CED CED7000T User manual
Competitive Edge Dynamics Ltd. Printed in China
LOCATION AND FUNCTION OF KEY PARTS & CONTROLS
In keeping with Competitive Edge Dynamics policy of continuous improvement and
development, CED reserves the right to make any changes or modifications in the specifications
deemed necessary, without prior notice. Therefore, the above photographs and descriptions
may vary slightly in detail from the actual product.
Start Button Review Button
Delay Time / Split Time
Par Time / First Shot
Delay Setting
Month / Day / Year / Time
Directional
Buttons
Enter Button
Start Button
Review Button
External Batt.
Pack Connection
Recharging Jack AUX Jack
String
Shots /
Review
Battery
Indicator
Cumulative
Time
Shot Detection Microphone
On / Off /
Clear Button
Menu Button
Loud Buzzer
1.
INTRODUCTION
Congratulations on purchasing the CED7000, CED7000T, or CED7000A Shot Activated Timer,
brought to you by Competitive Edge Dynamics and Double-Alpha Academy. The CED7000 Timer
is the most technologically advanced timer in the world, yet as easy to use as a mobile phone. The
CED7000 Timer features a complete custom backlit display, advanced programming, memory, and a
range of features that make all other timers in its price range obsolete! The CED7000 is simply the
SMALLEST, MOST COMPACT, LIGHTWEIGHT, and easy to use timer in the world today! 80 g
(2.9 oz) (100 x 47 x 18.5 mm / 3.9” x 1.87” x 0.7”
This manual covers features and functions of the following CED7000 timers
CED7000 Timer - Standard model featuring chrome buttons and trim plate.
CED7000T Tactical Timer - All black design featuring black buttons and trim plate.
CED7000A Airsoft Timer - a modied microphone and buzzer system.
New features / functions include:
• Memorystorage/recallandunlimitedshotrecord&reviewfunction
• CustomPARallowssingleormultipletimesettingswithvariabledelayintervalstothe0.01sec.level
• Dualforward/reverseREVIEWfunction
• IlluminatedfullfunctionLCDdisplayshowingataglancetotaltime,splits,shotnumber,Par,&
rstshottime
• Month,Day,Date,&Timedisplayedin12or24hourclockselection
• Optional50yardRFremotecapabilityforCEDBigBoardandTimeKeeper
• 999.99secondtimerecordcapacity
• Splitand1stshottimesdisplayedonallshotsred
• CombinedComstockFunction
• RepetitiveMode(Face/EdgeSimulation)
• Instant,Fixed,RandomorCustomProgrammedDelays
• Digitalsensitivityshotdetectorwithadjustablesoftwarelter
• Auto-StartFunction
• SilentOperationforvisualstarts
• R.O.(RangeOfcer)Mode
• Multi-ParMode-formultipleParsettingsfromonetimeractivation
• SpyMode-allowssilenttimeractivationformonitoringothersandvisualstarts
• StopWatchMode–usethetimerasastopwatchtoclockprops,movingtargets,andothershooters.
• CountdownMode
• AlarmClock
• Autoshut-offtoconservebatterydrain
• Aux.jack,forexternalloudhorn,visualstarts,ortargetturningrelateduse
• Self-diagnostictestsystem
• SuperLoudbeepwithvolumecontroladjustment
• RechargeableBatterywithlowbatteryLCDindicator
• Wrist&NeckbandLanyardsincluded
• ResetFunctiondesignedtorestoredefaultsettingsorre-activatethetimer
A table of contents listing each of these features is indicated on the following pages for your easy
reference.
Please read this operation manual completely to familiarize yourself with all the features of the
CED7000 and to ensure reliable operation.
2.
TABLE OF CONTENTS PAGE
*LOCATIONANDFUNCTIONOFKEYPARTS&CONTROLS Cover
*INTRODUCTION 1
Preparation
*BATTERY 4 - 5
Performance Details
Changing battery
LowBatteryIndicator
*OPTIONALBATTERYPACK 5
Operation
*BASICFUNCTIONS 5 - 6
Power On / Off
Automatic Shut-Off mode
Automatic Comstock Mode function
UsingStart/Review
*LCDDISPLAY 6
Display features / Illumination
*MENU/MODES 7
*PROGRAMMINGTHETIMER 7
*DAY/DATE/TIMESETTING 7 - 8
*MEMORYSTORAGE 8
Storing / reviewing strings of recorded data
*CUSTOMPROGRAMMEDFEATURES/FUNCTIONS 9
ReturntoDefaultSettings
*FIXED/RANDOM/INSTANTDELAYSELECTION 9
DelayFeatures/Modeselection
*AUTO-START 9
*SILENTOPERATION 9
VisualStarts
*PROGRAMMABLEPARTIMESELECTION 10 - 11
Selecting, Setting, Canceling Par, Multiple Par
*MULTI-PARTIMESELECTION 11 - 12
*R.O.(RANGEOFFICER)MODE 12
3.
TABLE OF CONTENTS (Continued) PAGE
*REPETITIVEMODE 13
Use&functionofmode
*COMBINEDCOMSTOCKMODE 13
Use&functionofmode
*SPYMODE 14
Use&functionofmode
* STOP WATCH MODE 14
*COUNTDOWNMODE 14
*ALARMCLOCK 15
*SELF-CHECKDIAGNOSTICTESTSYSTEM 15
Use/Function
*AUXILIARYJACKS(AUX) 15
Location/Function
*SHOTDETECTIONMICROPHONE 15 - 16
Microphone-Sensitivityadjustment
*FILTER 16
*BUZZERVOLUME 16
*RESETFUNCTION 16
*RFIDSETTING(onRFmodelsonly) 17
RFremotecapability
*FCC&R&TTECERTIFICATION 17
*AIRSOFTTIMERFEATURES 18
Guarantee 18
Warranty 18
Contact Us 18
Accessories 19 - 20
Related Products Cover
4.
PREPARATION
BATTERY:
The CED7000 functions on an internal rechargeable Lithium battery. The normal life cycle is 25 hours
of use or 33 days of stand-by. This estimate is based on 40 activations per hour or 1000 activations per
charge cycle and may vary with difference usage. The life of the battery should provide 500 to 1,000
re-charges. The full performance of a new battery is achieved only after two or three complete charge
and discharge cycles. The battery can be charged and discharged hundreds of times but it will eventu-
ally wear out. When the usage times are noticeably shorter than normal, it is time to purchase a new
battery.TheCED7000Timerisdesignedtouseaspecicrechargeablebatteryandcharger.ONLY
thespecicbatteryandchargerpackagedwiththeCED7000shouldbeusedwiththetimer.Returnthe
timer to CED or Double-Alpha Academy for a battery replacement. Contact us for prices or visit our
web sites for more details.
To charge the battery, connect the lead from the charger to the DC socket on the bottom of the timer.
Connect the charger to an AC wall socket. If the battery is completely empty, it may take a few minutes
before the charging indicator appears on the timer display. While the timer is charging, an escalating
battery symbol will appear on the right side of the LCD display window. Charging time depends on the
formofcharging.Usingthechargerwilltakeaprx.2hours.UsingtheOptionalBatteryPackwilltake
aprx. 2.5 hours if the timer is not used during this process. An optional Auto Charger is available which
plugsintothevehiclecigarettelighterjack.Chargingshouldtakeaprx.2hoursbythismethod.
Unplugthechargerfromtheelectricalplugandthetimerwhennotinuse.Donotleavethetimercon-
nected to the charger. Overcharging may shorten its lifetime. If left unused, a fully charged battery will
lose its charge over time. Temperature extremes can affect the ability of the battery to charge. Leaving
the battery (timer) in hot or cold places, such as in a closed car in summer or winter conditions, will
reduce the capacity and lifetime of the battery. Always try to keep the battery between 10 C and 32 C
(50Fand90F).ItisIMPORTANTtonotethattheperformanceofbothbatteryandLCDdisplaywill
be particularly limited in temperatures below freezing.
A“BatteryIndicator”isconstantlydisplayedonthetimer’sLCDscreen.Asthebatterydrainspower,
the symbol will turn from all black to clear displaying the amount of battery life remaining. The battery
symbolhasthreelevelsofindication.Full,half,andempty.Whenthebatteryreachesalowcharge
level,thebatterysymbolwillbeginashingindicatingtimetorechargethebattery.Thisprovidesam-
ple warning to charge the battery in order to prevent timer failure due to loss of battery power.
Ifthebatterydrainstoolow,awarningmessage(LowBatteryshuttingofftimer)willappearonthe
LCD display and within 30 seconds of usage, the timer will shutdown. The retention of stored data in
theCED7000willremainintactaslongasthebatteryhasaminimumof3.6V.
5.
BATTERY: (Continued….)
The timer continues to consume a trickle amount of power, even when turned off in order to keep the
internal clock (date / time) functioning and the memory storage intact. A newly
charged battery will provide over 25 hours of normal use and up to 33 days in stand-by or stored
capacity.
Optional Battery Pack:
AnoptionalBatteryPackisavailablethatwillprovideupto25hoursofextendedusefortheCED7000
Timer.Inadditiontoprovidingpowertothetimer,thebatterypackactuallychargesthetimer’sinter-
nalbatteryatthesametime.WhentheBatteryPackisconnectedtothebaseoftheCED7000Timer,
the battery symbol located on the LCD display will show an escalating signal, which informs the user
thattheinternalbatteryischarging.Whentheinternalbatteryisfullycharged,ORthe“AAA”batter-
iesinsidetheBatteryPackaredepletedoftheircharge,ORtheBatteryPackisdisconnectedfromthe
timer, the battery symbol will stop its escalating motion and display a solid battery level instead. If
theinternalbatteryisnotfullycharged,replacethetwo“AAA”batteriesinsidetheBatteryPackwith
fresh ones and re-connect it to the timer for continued charging use. When connected to the CED7000
Timer,theBatteryPackwillfullydepleteitschargingcapabilitieswithin2hours.Atsuchtime,itis
recommendedtodisconnecttheBatteryPackfromthetimer.NotallAlkalinebatterieshavethesame
output. Therefore, depending on the brand and rating, two “AAA” batteries may provide from 50% to
80%ofacompletechargetothetimer’sinternalbattery.
Example:EnergizerX92batteriesprovide80%charge.
OPERATION
BASIC FUNCTIONS:
TheCED7000canbeturnedonoroffbypressing(andholding)the“CLEAR”fora“onesecond”
duration. It is recommended that the Timer be turned off when not in use to conserve battery power.
TheCED7000isdesignedtoautomaticallyshut-offafterapproximatelyfteenminutesifnoinputis
received. The LCD will blank-out, but no loss of recorded input will occur. The user can re-activate
thetimerbypressing(andholdingforonesecond)the“CLEAR”button.
TheCED7000isautomaticallysetin“Comstock”Mode.TheInternationalIPSCRulebookdescribes
thisas:9.2.2“Comstock”:Unlimitedtimestopsonthelastshot,unlimitednumberofshotstobered,
stipulated number of hits per target to count for score.
TousetheCED7000,simplyturnontheTimerandpressoneofthetwo“START”buttonstoactivate
it.Abeepwillsound,(afterathreesecondxeddelay)whilesimultaneouslystartingtheclock.(note
–wheninuse,NOforwardtimeisshownonthedisplayuntilashotisregistered)
EachshotredwillregisterontheLCDdisplayandcontinuetodosouptoamaximumof999.99
seconds.TherearetwoSTARTbuttonsontheCED7000.Therstoneislocatedonthetopendofthe
timer,whiletheotherispositionedonthefrontcenterconsole.Uponcompletionofshooting,theLCD
displaywillindicatethe(rst)1stshotrecorded,thetotalshotsred/receivedandthecumulativetime
recorded. It will also display the Split time. The display also provides the day, month, year, and time,
unless this function is turned off.
6.
BASIC FUNCTIONS: (Continued….)
Toreviewthetimeeachshotwasred,presseitherthe“REVIEW”buttonlocatedonthetopendofthe
timerortheoneonthefrontcenterconsoleandtheLCDdisplaywillreturntotherstshotandtime
recordedinthecurrentstring.Thisprocedurecanbecontinuedthroughoutallshotsrecorded.TheRE-
VIEWfunctioncanbeviewedinforwardorreverseprogressionbyusingtheUP/DOWNDirectional
keys. The memory stores ten strings with up to 39 shots per string at all times. If a string contains more
than39shots,whenstoredtomemory,thetimerwillretaintherst38shotsandthenthe39thshottime
willbetheactuallastshotredinthestring.(Example–Ifthestringcontains44shotsendingat21.23
seconds,whenthestringisstoredintomemory,shot38willappearasredandshot39willappear
as21.23).BypressingtheLEFT/RIGHTDirectionalkeys(wheninREVIEWfunction),theusercan
move from one string to another. There are always the most recent 10 strings maintained in memory.
In addition to the shot number and cumulative time, the split time (difference) between the most re-
cently recorded shot and the preceding shot time will appear on the LCD display. The CED7000 has
thecapabilitytorecordunlimitedshotsred.Thememorywillretaintherst99timesreceived,and
thenreplacethe99thtimewiththelastshottimereceivedthereafter.Whenthe“REVIEW”buttonis
pressedtherstshot/timewillalwaysappear.Youcanthenreviewthrougheachshotrecordedby
pressingoneoftheREVIEWbuttons.
Bypressingthe“START”buttonagain,thetimerautomaticallystoresinmemorythepreviousdata
received and activates the buzzer/timer accordingly. However, the CED7000 is designed to prevent
accidental loss of results. In order to re-activate the “START” button, the “REVIEW” button
must be pressed at least once. An exception to this rule is when the “Combined Comstock” mode
is in use. Refer to “Combined Comstock” section for further details. The user can also override
this function by selecting the “AUTO START – ON” feature from the Menu options
LCD DISPLAY:
The illuminated display provides review of the most recent cumulative time recorded, split-time, par-
time,rst(1st.)shotreceived,andthetotalnumberofshotsred.Italsoindicateswhichstartdelay
mode the timer is set in, the current function mode (event in use) and has a “battery symbol” indicator
whichasheswhenabatterychargeisrequired.
The display will illuminate whenever input data is received or function buttons are pressed. This is
ideal for “low light” or indoor shooting conditions.
7.
MENU / MODES:
The CED7000 Timer has a complete menu of functions / features many of which offer custom pro-
grams,settings,andcapabilitiesthatnoothertimeronthemarkettodayprovides.Belowisalistof
the Menu options:
PROGRAMMING THE TIMER:
Pressthe“MENU”buttontodisplaythefullrangeofsettings&featuresoftheCED7000Timer.In
the center of the timer there are four directional keys with raised edges that provide directional move-
mentwithintheMenuselection.Inthecenterofthesekeysisthe“ENTER”button,whichismarked
withan“E”.The“UP&DOWN”keysallowtheusertoselectasettingorfunctionfromtheMenu,
bymovingthehighlightupordown.The“LEFT&RIGHT”keysallowtheusertoselectasetting
or value within a given mode, or function. Each directional key moves the highlighted selector in the
directionofthekeypressed.Whenavaluehasbeenselected(highlighted),presstheENTERbutton
tostore(conrm)it.Example:PressMENU,presstheDOWNkeyonetimetohighlightPAR,press
ENTER.ThedisplaywillshowhighlightedPAR.PressENTERtoconrmthis.Thedisplaywillthen
highlightthe“0”intheleftmostcolumn.Toset5.3secondsPAR,continuepressingtheRIGHTkey
onetimetillithighlightsthe“seconds”column.PresstheUPkeyvetimestodisplaythenumber“5”
.Then,presstheRIGHTkeyagaintohighlightthe0.10columnandtheUPkeytillthenumber“3”is
displayed.Onceyouhavethecorrecttimeselected,pressENTERtostoretheselectedPAR.
PressENTERtosavedata
PressCLEARtoexitwithoutsavingdata
ToclearanexistingParsetting,selecttheMenu,andthenscrolldowntoCLEARMODEandpress
ENTER.ThiswillclearanyPARsettings,functions,ormodeincurrentuseandreturnthetimerto
Comstock ready mode.
DAY/DATE/TIME SETTING:
SelectfromtheMenu“Time&Date”,pressENTERandthenselectfromthefollowingoptions.“Set
Time”, “Set Date”, or “Display Mode”. Within “Display Mode”, select one of the following time
formats:Date&Time,DateOnly,TimeOnly,orHideAll.If“HideAll”isselected,thedate&time
functions will not be displayed on the timer screen until the user returns to the function and selects one
oftheotheroptions,suchas“Time&Date”.
8.
DAY/DATE/TIME SETTING: (Continued….)
The program allows the user to select time or date only, or to set both which in turn displays each on
a 5 second rotational basis at the bottom of the LCD display window. In setting the time, the user is
given options of either AM / PM and either 12 or 24 hour clock. When setting the date, the month will
appearrst,followedbytheday,andthenyear.Selecting“HideAll”removesbothdate&timefrom
thedisplayscreen,butbothwillremainactivelysetinthetimermemory.ToreturntheTime&Date
to the display, the user must return to the function and selects one of the other options, such as “Time
&Date”.
If the battery charge is depleted, stored data in memory will be lost, and once the timer battery is
charged again, the day, date, time must be reset..
MEMORY STORAGE:
TheCED7000TimerincludesMEMORYSTORAGEthatallowsprevioustimes&splits,numberof
shotsred,andotherdisplayedinformationtoberecalled.Thetimerautomaticallystoreseachsetof
gatheredshots×inaSTRINGandsavesit.Example:TheTimerrecords6shotswithacumu-
lativetimeof3.58seconds.WhenthetimerisrestartedbypressingtheSTARTbutton,thedatafrom
thepreviousset(6shotswithtimesandsplits)isautomaticallysavedasSTRING2.EachnewString
isstoredinmemoryuntilitisfull,atwhichpoint,thetimerdropsofftherststringstored,moving
each remaining string in memory up one position and continues to store into memory the latest string
plus the previous nine ones before it. The timer has the capability of storing up to 10 strings in total,
including the current one, with each string containing as many as 39 shots. The memory will store the
rst38shotsreceivedandthentheLASTshotofthestringifcontainingmorethan38shots.There-
fore,ifastringcontains48shots,thememorystorestherst38shotsredandthenthe39thshotwill
be actually the last shot recorded which in this example is #48. Shot 39,, will always be the last shot
received in the string.
Toreview a previousSTRING ofshots recorded,press theREVIEWbutton, andthen presseither
the right or left directional key to select the desired string from memory storage. Once the string is
selected, the user can review shots within the string by pressing the up or down directional key. The
mostrecently(current)recordedstringwillalwaysbeshownasRecord#1.Thepreviousstringswill
thenbestoredasRecord2throughRecord10.String10wouldthenbetheoldeststringmaintainedin
memory and the next string to be dropped from memory.
Toremove(erase)thestringsfromthetimermemory,selectMEMORYSTORAGEfromtheMenuand
highlightERASEandpresstheENTERbutton.ThetimerwillthenaskyoutoconrmYESorNO.To
eraseALLofthestringsinmemory,highlightYESandpressENTERagain.Thisprocesswillerase
all memory stored in the timer. This feature is ideal when sharing the timer with someone else during
practice as it allows each user to record into memory only their own shooting results.
9.
CUSTOM PROGRAMMED FEATURES / FUNCTIONS:
The CED7000 Timer has a large range of custom programmable features and functions. The timer
is designed to retain all customized settings even after being shut off. The user can reset the timer to
theoriginaldefaultsettings,byselectingfromthemenu“DEFAULTSETTINGS”andthenselecting
“YES”,whichwillreturnthetimertotheoriginalfactorysettings.
FIXED / RANDOM / INSTANT DELAY SELECTION:
The CED7000 provides four types of start delays. A “Fixed”(F)three-seconddelayfromthetimethe
STARTbuttonispressedtotheactivationofthebuzzerandclock,providessufcienttimeforprepara-
tion and standby. A “Random”(R)delayprovidesarandomlyselected“twotove”seconddelay,
designed to eliminate any anticipation during individual practice or competition use.
An “Instant Go” (I) enables total control for the user by activating the timer instantly upon pressing
theSTARTbutton.Additionally,theusercanchooseacustomdelay,byselectingthe“Custom” (C)
settinginthepreferencemenuandenteringaspecicdelayupto9.9seconds.
Toselecta DELAY,press MENUand highlightDELAY andpress ENTER.Scroll upor downto
selectthedesireddelay(FIXED,RANDOM,INSTANT,CUSTOM),highlightit,andpressENTERto
conrmit.IfaCUSTOMdelayisselected,thedisplaywillthenshowtheusertwodigits(0.0).Press
the“right”keytohighlighttherstdigitandthenscrollupordowntoselectavaluefrom1to9and
thenpressthe“right”keytohighlighttheseconddigit(.0)andselectavalueforit.Thenconrmthe
timesetbypressingENTER.
AUTO-START:
TheCED7000TimerprovidestheabilityforreactivatingthetimerwithoutpressingtheREVIEWbut-
tonrst.Todisablethissafetyfeaturedesignedtopreventfalsestartsorlossofdata,scrollthroughthe
programmenuhighlightingtheAUTO-STARTmodeandpressENTER.Select“ON”andconrmit
bypressingENTERagain.WhenAUTO-STARTisactivated,theCED7000timerwillrestarteachand
everytimeeitherSTARTbuttonispressed.TodeactivateAUTO-START,followtheaboveprocedure
selecting“OFF”.
SILENT OPERATION:
TheCED7000TimercanbeusedforCowboyFastDrawandotherapplicationswhereavisualstart
insteadofsoundisrequired.Inselectingthisfunction,theCED7000timeractivatesquietlybutstill
producesa5.0Voutputfrom itsAUX jackallowing avisual startsignal tobe synchronizedto the
timer.Allotherfunctionsremainasnormal.SelectMenu,scrolldowntoSILENTOPERATIONand
highlightONorOFF.ThenpressENTERtoselectthemodepreferred.
10.
PROGRAMMABLE PAR TIME SELECTION:
AsinglePARtimecanbesetallowingtheusertocreateaxedintervaloftime.Selectionofa“Par
time”from0.60to999.99secondscanbeaccomplishedwiththeCED7000.(Note:Partimecanbe
settothe1/100thseclevel)SincetheSTARTbuzzerdurationbeepsfor0.50seconds,theminimum
PARtimeacceptedbythetimeris0.60seconds.ToselectaPARtime,pressMENU.Scrolldown
toselectthe“PAR”mode,highlightit,andpressENTERtoconrmit.SelectPar(forasinglePar
setting),CustomPar(forupto11PartimestobeactivatedoneafterthenexteachtimertheSTARTis
pressed), Auto Par (for up to 11 Par times and 11 delay times to be run automatically from one activa-
tion),orMultiplePar(torunupto5Partimesfromonesingleactivation)andpressENTERagain.
Pressthe“right”keytohighlighttherstcolumnandthenscrollupordowntoselectavaluefrom0
to 9 and then press the “right” key to highlight the second column and select a value for it and so on
untilallvevaluecolumnsareset.OncethedesiredPartimeisdisplayed,thenconrmthetimeset
bypressingENTER.
Toactivatethetimerandtheselected“Partime”,simplypresstheSTARTbutton.Asecond“stop”
beep will occur at the selected “Par time”. The timer will continue to record shots even after the se-
lectedPartimehaselapsed.Thisallowsaccuratereviewofalllateshotsandtheirexacttimered.
When in PAR time mode, the second beep will sound at the exact pre-set time for a 0.30 second
duration.
(Example – If a 5.00 second PAR time is selected, the PAR time is counted from the instant the
buzzer begins sounding (zero time) with the nal 0.30 second beep sounding precisely at 5.00
seconds, ending at 5.30 seconds total time)
TheCED7000timeralsofeaturestheabilitytobeprogrammedwithuptoelevenmultiplePARtimes
aswellasmultipledelayintervals.Additionally,eachPARtimeanddelayintervalcanbesettodiffer-
ent time lengths. When programming strings in Custom or Automatic Par, the user can clear values for
anystringshownonthedisplaybypressingtheCLEARbuttononce.IftheCLEARbuttonispressed
twice, it will erase all values set for the Par selection.
When in “Custom Par”, only the Par times are set for the number of desired strings up to a maximum
ofeleven.TheuserthenactivatesthetimerbypressingtheSTARTbutton,whichinturnrunseach
selectedParstringindividually.Theusermustre-presstheSTARTbuttontoactivatethenextstring,
but the timer moves forward to the next programmed Par each time it is activated until it completes all
strings programmed.
InAUTOMATICsetting,bothPARandDELAYtimesareselectedforanumberofstringsuptoa
maximumofeleven.OncetheSTARTbuttonispressedandthetimeractivated,itwillrunALLstrings
programmed automatically until completed.
Example:
String1PAR 3.00sec.
Delay 2.00 sec.
String2PAR 5.00sec.
Delay 3.00 sec.
String3PAR 6.50sec.
11.
PROGRAMMABLE PAR TIME SELECTION: (Continued….)
The example above shows that three Par strings were programmed to function consecutively, each
with a different Par time and a different delay between each Par setting. The timer will begin after the
presetdelay,withtherstPartimeof3.0seconds,followedbya2seconddelay.EachnewPartime
stringwillbeginwiththebuzzerandclockcountingfromZEROandthebuzzerresoundingattheend
of selected Par time, followed by the given delay (if any is set) and then the starting of the next Par
stringandsoonuntilthelastPartimestringprogrammedhasbeencompleted.TheuserMUSTselect
bothaPar&DelaytimebeforepressingtheENTERtostorethedata.No Delay time should be set
for the last Par time selected.
PLEASE NOTE: A programmed function may be stopped (interrupted) at any time during the running
oftheprogrambypressingtheREVIEWbutton.Thetimerthenproceedstothenextstring.Ifthe
userwishestorepeattherststringagain,pressCLEARbuttontwice,whichreturnsthetimertothe
rststringPar/delay.Iftheuserthenwantstomoveforwardtothenextstring,withoutrunningthe
rststring,presstheSTARTbutton,followedbytheREVIEWbuttonBEFOREthecountdowndelay
reacheszero(thiswillnotworkinINSTANTdelay).Thiswillprogressthetimerforwardthroughthe
automaticParsequencesonebyone.
MULTI- PAR TIME SELECTION:
Thisinnovative feature givestheuser astring ofupto vepossible Parbeepsbased ononetimer
activation only. The user can set Par times to the hundredth of a second for precise practice use. This
functionisexcellentfordryrepractice,draws,reloads,andtransitionalmovement.
Foruse,selectPARandthenscrolldownandselect“MULTI-PAR”,highlightit,andpressENTERto
conrmit.TheuserwillseeMulti-Par1with00.00totherightifit.Pressthe“right”keytohighlight
the desired column and then scroll up or down to select a value from 0 to 9 and then press “right” key
to highlight the next column and select a value for it and so on until all four value columns are set.
PressENTERtoconrmthesettingandadvancetothenextMulti-Parsettingtobeselected.The
timerallowsuptovePartimestobeselectedandenteredinMulti-Par.OnceALLofthedesiredPar
timeshavebeenselectedandentered,thenconrmthetimessetbypressingENTERagain.Dueto
thedurationoftheSTARTandPARbeeps,therstPar(inMulti-Par)cannotbesetforlessthan0.60
sec.,witheachsubsequentParbeingnotlessthan0.40seconds.
Example: Minimum allowed setting due to beep duration
P1= 01.00 00.60
P2= 01.25 00.40
P3= 01.20 00.40
12.
MULTI- PAR TIME SELECTION: (Continued….)
(The above example shows three Par times being activated by a single start beep. A total of four beeps
willbeemittedfromthetimer.OneSTARTbeepandthreePARbeepsattheintervalsselected.Each
PARtimeenteredwillbebasedfromthepreviousone.Thereforeintheaboveexample,fromthetimer
activation (start beep), the next beep will begin at 1.0 second, followed by another beep starting at 2.25
seconds,withthenalbeepstartingat3.45seconds.)
Toactivatethetimerandtheselected“Partimes”,simplypresstheSTARTbutton.Asecond“stop”
beep will occur at EACH of the selected “Par times”. The timer will continue to record shots through-
out the entire process, even after the selected Par times have elapsed. This allows accurate review of
allshotsandtheirexacttimesred.Thisselectedprogrammingwillremainactiveuntilcleared.This
allows the user to practice a given selected drill over and over again.
PLEASE NOTE: When using Multi-Par, the timer display will indicate the multiple Par 1 value as
thePAR timeon thedisplay andshow themode (MULTI-PAR1) in thelower displaymatrix area.
Once the timer is activated and as each Multi-Par setting progress, the current value will appear on the
display in an ongoing progression.
(When in a PAR time function, ALL (Par) beeps will sound at the exact pre-set time for a 0.30 sec-
ond duration! Note, that when in Multi-Par, a maximum Par time of 99.99 seconds is allowed)
ToclearanexistingParsetting,selecttheMenu,andthenscrolldowntoCLEARMODEandpress
ENTER.ThiswillclearanyPARsettings,functions,ormodeincurrentuseandreturnthetimerto
Comstock ready mode
R.O. (RANGE OFFICER) MODE:
DesignedforRangeOfcerswhowanttouseatimerformatchorinstructorpurposesanddesireonly
basic operation without additional features. When selected, the timer Menu only shows the follow-
ingbasicfunctions.DELAY,SINGLEPAR,&SENSITIVITY.Theusercanselectthedelayoption
desiredandadjustsensitivityandsetasinglePartime.ThetimerwillthenallowSTART&REVIEW
functionsand the displaycontinuesto show allinformationas normal. ALL OTHERFEATURES
ANDFUNCTIONSOFTHISTIIMERAREHIDDENANDINACTIVEWHENINROMODE.To
activate:SelectMenu,andscrolldowntohighlightROMode–pressENTER–HighlighteitherON
orOFFandpressENTER.
13.
REPETITIVE MODE:
Thisadvanced featureoftheCED7000isidealforPPC,UIT,Police,&Militaryqualicationtype
courseswhereaseriesofsimulated“exposures”atxedintervalsarerequired.Thisfunctionsimulates
theeffectofaturningtargetsystemwherethe“Face”and“Edge”timesareselectedbytheuser,aswell
as the desired number of times it is to be repeated.
SelectMODEfromtheMENUandthentheREPETITIVEMode.TheuserthenselectsagivenPAR
time,followedbyaspeciedEDGEtimeandthenthenumberoftimesitistobe
repeated.Usetheright/leftdirectionalkeystomoveforwardorbackwardandtheup/downdirectional
keystoselectvalueforeachsetting.KeepinmindthattheselectednumberofREPEATSisaddedto
therstactivation.Therefore,if3repeatsareselected,thetimerwillruntherstPartimeandthen
repeatitthreetimes,makingatotalofFOURPar(Face)times.
Thestartoftheselected“Face”periodisindicatedbythepressingofthe“Start”buttonandthesound-
ingofthebuzzer.IftheAuxiliaryjackisinuse,a5.0voltD.C.impulsewillbeemittedindirectsyn-
chronization with the buzzer, which allows the user to activate a real turning target replay if so desired.
At the end of the set Par time, the buzzer (and 5.0 volt impulse if in use) will beep for 0.30 seconds
indicatingtheendofthe“Face”period,andthebeginningofthe“Edge”period.Aftertheselected
EDGEtimeexpires,thesequencewillstartagain,andcontinuedoingsountilithascompletedthefull
amount of repeats that have been pre-set into the timer.
The“Repeats”willbedisplayedintheSTRINGcolumnduringthe“Edge”time,whichinturnwill
displayasacountdowninthesamefashionasanormaldelaydoes.Duringthe“Face”time,thetimer
will display shots received in the SHOT column.
* A programmed function may be stopped (interrupted) at any time during the running of the
program by pressing the REVIEW button. However, pressing the REVIEW button will return
the program to the beginning.
COMBINED COMSTOCK MODE:
The CED7000 features the ability of combining several “Comstock” scores cumulatively. Designed
forsituationswheretheuserwantstoaddthetimeoftwoormorestringstogether,butrequireseparate
start beeps. When the Timer is set in this mode, it will restart from the exact time and number of shots
last displayed on the timer prior to restarting it and will continue to accumulate both from that point
onward. The user can re-start the timer as many times as desired, with each new start resulting in a
continuedcumulativeshotandtimerecording.Tore-startthetimerfromzero,pressthe“CLEAR”but-
tonTWICE.Toendthe“CombinedComstock”function,enterthepreferenceMENU,selectMODE,
and then select “COMSTOCK” & press enter or select CLEAR MODE from the Menu and press
ENTER.Thiswillclearanysetting,function,ormodeincurrentuseandreturnthetimertoComstock
ready mode.
14.
SPY MODE:
DesignedtoallowtheusertoSPYonandtolearnfromothershooters.Whenthe“SpyMode”isse-
lected, the timer will switch automatically to “Instant Start” activation, and will turn up the sensitivity
to level 7. Additionally, the buzzer will not sound when the timer is activated. When in this mode,
theParfunctionisdisabledsincethereisnobeepsound,PressingtheSTARTbuttonwillsilentlyand
instantlyactivatethetimer,allowingtherecordingofshotsredinlocalproximityofthetimer.The
higher sensitivity level setting will enable the timer to pick up shots from a greater distance enabling
theusertorecord(monitor)anothershooter’sperformance.Iftheuserdecidesagreaterorlesserlevel
of sensitivity is needed, the setting can be manually changed by following the directions outlined in the
“SHOTDETECTIONMICROPHONE”sectionofthisinstructionmanual.
Thismodeisalsoperfectlysuitedfora2ndROonthestagetocreateabackuptimeonhisowntimer.
PLEASE NOTE: In this mode, the timer may also pick up other interferences as well due to the
heightenedsensitivitysettinglevel.Insomecaseswhereastageofremayinvolvelongdistances,the
timer may fail to register all shots due to the distance and sensitivity limitations.
STOP WATCH MODE:
Manytimesashooterwishestomeasureonastageofre,thetimingsequencesandmotionoftargets,
props, positions, as well as the transition times between various points of reference. Sometimes, it is
simply clocking the times of other shooters being watched. The CED7000 provides this function with
its built-in Stop Watch mode. When selected, the CED7000 timer acts as a Stop Watch. When in this
mode, both the microphone and buzzer on the timer are disconnected and will not function. To activate
theStopWatch,onceintheStopWatchmode,simplypresstheSTARTbutton.Theclockwilldisplay
itsrunningtimeintheTIMEareaofthedisplaywindow.ToeffectLaps,presstheREVIEWbutton
for each lap time desired. The Lap number will display in the SHOT area on the display window and
the lap time in the SPLIT area.
Tostopthetime,presstheSTARTagain.Tothenreviewthelaps,presstheREVIEWbutton,which
displayseachlap,itsnumberandtime.Toclearalltimesandlaps,presstheCLEARbuttononce.If
theSTARTbuttonispressedathirdtimewithoutclearingthedatastored,theinternalclockwillcon-
tinue running within the previous string displaying the current cumulative time from the original start
point. All lap data will be retained as part of the previous / current string until cleared.
COUNTDOWN MODE:
InCountdownMode,uponSTARTactivation,theCED7000Timerwillbeepandbegincountingdown
backwardfromanyselectedPARtimetozeroatwhichpoint,itwillbeepagain.ToactivateCount-
downmode,presstheMENUbutton,thenMODEandENTER.ScrolldownandhighlightCOUNT-
DOWN,pressENTERagain.CountdownModewillfunctionwithanydelaysetting,however,aPar
timeMUSTbeenteredtofunction.
PLEASE NOTE - The timer will NOT record shots or accept input data while operating in this
mode.
(This function is ideally suited for the National Shooting Complex “Sportsman’s Team Challenge
National Championship” or similar types of events. Ideal for controlling time-restricted match
stage walk through times)
15.
ALARM CLOCK:
TheCED7000allowstheusertoprogramasettimetobeawakenedornotiedat.Noneedtobelate
forascheduledappointment,orinreturningtoamatchstageafterlunch.ToprogramtheALARM
CLOCKontheCED7000,the“DAY/DATE/TIMESETTING”mustrstbeprogrammedandactive.
See that section of this instruction manual for details.
SelectMENU,andthenscrolldowntoALARMCLOCKandpressENTER.Foursegmentswillap-
pear“00.00”representinghour&minute.Presstherightdiagonalbuttonmovingthecursortoeach
segment. Press the up/down diagonal button to select a given time. Continue pressing the right direc-
tional button after the time has been set to advance to AM / PM. Highlight either AM or PM and press
ENTERtosetthetimeselected.Ifthetimehasbeensetina24-hourformat,noAM/PMwillappear.
TheuserhastheabilitytoturnonoroffthisfunctionbythenhighlightingONorOFFandpressing
ENTER.Thetimeselectedwillremainuntilchangedallowingtheusertoactivatethefunctionnumer-
ous times without changing the time details. When the selected time is reached, the timer will produce
short loud beeps until turned off. To “turn off” the Alarm Clock function once activated, simply press
eitherSTARTbutton,whichinturnsilencesthetimerandturnsofftheAlarmClockfunction.
PLEASE NOTE: The Alarm Clock function operates on a 12 or 24 hour standard, based upon what
hasbeenpresetinthetimers“DAY/DATE/TIMESETTING”.TheAM/PMfunctiononlyoperates
whenthetimerissettoa12hourstandard.If24hourstandardisineffect,theuserMUSTenteran
appropriate time ranging from 1 to 24 hours.
SELF-CHECK DIAGNOSTIC TEST SYSTEM:
The CED7000 incorporates a self-check diagnostic test program enabling the user to check systemati-
callyifthetimerisfunctioningproperly.Thisprovidesadditionalqualitycontrolwithfast,andeasy
self check capabilities in case the timer has been dropped or possibly damaged in some way. Select
“Self-Check”fromtheprogramMENUandpressENTER.Theprogramwillthengivetheuserin-
structions to be followed, which will in turn test each button, key, and the LCD display segments for
possible damage. When completed, if all parts and functions are operational, the program will indicate
that the diagnostics have been completed. If a button or key function is defective, the program will not
continueindicatingtotheuserthatrepairisrequired.IftheLCDdisplayisdamaged,theuserwillbe
able to visually see broken segments during the diagnostics program.
AUXILIARY JACK (AUX.):
Anauxiliaryoutputjackislocatedonthebottomendofthe CED7000.Whenamalejackplugis
inserted(3.5mmmonoplug),a5.0voltDCcurrentisemittedinexactconjunctionwiththebuzzer,
matchingthedurationofthebeep.WhenthePARtimesettingisinuse,theimpulseemittedatthe
completion of Par matches that of the buzzer sound exactly. This feature can be utilized to operate a
remote, self-powered buzzer, external horn (see the CED2000), light, loud-speaker, or a low-voltage
relay for target turning applications.
SHOT DETECTION MICROPHONE:
A high sensitivity microphone is used in the CED7000 to insure accurate recording of shots. A digital
“sensitivityadjustment” range settingallowsfor “netuning” ofthetimer tounusualenvironment
conditionssuchashighberms&backstops,smallindoorranges,ordensefogconditionswheregun
recanresultinunusualamountsofecho’sbouncingbackatthetimer.
16.
SHOT DETECTION MICROPHONE: (Continued….)
Thedigitalnumberedsettings(1to8),provideaexiblerangeofadjustmentofthemicrophonewhen
needed, depending on the shooting location and conditions. (1 = least sensitive / 8 = most sensitive).
Toadjustthesensitivity,selectMENU,thenSENSITIVITY,andthenscrollupordownusingtheDi-
rectional buttons to select the desired sensitivity level
The CED7000 shot-detecting microphone is software designed and factory preset at a mid level
range (4) that provides accurate function under most normal types of outdoor conditions. How-
ever, due to various changes in range conditions, climates, and locations, it is strongly recom-
mended to test your timer on the range it is to be used, prior to competition use, to insure it is
properly set. This will eliminate any chance of recording errors!
Always hold the timer with the front panel facing the Shooter! The microphone is located on
the upper front panel, positioned under the display screen and should have direct, clear line-
of-sight to the Shooter. In cases where a person is shooting around walls, or other objects, the
timer should be held in a manner that provides unobstructed view to the person shooting. The
Range Ofcial should be careful not to cover the microphone, or allow ejected cases to hit the
timer during recording. Ideally, the timer should be within six feet of the person ring the shot
to be recorded.
FILTER:
TheCED7000comeswithafactorypresetdefaultsoftwareltersetat8/100ofasecond.Therefore,
thetimerwillonlyrecordshotsasfastas9/100ofasecond.Thislterisdesignedtopreventunwanted
echo sounds, which cause erroneous recordings on timers. However, the CED7000 allows the user to
customadjustthesoftwarelterfrom9/100downto2/100ofasecondoranylevelinbetween.Such
adjustmentsmodifytheCED7000allowingthetimertodetectshotsasfastas33shotspersecondor
upto1,980shotsperminute.Toadjusttheltersetting,selectMENU,andthenFILTER,andusethe
directionalbuttonstoselectthedesiredamountoftimetobeltered.
BUZZER VOLUME:
The CED7000 is set with two volume levels for the buzzer beep. The normal one is a loud medium
tohighfrequencybeepinexcessof110db.SelectingtheSOFTsettingwilllowerthefrequencyand
dblevelbyaprx.50%.Thissettingisperfectforhomedryrepracticeandotheruseswherealoud
sounding beep is not desired.
RESET FUNCTION:
On the backside of the timer housing in the upper right hand corner, there is a small hole with the word
RESETunderit.Ifforanyreason,thisCED7000Timershouldfreezeup,goblankduringcharging,or
incur any other unforeseen problem, it is possible to reset the timer, which in doing, should resolve the
problem incurred. To reset the timer, use a small paperclip, straightening one end of it and inserting it
directlyintothesmallRESEThole.Continueinsertingthepaperclipuntilitcomesincontactwiththe
micro-switch.SLIGHTLYpressforward,untilthecontactswitchactivatesresettingthetimer.Iffor
any reason, the timer does not reset returning the function to normal operation, it should be returned to
CompetitiveEdgeDynamicsUSAforservicingand/orreplacementifunderwarranty.
17.
RFID SETTING:
IfthisCED7000TimerhasbeenpurchasedwiththeoptionalRFcapabilityfunctionforusewiththe
CEDBigBoardorCEDTimerKeeper,thefollowingsectionwillprovideinformationforlinkingthe
timertoaspecicCEDBigBoardorCEDTimeKeeper.
TheCED7000TimercanbeorderedwithanoptionalRFwirelessremotetransmitter(CED7000RF),
whichhasanunobstructedbroadcastrangeof30to50yardstoeitheraCEDBigBoardorCEDTime
Keeper.
Tolink(synchronize)a“CED7000RF”timertooneoftheseotherCEDproducts,presstheMenubut-
tonandscrolldowntoRFID.Selectafour-digitnumberofyourchoiceandenteritintothetimer.
ThenenterthesamenumberintoeithertheCEDBigBoardorCEDTimeKeepertobelinkedwith.
Once completed, the CED7000 timer will transmit recorded times instantly to the linked unit as they
arerecordedonthetimer.TheCEDTimerKeeperwillalsodisplaythenumberofshotsandthesplit
times as well.
IMPORTANT: North American laws governing RF frequency transmissions differ from those
in Europe and Africa and as a result of this, the RF frequency allowed for use in these regions
is different. All CED7000RF Timers, CED Time Keepers and CED BigBoard Displays sold in
North America are sold with 314 MHz frequency chips. Those sold in Europe come with 434
MHz. These two frequencies are NOT compatible and they will not allow proper transmission
when mixed.
FCC & R&TTE CERTIFICATION / INFORMATION:
ThisdevicecomplieswithPart15oftheFCCRules.Operationissubjecttothefollowingtwocondi-
tions: (1) This device may not cause harmful interference, and (2) This device must accept any interfer-
ence received, including interference that may cause undesired operation.
Warning:Changesormodicationstothisunitnotexpresslyapprovedbythepartyresponsiblefor
compliancecouldvoidtheuser’sauthoritytooperatetheequipment.
NOTE: This equipment has been testedand found to comply with the limits for a Class B digital
device,pursuanttoPart15oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotec-
tionagainstharmfulinterferenceinaresidentialinstallation.Thisequipmentgenerates,usesandcan
radiateradiofrequencyenergyand,ifnotinstalledandusedinaccordancewiththeinstructions,may
cause harmful interference to radio communications. However, there is no guarantee that interference
willnotoccurinaparticularinstallation.Ifthisequipmentdoescauseharmfulinterferencetoradioor
televisionreception,whichcanbedeterminedbyturningtheequipmentoffandon,theuserisencour-
aged to try to correct the interference by one or more of the following measures:
*Reorientorrelocatethereceivingdevice.
*Increasetheseparationbetweentheequipmentandreceiver.
*Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiver
is connected. (if an outlet is used)
*Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
18.
CED7000A AIRSOFT TIMER:
CEDhasintroducedanewAIRSOFTTimermodel.Thismodelfeaturesamodiedmicrophoneand
buzzersystem.ItisNOTdesignedforlivereuse.Themicrophoneistoosensitiveandthetimermay
pickupadditional“echo”sounds,whichwouldthenprovideinaccurateinformation.TheAIRSOFT
Timerwhenadjustedtolevel7orlevel8ontheSENSITIVITYADJUSTMENT,willallowthetimer
to “pick up” the sounds of MOST Airsoft pistols. At these two level settings, the db level output of the
buzzerisreduced(lowered)topreventthesoundfromactivatingthetimerwith“false”echo’s.The
timercomeswithaplasticlmcoveringtheLCDdisplayandthemicrophonetrimplate.Thislm
covershouldberemovedbeforeuse,HOWEVERITMUSTberemovedBEFOREusingthetimerat
levels7&8.Ifnotremoved,thetimerwillpickupfalserecordingswhenactivatedfromthebuzzer’s
vibrating sounds.
GUARANTEE
**30DAYMONEYBACKGUARANTEE**
The CED7000 was designed to provide the optimum Timer at an affordable price. We want you to be
completelysatisedwithourproduct.Ifyouarenotsatised,simplyreturnittouswithreceiptof
purchase, in undamaged condition within 30 days for a full refund of the product cost. The Guarantee
doesnotincludeS&H.
WARRANTY
**TWOYEARLIMITEDWARRANTY**
If the CED7000 breaks due to defective parts or workmanship, we will replace it for you within the
rsttwoyears.Thiswarrantydoesnotcoveranyfailuresattributabletoabuse,mishandling,failingto
follow operating instructions, alterations, or accident. If you accidentally break it, we will repair it at
cost for you. All claims must be accompanied by the original sales receipt or written proof of purchase,
and be returned in a properly packaged manner with shipping charges prepaid. We are proud of our
product and we want you to be too.
Returns or warranty service should be directed through your purchase location (for refund) or di-
rectlytoCompetitiveEdgeDynamicsinNorthAmericaandAsia(forservicingorreplacement)orto
Double-AlphaAcademyinEuropeandAfrica(ONLYIFYOURTIMERWASPURCHASEDFROM
ADEALERINEUROPEORAFRICA)..Ifyoushouldencounteranyproblemsorwishtocorrespond
on any matter, please write or fax to one of the following locations with details of the problem and if
needed, a return authorization will be provided.
Visit CED Web Site at: www.cedhk.com
Visit Double-Alpha Academy’s website at: www.doublealpha.biz
In North America:
Competitive Edge
Dynamics, USA
P.O. Box 486,
Oreeld, PA 18069-0486
Phone: (610) 366-9752
Fax: (610) 366-9680
Email: [email protected]
In Asia
Competitive Edge
Dynamics Ltd.
GPO Box 10590
Central, Hong Kong
Phone (852) 2866-6802
Fax: (852) 2866-6505
In Europe and Africa,
Double-Alpha Academy
Waalwijk, The Netherlands
Phone: (31) 416 660 464 /
GSM: (31) 652 661 442
FAX: (31) 416 392040
Email: [email protected]
This manual suits for next models
2
Table of contents
Other CED Timer manuals
