cecotec CONGA POPSTAR 7000 MATTRESS User manual

CONGA POPSTAR 7000 MATTRESS
Mattress vacuum cleaner with UV light and motorised brush
Instruction manual

INDEX
1. Parts and components
2. Before use
3. Operation
4. Cleaning and maintenance
5. Troubleshooting
6. Technical specications
7. Disposal of old electrical appliances
8. Technical support and warranty

SAFETY INSTRUCTIONS
Read these instructions thoroughly before using the appliance.
Keep this instruction manual for future reference or new users.
All safety instructions should be closely followed when using
the appliance.
-Make sure that the mains voltage matches the voltage
stated on the rating labelofthe appliance and thatthe outlet
is grounded.
- Do not allow the machine to run unattended.
-Do not immerse the cord, plug or other non-removable part
of the product in water or other liquids. Do not expose the
electrical connections to water. Make sure your hands are
dry before handling the plug or switching on the appliance.
-If the product falls accidentally in water, unplug it
immediately. Do not reach into the water!
-Do not use the device to vacuum hot objects such as carbon
or cigarette butts, sharp objects such as broken glass,
corrosive liquids, or ammable and explosive materials
such as gasoline and alcohol.
-Do not use this product to vacuum water or wet dust
and avoid using it next to water or in wet places such as
bathrooms, toilettes and laundry rooms.
-Do not look at the UV lamp on the bottom part of the device,
it could cause eye and skin damage.
-Do not irradiate the plants or persons with ultraviolet rays,
otherwise it may damage them. Do not use ultraviolet rays
in one place continuously, otherwise it may damage the
cleaning object.
- Do not disassemble de UV lamp.
- Do not sit on the product.
-Do not remove the rolling brush cover or force the cover
outward when the machine is powered on or running, so as

not to damage the product.
-Do not use this product forthe purposes ratherthan cleaning
textiles such as mattresses, blankets, pillows and sofas and
removing mite.
-Keep the device awayfrom heat sources and direct sun light.
-Check the power cord regularly for visible damage. If the
cord is damaged, it must be replaced by the ofcial Technical
Support Service of Cecotec, in order to avoid any type of
danger.
-Do not move the product or pull from it from its cord. Do
not use the cable as handle. Do not force the cable against
corners or sharp edges. Do not run appliance over the cord.
Keep the power cord away from hot surfaces.
-Do not use the appliance if its cord, plug, or housing is
damaged, nor after it malfunctions or has been dropped or
damaged in any way.
-Do not tryto disassemble the device byyourself. Contact the
ofcial Technical Support Service of Cecotec.
-Cleaning and maintenance must be carried out according to
this instruction manualto make surethe appliancefunctions
properly. Turn off and unplug the appliance before moving
and cleaning it.
-Store the appliance and its instruction manual in a safe and
dry place when not in use.
-This appliance is not intended to be operated by means of an
external timer or separate remote-control system.
-Turn off and unplug the device from the mains supply when
not in use and before cleaning. Unplug it when it is not going
to be used for a long time. Pull from the plug, not the cord, to
disconnect it from the outlet.
-This appliance is intended for domestic use only. It is not
suitable for commercial or industrial use. Do not use it

outdoors.
-No liability is accepted for any eventual damage or personal
injuries derived from misuse or non-compliance with this
instruction manual.
-The appliance is not intended to be used by children under
the age of 8. It can be used by children over the age of 8, as
long as they are given continuous supervision.
-This appliance is not intended to be used by persons
with reduced physical, sensory, or mental capabilities, or
lack of experience or knowledge, unless they have been
given supervision or instruction concerning the use of the
appliance in a safe way by a person responsible for their
safety, and understand the hazards involved.
-Supervise young children to make sure that they do not play
with the appliance. Close supervision is necessary when the
appliance is being used by or near children.
-Keep this product out of the reach of children under 8 years
old.
-The cleaning and maintenance of the appliance should not
be carried out by children.

1. PARTS AND COMPONENTS
Fig. 1
1. Cleaning mode button
2. On/Off button
3. Dust tank assembly
4. Cleaning mode indicator
5. Power cord
Fig. 2
1. Rolling brush
2. Hot air outlet
3. UV lamp
4. Power cord
2. BEFORE USE
- Remove all packaging materials.
-Inspect all parts of the appliance for visual damage. Unwind the power cord completely
and inspect it for damage. Do not use the appliance if the device or its cord have been
damaged or are not working properly. In case of damage, contact the ofcial Technical
Support Service of Cecotec for advice, repairs, or returns.
- Make sure all components are included in the package.
-Make sure you have read and understood all instructions and warnings in this instruction
manual. Pay particular attention to the safety instructions on previous pages.
- Keep the original box and the instructions manual.
3. OPERATION
Fig. 3.
1. Cleaning mode button
2. On/Off button
3. Mite removal mode indicator
4. Brush rotation mode indicator
5. Full cleaning mode indicator

Full cleaning mode: Vacuuming, Brush rotation & Mite removal
-Turn the device on. Itwillrun underFull cleaning mode (Vacuuming, Patting & Mite removal
with UV-C light) by default. The corresponding light indicator will turn on.
- Press the On/Off button once to turn the device off.
Vacuuming & Brush rotation mode
-Once the device is turned on in the Full cleaning mode, press the Mode button to switch to
Vacuuming & Patting mode. The corresponding light indicator will turn on.
- Press the On/Off button once to turn the device off.
Vacuuming & Mire removal mode
-Once the device is turned on in the Vacuuming & Patting mode, press the Mode button to
switch to Dust & Mite removal mode. The corresponding light indicator will turn on.
- Press the Mode button once to return to the Full cleaning mode.
- Press the On/Off button once to turn the device off.
Note
The 3 operating modes are set in a cycle. Press the Cleaning mode button once to switch from
one to another following the before order.
Warning
In order to avoid accidental injury, the UV lamp must be placed within 5 cm of the object to be
irradiated and the machine inclination must not exceed 30º. Outside this range, the UV lamp
will turn automatically off. Under this premise, the Mite removal mode indicator turns on,
indicating that the UV lamp is working normally.
After the mite eliminator starts to work, the hot air outlet continues to emit hot air and the
hot air temperature is high. Do not touch the hot air outlet with your hand while the machine
is working.
4. CLEANING AND MAINTENANCE
-It is recommended to clean the dust tank after each use; when the lter dust is blocked due
to excessive dust, it needs to be cleaned and replaced if necessary.
-If the dust tank is lled with dust during the process of use, clean it immediately.
-When the device has reached 30 hrs.- 50 hrs. use, (depending on the use of lter cotton), it
is suggested to buy a new lter cotton and change the air inlet lter cotton so as to ensure
good performance of the machine.

-UV penetration ability is weak. Any paper, glass and plastic will greatly reduce the intensity
of ultraviolet radiation. Therefore, dust and oil stains on the lamp tube will directly
affect its penetrating ability. UV lamps shall be cleaned regularly to avoid affecting UV
transmittance and intensity.
-Do not touch the UV lamp with your ngers, since stains can affect the penetration of UV
light.
-If the device is not going to be used for a long time, keep the machine in a cool and dry
place. Do not put it in direct sunlight or in humid environments.
Dust tank cleaning
1. Turn the device off and remove the power plug.
2. Place the machine in an upright position.
3. Press the dust tank release button.
4. Lift the dust tank assembly upwards.
5. Rotate the dust tank counterclockwise and lift the dust tank cover.
Fig. 4.
6. Take out the cotton lter and the dust tank lter.
7. Clean the dust tank.
Fig. 5.
Rolling brush cleaning
1. Take out the Rolling brush and clean it.
Fig. 6.
Fig. 7.
2. After cleaning, rst place the hexagonal rolling brush head gear into the belt, snap the
hexagonal rolling brush head into the base, and then press the four corner rolling brush
head on the other end into the base to assemble the rolling brush.
3. Finally, install the rolling brush cover in the reverse order.
Fig. 8.
Note
When cleaning the rolling brush, be sure to disconnect the power supply to avoid accidental
start of the roller brush and to avoid damage and injuries.
UV lamp cleaning and installation
1. Turn the device off and unplug it from the power supply.
2. Gently wipe the surface of the UV lamp with a dry cloth.
Note
When cleaning the UV lamp, be sure to disconnect the power supply to avoid electric shock
and injury to humans.

5. TROUBLESHOOTING
Problem Possible causes Solutions
The machine does not work.
The power plug is not inserted
tightly.
Check if the power plug is
inserted tightly.
The power socket has no
electricity.
Check the socket.
The on/off button is not pressed. Press the on/off button.
The absorbing force
becomes weaker.
Intake air lter cotton is too
dusty, causing protector
turn on
Clean the suction inlet.
Too many foreign objects are
attached on the lter cotton and
dust tank.
Clean the dust tank and
lter cotton.
There is too many foreign objects
in the second-level cyclone cover.
Clean the foreign objects
on the second-level
cyclone cover.
Intake air lter cotton is too
dusty, as a result, it may turn on
protector
Clean the dust from the
intake lter.
The ultraviolet light does
not work.
The ultraviolet light is badly
reected on the surface of
cleaned object, or it is far away
from the cleaned object.
In normal condition, the
ultraviolet light will be
started automatically when
the machine is 5cm away
from the object.
The machine stops on the
blanket.
Move the machine forwards
and backwards on the
blanket.
The machine is placed upright. The machine inclination
shall not exceed 30º.
The transparent lm on the
infrared detector at the bottom of
the machine is covered with dirt
or too much dust.
Wash the transparent lm
on the detector with half
dry cotton cloth.
The ultraviolet tube is damaged. Contact after-sale staff to
change ultraviolet tube.

The machine stops working
suddenly.
The dust tank is lled with the
dust.
To avoid overheating of
this product motor, the
overheating protection
mechanism has been
outtted on the machine. If
the product is overheated,
turn off the power supply,
clean up the blockage, and
then use it after two hours.
The suction inlet is blocked.
The lter cotton is blocked by
foreign objects.
The roller brush stops
working suddenly.
The foreign objects are wound on
the roller brush.
Open the cove of roller
brush as required, and then
clean the roller brush and
use it.
The belt falls off or has broken
off.
Open the cove of roller
brush as required, and
check if the belt falls off or
has broken off.
6. TECHNICAL SPECIFICATIONS
Product: Conga PopStar 7000 Mattress
Product reference: 05568
Rated voltage: 220-240 V~
Rated frequency: 50 Hz
Rated power: 700 W
Dust tank capacity: 0.35L
Made in China | Designed in Spain
7. DISPOSAL OF OLD ELECTRICAL APPLIANCES
The European directive 2012/19/EU on Waste Electrical and Electronic
Equipment (WEEE), species that old household electrical appliances must
not be disposed ofwith the normalunsorted municipalwaste. Old appliances
must be collected separately, in order to optimize the recovery and recycling
of the materials they contain and reduce the impact on human health and
the environment.
The crossed out “wheeled bin” symbol on the product reminds you of your
obligation to dispose of the appliance correctly.
Consumers must contact their local authorities or retailer for information concerning the
correct disposal of old appliances and/or their batteries.

8. TECHNICAL SUPPORT AND WARRANTY
This product is under warranty for 2 years from the date of purchase, as long as the proof
of purchase is submitted, the product is in perfect physical condition, and it has been given
proper use, as explained in this instruction manual.
The warranty will not cover the following situations:
-The product has been used for purposes otherthan those intended for it, misused, beaten,
exposed to moisture, immersed in liquid or corrosive substances, as well as any other fault
attributable to the customer.
-The product has been disassembled, modied, or repaired by persons, not authorised by
the ofcial Technical Support Service of Cecotec.
- Faults deriving from the normal wear and tear of its parts, due to use.
The warranty service covers every manufacturing defects of your appliance for 2 years, based
on current legislation, except consumable parts. In the event of misuse, the warranty will not
apply.
If at any moment you detect any problem with your product or have any doubt, do not hesitate
to contact Cecotec Technical Support Service at [phone].

Fig./Img./Abb./Afb./ Rys./Obr. 1
1
2
3
4
5
Fig./Img./Abb./Afb./ Rys./Obr. 2
1
2
3
4
Fig./Img./Abb./Afb./ Rys./Obr. 3
1
2
3
4
5

Fig./Img./Abb./Afb./ Rys./Obr. 4
Fig./Img./Abb./Afb./ Rys./Obr. 5
Fig./Img./Abb./Afb./ Rys./Obr. 6 Fig./Img./Abb./Afb./ Rys./Obr.7

Fig./Img./Abb./Afb./ Rys./Obr.8

www.cecotec.es
Grupo Cecotec Innovaciones S.L.
C/ de la Pinadeta s/n, 46930
Quart de Poblet, Valencia (Spain)
EA01210223
