CDN SD0202-R User manual

Model: SD0202
DIGITAL HIGH PRECISION SCALE
2.2 POUNDS/1000 GRAMS by ounces and grams
FOR PRECISE & GENERAL WEIGHING
•Precise to 0.01 oz/0.1 g
•NSF®Certied
•Tare function
•Removable stainless steel platform
•Selectable units
•Overload indication
•Low battery indication
•On/off button
•Auto-off after 4 minutes
•Food-safe ABS plastic with BioCote®
•Platform Size:
4.45 x 4.45 D (in)/11.3 x 11.3 (cm), removable
•Resolution: 0.01 oz, 0.1 g
•Product Dimensions:
4.45 W x 0.94 H x 7.13 D (inches)/
11.3 W x 2.4 H x 18.1 D (cm)
•Two AAA carbon zinc batteries (WERCSmart)
included
Note: Clean the scale before each use.
Important: DO NOT IMMERSE IN LIQUID.
Note: In the following instructions, names of the control
buttons are shown in CAPS. Function information that
appears on the display is shown in BOLD CAPS.
BATTERY INSTALLATION
Replace battery when LCD becomes dim. Lo appears
on the display when battery status is low and needs
to be replaced.
1. Power off the unit before installing the batteries.
2. Remove battery cover on the bottom by pressing
the latch toward the battery cover and lifting up.
3. Install two AAA carbon zinc batteries observing
polarity shown in compartment.
4. Replace the battery cover until it clicks shut.
OPERATING INSTRUCTIONS
Place the scale gently on a hard and at surface and
make sure it is steady before use to obtain accurate
measurements.
A. On/Off
1. Press the ON/OFF button to turn on. The display
ashes 8888 and then returns to zero within
3 seconds.
2. Press and hold the ON/OFF button for
2 seconds to turn off.
B. Auto Off
The scale automatically turns off after 4 minutes of
inactivity.
C. Unit Selection
Press the UNIT button to select the desired unit.
The display switches between oz and g.
D. Weighing Mode
Place an item on the scale platform. The weight
of the item appears on the display after the item
is stable.
Note: The minimum measurable weight is 0.04 oz/1.0 g.
Tel [phone] Fax [phone] Web CDNmeasurement.com

2
E. Tare
The tare function resets the scale display to zero
in order to measure only the weight of an item.
It is frequently used to subtract the weight
of containers.
1. When the scale is on, place a container on
the platform.
2. Press the TARE button to reset the display
to zero.
3. Place the item into the container or directly on
the scale platform. The weight of only the last
item added will appear on the display.
4. Continue to repeat steps 2. and 3. to measure
the respective weights of additional items.
5. To clear the tare, remove all items from the
platform and press the TARE button. The display
is reset to zero.
F. Battery Status
Lo appears on the display when battery status
is low and needs to be replaced with two AAA
carbon zinc batteries.
G. Overload Indication
EEEE indicates an overload when the item being
measured exceeds the capacity of the scale.
Immediately remove the overweight item to avoid
causing permanent damage to your scale.
Note: Clean the scale platform before each use. The
stainless steel removable platform is dishwasher safe;
the removable plastic platform base is not dishwasher safe.
Note: Replacement removable stainless steel platform
available.
USAGE GUIDELINES
• Scales are precision instruments and must be
handled with extreme care.
• Battery technology works best at room
temperature. Do not leave the scale in cold
rooms, refrigerators or freezers for extended
periods of time.
• Place the scale gently on a hard and at surface
and make sure it is steady before use.
• The minimum capacity of the scale is 0.04 oz/1.0 g.
• The maximum capacity of the scale is 2.2 lb/1000 g,
which is the capacity before using the tare function.
• Do not place overweight items on the scale.
• Do not place hot items directly on the scale
platform. They can distort the display. Rather, tare
a baking sheet at room temperature and then place
the hot item on it.
• Store the scale in a position that keeps it free from
any load bearing weight. Storing the scale with
pressure on the load cells can distort the weight
measurements over time.
• Hold the scale from the bottom when moving.
CARE OF YOUR PRODUCT
• Do not submerge any part of the scale in water.
• Wipe clean with a damp cloth.
• Store the scale at room temperature between
32 to 104°F/0 to 40°C.
PRECAUTIONS
• Keep the scale and/or battery away from children.
• Do not clean the scale with abrasive or corrosive
compounds, which may scratch the surface and
corrode the electronic circuits.
• Do not subject the scale to excessive force, shock,
dust, temperature or humidity, which may result in
malfunction, shorter electronic life span, damaged
battery and/or distorted parts.
• Do not tamper with the scale’s internal
components. Doing so will invalidate the warranty
and may cause unnecessary battery damage and/
or distorted parts.
• Do not subject the scale to excessive exposure
to direct sunlight.
• The unit is not waterproof — do not immerse it in
any liquid, which will result in faulty measurements.
• To avoid deformation, do not place the unit in
extreme temperatures.
• Always read the user manual thoroughly before
operating.

3
SPECIFICATIONS
Measurement Range 2.2 lb/1000 g
Unit of Measure oz/g
Resolution 0.01 oz, 0.1 g
Operating Range 32 to 104°F/0 to 40°C ≤90% RH
Accuracy 500 g ±1.2 g; 1000 g ±2.2 g
Power Supply Two AAA carbon zinc batteries
(WERCSmart) included
Platform Dimensions 4.45 W x 4.45 L (in)/
11.3 W x 11.3 L (cm)
, removable
Product Dimensions 4.45 W x 0.94 H x 7.13 D (inches)/
11.3 W x 2.4 H x 18.1 D (cm)
Weight 8.4 oz / 230 g (including battery)
Accessories Removable stainless steel platform
(AD-PF0202)
CE Note: This device could be sensitive to electrostatic
discharge. If electrostatic discharge or malfunctioning
occurs, please re-install the battery to reset this unit.

© 09 -2023 CDN Made in China CD9999345en - 9/23
Antimicrobial properties are
built-in to inhibit the growth of
bacteria that may affect this
product. According to EPA
guidelines we cannot claim that
the antimicrobial properties in this
product protect users or others
against bacteria, viruses, germs,
or other disease organisms.
This product does not protect
users or others against food-borne bacteria. Always clean and
wash this product thoroughly before and after each use.
The information in this document has been reviewed and is believed to
be accurate. However, neither the manufacturer nor its afliates assume
any responsibility for inaccuracies, errors or omissions that may be
contained herein. In no event will the manufacturer or its afliates be
liable for direct, indirect, special, incidental or consequential damages
arisen by using this product or resulting from any defect/omission in
this document, even if advised of the possibility of such damages.
The manufacturer and its afliates reserve the right to make
improvements or changes to this document and the products and
services described at any time, without notice or obligation.
1-Year Limited Warranty: Any instrument that proves
to be defective in material or workmanship (excluding
batteries) within one year of original purchase will be
repaired or replaced without charge upon receipt of the unit
prepaid at: CDN, PO Box 10947, Portland, OR 97296-0947
USA. This warranty does not cover damage in shipment
or failure caused by failure to adhere to the accompanying
instructions, inadequate maintenance, normal wear
and tear, tampering, accident, misuse, unauthorized
modication, obvious carelessness or abuse. CDN
shall not be liable for any consequential or incidental
damages whatsoever.
For more detailed information on our
products, please visit CDNmeasurement.com
or call 800-338-5594.
