Channel Vision C-0314 User manual

© 01/99, CHANNEL VISION™
ChannelVision
LimitedWarranty
Channel Vision Technology will repair or replace any defect
in material or workmanship which occur during normal use
of this product with new or rebuilt parts, free of charge in the
USA, for two years from the date of original purchase. This
warranty does not cover damages in shipment, failures
caused by other products not supplied by Channel Vision
Technology, or failures due to accident, misuse, abuse, or
alteration of the equipment. This warranty extends only to
the original purchaser. A purchase receipt, invoice, or other
proof of original purchase date will be required before
warranty repairs are provided.
Mail in service can be obtained during the warranty period by
calling toll free [phone]. A Return Authorization
number must be obtained in advance and be marked on the
outside of the shipping carton.
This warranty gives you specific legal rights, and you may
have other rights which vary from state to state. If a problem
with this product develops during or after the warranty
period, please contact Channel Vision, your dealer, or any
factory-authorized service center.
C-0314
8dB RF Amplified Splitter
234 FISCHER AVENUE lCOSTA MESA, CA 92626
[phone] l(800) 840-0288 l(714) 424-6510 FAX
HTTP://WWW.CHANNELVISION.COM lE-MAIL: [e-mail]
Central

Description
Channel Vision’s 8dB power injected amplifier increases the strength of the
incoming cable or antenna signal. The increased signal strength means that
you can distribute the television signal longer distances and to more outputs.
Unlike most RF amplifiers, the C-0314 uses an external power supply that
can be connected directly to the unit using a coax “F” connector. For added
versatility the power injection feature was removed so we could pass IR.
Instructions
Step 1: Snap the C-0314 into C-0112,C-0119,C-0138,C-0150 chassis of your
choice.
Step 2: Connect the incoming cable or antenna line to the INPUT port.
Step 3: Connect the outgoing coax cable to the OUTPUT port to distribute the signal
to 4 TV locations or a passive splitter.
Step 4: Connect the power transformer to the DC12V INPUT.
Please Note:
The unused trunk line connector or unused output of the last outlet device in each
trunk line MUST BE TERMINATED using a 75Ωterminator (model 2101).
Standard Wiring Layout
Cable or
Antenna
output
CHANNEL VISION
CentralCentral
C-0314
Warning
To prevent fire or shock hazard, do not
expose this appliance to rain or moisture
Specifications
Bandwidth 45-1000Mhz
Gain 8dB +/-1.5
Flatness +/-1dB
Return Loss (min) 14dB
Return 5-42Mhz
Dist. X-Mod. -70dB
CTB -65dB
Power Supply 12V/55mA
