Ceado ES900 Instructions for use

JUICE EXTRACTOR
INSTRUCTION AND MAINTENANCE MANUAL
GB
START
STOP
START
STOP
ES500
ES700
ES500S
ES900

JUICE EXTRACTOR
This is a commercial juice extractor for the preparation of fruit and vegetable juices with automatic
pulp ejection.
Like all appliances, it should be used with particular care to avoid injury to personnel and damage
to the appliance.
It is essential to read these instructions carefully before using the appliance and to follow the safety
recommendations.
Do not use the appliance if you have not read and understood these instructions!

JUICE EXTRACTOR
Main parts (Fig. 1 - Fig. 2 - Fig. 3)
Fig. 1
7
3
Fig. 2
2
8
2
1
Motor housing
Bowl
Spout
Juicer cover
Locking arm
Food pusher
Feed chute
Pulp container
Basket
8
7
6
5
4
3
2
1
9
Pulp retainer
rating disc
START button
STOP button
Motor shaft
Drive disc
15
14
13
12
11
10
4
6
59
11
10
1
15
14
Model ES700 with double feed chute ø 77 mm and ø 50 mm
13
12
Model ES900
Discharge connection
16

START
STOP
Fig. 3
ø 77 mm
START
STOP
ø 50 mm
Fig. 4
13
12 13 12
SAFETY RECOMMENDATIONS
GENERA INSTRUCTIONS
1. Read the following instructions carefully before using the appliance.
2. Installation and maintenance should be carried out by qualified
personnel only.
Model ES500S with feed chute ø 50 mmModel ES500 with feed chute ø 77 mm
Fig. 5
13
12
16
Model ES900

3. This appliance is intended for professional use, and should therefore
be used by adults and qualified personel only.
4. This appliace is not meant for use by persons (including children)
with reduced mental, sensorial or physical abilities or without
experience and knowledge, unless they have been duly instructed
on the use of such appliance and are supervised by a person
responsible for their safety.
CHI DREN SHOU D BE SUPERVISED SO AS TO ENSURE
THAT THEY DO NOT P AY WITH THE APP IANCE
5. Never use this appliance for purposes other than extracting juice
from pieces of fruit and vegetables. Any other use is dangerous.
6. Always work under safe conditions: do not use the appliance with
wet hands or feet. Do not use outdoors.
7. Keep the original package for possible future use. It is the most
suitable protection against damage during transport.
8. In case of fire use CO2extinguishers. Do not use water or powder
extinguishers.
9. Never place the appliance in water!
10. Do not disassemble the appliance or attempt to perform any repairs
inside it.
11. Always unplug the appliance before performing any maintenance or
cleaning and when it is not in use.
12. Never pull the appliance by the cord to move it. Never unplug it by
pulling the cord or touching it with wet hands.
If the power cord is damaged, it must be replaced by the
manufacturer or by its tecnichal assistance service or, in any
case, by someone having equivalent knowledge, so as to
prevent any risk.
13. WARNING: BE CAREFUL to never insert utensils, metal objects or
other rigid or sharp materials in the basket as it is dangerous and
could cause injury.
14. During maintenance procedures and while unpacking, do not hold or
lift the appliance by the locking arm of the juicer cover.
15. When cleaning the appliance use care in handling the basket so you
do not alter the alignment or reduce the performance of the
appliance.

16. Do not use the appliance if it is damaged or has loose parts.
Immediately contact an authorized Service Center.
17. Do not push fruit or vegetables into the feed chute with your fingers.
Always use the food pusher provided.
18. Do not touch the sharp teeth of the grating disc.
19. Do not insert fruit with stones (e. g. peaches, apricots, etc.) without
first removing the stone.
20. On model with two feed chutes never insert the ø 50 pusher in the
ø 77 chute.
21. Never use the appliance if the rotating basket is damaged.
WARNING: DO NOT PUT FINGERS OR ANYTHING OTHER
THAN THE APPROPRIATE FOOD PUSHER PROVIDED WITH
THE APP IANCE INSIDE THE FEED CHUTE. A WAYS USE
THE FOOD PUSHER TO PUSH THE FRUIT TOWARDS THE
ROTATING GRATING DISC.
SAVE THESE INSTRUCTIONS!
INSTA ATION
Comply with the safety recommendations indicated above and hereafter when installing the
appliance.
1. Before starting to use the appliance carefully wash and dry all the removable parts in contact
with food.
2. Make sure that the mains voltage is as indicated on the rating label of the appliance and that
the electrical system is grounded and equipped with a switch.
3. Install the appliance in a DRY, PROTECTED place, far from water sprays or splashes, heat
sources, open flames and inflammable substances.
Place the appliance on a flat, horizontal, stable surface where it cannot tip over.
The EC declaration of conformity for this appliance is available in the Products section of our
website www.ceado.com.

USE
Make sure the tabletop and feet are clean to ensure grip during operation.
Before first use: rinse all of the parts that will have contact with food in running water i.e.;
food pusher, juicer cover, basket, bowl, pulp container and pulp retainer. To disassemble the
various parts see Fig. 9, Fig. 10 and Fig. 11.
Suggestions (only for ES500, ES500S and ES700 models): to reduce the cleaning
procedures to a minimum we suggest placing a biodegradable plastic bag inside the pulp
container and folding the top of the bag over the edge of the pulp container (see Fig. 6). By
using this method, once you have finished using the appliance, you can put the waste directly
into a composting or waste bin.
Wash the fruit or vegetables you will use.
NOTE: Many types of fruit and vegetables for example apples, carrots and cucumbers fit
through the feed chute without having to be cut into pieces. When you make juice from carrots
it is a good idea to insert the larger end of the carrot first, or to cut the carrot in two or three
pieces.
For models with feed chute ø 50 mm, use the latter to juice carrots. To optimize the juice output
chop fruit into smaller pieces.
1
4. Plug the appliance into a socket protected by a suitably rated circuit breaker (MCB) or fuses.
Do not use an adaptor plug.
5. Stretch the power cable out to full length. Do not let it pass over sharp edges or hot surfaces.
Do not let oil spill on it. Do not let the power cable hang loose from the counter on which the
appliance stands.
6. To use the appliance more easily, we suggest that the appliance is placed on a table or counter
top so that the juice spout and the controls face towards the right side of the user (suggested
height for counter top from a round level: 90 cm (36 inches), to be adjusted according to the
height of the user).
Installation of model ES900 (see Fig. A)
1. Drill the worktop to insert the discharge connection using the "installation TEMPLATE" provided
(see attached sheet).
2. Place the appliance without the juicer cover, the pulp container and the bowl in the final
position with the aid of the indication of the position of the feet on the installation template.
3. Place the “discharge connection” in the hole just created, taking care to insert the fixing
hooks “b” correctly into the holes “c” provided in the bottom of the appliance.
4. Insert the pulp container completely into the “discharge connection”, ensuring that it is in a
perfectly straight position (see 4, Fig. A).
5. Complete the installation of the appliance by correctly positioning the bowl and the juicer cover
and closing the locking arm.

2
1
3
4
5
Fig. A
Model ES900
90°
OK
b
b
c
c
3
4

Ensure that the juice extractor is correctly assembled. Ensure that the basket is properly
cleaned before each use.
Check to see that locking arm is hooked on to the juicer cover.
Place a container under the spout of the bowl.
Turn on the motor by pushing the START button.
5
4
3
2
Fig. 6
Use the food pusher provided, to gradually push down the fruit and/or vegetables towards the
spinning grating disc at the bottom of the feed chute (see Fig. 7). To obtain more juice always
press the food pusher lightly. Do not insert fruit and/or vegetables when the motor is off.
NEVER USE YOUR FINGERS TO PUSH THE FRUIT AND/OR VEGETAB ES DOWN THE
FEED CHUTE OR TO C EAN THE CHUTE. A WAYS USE THE FOOD PUSHER
PROVIDED.
The juice will pour from the spout into the container placed below the spout. The separated pulp
will accumulate in the pulp container.
Continue to use the appliance until the container is filled with juice or until you have finished
the fruit or vegetables you are using or ensure the pulp container has become filled with pulp.
Turn the motor off by pushing the STOP button.
Note: Always wait until the motor has come to a complete stop before unhooking the locking arm.
Never use the locking arm to turn the appliance off. This could wear out the safety
mechanisms (safety microswitch and motor brake).
When the appliance is not in use leave the locking arm hooked to the juicer cover.
Only for ES500, ES500S and ES700 models:
When using the appliance control the level of pulp in the pulp container (with the motor turned
off). The quantity of fruit or vegetables that can be used before the pulp container is filled
varies depending on the type of fruit or vegetables used.
Should blockage occur while the appliance is in use before the pulp container is filled with
pulp it is a good idea to turn the appliance off and find the cause of the blockage.
NOTE! When using the juice extractor the pulp container can be emptied by turning the appliance
off and carefully removing the pulp container. (Put the pulp container in place before turning
the juice extractor back on).
6
9
7
10
8

C EANING AND MAINTENANCE
Suggestions (only for ES500, ES500S and ES700 models): to reduce the cleaning procedures to
a minimum we suggest placing a biodegradable plastic bag inside the pulp container, folding the top
of the bag over the edge of the pulp container (see Fig. 6). By using this method, once you have
finished using the appliance, you can put the waste directly in a composting or waste bin.
Before each cleaning remove the appliance’s plug.
By keeping the appliance well-cleaned and in working order you can maximize the quality of
the juice extracted and guarantee a longer life for the appliance itself. For this reason, after
every use, you should clean the basket, bowl, juicer cover, pulp container, pulp retainer, and
food pusher so that residues do not harden and encrust the appliance.
To clean the motor housing, clean with a cloth dampened with water or alcohol or with a
spray neutral solution.
Wipe with a dry cloth.
Never put the motor housing under running water and never immerse the appliance in
water.
To clean the juicer cover, bowl, basket, pulp container, pulp retainer and food pusher:
rinse under running water and wash with warm water and washing liquid. Rinse and dry.
Fig. 7

Fig. 8
To disassemble these components, unhook the locking arm and remove in this order; food
pusher, juicer cover, basket, pulp retainer, and bowl (Fig. 9, Fig. 10). Reassemble in the reverse
order taking care to place the juice spout in the appropriate slot of the motor housing, place the
pulp retainer correctly, place the basket in the bowl, making sure that the basket’s clutch disc
is correctly inserted on the drive disc and position the juicer cover on the bowl.
- The removable parts of the juice extractor, with the exception of the pulp container, are
dishwasher safe. The pulp container should not be immersed in hot water. Hot water can
deform the pulp container making it impossible to use.
- To obtain a higher yield of juice always control that the basket is well-cleaned by using a nylon
brush. Put the basket under running water and use the brush to clean the inside of the strainer
(see Fig. 8). Hold the basket up against the light to make sure that none of the perforations are
blocked. Should the perforations of the strainer remain blocked, immerse the basket in a
solution of hot water with 12% lemon juice or vinegar to loosen the blocked material.
Alternatively, wash the basket in a dishwasher.
- Handle the basket with care as even the slightest damage to the pulp container can cause the
juice extractor to vibrate undesirably during use.
As some products (such as peeled citrus fruits, celery and tomatoes) can easily encrust or
obstruct the perforations, you should frequently clean the basket.
THE BASKET HAS SMA SHARP TEETH. DO NOT TOUCH THE TEETH WHEN YOU
HAND E THE BASKET.
Do not use abrasive products or sponges to clean the basket.
Do not let traces of fruit or vegetables dry and harden on the pulp container, basket,
juicer cover or food pusher.
Never use bleach or chlorine-based cleaning products on the juice extractor.

For a periodic deep-cleaning you can disassemble the parts of the basket by unscrewing the
clutch disc (Fig. 11).
To disassemble the parts of the basket, hold the basket still with one hand and unscrew the
clutch disc. Pull the screw out of the basket.
Wash all of the parts in warm water with dish soap, removing any residues with the brush.
Reassemble in reverse order (Fig. 11) making sure that the parts are tightly attached to one
another.
INFORMATION ON FRUIT AND VEGETAB E JUICES
Freshly-made juices should be consumed immediately following their extraction to obtain maximum
vitamin content.
PURCHASE AND STORAGE OF FRUIT AND VEGETAB ES
- Always wash fruit and vegetables before juicing.
- Always use fresh produce.
- To save money and obtain higher-quality juices, always use fruit and vegetables that are in
season.
- Always keep produce ready to juice by washing it before putting it in the refrigerator.
- Most fruit and vegetables can be kept at room temperature. Delicate fruit and vegetables, such
as tomatoes, berries, lettuce, celery, cucumbers and herbs should be kept in the refrigerator
until use.
- Do not use overly ripe fruit because it clogs the basket very quickly.
PREPARATION OF FRUIT AND VEGETAB ES
- Fruit or vegetables with a hard or inedible skin or rind, such as melon, pineapple, mango, kiwi,
etc., must be peeled before being inserted in the juice extractor.
- All citrus fruits must be peeled be fore being inserted in the juice extractor.
- Remove the stones from fruits such as peaches, apricots, plums, etc., before inserting the fruit
in the juice extractor.
- A small quantity of lemon juice can be added to apple juice to prevent discoloration.
Suggestions: the juice extractor also gives a high yield of juice from oranges. Remember to always
peel oranges and all citrus fruits before inserting them in the juice extractor (we also suggest putting
the oranges in the refrigerator before use).

Fig. 9 Fig. 10
ES700
ES900
ES500

TROUB ESHOOTING
(See Table on the next page)
In case of any malfunction, defect of the appliance or if you suspect any breakage after a fall, unplug
the appliance immediately.
If you are unable to solve the problem referring to the table below, contact an Authorized Service
Centre.
Only qualified experts should repair the appliance.
We are not liable for any damage caused by repairs not made correctly and/or by unauthorized
personnel. In these cases the warranty does not apply.
RECOMMENDATIONS FOR PROPER
USE
When you make juice from different types of
ingredients with different consistencies it is a
good idea to start with the softer ingredients and
then subsequently use the harder ingredients.
When you make juice from herbs or lettuce you
should press them together to form compact
balls, or mix them together with other
ingredients to obtain a better result.
NOTE! Herbs and lettuce give a low yield of
juice. This is due to the characteristics of
the produce and of the juice extractor. It is
therefore advisable to always make juice
from herbs and lettuce mixed together with
other fruit or vegetables.
Different types of fruit and vegetables yield
different quantities of juice. The amount of juice
varies even between fruit and vegetables of the
same kind, for example two apples of the same
variety and with the same weight can produce
different quantities of juice. iven the fact that
juice recipes are not an exact science, using
precise quantities of ingredients for each juice
recipe is not a determining factor for the
successful outcome of the recipe.
NOTE! To obtain a high yield of juice always
press the food pusher lightly.
Screw rating
disc
Clutch disc
Basket
Fig. 11

Problem
The appliance does not turn
on.
•Make sure the feed chute is empty.
•Make sure it is plugged in.
•Make sure the safety circuit breaker is closed.
•Make sure the locking arm is correctly hooked onto the
juicer cover.
•If the problem occurs itself after a long period of intensive
use or overfilling, the motor could be in thermal protection
lock! Wait at least 20 minutes and try again. The waiting
time can be reduced by putting the appliance in a cool
place.
•The vibration can be caused by:
•Incorrect positioning of the basket. Check alignment.
•Deterioration of the structural components of the
basket. Check and replace if necessary.
•Accumulation of pulp in the basket. Check and empty
pulp if necessary.
•Full container.
•Blockage of the basket. Check and clean the basket.
•The opening of the spout is blocked. Check and clean the
bowl and spout.
•Use of fruit that has too much pulp or is too ripe. Check and
clean the bowl and basket.
The appliance vibrates in an
abnormal manner.
Juice does not come out of
the spout.
•Try to alternate between soft and hard fruits when using the
juice extractor.
Excessive accumulation of
pulp in the basket.
•Try to insert the fruit or vegetables more slowly and with
less force.
•Make sure that the basket is always carefully cleaned with
a nylon brush. Put the basket under running water and use
the brush to clean the inside of the strainer (see Fig. 8),
holding the basket up against the light to make sure that
none of the perforations are blocked. Should the
perforations of the strainer remained blocked, immerse the
basket in a solution of hot water with 12% lemon juice or
vinegar to loosen the material that blocked them.
Alternatively, wash the basket in a dishwasher.
•Fruit too ripe.
Pulp appears excessively
wet and a low quantity of
juice is produced.
Solution

THE MANUFACTURER RESERVES THE RIGHT TO MAKE ANY A TERATIONS TO
THE APP IANCE WITHOUT NOTICE
WARRANTY
This product is guaranteed against faulty materials and workmanship.
The warranty period may vary according to local laws or commercial uses of the country where the
product is marketed. Therefore, please contact the retailer from whom the product was purchased.
During the warranty period, this product can either be repaired or replaced, at the manufacturer's
discretion, at no additional cost only if it has been used according to the instructions in this use and
maintenance manual.
If the products needs maintenance or repairs during the warranty period, contact your retailer for
shipping instructions. The product should be shipped in its original package or other suitable
packing.
The warranty does not apply in case of neglect, misuse, abuse or unauthorized repairs. This
warranty does not apply to parts subject to deterioration through normal use such as wear to the
basket, the grating disc, etc.
The warranty is limited to the costs of repair or replacement of the product or its defective parts, or
an amount equivalent to the price paid for its purchase. No additional requests of damages will be
available to the purchaser.
The manufacturer will not accept any liability and the warranty will be invalidated if there is a
failure to follow these instructions and the technical and/or safety standards in the country where
the appliance is to be used.
In any case these instructions cannot cover every possible event and the user is recommended to
use the appliance responsibly.
DISPOSA
Correct disposal of this product (waste electrical and electronic
equipment)
(Applicable in the European Union and other countries with separate
collection systems in conformity with European Directive 2012/19/EU
and subsequent updates)
This product has been made from high-quality parts and materials,
which can be re-used and recycled.
Therefore, do not throw the product away with normal household waste
at the end of its working life. Take it to a collection point for recycling
electrical and electronic devices. This is indicated by this symbol on the
product and in the operating manual.
Please contact your local government office for information about the
exact location of the closer collection point.

Cod. 80412 - 01/2020
Progetto grafico K&L
Ceado S.r.l.
Tel.: [phone]
Fax: [phone]
E-mail: [email protected]
www.ceado.com
