USER’S GUIDE 2428
1
•After you perform an operation in any mode, pressing Breturns to the
Timekeeping Mode.
General Guide
The operational procedures for Modules 2428 and 2470 are identical. All of the
illustrations in this manual show Module 2428.
•Press Bto change from mode to mode. Each mode is explained in detail on
the following pages.
[Module 2470] [Module 2428]
Timekeeping Mode Time Setting ModeStopwatch ModeAlarm Mode
Press .
Backlight Precautions
The backlight uses an EL (electro-luminescent) panel that causes the entire
display to glow for easy reading in the dark.
•The electro-luminescent panel that provides illumination loses power after
very long use.
•The illumination provided by the backlight may be hard to see when viewed
under direct sunlight.
•The watch may emit an audible sound whenever the display is illuminated.
This is due to vibration of the EL panel used for illumination, and does not
indicate malfunction.
•Frequent use of the backlight shortens the battery life.
Timekeeping Mode
•In the Timekeeping Mode, press Cto switch
between the 12-hour and 24-hour formats.
•In the Timekeeping Mode, press Ato illuminate the
display for a few seconds.
•Day of the week is displayed as follows.
SU: Sunday MO: Monday
TU: Tuesday WE: Wednesday
TH: Thursday F R : Friday
SA: Saturday
Day of the week
Day
Hour
PM indicator
Minutes
Seconds
Alarm Mode
When the Daily Alarm is switched on, the alarm
sounds for 20 seconds at the preset time each day.
When the Hourly Time Signal is switched on, the
watch beeps every hour on the hour.
To set the alarm time
1.Hold down Awhile in the Alarm Mode until the
hour digits start to flash on the display. The hour
digits flash because they are
selected
.
2.Press Ato change the selection in the following
sequence.
•Pressing Aalso illuminates the display.
Hour Minutes
Normal Alarm Mode (No digit flashes)
•Once you reach the normal Alarm Mode, you have to hold down Aagain
until the hour digits start to flash.
3. Press Cto increase the selected digits. Holding down Cchanges the
number at high speed.
•The format (12-hour and 24-hour) of the alarm time matches the format you
select for normal timekeeping.
•When setting the alarm time using the 12-hour format, take care to set the
time correctly as morning or afternoon (PM).
4. After you set the alarm time, press Ato return to the Alarm Mode. At this
time the Daily Alarm is switched on automatically.
To stop the alarm
Press Ato stop the alarm after it starts to sound.
Hourly time
signal on
indicator
Mode indicator
Hour
Alarm on
indicator
Minutes
To switch the Daily Alarm and Hourly Time Signal on and off
Press Cwhile in the Alarm Mode to change the status of the Daily Alarm and
Hourly Time Signal in the following sequence.
[Alarm on Indicator/Hourly Time Signal on Indicator]
Hourly Time
Signal only
Daily Alarm
only
Both offBoth on
To test the alarm
Hold down Cwhile in the Alarm Mode to sound the alarm.
Stopwatch Mode
The Stopwatch Mode lets you measure elapsed time,
split times, and two finishes. The range of the
stopwatch is 59 minutes, 59.99 seconds.
(a) Elapsed time measurement
Start Stop Re-start Stop Clear
Start Split Split release Stop Clear
Start Split Stop Split release Clear
(b) Split time measurement
(c) Split time and 1st-2nd place times
First runner
finishes.
Second runner
finishes.
Record time of
first runner.
Record time of
second runner.
Time Setting Mode
To set the time and date
1.Use Bto enter the Time Setting Mode.
•The second’s digits flash because they are
selected.
2.Press Ato change the selection in the following
sequence.
•Pressing Aalso illuminates the display.
Seconds Hour Minutes
Day of week Day Month
3. While the second’s digits are selected (flashing), press Cto reset the
seconds to “00”. If you press Cwhile the second’s count is in the range of
30 to 59, the seconds are reset to “00” and 1 is added to the minutes. If the
second’s count is in the range of 00 to 29, the minute’s count is unchanged.
4. While any other digits (besides seconds) are selected (flashing), press Cto
increase the number. While the day of the week is selected, pressing C
advances to the next day. Holding down Cchanges the current selection at
high speed.
5. After you set the time and date, press Bto return to the Timekeeping Mode.
•If you do not operate any button for a few minutes while a selection is
flashing, the flashing stops and the watch goes back to the Timekeeping
Mode automatically.
