CDA DV 710 Guide

Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY
T: 01949 862 012 F: 01949 862 003 E: [email protected] W: www.cda.eu
DV 710 .. - Built Under Double Oven
Manual for Installation, Use and Maintenance

2
Important
This appliance is designed and manufactured solely for the cooking of domestic (household) food and
is not suitable for any non domestic application and therefore should not be used in a commercial
environment.
The appliance guarantee will be void if the appliance is used within a non domestic environment i.e. a semi
commercial, commercial or communal environment.
The CDA Group Ltd cannot be held responsible for injuries or losses caused by incorrect use or installation
of this product. Please note that CDA reserve the right to invalidate the guarantee supplied with this
product following incorrect installation or misuse of the appliance.
Appliance Information:
Please enter the details on the appliance rating plate below for reference, to assist CDA Customer Care in
the event of a fault with your appliance and to register your appliance for guarantee purposes.
Appliance Model
Serial Number
Important Information for Correct Disposal of the Product in Accordance with
EC Directive 2002/96/EC.
At the end of its working life, the product must not be disposed of as urban
waste. It must be taken to a special local authority differentiated waste
collection centre or to a dealer providing this service.
Disposing of a household appliance separately avoids possible negative
consequences for the environment and health deriving from inappropriate
disposal and enables the constituent materials to be recovered to obtain
significant savings in energy and resources. As a reminder of the need to
dispose of household appliances separately, the product is marked with a
crossed-out wheeled dustbin.
Declaration of CE Conformity
This double oven has been designed, constructed and marketed in compliance with:
- Safety requirements of EU Directive “Low Voltage” 2006/95/EC;
- Protection requirements of EU Directive “EMC” 2004/108/EC;
- Requirements of EU Directive 93/68/EEC.

3
Before Using for the First Time
– Read the instructions carefully before installing and using the appliance.
– After unpacking the appliance, check that it is not damaged. In case of doubt, do not use the appliance
and contact your supplier or a qualified engineer.
– Remove all the packing materials (i.e. plastic bags, polystyrene foam, etc.) and do not leave it around within
easy reach of children, as these may cause serious injuries. The packaging materials are recyclable.
– Do not attempt to modify the technical characteristics of the appliance, as it may become dangerous
to use.
– The appliance should be installed and all the electrical connections made by a qualified engineer in
compliance with local regulations in force and following the manufacturer's instructions.
Important Precautions and Recommendations
for Use of Electrical Appliances
Use of any electrical appliance implies the necessity to follow a series of fundamental rules. In particular:
– never touch the appliance with wet hands or feet;
– do not operate the appliance barefooted;
– do not allow children or disabled people to use the appliance without your supervision.
The manufacturer cannot be held responsible for any damages caused by improper, incorrect or
unreasonable use of the appliance.
Using the Double Oven for the First Time
You are advised to carry out the following operations:
– Assemble the interior of the top and the lower ovens as described under the heading “Cleaning and
maintenance”
– Switch the empty ovens ON at maximum temperature for about two hours to eliminate traces of grease
and smell from the components.
– Let the ovens cool down, switch off the electrical supply, then clean the inside of the ovens with a cloth
soaked in water and neutral detergent and dry thoroughly.

4
Important Safeguards and Recommendations
– Do not carry out any cleaning or maintenance without first disconnecting the appliance from the
electrical supply.
– During and after use of the double oven, certain parts will become very hot. Do not touch hot parts.
– After use always ensure that the control knobs are in the OFF position ( - ).
– Household appliances are not intended to be played with by children.
– Keep children away from the oven during use.
– Children, or persons with a disability which limits their ability to use the appliance, should have a
responsible person to instruct them in its use. The instructor should be satisfied that they can use the
appliance without danger to themselves or their surroundings.
– WARNING
When correctly installed, your product meets all safety requirements laid down for this type of product
category. However special care should be taken around the rear or the underneath of the appliance
as these areas are not designed or intended to be touched and may contain sharp or rough edges, that
may cause injury.
– Fire Risk! Do not store inflammable materials inside the ovens.
– Always use oven gloves when removing the shelves and food trays from the oven whilst hot.
– Clean the ovens regularly and do not allow fat or oils to build up in the oven base or trays. Remove
spillages as soon as they occur.
– Do not line the oven walls with aluminium foil. Do not place baking trays or the drip tray on the base
of the oven chambers.
– Always stand back from the double oven when opening the oven doors to allow steam and hot air to
escape before removing the food.
– Do not hang towels, dishcloths or other items on the double oven or its handles – as this could be a
fire hazard.
– Make sure that electrical cords connecting other appliances in the proximity cannot become entrapped
in the oven doors.
– Before disposing of an unwanted appliance, it is recommended that it is made inoperative and that all
potentially hazardous parts are made harmless.
– Important: This appliance has been designed for domestic use only. The appliance is NOT suitable for
use within a semi-commercial, commercial or communal environment.
– Safe food handling: leave food in the oven for as short a time as possible before and after cooking.
This is to avoid contamination by organisms which may cause food poisoning. Take particular care
during warmer weather.
– Do not operate your appliance by means of an external timer or separate remote-control system.

5
Control Panel
Controls Description
1. Oven temperature knob (Top oven)
2. Function selector knob (Top oven)
3. Function selector knob (Lower main oven)
4. Oven temperature knob (Lower main oven)
5. Clock and timer with “Touch-Control” keys (Lower main oven only)
Warning Lights:
6. Lower main oven temperature indicator light
7. Top oven temperature indicator light
Please Note: Your appliance has been fitted with a cooling fan to achieve optimum efficiency of the
controls and to ensure lower surface temperatures are maintained.
When the top oven is operating the cooling fan motor is always ON.
When only the bottom main oven is operating the cooling fan motor switches ON/OFF depending on
temperature.
Depending on cooking temperatures and times, the cooling fan may run on even after appliance oven
has been switched off. The duration of this time is dependent on previous cooking temperature and
duration.
1254
3
76
Fig. 1

6
Top Natural Convection Oven
General Features
This oven features 2 different thermostatic control functions to satisfy all
cooking requirements, provided by 3 heating elements:
– Upper element, 700 W
– Lower element, 1000 W
– Grill element, 2000 W
Note:
When using for the first time, you are advised to operate the oven at maximum
temperature (thermostat knob on the maximum position) for approximately
one hour in the mode and for another 15 minutes in the mode in
order to eliminate any traces of grease from the electrical elements.
Operating Principles
Heating and cooking in the natural convection oven are obtained:
a. by Normal Convection
The heat is produced by the upper and lower heating elements.
b. by Radiation
The heat is radiated by the infra red grill element.
Fig. 2 Fig. 3
How to Use the Top Oven
WARNING:
The door is hot, use the handle.
ATTENTION -
MOST IMPORTANT
Pay special attention not
to touch the hot heating
element inside the oven
cavity.

7
Thermostat Knob (Fig. 2)
This only sets the cooking temperature and does not switch the oven on.
Rotate clockwise until the required temperature is reached (from 50 °C to 250 °C).
The thermostat indicator light will illuminate when the oven is switched on and turns off when the oven
reaches the correct temperature.
The light will cycle on and off during cooking in line with the oven temperature.
Function Selector Knob (Fig. 3)
Rotate the knob clockwise to set the oven for one of the following functions:
Oven Light
By turning the function selector knob to this setting, the oven light will illuminate in the oven cavity.
The oven light will operate on all selected functions.
Traditional Convection Cooking
The upper and lower heating elements come on. The heat is dispersed by natural convection and the
temperature must be set to between 50 °C and 250 °C with the thermostat knob.
The oven must be preheated before cooking.
Recommended for:
Food that requires the same degree of cooking both inside and out, for example roasts, spare pork ribs,
meringues etc.
Traditional Grilling
The infrared grill element comes on. The heat is dispersed by radiation.
Use with the oven door closed and the thermostat knob to position 225 °C for max 15 minutes, then to
position 175 °C.
For cooking hints, see the chapter “USE OF THE GRILL”.
Recommended for:
Intense grilling, browning, cooking au gratin and toasting etc.
It is recommended that you do not grill for longer than 30 minutes at any one time.
Caution: the oven door becomes very hot during operation. Keep children well out of reach.

8
Oven Cooking
Before introducing the food, preheat the oven to the desired temperature.
For a correct preheating operation, it is advisable to remove the tray from the oven and introduce it
together with the food, when the oven has reached the desired temperature.
Check the cooking time and turn off the oven 5 minutes before the theoretical time to recuperate the
stored heat.
Use of the Grill
– Preheat the oven for about 5 minutes with the door closed.
– Introduce the food to be cooked, positioning the rack as close to the grill as possible.
– The dripping pan should be placed under the rack to catch the cooking juices and fats.
Grilling with the oven door closed.
It is recommended that you do not grill for longer than 30 minutes at anyone time.
Attention: the oven door becomes very hot during operation.
Keep children away.
The external parts of the oven become hot during operation.
Keep children well out of reach.

9
Lower Main Multifunction Oven
General Features
As its name indicates, this is an oven that presents particular
features from an operational point of view. In fact, it is possible to
insert 7 different programmes to satisfy every cooking need.
The 7 positions, thermostatically controlled, are obtained by 4
heating elements which are:
– Bottom element 1000 W
– Top element 900 W
– Grill element 2000 W
– Circular element 1900 W
Note:
Upon first use, it is advisable to operate the oven for 30 minutes in the position and to eliminate
possible traces of grease on the heating elements.
Repeat the operation for another 15 minutes with the grill element on as explained in the chapters
TRADITIONAL GRILLING and USE OF THE GRILL.
Operating Principles
Heating and cooking in the MULTI-FUNCTION oven are obtained in the following ways:
a. by Normal Convection
The heat is produced by the upper and lower heating elements.
b. by Forced Convection
A fan sucks in the air contained in the oven muffle, which sends it through the circular heating element
and then sends it back through the muffle. Before the hot air is sucked back again by the fan to repeat
the described cycle, it envelops the food in the oven, provoking a complete and rapid cooking.
It is possible to cook several dishes simultaneously.
c. by Semi-Forced Convection
The heat produced by the upper and lower heating elements is distributed throughout the oven by the
fan.
d. by Radiation
The heat is radiated by the infra red grill element.
e. by Radiation and Ventilation
The irradiated heat from the infra red grill element is distributed throughout the oven by the fan.
f. by Ventilation
The food is defrosted by using the fan only function without heat.

10
Thermostat Knob (Fig. 5)
This only sets the cooking temperature and
does not switch the oven on.
Rotateclockwiseuntiltherequired temperature
is reached (from 50 °C to 225 °C).
The thermostat indicator light will illuminate when the oven is switched on and turns off when the oven
reaches the correct temperature.
The light will cycle on and off during cooking in line with the oven temperature.
Function Selector Knob (Fig. 4)
Rotate the knob clockwise to set the oven for one of the following functions:
Oven Light
By turning the function selector knob to this setting, the oven light will illuminate in the oven cavity.
The oven light will operate on all selected functions.
Traditional Convection Cooking
The upper and lower heating elements come on. The heat is dispersed by natural convection and the
temperature must be set to between 50 °C and 225 °C with the thermostat knob.
The oven must be preheated before cooking.
Recommended for:
Food that requires the same degree of cooking both inside and out, for example roasts, spare pork ribs,
meringues etc.
How to Use the
Lower Main Oven
WARNING:
The door is hot, use the handle.
ATTENTION -
MOST IMPORTANT
Pay special attention not to
touch the hot heating element
inside the oven cavity.
Fig. 4 Fig. 5

11
Traditional Grilling
The infrared grill element comes on. The heat is dispersed by radiation.
Use with the oven door closed and the thermostat knob to position 225 °C for max 15 minutes, then to
position 175 °C.
For cooking hints, see the chapter “USE OF THE GRILL”.
Recommended for:
Intense grilling, browning, cooking au gratin and toasting etc.
It is recommended that you do not grill for longer than 30 minutes at any one time.
Caution: the oven door becomes very hot during operation. Keep children well out of reach.
Defrosting Frozen Foods
Only the oven fan comes on. Use with the thermostat knob set to “ ” - other positions have no effect.
The food is thawed by ventilation without heating.
Recommended for:
Quick thawing of frozen foods; one kg requires approximately 1 hour.
Thawing times vary according to the quantity and type of food to be thawed.
Hot Air Cooking
The circular element and fan come on. The heat is dispersed by forced convection and the temperature
can be regulated to between 50 °C and 225 °C via the thermostat knob. The oven does not require
preheating.
Recommended for:
Food which has to be well-cooked outside and soft or rosy inside, for example lasagne, lamb, roast beef,
whole fish etc.

12
Ventilated Grill Cooking
The infrared grill element and the fan come on. The heat is dispersed mainly by radiation and the fan then
distributes it all over the oven.
Use with the oven door closed. The temperature can be regulated via the thermostat knob to between
50 °C and 175 °C maximum.
The oven must be preheated for approximately 5 minutes. For cooking hints, see the chapter “GRILLING
AND AU GRATIN.
Recommended for:
Grilling where quick browning on the outside is required to keep the juices in.
For example: veal steaks, chops, hamburgers etc.
It is recommended that you do not grill for longer than 30 minutes at any one time.
Caution: the oven door becomes very hot during operation. Keep children well out of reach.
Maintaining Temperature After Cooking or Slowly Heating Foods
The upper heating element, the circular element and the fan come on.
The heat is dispersed by forced convection with greater intensity in the upper part.
The temperature can be set to between 50 °C and 140 °C via the thermostat knob.
Recommended for:
Keeping food warm after any type of cooking. Slow heating of cooked food.
Convection Cooking with Ventilation
The upper and lower heating elements come on and the fan.
The heat coming from above and below is dispersed by convection with ventilation.
The temperature can be set to between 50 °C and 225 °C via the thermostat knob.
Recommended for:
Voluminous dishes and large quantities which require the same degree of cooking both inside and out, for
example rolled roasts, turkey, roast legs, cakes etc.

13
Lower Main Oven Cooking Advice
Sterilization
Sterilization of foods to be conserved, in full and hermetically sealed jars, is done in the following way:
a. Set the switch to position .
b. Set the thermostat knob to position 185 °C and preheat the oven.
c. Fill the dripping pan with hot water.
d. Set the jars onto the dripping pan making sure they do not touch each other and the door and set the
thermostat knob to position 135 °C.
When sterilization has begun, that is, when the contents of the jars start to bubble, turn off the oven and
let cool.
Regeneration
Set the switch to position and the thermostat knob to position 150 °C.
Bread becomes fragrant again if wet with a few drops of water and put into the oven for about 10 minutes
at the highest temperature.
Simultaneous Cooking of Different Foods
With the function selector in position and the ventilated oven allows you to cook different types
of food at the same time.
Fish, cakes and meat can be cooked together without the smells and flavours mixing.
The only precautions required are the following:
– The cooking temperatures must be as close as possible with a maximum difference of 20 - 25 °C
between the different foods.
– Different dishes must be placed in the oven at different times according to the cooking time required
for each one. This type of cooking obviously provides a considerable saving on time and energy.
Grilling and “Au Gratin”
Grilling may be done by selecting grill+fan setting with the function selector knob, because the hot
air completely envelops the food that is to be cooked.
After having preheated the oven, simply place the food on the grid.
Close the door and let the oven operate until grilling is done.
Adding a few dabs of butter before the end of the cooking time gives the golden “Au Gratin” effect.
Grilling with the oven door closed.
It is recommended that you do not grill for longer than 30 minutes at any one time.
Caution: the oven door becomes very hot during operation. Keep children well out of reach.

14
Roasting
To obtain classical roasting, it is necessary to remember:
– that it is advisable to maintain a temperature between 180 °C and 200 °C.
– that the cooking time depends on the quantity and the type of foods.
Use of the Grill
– Preheat the oven for about 5 minutes with the door closed.
– Introduce the food to be cooked, positioning the rack as close to the grill as possible.
– The dripping pan should be placed under the rack to catch the cooking juices and fats.
Grilling with the oven door closed.
It is recommended that you do not grill for longer than 30 minutes at anyone time.
Attention: the oven door becomes very hot during operation.
Keep children away.
The external parts of the oven become hot during operation.
Keep children well out of reach.

15
Clock and Timer with “Touch-Control” Keys
(Lower Main Oven only)
Keys
and Touched simultaneously (for more than 2 seconds):
– setting the clock;
– setting the timer volume (by touching once, along
with the “ ” key);
– to cancel automatic cooking at any time.
Function selection (touched for more than 2
seconds):
– setting the clock (only after first connection or
after a power failure);
– timer;
– automatic cooking “dur” (duration) - how long
the food will take to cook (by touching the “
” key again);
– automatic cooking “End” - the time you would
like the oven turns off (by touching the “ ”
key two more times);
Increases the number shown on the display
Decreases the number shown on the display
Illuminated Symbols:
AUTO
flashing - Automatic cooking completed, oven in automatic position but not set
AUTO
steady illumination - Oven set for automatic cooking, cooking still not taking place
“
” flashing - Timer being set
“
” steady illumination - Timer in operation
“
” steady illumination - Oven set for manual cooking
“
” and AUTO AUTO flashing - Automatic cooking being set
“
” and AUTO steady illumination - Oven set for automatic cooking, cooking taking place.
Fig. 6

16
“Touch-Control” Keys
The “touch-control” keys shall be operated by the fingers (just by touching the key). When using touch
controls it is best to use the ball of your finger rather than the tip.
The keys are automatically deactivated:
– 8 seconds after the last selection; the deactivation is indicated by an acoustic signal (“beep”).
To reactivate just touch the “ ” key or the “ ” and “ ” keys.
Setting the Clock
When first connected, or after a power failure, the digits and “AUTO” will shown on the display. To set the
clock, touch the “ ” key, for more than 2 seconds, and then the “ ” or “ ” keys.
Important: The oven does not operate, in manual cooking, without first having set the clock.
To set the clock, with the appliance already connected, touch the “ ” and “ ” keys simultaneously (for
more than 2 seconds), then “ ” or “ ” keys.
Important: - changing the time will delete any automatic program;
– after setting the clock, the oven starts to operate in the selected function (manual cooking).
The “ ” symbol is steady illuminated.
Using the Timer
You can use the timer at any time, even when the oven is not in use. The timer does not turn the oven
off.
The timer can be set for up to 23 hours and 59 minutes.
– To set the timer, touch the “ ” key for more than 2 seconds (the “ ” symbol flashes), than the “
” or “ ” keys.
– After about 8 seconds an acoustic signal (“beep”) will sound confirming the regulation (“ ” symbol
steady illuminated).
– To check the remaining time touch the “ ” key for more than 2 seconds. If the remaining time is
more than a minute the display will show hours and minutes; if less than a minute the display will show
seconds.
– When the time is up, the timer will beep. Touch the “ ” key , for more then 2 seconds, to turn it
off; or press the “ ” or “ ” key to stop the beep and than the “ ” key, for more than 2 seconds,
to deactivate the “ ” symbol flashing on the display.
– Turn off the oven manually (function and thermostat knobs in the off position) if the manual cooking
has been completed.
Setting the Timer Volume
You can select from three volume levels.
– Touch the “ ” and “ ” keys simultaneously for more than 2 seconds.
– Touch the “ ” key; you can read on the display the current timer volume (“ton1”, “ton2” or
“ton3”).
– Touch the “ ” key to listen or change the timer volume.
– Timer volume activated: the last displayed.
– After about 8 seconds an acoustic signal (“beep”) will sound confirming the volume setting; then the
time of day will be displayed.

17
Automatic Cooking
Use automatic cooking to automatically turn the oven on, cook, and then turn the oven off.
1. Check the clock shows the correct time.
2. Select the function and temperature (function and temperature knobs). The oven will come on.
3. Decide how long the food will take to cook, allowing time for preheating if necessary.
4. Touch the “ ” key for more than 2 seconds and then touch again. “dur” will show (duration).
Using the “ ” and “ ” keys, set the cooking time.
5. Decide the time you would like the oven to turn off; touch the “ ” key for more than 2 seconds
and then touch it two times again. “End” will show. Using the “ ” and “ ” keys, set the cooking
time.
Note: While “dur” is displayed you can change to “End” just by touching one time the “MODE” key
(within 8 seconds from the last selection).
If there is time to wait before cooking starts, the current time of day and “AUTO” will show in the clock
display. The oven will switch off but is now set for automatic cooking.
If you are already at home to turn the oven on and only want the oven to turn off automatically, start
cooking as normal, then follow step 4 or step 5 to set a time to stop the oven.
When automatic cooking starts, “ ” will be displayed and the oven will turn on.
– To see the remaining cook time, follow step 4 up to display “dur” (duration).
– To see the set stop time, follow step 5 up to display “End”.
– To cancel automatic cooking at any time, touch the “ ” and “ ” keys simultaneously (for more than
2 seconds) and turn the temperature and function knobs to the off position.
When the stop time is reached, the oven will turn off, the timer will beep and “AUTO” will flash:
– Touch any key to stop the beeping.
– Touch the “ ” key, for more than 2 seconds, to return the oven to the manual mode (“ ” symbol
steady illuminated on the display).
– Turn the temperature and function knobs to the off position.
Attention: After a power failure any automatic program is deleted. Turn off the oven
manually.

18
Do’s and do not’s
– Do always grill with the oven door closed.
– Do read the user instructions carefully before using the double oven for the first time.
– Do allow the double oven to heat for one and a half hours, before using for the first time, in order to
expel any smell from the new oven insulation, without the introduction of food.
– Do clean your double oven regularly.
– Do remove spills as soon as they occur.
– Do always use oven gloves when removing food shelves and trays from the ovens.
– Do not allow children near the double oven when in use.
– Do not allow fat or oils to build up in the oven trays, or oven base.
– Do not place cooking utensils or plates directly onto the oven base.
– Do not grill food containing fat without using the grid.
– Do not cover the grilling grid with aluminium-foil.
– Do not use the oven tray for roasting.
– Do not place hot enamel parts in water. Leave them to cool first.
– Do not allow vinegar, coffee, milk, saltwater, lemon or tomato juice to remain in contact with enamel
parts (inside the oven and on the oven tray).
– Do not use abrasive cleaners or powders that will scratch the surfaces and the enamel.
– Do not attempt to repair the internal workings of your oven.
– Do remove the protective film before the first use.
– Fire risk! Do not store flammable material in the ovens.
For Your Safety
The product should only be used for its intended purpose which is for the
cooking of domestic foodstuffs.
Under no circumstances should any external covers be removed for servicing
or maintenance except by suitably qualified personnel.
Important Notes
Installation, and any demonstration, information or adjustments are not
included in the warranty.
The oven must be installed by a suitably qualified and registered person in
accordance with the relevant Standards.
ATTENTION:
The appliance gets
very hot, mainly
around the cooking
areas. It is very
important that
children are not
left alone in the
kitchen when you are
cooking.

19
IMPORTANT:
Before any operation
of cleaning and
maintenance
disconnect the
appliance from the
electrical supply.
ATTENTION:
Let the oven cool
down and pay special
attention no to touch
the hot heating
elements inside the
oven cavity.
CAUTION:
Do not use abrasive
substances or non-
neutral detergents as
these will irreparably
damage the surface.
CAUTION:
Do not use a steam
cleaner because the
moisture can get into
the appliance thus
make it unsafe.
CAUTION:
Do not store
flammable material
in the oven.
CAUTION:
Do not use harsh
abrasive cleaners or
sharp metal scrapers
to clean the oven
door glass since
they can scratch the
surface, which may
result in shattering
of the glass.
Care and Maintenance
It is advisable to clean when the appliance is cold and especially for cleaning
the enamelled parts.
Avoid leaving alkaline or acidic substances (lemon juice, vinegar, etc.) on the
surfaces.
Avoid using cleaning products with a chlorine or acidic base.
WARNING
When correctly installed, your product meets all safety requirements
laid down for this type of product category. However special care
should be taken around the rear or the underneath of the appliance
as these areas are not designed or intended to be touched and may
contain sharp or rough edges, that may cause injury.
Inside of Oven
The oven should always be cleaned after use when it has cooled down.
The cavity should be cleaned using a mild detergent solution and warm water.
Suitable proprietary chemical cleaners may be used after first consulting with
the manufacturers recommendations and testing a small sample of the oven
cavity. Abrasive cleaning agents or scouring pads/cloths should not be used
on the cavity surface.
NOTE: The manufacturers of this appliance will accept no responsibility for
damage caused by chemical or abrasive cleaning.
Enamelled Parts
All the enamelled parts must be cleaned with a sponge and soapy water only
or other non-abrasive products.
Dry preferably with a micro fibre or soft cloth.
Stainless Steel, Aluminium, Painted Parts and Silk-screen
Printed Surfaces
Clean using an appropriate product. Always dry thoroughly.
Stainless steel surfaces: can be cleaned with an appropriate stainless steel
cleaner.
IMPORTANT: these parts must be cleaned very carefully to avoid scratching
and abrasion. You are advised to use a soft cloth and neutral soap.
Glass Control Panel
Clean using an appropriate product. Always dry thoroughly.
Do not use harsh abrasive cleaners or sharp metal scrapers to clean the control
panel since they can scratch the surface, which may result in shattering of the
glass.

20
Replacing the Halogen Oven Lights
WARNING: Ensure the appliance is switched off before
replacing the lamp to avoid the possibility of electric
shock.
– Let the oven cavity and the heating elements to cool down;
– Switch off the electrical supply;
– Remove the protective cover C(fig. 7);
– Replace the halogen lamp Bwith a new one suitable for high temperatures
having the following specifications: 230V and same power (check watt
power as stamped in the lamp itself) of the replaced lamp.
IMPORTANT WARNING: Never replace the bulb with bare hands;
contamination from your fingers can cause premature failure.
Always use a clean cloth or gloves.
– Refit the protective cover;
Note: Oven bulb replacement is not covered by your guarantee.
BC
Fig. 7
WRONG
CORRECT
