Chauvet Professional OVATION-F-915-VW User manual

User Manual

Ovation F-915VW User Manual Rev. 1
Edition Notes
The Ovation F-915VW User Manual includes a description, safety precautions, installation, programming,
operation and maintenance instructions for the Ovation F-915VW as of the release date of this edition.
Trademarks
CHAUVET, the Chauvet logo and Ovation F-915VW are registered trademarks or trademarks of Chauvet &
Sons, LLC (d/b/a Chauvet and Chauvet Lighting) in the United States and other countries. Other company
and product names and logos referred to herein may be trademarks of their respective companies.
Copyright Notice
The works of authorship contained in this manual, including, but not limited to, all design, text and images
are owned by Chauvet.
© Copyright 2018 Chauvet & Sons, LLC. All rights reserved.
Electronically published by Chauvet in the United States of America.
Manual Use
Chauvet authorizes its customers to download and print this manual for professional information purposes
only. Chauvet expressly prohibits the usage, copy, storage, distribution, modification, or printing of this
manual or its content for any other purpose without written consent from Chauvet.
Document Printing
For best results, print this document in color, on letter size paper (8.5 x 11 in), double-sided. If using A4
paper (210 x 297 mm), configure the printer to scale the content accordingly.
Intended Audience
Any person installing, operating, and/or maintaining this product should completely read through the guide
that shipped with the product, as well as this manual, before installing, operating, or maintaining this
product.
Disclaimer
Chauvet believes that the information contained in this manual is accurate in all respects. However,
Chauvet assumes no responsibility and specifically disclaims any and all liability to any party for any loss,
damage or disruption caused by any errors or omissions in this document, whether such errors or
omissions result from negligence, accident or any other cause. Chauvet reserves the right to revise the
content of this document without any obligation to notify any person or company of such revision, however,
Chauvet has no obligation to make, and does not commit to make, any such revisions. Download the latest
version from www.chauvetprofessional.com.
Document Revision
This Ovation F-915VW User Manual is the 1
st
edition of this document. Go to www.chauvetprofessional.com
for the latest version.

Ovation F-915VW User Manual Rev. 1
Table of Contents
i
TABLE OF CONTENTS
1. Before You Begin ....................................................................... 1
What Is Included ........................................................................................... 1
Claims ........................................................................................................... 1
Manual Conventions ..................................................................................... 1
Symbols ........................................................................................................ 1
Safety Notes.................................................................................................. 2
Personal Safety.............................................................................................................. 2
Mounting and Rigging .................................................................................................... 2
Power and Wiring........................................................................................................... 2
Operation ...................................................................................................... 2
Expected LED Lifespan................................................................................. 2
2. Introduction ................................................................................ 3
Description .................................................................................................... 3
Features........................................................................................................ 3
Product Overview.......................................................................................... 3
Product Dimensions ...................................................................................... 4
3. Setup ........................................................................................... 5
AC Power...................................................................................................... 5
AC Plug .......................................................................................................................... 5
Power Linking................................................................................................................. 5
DMX Linking.................................................................................................. 5
DMX Personalities.......................................................................................................... 5
Remote Device Management (RDM) ............................................................ 5
Master/Slave Connectivity............................................................................. 5
Mounting ....................................................................................................... 6
Orientation...................................................................................................................... 6
Rigging ........................................................................................................................... 6
Procedure....................................................................................................................... 6
4. Operation .................................................................................... 7
Control Panel Operation................................................................................ 7
Control Options ............................................................................................. 7
Programming................................................................................................. 7
Menu Map ..................................................................................................... 7
Configuration (DMX) ..................................................................................... 9
Control Personalities ...................................................................................................... 9
Starting Address............................................................................................................. 9
DMX Values .................................................................................................. 10
18 Ch.............................................................................................................................. 10
16 Ch.............................................................................................................................. 10
13 Ch.............................................................................................................................. 11
9 Ch................................................................................................................................ 11
7 Ch................................................................................................................................ 11
6 Ch................................................................................................................................ 12
4 Ch................................................................................................................................ 12
Preset Color Temperature Chart.................................................................................... 12

Table of Contents
Ovation F-915VW User Manual Rev. 1
ii
Configuration (Standalone) ........................................................................... 13
Static Mode .................................................................................................................... 13
Zoom .............................................................................................................................. 13
Master/Slave .................................................................................................................. 13
Dimmer Profiles.............................................................................................................. 13
White Balance ................................................................................................................ 14
LED Frequency .............................................................................................................. 14
Fan Mode ....................................................................................................................... 14
Back Light ...................................................................................................................... 14
System Information ........................................................................................................ 14
Factory Reset................................................................................................................. 14
5. Technical Information ................................................................ 15
Product Maintenance .................................................................................... 15
6. Technical Specifications ........................................................... 16
Photometrics Charts...................................................................................... 17
Returns............................................................................................ 18
Contact Us ...................................................................................... 19

Page 1 of 19
Ovation F-915VW User Manual Rev. 1
Before You Begin
1. Before You Begin
What Is Included
Claims
Carefully unpack the product immediately and check the container to make sure all the parts are in the
package and are in good condition.
If the box or the contents (the product and included accessories) appear damaged from shipping, or show
signs of mishandling, notify the carrier immediately, not Chauvet. Failure to report damage to the carrier
immediately may invalidate your claim. In addition, keep the box and contents for inspection.
For other issues, such as missing components or parts, damage not related to shipping, or concealed
damage, file a claim with Chauvet within 7 days of delivery.
Manual Conventions
Symbols
• Ovation F-915VW
• Neutrik® powerCON® Power Cord
• Gel Frame (7.5 in/191 mm accessories)
• Warranty Card
• Quick Reference Guide
Convention Meaning
1–512 A range of values
50/60 A set of values of which only one can be chosen
<SET> A button on the product’s control panel
Settings A product function or a menu option
Symbol Meaning
Electrical warning. Not following these instructions may cause electrical damage to
the product, accessories, or the user.
Critical installation, configuration, or operation information. Not following these
instructions may make the product not work, cause damage to the product, or cause
harm to the operator.
Important installation or configuration information. The product may not function
correctly if this information is not used.
Useful information.
Any reference to power connections in this manual assumes the use of Neutrik®
powerCON® cables.
The term “DMX” used throughout this manual refers to the USITT DMX512-A
digital data transmission protocol.

Page 2 of 19
Before You Begin
Ovation F-915VW User Manual Rev. 1
Safety Notes
Read all the following safety notes before working with this product. These notes contain important
information about the installation, usage, and maintenance of this product.
Personal Safety
• Avoid direct eye exposure to the light source while the product is on.
• Always disconnect the product from the power source before cleaning or replacing the fuse.
• Always connect the product to a grounded circuit to avoid the risk of electrocution.
• Do not touch the product’s housing when operating because it may be very hot.
Mounting and Rigging
• This product is not intended for permanent installation.
• This product is for indoor use only! To prevent risk of fire or shock, do not expose this product to
rain or moisture. (IP20)
• CAUTION: When transferring product from extreme temperature environments, (e.g. cold truck to
warm humid ballroom) condensation may form on the internal electronics of the product. To avoid
causing a failure, allow product to fully acclimate to the surrounding environment before connecting
it to power.
• Mount this product in a location with adequate ventilation, at least 20 in (50 cm) from adjacent
surfaces.
• Make sure there are no flammable materials close to this product while it is operating.
• When hanging this product, always secure to a fastening device using a safety cable.
• Never carry the product by the power cord.
Power and Wiring
• Make sure the power cord is not crimped or damaged.
• Always make sure you are connecting this product to the proper voltage in accordance with the
specifications in this manual or on the product’s specification label.
• To eliminate unnecessary wear and improve its lifespan, during periods of non-use completely
disconnect the product from power via breaker or by unplugging it.
• Never connect this product to a dimmer pack or rheostat.
• Make sure to replace the fuse with another of the same type and rating.
• Never disconnect this product by pulling or tugging on the power cable.
Operation
• Do not operate this product if there is damage on the housing, lenses, or cables. Have the damaged
parts replaced by an authorized technician at once.
• Do not cover the ventilation slots when operating to avoid internal overheating.
• The maximum ambient temperature is 113 °F (45 °C). Do not operate the product at higher temperatures.
• In the event of a serious operation problem, stop using this product immediately!
Expected LED Lifespan
LEDs gradually decline in brightness over time, primarily because of heat. LEDs that are arranged in
clusters experience higher operating temperatures than single LEDs. For this reason, operating clustered
LEDs at their fullest intensity significantly reduces the LEDs’ lifespan. Under normal conditions, this
lifespan is 40,000 to 50,000 hours. If extending this lifespan is vital, lower the operating temperature by
improving the ventilation around the product, thus reducing the ambient temperature. In addition, limiting
the overall projection intensity may extend the LEDs’ lifespan.
This product contains no user-serviceable parts. Any reference to servicing in
this User Manual will only apply to properly trained, certified technicians. Do not
open the housing or attempt any repairs.
All applicable local codes and regulations apply to proper installation of this
product.
If your Chauvet product requires service, contact Chauvet Technical Support.

Page 3 of 19
Ovation F-915VW User Manual Rev. 1
Introduction
2. Introduction
Description
The Ovation F-915VW is a variable white Fresnel-style LED lighting fixture with 16-bit dimming resolution
for smooth fades. It delivers a beautiful flat, even field of light. Its motorized zoom, with a range between
30° to 85°, is controlled either manually or via DMX. Simple and complex DMX channel profiles offer
programming versatility. Virtually silent operation makes it ideal for use in any situation.
Features
• Operating modes:
• 4 Ch: Dimmer, color temperature, hue, zoom
• 6 Ch: 16-bit dimmer, color temperature, hue, zoom, strobe
• 7 Ch: Red, orange, green, royal blue, blue, lime, zoom
• 9 Ch: Dimmer, red, orange, green, royal blue, blue, lime, strobe, zoom
• 13 Ch: Dimmer, red, orange, green, royal blue, blue, lime, strobe, color temperature, hue,
dimmer speed mode, zoom, motor reset
• 16 Ch: 16-bit dimmer, 16-bit red, orange, green, royal blue, blue, and lime, strobe, zoom
• 18 Ch: 16-bit dimmer, 16-bit red, orange, green, royal blue, blue, and lime, strobe, color
temperature, hue, zoom
• Variable white LED Fresnel lighting fixture for theatre, film and production
• Smooth, motorized zoom from 30° to 85°
• Color Temperature Presets from 2800 K to 8000 K with high CRI and CQS
• Beautiful 16-bit dimming
• Proprietary LED engine delivers tremendous, equal output at all color temperatures
• Easy to use on board control of color temperature, zoom and dimming
• +/- Green adjustment via DMX or on-board control
• Independent color control over the 6-color engine when a splash of color is needed
• RDM (Remote Device Management) for added flexibility
• Adjustable PWM (Pulse Width Modulation) to avoid flickering on camera
• Virtually silent operation for use in studio and theatre applications
Product Overview
Menu Buttons
Knob 1
Neutrik® powerCON®
In/Out
Fuse Holder
Display
Knob 3
DMX In/Out
Tilt Adjustment Knob (x2)
Knob 2

Page 4 of 19
Introduction
Ovation F-915VW User Manual Rev. 1
Product Dimensions
10.82 in
275 mm
7.56 in
192 mm
22.41 in
569 mm
17.8 in
452 mm
8.31 in
211 mm
12.59in
320 mm

Page 5 of 19
Ovation F-915VW User Manual Rev. 1
Setup
3. Setup
AC Power
Each Ovation F-915VW has an auto-ranging power supply that works with an input voltage range of 100 to
240 VAC, 50/60 Hz. To determine the power requirements for each Ovation F-915VW, refer to the label
affixed to the product. You can also refer to the Technical Specifications chart in this manual.
The listed current rating indicates the maximum current draw during normal operation. For more
information, download Sizing Circuit Breakers from the Chauvet website: www.chauvetprofessional.com.
AC Plug
The Ovation F-915VW comes with a power input cord terminated with a Neutrik® powerCON® connector
on one end and an Edison plug on the other end (U.S. market). If the power input cord that came with your
product has no plug, or if you need the change the plug, use the table below to wire the new plug.
Power Linking
The product supports power linking. You can power link up to 6 products at 120 V; up to 10 at 208 V; or up
to 12 at 230 V.
This product comes with a power input cord. Power linking cables are available from Chauvet for purchase.
DMX Linking
You can link the Ovation F-915VW to a DMX controller using a 3- or 5-pin DMX connection. If using other
DMX-compatible products with this product, you can control each individually with a single DMX controller.
DMX Personalities
The Ovation F-915VW uses a 3- or 5-pin DMX data connection for the 4 Ch, 6 Ch, 7 Ch, 9 Ch, 13 Ch, 16
Ch, and 18 Ch DMX personalities.
• Refer to the Introduction chapter for a brief description of each DMX personality.
• Refer to the Operation chapter to learn how to configure the Ovation F-915VW to work in these personalities.
•The DMX Values section provides detailed information regarding the control personalities.
Remote Device Management (RDM)
Remote Device Management, or RDM, is a standard for allowing DMX-enabled devices to communicate
bi-directionally along existing DMX cabling. Check the DMX controller’s User Manual or with the
manufacturer as not all DMX controllers have this capability. The Ovation F-915VW supports RDM protocol
that allows feedback to make changes to menu map options.
Master/Slave Connectivity
The Master/Slave mode allows an Ovation F-915VW (the master) to control one or more Ovation F-915VW
products (the slaves) without a DMX controller. One Ovation F-915VW becomes the master when running an
auto program, or by being in Static mode.
You must configure each slave’s control panel to operate in Slave mode. During Master/Slave operation,
the slaves will operate in unison with the master.
• Always connect the product to a protected circuit (circuit breaker or fuse). Make
sure the product has an appropriate electrical ground to avoid the risk of
electrocution or fire.
• To eliminate unnecessary wear and improve its lifespan, during periods of non-use
completely disconnect the product from power via breaker or by unplugging it.
Never connect the product to a rheostat (variable resistor) or dimmer circuit, even if
the rheostat or dimmer channel serves only as a 0 to 100% switch.
Connection Wire (U.S.) Wire (Europe) Screw Color
AC Live Black Brown Yellow or Brass
AC Neutral White Blue Silver
AC Ground Green/Yellow Green/Yellow Green
If you are not familiar with or need more information about DMX standards, Master/
Slave connectivity, or the DMX cables needed to link this product to a DMX controller,
download the DMX Primer from the Chauvet website: www.chauvetprofessional.com.
DO NOT connect a DMX controller to products operating in Master/Slave mode. The
DMX controller signals may interfere with the signals from the master.
•The Operation section of this manual provides detailed instructions on how to
configure the master and slaves.
• If you are not familiar with or need more information about DMX standards, or the
DMX cables needed to link this product to a DMX controller, download the DMX
Primer from the Chauvet website: www.chauvetprofessional.com.

Page 6 of 19
Setup
Ovation F-915VW User Manual Rev. 1
Mounting
Before mounting the product, read and follow the safety recommendations indicated in the Safety Notes.
For our CHAUVET Professional line of mounting clamps, go to http://trusst.com/products/.
Orientation
Always mount this product in a safe position, making sure there is adequate room for ventilation,
configuration, and maintenance.
Rigging
Chauvet recommends using the following general guidelines when mounting this product.
• Before deciding on a location for the product, make sure there is easy access to the product for
maintenance and programming purposes.
• Make sure that the structure onto which you are mounting the product can support the product’s
weight. See the Technical Specifications for weight information.
• When mounting the product overhead, always use a safety cable. Mount the product securely to a
rigging point, whether an elevated platform or a truss.
• When rigging the product onto a truss, use a mounting clamp of appropriate weight capacity.
• When power linking multiple products, mount the products close enough for power linking cables to
reach.
• The bracket adjustment knobs allow for directional adjustment when aiming the product to the
desired angle. Only loosen or tighten the bracket knobs manually. Using tools could damage the
knobs.
Procedure
The Ovation F-915VW comes with a bracket to which you can attach a mounting clamp directly. You must
supply the mounting clamps. Make sure the clamps are capable of supporting the weight of this product.
Use at least one mounting point per product. For the CHAUVET Professional line of mounting clamps, go
to http://www.trusst.com/products.
Mounting Diagram
Brackets
Mounting Clamps
Bracket Adjustment Knobs
Safety Cables

Page 7 of 19
Ovation F-915VW User Manual Rev. 1
Operation
4. Operation
Control Panel Operation
Control Options
Set the Ovation F-915VW starting address in the 001–512 DMX range. This enables control of up to 28
products in the 18-channel 18 Ch personality.
Programming
Refer to the Menu Map to understand the menu options. The menu map shows the main level and a
variable number of programming levels for each option.
• To go to the desired main level, press <MENU> repeatedly until the option shows on the display.
Press <ENTER> to select. This will take you to the first programming level for that option.
• To select an option or value within the current programming level, press <UP> or <DOWN> until
the option shows on the display. Press <ENTER> to select. In this case, if there is another
programming level, you will see that first option, or you will see the selected value.
• Press <MENU> repeatedly to exit to the previous main level.
Menu Map
Button Function
<MENU> Exits from the current menu or function
<ENTER>
Enables the currently displayed menu or sets the currently selected value in to the current function
<UP> Navigates upward through the menu list or increases the numeric value when in a function
<DOWN> Navigates downward through the menu list or decreases the numeric value when in a function
Knob 1 Push once then turn to select the color temperature. Push again then turn to set the hue.
Knob 2 Push then turn to increase or decrease the dimmer
Knob 3 Push then turn to increase or decrease the zoom
Main Level Programming Levels Description
DMX
Address 001–509*
Selects DMX address (*highest channel
restricted to personality chosen)
DMX
Personality
4 Ch 4-channel: dimmer, color temperature,
hue, zoom
6 Ch 6-channel: 16-bit dimmer, color
temperature, hue, zoom, strobe
7 Ch 7-channel: red, orange, green, royal
blue, blue, lime, zoom
9 Ch
9-channel: dimmer, red, orange, green,
royal blue, blue, lime, strobe, zoom
13 Ch
13-channel: dimmer, red, orange,
green, royal blue, blue, lime, strobe,
color temperature, hue, dimmer speed
mode, zoom, motor reset
16 Ch
16-channel: 16-bit dimmer, 16-bit red,
orange, green, royal blue, blue, and
lime, strobe, zoom
18 Ch
18-channel: 16-bit dimmer, 16-bit red,
orange, green, royal blue, blue, and lime,
strobe, color temperature, hue, zoom
Static
Color
Temperature
2800K
Dimmer
000–255
Sets the color temperature, dimmer,
and hue (green/magenta) levels.
Emulates a tungsten lamp at the
specified color temperature.
2900K
3000K
3100K
3200K
Hue -25–25
3300K
3400K
3500K

Page 8 of 19
Operation
Ovation F-915VW User Manual Rev. 1
Static
(cont.)
Color
Temperature
(cont.)
3600K
Dimmer
000–255
Sets the color temperature, dimmer,
and hue (green/magenta) levels.
Emulates a tungsten lamp at the
specified color temperature.
3700K
3800K
3900K
4000K
4100K
4200K
4300K
4400K
4500K
4600K
4700K
4800K
4900K
5000K
Hue -25–25
5100K
5200K
5300K
5400K
5500K
5600K
5700K
6000K
6500K
7000K
7500K
8000K
Manual
Color Mixer
Red
<000–255>
Combine red, orange, green, royal
blue, blue, and lime to make a custom
color (0–100%)
Orange
Green
Royal Blue
Blue
Lime
Zoom 0–255 Controls zoom
Master/
Slave
Master DMX mode (Master)
Slave Slave mode
Dimmer
Mode
Off Linear dimmer
Dimmer 1–3 Dimming curves Dimmer 1 (fast) to
Dimmer 3 (slow)
White
Balance
Off Uses factory default white setting
Manual
Red
<125–255>
Sets red LED maximum value
Orange Sets orange LED maximum value
Green Sets green LED maximum value
Royal Blue Sets royal blue LED maximum value
Blue Sets blue LED maximum value
Lime Sets lime LED maximum value
Main Level Programming Levels Description

Page 9 of 19
Ovation F-915VW User Manual Rev. 1
Operation
Configuration (DMX)
Use control configurations to operate the product with a DMX controller.
Control Personalities
This setting allows you to choose a particular control personality.
1. Go to the DMX Personality main level.
2. Select the desired personality, from 4 Ch, 6 Ch, 7 Ch, 9 Ch, 13 Ch, 16 Ch, or 18 Ch.
Starting Address
Each product will respond to a unique starting address from the DMX controller. All products with the same
starting address will respond in unison.
1. Go to the DMX Address main level.
2. Select the starting address (001–512).
The highest recommended starting address for each DMX mode is as follows:
LED
Frequency
600Hz
Sets the PWM frequency
1200Hz
2000Hz
4000Hz
6000Hz
25KHz
Fan Mode Auto Sets the fan to auto mode
On Sets the fan to always on
Back Light
On Display backlight always on
10S Turns off display backlight after 10
seconds of inactivity
20S Turns off display backlight after 20
seconds of inactivity
30S Turns off display backlight after 30
seconds of inactivity
Information
Fixture Hours <_ _ _ _H> Shows total hours the product has
been powered on
Version <V_._> Shows current firmware version
UID <_ _ _ _ _ _ _ _ _ _ _ _> Shows product UID
Reset
Factory
No Resets the product to factory default
settings
Yes
• See the Starting Address section for the highest starting address you can select for each
personality.
• Make sure that the starting addresses on the various products do not overlap due to the
new personality setting.
Personality Address
18 Ch 495
16 Ch 497
13 Ch 500
9 Ch 504
7 Ch 506
6 Ch 507
4 Ch 509
Main Level Programming Levels Description

Page 10 of 19
Operation
Ovation F-915VW User Manual Rev. 1
DMX Values
18 Ch
16 Ch
Channel Function Value Percent/Setting
1 Dimmer 000 255 0–100%
2 Dimmer Fine 000 255 0–100%
3Red 000 255 0–100%
4 Red Fine 000 255 0–100%
5 Orange 000 255 0–100%
6 Orange Fine 000 255 0–100%
7Green 000 255 0–100%
8 Green Fine 000 255 0–100%
9 Royal Blue 000 255 0–100%
10 Royal Blue Fine 000 255 0–100%
11 Blue 000 255 0–100%
12 Blue fine 000 255 0–100%
13 Lime 000 255 0–100%
14 Lime Fine 000 255 0–100%
15 Strobe 000 010 No function
011 255 Strobe, slow to fast
16 Color Temperature 000 255 See Preset Color Temperature Chart
17 Hue 000 255 -25–25
18 Zoom 000 255 Narrow to wide
Channel Function Value Percent/Setting
1 Dimmer 000 255 0–100%
2 Dimmer Fine 000 255 0–100%
3Red 000 255 0–100%
4 Red Fine 000 255 0–100%
5 Orange 000 255 0–100%
6 Orange Fine 000 255 0–100%
7Green 000 255 0–100%
8 Green Fine 000 255 0–100%
9 Royal Blue 000 255 0–100%
10 Royal Blue Fine 000 255 0–100%
11 Blue 000 255 0–100%
12 Blue fine 000 255 0–100%
13 Lime 000 255 0–100%
14 Lime Fine 000 255 0–100%
15 Strobe 000 010 No function
011 255 Strobe, slow to fast
16 Zoom 000 255 Narrow to wide

Page 11 of 19
Ovation F-915VW User Manual Rev. 1
Operation
13 Ch
9 Ch
7 Ch
Channel Function Value Percent/Setting
1 Dimmer 000 255 0–100%
2Red 000 255 0–100%
3 Orange 000 255 0–100%
4Green 000 255 0–100%
5 Royal Blue 000 255 0–100%
6Blue 000 255 0–100%
7Lime 000 255 0–100%
8Strobe 000 010 No function
011 255 Strobe, slow to fast
9 Color Temperature 000 255 See Color Temperature Chart
10 Hue 000 255 -25–25
11 Dimmer Speed Mode
000 051 No function
052 101 Dimmer speed mode off Hold for 3 seconds:
Overrides and
changes menu
selection
102 152 Dimmer speed mode 1
153 203 Dimmer speed mode 2
204 255 Dimmer speed mode 3
12 Zoom 000 255 Narrow to wide
13 Motor Reset
000 200 No function
201 220 Motor reset
221 255 No function
Channel Function Value Percent/Setting
1 Dimmer 000 255 0–100%
2Red 000 255 0–100%
3 Orange 000 255 0–100%
4Green 000 255 0–100%
5 Royal Blue 000 255 0–100%
6Blue 000 255 0–100%
7Lime 000 255 0–100%
8Strobe 000 010 No function
011 255 Strobe, slow to fast
9 Zoom 000 255 Narrow to wide
Channel Function Value Percent/Setting
1Red 000 255 0–100%
2 Orange 000 255 0–100%
3Green 000 255 0–100%
4 Royal Blue 000 255 0–100%
5Blue 000 255 0–100%
6Lime 000 255 0–100%
7 Zoom 000 255 Narrow to wide

Page 12 of 19
Operation
Ovation F-915VW User Manual Rev. 1
6 Ch
4 Ch
Preset Color Temperature Chart
Channel Function Value Percent/Setting
1 Dimmer 000 255 0–100%
2 Dimmer Fine 000 255 0–100%
3 Color Temperature 000 255 See Preset Color Temperature Chart
4Hue 000 255 -25–25
5 Zoom 000 255 Narrow to wide
6Strobe 000 010 No function
011 255 Strobe, slow to fast
Channel Function Value Percent/Setting
1 Dimmer 000 255 0–100%
2 Color Temperature 000 255 See Preset Color Temperature Chart
3Hue 000 255 -25–25
4 Zoom 000 255 Narrow to wide
DMX Channel
Value
Color
Temperature
DMX Channel
Value
Color
Temperature
DMX Channel
Value
Color
Temperature
000 005 No function 084 090 3900–4000K 168 174 5100–5200K
006 013 2800–2900K 091 097 4000–4100K 175 181 5200–5300K
014 020 2900–3000K 098 104 4100–4200K 182 188 5300–5400K
021 027 3000–3100K 105 111 4200–4300K 189 195 5400–5500K
028 034 3100–3200K 112 118 4300–4400K 196 202 5500–5600K
035 041 3200–3300K 119 125 4400–4500K 203 209 5600–5700K
042 048 3300–3400K 126 132 4500–4600K 210 216 5700–6000K
049 055 3400–3500K 133 139 4600–4700K 217 223 6000–6500K
056 062 3500–3600K 140 146 4700–4800K 224 230 6500–7000K
063 069 3600–3700K 147 153 4800–4900K 231 237 7000–7500K
070 076 3700–3800K 154 160 4900–5000K 238 244 7500–8000K
077 083 3800–3900K 161 167 5000–5100K 245 255 8000K
Note: The color temperatures above are simulated renditions of the color output
produced as compared to a tungsten lamp at the specified color temperature.
Chauvet makes no guarantee of the color output accuracy.

Page 13 of 19
Ovation F-915VW User Manual Rev. 1
Operation
Configuration (Standalone)
Use standalone configuration to operate the product without a DMX controller.
Static Mode
The Static mode allows for an unchanging color without a DMX controller.
Color Temperature
1. Go to the Static main level.
2. Select Color Temperature.
3. Select the desired color temperature (see Preset Color Temperature Chart).
4. Select the desired output level (<000–255>).
Manual Color Mixer
1. Go to the Static main level.
2. Select Manual Color Mixer.
3. Select the color to edit (Red, Orange, Green, Royal Blue, Blue, or Lime).
4. Select the desired output level for that color (<000–255>).
5. Repeat steps 3 and 4 until product outputs as desired.
Zoom
The zoom setting allows standalone control of the motorized zoom.
1. Go to the Zoom main level.
2. Select the desired zoom level (0–255).
Master/Slave
The Master/Slave mode allows a group of Ovation F-915VW products (the slaves) to simultaneously
duplicate the output of another Ovation F-915VW (the master) without a DMX controller.
To set each of the slaves:
1. Go to the Master/Slave main level
2. Select Slave.
To set the master:
1. Go to the Master/Slave main level
2. Select Master.
3. Select a static setting.
Dimmer Profiles
This setting determines how fast the output of the Ovation F-915VW changes when you modify the output value.
This setting provides four different options to simulate the dimming curve of an incandescent lighting product.
1. Go to the Dimmer Mode main level.
2. Select a dimmer curve (Off, Dimmer 1, Dimmer 2, or Dimmer 3).
• The master is the one that runs a program whether in Auto or Static mode.
• Do not connect a DMX controller to the products configured for Master/Slave operation.
The DMX controller may interfere with signals from the master.
• The master should be the first product in the daisy chain.
Off: The output is proportional (linear) to the dimmer channel value.
Dimmer 1-3: The output follows the dimmer value based on the corresponding dimmer
curve, Dimmer 1 being the fastest.

Page 14 of 19
Operation
Ovation F-915VW User Manual Rev. 1
White Balance
This setting determines the maximum output values for each color, which affects the appearance of a full
output white.
1. Go to the White Balance main level.
2. Select Off (the product will use a default setting) or Manual.
3. For Manual mode, select the color value to edit (Red, Orange, Green, Royal Blue, Blue, or
Lime).
4. Set the maximum value for the selected color (125–255).
5. Repeat steps 3 and 4 until the product outputs as desired.
LED Frequency
This option changes the Pulse Width Modulation (PWM) frequency of the LEDs on the Ovation F-915VW.
1. Go to the LED Frequency main level.
2. Select PWM Frequency (600Hz, 1200Hz, 2000Hz, 4000Hz, 6000Hz, or 25Khz).
Fan Mode
This setting determines how the fan speed on the Ovation F-915VW is set.
1. Go to the Fan Mode main level.
2. Select Auto (fan speed will increase or decrease based on product temperature) or On (fan
speed will always be at maximum).
Back Light
This setting allows for selection of the amount of time the backlight on the Ovation F-915VW’s display
stays on after the last button is pressed on the control panel.
1. Go to the Back Light main level.
2. Select On (remains on), 10S (10 seconds), 20S (20 seconds), or 30S (seconds).
System Information
This option displays the total number of hours the product has run, the installed software version, and the
product’s UID.
1. Go to the Information main level.
2. Select Fixture Hours, Version, or UID.
Factory Reset
This option restores the Ovation F-915VW to factory default settings.
1. Go to the Reset Factory main level.
2. Select No or Yes.

Page 15 of 19
Ovation F-915VW User Manual Rev. 1
Technical Information
5. Technical Information
Product Maintenance
To maintain optimum performance and minimize wear, clean this product frequently. Usage and
environment are contributing factors in determining the cleaning frequency.
Clean this product at least twice a month. Dust build-up reduces light output performance and can cause
overheating. This can lead to reduced light source life and increased mechanical wear.
To clean the product:
1. Unplug the product from power.
2. Wait until the product is at room temperature.
3. Use a vacuum (or dry compressed air) and a soft brush to remove dust collected on the external
vents.
4. Clean all transparent surfaces with a mild soap solution, ammonia-free glass cleaner, or isopropyl
alcohol.
5. Apply the solution directly to a soft, lint free cotton cloth or a lens cleaning tissue.
6. Softly drag any dirt or grime to the outside of the transparent surface.
7. Gently polish the transparent surfaces until they are free of haze and lint.
Always dry the transparent surfaces carefully after cleaning them.
Do not spin the cooling fan using compressed air because you could damage it.

Page 16 of 19
Technical Specifications
Ovation F-915VW User Manual Rev. 1
6. Technical Specifications
Dimensions and Weight
Note: Dimensions in inches rounded to the nearest decimal digit.
Power
Light Source
Photometrics
Thermal
DMX
Ordering
Length Width Height Weight
22.41 in (569.44 mm) 12.59 in (320 mm) 10.82 in (275 mm) 18.6 lb (8.5 kg)
Power Supply Type Range Voltage Selection
Switching (internal) 100 to 240 VAC, 50/60 Hz Auto-ranging
Parameter 120 V, 60 Hz 208 V, 60 Hz 230 V, 50 Hz
Consumption 216 W 220 W 223 W
Operating Current 1.8 A 1.1 A 1 A
Power linking current
(products) 13.6 A (7 products) 13.6 A (13 products) 13.6 A (14 products)
Power I/O U.S./Worldwide UK/Europe
Power input connector Neutrik® powerCON® A Neutrik® powerCON® A
Power output connector Neutrik® powerCON® B Neutrik® powerCON® B
Power Cord plug Edison (U.S.) Local Plug
Type Color Quantity Power Current Lifespan
LED Red 6 3 W 960 mA 50,000 hours
LED Orange-red 15 3 W 960 mA 50,000 hours
LED Green 8 3 W 960 mA 50,000 hours
LED Blue 12 3 W 960 mA 50,000 hours
LED Royal blue 16 3 W 960 mA 50,000 hours
LED Lime 32 3 W 960 mA 50,000 hours
Color Temperature
(range) Beam Angle Field Angle Zoom Angle Illuminance @ 5 m (30°)
Illuminance
@ 5 m (73°)
2800 to 8000 K 17° to 54° 30° to 85° 30° to 85° 1,748 lux 414 lux
Maximum External Temperature Cooling System
113 °F (45 °C) Fan-assisted convection
I/O Connector Channel Range
3- and 5-pin XLR 4, 6, 7, 9, 13, 16 or 18
Product Name Item Name Item Code UPC Number
Ovation F-915VW OVATIONF915VW 03031392 781462217402
