CCL 206B Owner's manual

1
Operating / Programming Manual & Warranty Document
PBX Model: 206B
We extend a warm welcometo youon becoming a part of the Copper Connections family.
Our servicesupport Engineers shall be working hard through our channel partners to ensure your satisfaction
with the product and after sales services.
We welcomeyour feedback /query at [e-mail]
.Contents .
Introduction
Installation
Terminologies Used
Programmingthe PBX
Allowed Table
Auto Attendant Settings
Auto Call Back
Auto Call Disconnection
Barge-In
Call Forward
Call Pick-Up
CLI (Calling Line Identification)
CLI Transferable / Internal CLI
CLI –Digits addition
CLI RecievingMode (DTMF/ FSK)
CLI Transmitting Mode(DTMF)
Conferencewith 1 Junction & 1 Ext
Conferencewith 2 Junctions
Day / Night Mode
Denied Table –A
Denied Table –B
Do Not Disturb (DND)
Door Phone
Emergency Call
Extension to Extension call
Flash Time setting
Flexible Numbering
Hot Line to Junction
Hot Line to Extension
Junction Accessduring Power Failure
Junction AccessControl
Junction Dialing Controls
Junction Call Hold + Transfer
Junction Dialing Delay Time

2
Junction Line Ring Assignment
Junction Line - Enable / Disable
Junction Grouping
Junction to Junction Forwarding
Memory Dialing
Operator Extension Setting
Password
PBXVersion
Redial
Resetting the PBXprogramming
Ring Time Settings
Troubleshooting
Technical Specifications
Warranty claim details
NOTE-Copper Connections reserves the right to alter equipment specifications and description contained herein and
makes no commitment to updateor keep current the information herein. All information herein is subject to change
at any time without notice. No part of this publication shall be deemed to be part of any contract or commitment
whatsoever.
- Product specifications and features are subject to changes without prior notice due to our constant endeavor to improve
the product.
- All features mentioned in this manual are not part of standard systems. Some features need optional
hardware/software up-gradation.
- Not every feature in this manual is likely to have been installed in yoursystem or extension.
.Introduction .
All Junction lines of the PBX are Disabled in default. To enable them refer heading “Junction Line - Enable /
Disable“
Model
Junction Lines
Extensions
DoorPhones
DoorLocks
206B
Numbered as
1, 2
-Numbered as 601 to 606
-602 is the Operator.
-Programming can be donefrom
601, 602
1
1 Door Phone
consumes 1
Extension port.
NA
.Installation .
Cabling
- All cables of the EPABX should be at least 6” away from the electric al cables.
- They should be at least 12” away from the area of high frequencies like tube light
chokes, Electric Motors, etc. If it is not possibleto avoid, thenuse shielded cables
and earth the shield.
Earthing
Earth connected to the EPABX should not have more than 5 volts on it.
3 PIN AC Plug
GOOD EARTHING
BAD EARTHING
Voltmeter reading between N & E
must be more than 100mV and
less than 5V
If voltmeter reading between
N & E is more than 5V, do
not run the Copper
Connections System on it.
Location
-The PBX should be installed in a well ventilated area and at a place where there is no chance of liquid spilling overit or
moisture getting into it (Like in the Bathrooms etc).
-Direct sun light should not fall on the PBX.
-The PBX should be installed on the wall at a minimum of 2 ft height from thefloor.
Note:The Company’s warrantee voids if the above points are not followed.
Front Panel Indications
Following is the descriptions of the LED indicators of thefront panel of the PBX:
LED Name Description
POWER Blinking means PBX is working on Mains AC or Battery.
Connections
The PBX has the following connectors on its side panel:
V
E.
N. L
.

3
Connectors Description
LINE 1 Terminate the 1st Junction Line here through a RJ Connector.
LINE 2 Terminate the 2nd Junction Line here through a RJ Connector.
EXT 601 –EXT 606 Terminate the 1st –6th Extension wires over here through a RJ Connector.
AC 220V Connect the 3 pinmain lead here. Make sure that the EARTH wire connected to it is coming directly from the
point where EARTH is created.
Switch at the Bottom of the PBX
It is for switching the PBX ON / OFF.
Note:The PBX is supplied RJ Connectors with short leads for terminating the cables to RJ Sockets. It is recommended to
Crimp RJ connectors directly to the cables in order to maintain the aesthetics.
Precautions:
-The Mains AC socket from where the PBX is given220 V AC, should be separately made by taking direct connections
from the MCB Box and no other Electrical appliance should be connected on this point.
.Terminologies Used .
JUNCTION LINES - Telephone Lines provided by the Department of Telecom.
EXTENSION LINES - Extension Lines mean the EPABX extension lines.
.Programming the PBX .
To program most of thefeature mentioned in this manual, programming Password is to be entered from any extensions
(601, 602, 603, 604, 605, 606) through the following command:
#0000 (Here, 0000 is the default Password)
In case of any mistakewhile programming, keep the Handset downand pick up again.
Whenever a correct input is entered, PBX will give one single acceptance tone and when wrong input is given, it will give
three tones.
.Allowed Table .
Numbers to be allowed to extensions whose L = 0, are to be defined in this table. For value of L refer “Junction Dialing
Controls”.
This table has 16 Locations.
Procedure:Dial #0000 + 43 QQ ABCD#
Where QQ= 01 to 16 (16 Locations of the Table)
ABCD= The starting 4 digits of theTel numbers to be allowed to extension.
For less than 4 digits, dial #at the end of digits.
To clear this Table,Dial #0000 + 43 #
To clear a particular location of this table,Dial #0000 + 43 QQ #
.Auto Attendant Operations .
When the PBX is operated in this mode, the Junction caller gets a welcome message.
Three types of messages can be recorded for the following 3 conditions:
Welcome Message (10 Seconds)
Busy Message (5 Seconds)
No Answer Message (5 Seconds)
Auto Attendant Enable/ Disable:
To set Junction in Auto Attendant mode:
Dial #*0000 + 10J # where J= Junction Number 1,2
To set Junction in Direct Ring mode:
Dial #*0000 + 11J #
Message Recording/ Listening:
To Record Auto Attendant Message:
Dial #*0000 + 12 M #
Recording starts aftera confirmation beep. There will be a second beep for recording end.
Listen Auto Attendant Message:
Dial #*0000 + 13M #
Where- M = 1 for Welcome Message (10 Secs)
= 2 for Busy Message (5 Secs)
= 3 for No Answer Message (5 Secs)

4
Busy Message ON/OFF:
The facility of playing Busy message can be turned ON or OFF.
To turn ON Busy Message: Dial #*0000 + 124 #
To turn OFF Busy Message: Dial #*0000 + 134#
Ring Time Setting:
This is the time for which call will ring on dialed extension.
Dial #*0000 + 496 TT # where TT is time duration in seconds (01-99)
Extension Number Dial Timeout:
Afterthe welcome message is played, the user must dial an extension number within this time period.
If no extension number is dialed, then the message can either be repeated or call can be transferred to an extension.
Dial #*0000 + 160 TT # where TT is time duration in seconds (01-10)
Auto Attendant Mode Settings
1.Options when caller doesn’t dial any number / dials a wrong number:
a) Disconnect Junction Line: # * 0000 160 #
b) Transfer the call to Operator: # * 0000 161 #
If operator is busy, call will ring as per programmed junction landing in Simultaneous/ Round Robin.
c) Transfer the call as defined in Junction Landing: # * 0000 1616 #
Default: Call is transferred to Operator.
2.Options when called extension in busy or not answered:
a) Disconnect Junction Line: # * 0000 166 #
b) Transfer the call to Operator: # * 0000 1660 #
If operator is busy, call will ring as per programmed junction landing in Simultaneous/ Round Robin.
c) Transfer the call as defined in Junction Landing: # * 0000 1666 #
d) Play Welcome Message again: # * 0000 1665 #
Default: Call is transferred to Operator.
.Auto Call Back .
From Busy Junction Lines
To get a call back when any of the busy Junction lines get free, following is the procedure:
Dial 0
Get engaged tone
Dial #
Keep the handset down.
As soon as any one of thebusy Junction lines gets free, the Extension will ring. It will ring once and the user can pick
Handset within 10 secs to get connected to the Junction line.
From Busy Extensions
To get a call back when any of the busy Extension gets free, following is the procedure:
Dial Extension Number
Get engaged tone
Dial # and Keep the handset down.
As soon as the busy Extension gets free, the called and calling Extensions will ring simultaneously. User can pick
handset within 10 secs to get connected to each other.
.Auto Call Disconnection .
Selected extensions can be programmed to disconnect Out going Junction call after talking for aset time.
Procedure:Dial #0000 + 6 N TT #
Where, N= Last digit of the Extension Number.
TT= 01 to 99. Time in minutes afterwhich the Junction call is to be disconnected.
Note:In default there is no restriction.
:This auto call disconnection is not applicable on incoming Junction calls.
To cancel this feature:Dial 6 N 00 #
.Barge-In .
Extension number 601 and 602 has the facility to barge into any Extension orJunction Line and over hear ortalk in
conference.
To listen to a Junction line, dial # 7 J (J= Junction Number 1, 2)
To listen to an Extension, dial # 77 NN (NN= Ext Number)

5
.Call Forward .
There are two types of Call Forwarding:
Call Forward Always
Dial # 26 N XXXX
Where, XXXX= Extension number where Calls are to be forwarded. Flexible number (2-4 digits long)
N= the last digit of the original Extension.
Dial # 26 N # (To clear the feature of N Extension)
Dial # 26 # (To clear the Call Forward Always feature of all the extensions. T)
Call Forward When Busy / No Answer (This can also be used as Round Robin feature - Refer “Junction Line Ring
Assignment”)
If calls are to be diverted only when the Extension is busy oris not answering, then:
Dial # 27 N XXXXWhere, XXXX= Extensionnumber where Calls are to be forwarded. If flexible numbering is
done then enter the Flexible number. If the Flexible number is say 26 then
XXXX will be = 26 & not 026.
N= The last digit of the Original Extension number (Not the flexible number)
Dial # 27 N # (To clear call forward of NNExtension)
:To cancel Call Forwarding Busy / No Answer of all the extensions:
Dial # 27 # from any of theprogramming Extensions.
:To cancel all type of Call Forwarding of all the extensions:
Dial # 25 # from any of theprogramming Extensions.
:To retain the Call Forwarding programming afterthe PBX is switched ON/OFF,
Dial #0000 + 171 # (This is the default setting in the PBX)
:To lose the Call Forwarding programming afterthe PBX is switched ON/OFF,
Dial #0000 + 170 #
Ring Time change in Call Forward When Busy / No Answer
The ring time on extension, in case of Call Forward, can be changed using the following program:
Dial #0000 + 184 TT #
Where, TT= 01 –99 Ring Time in seconds
Default value = 20 secs
Note: The time entered here, should be less than the Internal Call Ringing Time.
.Call Pick-Up .
PBX has various codes for call pick up as detailed below:
Dial 5 or Dial # 9 - To pick up an incoming Junction call ringing on another extension,.
It will pick the calls in following priority
Junction Call being Transferred
Incoming Junction Call ringing
Junction Call on Hold
DoorPhone Call
Internal Call
Note- Call Pick up by 5 will work only when there is no flexible numbering is starting by 5. If any flexible numbering is done
which is started with 5 then call Pick up by 5 gets automatically cancelled.
.CLI (Calling Line Identification) .
The incoming Junction call telephone number is displayed on the LCD of the CLI phone on which the defined Junction call
rings. This feature will work with Telephones having CLI feature.
.CLI Transferable/ Internal CLI .
When a Junction call is transferred from an extension to another extension, the external telephone number is displayed on
the LCD of the CLI phone. When an extension calls another extension, Extension number is displayed on the LCD of the
CLI phone.
.CLI –Digits addition .
Some CLI Telephones cannot display less than 4 digit numbers. In that case if thePBX extension numbers are less than 4
digits then additional dummy Zeros need to be added by the PBX.
Procedure:
To Enable, Dial #0000 + 180 1 #
To Disable, Dial #0000 + 180 0 #
Note- If CLI digit addition is enable then if extension is of 2 digits then 2 dummy zeros are added before extension number
and if the extension number is of 3 digits then a zero is added before the extension number.
Default: Disabled

6
.CLI Receiving Mode (DTMF / FSK ) .
The system senses CLI on Junction lines in DTMF mode or FSK mode.
Procedure:
Dial #*0000 + 181 J 0 # for FSK mode
Dial #*0000 + 181 J 1 # forDTMF mode where J= Junction Number 1, 2
Default: DTMF mode
.CLI Transmitting Mode (FSK)
.
The PBX generates CLI on Extensions in DTMF mode in default.
.Conference with 1 Junction & 1 Ext .
An extension user can establish a conference with an extension and a Junction line.
Process:During conversation with a Junction line, Hook-Flash to hold the line.
Then dial Ext No.
.Conference with 2 Junctions .
An extension user can establish a conference with 2 Junction Lines.
Process:
During conversation with a Junction line - Hook-Flash - ## (To parktheCall) –0 –Tel. No (who is to be included in
conferencing) –Hook Flash - # * - Now all 3 party can talk to each other.
When Ext keeps the Handset down, the conference ends.
.Day / Night Mode .
The PBX can be configured in2 sets of programming. One for the day mode and one f orthe night mode.
To change the system to Day Mode, Dial # 20
To change the system to Night Mode, Dial # 21
Default:Day Mode.
.Denied Table –A .
Numbers to be disallowed to extensions whose L = 4, are to be defined inthis table. For value of L refer “Junction Dialing
Controls”.
This table has 16 Locations.
Procedure:Dial #0000 + 41 QQ ABCD#
Where QQ= 01 to 16 (16 Locations of the Table)
ABCD= The starting 4 digits of theTel numbers to be denied to extension.
For less than 4 digits, dial #at the end of digits.
To clear this Table:Dial #0000 + 41 #
To clear a particular location of this table: Dial #0000 + 41 QQ #
.Denied Table –B .
Numbers to be disallowed to extensions whose L = 5, are to be defined in this table. For value of L refer “Junction Dialing
Controls”.
This table has 16 Locations.
Procedure:Dial #0000 + 42 QQ ABCD#
Where QQ= 01 to 16 (16 Locations of the Table)
ABCD= The starting 4 digits of theTel numbers to be denied to extension.
For less than 4 digits, dial #at the end of digits.
To clear this Table:Dial #0000 + 42 #
To clear a particular location of this table:Dial #0000 + 42 QQ #
.Do Not Disturb (DND) .
In DND mode, no one can call the DND extension
PROCEDURE: Dial # 83
To cancel DND, simply lift Handset.
Default: Normal Mode
.Door Phone .
One Door Phone can be connected to the PBX.
Open the back coverof the Door Phone and connect 2 wires on the Terminal block.
These 2 wires are to be connected to any of theExtension port (from 601 to 606) of the PBX.
To define the Extension as the first Door Phone extension, program as below:
Dial #0000 + 80 N#
Where, N = 1 - 6 (Representing the Extension numbers from 601 to 606)

7
To make the first Door Phoneextension as a normal Extension, program as below:
Dial #0000 + 800 #
Door Phone ring assignment
Dial #0000 + 82 N # - To assign extensions to ring when Door Phone calls.
Where, N= 1 –6 (Representing the Extension numbers from 601 to 606)
Repeat the program for up to 3 Extensions maximum except door phone.
Dial #0000 + 82 # - To clear all programmed extensions for Door Phone calls.
.
.Emergency Call .
When any extension dials # 88, all extensions start ringing. All extensions get connected to the extension who had dialed
the Emergency code. All can talk in conference.
.Extension to Extension call .
Extension numbers in default are from 601 to 606 and can be changed to 2 digits, 3digits or 4 digits numbering as
explained under the heading “Flexible Numbering”.
.Flash Time setting .
The Flash time of the PBX can be changed as described below:
Dial #0000 + Dial 00 L #
Here, L= 1 (for 0.8 secs)
2 (for 1.0 secs)
3 (for 1.2 secs)
4 (for 1.5 secs)
5 (for 1.8 secs)
Default: 0.4 Secs
.Flexible Numbering .
Extension numbers can be changed to a desired number of 1 digit, 2digit, 3digit or 4 digits from 11 –6999.
The numbering can either be 1 digit, 2digit, 3 digits or 4 digits in any combination.
The flexible number cannot begin with digits 0, 7, 8 and 9.
Procedure:
Dial #0000 + 9000 + # (This also resets all the flexible numbering of the PBX)
Dial #0000 + 9 N ABCD #
Where, N = Last digit of the original extension number (This original number always remains the one
that is printed on the MDF even if flexible numbering is done).
ABCD = The new Extension number. For less than 4 digits, dial # at the end Of Extension Number.
If all the new numbers to be made in sequence then following programming canbe donewith single program. This avoids
lengthy programming:
Dial #0000 + 9000 L K #
Where, L = Length of new numbers –3 digits or 4 digits
K = First digit of thenew numbering. If K=2 then the numbering will become 201 (or 2001)
Onwards. Then all those Numbers can be changed through the following programming.
Default: 601,602, to 606
.Hot Line to Junction .
Some or all extensions can be programmed to get Junction Line on lifting the Handset.
To dial internal numbers, dial on lifting the Handset. You will get internal dial tone of the PBX.
To program an extension to get a free Junction line on lifting handset,
Dial #0000 + 20 N#
Where, N= last digit of Extension numbers that is to be programmed for Direct Junction Access.
Dial #0000 + 20 # - To convert all Extensions in “Hot Line to Junction” mode
Dial #0000 + 21 N # - To convert NN Extension in normal mode.
Dial #0000 + 21 # - To convert all Extensions in normal mode.
Note:When all Extensions are converted to Hot Line then to get into the Programming mode, lift Handset –dial # 0000
+ Whatever Programming to be done.
Default: Normal Mode
.Hot Line to Extension .
Some or all extensions can be programmed to get connected to an Extension, on lifting the Handset.
To dial internal numbers, dial on lifting the Handset. You will get internal dial tone of the PBX.
To program an extension in this mode,
Dial #0000 + 883 N XXXX#
Where, N= last digit of Original Extension numbers that is to be programmed for this feature.

8
XXXX = Extension number to which call will land in Hotline feature..
Dial #0000 + 884 N # - To convert N Extension in normal mode.
Note:When all Extensions are converted to Hot Line then to get into the Programming mode, lift Handset –dial # 0000
+ whatever Programming to be done.
Default: All extension is in Normal Mode.
.Junction Access During PowerFailure .
When the system is switched OFF, the Junction lines get directly connected to following respective extensions.
Junction Number Extension Number to which it gets connected
01 601
02 602
.Junction Access Codes / Change .
Junction lines can be accessed in rotation by dialling 0.
To access a particular junction line:
#11 - To access 1st Junction Line
#12 - To access 2nd Junction Line
The junction access code can be changed from 0 to 8. Refer heading ‘Junction Grouping’ f or procedure.
.Junction Access Control .
Every Extension can be programmed to access Junction Line.
The access to each Extension can be different inDay mode and Night mode.
Procedure:
Dial # 0000 + 70 J N X # (For Day Mode)
Dial # 0000 + 71 J N X # (For Night Mode)
Where J = Junction Number (1, 2)
N = Last Digit of Extension Number
X = 0 to Allow Junction access
1 to Disallow Junction access.
Dial #0000 + 70 J X # (To allow/disallowall extensions to access Junction in Day Mode)
Dial #0000 + 71 J X # (To allow/disallowall extensions to access Junction in Night Mode)
Default: All extensions are allowed to access Junction Line in both Day and Night mode.
.Junction Dialing Controls .
Junction dialing facility can be controlled Extension wise as below:
Dial #0000 + 40 N L #
where, N= Last digit of Extension number.
L = 0 - The Extension can dial only the numbers starting with digits defined in “Allowed Table”
1 - The Extension can dial all numbers.
2 - The Extension can dial all numbers except forISD numbers.
3 - The Extension can dial all numbers except for STD numbers.
4 - The Extension can dial all numbers except f or the numbers starting with digits defined in “Denied
Table-A”
5 - The Extension can dial all numbers except for the numbers starting with digits defined in “Denied
Table-B”
6 - The Extension cannot dial out but can make internal calls.
To give all extensions the same L value:Dial #0000 + 40 L #
Note:In default: all extensions are in L = 1 mode.
.Junction Call Hold + Transfer .
To transfer a Junction line to another extension, FLASH and dial the Extension number while talking on the junction line.
Now there can be following 4 conditions:
1. When called extension lifts, calling extension can converse and then keep the Handset down. The Junction call will
then get transferred.
2. Called extension lif ts but doesn’t want to talk then he may keep the Handset down.
The call will come back to the transferring extension.
3. The called extension is ringing but not lifting theHandset. Keep the Handset down.
The call will ring on the called extension for25 secs and if not answered it will ring back on the transferring extension.
Now if the Transferring extension is busy, the Junction call will keep waiting for the Transferring extension to get free.
4. If the called Extension is engaged, the user will hear 2 tones. Now FLASH to get back to the Junction line. If FLASH is
not done within 10 secs, the Junction line will get connected. This is the default setting in the PBX.

9
Alternately the user can change to the following mode:
On dialing an engaged extension user would get engaged tone. During the engaged tone user can FLASH and get
connected to the Junction line.
Programming:Dial #0000 + 831 #
To shift back to thedefault setting, Dial #0000 + 830 #
.Junction Dialing Delay Time .
This is the time after the last digit dialed by anextension on Junction Line.
It is 7 secs in default.
The PBX assumes call maturity from afterthe lapse of this time.
The FLASH function to hold an Incoming Junction call starts working after the lapse of this time.
To change this delay time, Dial #0000 + 03 TT # Where, TT= 01 to 99 secs. Default value = 07 (7 secs)
.Junction Line Ring Assignment .
Junction lines incoming ring can be set in the Direct ring modes:
Direct Ring Mode (Calls land on Operator or defined extensions in Simultaneous Ring mode or Round Robin
Ring mode)
Direct RingMode (Simultaneous / Round Robin)
Simultaneous Ring
In this mode, incoming Junction lines ring on one or more Extensions.
Incoming ring of Junction Lines can be programmed separately forDay and Night modes as described below:
Dial #0000 + 3 J M 0 + N1+ N2…..+N6#
Where J = Junction Number (1, 2)
M = 0 for Day mode/ 1 for Night Mode
N1….N6= Here N is the last digit of Original extension number (Not the Flexible Number)
Round RobinRing
In this mode,the incoming Junctioncall landsonone extension.If that extensionis busy or doesn’t respond within few rings then the call
shiftsto anotherextension.
Programming:
Dial #0000 + 3 J M 1 + N1+ N2…..+N6#
Where J = Junction Number (1, 2)
M = 0 forDay mode/ 1for Night Mode
N1….N6= Here N is the last digit of Original extension number (Not the Flexible Number)
When all assigned extensions are busy
When the extensions assigned for the Junction incoming call are busy, The assigned extension when busy, will hear a
waiting call beep after every 5 seconds. On flashing ext will get connected to incoming junction call.
Default: All the Junction Lines land on Extension number 601 and 602 in Simultaneous Mode.
.Junction Line - Enable / Disable .
To Enable Junction Line, Dial #0000 + 060 J #
To Disable Junction Line, Dial #0000 + 061 J# Where J = Junction Number (1, 2)
Note: In default Junction Line is enabled.
.Junction Grouping .
Two set of Junction groups canbe made. One group can be accessed say by dialing 0 and the other group of Junction
lines by dialing 8.
To allot group 0 to a Junction= Dial #*0000 + 50 J 0 #
To allot group 8 to a Junction= Dial #*0000 + 50 J 8 #
Where, J = Junction Number (1-2)
.Junction to Junction Forwarding .
There are 2 types of Junction to Junction Transfer:
1. Incoming Junction Call on Ext to be transferred to another Tel Number/Cell number.
2. Making 2 Junction lines talk to each other while Ext remains out of theconversation.
Incoming Junction Call on Ext to be transferred to another Tel Number/Cell number
Any of the Extension can feed in a Telephone Number or Cell number on its extension whereby the incoming calls on its
extension would get diverted to those numbers.
While talking a tone will be heard after2 minutes and if is pressed then the call would get extended for another 2
minutes. Like this user can keep extending the talk time. If is not pressed then the calls will disconnect. If user wishes to
disconnect in between then # need to be pressed.

10
Programming:
Dial from your own Extension #84* Tel No (where calls are to be diverted to) #
Increasing or decreasing the Talk time in such forwarded calls:
#84TT
Where, TT= 01 to 99.
In default TT = 09 x 10 = 90 Secs (80 secs talk time and 10 secs Alert Time)
To cancel the feature, dial from yourown Extension #84#
Making 2 Junction lines talk to each other while Ext remains out of the conversation.
Process:During conversation with a Junction line - Hook-Flash - #6 (To park theCall) –0 –Tel No (who is to
be connected to the previous Junction call) –Hook Flash - # - Now all 3 party can talk to each other.
but Ext can keep Handset down. The 2 Junction lines will hear a tone after2 minutes and if any of them
presses * then they can talk foranother 2 minutes. Like this they can keep extending the talk time. If * is
not pressed then the calls will disconnect. If they wish to disconnect in between then any of them need to
dial #.
.Memory Dialing .
The PBX has memory for 48 telephone number that can be dialed from an extension by dialing 2 digits codes. However, if
the ext is given only local dialing facility, thenit cannot dial STD number of thememory.
Memory Dialing Enable/Disable:
To Enable : Dial #*0000 + 37 0#
To Disable : Dial #*0000 + 37 1#
Default: Disabled
Note- If memory dialing is disabled then it will check the Junction dialing control for extension.
Storing Telephone number in memory:
Dial #*0000 35 CC J NN#
Where CC= Memory location (01-48)
J= Junction Number (1-2) orJunction Group ‘0’ or Junction Group ‘8’
NN= Telephone number (maximum 16 digits)
Note: In case mobile numbers are not dialing properly each time, add 0 or 00 before the number while adding.
Deleting memory codes:
To delete a particular dialing code: Dial #*0000+ 35 CC#
To delete all memory dialing code: Dial #*0000+ 36#
To dial a number from memory: Dial 7CC
.Operator Extension Setting .
In default, Extension number 606 is defined as Operator and this extension can be changed if desired by the user.
To change the Operator Extension:
Dial #0000 + 15 N # (N = Last digit of Extnwhich is to be made the Operator)
Default: Operator Extension is 606
To call operator, Dial 9
.Password .
There is only one Password for the whole PBX programming and this Password can be changed by the user. The default
Password is 0000.
To change the Password: #0000 + 09 XXXX# Here, 0000 = Default password
XXXX = New Password
To reset default Password: # * # * # * #
.PBX Version
To check the PBX Version Dial #64 from CLI Phone, PBX will give a beep tone after that put the handset down.
When Phone is ON Hook PBX version is displayed aftera ring.
.Redial
To redial Telephone number on Junction Line, Dial 0 + Telephone Number
Get Engaged Tone
Press ** on the SLT Telephone set.
Alternately, press ‘Redial’ key on Telephone Set after getting engaged tone.
.Resetting the PBX programming .

11
To reset all the program of thePBX except Flexible numbering & Junction Enable/Disableto default values,
Dial #0000 + 0000 + #
To erase only flexible numbering of the PBX, Dial #0000 + 9000 + #
.Ring TimeSettings .
Two type of ringing time can be configured as explained below:
Junction Ring to be sensed as disconnected
The PBX senses the Junction line as disconnected after7 secs of the last ring voltage. This time can be reduced or
increased by using the following program:
Dial #0000 + 182 TT #
Where, TT= 50 in default for 5 secs delay. Reducing this time could give problem in CLI.
Internal Call Ringing Time
This is the time for which an extension keeps ringing when an Extension call another Extension.
Program:Dial #0000 + 494 TT #
Where, TT= 01-99 secs (Default Value = 99 secs)
.Troubleshooting .
Problem Solution
There is no ring on any extension Press RESET Switch (next to the relay) on the SMPS card of the PBX, twice.
The Power LED on the front panel Re-insert the connectors of the lead that connects
Is ON but there is no dial toneon the SMPS card to the main card of the PBX.
any extension. Re-insert the connectors at both ends of the lead.
.Technical Specifications .
Switching
Space Division Multiplexing
Power Supply
Transformer type
Input
AC 80V to 260V
Wattage at 220V
10 W
Extension Loop Resistance
Less than 600 Ohms
Ambient Temperature
+5C to +45C
Ambient Humidity
95% Maximum
Telephone Sets
Pulse or DTMF dialing Phones
Cabling
2 Core from every Telephone set to the PBX
.Warranty claim details .
This manual is also your Warranty document and should be preserved along with Invoice copy for claiming
warranty.
ModelNumberasper the Invoice: . . . . . . . . . . . . .. . . . . . . . . ProductS.No.: . .. . . . . . . . . . . .. . . . . .. . . . . . . . .. . . . . . . . . . . . . . . .
Date of purchase:. . . . . . . . . . .. . . . . . . . . . . . . . . PurchaserName:. . . . . . . . . . . . .. . . . . . . . . . . .. . . . . . . . . . . . . . . . . ..
Purchaser’s ContactNo: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Purchaser’s Address: . . . . . . . . . . . . . .. . . . . . . . . . . .. . . . . . . . . . . .. ..
. . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . .. . . . . . . . .. . . . . .. . . . . . . . . . . . . . . . . . . . . . . .. . . . . . . . . . . . . .
CopperConnectionsPvt. Ltd. warrants that this productis manufacturedunderstringentqualitystandards,makingitfreef rom defectsin
material andworkmanship,asper the followingtermsand conditions:
1. The limitedwarrantyforthe system is validfor a periodof twelvemonthsfrom thedate of purchaseor fifteenmonthsfrom the date
of manufacture whicheverisearlier.
2. The limited warranty extends only to the original consumer/ purchaser of the product and is not assignable or transferable to any
subsequentpurchaser/enduser.
3. Duringthe limited warrantyperiod,CopperConnectionsPvt.Ltd. or its authorised service networkwill repairor replace, at Copper
Connections Pvt. Ltd. option, any defective productorparts thereof with a newor factoryrebuildreplacementitemsand return the
product to the consumer in working conditions. No charge will be made to the consumer for either parts or labour in repairing or
replacing theproduct. All replaced parts shall become the propertyof CopperConnectionsPvt. Ltd..
4. Repaired productwillbe warranted fora balanceof original warrantyperiod.
5. Upon request from Copper Connections Pvt. Ltd. or its authorised service center, the consumer must provide purchase receipt or
other informationtoprovethe date andplaceof purchase.
6. The consumershallhavenobenefitor coverageif anyof the followingconditionsareapplicable:
a) The producthas been subjectedto abnormaluse,abnormalcondition,improperstorage,exposuretomoisture or dampness,
exposure to excessive temperature or fire etc., unauthorised modifications, unauthorised connections, unauthorised repairs
including but not limited to use of unauthorised spare parts in repairs, misuse, neglect, abuse, accident, alteration, improper
installation.
b) CopperConnectionsPvt. Ltd. was not notified byconsumerof the alleged defectormalfunction of the productduring the limited
warrantyperiod.
c) The productwas used with or connectedto equipmentnotfitfor usewith CopperConnectionsPvt. Ltd. system or usedin other
than its intended use.

12
d) THE SYSTEM IS NOTCONNECTED TO A PROPER EARTH OR INCASE HIGH VOLTAGES APPEAR ON EARTH.
e) THE DAMAGE IS CAUSED BY LIGHTENING ON EXTENSIONS/ JUNCTION LINES/ OR SPIKES/ SURGES/ HIGH
VOLTAGES FROM AC MAIN SUPPLY.
7. The consumermaycontactthe authorised dealerto callthe servicepersonnel forcarryingout repairsor maintenanceandthesame
wouldbeattendedwithina reasonableresponsetimeassignedtothe dealer.
8. The consumerwill be billedforparts or labourchargesnotcoveredby this limitedwarranty.
9. If the productis broughtto Copper ConnectionsPvt. Ltd. forrepairs, afterthe warrantyperiod CopperConnectionsPvt. Ltd. normal
servicepolicyshall applyand customershallbe chargedaccordingly.
10. In no event shall Copper Connections Pvt. Ltd. or their authorised dealer be liable for special or consequential damages or any
delay in the performance of this warranty due to causes beyond their control. Copper Connections Pvt. Ltd. shall not be liable for
incidental orconsequential damageora loss of anticipated benefits orprofits,loss or impairmentof privacy of conversation, work
stoppageor lossor impairmentof dataarisingout of the use or inabilityto usethe product.
11. CopperConnectionsPvt.Ltd. neitherassumesnorauthorisesany authorisedservicecenteror any person or entity to assumefor it
any otherobligationorliabilitybeyondwhatis expresslyprovided bythis limitedwarranty.All warrantyinformation,productfeatures
andspecificationsaresubjectto changewithoutprior notice.
12. Any disputearisingout of this warranty shall be subjected to jurisdictionof the arbitratorwithin the city of Delhi.
13. The decision of Copper Connections Pvt. Ltd., on defects, damages etc shall be final and binding on the parties and no dispute
regardingthis,couldbe agitatedbeforeanycivil court.
14. If the product is purchased online through Amazon or other web portals, then in case of repair, the system is to be sent to the
mentioned companyaddressinDelhi.One-waydeliverycharge will be borneby company,andone-waywillhaveto be borneby the
user. Part no: 206B - 13
_______________________________________
ISO 9001:2015 Certified company
CopperConnectionsLimited
B-221, Okhla Industrial Area, Ph-1, NewDelhi-110020. Ph: [phone]
www.copperconnections.com
