Cateye GVolt70 User manual

Manual
K 1580
RECHARGEABLE HEADLIGHT
HL-EL551G RC
Under The Handlebar Mount Model
Click
ENG
Design Pat. Pending
Copyright© 2018 CATEYE Co., Ltd.
HLEL551GRC-181225 2
1
WARNING!!!
• Be sure to direct the light beam downward so the
driver approaching does not get dazzled.
• Before your trip, please make sure the light is firmly
mounted to the bracket and it lights up.
• Always attention to the remaining battery power by
checking the indicator periodically while using.
CAUTION!
• Do not place it within children’s reach.
• In preparation for unexpected battery shutoff, we
recommend you carry a spare light.
• This product is water-resistant under normal daily
use and can be used in the rain. However, do not
intentionally submerge it in water.
• If the light unit or parts become dirty with mud, etc.,
clean with a soft cloth which is moistened with mild
soap. Never apply paint thinner, benzine or alcohol;
damage will result.
LITHIUM-ION BATTERIES
Cautions on recharging
• Avoid charging in direct sunlight or in a vehicle
parked under direct sunlight, and make sure to
charge only when the ambient temperature is
between 41°F and 104 °F (5 and 40°C).
• Before charging, be sure that no dust or other foreign
objects attach to the USB plug.
• Do not subject the light to vibrations while charging.
• Once charging is complete, be sure to disconnect the
USB plug.
Cautions in use
• Charging, discharging, and storing in high tempera-
tures will cause the rechargeable battery to
deteriorate faster.
Do not place the light inside a vehicle or near a
heater.
• If the illumination time is significantly reduced even
after proper charging, the rechargeable battery may
be nearing the end of its service life. Dispose of the
battery as described in “Cautions for dispose”.
Cautions on storage
Cool and dry storage is recommended. For long period
storage, it is important to charge the battery 30
minutes every 6 months.
Cautions for dispose
When disposing of the light unit, remove the internal
rechargeable battery and dispose of it according to
local regulations.
Standard charging time
Approx. 2.5 h
(USB 2.0)
HOW TO CHARGE
2HOW TO MOUNT TO A BICYCLE
3SWITCH OPERATION
Always charge the product before use.
1. Connect the light unit to your PC or a commercial
USB battery charger using the USB cable.
(Fig 1 – ).
The switch indicator turns on and charging starts.
* When your PC is in sleep state, the unit cannot be
charged.
* We recommend using 500+mAh (USB 2.0)USB
battery charger.
* If the indicator flashes rapidly, there is a charging
error. Remove the cable and try again.
2. After charging is completed, remove the USB cable,
and install the charge jack cover.
* Charging and lighting times are approximate values,
and will vary by environmental and user conditions.
Light unit FlexTight™
bracket
(H-34N)
Before using the light, read this
manual thoroughly and keep it
for future reference.
5342730
USB cable
(MICRO USB)
5338827N
FlexTight™ bracket
(H-34N)
SPARE / OPTIONAL PARTS
USB cable
(MICRO USB)
2
1
To PC or
USB battery charger
USB cable
Charge
jack cover
Switch (Indicator)
On
Charging
Off
Charging is
completed
3
2
1
*1
4
Bracket DialStrap
5
Release button
Screw
Rubber pad
1 2
Can only be mounted under the handlebar.
Indicator (Light up)
ONOFF
*2
Switch (indicator)
LowHigh Middle
Approx. 2 h Approx. 3 h Approx. 15 h
Switch : Press and hold
SPECIFICATIONS
Light source High-intensity LED x 1
Battery type Li-ion 3.6v 3400 mAh
Charge Micro USB plug
Operating time High : Approx. 2 hours
Middle : Approx. 3 hours
Low : Approx. 15 hours
* Average runtime at 20˚C.
Standard charging time Approx. 2.5 hours
Temperature range Charging : 41˚F – 104˚F (5˚C – 40˚C)
Operating : 14˚F – 104˚F (-10˚C – 40˚C)
Recharge/discharge number of times
About 300 times
(until the rated capacity drops to 70%)
Dimensions/weight 1-13/32” x 4-3/16” x 1-53/64”
(
35.9 x 106.5 x 46.5 mm
)
/ 3.4 oz
(
96.5 g
)
*
The specifications and design are subject to change without notice.
1. Mount the bracket to the
handlebar. (Fig 2 – )
2. Insert the light unit into
the bracket until it clicks,
and adjust the beam angle.
()
3. To remove the light unit,
depress the release button
()on the top of the unit
and pull the unit forward.
*
To re-adjust the beam angle,
loosen the dial enough to
move the bracket, and firmly
tighten it after adjustment.
1
4
5
3
Remaining battery
capacity:
When the switch
(indicator)lights up,
the remaining battery
power is 20% or less.
Please charge as soon
as possible.
*2 : When turning the
light on, it lights up in
the mode that was
used last time. (Mode
memory function)
Before Initial Use
This unit is shipped with a small charge to check
the light. Be sure to charge it before use,
according to the instructions “HOW TO CHARGE”.
CAUTION!:
•
Be sure to tighten the dial by hand. When you tighten it too hard with a tool, the screw thread may be stripped.
• Check the dial and screw (*1) on the bracket periodically, and use them without any loosening.
• Round off the cut edge of the bracket strap to prevent injury.
Mounting height : 400 – 1200 mm

LIMITED WARRANTY
2-year Warranty: Light unit only (excludes battery deterioration)
CatEye products are warranted to be free of defects from materials and workmanship for a period of 2 years
from original purchase. If the product fails to work during normal use, CatEye will repair or replace the
defect at no charge. Service must be performed by CatEye or an authorized retailer. To return the product,
pack it carefully and enclose the warranty certificate (proof of purchase)with instruction for repair. Please
write or type your name and address clearly on the warranty certificate. Insurance, handling and transporta-
tion charges to CatEye shall be borne by person desiring service.
2-8-25, Kuwazu, Higashi Sumiyoshi-ku, Osaka 546-0041 Japan
Attn : CATEYE Customer Service Section
Phone: [phone]
Fax : [phone]
E-mail: [email protected]
URL : http://www.cateye.com
