Chamberlain APT Installation and operating instructions

ADDENDUM
MODEL APT
LOGIC CONTROL (VER. 2.0)
INDUSTRIAL DUTY DOOR OPERATOR
This addendum is to be used in conjunction with T manual 01-17278. Refer
to manual 01-17278 for all mounting and wiring instructions. APT s ecifi-
cations and com onent identification are included with this addendum. For
s ecifications, service, or re lacement art requirements, use this adden-
dum in lieu of those include with the manual.
c2002, The Chamberlain Group, Inc.
All rights Reserved
01-10384H
LISTED DOOR OPERATOR
41B6
MECHANICAL
DRIVE REDUCTION:.............Primary: Heavy duty
(5L) V-Belt. Secondary: #41 chain/sprocket. Output:
#48 chain
OUTPUT SHAFT SPEED:.....96 R.P.M.
DOOR SPEED:......................7 - 8” per sec.
depending on door
BRAKE:(Optional) .................Solenoid actuated disc
BEARINGS:...........................Output Shaft: Shielded
Ball Bearing. Clutch & Intermediate Shaft: Shielded
Ball Bearing.
MOTOR
TYPE: .................................Continuous duty
HORSEPOWER:.................1/2 Hp
SPEED:...............................1725 RPM
VOLTAGE: ..........................
115/230 Volts - Single phase
230/460 Volts - Three phase
CURRENT: .........................See motor nameplate
SAFETY
DISCONNECT: .............Quick disconnect door arm for
emergency manual door operation.
REVERSING EDGE: ....(Optional) Electric or pneumatic
sensing device attached to the bottom edge of door.
A REVERSING DEVICE IS STRONGLY RECOM-
MENDED FOR
ALL COMMERCIAL OPERATOR
INSTALLATIONS.
REQUIRED WHEN THE 3 BUTTON
CONTROL STATION IS OUT OF SIGHT OF DOOR
OR ANY OTHER CONTROL (AUTOMATIC OR MAN-
UAL) IS USED.
SPECIFICATIONS
MOTOR WIRING DIAGRAM - 115/230 VOLT / SINGLE PHASE
ELECTRICAL
TRANSFORMER:.............24VAC
CONTROL STATION:......NEMA 1 three button station.
OPEN/CLOSE/STOP W/ LED
WIRING TYPE:.................C2 (Factory Shipped)
Momentary contact to OPEN & STOP, constant pres-
sure to CLOSE, open override plus wiring for sensing
device to reverse. See Model T Manual pages 16, 17
and 18 for optional wiring types and operating modes.
LIMIT ADJUST:................Linear driven, fully
adjustable screw type cams. Adjustable to 24 feet.
NOTE: Refer to T logic II Manual for O3 (3-Phase) wiring.
See below for internal wiring of motor in lieu of the motor diagrams shown in Model T owner’s manual. See Model
T owner’s manual for all power and control connections.
LOGIC CONTROL
L
C2 Wiring
FACTORY SET
See pages 13 & 14
for other wiring
configurations
The Maintenance Alert System
allows the installer to set an internal
Maintenance Cycle Counter. An LED
on the 3-button station will signal when
the set number of cycles is reached or
when the opener requires immediate
service.
TM
PATENT PENDING

3
2
MODEL APT - ILLUSTRATED PARTS
C2
C14
C15
C3
C16
C13
S8
S1 S7
S3
S2
O6
O3
O2
O5
O9
1
2
B12
H3
H5
H7 H6
4
H4
H2
H1
O2
O4
O7
O12
S5 S2
S4
C11
C7
C12 C5
C4
C3
C6 C8 C1
B1
B14
B6
B15 B14
B7
B9
B14
3
B13 B11
B10
B8
B4
B3 B15
B2 B11
B11
B5
MODEL APT - REPLACEMENT PARTS LIST
INDIVIDUAL COMPONENTS
PART #
10-10030
K20-1050B2RL
K20-3050B4RL
K-BAPT5011
K-BAPT5021
K-BAPT5023
K-BAPT5043
Varies
ITEM
1
2
3
4
QTY
1
1
1
1
1
1
1
1
DESCRIPTION
Frame Spacer Bracket
Motor Kit (BAPT5011L2 & BAPT5021L2)
Motor Kit (BAPT5023L2 & BAPT5043L2)
Electrical Box Kit (Model BAPT5011L2)
Electrical Box Kit (Model BAPT5021L2)
Electrical Box Kit (Model BAPT5023L2)
Electrical Box Kit (Model BAPT5043L2)
Track
K72-13058 INTERMEDIATE SHAFT KIT
PART #
11-10016
12-729
15-41B10G1
15-41B16GXX
19-41023
86-RP08-102
86-RP08-200
ITEM
S1
S2
S3
S4
S5
S7
S8
QTY
1
2
1
1
1
1
1
DESCRIPTION
Intermediate Shaft
Ball Bearing, 3/4”
Sprocket, 41B10 x 3/4” Bore PM
Sprocket, 41B16 x 3/4” Bore
Intermediate Drive Chain, #41 x 23
Roll Pin, 1/4” Dia x 1-1/8” Long
Roll Pin, 1/4” Dia x 2” Long
K72-13059 OUTPUT SHAFT KIT
PART #
11-10124
12-10331
15-41B32GXX
15-48B10G1
15-48B10GXX
19-41047
19-48033M
80-10023
86-RP08-102
86-RP08-108
80-10022
87-P-075
ITEM
O1
O2
O3
O4
O5
O6
O7
O8
O9
O10
O11
O12
QTY
1
2
1
1
1
1
1
1
2
1
4
1
DESCRIPTION
APT Output Shaft
Flange Ball Bearing, 3/4” ID
Sprocket, 41B32 x 3/4” Bore
Sprocket, 48B10 x 3/4” Bore PM
Sprocket, 48B10 x 3/4” Bore
Drive Chain, #41 x 47
Chain, #48 Links w/Master
Shim Washer, Thin
Roll Pin, 1/4” Dia x 1-1/8” Long
Roll Pin, 1/4” Dia x 2” Long
Shim Washer, Thick
Retainer, 3/4”
71-AB120 (115V BRAKE KIT)
71-AB240 (230/460V BRAKE KIT)
PART #
10-10187
10-10190
11-10192
11-10193
18-10914
19-48001
22-120
22-240
31-10186
75-12794
75-12795
75-12796
80-11598
80-5001
82-WX10-08T
86-CP04-112
ITEM
B1
B2
B3
B4
B5
B6
B7
B8
B9
B10
B11
B12
B13
B14
B15
QTY
1
1
4
4
4
1
1
2
1
1
1
4
1
12
2
DESCRIPTION
Brake Solenoid Cover
Brake Release Lever
Spring Cup for Brake Assembly
Brake Stud
Spring, Compression x .87” Long
Chain, #48 x 1 Pitch
Solenoid, 120V (115V Units)
Solenoid, 240/460V (230/460V Units)
Spacer, .20 ID x .31 Long
Brake Mounting Plate Assembly
Brake Pressure Plate Assembly
APT Brake Motor Pulley Assembly
Nut, #10-32 Coupling Hex
Key, 3/16 x 3/16 x 1-3/4” Long
Screw, #10-32 x 1/2” Serrated Flange
Cotter Pin, 1/8” x 1-3/4” Zinc Plate
K77-10386 HARDWARE KIT
PART #
10-10203
10-10204
10-10205
10-10371
75-10259
75-10387
75-10388
K75-10406
ITEM
H1
H2
H3
H4
H5
H6
H7
-
QTY
1
1
1
1
2
1
1
1
DESCRIPTION
Curved Arm
Door Bracket
Header Bracket
Straight Arm for APT
Track Spacer Assembly
Slider Assembly
Chain Tensioner Assembly
Drive Link Assembly
PART #
10-10203
10-10371
ITEM
H1
H4
QTY
1
1
DESCRIPTION
Curved Arm
Straight Arm for APT
K75-13074 STRAIGHT AND CURVED ARM ASSY
INDIVIDUAL ASSEMBLY SERVICE KITS
PART #
K75-10387
K75-10388
ITEM
H6
H7
DESCRIPTION
Slider Assembly
Chain Tensioner Assembly
K72-13057 CLUTCH SHAFT KIT
PART #
10-10166
11-10014
12-729
15-41B10G1
16-5L300
17-10165
18-10164
39-10167
84-SH-76
85-FW-75
86-CP05-108
86-RP08-102
86-RP08-200
87-P-075
ITEM
C1
C2
C3
C4
C5
C6
C7
C8
C11
C12
C13
C14
C15
C16
QTY
1
1
2
1
1
1
1
1
1
5
1
1
1
1
DESCRIPTION
Clutch Plate
Clutch Shaft
Ball Bearing, 3/4”
Sprocket, 41B10 x 3/4” Bore PM
V Belt, 5L x 30”
Pulley, 7” OD
Spring, Clutch
Clutch Disc
Nut, 3/4-16 Castle
Flatwasher, 3/4”
Cotter Pin, 5/32” x 1-1/2” Long
Roll Pin, 1/4” Dia x 1-1/8” Long
Roll Pin, 1/4” Dia x 2” Long
Push Ring, 3/4” ID
O11
O1
O9
O10
BRAKE ASSEMBLY

3
2
MODEL APT - ILLUSTRATED PARTS
C2
C14
C15
C3
C16
C13
S8
S1 S7
S3
S2
O6
O3
O2
O5
O9
1
2
B12
H3
H5
H7 H6
4
H4
H2
H1
O2
O4
O7
O12
S5 S2
S4
C11
C7
C12 C5
C4
C3
C6 C8 C1
B1
B14
B6
B15 B14
B7
B9
B14
3
B13 B11
B10
B8
B4
B3 B15
B2 B11
B11
B5
MODEL APT - REPLACEMENT PARTS LIST
INDIVIDUAL COMPONENTS
PART #
10-10030
K20-1050B2RL
K20-3050B4RL
K-BAPT5011
K-BAPT5021
K-BAPT5023
K-BAPT5043
Varies
ITEM
1
2
3
4
QTY
1
1
1
1
1
1
1
1
DESCRIPTION
Frame Spacer Bracket
Motor Kit (BAPT5011L2 & BAPT5021L2)
Motor Kit (BAPT5023L2 & BAPT5043L2)
Electrical Box Kit (Model BAPT5011L2)
Electrical Box Kit (Model BAPT5021L2)
Electrical Box Kit (Model BAPT5023L2)
Electrical Box Kit (Model BAPT5043L2)
Track
K72-13058 INTERMEDIATE SHAFT KIT
PART #
11-10016
12-729
15-41B10G1
15-41B16GXX
19-41023
86-RP08-102
86-RP08-200
ITEM
S1
S2
S3
S4
S5
S7
S8
QTY
1
2
1
1
1
1
1
DESCRIPTION
Intermediate Shaft
Ball Bearing, 3/4”
Sprocket, 41B10 x 3/4” Bore PM
Sprocket, 41B16 x 3/4” Bore
Intermediate Drive Chain, #41 x 23
Roll Pin, 1/4” Dia x 1-1/8” Long
Roll Pin, 1/4” Dia x 2” Long
K72-13059 OUTPUT SHAFT KIT
PART #
11-10124
12-10331
15-41B32GXX
15-48B10G1
15-48B10GXX
19-41047
19-48033M
80-10023
86-RP08-102
86-RP08-108
80-10022
87-P-075
ITEM
O1
O2
O3
O4
O5
O6
O7
O8
O9
O10
O11
O12
QTY
1
2
1
1
1
1
1
1
2
1
4
1
DESCRIPTION
APT Output Shaft
Flange Ball Bearing, 3/4” ID
Sprocket, 41B32 x 3/4” Bore
Sprocket, 48B10 x 3/4” Bore PM
Sprocket, 48B10 x 3/4” Bore
Drive Chain, #41 x 47
Chain, #48 Links w/Master
Shim Washer, Thin
Roll Pin, 1/4” Dia x 1-1/8” Long
Roll Pin, 1/4” Dia x 2” Long
Shim Washer, Thick
Retainer, 3/4”
71-AB120 (115V BRAKE KIT)
71-AB240 (230/460V BRAKE KIT)
PART #
10-10187
10-10190
11-10192
11-10193
18-10914
19-48001
22-120
22-240
31-10186
75-12794
75-12795
75-12796
80-11598
80-5001
82-WX10-08T
86-CP04-112
ITEM
B1
B2
B3
B4
B5
B6
B7
B8
B9
B10
B11
B12
B13
B14
B15
QTY
1
1
4
4
4
1
1
2
1
1
1
4
1
12
2
DESCRIPTION
Brake Solenoid Cover
Brake Release Lever
Spring Cup for Brake Assembly
Brake Stud
Spring, Compression x .87” Long
Chain, #48 x 1 Pitch
Solenoid, 120V (115V Units)
Solenoid, 240/460V (230/460V Units)
Spacer, .20 ID x .31 Long
Brake Mounting Plate Assembly
Brake Pressure Plate Assembly
APT Brake Motor Pulley Assembly
Nut, #10-32 Coupling Hex
Key, 3/16 x 3/16 x 1-3/4” Long
Screw, #10-32 x 1/2” Serrated Flange
Cotter Pin, 1/8” x 1-3/4” Zinc Plate
K77-10386 HARDWARE KIT
PART #
10-10203
10-10204
10-10205
10-10371
75-10259
75-10387
75-10388
K75-10406
ITEM
H1
H2
H3
H4
H5
H6
H7
-
QTY
1
1
1
1
2
1
1
1
DESCRIPTION
Curved Arm
Door Bracket
Header Bracket
Straight Arm for APT
Track Spacer Assembly
Slider Assembly
Chain Tensioner Assembly
Drive Link Assembly
PART #
10-10203
10-10371
ITEM
H1
H4
QTY
1
1
DESCRIPTION
Curved Arm
Straight Arm for APT
K75-13074 STRAIGHT AND CURVED ARM ASSY
INDIVIDUAL ASSEMBLY SERVICE KITS
PART #
K75-10387
K75-10388
ITEM
H6
H7
DESCRIPTION
Slider Assembly
Chain Tensioner Assembly
K72-13057 CLUTCH SHAFT KIT
PART #
10-10166
11-10014
12-729
15-41B10G1
16-5L300
17-10165
18-10164
39-10167
84-SH-76
85-FW-75
86-CP05-108
86-RP08-102
86-RP08-200
87-P-075
ITEM
C1
C2
C3
C4
C5
C6
C7
C8
C11
C12
C13
C14
C15
C16
QTY
1
1
2
1
1
1
1
1
1
5
1
1
1
1
DESCRIPTION
Clutch Plate
Clutch Shaft
Ball Bearing, 3/4”
Sprocket, 41B10 x 3/4” Bore PM
V Belt, 5L x 30”
Pulley, 7” OD
Spring, Clutch
Clutch Disc
Nut, 3/4-16 Castle
Flatwasher, 3/4”
Cotter Pin, 5/32” x 1-1/2” Long
Roll Pin, 1/4” Dia x 1-1/8” Long
Roll Pin, 1/4” Dia x 2” Long
Push Ring, 3/4” ID
O11
O1
O9
O10
BRAKE ASSEMBLY

ADDENDUM
MODEL APT
LOGIC CONTROL (VER. 2.0)
INDUSTRIAL DUTY DOOR OPERATOR
This addendum is to be used in conjunction with T manual 01-17278. Refer
to manual 01-17278 for all mounting and wiring instructions. APT s ecifi-
cations and com onent identification are included with this addendum. For
s ecifications, service, or re lacement art requirements, use this adden-
dum in lieu of those include with the manual.
c2002, The Chamberlain Group, Inc.
All rights Reserved
01-10384H
LISTED DOOR OPERATOR
41B6
MECHANICAL
DRIVE REDUCTION:.............Primary: Heavy duty
(5L) V-Belt. Secondary: #41 chain/sprocket. Output:
#48 chain
OUTPUT SHAFT SPEED:.....96 R.P.M.
DOOR SPEED:......................7 - 8” per sec.
depending on door
BRAKE:(Optional) .................Solenoid actuated disc
BEARINGS:...........................Output Shaft: Shielded
Ball Bearing. Clutch & Intermediate Shaft: Shielded
Ball Bearing.
MOTOR
TYPE: .................................Continuous duty
HORSEPOWER:.................1/2 Hp
SPEED:...............................1725 RPM
VOLTAGE: ..........................
115/230 Volts - Single phase
230/460 Volts - Three phase
CURRENT: .........................See motor nameplate
SAFETY
DISCONNECT: .............Quick disconnect door arm for
emergency manual door operation.
REVERSING EDGE: ....(Optional) Electric or pneumatic
sensing device attached to the bottom edge of door.
A REVERSING DEVICE IS STRONGLY RECOM-
MENDED FOR
ALL COMMERCIAL OPERATOR
INSTALLATIONS.
REQUIRED WHEN THE 3 BUTTON
CONTROL STATION IS OUT OF SIGHT OF DOOR
OR ANY OTHER CONTROL (AUTOMATIC OR MAN-
UAL) IS USED.
SPECIFICATIONS
MOTOR WIRING DIAGRAM - 115/230 VOLT / SINGLE PHASE
ELECTRICAL
TRANSFORMER:.............24VAC
CONTROL STATION:......NEMA 1 three button station.
OPEN/CLOSE/STOP W/ LED
WIRING TYPE:.................C2 (Factory Shipped)
Momentary contact to OPEN & STOP, constant pres-
sure to CLOSE, open override plus wiring for sensing
device to reverse. See Model T Manual pages 16, 17
and 18 for optional wiring types and operating modes.
LIMIT ADJUST:................Linear driven, fully
adjustable screw type cams. Adjustable to 24 feet.
NOTE: Refer to T logic II Manual for O3 (3-Phase) wiring.
See below for internal wiring of motor in lieu of the motor diagrams shown in Model T owner’s manual. See Model
T owner’s manual for all power and control connections.
LOGIC CONTROL
L
C2 Wiring
FACTORY SET
See pages 13 & 14
for other wiring
configurations
The Maintenance Alert System
allows the installer to set an internal
Maintenance Cycle Counter. An LED
on the 3-button station will signal when
the set number of cycles is reached or
when the opener requires immediate
service.
TM
PATENT PENDING
