Central Machinery 94652 User manual

TABLE TILT BANDSAW
12” - 3/4 HP
ASSEMBLY AND OPERATING INSTRUCTIONS
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our Web site at: http://www.harborfreight.com
TO PREVENT SERIOUS INJURY,
READ AND UNDERSTAND ALL WARNINGS
AND INSTRUCTIONS BEFORE USE.
Copyright©2006 by Harbor Freight Tools®. All right reserved. No portion of
this manual or any artwork contained herein may be reproduced in any shape
or form without the express written consent of Harbor Freight Tools.
For technical questions, please call 1-800-444-3353.
®
Due to continuing improvements, actual product may differ slightly from the product described herein.
Model 94652

SKU 94652 For technical questions, please call 1-800-444-3353 PAGE 2
SAVE THIS MANUAL
You will need this manual for the safety warnings and precautions, assembly, op-
erating, inspection, maintenance and cleaning procedures, parts list and assem-
bly diagram. Keep your invoice with this manual. Write the invoice number on the
inside of the front cover. Keep this manual and invoice in a safe and dry place for
future reference.
GENERAL SAFETY RULES
WARNING!
READ AND UNDERSTAND ALL INSTRUCTIONS
Failure to follow all instructions listed below may result in
electric shock, fire, and/or serious injury.
SAVE THESE INSTRUCTIONS
WORK AREA
1. Keep your work area clean and well lit. Cluttered benches and dark areas
invite accidents.
2. Do not operate power tools in explosive atmospheres, such as in the
presence of flammable liquids, gases, or dust. Power tools create sparks
which may ignite the dust or fumes.
3. Keep bystanders, children, and visitors away while operating a power tool.
Distractions can cause you to lose control. Protect others in the work area from
PRODUCT SPECIFICATIONS
Electrical Requirements 120 VAC / 60 Hz / 3/4 HP / 1,650 RPM
Internal Thermal Protection
Power Switch Paddle Switch with Pull-Out Safety Key
Power Cord 5 Ft. Long / 18 AWG x 3C – SJTW
Power Plug 3-Prong / Grounded
Maximum Cutting Height 6-3/4”
Maximum Stock Throat 12”
Saw Blade Size/Type 92-15/16” Diameter x 1/4” Wide x .018” Thick / 4-TPI ATB Tooth Pattern
Worktable Dimensions 15”-7/8” Long x 21-1/2” Wide x 1-1/4” Thick
Worktable Tilt Capability 0° to 45° in 1° Increments (Right Tilt Only)
Pulley Cutting Speeds 1214 Ft. Per Minute / 2461 Ft. Per Minute
Drive Method 1 V-Belt & 2 Pulleys
Dust Chute Dimensions 3-3/4” O.D. x 3-1/2” I.D. x 2” Deep
Overall Dimensions 33” Long x 21-1/2” Wide x 66” High
Accessories Fence Gauge / Saw Blade / Spanner Wrench / Allen Key Wrenches (Qty. 2) / Push Stick
Unit Weight 206 Pounds

SKU 94652 For technical questions, please call 1-800-444-3353 PAGE 3
ELECTRICAL SAFETY
4. Grounded tools must be plugged into an outlet properly installed and
grounded in accordance with all codes and ordinances. Never remove the
grounding prong or modify the plug in any way. Do not use any adapter
plugs. Check with a qualified electrician if you are in doubt as to whether
the outlet is properly grounded. If the tools should electrically malfunction or
break down, grounding provides a low resistance path to carry electricity away
from the user.
5. Double insulated tools are equipped with a polarized plug (one blade is
wider than the other). This plug will fit in a polarized outlet only one way. If
the plug does not fit fully in the outlet, reverse the plug. If it still does not
fit, contact a qualified electrician to install a polarized outlet. Do not
change the plug in any way. Double insulation eliminates the need for the
three wire grounded power cord and grounded power supply system.
6. Avoid body contact with grounded surfaces such as pipes, radiators,
ranges, and refrigerators. There is an increased risk of electric shock if your
body is grounded.
7. Do not expose power tools to rain or wet conditions. Water entering a power
tool will increase the risk of electric shock.
8. Do not abuse the Power Cord. Never use the Power Cord to carry the tools
or pull the Plug from an outlet. Keep the Power Cord away from heat, oil,
sharp edges, or moving parts. Replace damaged Power Cords immediately.
Damaged Power Cords increase the risk of electric shock.
9. When operating a power tool outside, use an outdoor extension cord
marked “W-A” or “W”. These extension cords are rated for outdoor use, and
reduce the risk of electric shock.
PERSONAL SAFETY
10. Stay alert. Watch what you are doing, and use common sense when operat-
ing a power tool. Do not use a power tool while tired or under the influence
of drugs, alcohol, or medication. A moment of inattention while operating
power tools may result in serious personal injury.
11. Dress properly. Do not wear loose clothing or jewelry. Contain long hair.
Keep your hair, clothing, and gloves away from moving parts. Loose clothes,
jewelry, or long hair can be caught in moving parts.
debris such as chips and sparks. Provide barriers or shields as needed.

SKU 94652 For technical questions, please call 1-800-444-3353 PAGE 4
12. Avoid accidental starting. Be sure the Power Switch is off before plugging
in. Plugging in power tools with the Power Switch on, invites accidents.
13. Remove adjusting keys or wrenches before turning the power tool on. A
wrench or a key that is left attached to a rotating part of the power tool may result
in personal injury.
14. Do not overreach. Keep proper footing and balance at all times. Proper
footing and balance enables better control of the power tool in unexpected situa-
tions.
15. Use safety equipment. Always wear eye protection. Dust mask, non-skid
safety shoes, hard hat, or hearing protection must be used for appropriate condi-
tions.
TOOL USE AND CARE
16. Use clamps (not included) or other practical ways to secure and support
the workpiece to a stable platform. Holding the workpiece by hand or against
your body is unstable and may lead to loss of control.
17. Do not force the tool. Use the correct tool for your application. The correct
tool will do the job better and safer at the rate for which it is designed.
18. Do not use the power tool if the Power Switch does not turn it on or off.
Any tool that cannot be controlled with the Power Switch is dangerous and must
be replaced.
19. Disconnect the Power Cord Plug from the power source before making any
adjustments, changing accessories, or storing the tool. Such preventive
safety measures reduce the risk of starting the tool accidentally.
20. Store idle tools out of reach of children and other untrained persons. Tools
are dangerous in the hands of untrained users.
21. Maintain tools with care. Keep cutting tools sharp and clean. Properly
maintained tools with a sharp cutting edge are less likely to bind and are easier
to control. Do not use a damaged tool. Tag damaged tools “Do not use” until
repaired.
22. Check for misalignment or binding of moving parts, breakage of parts, and
any other condition that may affect the tool’s operation. If damaged, have
the tool serviced before using. Many accidents are caused by poorly main-
tained tools.

SKU 94652 For technical questions, please call 1-800-444-3353 PAGE 5
23. Use only accessories that are recommended by the manufacturer for your
model. Accessories that may be suitable for one tool may become hazardous
when used on another tool.
SERVICE
24. Tool service must be performed only by qualified repair personnel. Service
or maintenance performed by unqualified personnel could result in a risk of injury.
25. When servicing a tool, use only identical replacement parts. Follow
instructions in the “Inspection, Maintenance, And Cleaning” section of this
manual. Use of unauthorized parts or failure to follow maintenance instructions
may create a risk of electric shock or injury.
SPECIFIC SAFETY RULES
1. Maintain labels and nameplates on the Bandsaw. These carry important
information. If unreadable or missing, contact Harbor Freight Tools for a
replacement.
2. Always wear safety impact eye goggles and heavy work gloves when
using the Bandsaw. Using personal safety devices reduce the risk for in-
jury. Safety impact eye goggles and heavy work gloves are available from
Harbor Freight Tools.
3. Maintain a safe working environment. Keep the work area well lit. Make sure
there is adequate surrounding workspace. Always keep the work area free of ob-
structions, grease, oil, trash, and other debris. Do not use a power tool in areas
near flammable chemicals, dusts, and vapors. Do not use this product in a damp
or wet location.
4. Avoid unintentional starting. Make sure you are prepared to begin work before
turning on the Bandsaw.
5. Do not force the Bandsaw. This tool will do the work better and safer at the
speed and capacity for which it was designed. Do not force the workpiece into
the Saw Blade.
6. WARNING! Keep hands and fingers away from cutting area and Saw Blade.
7. Never leave the Bandsaw unattended when it is plugged into an electrical
outlet. Turn off the tool, and unplug it from its electrical outlet before leaving.

SKU 94652 For technical questions, please call 1-800-444-3353 PAGE 6
8. Make sure the Bandsaw is located on a flat, level, sturdy surface capable
of supporting the weight of the Saw and workpieces. Always “chock” the
Wheels to prevent the Bandsaw from accidentally moving.
9. Make sure the Table of the Bandsaw and surrounding area are clear with
the exception of the workpiece to be cut.
10. Before using the Bandsaw, check to make sure the Saw Blade is prop-
erly mounted and is not cracked or bent.
11. Industrial applications must follow OSHA guidelines.
12. Never stand on the Bandsaw. Serious injury could result if the Bandsaw is
tipped or if the rotating Saw Blade is accidently contacted.
13. Never attempt to cut more than one workpiece at a time.
14. Whenever possible, use the accessory Push Stick when cutting.
15. When cutting a large workpiece, make sure its entire length is properly
supported. If necessary, use a roller stand (not included).
16. Allow the Saw Blade to rotate to full speed before feeding a workpiece into
the Blade. When turning off the Bandsaw, allow the Saw Blade to spin down
and stop on its own. Do not press against the Saw Blade to stop it.
17. To avoid accidental injury, always wear heavy duty work gloves when
changing the Saw Blade.
18. The Saw Blade will become hot while cutting. Allow the Saw Blade to com-
pletely cool before handling.
19. Do not force the workpiece into the Saw Blade when cutting. Apply moder-
ate pressure, allowing the Saw Blade to cut without being forced.
20. Turn off the Bandsaw and allow the Saw Blade to completely stop if the Saw
Blade is to be backed out of an uncompleted cut.
21. Never attempt to remove material stuck in the moving parts of the Bandsaw
while it is plugged in and running.
22. Make sure the workpiece to be cut off has sufficient room to move side-
ways. Failure to do so may result in off-cut binding against the Saw Blade.
23. Always unplug the Bandsaw from its electrical outlet before performing any
inspection, maintenance, or cleaning procedures.

SKU 94652 For technical questions, please call 1-800-444-3353 PAGE 7
24. Keep this product and all other tools and equipment away from children
and animals. Do not allow spectators in the work area.
25. Keep all safety guards in place and in proper working order.
26. This Bandsaw is designed for indoor use only.
27. WARNING! Some dust created by power sanding, sawing, grinding, drilling,
and other construction activities, contain chemicals known (to the State of Califor-
nia) to cause cancer, birth defects or other reproductive harm. Some examples
of these chemicals are: lead from lead-based paints, crystalline silica from bricks
and cement or other masonry products, arsenic and chromium from chemically
treated lumber. Your risk from these exposures varies, depending on how often
you do this type of work. To reduce your exposure to these chemicals: work in
a well ventilated area, and work with approved safety equipment, such as those
dust masks that are specially designed to filter out microscopic particles.
(California Health & Safety Code 25249.5, et seq.)
30. WARNING! People with pacemakers should consult their physician(s) be-
fore using this product. Operation of electrical equipment in close proximity to a
heart pacemaker could cause interference or failure of the pacemaker.
31. WARNING! The warnings and cautions discussed in this manual cannot
cover all possible conditions and situations that may occur. It must be under-
stood by the operator that common sense and caution are factors which cannot
be built into this product, but must be supplied by the operator.
SAVE THESE INSTRUCTIONS
WARNING!
Improperly connecting the grounding wire can result in the risk of electric
shock. Check with a qualified electrician if you are in doubt as to whether the
outlet is properly grounded. Do not modify the power cord plug provided with
the tool. Never remove the grounding prong from the plug. Do not use the
tool if the power cord or plug is damaged. If damaged, have it repaired by a
service facility before use. If the plug will not fit the outlet, have a proper outlet
installed by a qualified electrician.
GROUNDING

SKU 94652 For technical questions, please call 1-800-444-3353 PAGE 8
GROUNDED TOOLS:TOOLS WITH THREE PRONG PLUGS
1. Tools marked with “Grounding Required” have a three wire cord and three prong
grounding plug. The plug must be connected to a properly grounded outlet. If
the tool should electrically malfunction or break down, grounding provides a low
resistance path to carry electricity away from the user, reducing the risk of elec-
tric shock. (See Figure A.)
2. The grounding prong in the plug is connected through the green wire inside the
cord to the grounding system in the tool. The green wire in the cord must be the
only wire connected to the tool’s grounding system and must never be attached
to an electrically “live” terminal. (See Figure A.)
3. Your tool must be plugged into an appropriate outlet, properly installed and
grounded in accordance with all codes and ordinances. The plug and outlet
should look like those in the following illustration. (See Figure A.)
FIGURE A
120 VOLT,
GROUNDED,
ELECTRICAL OUTLET
THIS PRODUCT
USES A
3-PRONG PLUG
DOUBLE INSULATED TOOLS: TOOLS WITH TWO PRONG PLUGS
4. Tools marked “Double Insulated” do not require grounding. They have a special
double insulation system which satisfies OSHA requirements and complies with
the applicable standards of Underwriters Laboratories, Inc., the Canadian
Standard Association, and the National Electrical Code. (See Figure B.)
5. Double insulated tools may be used in either of the 120 volt outlets shown in the
following illustration. (See Figure B.)
120 VOLT,
GROUNDED,
ELECTRICAL OUTLETS
THIS PRODUCT
DOES NOT
USE A
2-PRONG PLUG
FIGURE B

SKU 94652 For technical questions, please call 1-800-444-3353 PAGE 9
EXTENSION CORDS
1. Grounded tools require a three wire extension cord. Double Insulated tools
can use either a two or three wire extension cord.
2. As the distance from the supply outlet increases, you must use a heavier gauge
extension cord. Using extension cords with inadequately sized wire causes a
serious drop in voltage, resulting in loss of power and possible tool damage.
(See Figure C.)
3. The smaller the gauge number of the wire, the greater the capacity of the cord.
For example, a 14 gauge cord can carry a higher current than a 16 gauge cord.
(See Figure C.)
4. When using more than one extension cord to make up the total length, make
sure each cord contains at least the minimum wire size required.
(See Figure C.)
5. If you are using one extension cord for more than one tool, add the nameplate
amperes and use the sum to determine the required minimum cord size.
(See Figure C.)
6. Make sure your extension cord is properly wired and in good electrical condition.
Always replace a damaged extension cord or have it repaired by a qualified elec-
trician before using it.
7. Protect your extension cords from sharp objects, excessive heat, and damp or
wet areas.
RECOMMENDED MINIMUM WIRE GAUGE FOR EXTENSION CORDS*
(120 OR 240 VOLT)
NAMEPLATE
AMPERES
(At Full Load)
EXTENSION CORD LENGTH
25 Feet 50 Feet 75 Feet 100 Feet 150 Feet
0 – 2.0 18 18 18 18 16
2.1 – 3.4 18 18 18 16 14
3.5 – 5.0 18 18 16 14 12
5.1 – 7.0 18 16 14 12 12
7.1 – 12.0 18 14 12 10 -
12.1 – 16.0 14 12 10 - -
16.1 – 20.0 12 10 - - -
FIGURE C * Based on limiting the line voltage drop to five volts at
150% of the rated amperes.

SKU 94652 For technical questions, please call 1-800-444-3353 PAGE 10
SYMBOLOGY
Double Insulated
Canadian Standards
Association
Underwriters
Laboratories, Inc.
Volts Alternating Current
Amperes
No Load Revolutions
per Minute (RPM)
no
xxxx/min.
A
V ~
UNPACKING
When unpacking, check to make sure all the parts shown on the Parts Lists on pages 21
and 22 are included. If any parts are missing or broken, please call Harbor Freight Tools
at the number shown on the cover of this manual as soon as possible.
ASSEMBLY INSTRUCTIONS
NOTE:
For additional information regarding the parts listed in the following
pages, refer to the Assembly Diagrams on pages 23 and 24.
CAUTION! Always make sure the Power Switch (98) for the Bandsaw is in
its “OFF” position and the tool is unplugged from its electrical outlet prior to as-
sembling the tool, adding any accessories, or making adjustments to the tool.
To Install The Table:
1. With assistance, place the Table (6) upon the two Supports (128).
(See Figure D, next page.)
2. Align the four threaded mounting holes in the Table (6) with the four mounting
holes in the two Supports (128). (See Figure D.)
