Casio GW-002J Troubleshooting guide

SERVICE MANUAL
& PARTS LIST
(WITHOUT PRICE)
QW-2914
MODULE NO.
R
REF. NO. S/M-883
MAR. 2005
GW-002J
Ver.1 : Apr. 2007

CONTENTS
Page
1. SPECIFICATIONS: MODULE QW-2914 .................................................... 1
2. OPERATION CHART: MODULE QW-2914 ............................................... 2
3. DRAWINGS: MODULE QW-2914
3-1. LCD DIAGRAM ............................................................................................10
3-2. CIRCUIT DIAGRAM ..................................................................................... 11
3-3. CHECKING TERMINALS AND COMPONENTS ......................................... 12
4. EXPLODED VIEW: MODULE QW-2914 ................................................... 14
5. PARTS LIST: MODULE QW-2914 ............................................................ 15
6. PRECAUTIONS FOR REPAIR: MODULE QW-2914
6-1. AC (ALL CLEAR) AND REMOVING OF MODULE ..................................... 16
6-2. ACCURACY CHECKING .............................................................................16
6-3. SOLAR CELL-PCB ASS'Y CONTACT CHECKING....................................17
6-4. HOW TO CHECK TILT SENSOR.................................................................17
7. TROUBLESHOOTING FOR TIME RECEPTION: MODULE QW-2914 .... 18
8. CHANGES TO THE PCB ASS'Y ............................................................... 19

— 1 —
1. SPECIFICATIONS: MODULE QW-2914
Battery CTL1616 (Storage battery)
Note: Use CTL1616 only. Other storage battery or CR1616 can cause
damage to the watch.
Battery life Approx. 8.5 months (from full charged condition)
Current consumption 1.161 µA maximum
Alarm system Piezo plate on Cover/Back
Accuracy ±15 sec./month
Accuracy setting system Trimmer capacitor
Accuracy checking See page 16
Functions • Electro-luminescent backlight
Full auto EL light
• Solar powered
• Battery power indicator
• Power Saving (Turns off the display when the watch is left in the dark)
• Time calibration signal reception
Auto receive (Three times a day at 1:00AM, 2:00AM and 3:00AM)
Manual receive
Last date/time received display
• ReceivableTime Calibration Signals
Fort Collins, Colorado (Call sign: WWVB, Frequency: 60KHz)
Fukushima, Japan (Call sign: JJY, Frequency: 40KHz)
Fukuoka/Saga, Japan (Call sign: JJY, Frequency: 60KHz)
• World Time
29 time zones (30 cities), daylight saving time on/off
• 1/100-sec.stopwatch
Measuring capacity: 23:59'59.99"
Measuring modes: Elapsed time, split time, 1st-2nd place times
• Daily alarms
5 independent daily alarms(4 one-time alarms and 1 snooze alarm)
• Hourly alarms
• Auto-calendar (to year 2039)
• 12/24-hr format
• Regular timekeeping:
hr, min, sec, pm, month, date, day
• Countdown timer
Measuring unit: 1/10 second
Countdown range: 60 minutes
Countdown start time setting range: 1 to 60 minutes (1-minutes increments)
Item Detail

— 2 —
2. OPERATION CHART: MODULE QW-2914
Power Saving causes the watch to enter a sleep state automatically and save power whenever the watch is left in the dark. The Power Saving feature of the watch is turned on at the factory. •Note that the watch may also enter the sleep state if the watch is blocked from light by your sleeve. ■How the sleep state works Display sleep state The display sleep state is triggered whenever the watch is left in the dark for about one hour between the hours of 10:00 p.m. and 6:00 a.m. •The display sleep state causes the display to go blank, except for
a flashing Power Saving indicator. The alarm and the hourly time signal continue to operate normally while the watch is in the display sleep state.
•The watch will not enter the sleep state if it is in the Timer Mode or
the Stopwatch Mode.
Power Saving Indicator
Function sleep state The function sleep state is triggered whenever the watch is left in the dark for six or seven days. The power saving indicator stops flashing and remains on the display to indicate the function sleep state. •The alarm and the hourly time signal are disabled while the watch
is in the function sleep state, and time calibration signal auto receive is not performed.
•Digital timekeeping functions continue to operate normally in the
function sleep state.
■To recover from the sleep state Move the watch to a brightly lit location or press any button. The watch will also recover from the sleep state if you angle it towards your eyes for reading (see “To illuminate the display with the auto
light switch”).
•It can take up to two seconds before display figures re-appear
after you place the watch in a well-lit area.
■To turn Power Saving on and off Use the procedure under “Configuring Home Time Settings”to turn
Power Saving on or off.
Leaving the watch in a drawer or anywhere else it is dark can cause Power Saving to trigger in order to conserve battery power.
This watch is available with either of two different LCD types: light background with dark figures (black-on-white) or dark background with light figures (white-on-black). Note that all of the samples in this manual show the black-on- white type LCD.
Black indicates “ON”.White indicates “ON”.
Black-On-White White-On-Black
Power Saving LCD Types
Each press of the CC
CC
Cbutton sounds a confirmation tone and cycles through available modes in the sequence shown below.
•The display will revert to the Timekeeping Mode automatically if you leave the Alarm Mode screen displayed without performing any
operation for about two or three minutes.
Timekeeping Mode
(Screen Switching)
(Display Illumination)
(Mode switching)
Graphic Dial
Hour, minute, second
Receive Indicator
Month/Day Day of the Week
Battery Indicator
Changing Display Screen Contents Each press of the button toggles the lower display contents between the date (month/day) and the day of the week. Days of the Week SUN: Sunday MON: Monday TUE: Tuesday WED: Wednesday THU: Thursday FRI: Friday SAT: Saturday •
A segment appears with the passage of each second of the current minute.
•
For details about the battery level indicator, see “Battery Level Indicator”. For details about the receive indicator, see
“Receive Indicator”.
Button Button
Button
Button Button
PM Indicator (Appears with times between noon and midnight.)
Modes and Display Screens
World Time Mode Alarm Mode
Stopwatch Mode Timer Mode
Current Time in Selected City
City Code
Alarm Time
Alarm Number
Timer Time
Mode Indicator
Elapsed Time
Mode Indicator

— 3 —
The power supply of this watch uses a solar cell to generate electrical power, which is stored by a rechargeable battery. Using or storing the watch where it is not regularly exposed to light, or allowing it to be blocked from light by your sleeve for long periods as you are wearing it can cause the power of the rechargeable battery to run down. To ensure stable operation, be sure to allow the watch to be exposed to light as much as possible when you are wearing or storing it. Important! Note that all data in memory and all settings are cleared whenever you allow the level of the rechargeable battery to drop to Level 4. ■Flashing Recover Indicator If you use the light or alarm a number of times during a short period, a recover (RECOV) indicator flashes on the display and the following operations become disabled as battery power recovers. •Display illumination, •Alarm and hourly time signal •Time calibration signal reception Normal operation will return after the battery recovers.
Recover Indicator
■Charging Precautions Avoid charging the watch in the following locations, and anywhere else where the watch may become very hot. •On the dashboard of an automobile parked in the sun •Very close to an incandescent light source or other sources of
heat
•In a location exposed to direct sunlight for long periods Note that the display panel may become black under very high temperatures. This is temporary, and the display will appear normal again at lower temperatures.
Depending on the light source you are using, the case of the watch may become quite hot during charging. Take care to guard against burn injury after charging.
■To charge the battery Point the solar panel (display) of the watch at a light source. •Remember that even a partial blockage of the solar cell reduces
charging efficiency. Example: Positioning the watch
Solar Cell
•The illustration shows the resin band model.
Power Supply Display Illumination
An EL (electroluminescent) panel is used to illuminate the display of the watch for easy reading in the dark. An auto light switch automatically illuminates the display when you angle the watch towards your eyes for reading. ■To illuminate the display manually
Press the LL
LL
Lbutton in any
mode to illuminate the display of the watch.
•You can use the procedure under
“To specify the illumination duration”to select either 1.5 seconds or 2.5 seconds for the illumination duration.
•Pressing the Lbutton illuminates the display regardless of
whether the auto light switch is on or off.
You may hear a faint rattling sound when you move the watch around. This sound is caused by the movement of a metal bulb that controls operation of the auto light switch, and does not indicate malfunction.
■To illuminate the display with the auto
light switch
The auto light switch automatically illuminates the display whenever you angle the watch towards your eyes for reading, but only when it is dark. •The auto light switch does not illuminate the display when
surrounding light is bright.
You can use the procedure under “To specify the illumination duration”to configure the illumination duration as approxi- mately 1.5 seconds or 2.5 seconds.
■To turn the auto light switch on and off While a setting screen (one on which a setting is flashing) is on the display, hold down the Lbutton for about two seconds to toggle the auto light switch on (auto light switch on indicator displayed) and off (no indicator displayed).
Auto Light Switch On Indicator
■Positioning Your Arm Correctly •You should be wearing the watch on the outside of your wrist
when using the auto light switch.
•Make sure that the left (9 o’clock) and
right (3 o’clock) sides of the watch are
within ±15 degrees of being parallel with the ground. The auto light switch may not operate properly if the angle is greater.
Important! •The light may be difficult to see if you turn it on under bright
sunlight.
•If you press any button or if an alarm operation starts while the
display is illuminated, illumination will turn off.
•Display illumination does not work while you are performing a time
calibration signal manual receive operation.
•You may hear humming sound from the watch while the display is
illuminated. This is caused by vibration of the EL panel used of illumination, and does not indicate malfunction
.
Auto Light Precautions
•Frequent use of the auto light can run down the battery. •The auto light switch may cause the display to illuminate when
your sleeve covers the display of the watch.
•The display may not illuminate immediately when you angle the
watch towards your face. This does not indicate malfunction.
•The display remains illuminated for the currently set duration (1.5
or 2.5 seconds) only, even if you leave the watch angled towards your face.
•The auto light switch is automatically disabled whenever battery
power is at Level 3 or lower.
•The display may illuminate unintentionally when you wear the
watch on the inside of your wrist, when you shake your arm, or when you raise your arm. Be sure to turn off the auto light switch whenever you do not need display illumination.
•Keep the auto light switch turned off whenever you are wearing
the watch on the inside of your wrist.
•Electro-static charge and magnetism can interfere with auto light
operation and even make operation impossible. If this happens lower your arm to the starting position and then raise it again. If you still have trouble with illumination, try lowering your arm down to your side and then raise it to your face for reading.
Battery Level Indicator
Normal operation enabled. Normal operation enabled.Level 1
Black-On-
White White-On-
Black
Level 2 Level 3 Level 4
Digital display, illumination, alarms, tones (alarms, hourly time signal), and signal reception disabled.
All functions, including timekeeping, disabled.
•Exposing the watch to direct sunlight or other strong light may cause
the battery level indicator to indicate a level momentarily that is higher than the actual battery level. Because of this, you should wait for a short while after charging to check the battery level indicator.
•Even after the battery drops to Level 4, you will be able to resume
normal operation by charging the battery.
•When charging from Level 4, the display will start operating when
the battery reaches Level 3. At this time you will be able to configure time and date settings, but you should keep the watch exposed to light until the battery reaches Level 2 or Level 1.
■Start charging at Level 3! Battery Level 3 indicates that remaining battery power is very low. Be sure to expose the watch to light for recharging as soon as possible after the Level 3 indicator starts to flash.
■Charging Guide Starting from a full charge, the watch should be able to continue operating for about eight months without further charging under the conditions described below. Daily Use (All time values are approximate.) •Display Illumination: 1.5 seconds •Alarm: 10 seconds •Signal reception: 16 minutes •Display On: 18 hours Making sure the watch is regularly exposed to light ensures stable operation. •Charge Times Required to Advance to a Higher Level
Approximate Exposure Time
Level 4 Level 3 Level 2 Level 1
––––––
2 hours 6 hours22 hours 5 hours 9 hours
101 hours
30 hours109 hours 61 hours222 hours
Exposure Level
(Brightness)
Outdoor Sunlight
(50,000 lux)
Daylight Through a Window on
an Overcast Day (5,000 lux)
Indoor Fluorescent
Lighting (500 lux)
Sunlight Through a
Window (10,000 lux)
•Note that the above charging times are for reference only. Actual
charging time depends on a variety of environmental factors.
Rotate your arm so the watch isangled at about 40degrees, so you can read its display.
With the watch on your wrist, position it level with the ground.
11 11
122
22
2
At least 40 degrees
Required Daily Charging Time •
The following is the daily
amount of charging required each day to support the operations under “Daily Use”.
Exposure Level
(Brightness)
Outdoor Sunlight
(50,000 lux) 5 minutes
24 minutes 48 minutes
8 hours
Sunlight Through
a Window
(10,000 lux)
Daylight Through a
Window on an Overcast
Day (5,000 lux)
Indoor
Fluorescent
Lighting (500 lux)
Approximate
Exposure
Time

—4 —
■To specify the illumination duration 1.
In the Timekeeping Mode, hold down AA
AA
Afor about
two seconds.
•This will cause your Home
City code to flash on the display.
2.
Press the CC
CC
Cbutton three
times to display the flashing seconds count.
3.
Press the BB
BB
Bbutton to
toggle the illumination duration between about 1.5 seconds ( indicator)
and 2.5 seconds (indicator).
4.
After the setting is the way you want, press the AA
AA
A
button to exit the setting screen.
•The watch will also exit the setting screen automatically if you
do not perform any operation for about two or three minutes.
Home City Code
(3 times) Seconds
What is a radio-controlled watch? Your radio-controlled watch is designed to receive a time calibration signal that contains standard time data, and adjust its current time setting accordingly.
Signal data
Cesium
atomic
clock
Transmitter
Internally
Decode
Watch
Time data
Signal is received using built-in antenna.
Watch decodes received data and converts it to time data. Time is adjusted according to time data.
Long- wave time calibration signal
After the watch receives the Standard Time signal, it performs internal calculations to determine the current time. Because of this, there may be an error of up to one second in the displayed time.
How a Radio-controlled Watch Works
Reception Range This watch is designed to receive the standard time calibration signal of Japan (JJY) or of the United States (WWVB). The signal that is received depends on the current Home City setting. •For information about selecting a Home City, see “Configuring Home Time Settings”. For information about city codes, see the “World Time
City Code List”.
Home City
TYO, SEL
LAX, DEN, CHI, NYC
Transmitter
Either the Mt. Otakadoya signal (40kHz) or the Mt. Hagane signal (60kHz) Fort Collins, Colorado signal
1000km
Mt. Hagane
(60kHz)
Mt. Otakadoya
(40kHz)
500km
1000km
500km
Japan Transmitter Locations
•Under optimum conditions, the calibration signal should be
receivable up to 1,000 kilometers from the transmitter. Note that the wave is relatively weak at distances greater than 500km, so reception may be poor at long distances.
U.S. Transmitter Location
3000km
1000km
Fort Collins
•Under optimum conditions, the calibration signal should be
receivable up to 3,000 kilometers from the transmitter. Note that the wave is relatively weak at distances greater than 1,000km, so reception may be poor at long distances.
•Geographic contours, nearby buildings, seasonal conditions, the time of day, can even make reception impossible even when you are within
range of the transmitter.
•Best reception is possible late at night.
Location Reception is difficult and may even be impossible in the locations described below. Avoid such locations when performing signal reception. •You should think of your watch operating like a radio or TV when it
is receiving the calibration signal.
If you are experiencing problems with reception, move away from the types of locations described above to a location with better reception, and try again.
Calibration Signal •The Japanese calibration signal (Call Sign: JJY) is maintained by
the National Institute of Information and Communications Technology (NICT). It is a long wave signal transmitted 24 hours a day from the Mt. Otakadoya transmitter (40kHz) located in Tamura-gun, Fukushima Prefecture, and from the Mt. Hagane transmitter (60kHz) located on the border between Saga Prefecture and Fukuoka Prefecture.
•The U.S. calibration signal (Call Sign: WWVB) is transmitted by
the National Institute of Standards and technology from Fort Collins, Colorado.
Note that transmission of the time calibration signal may be interrupted occasionally due to maintenance, lightning, etc.
Near high-voltage linesAmong or near buildings
Near mountains
Inside a vehicle
(automobile, train, plane, etc.)
In a location where there is radio interference (construction site, airport, etc.)
Next to a household appliance or office equipment (TV, speaker, fax, computer, cell phone, etc.)
Receiving the Calibration Signal There are two methods you can use to receive the time calibration signal. Auto Receive (3 times per day) When the Home City setting is TYO or SEL, the time calibration
signal is received automatically at 1:00, 2:00, and 3:00 each morning. •If both the 2:00 and 3:00 receive operations are unsuccessful, a
receive operation is performed at 4:00. If receive is still unsuccessful, it is performed again at 5:00.
•If all five of the above receive operations are unsuccessful, a
receive operation is performed again at midnight the following day.
When the Home City is NYC, CHI, DEN, or LAX, auto receive is performed at midnight, and at 1:00 and 2:00 in the morning. •If both the 1:00 and 2:00 receive operations are unsuccessful, a
receive operation is performed at 3:00. If receive is still unsuccessful, it is performed again at 4:00.
•If all five of the above receive operations are unsuccessful, a
receive operation is performed again at 5:00.
Manual receive (You initiate reception using a button operation.)
The watch is set up for auto receive at the factory, so all you need to do is to place it in a location that allows good reception each night.

— 5 —
■To position the watch for optimum
reception
Remove the watch from your wrist and place it somewhere so its top (12 o’clock side, where the antenna is located) is facing
approximately in the direction of the signal transmitter. Keep the watch away from metal objects.
Resin band
Metal band
•Orienting the watch so it is sideways to the transmitter makes it
more difficult to receive the signal.
•Do not move the watch while it is receiving the calibration signal. ■Time Required for Reception A calibration signal receive operation takes anywhere from about two to five minutes. •Note that when “AUTO”(Auto Select) is specified as the
transmitter selection mode, signal reception can take up to 12 minutes.
•See “Configuring Auto Receive Settings”for more information.
■To perform manual receive
In the Timekeeping Mode, hold down the DD
DD
Dbutton for about
two seconds.
•The watch will beep and
reception will start. An indicator will appear on the display to indicate reception conditions.
■To interrupt reception
Press the DD
DD
Dbutton.
•All other buttons besides Dare disabled during signal reception. When reception is successful The watch terminates reception and adjusts the current time. Next it beeps and then displays the date and time that the adjustment was performed. •The watch will return to the Timekeeping Mode screen if you
press the Dbutton or if you do not perform any operation for about two or three minutes.
Reception Error (ERR Indicator) The watch does not adjust its current time setting, and displays “ERR”when signal reception is unsuccessful for some reason.
•The watch will return to the Timekeeping Mode screen if you
press the Dbutton or if you do not perform any operation for about two or three minutes.
■Receive Indicator The receive indicator cycles from “Unstable”through “Stable”as
shown below while reception is in progress. How far it cycles depends on the signal strength. Keep the watch in a location where reception is stable while reception is in progress.
White-On- Black Black-On- White
Unstable Stable
•Even under optimum reception conditions, it can take about 10
seconds for reception to stabilize.
•Use the receive indicator to check reception status and to
determine the best location for signal reception.
•Note that weather, the time of day, surroundings, and other
factors can all affect reception.
Receive Indicator
■To view the last reception date and time
In the Timekeeping Mode, press the DD
DD
Dbutton.
•This causes the display to start alternating between the last
reception date screen and the last reception time screen at two- second intervals.
•“– ––” will appear in the digital display if the watch has not been
able to perform any signal reception successfully.
•To return to the Timekeeping Mode, press the Dbutton again. •The watch will return to the Timekeeping Mode automatically if
you do not perform any operation for about two or three minutes.
Last reception date
2 seconds
Last reception time
3.
Use the DD
DD
Dand BB
BB
Bbuttons
to cycle through the available auto receive settings.
4.
When the setting is the way you want, press the
AA AA
Abutton.
•This will exit the setting
screen and return to the last reception date and time screens.
•To return to the Timekeeping
Mode, press the Dbutton again.
•The watch will return to the
Timekeeping Mode automatically if you do not perform any operation for about two or three minutes.
Configuring Auto Receive Settings Use the procedure below to turn auto receive of the time calibration signal on or off. When TYO (Tokyo) or SEL (Seoul) is selected as your Home City, you can also specify the transmitter selection mode, which controls which Japanese transmitter signal should be used for time calibration. •For information about selecting your Home City, see “Configuring
Home Time Settings”.
•The initial factory default settings for auto receive are Home City =
TYO (Tokyo); Auto Receive = On; Transmitter = AUTO
•The following procedure can be performed only when TYO, SEL,
NYC, CHI, DEN, or LAX is selected as the Home City.
■To configure auto receive settings 1.
In the Timekeeping Mode, press the DD
DD
Dbutton.
•This causes the display to
start alternating between the last reception date and time screens.
•The watch will return to the
Timekeeping Mode automatically if you do not perform any operation for about two or three minutes.
2.
Hold down the AA
AA
Abutton
for about two seconds.
•This will cause the current
auto receive setting to flash on the display.
Auto Receive Settings when the Home City is TYO or SEL
•AUTO
Auto receive turned on with automatic selection of either the
Mt. Otakadoya signal (40kHz) or the Mt. Hagane signal (60kHz), whichever is strongest.
•J40
Auto receive turned on for the Mt. Otakadoya signal (40kHz).
•J60
Auto receive turned on for the Mt. Hagane signal (60kHz).
•OFF
Auto receive turned off.
Auto Receive Settings when the Home City is NYC, CHI, DEN, or LAX
•ON
Auto receive turned on for the Ft. Collins, Colorado signal.
•OFF
Auto receive turned off.
Calibration Signal Reception Precautions •Auto reception can be performed while the watch is in the
Timekeeping Mode or World Time Mode only.
•Reception cannot be performed while Timer Mode countdown is in
progress.
•Pressing any button while auto reception is in progress will cause
the watch to beep and then exit the receive operation.
•Make sure you are within the range of the calibration signal
transmitter before performing the reception operation. Remember that geographic contours, nearby buildings, seasonal conditions, the time of day, can even make reception impossible even when you are within range of the transmitter.
•Proper reception may be impossible if there is something blocking
the signal. If reception is unsuccessful, try again.
•This watch is designed to adjust its current time setting in
accordance with the calibration signal transmitted in Japan and the United States only. It operates like a standard (non-radio controlled) watch outside of the range of the receivable time calibration signal transmitters.
•When the watch is unable to adjust its time signal using the
calibration signal for some reason, timekeeping accuracy is within ±15 seconds per month.
•Strong electrostatic charge can cause timekeeping error. •Signal reception is cancelled if the alarm starts to sound while it is
being performed.
•The watch’s calendar shows dates up to the year 2099.
Attempting a receive operation after that causes an error.

—6 —
Troubleshooting The watch cannot receive the time calibration signal. •Is the signal being transmitted?
Though the Japanese calibration signal (Call Sign: JJY) is
continually transmitted by the National Institute of Information and Communications Technology (NICT) in theory, it may sometimes be interrupted for periodic maintenance work, or because of lightning or other problems.
•Are you within the reception range of a transmitter?
See “Reception Range”for information about areas where the
watch can receive the signal.
•Is there something in the immediate area that may be interfering
with reception?
Even if you are within the reception range of a transmitter, objects
between you and the transmitter or electrical noise can interfere with reception. Avoid such areas during signal reception. See “Location”for more information.
•Do you have the correct Home City code selected?
Remember that auto receive is not performed unless TYO
(Tokyo), SEL (Seoul) NYC (New York), CHI (Chicago), DEN (Denver), or LAX (Los Angeles) is selected as the Home City. Select the correct Home City code using the procedure under “Configuring Home Time Settings”.
•Is auto receive turned off (OFF)?
Use the procedure under “Configuring Auto Receive Settings”to
turn on auto receive.
•Is the watch in any mode other than the Timekeeping Mode or
World Time Mode during the auto receive times (midnight, 1:00 a.m., 2:00 a.m., 3:00 a.m., 4:00 a.m., and 5:00 a.m.)?
Auto receive is performed only when the watch is in the
Timekeeping Mode or World Time Mode. It is not performed if the watch is in any other mode.
Time calibration signal reception is successful, but the hourly
time signal and current time are slightly off. •After the watch receives the time calibration signal, it performs an
internal decoding process before updating its time setting. Because of this, the time setting may be slightly off (within one second).
Time calibration signal reception is successful, but the current time is one hour fast. •Do you have summer time (DST) turned on (ON)? Use the
procedure under “Configuring Home Time Settings”to turn off summer time.
Time calibration signal reception is successful, but the current time setting is wrong. •Is the correct city code selected for your Home City?
If you are in Japan, you should have TYO selected for your Home City. For other areas, select the correct Home City code using the procedure under “Configuring Home Time Settings”.
World time lets you display the current time in any one of 30 cities (29 time zones) around the world. •When you enter the World Time Mode, the screen for the city that
was displayed when you last exited the mode appears first.
•The seconds count in the World Time Mode is linked with the
Timekeeping Mode seconds count.
•The same 12-hour/24-hour format you select for the Timekeeping
Mode time is also applied in the World Time Mode.
Important! •If the World Time Mode time is incorrect, check the current time
settings in the Timekeeping Mode and the World Time city settings.
•For more information, see “Configuring Home Time Settings”.
Using Summer Time (DST) Summer time, or Daylight Saving Time (DST) as it is known in some countries, calls for setting clocks ahead one hour during the summer season. Note that the use of summer time depends on the country and even the local area. ■To turn summer time on or off 1. In the World Time Mode,
use the DD
DD
Dand BB
BB
Bbuttons
to display the screen for the city code whose summer time setting you want to change.
2. Hold down the AA
AA
Abutton
for about two seconds.
•This toggles summer time on and off. •The “DST”indicator appears on the display and timekeeping
is advanced by one hour when summer time is turned on.
•You can turn summer time on or off independently for each
World Time Mode city. Note, however, that you cannot turn on summer time for the “GMT”city code.
•Turning on summer time for your home time city causes the
time shown in the Timekeeping Mode to be advanced by one hour.
World Time City Code List
City
Code City Name
–––
HNL
ANC
L AX
DEN
CHI
NYC CCS
RIO
––– –––
GMT
LON
PAR
BER
ATH
CAI
Honolulu
Anchorage
Los Angeles
Denver
Chicago
New York
Caracas
Rio de Janeiro
Greenwich Mean Time
London
Paris
Berlin
Athens
Cairo
–11
–10
–9 –8 –7 –6 –5 –4 –3 –2 –1
+0 +0 +1 +1 +2 +2
GMT
Differential
City
Code City Name
GMT
Differential
JRS JED
THR
DXB
KBL
KHI
DEL
DAC
RGN
BKK
HKG
SEL
TYO
ADL
SYD
NOU
WLG
Jerusalem
Jeddah
Teheran
Dubai
Kabul
Karachi
Delhi
Dakar
Yangon
Bangkok
Hong Kong
Seoul
Tokyo
Adelaide
Sydney
Noumea
Wellington
+2 +3
+3.5
+4
+4.5
+5
+5.5
+6
+6.5
+7 +8 +9 +9
+9.5
+10
+11
+12
•The contents of the above table are current as of June 2004. •Time differentials in the above table are in accordance with
Universal Time Coordinated (UTC).
DST Indicator
World Time Mode
The auto receive ON/OFF settings don’t appear when configuring auto receive settings. •Auto receive ON/OFF settings do not appear on the display
unless TYO (Tokyo), SEL (Seoul), NYC (New York), CHI (Chicago), DEN (Denver), or LAX (Los Angeles) is selected as the
Home City. Use the procedure under “Configuring Home Time Settings”to select your correct Home City.
The auto receive AUTO, J40, and J60 settings do not appear
when configuring auto receive settings. •The AT, J40, and J60 transmitter selection mode options are
available only when TYO (Tokyo) is selected as the Home City code. Use the procedure under “Configuring Home Time Settings” to select your correct Home City.
What time is auto receive performed? •Auto receive is performed in the middle of the night, when
reception conditions are best. Before going to bed at night, place the watch near a window, with its 12 o’clock position facing in the general direction of the transmitter.
How can I perform manual receive? •Hold down the lower right Dbutton for about two seconds. The
watch will beep to indicate that manual receive has started. Place it near a window, with its 12 o’clock position facing in the general direction of the transmitter.
How can I view the last reception date and time? •In the Timekeeping Mode, press the lower right Dbutton. This
will display the date and time that the time calibration signal was last received successfully. To return to the Timekeeping Mode, press the Dbutton again. See “To view the last reception date and time”for more information.
•Check the auto signal reception setting whenever you have
problems with signal reception or when the time setting produced by signal reception is incorrect.
•The initial factory default configuration of the reception settings
are shown below. You do not need to change these settings if you use the watch in Japan.
Auto Receive Home City Summer Time
Tokyo Auto Japan transmitter select (40kHz/ 60kHz) Auto switching in accordance with signal data
■
To search for a city code
In the World Time Mode, press the DD
DD
D(westward) or BB
BB
B
(eastward) button.
•This scrolls the available city codes. •Holding down the Band Dbuttons scrolls at high speed.
(Eastward)
(Westward)
City Code
Current Time in Selected City

—7 —
Alarms ■Daily Alarms (AL1 to AL4) The watch beeps for about 10 seconds when an alarm time is reached. ■Snooze Alarm (SNZ) With the snooze alarm, the watch beeps for 10 seconds when the alarm time is reached, and up to seven times at five-minute intervals thereafter (approximately 30 minutes total). Pressing any button stops the beeper, but the alarm will sound again after five minutes. ■To set an alarm time 1. In the Alarm Mode, use the
DD DD
Dbutton to scroll through the alarm screens until the one whose setting you want to change is displayed.
Alarm 3
(AL3)
Alarm 1
(AL1) Alarm 2
(AL2)
Alarm 4
(AL4)
Hourly Time
Signal (SIG)
Snooze Alarm
(SNZ)
2. Hold down the AA
AA
Abutton
for about two seconds until the hour digits start to flash on the display.
•This also causes the alarm on
indicator to appear and automatically turns on the alarm.
3. Use the CC
CC
Cbutton to
select the digits you want to change.
•Each press of the Cbutton
moves the flashing between the hour digits and minute digits.
Alarm Number
(Next alarm)
Alarm on indicator
Hour
Hour
4. Use the DD
DD
D(+) and BB
BB
B(–)
buttons to change the currently selected digits.
•Holding down either button
changes the setting at high speed.
Repeat steps 3 and 4 for the hour digits and the minute digits to set the time you want.
•When setting the hour, make sure you specify AM (A) or PM (P)
correctly when using 12-hour timekeeping, or that you specify the correct 24-hour time.
•The same 12-hour/24-hour format you select for your home time
is also applied in the Alarm Mode.
5. When the setting is the way you want, press the AA
AA
A
button.
•This exits the setting screen. •The display also will exit the setting screen automatically if
you do not perform any operation for about two or three minutes.
■To turn an alarm on and off 1. In the Alarm Mode, use the DD
DD
Dbutton to display the
screen for the alarm you want to turn on or off.
2. Press the BB
BB
Bbutton to toggle the displayed alarm on
(alarm on indicator displayed) or off (alarm on indicator not displayed). Turning on the snooze alarm will cause the “SNZ” indicator to appear on the display.
Alarm 1
Snooze On Indicator
Alarm On Indicator
Alarm On Indicator
Snooze Alarm
(Increase)
(
Decrease
)
■To stop the alarm beeper Press any button. •In the case of the snooze alarm the alarm will sound again in
about five minutes. “SNZ”flashes on the display during the
five-minute period between snooze alarms (indicating that the alarm will sound again).
•The snooze alarm will be canceled automatically when any of the
following occurs while the SNZ indicator is flashing on the display.
•If you turn off the snooze alarm •If you display the snooze alarm setting screen •If you display the Timekeeping Mode setting screen
■To test the alarm In the Alarm Mode, hold down the Dbutton to sound the alarm.
Using the Alarm and Hourly Time Signal
The stopwatch measures elapsed time in units of 1/100 second up to 23 hours 59 minutes, 59.99 seconds (24 hours). When the maximum limit is reached, the elapsed time automatically returns to zero and timing continues from there. ■Performing Stopwatch Operations
In the Stopwatch Mode, press the CC
CC
Cbutton to start and stop
elapsed time measurement.
•During elapsed time measurements, segments in the graphic
dials appear and disappear to indicated the passage of time.
(Start/Stop)
(Split/Reset)
Minutes
Seconds Hours
1/100 Second
•Pressing the Bbutton while timing is being performed
freezes the current elapsed time on the display and displays the “SPL”(split) indicator, while elapsed timing continues internally.
•Changing to another mode while a split time is displayed
clears the split time.
•Pressing the Bbutton while elapsed time measurement is
stopped resets the stopwatch to all zeros.
■Elapsed Time Measurement
Stop ResetStart
Cumulative Elapsed Time Measurement Pressing the Dbutton to restart the stopwatch without resetting it to all zeros causes the elapsed time measurement to resume from where it was last stopped. ■Split Time Measurement
Record Split Release Split ResetStopStart
Split Indicator
Split Time Display
Clears split time.
■1st and 2nd Place Finishers Start 1st finish
(Displays time of 1st finish.)
2nd finish Displays time
of 2nd finish. Reset
Stopwatch Mode
Hourly Time Signal The hourly time signal causes the watch to beep twice every hour on the hour. ■To turn the hourly time signal on and off 1. In the Alarm Mode, use the DD
DD
Dbutton to display the
hourly time signal screen.
2. Press the BB
BB
Bbutton to toggle the hourly time signal on
or off.
•Turning on the hourly time signal causes the hourly time signal
indicator to appear on the display. The watch will beep twice every hour on the hour.
Hourly Time Signal On Indicator
Hourly Time Signal Screen
Minutes

—8 —
You can set the start time of the time in the range of 1 to 60 minutes, in units of one minute. The watch beeps for 10 seconds when the end of the countdown is reached. ■To set the timer time 1. In the Timer Mode, hold
down AA
AA
Afor about two
seconds.
•This will cause the minute
digits of the timer start time to flash.
2. Use the DD
DD
D(+) and BB
BB
B(–)
buttons to change the start time.
•Holding down either button
scrolls the start time setting at high speed.
•You can set a start time in the
range of 1 minute to 60 minutes.
3. After start time is the way
you want, press the AA
AA
A
button.
•This exits the setting screen. •The watch will also exit the
setting screen automatically if you do not perform any operation for about two or three minutes.
Minutes
(Forward)
(Back)
■Using the Timer
In the Timer Mode, press the DD
DD
Dbutton.
•Each press of the Dbutton starts or stops the countdown.
•The timer counts down in 1/10 second units. •During elapsed time measurements, segments in the graphic
dials appear and disappear to indicated the passage of time.
(Start/Stop)
(Reset)
Minutes
Seconds
1/10 second
•Pressing the Bbutton while the countdown is stopped
resets the display to the start time.
•Pressing the Dbutton again while the timer countdown is
stopped restarts the countdown.
■End of Countdown The watch beeps for 10 seconds when the end of the countdown is reached. ■To stop the time up beeper Press any button while the beeper is sounding to stop it.
Timer Mode
Home time settings include your Home City (the city where you will normally use the watch), the current time and date in your Home City, and other settings. •Use the Timekeeping Mode to configure home time settings. •Also use the following procedure when you want to turn Power
Saving on or off.
■To configure home time settings 1. In the Timekeeping Mode,
hold down the AA
AA
Abutton
for about two seconds.
•This will cause the city code
currently selected as the Home City to flash on the display.
2. Use the DD
DD
D(westward)
button and the BB
BB
B
(eastward) button to scroll through the city codes until the one you want to select is displayed.
•See the “World Time City
Code List”for information about city codes.
•Holding down either button
scrolls at high speed.
3. When the city code you
want is displayed, press the CC
CC
Cbutton.
•This will display the summer
time (DST) setting screen.
(Westward)
(
Eastward
)
TYO = Tokyo
Home City Code
4. Press the DD
DD
Dbutton to
cycle through the available summer time (DST) settings until the one you want to select is displayed.
•A (AUTO)
This setting enables the auto summer time setting, which turns summer time on or off in accordance with the received time calibration signal. •This setting uses Japan summer time data when TYO is
selected as the Home City, and U.S. summer time data when NYC, CHI, DEN, or LAX is selected as the Home
City.
•OF (OFF)
This setting turns off summer time and returns to normal
timekeeping.
•On (ON)
This setting turns on summer time and advances the current time by one hour.
•Only OFF or ON can be selected if the current Home City code is
a setting other than HKG, TYO, SEL, NYC, CHI, DEN, LAX, ANC,
or HNL.
5. When the summer time
setting is the way you want, use the CC
CC
Cbutton to
cycle the display through the settings shown below.
Summer Time
Home City
Code
Power Saving
12/24-hour
Timekeeping
Hour
Minute
Month Year
Day
Seconds
Configuring Home Time Settings

— 9 —
10.
When all of the settings are the way you want, press the
AA AA
Abutton.
•This exits the setting screen. •The display also will exit the setting screen automatically if
you do not perform any operation for about two or three minutes.
6. While the 12/24-hour
timekeeping setting is flashing, press the DD
DD
D
button to toggle between 12-hour (“12H”) and 24-hour (“24H”) timekeeping.
7. While the seconds are
selected, press the DD
DD
D
button to reset them to 00 in accordance with the time signal on the radio, TV, etc.
•Pressing the Dbutton while
the seconds count is in the range of 30 to 59 resets it to 00 and also adds 1 to the minutes. Pressing the D button in the range of 00 to 29 resets the seconds count without changing the minutes.
•Pressing the Bbutton while
the seconds count is flashing changes the display illumination duration. See “To
specify the illumination duration”for more information.
8. While the hour, minutes,
year, month, or day setting is flashing, use the DD
DD
D(+)
and BB
BB
B(–) buttons to
change the setting.
•Holding down either button
changes the setting at high speed.
•When setting the hour, make
sure you specify AM (no indicator) or PM (P) correctly, or that you specify the correct 24-hour time.
•You can set a year in the range of 2000 to 2099. The day of
the week is set automatically in accordance with the date you set.
•The watch automatically makes adjustments for leap years
and month lengths.
9. While the Power Saving
setting is flashing, press the DD
DD
Dbutton to toggle it
on (ON) or off (OF).
•If you turn on Power Saving,
the Power Saving indicator will be on the display when you exit the setting screen.
Use the Cbutton to select each of the settings and the Dand
Bbuttons to change them.
Resets to 00.
Indicates 12-hour or 24-hour timekeeping.
(Forward)
(Back)
Hour Year
Minutes

—10 —
3. DRAWINGS: MODULE QW-2914
3-1. LCD DIAGRAM
LC4 L34 L 2 L 3 L 4 L 5 L 6 L 7 L 8 L 9 L10 L11 L12 L13 L14 L15 L16 L17 L18 L19 L20 L21 L22 L23 L24 L25 L26 L27 L32 L28 L29 L30 LC3 LC1 L31 L 1 L33 LC2 LC5
W6
col0
min
g1
c1
b1
d1
e1
sec
W7
W8
W9
f0 b0
f4
g0
c0e0
d0
W5 W4
d5
W3
g4
a0
a4 a3
f3
g3
c4
b4
e4 e2
d2
c2
d4
b5f5 b2f2
a2
b3
d3
e3 c3
g2
PM DST
W0
SNZ
ALM
W2
HIGH
MID
W1
y0 x16
x0
y4
anta0
anta2
anta1
hyp
f1
a1
g5
c5e5
a5
SIG
SPL1
PSAVE
RECOVER AUTOEL
LCHARGE
b4
LCHARGE
PSAVE
f4
b3
g5
a3
col0
min
a4
x16y3
c5
e4 a5
g4
g3
c3
x16y1
d3
e3
x15y3
c4
d4
d5
x16y4
x11y1
x10y0x10y4x10y2
f5
x10y3 x10y1
x11y3 x11y4
x14y4
e5
x11y2
x14y1
x11y0
x14y2 x14y0x14y3
x15y2
x13y2 x13y1
x15y0
DST
x13y0x13y3
PM
x12y2 x12y1x12y0x12y3 x12y4
x13y4
x15y1
x16y0
AUTOEL
x15y4
RECOVER
f3
x16y2
b5 SPL1
hyp
HIGH
L28
L29
L 6
L 7
L 8
L 9
L10
L11
L12
L13
L14
L15
L16
L17
L 5
L30
LC5
b2
g1
f2
b1
a2e2 d2
d1 anta2
anta0
anta1
g2
c1
e1 f1
MID sec
a1
L 4
L 3
L 2
L 1
c2
f0 c0
x8y2
x6y3 x6y1x6y0
x8y4
x5y3 x6y4
W1
W8
x8y3 x8y1
x6y2
x4y1
x3y2 x2y4
x1y2
x8y0
x0y1
g0
x3y1
x7y1x7y0
x4y2
SIG
W7
x0y2 x1y3
e0
x2y2
x0y0
x1y0
x2y0
x3y0x3y4
x4y4x4y3
W9
W0W2
x7y4
d0
x7y3
x5y0x5y4
SNZ
W4
W5 W6
W3
x4y0
x3y3 x2y1
x1y1
b0
x0y3 ALM
x5y1
a0
x5y2
x0y4
x1y4
x7y2
x2y3
x9y1x9y3x9y2 x9y4 x9y0
L18
L19
L20
L21
L22
L23
L25
L26
L24
L27
L31
L32
L33
L34
LC1 LC2 LC3 LC4LC1 LC2 LC3 LC4 LC5
COM
COM
SEG
SEGSEG COM

— 11 —
3-2. CIRCUIT DIAGRAM
GND VDD2
BAT
VCH VDD3 VC1 VC2
C3
C2C5
XTB
Xtal
L1 - - - - L34 LC1 - - - - - LC5
CT
LD1
SA S2
VDD1
C1
BD
C8
LL1
Tr1
XT
T1 T2 T3 KI1 KI2 KI3 KI4 KI5 KI6 KI7 KI8 KI9
S1
SCR SCIN
RP1RP2
Cp
PZ
VDSP
C4
VC3 VC4
Di1
VHF
C6
SDO SCK CSB
AC T4
KC4 KC3 KC2 KC1
R1
R2
VSC
C7
SC
C9
✽1
R3
✽1✽1
Z
VPM
Di2 R1
Rb
GNDB
✽7
✽1
S4
S3
SDI
✽1
N1 N2
✽8
SK
KS
✽2
✽2
✽6 ✽6 ✽4 ✽4 ✽4
✽3 ✽3 ✽3 ✽3
✽3
✽5
✽3
✽9
✽10
✽11
✽3
✽2Cxt
Rxt2
Ccp
Cbat
Rbat
Xtal2
ISB
ANT
Rcp
Rxt3
Xtal3
Cc
✽13
✽12
✽13
✽13
✽13 ✽13 ✽13
Rpd
✽14
✽15
L36L35
INV
LL2
VCC
Rel
ENB GND RT1 RT2
NC NC NC
ELD
CIL
EL
BACK FRONT
✽16
Tr2
Rld1LED1
LED2 Rld2
✽17
✽17
✽17
LCD ( 2.8V 1/3b 1/5d )
LSI
TOTAL 106PINS
BONDING 82PINS
Crh1 Crh2 Crh3 Crl1 Crl2 Crl3
FET-S
GND4
FET-D
P1
GND3
P2
P14
GND5
TCO VCC
P9 P7
Hold
P5
P12 P13
GND1
P3-2
P4
Pon
P3-1
Asel
GND2
✽ 1. No bonding ✽ 2. Kl7-GND: Open (No Soldering) Kl6-KC1: Open (No Soldering) Kl6-KC3: Open (No Soldering) ✽ 3. Latch type key ✽ 4. Short (Soldering) (R trimming) ✽ 5. Inclination sensor ✽ 6. Short (Soldering) (N trimming) ✽ 7. GNDB is used for the bias on the back of the tip. ✽ 8. L28~L30 are used as the static drive pins. ✽ 9. Normal Low ✽ 10. LD2 (Normal Low) is used in this module.
✽ 11. KC3 is used in this module. ✽ 12. Cxt is not mounted in the specification for dual translmitters. ✽ 13. Cc, Crl1, Crl2, Crl3, Rxt3 and Xtal3 are not mounted in the specification
for single transmitter. ✽ 14. Rpd is mounted only in the specification which does not include signal reception. ✽ 15. No parts except Rdp are mounted within the area of the dotted line in
modules without signal reception function. ✽ 16. This PKG can be used with both EL and LED, and the one which is not used is not mounted. ✽ 17. As P3-1, P3-2 and VCC are connected inside ISB, any one of them should be connected to the wiring of Rbat-Cbat.

— 12 —
3-3. CHECKING TERMINALS AND COMPONENTS
1-chip type (pre-change)
Short pad for R trimming
Short pad for N trimming
Short pad for switching modules
OSCILLATOR/CRYSTAL
SENSOR/TILT
CUSHION 6
CUSHION 506
CAPACITOR/TRIMMER
CUSHION 506
12a. PCB ASS'Y
(7640 8263)
GND VSC
KI5
LEDOUT R2
VDD2
R1
VDD2 R2
LEDOUT
R1
LD1 GND
LEDOUT
R1
BD
KI9GND
GNDB
KI3
KI1
GND
GND
KC1
KI6
GND
VSC VDD2
GNDKI8
GND
GND
SCR
SCIN
GND KC3
KI7
GND
N1
SCIN
N2
KI6
R3
R1GND
R2GND
SCIN
KI4
KI2
KI1
KI2
KI4
KI3
P12
VSC
VDD2
BD
KI8
ELD
KI2
AC
KI5
VCH
VC1
KI9
RT2
RT1
GND
VDD2
RT2
RT1
LD1
ELD
CIL
GND
GND
GND
LL1
VCHGND
LL1
VDD2
CIL
GND
GND
VDD1
GND
GND
VHF
VDD3
R1
VDD2
LL1
GND
XT
GND
VCC
VDD2
XTB
Rxt3 P5 P7P5
VC3
VDSP
GND
Rcp
GND
GND
VDD2
P2
P4
Rxt2
P7
VCC
FET-S
Rxt3
VC1
P2
P1
FET-D
LL1
VDSP
VC4
VC2
P9
Rcp
GND
R1
XT
VDD2
Rxt2
P13
P14
LD1
P7
GND
VDD2
GND
GND

—13 —
2-chip type (post-change)
Short pad for R trimming
Short pad for N trimming
Short pad for switching modules
OSCILLATOR/CRYSTAL
OSCILLATOR/CRYSTAL
SENSOR/TILT
CUSHION 6
CUSHION 6
CAPACITOR/TRIMMER
CUSHION 506
12b. PCB ASS'Y
(7641 0226)
R1
R2
KI2
VDD2
GND
R2
VDD2
SCIN
VDD2
GND KC3
KC1
GND
KI6
KI7
KI6
KI9
VSC
GND
VHF
VC3
VC4
SCIN
GND
GNDB
GND
VSC
KI5
GND
ELD
K12
KI1
LEDOUT
R1 LEDOUT LD1
LEDOUT
GND
SCR
VDD2
BD
KI3
AC
VC1
KI8
CIL
VCH
KI4
LD1
RT2
GND
GND
GND
GND
LL1
VC1
GND VDD3
GND
R1 VDD2
LL1
GND
XTB
KI5
VC2
VDD2 3
S2
1
LL1
GND
R1
K12
VDD2
GND
RT1ELD
CIL
VSC
GND
KI1
39
3
Rcp
S
DD
KC2
GND
D
GND
GND
2
KC2
S
Rxt3
5
7
5
GND
Rxt2
77
RT2
VDSP
XT
GND
GND
G
VDD2
XT
GND
VCH
VDD2 GND
GND
16 12 GND GND 13 14
LL1
R1
G
VDD2
VDD2
VDSP
VDD1
Rxt2
GND
RT1
VDD2
4
GND KI8
R2
GND R1
GND
R3 GND
Rxt3
N2
N1
GND
GND
GND
SCIN
KI4 KI3
VSC

—14 —
4. EXPLODED VIEW: MODULE QW-2914
1-chip type : 15a (1017 2599)
2-chip type : 15b (1022 1067)
3 (1016 8959)
8 (7231 1777)
13 (1012 3230)
11 (1016 9827)
1-chip type : 12a (7640 8263)
2-chip type : 12b (7641 0226)
PCB ass'y
7 (1017 2603)
19 (1010 6532)
10 (1006 5664)
4 (1008 3365)
16 (1017 2600)
19 (1010 6532)
9 (1017 2597)
18 (7230 1045)
1 (1006 5657)
Battery storage (CTL1616)
17 (7201 9599)
20 (7210 9058)
2-chip type : 21 (1022 1111)

5. PARTS LIST: MODULE QW-2914
Note: 1. Prices and specifications are subject to change without prior notice.
2. Spare parts are classified as follows according to their importance in after-sales service.
A Rank ---------------------------------------- Very Important
B Rank ---------------------------------------- Important
C Rank ---------------------------------------
-
Less important
3. Batteries in Bulk pack on the tray will be supplied from our Overseas Spare Parts Section under charge basi
s
Batteries in Blister pack will be supplied from our Sales Department.
4. As for order/supply of spare parts, refer to the separate publication "GUIDE BOOK for spare parts supply".
Item Code No. Parts Name S
p
ecification A
pp
licable Q R
7640 8204 MODULE/WITH MOVEMENT QW-2914YC-01TK GW-002J-8A 1 A
11006 5657 BATTERY/STORAGE CTL1616 QW-2914YC-01TK 1 B
21009 7666 CAPACITOR/TRIMMER CTZ2E-25C-W2-P QW-2914YC-01TK 1 B
31016 8959 CONTACT/BATTERY 2730 Q255819-2V05 QW-2914YC-01TK 1 C
41008 3365 CONTACT/BATTERY(-) 1673 Q358740A-2 QW-2914YC-01TK 1 C
57211 0064 CUSHION 6 Q4914A-1 QW-2914YC-01TK 1 C
67211 9631 CUSHION 506 Q49364-1 QW-2914YC-01TK 2 C
71017 2603 EL YEL-2914-A-00 QW-2914YC-01TK 1 A
87231 1777 HOLDER 1381 Q456843-1 QW-2914YC-01TK 1 C
91017 2597 INTERCONECTOR/ 2914 RJQ521721-001V01 QW-2914YC-01TK 1 C
10 1006 5664 LABEL/ 2368 Q468543A-1 QW-2914YC-01TK 1 C
11 1016 9827 LCD S2914-01THP QW-2914YC-01TK 1 A
13 1012 3230 SCREW/FLAT2730 RJQ513792-001V01 QW-2914YC-01TK 1 B
14 7105 5275 SENSOR/TILT TS-2418-P QW-2914YC-01TK 1 B
16 1017 2600 SPACER 2914-1 RJQ522168-001V01 QW-2914YC-01TK 1 C
17 7201 9599 SPRING/COIL 967-1 Q430081-1 QW-2914YC-01TK 1 B
18 7230 1045 SPRING/COIL 2017-1 Q462959-1 QW-2914YC-01TK 2 B
19 1010 6532 SPRING/COIL 2611-1 Q470669A-1 QW-2914YC-01TK 2 B
20 7210 9058 POLE Q430269A-1 QW-2914YC-01TK 1 C
12a 7640 8263 PCB ASS'Y RJQ522663*001V01TK QW-2914YC-01TK 1 A
15a 1017 2599 SPACER 2914 RJQ521942-001V02 QW-2914YC-01TK 1 C
12b 7641 0226 PCB ASS'Y RJQ529876*001V01TK QW-2914YC-01TK 1 A
15b 1022 1067 SPACER 2914-2 RJQ529592-001V02 QW-2914YC-01TK 1 C
21 1022 1111 HOUSING RJQ529593-001V03 QW-2914YC-01TK 1 C
For the
p
rices and minimum order/su
pp
l
y
q
uantities of the above
p
arts, refer to the Parts Price List P.P.L.-616.
Notes: Q - Used quantity
R - Rank
1-chi
p
t
yp
e
2-chi
p
t
yp
e
— 15 —

—16 —
6. PRECAUTIONS FOR REPAIR: MODULE QW-2914
6-1. AC (ALL CLEAR) AND REMOVING OF MODULE
1. Perform AC (ALL CLEAR) when inserting a new battery, or else the memories and/ or counters may give
erratic displays.
Touch the AC contact and the main plate with the metallic tweezers.
The contact should be made for about two seconds.
2. On removing of the module from the case, please insert the precision screw driver between the module
and the case pointed by arrows.
6-2. ACCURACY CHECKING
Check the accuracy of the module with the quartz timer after switching the module to “ACCURACY
CHECKING MODE”.
The operations are shown below:
A) SWITCHING TO “ACCURACY CHECKING MODE”
While pressing the A button, press Cand Dbuttons at the normal timekeeping mode.
Then all the segments are displayed and the LCD drive signals are changed to the static drive signal
of “32 Hz”so that you can check the accuracy with the quartz timer.
B) CANCELLATION OF THE “ACCURACY CHECKING MODE”
Press any button.
Then the display is returned to its original state.
NOTE: The “ACCURACY CHECKING MODE” will
automatically return to the regular mode
in 1 ~ 2 hour(s) without any operation. QW-2914
A
C
B
D
L

—17 —
6-3. SOLAR CELL-PCB ASS'Y CONTACT CHECKING
Check a Solar cell and PCB ass'y are contacted correctly by contact spring, when a module is
disassembled.
1. To enter TEST mode.
1) While pressing Dbutton, press Aand Bbuttons at the normal timekeeping mode.
2. Check a Solar cell and PCB ass'y contact in the following order.
1) Display side up and place the watch on the desk.
2) Check the display indicates as figure 2.
3) Display side down and place the watch on the desk more than 3 seconds.
Or go to a dark room and place the watch more than 3 seconds.
4) Check the display indicates as figure 3.
If“8888”isnot appeared on thedisplay,disassembleagain the module andcheckthecontact spring
between the Solar cell and PCB.
Figure 4 Figure 5
Figure 3
Figure 1 Figure 2
Press D, Aand Bbuttons
Tilt the watch towards you
more than 40°More than 40°
D
B
C
A
Place the watch in a dark
room more than 3 seconds.
3. To exit from TEST mode
Press any button.
6-4. HOW TO CHECK TILT SENSOR
1) Press A, Band Cbuttons at the normal timekeeping mode.
2) Check the display indicates as figure 4.
3) Tilt the watch towards you more than 40 degrees.
4) Check the display indicates as figure 5.
Appear “8888”on display.
Appear “TLT”on display. Appear“8888”ondisplay.

—18 —
7. TROUBLESHOOTING FOR TIME RECEPTION: MODULE QW-2914
Yes
No
Yes
No
Yes
No
Yes
No
START
Check whether the Home City
code is selected correctly.
Perform MANUAL time
calibration signal reception
OK
There is a possibility of the bad location for reception.
Perform AUTO time
calibration signal reception
Replace the PCB ass'y
Signal
reception OK?
Signal
reception OK?
Signal
reception OK?
Replace the Case center
ass'y with antenna
Signal
reception OK?
OK
OK
OK
