Catchbox Catchbox Plus User manual

User Manual
Copyright 2018 Catchbox SIA
Plus

Catchbox Plus
Transmitter
Catchbox Wireless
Charger
Catchbox
Presenter Mic
Catchbox Plus
Receiver
Catchbox
Cover

1 Safety Instructions................................................................................................. 4
2 Quick Start............................................................................................................... 6
Setting Up the Catchbox........................................................................................... 6
Throwing the Catchbox ............................................................................................ 13
Speaking into the Catchbox.................................................................................... 14
3 Product Description ............................................................................................ 15
Overview...................................................................................................................... 15
DECT Wireless Standard Overview........................................................................ 16
4 General System Specifications........................................................................ 17
Transmitter Specifications ....................................................................................... 18
Receiver Specifications............................................................................................ 19
Wireless Charger Specifications ............................................................................ 20
Presenter Mic Specifications ...............................................................................21
Catchbox Cover Specifications .............................................................................. 22
5 Operations.............................................................................................................. 24
Opening the Catchbox Microphone....................................................................... 24
Locking the Transmitter to the Cover .................................................................... 25
Setting up the Receiver............................................................................................ 26
Setting up the Transmitter ....................................................................................... 30
Pairing the Transmitter and the Receiver ............................................................. 31
Charging the Transmitter with the USB cable ..................................................... 32
Charging the Transmitter with the Wireless Charger ......................................... 33
Setting up the Presenter Mic................................................................................34
Pairing the Presenter Mic and the Receiver.......................................................36
Charging the Presenter Mic..................................................................................37
How to wear the Presenter Mic............................................................................38
Setting the lanyard on the Presenter Mic...........................................................39
6 Troubleshooting.................................................................................................... 40
7 Maintenance, Storage, and Disposal ............................................................. 42
8 Certification........................................................................................................... 44
Contents

4
Catchbox Plus
NOTICE
• Before using the product, read and understand the user manual and inform others of proper usage.
• Follow all warnings and instructions on the product and in this manual.
• Keep this user manual and always include it when passing the equipment on to third parties.
WARNING
• Not heeding these warnings may lead to serious injury or property damage.
• Do not throw at peoples’ heads and always make sure everyone is aware of the situation before throwing.
• Do not use in situations with fragile objects, hot liquids, or people susceptible to injury, like the very young or old.
• Do not throw long passes (>5 m / 16 ft) or hard passes.
• Properly lock the into the Cover before use. Always use the Cover and the
• foam cap on the Transmitter, when using the product.
• Do not swing or throw the product from its handle. This may cause the Transmitter to detach from the Cover and
cause injury.
• Operating or storing this product at temperatures above 50 degrees Celsius or 122 degrees Fahrenheit will
cause the locking mechanism to fail permanently.
• The use of other antennas than those provided by the manufacturer is strictly prohibited.
• This product contains magnets which could affect the functioning of pacemakers and other electronic implants.
These could stop working or switch into test mode, causing illness. If you wear these devices keep sufficient
distance to magnets. Warn others who wear these devices from getting too close to magnets.
CAUTION
• Magnets produce a far-reaching, strong magnetic field. Keep magnets away from devices and objects that could be damaged by
strong magnetic fields, like laptops and other electrical equipment.
• Do not place the product near heat sources such as heating ducts or radiators and do not expose it to direct sunlight, excessive
dust, moisture, rain, mechanical vibrations or shock.
• Do not use near water. Use equipment indoors only. If the equipment comes into contact with a liquid, turn off the product, shut
down the sound system and disconnect the power cable from the power outlet immediately.
• Avoid excessive volume. Do not exceed 70dBa for airborne noise.
• Operate the equipment only with the included power supply.
• Clean the equipment with a moistened (not wet) cloth only. Be sure to disconnect the equipment from the power outlet before
cleaning the equipment. Unplug the apparatus during lightning storms or when not in use.
• Protect the power supply cord from being walked on or pinched.
• The equipment should be opened, serviced, and repaired by qualified service personnel only.
• Do not attempt to modify this product or its accessories and use only accessories and attachments, like antennas and power
supply, specified by the manufacturer.
• Changes or modifications to the equipment not expressly approved by manufacturer can void the warranty and user’s authority to
operate the equipment.
• Wireless Charger uses strong electromagnetic field to operate. Keep the the equipment away from metallic objects as those can heat
up and cause injury or property damage.
1 Safety Instructions

5
Catchbox Plus

6
Catchbox Plus
2 Quick Start
Setting up the Catchbox
To reduce setup time, each Catchbox Plus Receiver and Catchbox Plus
Transmitter unit have been paired before being shipped.
Use Case A
Catchbox with
an Audio System
Use Case B
Catchbox with a
Computer
Use Case C
Catchbox with an Audio
System and a Computer
Step 1
Identify your Use Case

7
Catchbox Plus
Depending on the input type of your Audio device, you may need to use
additional audio adapters (purchased separately). Please refer to the wiring
diagram of the Receiver’s balanced audio output (page 19)
Use Case A
Catchbox with an Audio System
1. Plug the included Power supply to AC mains outlet and connect it to the Receiver's micro-USB
socket.
2. Plug the included audio cable to the Receiver's balanced audio output and connect it to the input
of your Audio System (mixer board, amplifier or other audio device).
3. Turn on both the Transmitter and the Receiver.
POWER
AUDIO

8
Catchbox Plus
Use Case B
Catchbox with a Computer
1. Plug the included USB data cable to to the computer’s USB port and connect it to the Receiver’s
micro-USB socket.
2. Turn on both the Transmitter and the Receiver.
3. Go to your computer’s audio settings and enable the input signal from Catchbox. See detailed
instructions on Page 26.
POWER & AUDIO

9
Catchbox Plus
Use Case C
Catchbox with an Audio System and a Computer
1. Plug the included USB data cable to to the computer's USB port and connect it to the Receiver's
micro-USB socket.
2. Plug the included audio cable to the Receiver's balanced audio output and connect it to the input
of your Audio System.
3. Turn on both the Transmitter and the Receiver.
4. Go to your computer's audio settings and enable the input signal from Catchbox. See detailed
instructions on Page 26.
Depending on the input type of your Audio device, you may need to use
additional audio adapters (purchased separately). Please refer to the wiring
diagram of the Receiver’s balanced audio output on (page 19).
POWER
AUDIO

10
Catchbox Plus
Step 2
Remove the Transmitter from the Cover
by twisting it 90 degrees and pulling
upwards. This motion will misalign the
internal magnets and allow for easy
removal of the Transmitter unit.
Step 3
To turn on the Transmitter press and
hold the power button. LEDs on the front
panel will turn on.
Connect the Receiver to the power
souce. Turn On the Receiver using the
switch on the back panel of the device.
The LEDs in the front panel will turn on.

11
Catchbox Plus
Step 4
Adjust the volume using the volume buttons
on the Transmitter and on the Receiver.
Avoid excessive volume. Do not exceed 70 dBa for airborne noise.

12
Catchbox Plus
Step 5
Place the Transmitter into the Cover,
making sure to align the magnetic locking
mechanism so it is secure. Use the visual
marks for guidance.
Always properly lock the Transmitter unit, with the attached foam cap, into
the Cover before use. Improperly locking the Transmitter, or a failed locking
mechanism, will result in the Transmitter unit coming out during use, potentially
leading to serious injury and/or property damage.

13
Catchbox Plus
Throwing the Catchbox
To throw the Catchbox microphone, find someone in the audience who wants to ask a question or
make a comment. Make sure that the person and those around him or her are aware of the situation
and are prepared to catch.
Short, underhand passes of up to 5 m / 16 ft distance are recommended.
If someone farther away has a question, try to get the entire audience involved
by having members pass the Catchbox short distances to the person who
wants it. This is a great way to activate the crowd.
Improper throwing and use of the device can lead to serious injury and/or
property damage. Do not throw at peoples’ heads and always make sure
everyone is aware of the situation before throwing. Do not use in situations
with fragile objects, liquids, or people susceptible to injury. Do not kick, hit or
swing the Catchbox by its handle.

14
Catchbox Plus
Speaking into the Catchbox
To use the Catchbox, simply speak into the foam cap located on top of the Transmitter. An optimal
distance of 20 cm / 8 in will provide the clearest sound while not blocking the face of the person
speaking.
Avoid using the Catchbox near loudspeakers as this can cause audio
feedback.

15
Catchbox Plus
Overview
Catchbox Plus is a complete wireless microphone system designed for use in meeting rooms and event
spaces with audiences of up to 1000 people with the wireless range of up to 100 m / 330 ft (Line of
Sight). The product includes a Receiver and one or two Transmitters (capsules) with soft Catchbox
Covers. Wireless Charger and Presenter Mic are optionally available.
Transmitter capsule comes with a rechargeable Li-ion battery that can be recharged using the included
power with micro-USB connector supply or the Wireless Charger. Catchbox automatically turns off when
placed onto the Wireless Charger and turns back on when picked up eliminating the need for active
device management. The unique patented Automute technology turns off the audio signal when the
microphone is being thrown ensuring the system doesn’t make any unwanted noises when passed
around (US Patent: US9936319B2).
Catchbox Plus uses DECT digital wireless communications standard (DECT 6.0 in North America,
J-DECT in Japan). Two built-in antennas and Dynamic Channel Allocation (DCA) algorithm for frequency
selection makes sure Catchbox Plus won’t interfere with other wireless microphones or DECT-enabled
devices.
Key Features
• Licence-free wireless transmission
• Rechargeable battery
• DCA automatic frequency selection
• Automute technology
• Wireless charging
• Two microphone connectivity
• USB audio output
• Balanced analog audio output
3 Product Description

16
Catchbox Plus
DECT Wireless Standard Overview
DECT is an acronym for Digital Enhanced Cordless Telecommunications. DECT standard uses a
distributed Dynamic Channel Allocation (DCA) algorithm to automatically and dynamically (during
the use of the product) select the transmission frequency from the designated frequency band.
It helps to avoid potential interference with other DECT-enabled devices. However, other DECT-
enabled devices such as cordless phones or translation systems may cause interference if used
close Catchbox Plus system. The wireless range of Catchbox Plus product is 100 m / 330 ft
under ideal working conditions (Line of Sight). However, indoor obstacles like walls, furniture and
people may reduce the effective range.
DECT standard uses the following frequency bands:
1.880 to 1.900 GHz in Europe
1.920 to 1.930 GHz (DECT 6.0) in the United States and Canada
1.893 to 1.906 GHz (J-DECT) in Japan
Other regions in the world may use different spectrum allocations. Please check the actual
frequency band with your local authority.
Improving wireless signal strength
Users can improve the performance of the system through the following measures:
Ensure that there are no objects or walls between the Transmitter and the Receiver
Decrease the distance between the Transmitter and the Receiver
Don’t place the Transmitter and the Receiver in different rooms
Don’t place the Receiver in a closed area, like inside a cupboard (especially metallic).

17
Catchbox Plus
4 General System Specifications
• Catchbox Plus Transmitter (one or two)
• Catchbox Cover (one or two)
• Catchbox Plus Receiver with power supply
• Audio cable
• Micro-USB audio data cable
• Catchbox Wireless Charger with power supply (optional)
• Catchbox Presenter Mic with power supply (optional)
Catchbox Plus
Transmitter
Catchbox
Wireless Charger
Catchbox Plus
Receiver
Catchbox
Presenter Mic
Catchbox
Cover
Frequency band DECT / DECT 6.0 / J-DECT
(1.7-1.9 GHz depending on the region)
Operation range 100m / 330 ft
Operating temperature range 0-30 degrees Celsius
32-86 degrees Fahrenheit
Audio latency 14 ms
Included components:

18
Catchbox Plus
Transmitter Specifications
Specifications
Weight (without Cover) 170 g / 5.9 oz
Dimensions 180 x 180 x 180 mm / 7 x 7 x 7 in
Audio frequency response 50-12000 Hz
Battery type Lithium-ion, rechargeable
Battery life (full charge) 14 h
Charging time 6 h (Wireless Charger) or 3 h (USB cable)
Parts
1. Foam Cap
2. Power button
3. LEDs
4. Volume up button
5. Volume down button
6. Magnetic lock
7. Power jack (USB micro)
Front view Rear view
Frequency response
Note: Frequency
response is measured
with attached foam cap

19
Catchbox Plus
Receiver Specifications
Parts
1. Volume buttons
2. Volume LEDs
3. Status LEDs
4. Pairing button
5. Balanced audio output
6. Power switch
7. Power jack (USB micro)
Specifications
Weight 200g / 7oz
Dimensions (without antennas) 130 x 130 x 40 mm / 5.11 x 5.11 x 1.57 in
Power supply 5V 1A USB micro
Analog audio output TRS 6.3 mm / 1/4 in jack - balanced
Digital audio output USB micro, USB-Audio protocol, no codec
installation required
Front view
Rear view
Balanced Audio
Output Schematic
Both audio outputs operate simultaneously

20
Catchbox Plus
Wireless Charger Specifications
Specifications
Weight 770 g / 27.1 oz
Dimensions 190 x 190 x 28 mm / 7.4 x 7.4 x 1.1 in
Wireless charging protocol Proprietary
Parts
1. Indication LEDs
2. Power jack (USB micro)
Wireless Charger is optimized for charging only Catchbox products and will not
charge other electronic devices such as mobile phones. Don’t place electronic
devices with the Wireless Charger as doing so may damage the Wireless
Charger and/or device placed on it.
