With theAuto-Start function, the watch performs a 5-second countdown. When
the countdown reaches zero, stopwatch operation starts automatically. During
the final three seconds of the countdown, a beeper sounds with each second.
To use the Auto-Start function
1. While the stopwatch screen is showing all
zeros in the Stopwatch Mode, press A.
•This displays a 5-second countdown screen.
•To return to the all zeros screen, press A
again.
2. Press Lto start the countdown.
•When the countdown reaches zero, a tone
sounds and a stopwatch timing operation
starts automatically.
•Pressing Lwhile the Auto-Start countdown
isin progressimmediately startthestopwatch.
STOPWATCH MODE
A
CD
L
B
Hours Seconds
Mode indicator
1/100 second
Minutes
COUNTDOWN ALARM MODE
The countdown timer can be set within a range
of 1 second to 24 hours. When the countdown
reaches zero, an alarm sounds.
•You can also select auto repeat, which
automaticallyrestarts the countdownfrom the
original value you set whenever zero is
reached.
•You can also use a progress beeper, which
causes the watch to beep at various points
along the countdown.
•In the Countdown Alarm Mode, press Dto
illuminate the display.
To set the countdown time
1. Holddown Awhile inthe CountdownAlarm Mode untilthehours digit starts
to flash on the display. The hours digit flashes because it is
selected .
2. Press Cto change the selection in the following sequence.
SecondsHours Minutes
3. Press Dto increase the selection or Bto decrease it. Holding down either
button changes the selection at high speed.
•To set the starting value of the countdown time to 24 hours, set 0:00 00.
4. Afteryou set thecountdown time, press Atoreturn to theCountdownAlarm
Mode.
•Ifyou do notoperate anybutton for afew minutes whilea selectionis flashing,
the flashing stops and the watch goes back to the Countdown Alarm Mode
automatically.
A
CD
L
B
Seconds
1/10 second
Progress beeper on
indicator
Hours
Mode indicator
Minutes

1583/1584-4
A
CD
L
B
Solar cell panel
Battery power indicator
Level Indicator Functional Status
1
2
3
4
5
All functions enabled.
All functions enabled.
Alarms, Hourly Time Signal, backlight disabled.
Alarms, Hourly Time Signal, backlight, display disabled;
timekeeping enabled.
Alarms, Hourly Time Signal, backlight, display, timekeeping
disabled.
/
/
/
/
/
This watch is equipped with a solar cell and a
storage battery (secondary battery) that is
chargedby the electrical powerproduced by the
solar cell.
•The area outside of the LCD digital areas is a
solar cell panel that picks up available light to
charge the storage battery.
•ASleep Mode is providedto conserve battery
power.
•With the Module 1584, battery power is
indicated by .
Important!
•Storingthe watch forlong periodsin an areawhere there isno lightor wearing
it in such a way that it is blocked from exposure to light can cause storage
battery power to run down. Be sure that the watch is normally exposed to
light whenever possible.
•Thiswatch employs a solarcell that converts lightinto electricity that charges
a built-in storage battery. Normally, the storage battery should not need
replacement, but after very long use over a number of years, the storage
batterymay loseits abilityto achievea fullcharge. Shouldyou noticeproblems
withgettingthe storage battery toa full charge, contactyour dealer or CASIO
distributor about having the storage battery replaced.
•The storage battery should be replaced with a CASIO-specified ML-2020
battery only. Other storage batteries can cause damage to the watch.
•Be sure to put the watch into its Sleep Mode and keep in an area normally
exposedto lightwhen storing itfor longperiods.This helps tokeep thestorage
battery from going dead.
Battery Power Indicator
The battery power indicator on the display shows you the current status of the
storage battery’s power.
BATTERY
A
CD
L
B
[Sleep Mode]
To use the countdown timer
Press Lwhile in the Countdown Alarm Mode to start the countdown timer.
•When the countdown reaches zero and auto repeat is turned off, the alarm
sounds for 10 seconds or until you stop it by pressing any button. The
countdown time is automatically reset to its starting value after the alarm
stops.
•Press Lwhile a countdown operation is in progress to pause it. Press L
again to resume the countdown.
•To completely stop a countdown operation, first pause it (by pressing L),
and then press B. This returns the countdown time to its starting value.
To turn auto repeat on and off
1. Hold downAwhile in the CountdownAlarm
Mode until the hours digit starts to flash on
the display.
2. Press Lto turn auto repeat on (AUTO
displayed) and off (AUTO not displayed).
3. Press Ato return to the Countdown Alarm
Mode.
•The auto repeat on indicator (AUTO)
appears in the upper part of the display only
in the start time setting screen (starting time
digits flashing).
•When the end of the countdown is reached while auto repeat is on, the alarm
sounds,but thecountdownstartsagainautomatically wheneverthe countdown
reaches zero.You can stop timing by pressing L, and manually reset to the
starting countdown time by pressing B.
•Normally, an alarm tone sounds for about 10 seconds when the end of the
countdown is reached. If you use auto repeat with start time of 10 seconds or
less, the alarm tone sounds for only one second.
•Frequent use of auto repeat with a short countdown time can reduce the
chargeof the storagebattery and causethe countdowntimealarm tobecome
disabled, so it does not sound.
To turn progress beeper on and off
PressBwhile inthe CountdownAlarmMode (whilethe countdownis completely
stopped or ongoing) to turn the progress beeper on ( displayed) and off (
not displayed).
•When the progress beeper is turned on, the watch beeps as the countdown
time passes the 10, 5, 4, 3, 2, and 1-minute marks, and the 50, 40, 30, 20,
10, 5, 4, 3, 2, and 1-second marks.
A
CD
L
B
Auto repeat on indicator
•AtLevel 4,the displayis disabledbut timekeepingand otherfunctionscontinue
to operate internally. Pressing any button causes the Timekeeping Mode
screen to appear for two or three minutes.
•At Level 5, all functions are disabled. Functions are enabled once again after
the storage battery is charged, but anything previously stored in memory is
lost. Because of this, you must set the current time and alarms, and re-input
Telememo data items after the storage battery is charged.
Charging Precautions
Certain charging conditions can cause the watch to become very hot. Avoid
leaving the watch in the areas described below whenever charging its storage
battery.
Warning!
Leaving the watch in sunlight to charge its storage battery can cause it to
become quite hot. Take care when handling the watch to avoid burn injury.
•On the dashboard of a car parked in direct sunlight
•Too close to an incandescent lamp
•Under direct sunlight or in any other area exposed to intense heat for long
periods
Charging Guide
Required charge time when the backlight is used for two seconds and the alarm
sounds for 20 seconds per day:
•Approximately 8 hours of 500 lux (indoor fluorescent lighting) per day
•Approximately 1 hour 15 minutes of 3,000 lux (direct fluorescent lighting) per
day
•Approximately50 minutesof 36,000 lux(afternoon outdoorsunlight) per week
(7 minutes per day)
Required charge time when the backlight is used for 30 seconds and the alarm
sounds for 20 seconds per day:
•Approximately 4 hours 30 minutes of 3,000 lux (direct fluorescent lighting)
per day
•Approximately 2 hours 20 minutes of 36,000 lux (afternoon outdoor sunlight)
per week (20 minutes per day)
Using the Sleep ModeIn any mode (except while figures are flashing
on the display for input), hold down Cfor about
two seconds.
•This enters the Sleep Mode, which clears the
display. Timekeeping and other functions
continue to be performed internally.
•Alarms, the Hourly Time Signal, and the
backlight are disabled while the watch is in
the Sleep Mode.
•Pressinganybutton (exceptA)exitsthe Sleep
Mode and enters the Timekeeping Mode.
About Auto Display
Auto Display is a demonstration feature that continually changes the contents
ofthe digital display. Note thatyoucannot use anyof the watch’s otherfunctions
while Auto Display is operating.
To turn off Auto Display
Hold down Afor about two seconds until the watch beeps.
To turn on Auto Display
1. In any mode (except while figures are flashing on the display for input), hold
down Cfor about two seconds to enter the Sleep Mode.
2. Hold down Afor about two seconds until the watch beeps. This indicates
that Auto Display is on.
•You cannot turn onAuto Display while a setting screen (indicated by flashing
digits) is on the display.
•Leaving the watch in a dark area can cause Auto Display operation to stop.
Normal operation should resume when the watch is again exposed to light.
•Auto Display cannot be turned on while the storage battery is at Level 4 or
Level5. AutoDisplay alsoturns offautomatically wheneverthe storagebattery
drops to Level 4 or Level 5.

1583/1584-5
CHARACTER LIST
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59 A
60 B
61 C
62 D
63 E
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
64 F
65 G
66 H
67 I
68 J
69 K
70 L
71 M
72 N
73 O
74 P
75 Q
76 R
77 S
78 T
79 U
80 V
81 W
82 X
83 Y
84 Z
85 0
86 1
87 2
88 3
89 4
90 5
91 6
92 7
93 8
94 9
95 -
96 .
97 /
98 :
1 (space)
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
