CFF PRO Series Installation guide

CFF PRO SERIES ELITE HD SQUAT STANDS
Assembly&CareInstructions

THANK YOU!
First of all, thank you for purchasing the only        
bolttogether squat stands on the market capable of       
handling this kind of weight. Before you go throwing        
8001200lbs at these things, please review these      
instructions to ensure your stands are correctly      
assembledandlast.

INCLUDED IN THIS DOCUMENT

● explodeddrawing&partslist
● assemblysteps
● SPECIALPRECAUTIONS
● careforyoursquatstands


EXPLODED DRAWING & PARTS LIST

PLEASE MAKE SURE YOU HAVE ALL THE PIECES!


_
V.04.14.2015
1


No.
Description
Qty
No.
Description
Qty
1
RearBaseFrame
2
19
RubberBumper
4
2
FrontBaseFrame
2
20
PUWheel
4
3
TopUpright
2
21
EndCap
4
4
SpotterArm
2
22
PlasticSleeve
2
58
PinSet
2
23
Tag
2
9
BarHolder
2
24
AllenBolt,M6x12mm
44
10
ProtectingPlastic,95x40mm
4
25
FlatWasher,M8
10
11
ProtectingPlastic,95x40mm
4
26
FlatWasher,M12
8
12
ProtectingPlastic,50x40mm
4
27
NylonNut,M8
4
13
ProtectingPlastic,24x38mm
2
28
NylonNut,M12
4
14
ProtectingPlastic,158x38mm
2
29
AllenBolt,M12x125mm
4
15
ProtectingPlastic,84x38mm
2
30
AllenBolt,M8x50mm
4
16
ProtectingPlastic,48x43mm
2
31
AllenBolt,M8x40mm
2
17
ProtectingPlastic,35x48mm
2
32
Rivet
4
18
ProtectingPlastic,311x48mm
2


8


ASSEMBLY STEPS
STEP 1
Assemblebaseframe.
Attach rear base frame [1] to front base frame [2] using the long, M12x125mm bolts [29]. Slip (1)                 
M12 flat washer [26] over each bolt before running through front base frame and out other side of                 
rearbaseframe,thenaddanotherwasherandanM12nylonnut[28].


_
V.04.14.2015
2

STEP 2
Installuprights.
Sliptopupright[3]intoassembledbaseframe,lockingintoplacewithpin[5].
NotetheorientationoftheJhookuprightinthepicturebelow.




STEP 3
Attachspotterarms.
Spotterarmsattachwithremaininglockpins.
Note:Tightenallnuts&boltswithwrenchespriortouse.




_
V.04.14.2015
3

SPECIAL PRECAUTIONS
YOU CAN’T LIFT WHEN YOU’RE DEAD

!IMPORTANT!
You know these squat stands are designed to handle serious weight  1200lbs. It’s probably one of                
the reasons you bought them. Maxing out these stands requires special precautions. We strongly             
recommend loading the plate horns to weight the stand when going over 400lbs and sandbagging              
the front of the stands when crossing the 800lb mark. Beyond that, best practice is to bolt these                 
things to the floor. Failure to adhere to these recommendations can lead to some very, very               
baddays.



CARING FOR YOUR SQUAT STANDS
MAKE YOUR INVESTMENT LAST

Inspect&tighten
Periodically inspect the stands for signs of wear or loosening hardware. Make sure all nuts & bolts                
are tight. These are designed to support serious weight and deliver reliable service over many              
years,butitwillonlydosowhenproperlyassembledandmaintained.



CONTACT CFF WITH ANY QUESTIONS
WE WANT YOU HAPPY!

phone:(717)2077171
email:[email protected]

We’rehereifyouneedus.(Andweappreciateyourfeedback!)

