Module No. 2288 2288-1
GENERAL GUIDE
•Press Cto change from mode to mode.
•Pressing Lin any mode illuminates the display for about 3 seconds.
•If you do not perform any operation for a few minutes while a setting screen (with flashing digits) is on the display, the watch automatically exits the setting screen.
•If you do not perform any operation for a few minutes in the Data Bank Mode or Day Counter Mode, the watch automatically reverts to the normal timekeeping screen.
Timekeeping Mode Data Bank Mode
Press C.
Day Counter Mode Alarm Mode Stopwatch Mode Dual Time Mode
TIMEKEEPING MODE
•Press Dto toggle between 12-hour and 24-hour
timekeeping.
•With 12-hour timekeeping, times between midnight and
noon are indicated by A (am), while times between noon
and midnight are indicated by P (pm).
•The A and P indicators do not appear when you are
using 24-hour timekeeping.
To set the time and date
1.While in the Timekeeping Mode, hold down Auntil the
seconds digits flash on the display, indicating the
setting screen.
2.Press Cto move the flashing in the sequence shown below.
DST
Seconds
Day
Hour
Year
Month Minutes
3.While the seconds setting is selected (flashing), press Dto reset it to 00. If you
press Dwhile the seconds setting is in the range of 30 to 59, the seconds are
reset to 00 and 1 is added to the minutes. If the seconds setting is in the range of
00 to 29, the minutes count is unchanged.
•While the DST∗setting is selected (DST on indicator is flashing), press Dto
toggle it on (on) and off (OF). If DST setting is on, the DST on indicator is shown
in the Timekeeping Mode, Day Counter Mode and Alarm Mode.
4.While any other setting is selected (flashing), press Dto increase it or Bto
decrease it. Holding down either button changes the setting at high speed.
5.After you make the settings you want, press Ato exit the setting screen.
•The day of the week is automatically set in accordance with the date.
•The date can be set within the range of January 1, 2000 to December 31, 2039.
•The watch’s built-in full automatic calendar automatically makes allowances for
different month lengths and leap years. Once you set the date, there should be no
reason to change it except after the replacement of the watch’s battery.
∗Daylight Saving Time (DST), which is also sometimes called “summer time”
advances the time for one hour, as is the custom in some areas during the
summer. Remember that not all countries or even local areas use Daylight Saving
Time.
ABOUT THE BACKLIGHT
Press Lto illuminate the display for about 3 seconds.
•The backlight of this watch employs an electro-luminescent (EL) light, which loses
its illuminating power after very long term use.
•Frequent use of the backlight shortens the battery life.
•The watch emits an audible sound whenever the display is illuminated. This does
not indicate malfunction of the watch.
•The illumination provided by the backlight may be hard to see when viewed under
direct sunlight.
•The backlight automatically turns off whenever an alarm sounds.
Seconds
Day of week
PM
indicator
Hour Minutes
Year - Month - Day
DST on indicator
DATA BANK MODE
The Data Bank Mode lets you store up to 25 records,
each with a name (up to eight characters) and a phone
number (up to 12 digits). Data is automatically stored into
alphabetical order based on the name data. You can
recall records by scrolling through them on the display.
•The record on the display when you exit the Data Bank
Mode appears first the next time you enter the Data
Bank Mode.
To input a new Data Bank record
1.In the Data Bank Mode, use Dor Buntil the new data
screen appears.
•If the new data screen does not appear when you
press Dand B, it means that memory is full. To
store another record, you will first have to delete a
record stored in memory.
2.Hold down Aand a cursor appears on the text area.
3.Use Dor Bto scroll through characters at the current cursor position. Characters
scroll in the sequence shown below.
A to Z 0 to 9
(Space)
Press .
Press .
•Holding down either button scrolls at high speed.
4.When the character you want is at the current cursor position, press Cto move the
cursor to the right.
5.Repeat the steps 3 and 4 to input the rest of the characters.
•You can input up to eight characters for the name, though only three characters
are visible at a time. If the name you input has fewer than eight characters, use
Cto move the cursor to the eighth space (which means you would press C
three times after inputting a five-character name).
•Holding down Cto move the cursor at high speed.
6.After you input the name, use Cto move the cursor to the number area.
•Pressing Cwhile the cursor is located at the eighth character of the text area
advances to the number area. Pressing Cwhile the cursor is located at the 12th
digit of the number area returns to the text area.
7.Use Dor Bto scroll through characters (hyphen, numbers, space) at the current
cursor position on the number area. Characters scroll in the sequence shown
below.
0 to 9 (Space)
Press .
Press .
•Holding down either button scrolls characters at high speed.
•You can input up to 12 digits for the number.
8.After inputting the name and number of the record, press Ato store it and exit the
setting screen.
•The display can show only three name characters at a time. Longer names scrolls
continuously from right to left. The symbol “ ” indicates that the character to the
left is the last, and the character to the right is the first.
To recall Data Bank data
In the Data Bank Mode, press Dto scroll forward through the stored data items or B
to scroll in reverse.
•Holding down either button scrolls at high speed.
To edit Data Bank data items
1.In the Data Bank Mode, use Dor Bto display the data you want to edit.
2.Hold down Auntil the cursor appears in the display.
3.Use Cto move the cursor to the character you want to change.
•Holding down Cto move the cursor at high speed.
4.Use Dor Bto change the character.
•Holding down either button scrolls characters at high speed.
•See step 3 of “To input a new Data Bank record” for information on inputting
name characters, and step 7 for inputting number characters.
5.After making the changes that you want, press Ato store them and exit the setting
screen.
To delete a Data Bank record
1.In the Data Bank Mode, use Dor Bto display the record you want to delete.
2.Hold down Auntil the cursor appears in the display.
3.Press Dand Bat the same time. The message “CLR” appears in the display,
indicating that the record was deleted.
•After the record is deleted, the cursor appears in the text area, ready for input.
4.Input a new record or press Ato exit the setting screen.
Mode indicator
Text area Number area
Remaining memory
[ New Data Screen ]
