cef Quad Pod User manual

The Quad Pod
Assembly Instructions
KIDS
Our Customers. Our Inspiration.
We should all try to be more like them

Components
What’s in the Box!
Connector Plate (1)
STEEL BASE (1)
1) 12 ¼”-20 serrated bolts
2) 16 ¼”-20 decorative bolts
3) 4 casters
TOOLS: WHAT YOU WILL NEED
*STANDARD PHILIPS HEAD SCREWDRIVER
* #4 STANDARD ALLEN WRENCH

Let’s Get Started!
1
2
THE 4 PODS WILL NEED TO BE PLACED FACE
DOWN INITIALLY TO ATTACH THE CONNECTOR
PLATE AND STEEL FRAME
BEFORE GETTING STARTED, IT IS IMPORTANT
THAT ALL “POD” DOORS WILL OPEN TO THE
RIGHT AS SHOWN ONCE PLACED UPRIGHT

3
4
WHEN ALL FOUR PODS ARE UPSIDE DOWN ,
THE ALIGNMENT OF THE BOLT HOLES SHOULD
LOOK AS SHOWN
THIS WILL ENSURE THE CONNECTOR PLATE
LINES UP WITH THE PRE-DRILLED HOLES
PLACE THE CONNECTOR PLATE OVER THE
INTERSECTION WITH THE OPEN BOLT HOLES
USE 4 DECORATIVE BOLTS AND INSERT THEM,
TIGHTEN WITH #4 ALLEN WRENCH

5
6
AFTER THE FRAME IS ALIGNED CORRECTLY WITH
THE HOLES USE 4 DECORATIVE BOLTS TO
ATTACH. TIGHTEN WITH THE STANDARD #4
ALLEN WRENCH
ONCE THE CONNECTOR PLATE IS ATTACHED,
PLACE THE STEEL FRAME OVER THE PARAMETER
OF THE 4 PODS SO THEY ALIGN WITH THE BOLT
HOLES IN EACH CORNER

7
8
LINE THE THREE HOLES ON THE CASTER UP WITH
THE STEEL FRAME AS SHOWN
WITH THE (12) SERRATED BOLTS, ATTACH THREE
PER CASTER AND TIGHTEN WITH ALLEN WRENCH
AFTER BOLTS ARE TIGHTENED, LOCK THE
CASTERS IN PLACE BEFORE FLIPPING THE CART
THE CORRECT SIDE UP
TAKE THE BUTCHER BLOCK OUT OF ITS BOX AND
PLACE IT OVER THE 4 PODS
THE ELECTRICAL WILL BE ATTACHED ALREADY
AND SHOULD BE PLACED DIRECTLY OVER THE
CENTER SQUARE
THE TRASH BIN HOLE WILL LINE UP WITH THE
CHOSEN TRASH HOLE IN THE PODS

9
10
BEFORE BOLTING DOWN THE TOP, RUN THE
ELECTRICAL CORD THROUGH THE MIDDLE
SQUARE AS SHOWN
INSERT (8) DECORATIVE BOLTS TO ATTACH THE
BUTCHER BLOCK TOP TO THE 4 PODS
(4) DECORATIVE BOLTS WILL BE INSERTED
AROUND THE ELECTRICAL
(4) DECORATIVE BOLTS WILL BE ATTACHED ON
EACH CORNER OF THE PODS
TIGHTEN WITH STANDARD #4 ALLEN WRENCH
