Channel Vision CVT-2/8WB User manual

C-0333
CVT-2/8WB
2x8 Amplifier for Standard & Wide-Band
CATV Systems
0
1

Gain:
Forward Path (54-860MHz): +4.5dB, (975-1525MHz): Passive
Reverse Path (5-42MHz): Unity
1
5
2
6
3
7
4
8
Cable In
+4.5dB
12VDC
MOD In
-15.5dB
TM
C H A N N E L V I S I O N CVT-2/8WB
IR
Passing
Gain:
Forward Path (54-860MHz): +4.5dB, (975-1525MHz): Passive
Reverse Path (5-42MHz): Unity
1
5
2
6
3
7
4
8
Cable In
+4.5dB
12VDC
MOD In
-15.5dB
TM
C H A N N E L V I S I O N CVT-2/8WB
IR
Passing
23
The CVT-2/8WB and C-0333 are 8-output amplified splitters with a built-in
combiner for modulated signals. They allow IR signals to pass through the
modulator input to the TV outputs, making it a perfect match for the
E2200IR, E3200IR or E4200IR. The CVT-2/8WB is designed to mount
directly on any flat surface, while the C-0333 can snap directly into a
structured wiring enclosure.
Features:
!8 Amplified outputs: 4.5dB Gain
!Amplified return path from 5-42MHz
!Compatible with Advanced Wide Bandwidth Digital CATV systems
!Supports 1 modulator input
!Allows IR pass through on the modulator input port
!Easy installation
Accessories Included:
Power Supply 75 ohm Terminators
CVT-2/8WB
C-0333
Basic Amplified Splitter Application
Connect the CVT-2/8WB as shown and locate it at the main distribution point
in the house. The CVT-2/8WB will supply the amplified TV signal to 8 TV
locations.
TV set TV set
CVT-2/8WB
TV set TV set
MOD IN
Connect modulator here
MOD IN
Connect modulator here
TV OUTPUTS
Connect TVs here
TV OUTPUTS
Connect TVs here
POWER IN
Connect power supply here
POWER IN
Connect power supply here
12VDC, 500mA
CABLE IN...Connect the antenna
or cable service feed here
CABLE IN...Connect the antenna
or cable service feed here
Input from
Antenna or CATV
Connect up to 8 TVs
Terminate any unused outputs
Power
Supply
C-0333
Wide-Band Amplifier With Active Return Path
POWER INPOWER IN CABLE INCABLE IN
TV OUTPUTSTV OUTPUTS +4.5 dB+4.5 dB 12 VDC12 VDC
MOD INMOD IN 11223344
55667788

Gain:
Forward Path (54-860MHz): +4.5dB, (975-1525MHz): Passive
Reverse Path (5-42MHz): Unity
1
5
2
6
3
7
4
8
Cable In
+4.5dB
12VDC
MOD In
-15.5dB
TM
C H A N N E L V I S I O N CVT-2/8WB
IR
Passing
Gain:
Forward Path (54-860MHz): +4.5dB, (975-1525MHz): Passive
Reverse Path (5-42MHz): Unity
1
5
2
6
3
7
4
8
Cable In
+4.5dB
12VDC
MOD In
-15.5dB
TM
C H A N N E L V I S I O N CVT-2/8WB
IR
Passing
23
The CVT-2/8WB and C-0333 are 8-output amplified splitters with a built-in
combiner for modulated signals. They allow IR signals to pass through the
modulator input to the TV outputs, making it a perfect match for the
E2200IR, E3200IR or E4200IR. The CVT-2/8WB is designed to mount
directly on any flat surface, while the C-0333 can snap directly into a
structured wiring enclosure.
Features:
!8 Amplified outputs: 4.5dB Gain
!Amplified return path from 5-42MHz
!Compatible with Advanced Wide Bandwidth Digital CATV systems
!Supports 1 modulator input
!Allows IR pass through on the modulator input port
!Easy installation
Accessories Included:
Power Supply 75 ohm Terminators
CVT-2/8WB
C-0333
Basic Amplified Splitter Application
Connect the CVT-2/8WB as shown and locate it at the main distribution point
in the house. The CVT-2/8WB will supply the amplified TV signal to 8 TV
locations.
TV set TV set
CVT-2/8WB
TV set TV set
MOD IN
Connect modulator here
MOD IN
Connect modulator here
TV OUTPUTS
Connect TVs here
TV OUTPUTS
Connect TVs here
POWER IN
Connect power supply here
POWER IN
Connect power supply here
12VDC, 500mA
CABLE IN...Connect the antenna
or cable service feed here
CABLE IN...Connect the antenna
or cable service feed here
Input from
Antenna or CATV
Connect up to 8 TVs
Terminate any unused outputs
Power
Supply
C-0333
Wide-Band Amplifier With Active Return Path
POWER INPOWER IN CABLE INCABLE IN
TV OUTPUTSTV OUTPUTS +4.5 dB+4.5 dB 12 VDC12 VDC
MOD INMOD IN 11223344
55667788

45
Cascaded Application with IR Control
The IR engine built into the E2200IR, E3200IR, and E4200IR can support up
to 8 TV locations with IR receivers. Note: any TV location that does not have
IR receiver needs to be DC blocked using model 3109.
Large System Amplified Splitter Application
The CVT-2/8WB can be cascaded for situations that require more than 8
outputs. Each of the 8 outputs of the CVT-2/8WB can feed the input of an
additional CVT-2/8WB creating a system with 64 TV outputs.
CVT-2/8WB
IR-4101
Input from
Antenna/CATV
Power Supplies
not shown
RF OUTRF OUT
DC 15V INDC 15V IN
OUTPUT
IR
OUTPUT
IR
CABLECABLE
ANTENNAANTENNA
ANTENNA + CABLEANTENNA + CABLE
VIDEOVIDEO
AUDIOAUDIO
L RL R
BB
AA
VIDEOVIDEO
AUDIOAUDIO
L RL R
DD
CC
1144
33
22
11223344
OUTPUT
IR
OUTPUT
IR
Sat Receiver
IR Emitter
E4200IR
CameraCameraCamera
TV set
123
456
789
0
eow
Pr
Gain:
Forward Path (54-860MHz): +4.5dB, (975-1525MHz): Passive
Reverse Path (5-42MHz): Unity
1
5
2
6
3
7
4
8
Cable In
+4.5dB
12VDC
MOD In
-15.5dB
TM
C H A N N E L V I S I O N CVT-2/8WB
IR
Passing
Gain:
Forward Path (54-860MHz): +4.5dB, (975-1525MHz): Passive
Reverse Path (5-42MHz): Unity
1
5
2
6
3
7
4
8
Cable In
+4.5dB
12VDC
MOD In
-15.5dB
TM
C H A N N E L V I S I O N CVT-2/8WB
IR
Passing
Gain:
Forward Path (54-860MHz): +4.5dB, (975-1525MHz): Passive
Reverse Path (5-42MHz): Unity
1
5
2
6
3
7
4
8
Cable In
+4.5dB
12VDC
MOD In
-15.5dB
TM
C H A N N E L V I S I O N CVT-2/8WB
IR
Passing
Gain:
Forward Path (54-860MHz): +4.5dB, (975-1525MHz): Passive
Reverse Path (5-42MHz): Unity
1
5
2
6
3
7
4
8
Cable In
+4.5dB
12VDC
MOD In
-15.5dB
TM
C H A N N E L V I S I O N CVT-2/8WB
IR
Passing
Gain:
Forward Path (54-860MHz): +4.5dB, (975-1525MHz): Passive
Reverse Path (5-42MHz): Unity
1
5
2
6
3
7
4
8
Cable In
+4.5dB
12VDC
MOD In
-15.5dB
TM
C H A N N E L V I S I O N CVT-2/8WB
IR
Passing
CVT-2/8WB (Master)
CVT-2/8WB (Slave)
CVT-2/8WB (Slave)
CVT-2/8WB (Slave)
Input from
Antenna/CATV
Use a total of 9 CVT-2/8WBs to achieve 64 TV outputs.
Power Supplies
not shown
Terminate any unused outputs
(1 of 8 from this slave)
(1 of 8 from this slave)
(1 of 8 from this slave)
Note: For runs of 150’
or less use one of
the Master outputs.
Note: For runs between
150-250’ use one of the
Slave outputs.
TV set
TV set
TV set
TV set
RF Filter
Use DC block
& terminator
on any unused output

45
Cascaded Application with IR Control
The IR engine built into the E2200IR, E3200IR, and E4200IR can support up
to 8 TV locations with IR receivers. Note: any TV location that does not have
IR receiver needs to be DC blocked using model 3109.
Large System Amplified Splitter Application
The CVT-2/8WB can be cascaded for situations that require more than 8
outputs. Each of the 8 outputs of the CVT-2/8WB can feed the input of an
additional CVT-2/8WB creating a system with 64 TV outputs.
CVT-2/8WB
IR-4101
Input from
Antenna/CATV
Power Supplies
not shown
RF OUTRF OUT
DC 15V INDC 15V IN
OUTPUT
IR
OUTPUT
IR
CABLECABLE
ANTENNAANTENNA
ANTENNA + CABLEANTENNA + CABLE
VIDEOVIDEO
AUDIOAUDIO
L RL R
BB
AA
VIDEOVIDEO
AUDIOAUDIO
L RL R
DD
CC
1144
33
22
11223344
OUTPUT
IR
OUTPUT
IR
Sat Receiver
IR Emitter
E4200IR
CameraCameraCamera
TV set
123
456
789
0
eow
Pr
Gain:
Forward Path (54-860MHz): +4.5dB, (975-1525MHz): Passive
Reverse Path (5-42MHz): Unity
1
5
2
6
3
7
4
8
Cable In
+4.5dB
12VDC
MOD In
-15.5dB
TM
C H A N N E L V I S I O N CVT-2/8WB
IR
Passing
Gain:
Forward Path (54-860MHz): +4.5dB, (975-1525MHz): Passive
Reverse Path (5-42MHz): Unity
1
5
2
6
3
7
4
8
Cable In
+4.5dB
12VDC
MOD In
-15.5dB
TM
C H A N N E L V I S I O N CVT-2/8WB
IR
Passing
Gain:
Forward Path (54-860MHz): +4.5dB, (975-1525MHz): Passive
Reverse Path (5-42MHz): Unity
1
5
2
6
3
7
4
8
Cable In
+4.5dB
12VDC
MOD In
-15.5dB
TM
C H A N N E L V I S I O N CVT-2/8WB
IR
Passing
Gain:
Forward Path (54-860MHz): +4.5dB, (975-1525MHz): Passive
Reverse Path (5-42MHz): Unity
1
5
2
6
3
7
4
8
Cable In
+4.5dB
12VDC
MOD In
-15.5dB
TM
C H A N N E L V I S I O N CVT-2/8WB
IR
Passing
Gain:
Forward Path (54-860MHz): +4.5dB, (975-1525MHz): Passive
Reverse Path (5-42MHz): Unity
1
5
2
6
3
7
4
8
Cable In
+4.5dB
12VDC
MOD In
-15.5dB
TM
C H A N N E L V I S I O N CVT-2/8WB
IR
Passing
CVT-2/8WB (Master)
CVT-2/8WB (Slave)
CVT-2/8WB (Slave)
CVT-2/8WB (Slave)
Input from
Antenna/CATV
Use a total of 9 CVT-2/8WBs to achieve 64 TV outputs.
Power Supplies
not shown
Terminate any unused outputs
(1 of 8 from this slave)
(1 of 8 from this slave)
(1 of 8 from this slave)
Note: For runs of 150’
or less use one of
the Master outputs.
Note: For runs between
150-250’ use one of the
Slave outputs.
TV set
TV set
TV set
TV set
RF Filter
Use DC block
& terminator
on any unused output

Gain:
Forward Path (54-860MHz): +4.5dB, (975-1525MHz): Passive
Reverse Path (5-42MHz): Unity
1
5
2
6
3
7
4
8
Cable In
+4.5dB
12VDC
MOD In
-15.5dB
TM
C H A N N E L V I S I O N CVT-2/8WB
IR
Passing
PRO
CH AN NE L
TM
VI S I O N
CH AN NE L
VI S I O NTM
Model
P-0321
CATV Input MOD Input
Output
Power
IR Out
Pat. Pending
Part No. HS-2
2-WAY SPLITTER/COMBINER
5MHz-1GHz All Port DC passing
TM
CHAN NEL VISI O N
IN/out
OUT/in OUT/in
Digital CATV
Location
Analog CATV
Location
odulat r
Mo
CATV
e
Chann l
VisionTM
A0511
CVT-2/8WB
P-0321
Input from
Antenna/CATV
RF OUTRF OUT
DC 15V INDC 15V IN
OUTPUT
IR
OUTPUT
IR
CABLECABLE
ANTENNAANTENNA
ANTENNA + CABLEANTENNA + CABLE
VIDEOVIDEO
AUDIOAUDIO
L RL R
BB
AA
VIDEOVIDEO
AUDIOAUDIO
L RL R
DD
CC
1144
33
22
11223344
OUTPUT
IR
OUTPUT
IR
Sat Receiver
IR Emitter
E4200IR
CameraCameraCamera
F Fi ter
R l
123
456
789
0
w
Poer
Part No. HS-2
2-WAY SPLITTER/COMBINER
5MHz-1GHz All Port DC passing
TM
CHA NN EL VISI O N
IN/out
OUT/inOUT/in
Using the CVT-2/8WB with the Affinity (P-0321)
The CVT-2/8WB can be integrated with the P-0321 to send modulated signals
through a system that has some TVs with digital cable boxes and some TVs
without digital cable boxes. An RF filter can be used to remove the digital
content from the TVs which do not have digital boxes. This allows modulated
channels to be inserted without interference problems. The P-0321 preserves
the digital content for the locations that do have digital boxes. Additional details
regarding the operation of the Affinity model P-0321 can be found in its
installation manual.
6
Power Supplies
not shown 7
Specifications: (typical @25º C)
Specifications subject to change without notice.
Operation Time
Frequency Range
Frequency Range
Full Time Bypass
54-860 / 975-1525MHz
5-42MHz
Insertion Loss
Gain 54-800MHz
5-40MHz
800-860MHz
40-42MHz
975-1525MHz
<20dB (15dB typ.)
5.0dB
-1.0dB
-14dB
4.0dB
-1.5dB
6.0dB
0dB
-17dB
5.0dB
-1.0dB
7.0dB
1.0dB
+1.0dB
+1.0dB
-20dB
>14dB
>14dB
>18dB
>20dB
7.5dB
20dB
60ns
55ns
12ns
74dBC
56dBC
60dBC
58dBC
>110dB
+23.0 dBmV
+43.0 dBmV
75 ohm
180mA
65mA
12-15VDC
64dBC
53dBC
60dBC
56dBC
22ns
36ns
6.0dB
0dB
Return Loss (I/O)
Return Loss (I/O)
Return Loss (I/O)
Nominal Impedance “F” Female
Isolation
Isolation
Supply Voltage (DC)
Noise Figure@70 degrees F
Noise Figure@70 degrees F
Group Delay (54 to 66MHz)
Group Delay (5 to 10MHz / 36MHz to 42MHz)
Group Delay (66 to 88MHz)
Group Delay (10 to 36MHz)
Group Delay (88 to 1000MHz)
Composite Second Order Distortions
Composite Second Order Distortions
Composite Triple Beat Distortions
Composite Triple Beat Distortions
Cross Modulation Distortions
Cross Modulation Distortions
Second Hum Modulation
Second Hum Modulation
Rated Output Level @160 channels, 6MHz each
Rated Output Level @2 channels, 6MHz each
Power Consumption
Power Consumption
>14dB
IR PASS
Flatness
Flatness
RFI Shielding
Yes
ITEM MIN. MAX.TYP.
MODULATOR PATH
CATV FORWARD PATH
CATV RETURN PATH
GENERAL SPEC

Gain:
Forward Path (54-860MHz): +4.5dB, (975-1525MHz): Passive
Reverse Path (5-42MHz): Unity
1
5
2
6
3
7
4
8
Cable In
+4.5dB
12VDC
MOD In
-15.5dB
TM
C H A N N E L V I S I O N CVT-2/8WB
IR
Passing
PRO
CH A N N E L
TM
VI S I O N
CH A N N E L
VI S I O NTM
Model
P-0321
CATV Input MOD Input
Output
Power
IR Out
Pat. Pending
Part No. HS-2
2-WAY SPLITTER/COMBINER
5MHz-1GHz All Port DC passing
TM
CHAN NEL VISI O N
IN/out
OUT/in OUT/in
Digital CATV
Location
Analog CATV
Location
dul r
Mo ato
CATV
e
Chann l
VisionTM
0
A511
CVT-2/8WB
P-0321
Input from
Antenna/CATV
RF OUTRF OUT
DC 15V INDC 15V IN
OUTPUT
IR
OUTPUT
IR
CABLECABLE
ANTENNAANTENNA
ANTENNA + CABLEANTENNA + CABLE
VIDEOVIDEO
AUDIOAUDIO
L RL R
BB
AA
VIDEOVIDEO
AUDIOAUDIO
L RL R
DD
CC
1144
33
22
11223344
OUTPUT
IR
OUTPUT
IR
Sat Receiver
IR Emitter
E4200IR
CameraCameraCamera
RF Filter
123
456
789
0
Pwro e
Part No. HS-2
2-WAY SPLITTER/COMBINER
5MHz-1GHz All Port DC passing
TM
CHA NN EL VISI O N
IN/out
OUT/inOUT/in
Using the CVT-2/8WB with the Affinity (P-0321)
The CVT-2/8WB can be integrated with the P-0321 to send modulated signals
through a system that has some TVs with digital cable boxes and some TVs
without digital cable boxes. An RF filter can be used to remove the digital
content from the TVs which do not have digital boxes. This allows modulated
channels to be inserted without interference problems. The P-0321 preserves
the digital content for the locations that do have digital boxes. Additional details
regarding the operation of the Affinity model P-0321 can be found in its
installation manual.
6
Power Supplies
not shown 7
Specifications: (typical @25º C)
Specifications subject to change without notice.
Operation Time
Frequency Range
Frequency Range
Full Time Bypass
54-860 / 975-1525MHz
5-42MHz
Insertion Loss
Gain 54-800MHz
5-40MHz
800-860MHz
40-42MHz
975-1525MHz
<20dB (15dB typ.)
5.0dB
-1.0dB
-14dB
4.0dB
-1.5dB
6.0dB
0dB
-17dB
5.0dB
-1.0dB
7.0dB
1.0dB
+1.0dB
+1.0dB
-20dB
>14dB
>14dB
>18dB
>20dB
7.5dB
20dB
60ns
55ns
12ns
74dBC
56dBC
60dBC
58dBC
>110dB
+23.0 dBmV
+43.0 dBmV
75 ohm
180mA
65mA
12-15VDC
64dBC
53dBC
60dBC
56dBC
22ns
36ns
6.0dB
0dB
Return Loss (I/O)
Return Loss (I/O)
Return Loss (I/O)
Nominal Impedance “F” Female
Isolation
Isolation
Supply Voltage (DC)
Noise Figure@70 degrees F
Noise Figure@70 degrees F
Group Delay (54 to 66MHz)
Group Delay (5 to 10MHz / 36MHz to 42MHz)
Group Delay (66 to 88MHz)
Group Delay (10 to 36MHz)
Group Delay (88 to 1000MHz)
Composite Second Order Distortions
Composite Second Order Distortions
Composite Triple Beat Distortions
Composite Triple Beat Distortions
Cross Modulation Distortions
Cross Modulation Distortions
Second Hum Modulation
Second Hum Modulation
Rated Output Level @160 channels, 6MHz each
Rated Output Level @2 channels, 6MHz each
Power Consumption
Power Consumption
>14dB
IR PASS
Flatness
Flatness
RFI Shielding
Yes
ITEM MIN. MAX.TYP.
MODULATOR PATH
CATV FORWARD PATH
CATV RETURN PATH
GENERAL SPEC

500-254 rev A1
www.chann e l v i s i o n . c o m
234 Fischer Avenue, Costa Mesa, California 92626 USA
[phone] [phone] [phone] fax
email: [email protected]
Channel Vision Technology will repair or replace any defect in
material or workmanship which occurs during normal use of this
product with new or rebuilt parts, free of charge in the USA, for one
year from the date of original purchase. This is a no hassle warranty
with no mail in warranty card needed. This warranty does not cover
damages in shipment, failures caused by other products not supplied
by Channel Vision Technology, or failures due to accident, misuse,
abuse, or alteration of the equipment. This warranty is extended only
to the original purchaser, and a purchase receipt, invoice, or other
proof of original purchase date will be required before warranty
repairs are provided.
Mail in service can be obtained during the warranty period by calling
[phone] toll free. A Return Authorization number must be
obtained in advance and can be marked on the outside of the shipping
carton.
This warranty gives you specific legal rights and you may have other
rights (which vary from state to state). If a problem with this product
develops during or after the warranty period, please contact Channel
Vision Technology, your dealer or any factory-authorized service
center.
Channel Vision products are not intended for use in medical,
lifesaving, life sustaining or critical environment applications.
Channel Vision customers using or selling Channel Vision products
for use in such applications do so at their own risk and agree to fully
indemnify Channel Vision for any damages resulting from such
improper use or sale.
1
