Casio 1856 Configuration guide

1856/1933/2065-1
Module No. 1856/1933/2065
GENERAL GUIDE
•Press CC
CC
Cto change from mode to mode.
•In the Timekeeping Mode, press DD
DD
Dto illuminate the display for about 3 seconds. In the Stopwatch Mode, press BB
BB
Bto illuminate the display.
Timekeeping Mode Mix Mode Alarm Mode Stopwatch Mode
TIMEKEEPING MODE
•In the Timekeeping Mode, press EE
EE
Eto switch between
the 12-hour and 24-hour formats. When using the 12-
hour timekeeping format, the letters A and P are used
to indicate “am” and “pm” on the display. No indicator
appears on display for 24-hour format.
•Press DD
DD
Din the Timekeeping Mode to activate the EL
backlight.
•Pressing BB
BB
Bin the Timekeeping Mode randomly selects
and plays one of the six melodies (three preset melo-
dies, three user melodies) in watch memory. While a
melody is playing, dancers and musicians perform on
the display.
Pressing any button interrupts play of the melody.
•See the “MELODY LIST” at the back of this manual for
details on the three preset melodies.
To set the time and date
1.Hold down AA
AA
Awhile in the Timekeeping Mode. The seconds digits flash on the
display because they are
selected .
2.Press CC
CC
Cto change the selection in the following sequence.
Hour
Seconds Minutes
Month
Day
Year
Contrast
3.While the seconds digits are selected (flashing), press EE
EE
Eor BB
BB
Bto reset the sec-
onds to 00. If you press EE
EE
Eor BB
BB
Bwhile the seconds count is in the range of 30 to 59,
the seconds are reset to 00 and 1 is added to the minutes. If the seconds count is
in the range of 00 to 29 , the minutes count is unchanged.
4.While any other digits (besides seconds) are selected (flashing), press EE
EE
Eto in-
crease the number or BB
BB
Bto decrease it. Holding down either button changes the
current selection at high speed.
•Use the contrast adjustment screen (indicated by “CNT”) to adjust display contrast
within a range of 1 to 7. Press EE
EE
Eto increase the contrast value (which makes
figures darker) or BB
BB
Bto decrease the value. In the case of contrast setting, holding
either button does not change the contrast setting at high speed.
5.After you set the time and date, press AA
AA
Ato return to the Timekeeping Mode.
•The day of week is automatically set in accordance with the date.
•The date can be set within the range of January 1, 1995 to December 31, 2039.
•If you do not operate any button for a few minutes while a selection is flashing, the
flashing stops and the watch goes back to the Timekeeping Mode automatically.
About the backlight
In the Timekeeping Mode, press DD
DD
Dto illuminate the display for about 3 seconds.
In Stopwatch Mode, press BB
BB
Bto illuminate the display for about 3 seconds.
•The backlight of the watch employs an electro-luminescent (EL) light, which loses
illuminating power after very long use.
•The illumination provided by the backlight may be hard to see when viewed under
direct sunlight.
•The watch will emit an audible sound whenever the display is illuminated. This is
caused by a transformer that vibrates when the EL panel lights up. It does not
indicate malfunction of the watch.
•The backlight automatically turns off whenever an alarm sounds.
MIX MODE
The Mix Mode lets you arrange your own melody and store it in watch memory. You
can select a rhythm, tempo, and phrase to create a melody. See “USING THE MIX
MODE” for details about how to create a melody.
To play a Mix Mode melody
1.Use the EE
EE
Ebutton to select one of the three available
melodies.
2.Press DD
DD
Dto play the currently selected melody. Press-
ing any button interrupts play of the melody.
•While a melody is playing, dancers and musicians per-
form on the display.
•If the melody number you select above does not have a
user memory assigned to it, a default rhythm pattern
plays instead.
•Pressing BB
BB
Bwhile a melody is selected (but not playing)
displays the melody evaluation screen for the melody.
See “USING THE MIX MODE” for details on evaluating
melodies.
•Holding down BB
BB
Bfor about two seconds while a melody is selected (but not playing)
deletes the melody.
Day of week
Month – Day
PM indicator
Hour
Minutes
Seconds
ALARM MODE
You can set five independent alarms. Use the Alarm Mode
to turn the alarm and the Hourly Time Signal on and off.
•When an alarm is turned on, an alarm tone sounds for
about 10 to 30 seconds when the alarm time is reached.
•When the Hourly Time Signal is turned on, the watch
beeps every hour on the hour.
•You can use any of the preset melodies (M-1, M-2, M-
3) or melodies you arrange with the Mix Mode for the
alarm in place of the standard beep sound. See “US-
ING THE MIX MODE” for details on arranging your own
melodies.
•See the “MELODY LIST” on the next page of this man-
ual for details on the three preset melodies.
•The alarm does not sound if the alarm time is reached
while you are arranging a melody in the Mix Mode.
To set alarms 1.Press EE
EE
Ewhile in the Alarm Mode to select an alarm
(Alarm 1 through Alarm 5).
Alarm 2
Alarm 1 Alarm 3
Alarm 5
Hourly Time Signal
Alarm 4
2.After you select an alarm, hold down AA
AA
A. The alarm
sound name flashes on the display because it is
se-
lected
.
•At this time, the alarm is automatically switched on.
3.Press CC
CC
Cto change the selection in the following se-
quence.
Hour
Alarm sound
name Minutes
4.Press EE
EE
Eto increase the selected digits and BB
BB
Bto decrease them. Holding down
either button changes the selection at high speed.
•The format (12-hour and 24-hour) of the alarm time matches the format you select
for normal timekeeping.
•When setting the alarm time using the 12-hour format, take care to set the time
correctly as morning (A) or afternoon (P).
5.While the alarm sound name is flashing, press EE
EE
Eor BB
BB
Bto scroll through the avail-
able alarm sounds to find the one you want.
M-2
M-1 M-3
001
BEEP
002003
•Melody numbers, 001 through 003 can be replaced by user melody names. If you
have not created your own melodies or if you did not assign names to melodies
you created, melodies are identified by their numbers 001 through 003.
6.After you finish inputting data, press AA
AA
Ato return to the Alarm Mode.
•If you do not operate any button for a few minutes while a selection is flashing, the
flashing stops and the watch goes back to the Alarm Mode automatically.
To stop the alarm
Press any button to stop an alarm when it starts to sound.
To switch an Alarm on and off
1.In the Alarm Mode, press EE
EE
Eto select an alarm.
2. When the alarm you want is selected, press BB
BB
Bto switch
it on and off.
......... Individual alarm indicator
Indicates whether the alarm whose number
is currently selected in the Alarm Mode is
on.
ALM ....... General alarm indicator
This indicator is shown on the display in all
modes while any alarm is on.
Title
Melody number
Current time
Alarm sound name
Individual alarm on indicator
General alarm on indicator
Alarm time
Alarm number
Individual alarm on indicator
General alarm on indicator
Alarm timeAlarm number
Current time
Mode indicator
Individual alarm on indicator
General alarm on indicator
Alarm time
Alarm number

1856/1933/2065-2
Elapsed time measurement
Start Stop Re-start Stop Clear
Start Split Split release Stop Clear
Start Split Stop Split release Clear
Split time measurement
Split time and 1st-2nd place times
First runner
finishes. Second runner finishes.
Record time of
first runner.
Record time of
second runner.
To turn Hourly Time Signal on and off
1.In the Alarm Mode, press EE
EE
Eto select the Hourly Time
Signal.
2.When the Hourly Time Signal is selected, press BB
BB
Bto
toggle it on (ON appears in lower part of the display)
and off (OFF displayed).
......... Hourly Time Signal Indicator 1
This indicator is shown in the Alarm Mode
only to indicate that the Hourly Time Signal
is on.
SIG ........ Hourly Time Signal Indicator 2
This indicator is shown on the display in all
modes while the Hourly Time Signal is on.
To test the alarm
Press DD
DD
Dwhile in the Alarm Mode to sound the alarm. Press any button to stop the
alarm.
STOPWATCH MODE
The Stopwatch Mode lets you measure elapsed time, split
times, and two finishes. The range of the stopwatch is 23
hours, 59 minutes, 59.99 seconds. You can use the EL
backlight by pressing BB
BB
Bat any time while the stopwatch
is operating.
Hourly time signal
on indicator 2
Hourly time signal
on indicator 1
Current time
Hourly time signal
on/off display
Mode indicator
Hours
Minutes
Seconds
1/100 Second
M-1 HIGH ENERGY PROTONS
M-2 FEEL THE UNIVERSE
M-3 FREAK
All of these are CASIO original melodies.
MELODY LIST
M-1 New year’s day
M-2 Orinoco flow
M-3 Runaway T-9890248
1856
1933
M-1 Lovin’ you
M-2 In The Summertime
M-3 Baby, I love Your Way T-9910248
2065

1856/1933/2065-3
Number Rhythm Name Number Rhythm Name
01 16 beat 09 Country
02 New jack swing 10 Swing
03 Mambo 11 House
04 Rock 12 R&B
05 Bossa nova 13 Soul
06 Ballad 14 Oriental
07 Samba 15 Hip hop
08 Reggae 16 Techno
•Pressing DD
DD
Dplays a sample of the currently displayed rhythm. Press any button to
interrupt play of a rhythm.
3.After setting the rhythm, press EE
EE
Eto cycle through the available tempo values in
the sequence shown below.
130
170 160 150 140180
60 70 80 90 100 110 120
200 190
•The initial tempo setting is the one that is recommended for the currently selected
rhythm.
•Pressing DD
DD
Dplays a sample of the currently selected rhythm and tempo. Press any
button to interrupt play of a rhythm.
Selecting a Phrase While rhythm and tempo selection screen is on the dis-
play, press CC
CC
Cto display the phrase selection screen.
You can assign one of 10 musical phrases each to but-
tons BB
BB
B, CC
CC
C, DD
DD
Dand EE
EE
E. A button mark (flashing) and the
phrase mark on the display shows which phrase is as-
signed to which button.
The following table shows the meaning of each phrase mark.
Phrase Mark Instrument Phrase Mark Instrument
Electric guitar
Timbales
Trumpet
Piano
Maracas
Bell
Cymbal
Violin
Accordion
Marimba
•Each phrase is written in a style that is representative of its phrase mark instru-
ment.
To assign a phrase to a button 1.Use EE
EE
Eto select the button to which you want
to assign the phrase.
2.Use BB
BB
Bto select a phrase.
•Repeat steps 1 and 2 to assign phrases to all
four buttons.
•Pressing DD
DD
Dplays a sample of the currently se-
lectedphrase. Pressany buttonto interruptplay
of a phrase.
Rhythm number
Tempo value
Button position number
Phrase mark
Button marks
P-1
P-2
P-3
P-4
Hold down AA
AA
A
Press AA
AA
A
Press DD
DD
D
Press CC
CC
C
no operation
for a few minutes
Press CC
CC
C
Selecting a
Melody Number Selecting a
Rhythm and Tempo Selecting a Phrase Insert Phrases Assign a title
The above illustration shows the general flow of the Mix Mode only.
Note that you will also have to press other keys in addition to those noted above.
Press CC
CC
C
Press DD
DD
D
The Mix Mode lets you arrange your own melody and store it in watch memory. You
can select a rhythm, tempo and phrase to create a melody eight measures long.
Rhythm Measure
1Measure 2Measure 3Measure 4Measure 5Measure 6Measure 7Measure 8
Phrase
•You can arrange a melody using the watch’s pre-pro-
grammed rhythms and phrases only. You cannot input
your own melodies.
After you arrange a melody, you can play it back in the
Mix Mode or use it for an alarm sound.
•In the Timekeeping Mode, press CC
CC
Cto enter the Mix
Mode.
•The following shows the default rhythm patterns that are assigned to each melody
number. These patterns are automatically restored whenever you delete the melo-
dy.
Melody Number 001 002 003
Melody Name 001 002 003
Rhythm Number 01 02 03
Rhythm Name 16 beat New jack swing Mambo
Tempo Value 120 190 110
P-1 Electric guitar Trumpet Violin
P-2 Trumpet Marimba Accordion
P-3 Maracas Bell Timbales
P-4 Cymbal Cymbal Piano
Phrases
Assign
General Procedure
The following are the general steps for arranging a melody in the Mix Mode. Details
for each step are provided in the following sections.
1.Select a melody number (001~003).
2.Select a rhythm and tempo that you want to use as a basis for your melody.
3.Assign phrases to each button.
4.Insert phrases by pressing buttons in accordance with the rhythm.
5.Assign a melody name to the completed melody.
Important!
If you do not perform any button operation for a few minutes while arranging a melo-
dy, the watch automatically returns from the input screen to the standard Mix Mode
screen. If this happens, restart from step 1 of the General Procedure.
Selecting a Melody Number
There are three melody memory areas numbered 001, 002 and 003. Press EE
EE
Eto
select the memory area where you want to store the melody you will arrange.
001 003002
•Until you input your own melody name, the default melody name is the same as the
melody number.
•Selecting a melody number that already has a melody assigned to it and inputting a
new melody causes the existing melody to be replaced by the new one.
•Pressing DD
DD
Dwhile the melody number that already has a melody assigned to it is on
the display plays back the melody. Press any button to interrupt melody playback.
•Pressing BB
BB
Bwhile the melody number that already has a melody assigned to it is on
the display displays an evaluation of the melody. See “Mixing a Melody” below for
details.
•Holding down BB
BB
Bfor about two seconds while a melody number that already has a
melody assigned to it is on the display deletes the melody and restores the melody
number’s default pattern.
Selecting a Rhythm and Tempo
Select a rhythm and tempo that you want to use as a ba-
sis for your melody.
1.Hold down AA
AA
Auntil the rhythm selection screen appears.
•The indicators “REC” and “TEMPO” appear on the dis-
play.
2.Press BB
BB
Bto advance to the next rhythm number. The
following table shows the meaning of each rhythm num-
ber.
Melody name Melody number
USING THE MIX MODE
Mixing a Melody Use the following procedure to play phrases in time with
the rhythm you selected to arrange the melody you want.
The melody stops automatically after eight measures.
1.When the phrase assignment screen is on the display,
press CC
CC
Cto display the Mix Mode standby screen.
•Pressing CC
CC
Cagain returns to the rhythm and tempo set-
ting screen.
•Holding down BB
BB
Bat this time displays the numbers of
the currently selected rhythm and tempo.
•Pressing EE
EE
Eat this time displays the MUTE indicator,
which means that output is muted. While MUTE is on
the display, you can arrange your melody without out-
putting any sound. Press EE
EE
Eagain to clear the MUTE
indicator and unmute the output.
Melody number
[Standby screen]

1856/1933/2065-4
2.Press DD
DD
D. This causes a four-beat count to sound and
then starts the mixer.
3.Insert phrases by pressing BB
BB
B, EE
EE
E, DD
DD
Dand CC
CC
Cin accor-
dance with the rhythm.
•During the above mixing procedure, the left side of the
upper display shows the instrument for the phrase that
is assigned to each button you press. The right side of
the upper display shows random animations of musi-
cians.
A 11-level evaluation screen appears after you finish inputting the phrase. The fol-
lowing table shows the display indicator for each evaluation point range.
•Press BB
BB
Bif you want to view the evaluation again.
Evaluating a Melody
After you mix an melody, you can evaluate it and decide whether or not you want to
keep it.
To accept a melody and assign it a name
1.While the OK message is on the display after you finish
arranging a melody under “Mixing a Melody”, press DD
DD
D
to accept the melody and display the name assignment
screen.
•This displays the name input screen, with a character
input cursor flashing at the far left. You can input up to
three characters for a melody name.
2.Use EE
EE
Eand BB
BB
Bto scroll forward and back through characters at the current cursor
position.
Press
Press A to Z0 to 9 (Space)
3.When the character you want is at the cursor position, press CC
CC
Cto move the cursor
to the right.
•Repeat steps 2 and 3 to input the other two characters.
4.After the melody name is the way you want it, press AA
AA
Ato store the melody and its
melody name in memory, and return to the normal Mix Mode screen.
•After you arrange a melody, you can play it back in the Mix Mode or Timekeeping
Mode, and you can use it for an alarm sound.
•Pressing AA
AA
Abefore OK appears on the display aborts the procedure without saving
anything.
•Pressing AA
AA
Awhile OK is on the display stores the melody with the name currently
assigned to the melody number.
•Not performing any operation for two or three minutes while OK message is on the
display stores the melody with the name currently assigned to the melody number.
•You can assign a name to a melody only immediately after arranging the melody.
You cannot change the melody name only without changing the melody itself.
To reject a melody
1.While the OK message is on the display after you finish arranging a melody under
“Mixing a Melody”, press EE
EE
Eto reject the melody. At this time, the message NG
appears on the display.
2.Press DD
DD
D. At this time, the message RETRY appears on the display.
3.Next, the rhythm and tempo selection screen appears, so you can try arranging the
melody again.
To delete the melody
•Holding down BB
BB
Bfor about two seconds while a melody number that already has a
melody assigned to it is on the display deletes the melody and restores the melody
number’s default pattern.
MeasureTempo value
43
214
3
2
1
9
87
659
87
65
Display Indicator
bar
graph
flashes
Point
Range
10
5 to 9
0 to 4
