Chamberlain 882LMW User manual

To prevent possible SERIOUS INJURY or DEATH from
electrocution:
• Be sure power is NOT connected BEFORE installing door
control.
• Connect ONLY to 12 VOLT low voltage wires.
To prevent possible SERIOUS INJURY or DEATH from a closing
garage door:
• Install door control within sight of garage door, out of reach of
children at a minimum height of 5 feet (1.5 m), and away from
ALL moving parts of door.
• NEVER permit children to operate or play with door control
push buttons or remote control transmitters.
• Activate door ONLY when it can be seen clearly, is properly
adjusted, and there are no obstructions to door travel.
• ALWAYS keep garage door in sight until completely closed.
NEVER permit anyone to cross path of closing garage door.
• Unattended devices and features are to be used ONLY with
sectional doors.
MULTI-FUNCTION CONTROL PANEL
(SECURITY+ 2.0®)
For use with Security+ 2.0®Garage Door Openers, Wi-Fi®enabled
Security+ 2.0®Garage Door Openers (indicated by the Wi-Fi logo on
the garage door opener cover) and MyQ®accessories.
UNATTENDED OPERATION
The Timer-to-Close (TTC) feature, the MyQ®Smartphone Control app,
and MyQ®Garage Door and Gate Monitor are examples of unattended
close and are to be used ONLY with sectional doors. Any device or
feature that allows the door to close without being in the line of sight
of the door is considered unattended close. The Timer-to-Close (TTC)
feature, the MyQ®Smartphone Control, and any other MyQ®devices
are to be used ONLY with sectional doors.
INSTALLATION
To insert or release
wire, push in tab with
screwdriver tip.
7/16"
(11 mm)
7/16"
(11 mm)
5 feet (1.5 m)
minimum
NOTICE: To comply with FCC and or Industry Canada rules (IC), adjustment or modifications of
this receiver and/or transmitter are prohibited, except for changing the code setting or replacing
the battery. THERE ARE NO OTHER USER SERVICEABLE PARTS.
Tested to Comply with FCC Standards for Home or office use. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
GANG BOX
DRYWALL
6ABx1-1/4" Drywall Anchors
6-32x1"
LOCK
Prevents activation of the garage door opener from remote controls while
still allowing activation from the door control and keyless entry. Factory
default is OFF.
Turn ON: Press and hold the LOCK button for 2 seconds. The
command LED will blink as long as the lock feature is activated.
Turn OFF: Press and hold the LOCK button again for 2 seconds. The
command LED will stop blinking and normal operation will resume.
LIGHT
Press the LIGHT button to turn the garage door opener lights on or off.
The LIGHT button will not control the lights when the door is in motion.
When the lights are turned on they will stay on until the LIGHT button is
pressed again, or until the garage door opener is activated. Once the
garage door opener is activated the lights will turn off after a specified
period of time (see below).
TO CHANGE THE AMOUNT OF TIME THE GARAGE DOOR OPENER
LIGHTS WILL STAY ON
Press and hold the LOCK button until the garage door opener lights flash
(about 10 seconds). The garage door opener lights will flash up to 4
times to indicate current setting:
1 Flash = Lights stay on 1 ½ minutes
2 Flashes = Lights stay on 2 ½ minutes
3 Flashes = Lights stay on 3 ½ minutes
4 Flashes = Lights stay on 4 ½ minutes (factory default)
Repeat the steps above until your desired time frame is reached.
LIGHT FEATURE FOR THE SAFETY REVERSING SENSORS
The garage door opener lights will turn on when the safety reversing
sensor beam is interrupted. Factory default is ON.
Turn ON: Start with the garage door opener lights on. Press and hold
the LIGHT button to turn off the light, continue to hold until the light
turns on (about 10 seconds).
Turn OFF: Start with the garage door opener lights off. Press and
hold the LIGHT button to turn on the light, continue to hold until the
light turns off (about 10 seconds).
MAINTENANCE ALERT SYSTEM (MAS)
When the garage door opener needs to be serviced (approximately
4500 garage door opener cycles) the command and service LEDs will
alternately blink back and forth. Factory default is OFF.
Turn ON/OFF: Press and hold the LEARN button. Then press the LIGHT
button. The service LED will blink the status; ON is 2 blinks and OFF is 3
blinks.
LEARN Button
LIGHT Button
Service LED
(red)
LOCK Button
Command LED
(yellow)
PROGRAM
1
2
3
PIN
?? ??
REMOTE CONTROL
1. Press the LEARN button on the
door control twice. The
Command LED will blink.
2. Press and release the button on
the remote control that you wish
to operate your garage door.
The garage door opener lights will
flash (or two clicks will be heard)
and the Command LED will stop
blinking when the code has been
programmed.
KEYLESS ENTRY
1. Press the LEARN button on the door
control twice. The Command LED will
blink.
2. Enter a 4-digit personal identification
number (PIN) on the keypad. Then
press the ENTER button.
The garage door opener lights will flash (or
two clicks will be heard) and the Command
LED will stop blinking when the code has
been programmed.
1. Lift the push bar on the door control. Press and release the LEARN button. The garage door
opener will beep once and the command LED on the door control will blink to indicate Wi-Fi
learn mode. You have 20 minutes to complete the connection process.
2. On your mobile device, go to Settings > Wi-Fi and select the network with the “MyQ-” prefix.
Command LED
3. Launch the web browser on your smartphone
or tablet. Enter setup.myqdevice.com into
the browser address bar. Follow the on
screen prompts to connect the garage door
opener to your Wi-Fi network. The MyQ serial
number will display on screen. Write the
serial number in the space below.
4. Download the MyQ app from the App Store®
or Google Play™ store. Sign up for your MyQ
account and add the MyQ serial number to
your account.
If you are unsuccessful adding your device,
try an alternate web browser or visit WiFiHelp.
LiftMaster.com.
Unplug the garage door opener. Disconnect
the battery (if applicable).
1. Connect the wires to the back of the door
control.
2. Secure the door control to the wall.
3. Connect the wires to the garage door
opener.
Plug in the garage door opener and reconnect
the battery. The command LED on the door
control will blink if installed correctly. To
synchronize the garage door opener and the
door control, press the push bar up to 3 times,
until the garage door opener activates.
FEATURES
CONNECT YOUR GARAGE DOOR OPENER
TO YOUR HOME WI-FI®NETWORK
(for Wi-Fi garage door
openers ONLY)
Press the push bar to open
or close the door.
Wi-Fi®is a registered trademark of Wi-Fi Alliance.
App Store is a service mark of Apple Inc.
Google Play is a trademark of Google Inc.
RED
WHITE
MODEL 882LMW
ONE YEAR LIMITED WARRANTY
LiftMaster warrants to the first consumer purchaser of this
product that it is free from defect in materials and/or workmanship
for a period of 1 year from the date of purchase.
1-800-528-9131
LiftMaster.com
© 2016, LiftMaster
Tous droits réservés
114A4907
