Channel Vision ARIA Audio A0326 User manual

A0326
ARIA Audio Streaming Source Receiver
with a built in Bluetooth 4.2 Module
®
2017
ARIA Audio
by

Model A0326
Channel Vision’s ARIA Audio Streaming Receiver is equipped with a Blue tooth 4.2
module, users will enjoy further streaming distances and a more reliable streaming
connection with enhanced audio acoustic features with the melody 3D surround
sound and bass boost enrichments. The A0326 also features “deep sleep” mode to
conserve power, customized zone naming, security code settings, and a unique
property management mobile app reset control.
The A0326 ARIA Audio streaming source receiver provides a local wireless
connection for the purpose of streaming audio from sources such as smart-phones,
tablets and computers, etc with blue tooth streaming source capability to ARIA Audio
equipped audio systems. When the A0326 is paired through ARIA Audio’s Android or
IOS app, it will receive your selected music such as iTunes, Pandora, Spotify etc.
from the smart phone to the ARIA Audio streaming source receiver. This connection
will remain on until pairing is disconnected, or the streaming source device (smart
phone), is out of range. ARIA will enter a power saving mode to conserve power
consumption and deep sleep after a period of no use. Upon entering into range, the
connection will automatically reconnect and play music in the zone and follow the user
around their home or business with multiple systems installed in select locations. In
addition, this can be set up as a multi-room installation to play in all zones
simultaneously.
Operation:
To pair to the A0326, download the Android or IOS app, in pair mode, the 2 LED’s on
the front of the ARIA receiver will flash. The Blue tooth identification code will have
the prefix ARIA_ _ _ in front of the individual code number. When pairing occurs, a
slow green LED will flash every 3 seconds on the front plate. For systems with
multiple A0326s, it is recommended the codes be changed to easily identify each
room for optimal user experience.
Operating Range:
ARIA’s streaming source receiver devices are intended to provide wireless
communication between enabled devices within a room. In ideal line of site conditions
range can be up to 147.’ This distance can be reduced significantly by transmission
interference from other communication devices, electrical wiring and room
construction materials, such as brick walls and concrete floors. When the A0326 is
operating near maximum range, the signal may intermittently drop in and out, as
signal strength varies.
The following are trademarks held by their respective owners in the USA and International Countries: Android, Pandora, Google,
Spotify. iTunes and IOS are registered trademarks of Apple Inc. in the USA and International Countries

ARIA Audio Source Volume Level Compatibility:
The audio output level from streaming sources can vary from brand to brand.
Although the A0326 has been adjusted to be equal to the output of most streaming
source devices, in some cases the level may be different. Most devices have their
own adjustable volume level, and it is recommended that this be used to adjust the
output level to match the main audio source’s volume level.
Room Identification:
Pairing each A0326 requires the identification of an individual code number beginning
with the prefix ARIA0001 through ARIA0999. This code number can be replaced with
an individual room name identification such as Bedroom1, Study, Patio, etc. up to 8
characters.
Security Pairing Code:
When pairing for the first time, you must first download Channel Vision’s ARIA Audio
app. and follow the setup on the pages that follow. The app. requires a security code.
The default code is 0000 and can be changed upon connecting the app to the blue
tooth receiver. Individual blue tooth receiver room naming and discrete security
pairing code can be changed with the renaming app at any time before or after
installation. Authorized dealers have additional setup options for security and
property management features.
Green/White - Left channel ground
Green - Left channel
Orange/White - Right channel ground
Blue -
Blue/White -
Orange - Right channel
Brown/White - Ground
Brown - 24vDC
TIA-568A RJ-45 Modular Plug
Side view:
Top view:
Symptom
Warning: Do not adjust the volume all the way up if no audio is present. Doing so could
damage your speakers if audio reconnects.
1. Both front lights are flashing on the front of ARIA plate
Ans. blue tooth source is not connected
Sol. begin w/app setup instructions, starting with the app before the phone settings
1. Verify the music source is active before pairing
2. A slow green flashing LED indicates when the blue tooth and ARIA streaming receiver are
paired, turn up the volume on the audio of your smart phone and/or amplifier.
3. Try a different streaming source receiver source device.
4. Verify streaming source receiver music source (i.e. phone/tablet) device is in play mode
Troubleshooting Steps
Not linking with
streaming source
Linking with streaming
source receiver
device, but no audio is
not used
not used

*Use 110 connectors
only. Do not connect
Blue/Blue-White
The A0326 features
Blue tooth Wireless Audio
Receiver designed for any
Distributed System. The
A0326 is the perfect solution
for streaming Blue tooth
Audio to your home speakers
or home theater center when
your equipment is located a
distance away from your
living area.
a built-in
3
Output Wall Plate
Audio Outputs
Connect to your
amplifier. RJ-45 (NOT USED)
110
Connectors
Receive signals
from the wall dock
via Category 5 or
Category 6 cable.
Back
Front
Installation - Single Zone Audio:
As a single zone audio system, plug the RJ-45 output
(bottom Rj45) of the A0326 blue tooth streaming
receiver to the output L&R audio plate for a rich
sounding, custom installed audio experience.
h
A0350 Amplifier
Ic615 Speakers
A0326 Blue tooth Receiver
Installation Diagram
TM
B y CHANN EL V IS ION
ARIA
Local In
Active
Spkrs 24VDC
IR In
Flush Mount Amplifier
18/2 AWG
Wire
2-cond power input option
optional Audio input
Audio output to Amplifier
Factory jumper setting when
used with 100 watt amplifier
Blue tooth setting is 1 & 2
pins covered with jumper
Recommended low voltage
mud ring for installation
Arlington Lv1 or equal
Cat5 up to 300’

1. Download the App from the Android Store:
2. Open ARIA Audio app and click on the Blue tooth Icon
3. Click on Refresh Button
4. Select ARIA Audio Module
5. Once ARIA pairing is selected,
Go to the Blue tooth settings of your smart phone
6. Select the ARIA Audio with the same name and pair with it by clicking
OK on pair request
7. Immediately open ARIA App
and go to settings in the App

8. Click on Master, then pair password: 0000
9. Enter password 0000, then submit, you’re
now paired to play music
10. You can play music from any music app or use the in app features
to play music from Pandora, Spotify and Google play music

Music manager features audio enhancements such as
3D surround sound, bass boost, and equalizer enhancements.
We’ve selected our favorite equalizer settings
for the music selection.

500-411 Rev B
www.channelvi s i o n . c o m
234 Fischer Avenue, Costa Mesa, California 92626 USA
[phone]
email: [email protected]
1
See website for details: http://channelvision.com/warranty/
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void
your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled
environment. This device and its antenna must not be located or operating in conjunction with any other
antenna or transmitter.
Tested To Comply
With FCC Standards
Proudly designed and manufactured in the USA
