Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference. 20i
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright© 2014 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly an d se rv ic e may n ot b e in cl uded.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Page 2 ;&(%$*4.8"4,7%<'*#$"&8#=%/7*,#*%4,77%>?@@@?@AA?BCDC1 Item 93762
EF;6GH IJ6KFGLIM NFLMG6MFMO6E6GPJ
G,+7*%&2%O&8$*8$#
Safety ......................................................... 3
Specifications ............................................. 7
Setup .......................................................... 8
Operation ................................................... 13
Maintenance .............................................. 20
Parts List and Diagram .............................. 25
Warranty .................................................... 28
QFKMLMR%EHNSITE%FMU%U6;LMLGLIME
This is the safety alert symbol. It is used to alert you to potential
personal injury hazards. Obey all safety messages that
follow this symbol to avoid possible injury or death.
Indicates a hazardous situation which, if not avoided,
will result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in death or serious injury.
Indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
Addresses practices not related to personal injury.
Page 3;&(%$*4.8"4,7%<'*#$"&8#=%/7*,#*%4,77%>?@@@?@AA?BCDC1Item 93762
EF;6GHIJ6KFGLIMNFLMG6MFMO6 E6GPJ
LNJIKGFMG%EF;6GH%LM;IKNFGLIM
R*8*(,7%G&&7%E,2*$V%Q,(8"83#
K*,9%,77%#,2*$V%),(8"83#%,89%"8#$('4$"&8#1%%
Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury.
E,W*%,77%),(8"83#%,89%"8#$('4$"&8#%2&(%2'$'(*%(*2*(*84*1
1. KEEP GUARDS IN PLACE and in working order.
2. REMOVE ADJUSTING KEYS AND
WRENCHES. Form habit of checking to
see that keys and adjusting wrenches are
removed from tool before turning it on.
3. KEEP WORK AREA CLEAN.
Cluttered areas and benches invite accidents.
4. DON’T USE IN DANGEROUS ENVIRONMENT.
Don’t use power tools in damp or wet locations,
or expose them to rain. Keep work area well lighted.
5. KEEP CHILDREN AWAY. All visitors should
be kept safe distance from work area.
6. MAKE WORKSHOP KID PROOF with padlocks,
master switches, or by removing starter keys.
7. DON’T FORCE TOOL. It will do the job better
and safer at the rate for which it was designed.
8. USE RIGHT TOOL. Don’t force tool or attachment
to do a job for which it was not designed.
G,+7*%F-%%K6OINN6MU6U%NLMLNPN%QLK6%RFPR6%
;IK%6XG6MELIM%OIKUE%
Y>Z[%!ITG\
MFN6JTFG6%
FNJ6K6E
Y,$%2'77%7&,9\
6XG6MELIM%OIKU%
T6MRG]
25′ 50′ 100′ 150′
0 – 6 18 16 16 14
6.1 – 10 18 16 14 12
10.1 – 12 16 16 14 12
12.1 – 16 14 12 U&%8&$%'#*1
9. USE PROPER EXTENSION CORD. Make sure
your extension cord is in good condition.
When using an extension cord, be sure to use
one heavy enough to carry the current your
product will draw. An undersized cord will
cause a drop in line voltage resulting in loss
of power and overheating. %Table A shows the
correct size to use depending on cord length
and nameplate ampere rating. If in doubt, use
the next heavier gauge. The smaller the
gauge number, the heavier the cord.
10. WEAR PROPER APPAREL. Do not wear
loose clothing, gloves, neckties, rings, bracelets,
or other jewelry which may get caught in moving
parts. Nonslip footwear is recommended.
Wear protective hair covering to contain long hair.
11. ALWAYS USE SAFETY GLASSES. Also use
face or dust mask if cutting operation is dusty.
Everyday eyeglasses only have impact resistant
lenses, they are NOT safety glasses.
12. SECURE WORK. Use clamps or a vise to
hold work when practical. It’s safer than using
your hand and it frees both hands to operate tool.
13. DON’T OVERREACH.
Keep proper footing and balance at all times.
14. MAINTAIN TOOLS WITH CARE. Keep
tools sharp and clean for best and safest
performance. Follow instructions for
lubricating and changing accessories.
15. DISCONNECT TOOLS before servicing;
when changing accessories, such as
blades, bits, cutters, and the like.
16. REDUCE THE RISK OF UNINTENTIONAL
STARTING. Make sure switch is in
off position before plugging in.
17. USE RECOMMENDED ACCESSORIES.
Consult the owner’s manual for recommended
accessories. The use of improper accessories
may cause risk of injury to persons.
18. NEVER STAND ON TOOL.
Serious injury could occur if the tool is tipped or
if the cutting tool is unintentionally contacted.
19. CHECK DAMAGED PARTS. Before further use
of the tool, a guard or other part that is damaged
should be carefully checked to determine that
it will operate properly and perform its intended
function – check for alignment of moving parts,
binding of moving parts, breakage of parts,
mounting, and any other conditions that may
affect its operation. A guard or other part that is
damaged should be properly repaired or replaced.
20. DIRECTION OF FEED.
Feed work into a blade or cutter against the
direction of rotation of the blade or cutter only.
21. NEVER LEAVE TOOL RUNNING UNATTENDED.
TURN POWER OFF. Don’t leave tool
until it comes to a complete stop.
Page 4 ;&(%$*4.8"4,7%<'*#$"&8#=%/7*,#*%4,77%>?@@@?@AA?BCDC1 Item 93762
EF;6GH IJ6KFGLIM NFLMG6MFMO6E6GPJ
R(&'89"83%L8#$('4$"&8#
%
GI%JK6!6MG%6T6OGKLO%E]IO^%FMU%U6FG]%;KIN%LMOIKK6OG%
RKIPMULMR%QLK6%OIMM6OGLIM%K6FU%FMU%;ITTIQ%G]6E6%LMEGKPOGLIME-
>>[?>Z[%!FO%R(&'89*9%G&&7#-%G&&7#%)"$.%G.(**%J(&83%J7'3#
1. In the event of a malfunction or breakdown,
grounding provides a path of least resistance for
electric current to reduce the risk of electric shock.
This tool is equipped with an electric cord having an
equipment-grounding conductor and a grounding
plug. The plug must be plugged into a matching
outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
2. Do not modify the plug provided – if it will
not fit the outlet, have the proper outlet
installed by a qualified electrician.
3. Improper connection of the equipment-grounding
conductor can result in a risk of electric shock.
The conductor with insulation having an outer
surface that is green with or without yellow
stripes is the equipment-grounding conductor.
If repair or replacement of the electric cord or
plug is necessary, do not connect the equipment-
grounding conductor to a live terminal.
4. Check with a qualified electrician or service
personnel if the grounding instructions are
not completely understood, or if in doubt as
to whether the tool is properly grounded.
5. Use only 3-wire extension cords that
have 3-prong grounding plugs and 3-pole
receptacles that accept the tool’s plug.
6. Repair or replace damaged or
worn cord immediately.
R(&'89"83%
J"8
>ZB%!FO%_?J(&83%J7'3%,89%I'$7*$
Y2&(%'/%$&%>ZB%!FO%,89%'/%$&%>B%F\
7. This tool is intended for use on a circuit that has
an outlet that looks like the one illustrated above in
>ZB%!FO%_?J(&83%J7'3%,89%I'$7*$. The tool has
a grounding plug that looks like the plug illustrated
above in >ZB%!FO%_?J(&83%J7'3%,89%I'$7*$.
8. The outlet must be properly installed and grounded
in accordance with all codes and ordinances.
9. Do not use an adapter to connect
this tool to a different outlet.
S,89%E,)%E,2*$V%Q,(8"83#
;&(%H&'(%I)8%E,2*$V%K*,9%L8#$('4$"&8%
N,8',7%S*2&(*%I/*(,$"83%E,)
1. Wear eye protection.
2. Do not remove jammed cutoff pieces
until blade has stopped.
3. Maintain proper adjustment of blade tension,
blade guides, and blade guide bearings.
4. Adjust upper guide to just clear workpiece.
5. Hold workpiece firmly against table.
6. Use special care when unpacking or
replacing Band Saw blade. Blade can be
under tension and may suddenly uncoil.
Wear ANSI-approved safety glasses under a
full face shield and heavy-duty work gloves.
7. Keep hands away from cutting area and Saw Blade.
8. UI%MIG%IJ6KFG6%QLG]%FMH%RPFKU%
ULEFST6U=%UFNFR6U=%IK%K6NI!6U1%%N&W"83%
3',(9#%5'#$%5&W*%2(**7V%,89%47&#*%"8#$,8$7V1%
9. Properly adjust the upper blade guide, blade
tension and blade guide bearing before each
use to reduce the risk of injury. See Operating
Instructions for explanation of needed adjustments.
Page 5;&(%$*4.8"4,7%<'*#$"&8#=%/7*,#*%4,77%>?@@@?@AA?BCDC1Item 93762
EF;6GHIJ6KFGLIMNFLMG6MFMO6 E6GPJ
10. Never leave the Band Saw unattended when it is
plugged into an electrical outlet. Turn off the tool,
and unplug it from its electrical outlet before leaving.
11. Make sure the Band Saw is located on a flat,
level, sturdy surface capable of supporting
the weight of the Saw and workpieces.
Always “chock” the Wheels to prevent the
Band Saw from accidentally moving.
12. Before using the Band Saw, check to
make sure the Saw Blade is properly
mounted and is not cracked or bent.
13. Never attempt to cut more than
one workpiece at a time.
14. Never attempt to cut freehand. Make sure the
workpiece to be cut is pressed firmly against
the Table and/or secured in the Vise.
15. When cutting a large workpiece, make sure
its entire length is properly supported. If
necessary, use a roller stand (not included).
16. Do not lean on the Band Saw when
the tool is in its upright position.
17. When moving the Band Saw, always have its
Head lowered to its horizontal position and the
Locking Pin (116) inserted in the Pivot (121).
18. Allow the Saw Blade to rotate to full speed
before feeding a workpiece into the Blade.
When turning off the Band Saw, allow the Saw
Blade to spin down and stop on its own. Do
not press against the Saw Blade to stop it.
19. Wear heavy-duty work gloves when
changing the Saw Blade.
20. Turn off the Band Saw and allow the Saw
Blade to completely stop if the Saw Blade is
to be backed out of an uncompleted cut.
21. Use indoors only.
22. If the teeth of the Saw Blade are so far apart that
they straddle the workpiece, severe damage to
the workpiece and/or Saw Blade will result.
23. The use of accessories or attachments not
recommended by the manufacturer may
result in a risk of injury to persons.
24. When servicing use only identical replacement parts.
25. Only use safety equipment that has been approved
by an appropriate standards agency. Unapproved
safety equipment may not provide adequate
protection. Eye protection must be ANSI-approved
and breathing protection must be NIOSH-approved
for the specific hazards in the work area.
26. Stay alert, watch what you are doing and use
common sense when operating a power tool.
Do not use a power tool while you are tired or
under the influence of drugs, alcohol or medication.
A moment of inattention while operating power
tools may result in serious personal injury.
27. Industrial applications must follow OSHA guidelines.
28. Maintain labels and nameplates on the tool.
These carry important safety information.
If unreadable or missing, contact
Harbor Freight Tools for a replacement.
29. Avoid unintentional starting.
Prepare to begin work before turning on the tool.
30. People with pacemakers should consult their
physician(s) before use. Electromagnetic fields in
close proximity to heart pacemaker could cause
pacemaker interference or pacemaker failure. In
addition, people with pacemakers should:
• Avoid operating alone.
• Do not use with power switch locked on.
• Properly maintain and inspect to avoid electrical
shock.
• Any power cord must be properly
grounded. Ground Fault Circuit Interrupter
(GFCI) should also be implemented – it
prevents sustained electrical shock.
31. The warnings, precautions, and instructions
discussed in this instruction manual cannot cover all
possible conditions and situations that may occur.
It must be understood by the operator that
common sense and caution are factors
which cannot be built into this product,
but must be supplied by the operator.
Page 6 ;&(%$*4.8"4,7%<'*#$"&8#=%/7*,#*%4,77%>?@@@?@AA?BCDC1 Item 93762
EF;6GH IJ6KFGLIM NFLMG6MFMO6E6GPJ
!"+(,$"&8%E,2*$V
This tool vibrates during use. Repeated or
long-term exposure to vibration may cause
temporary or permanent physical injury,
particularly to the hands, arms and shoulders.
To reduce the risk of vibration-related injury:
1. Anyone using vibrating tools regularly or for an
extended period should first be examined by a
doctor and then have regular medical check-ups
to ensure medical problems are not being caused
or worsened from use. Pregnant women or
people who have impaired blood circulation to
the hand, past hand injuries, nervous system
disorders, diabetes, or Raynaud’s Disease should
not use this tool. If you feel any medical or
physical symptoms related to vibration (such as
tingling, numbness, and white or blue fingers),
seek medical advice as soon as possible.
2. Do not smoke during use. Nicotine reduces
the blood supply to the hands and fingers,
increasing the risk of vibration-related injury.
3. Use tools with the lowest vibration when there
is a choice between different processes.
4. Include vibration-free periods each day of work.
5. Grip workpiece as lightly as possible (while still
keeping safe control of it). Let the tool do the work.
6. To reduce vibration, maintain the tool as
explained in this manual. If any abnormal
vibration occurs, stop use immediately.
%EF!6%G]6E6%LMEGKPOGLIME1
Page 7;&(%$*4.8"4,7%<'*#$"&8#=%/7*,#*%4,77%>?@@@?@AA?BCDC1Item 93762
EF;6GHIJ6KFGLIMNFLMG6MFMO6 E6GPJ
E/*4"2"4,$"&8#
Electrical Rating 120VAC / 60 Hz / 6.5 A
Motor No Load Speed 1700 RPM
Blade Speeds 80 FPM / 120 FPM / 200 FPM
Cutting Capacity 4-1/2" Round Stock
4" x 6" Rectangular Stock
Throat Depth 4-1/2"
Angle Cutting Capacity 0°– 45° (Left) Miter Plate on
Horizontal Cutting Bed
Horizontal Bed 11-1/2" L x 7-1/2" W x 23-1/2" H
Vertical Bed 9-1/2" L x 9-1/2" W x 33-1/2" H
V-Belt Type 0-506
Blade Size 64-1/2" L x 1/2" W x
0.025″ Thick / 14 TPI
Page 8 ;&(%$*4.8"4,7%<'*#$"&8#=%/7*,#*%4,77%>?@@@?@AA?BCDC1 Item 93762
EF;6GH IJ6KFGLIM NFLMG6MFMO6E6GPJ
E*$'/%?%S*2&(*%P#*-
%K*,9%$.*%6MGLK6%LNJIKGFMG%EF;6GH%LM;IKNFGLIM%#*4$"&8%,$%$.*%+*3"88"83%&2%$."#%
5,8',7%"847'9"83%,77%$*`$%'89*(%#'+.*,9"83#%$.*(*"8%+*2&(*%#*$%'/%&(%'#*%&2%$."#%/(&9'4$1
GI%JK6!6MG%E6KLIPE%LMaPKH%;KIN%FOOLU6MGFT%IJ6KFGLIM-%
G'(8%$.*%J&)*(%E)"$4.%&2%$.*%$&&7%&22%,89%'8/7'3%$.*%$&&7%2(&5%"$#%*7*4$("4,7%&'$7*$%
+*2&(*%/*(2&(5"83%,8V%/(&4*9'(*%"8%$."#%#*4$"&81
MIG6- For additional information regarding the parts listed in the following
pages, refer to the Assembly Diagram near the end of this manual.
F##*5+7V0N&'8$"83
G&%F##*5+7*%$.*%E$,89
1. Insert the Pull Handle (12) into the two
mounting holes located in the upper section
of one Stand (10). Then secure the Pull
Handle to the Stand, using two Pins (11).
2. Attach one end of the Tool Plate (128) to the upper
section of one Stand (10), using two Bolts (9),
four Flat Washers (8), and two Nuts (6)1
3. Attach the other end of the Tool Plate
to the upper section of the remaining
Stand, using two Bolts (9), four Flat
Washers (8), and two Nuts (6).
4. Align the two mounting holes in the Wheel
Bracket (130) with the two mounting
holes located in the lower section of the
Stand without the Pull Handle.
5. Secure the Wheel Bracket to the Stand,
using two Bolts (9), four Flat Washers (8),
and two Nuts (6)1%%Refer to Figure A.
G&&7%J7,$*%Y>Z@\G&&7%J7,$*%Y>Z@\
Q.**7%Q.**7%
S(,4b*$%S(,4b*$%
Y>_[\Y>_[\
J"8%Y>>\J"8%Y>>\
J'77%],897*%Y>Z\J'77%],897*%Y>Z\
@@
@@
@@
DDAA
AA
@@DD
E$,89%Y>[\E$,89%Y>[\
E$,89%Y>[\E$,89%Y>[\
;"3'(*%F
Page 9;&(%$*4.8"4,7%<'*#$"&8#=%/7*,#*%4,77%>?@@@?@AA?BCDC1Item 93762
EF;6GHIJ6KFGLIMNFLMG6MFMO6 E6GPJ
G&%F$$,4.%$.*%S,89%E,)%$&%$.*%E$,89
1. With assistance and an adequate lifting
device, carefully set the Band Saw on top of
the Stand assembly. Place the motor end
of the Saw at the wheeled end of the stand,
making sure the upper section of the Stand
fits inside the base of the Band Saw1
2. Align the mounting holes on the base of the Band
Saw with the mounting holes located on the upper
sections of the Stand assembly. Refer to Figure B.
NIPMGLMR%
]IT6
NIPMGLMR%
]IT6
NIPMGLMR%
]IT6
NIPMGLMR%
]IT6
NIPMGLMR%
]IT6
NIPMGLMR%
]IT6
;"3'(*%S-%%E$,89%YG&/%!"*)\
3. Secure the Band Saw to the Stand assembly,
using a Bolt (13) and Flat Washer (3) on the
outside and another Flat Washer (3), Spring
Washer (4), and Nut (5) on the inside of each
of the six mounting holes. Refer to Figure C.
S&7$%Y>_\
;7,$%Q,#.*(%Y_\
;7,$%Q,#.*(%Y_\
E/("83%Q,#.*(%Yc\
M'$%YB\
Y8&$%W"#"+7*\
;"3'(*%O
G&%F$$,4.%$.*%E$&4b%E$&/%F##*5+7V
1. When mounted to the Band Saw, the
adjustable Stock Stop assembly is used to
make repetitive cuts of the same length.
2. To attach the Stock Stop (18), slide the
Shaft (19) into the mounting hole in the Machine
Bed (122), and secure the Shaft by tightening
the Set Screw (49).%%Refer to Figure D.
3. Slide the Stock Stop onto the Shaft, and
secure by tightening the Screw (17)1
E$&4b%
E$&/%
Y>@\
N&'8$"83%N&'8$"83%
]&7*]&7*
E4(*)%Y>C\E4(*)%Y>C\
E.,2$%
Y>D\
E*$%E4(*)%YcD\
;"3'(*%U
G&%F$$,4.%$.*%J'77*V%O&W*(
1. Position the Pulley Cover (101) over the
Spindle Shaft (97) and Motor Shaft.
2. Align the mounting hole in the Pulley Cover with
the mounting hole in the Body Frame (93).
3. Secure the Pulley Cover to the Band Saw,
using one Screw (89), Spring Washer (7)
and Flat Washer (8). Refer to Figure E.
J'77*V%O&W*(%
Y>[>\
Q&(5%
E.,2$%
YDC\
N&$&(%Y>>B\
S&9V%
;(,5*%
YD_\
E4(*)%Y@D\
E/("83%Q,#.*(%YC\
;7,$%Q,#.*(%Y@\ N&$&(%E.,2$
;"3'(*%6
Page 10 ;&(%$*4.8"4,7%<'*#$"&8#=%/7*,#*%4,77%>?@@@?@AA?BCDC1 Item 93762
EF;6GH IJ6KFGLIM NFLMG6MFMO6E6GPJ
G&%F$$,4.%$.*%E/"897*%J'77*V%,89%N&$&(%J'77*V
1. Slide the Spindle Pulley (99) fully onto the Spindle
Shaft (97). Secure the Spindle Pulley to the Spindle
Shaft using one Screw (52). Refer to Figure F.
2. Insert the Shaft Key (51) in the slot on the Motor
Shaft. Align the slot in the Motor Pulley (105)
with the Shaft Key. Slide the Motor Pulley fully
onto the Motor Shaft. Secure the Motor Pulley
to the Motor Shaft using one Screw (52)1
N&$&(%J'77*V%Y>[B\
E.,2$%^*V%E.,2$%^*V%
YB>\YB>\
E/"897*%
J'77*V%
YDD\
!?S*7$%!?S*7$%
Y>[[\Y>[[\
E4(*)%YBZ\%E4(*)%YBZ\%
Y8&$%#.&)8\Y8&$%#.&)8\
E4(*)%YBZ\%E4(*)%YBZ\%
Y8&$%#.&)8\Y8&$%#.&)8\
;"3'(*%;
G&%L8#$,77%$.*%!?S*7$
1. Loosen the Bolt (108) and press the Motor (115)
toward the Body. Refer to Figure G.
2. Place the V-Belt (100) around the top
grooves in the Spindle Pulley (99) and
Motor Pulley (105). Refer to Figure F.
3. Adjust the position of the Motor to obtain
approximately 1/2″ depression in the V-Belt
when applying pressure with your thumb.
4. Re-tighten the Bolt to secure the Motor in place.
S&7$%Y>[@\S&7$%Y>[@\
N&$&(%Y>>B\
;"3'(*%R
G&%F9d'#$%$.*%O'$$"83%E/**9
1. The Band Saw is designed to cut at three different
speeds: 80, 120, and 200 FPM%(Feet Per Minute)
depending on the type of material being cut.
NFG6KLFT EJ66U
Y;JN\
JPTT6H%RKII!6
EJLMUT6 NIGIK
Tool Steel,
Stainless
Alloy Steels,
Bearing
Bronze
80 TFKR6 ENFTT
Medium to High
Carbon Steels,
Hard Brass
or Bronze
120 N6ULPN N6ULPN
Low to Medium
Carbon Steels,
Soft Brass,
Aluminum, Plastic
200 TFKR6ENFTT
;"3'(*%]
2. Refer to the Chart at left to determine
the proper cutting speed for a specific
type of material being cut.
3. The cutting speed can be adjusted by
changing the position of the V-Belt:
a. Loosen the Bolt (108) and press the
Motor (115) toward the Body.
b. Place the V-Belt around the desired grooves in
the Spindle Pulley (99) and Motor Pulley (105).
c. Ease the Motor back to its original position
to tighten the tension on the V-Belt.
d. Re-tighten the Bolt to secure the Motor
in place. Refer to Figure F, Figure G.
QFKMLMRe%%GI%JK6!6MG%E6KLIPE%LMaPKH-
Always securely close the Lid on the Pulley Cover
after installing a V-Belt or adjusting the cutting speed.
