Central Machinery 41889 Quick reference guide

16” Variable Speed
Scroll Saw
Model 4188941889
4188941889
41889
Assembly & Operating Instructions
Copyright 1999 by Harbor Freight Tools®.All Rights Reserved.
No portion of this manual or any artwork contained herein may be reproduced in any
manner, shape or form without the express written consent of Harbor Freight Tools.
For technical questions and replacement parts, please call 1-800-444-3353.
www.HarborFreight.com
Brought to You by Augusta Flint

ElectricMotor: 380 - 1500 RPM variable speed
110V/60Hz,double insulated
BladeSpeed: 350 to 1400 spm, variable speed
BladeLength: 5”,pintype
ThroatDepth: 16”
Max.StockThickness: 2-1/4”
TableDimensions: 16-1/4”L x 10”Wtapered x6-7/8”H
TableAngleSetting: 0O- 45Oin1Oincrements
PowerCord: 78”, UL approved, 3-wiregrounded
PowerPlug: CSA-approved,3 prong grounded
PowerSwitch: CSA-approved
OverallDimensions: 16-5/8”L x 12-1/8” W x 25-1/4”H
Weight: 26.8 Lbs.
MODEL#4188916” SCROLLSAWSPECIFICATIONS
INCLUDEDACCESSORIES
1. 2.5mm,3mm,4mmLHexWrenches
2. BladeAdapters
3. PinBlade
PRODUCT FEATURES
1. Highpowered, variable-speedtool deliversimpressivewoodcutting power.
2. Double insulated construction, with 18 Gauge UL approved power cord.
3. Easilyadjustabletableangle, withscaleforaccuratemeasurement.
4. Built inblowerkeepsbladeclean,andaffords clearviewofcutting operation.
5. Uses readily-availablestandard5”pin blades.
SAVETHISMANUAL
Youwillneedthismanualfor thesafetywarningsandcautions,assemblyinstructions,operatingprocedures,
maintenanceprocedures,troubleshooting, partslist,anddiagram.Keep yourinvoicewiththismanual.
Writethe invoicenumberonthe insideofthe frontcover.Keep boththismanual andyourinvoicein asafe,
dryplacefor futurereference.
Page 2 SKU # 41889
NOTICE
The Warnings, Cautions, and Instructions discussed in this instruction manual cannot
cover all possible conditions and situations that may occur. It must be understood by
the operator that common sense and caution are factors which cannot be built into this
product, but must be supplied by the operator.
Brought to You by Augusta Flint

SAFETY WARNING & CAUTIONS
1. KEEPWORKAREACLEAN. Clutteredareasinvite injuries.
2. OBSERVEWORKAREACONDITIONS. Donot usetools indamp, wet,or poorlylit locations.
Don’texpose torain.Keep workarea welllit.Do notuse electricallypoweredequipment inthe
presenceofflammablegases orliquids.
3. KEEPCHILDRENAWAY. Childrenmust neverbe allowedin theworkarea. Donot letthem
handlemachines,tools,or equipment.
4. STOREIDLE EQUIPMENT.Whennotin use,tools mustbelocked upin adrylocation toinhibit
rust.Always lockup toolsand keepoutof reachof children.
5. DO NOTFORCE THETOOL. Itwilldo thejob betterand moresafely at therate forwhich it
wasintended. Donotuse inappropriateattachments inanattempt toexceed thetool’s capacities.
6. USE THERIGHT TOOLFOR THE JOB.Do notuse atool for apurpose forwhich itwas not
intended.
7. DRESSPROPERLY. Donot wearloose clothingorjewelry, asthey canbecaught inmoving
parts.Non-skidfootwearisrecommended.Wear restrictivehaircovering tocontainlong hair.
Alwayswearappropriate workclothing.
8. USE EYE,EARAND BREATHING PROTECTION.Always wearANSI approvedimpact
safetygoggles ifyouare producingmetalfilings orwoodchips.WearanANSIapproved dustmask
orrespirator whenworkingaround metal,wood, andchemicaldusts andmists.UseANSI
approvedearprotection whenworkingina loudornoisyenvironment.
9. DO NOTABUSETHEPOWER CORD.Protectthe powercord fromdamage, either from
impacts,pullingor corrosivematerials.Donot yankmachine’scord todisconnectitfrom the
receptacle.
10. DO NOTOVERREACH. Keep properfooting andbalance atall times.Donot reachover or
acrossrunningmachines.
11. MAINTAINTOOLSWITHCARE. Keeptools sharpand clean forbetter andsafer performance.
Followinstructionsforlubricating andchangingaccessories.Inspectpowercord periodicallyand,if
damaged,haveitrepaired byanauthorizedtechnician.Inspect allmovingpartsandmounting bolts
priortouse.Control handleandpowerswitchmustbe keptclean,dry,and freefromoilandgrease.
12. REMOVEADJUSTING KEYSANDWRENCHES. Besure thatkeysandadjustingwrenches
areremoved fromthetool ormachine worksurfacebefore operation.
13. AVOID UNINTENTIONALSTARTING. Besure thatyou arepreparedto beginwork before
turningthestartswitchon.
14. STAYALERT.Watchwhat youare doing.Donot operatethis machinewhenyou aretired.
15. DO NOT OPERATE THIS MACHINEWHILE UNDERTHE INFLUENCE OFALCOHOL,
DRUGS,OR PRESCRIPTION MEDICINES.
16. CHECKFOR DAMAGEDPARTS.Before usingany tool,anypart thatappears damagedshould
becarefullychecked todeterminethatitwilloperateproperlyandperform itsintendedfunction.
Checkforalignmentand bindingofmovingparts,anybroken partsormountingfixtures,andany
othercondition thatmayaffectproper operation.Anypart thatisdamagedshouldbe properly
repairedor replacedbya qualifiedtechnician. Donotuse thetool ifanyswitch doesnot turnonand
offproperly.
17. REPLACEMENTPARTSANDACCESSORIES.Whenservicing,use onlyidenticalreplacement
parts, whichareavailable fromHarborFreightTools.Use ofanyother partswillvoid thewarranty.
Page 3 SKU # 41889
WARNING: When using powered equipment, basic safety precautions should
always be followed to reduce the risk of personal injury and hazards.
Brought to You by Augusta Flint

SPECIALWARNINGSWHEN USINGTHISSCROLLSAW
Using this powerful tool may create special hazards.
Operating the Saw.
1. Avoid overloadingthesaw.If thespeeddrops abnormally,decreasethepressureimmediately.
2. Always usesharpblades whicharesuited tothematerial youare cutting.Ifthe bladestopsabruptly,
orbecomesblocked, turnoffthepowerswitchimmediately.
3. Do notapplyexcessive pressuretothe workpiecewhile cutting.
4. Be carefultouse thepower switchproperly.Be awarethatthesawwill continueto
operatewhilethepowerswitchisON.YoumustmanuallyturntheswitchtoOFFtostopthemotor.
5. Never startthesaw whiletheblade isin contactwithany material.Allowthe sawtoreach its
normaloperating speedbeforeapplying theworkpieceto theblade.
6. Never operatethe sawifthemetalsafety guard(drop foot)is notin place.
7. Never touchtheblade, upperblade holderorany othermoving partswhilethe sawis inoperation.
8. Never walkawayfrom thesawuntilit hasstoppedoperating completely.
9. Before cutting,adjustthe dropfoottorideon thesurfaceof theworkpiece.This willprevent the
workpiecefrom “jumping”upand down,whichcan damagethe workpiece,thesaw, andtheblade.
10. Hold theworkpiecefirmlywhile cutting.Theactionofthebladeagainsttheworkpiece cancauseit
to“kick out”.If youexperienceexcessive “kickout” checkyour bladetoassure thatit isthe proper
typeforthe materialbeingcut, thatitis installedwiththeteeth down,andthat itissharp.
11. Always wearANSIcertified eyeprotection,and donotallow othersnearbywhen usingthistool.
Cuttingsandsplinters canbeejectedat highspeedwhilecutting.
12. Do nothandlethebladeimmediately afteruse;itmaybe veryhot,potentiallycausingburns
or injury.
13. Makesure theworkpieceisfreeof nailsorother debriswhichcan interferewiththe cuttingprocess,
andpossiblycause damageorinjury.
14. Your sawmust bebolted orclamped to theworkbench priorto use.
Ensure the safety of the workplace.
1. Always wearANSI-approvedeyeprotection whentrimming.
2. Clear theworkarea ofanyparts ordebris thatcouldcause injurybyinterfering withthe
cuttingprocess.
3. Removetrimmed offsections immediatelytopreventtheir being ejectedbythesaw.
4. Keep childrenandunauthorizedpersons awayfromthearea whencutting.
5. Avoiddistractionswhilecutting.
6. Never leavethesaw unattendedwherechildrenor unauthorizedpersonscan useitwithout
supervision.
Inspect the Scroll Saw before use.
1. Before cutting,runthe toolforabout10 secondstoensure thatallmoving partsarerunning
smoothlyand thereareno looseparts,rattles,orsparking thatwouldindicate damage.
2. Repair anydamagebeforeusingthistool.
3. Be surethebladeis firmlyandproperlyinstalled beforeuse.Improperlyinstalled bladesmayeject
suddenlyathigh speedfromthe saw.
Page 4 SKU # 41889
Brought to You by Augusta Flint

ELECTRICALLIMITS ANDWARNINGS
1. Ifusinganextensioncord,observetheminimumgaugerequirementsfoundinthefollowing
chart.Improper extensioncorduse canresultin electricalhazardand poortool performance.
AMP Total Extension Cord Length in Feet
RATING 25 50 75 100 125 150 175 200
0-10 Amp 18 18 16 16 14 14 12 12
10.1-13 Amp 16 16 14 14 14 12 12 12
13.1-15 Amp 14 14 12 12 12 12 12 --
Use only UL approved extension cord.
2. Avoidwetconditionswhenusingelectricalequipment.
3. Use only a grounded outlet with appropriate breaker switch in-line.
4. Always inspect power cords and extension cords for damage before use. Never plug in a
power cord that is not in good condition.
5. Harbor Freight Tools can supply UL listed and outdoor rated power cords in various AWG
gaugeratingsas needed.
Page 5 SKU # 41889
BASICOPERATION
Thissawuses averythin, veryfineblade,which movesupand
downathighspeed.Thistype ofsawis idealformaking
detailedcurvedcutsinrelativelythin materials.Fretwork,signs,
andgingerbreaddecorationscanbereadilymadewithascrollsaw.
1. After selectingandinstalling theproperblade forthework athand,position theworkpieceon the
table.
2. Lower thefootonto theworkpiece, sothatit justrests onthesurface ofthe material.Tightenthe
footintoposition withtheknob.
3. With thematerialnot touchingthe blade,turnthe powerON bypressingthe upperpart ofthe
rockerswitch.
4. When thesaw hascomeup tofull speed,gently pushtheedgeofthe workpieceinto theblade.
Noticehow wellthe blademakes thecut.Adjust thespeed ifnecessary.
NOTE: In general, harder and thinner materials require finer saw teeth and higher speeds. Softer and
thicker materials generally require slower speeds. Finding the ideal saw blade and speed combina-
tion may require some experimentation and experience.
5. As youwork,remove cutoff piecesofwork material.
6. For cuttingenclosedareas,first drillahole throughthecut-outarea, installthebladethrough the
hole,then cutoutthe enclosedarea withthescroll saw.
7. Keep yourhands awayfromthe sawblade whileusing thissaw.Where possible,use apushstick to
guidethe workpieceintothe blade,keepingyour handsaway.
Figure 1. Electrical Controls
and Fuse Cover.
Brought to You by Augusta Flint

Page 6 SKU # 41889
1. Table. Providesaworkingsurfacetosupporttheworkpiece.
2. SawdustBlower. Keepsyourworkpiececleanformoreaccuratescrollcuts.For bestresults,adjustthe
blowertothepointatwhichthebladeiscutting.Toadjust,loosenthesetscrewinthedropfoot,positionthe
blowerandretightenthescrew. CAUTION:donotovertightenthescrew,whichmaycollapsethetube.
3. PowerCord.Thisisa3-wireULapprovedcordandCSA-approvedgroundedplugforuseina110-120Volt,
60Hzoutletonly.Besureyourpowersupplyisprotectedwithanappropriate breakerswitch.
4. DropFoot.Thefootshouldalwaysbeadjustedsoitjustrestsontopoftheworkpiece..Youwanttopreventthe
workpiecefromlifting,butnotcreatedragonthesurface.
5. DropFootLockKnob.Loosenandtightenthisknobasyouadjustthedropfoot.
6. BladeTensionKnob.Allowsyoutoloosenortightenthebladetension.Youalsousethisknobwhenreplacing
theblade.
7. TableLockKnob.Thisknoballowsyoutoadjustthetableangleupto45degrees.
8. DegreeScale.Thisscaleindicatesthedegreefromhorizontalthatyouhavethetableset.
9. PowerSwitch.TurntheswitchuptoturnON,anddowntoturnOFF.
10. ElectricalBreakerSwitch.Thisfusewillautomaticallycutoffpowertothesawintheeventofashortor
surgeinthepowersupply.Ifthefuseactivates,findandrepairthesourceoftheproblembeforereplacingthefuse.
11. SpeedControl.Turnthisknobtotherighttoincreasesawbladespeed,andtothelefttoreducespeed.
12. TableInsert.Thisshouldalwaysbeinplaceandflushwiththetableduringthecuttingoperation.
Figure 2. Basic Components
and Features of Your Scroll Saw.
Brought to You by Augusta Flint

Page 7 SKU # 41889
INSTALLINGTHESAWBLADE
Your new scroll saw accepts 5” pin-type blades. Your saw is also equipped with blade
adapters that allow you to use a variety of 5” plain-end blades.
WARNING: To prevent personal injury, always disconnect the plug from the power source
before changing blades or making adjustments.
1. Rotate thebladetension knobcounter-clockwise toreleaseblade tension.
2. Remove thetableinsert andremovethe bladefromthe upperandlowerbladeholdersbypulling
forwardonthe bladeandthen liftingthebladethrough theaccesshole inthetable.Slight downward
pressureagainstthe upperholdermaybe helpfulwhenremovingthe bladefromupperholder.
3. Look atthe bladeholders closelyandnotice theblade slotsand recessesin theblade holders.The
bladeholders aremadeso youcan positiontheblade forcutting fromthefront orfromthe sideof
thesaw asshowninFigure3above. Cuttingfromthe sideof thesawwillbenecessary ifyour
workpieceexceeds 16inchesin length.Thisallowsyour scrollsawto cutlike abandsaw.This
optionisfor0Otablesetting only.
4. In ordertocut, andto avoiduncontrollablelifting ofthe workpiece,theteeth oftheblade usedon
thescrollsaw shouldalwayspointdownward.
5. Install thebladeby insertingone endofthe bladethroughthe accesshole inthetable andhookthe
bladepin inthe pinrecessin thelower bladeholder.Slide thetop bladepininto thepin recessofthe
innerupper bladeholder.You mayneedto pressdownlightly ontheupper bladeholderto install
theblade.
6. Carefully tightenthebladebyrotating thebladetensionknobclockwise untilyoufeeltheslack inthe
blade removed.Double checkto seethat pinsare properlylocatedin theblade holder.Then turn
thebladetension knobONEfullturn clockwise.Thisamountof bladetensionshoulddowellfor
mostcuttingoperations andblades.
Fig. 3. Installing the Blade
Brought to You by Augusta Flint

Fig. 4. Aligning the Table
and adjusting the Scale
Page 8 SKU # 41889
ADJUSTINGANDUSINGTHETABLEALIGNMENTFEATURE
Aligning the Degree Scale Pointer
1. Loosen thetablelock knobandmovethetable untilitis
approximatelyperpendicular,thatis,atarightangle to
theblade.
2. Place asmall squareon thetable nextto theblade as
shownin Figure4 tocheckif thetable is90O to the
blade.If adjustmentis needed,raiseor lowerthe table
untilit isasclose to90Oaspossible. Securelytightenthe
tablelock knob.
3. Loosen thescrewholding thedegree scalepointer,as
shown in Figure 4. Movethe pointerto the 0Odegree
markeron thescale,and securelytightenthe screw.
Rememberthescale isaconvenientguide, butshouldnot
bereliedupon forextremelyaccurate cutting.Make
practicecuts inscrapwood todetermineif yourangle
settingsare correct.
Setting the Table for Horizontal or Bevel Cutting.
1. Loosen thetable lockknob,and thesaw table canbe
tiltedto theleftandlockedinanyangle from0O degree
horizontalcuttingpositionupto 45Oforbevel cutting.
2. A degreescale isalso providedunder thework table asa
convenientreferenceforsettingtheapproximatetable
angleforbevelcutting.Whengreaterprecisionis
required,make practicecuts andadjust thetable as
necessaryforyourrequirements.
3. NOTE: Whencuttingat angles,the dropfootcan betilted
soitis parallelwiththetable surface,andrestsflush
againstthe workpiece.To tiltdropfoot, loosentheallen
screw,tiltthe footsoit isparallelwith thetable,and then
securelyretightenthescrew.
Fig. 5. Adjusting the Table Angle
PLEASE READTHE FOLLOWINGCAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS DIAGRAM IN THIS MANUAL AS
A REFERENCE TOOL ONLY: NEITHER THE MANUFACTURER NOR DISTRIBUTOR MAKES ANY
REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE
ANY REPAIRS TO THE PRODUCT OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE
PRODUCT: IN FACT THE MANUFACTURER A ND/OR DISTRIBUTOR EXPRESSLY STATES THATALL REPAIRS
AND PARTS REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS AND
NOT BYTHE BUYER. THE BUYERASSUMESALL RISKAND LIABILITYARISING OUT OF HIS OR HER REPAIRS
TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER
INSTALLATION OF REPLACEMENT PARTS THERETO.
Brought to You by Augusta Flint

PARTS DIAGRAM #41889SCROLLSAW
Please see Parts Diagram on Following Page
Page 9 SKU # 41889 REV09/04
P/N Description
1 AdjustmentAssembly
2 PowerSupply
3 SpringWasherm6
4 HexNutm6
5 Pan Head Screw m5 x 10
6 PlateCover
7 SpringWasherm8
8 Hex Head Screw m8 x 25
9 Base
10 Hex Head Screw m6 x 20
11 HousingSet
12 SupportTable
13 Indicator
14 Pan Head Screw m5 x 10
15 BracketTilt
16 SpringWasherm5
17 Spring
18 FlatWasherm6
19 Hex HeadBolt m6x 40
20 Spring
21 BoltTension
22 Lower RockerArmAsembly
23 SpringWasherm4
24 Hex HeadBolt m4x 10
25 BearingFlamge
26 Pan Head Screw m5 x 6
27 Round Head Screw m6 x 25
28 Retainer
29 Upper RockerArmAssembly
30 Hex Nutm5
31 Hex HeadBolt m5x 30
32 Spacer Bearing
33 Spacer Bearing
34 LinkAssembly
35 AllenWrenches, 2.5,3,4mm
36 Cord Clamp
37 Upper Holder
38 Hex HeadBolt m5x 25
P/N Description
39 FlatWasher
40 Lower Holder
41 ToothWasher
42 Hex HeadBolt m4x 10
43 TableInsert
44 Knob
45 Blade
46 Pan Head Screw m4 x 16
47 BladeGuard
48 Tooth washerm5
49 Pan Head Screw m5 x 10
50 Switch Cover
51 Motor
52 Eccentric
53 Table
54 Hex HeadBolt m6x 40
55 PVC Pipe
56 Support Rod
57 BellowsLock
58 Bellows
59 ToothWasherm4
60 Set Screws m8 x 8
61 Pan Head Screw m4.2 x 8
63 Pan Head Screw m4 x 20
64 Pan Head Screw m4 x 6
65 Pan Head Screw m5 x 35
66 Pan Head Screw m5 x 30
67 BlowerTube
68 Knob
69 BearingFence
70 Set Plate
71 Switch Case
72 Power Switch
73 Fuse Box
75 Motor Base
76 Pan Head Screw m4 x 16
Brought to You by Augusta Flint

Page 10 SKU # 41889
PARTS DIAGRAM #41889SCROLLSAW
Please see Parts List on Previous Page
Brought to You by Augusta Flint
