CE-Link TM0008P User manual

Wireless Charger
User Manual

CONETNES
1.0 INTRODUCTION ----------------------------------------------------1
2.0 FEATURES ----------------------------------------------------------1
3.0 SPECIFICATIONS --------------------------------------------------1
4.0 PACKAGE CONTENTS ----------------------------------------------2
5.0 OPERATION---------------------------------------------------------2
6.0 CONNECTION DIAGRAM -------------------------------------------3

Wireless Charger
1
Wireless Charger
DEAR CUSTOMER
Thank you for purchasing this product. For optimum performance and
safety, please read these instructions carefully before connecting,
operating or using this product. Please keep this manual for future
reference.
1.0 INTRODUCTION
This product is a high-performance wireless charger. This product is
suitable for mobile phones, MP3, MP4, digital productions, and other
productions based on wireless charging 5W or 10W. Connect the
wireless to a power charger, and then you can charge your device
supported wireless charging (MP3, mobile phones, etc) by put it on
the charger directly. It is helpful in long time journey and convenient
for business!
2.0 FEATURES
Transmitting terminal input: 5V/2A,9V/2A ,12V/1.5A
Transmitting terminal output: 5W/7.5W/10W
Intelligent red/white indicator to show working condition
Compliant with QI, CE, FCC standards
It is light, smart and convenient to use
3.0 SPECIFICATIONS
Input
Type-C 5V/2A, 9V/2A, 12V/1.5A
Output
10W Max
Switch Frequency
110~205kHz
Operating Temperature Range
0~30°C
Storage Temperature Range
-20 ~ 70°C
Operation Humidity
10% ~ 80% RH
Storage Humidity
5% ~ 95% RH
Size
W92.5mm*H105mm*T96.5mm
Weight
95g±3g

Wireless Charger
2
4.0 PACKAGE CONTENTS
Before attempting to use this unit, please check the packaging and
make sure the following items are contained in the shipping carton:
Main unit×1
User Manual×1
5.0 OPERATION
Operation Procedures
1. Connect the wireless charger to the power adapter, the white
light will turn on for 3s then go off.
2. Place your device (which supports wireless charging) on the
charger and the white light will stay on.
3. When finished charging, the white light will stay on.
4. Please take out the device after it is fully charged.
Note: red light for staying on when malfunction occurs.
Operation Notes
1. For optimum performance, please use the wireless charger
according to this user manual.
2. Please connect the wireless charger to a power adapter which
output should be 5V/2A, 9V/2A,12V/1.5A.
3. Please unplug the wireless charger after using.
4. Do not use the wireless charger with an electronic product which is
not in conformity with the specifications, so as to avoid any
problem caused by specification mismatching.
5. It’s normal that wireless charger will be a little overheated in the
use process.
6. When the wireless charger stops working under some accidents ,
you need to check whether the device is compatible with this
charger.
7. Do not let the wireless charger close to fire, such as stove, candles
and etc.
8. Do not let the wireless charger soak into liquid, such as swimming
pool, bathtub, etc.
9. Do not wash the wireless charger with corrosive cleaner.
10.If the wireless charger cannot work properly, please contact the
store or distributor in your area.
11.Do not place metal objects on the back of the phone while it is
charging wirelessly.Please check that there is no metal foreign
body on the back of your mobile phone when using this product.

Wireless Charger
3
6.0 CONNECTION DIAGRAM
FCC Warning
This device complies with part 18 of the FCC Rules. Operation is subject to the
following two conditions:
(1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause
undesired operation.
NOTE: Any changes or modifications to this unit not expressly approved
by the party responsible for compliance could void the user's authority to
operate the equipment.
This equipment complies with FCC RF radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated
with a minimum distance of 20 centimeters between the radiator and your
body.
