Chauvet COLORado Batten 144 Tour User manual

User Manual

Edition Notes
COLORado™ Batten 144 Tour User Manual Rev. 6
Edition Notes
The COLORado™ Batten 144 Tour User Manual Rev. 6
covers the description,
safety precautions, installation, programming, operation, and maintenance of the
COLORado™ Batten 144 Tour. Chauvet released this edition of the COLORado™
Batten 144 Tour User Manual in June 2015.
Trademarks
CHAUVET® is a registered trademark of CHAUVET & Sons Inc. (d/b/a CHAUVET®
or Chauvet). The CHAUVET® logo in its entirety including the CHAUVET® name
and the dotted triangle, and all other trademarks i
n this manual pertaining to
services, products, or marketing statements are owned or licensed by Chauvet
. Any
other product names, logos, brands, company names,
and other trademarks
featured or referred to within this document are the property of their respective
trademark holders.
Copyright Notice
Chauvet owns the content of this User Manual in its entirety, including but not limited
to pictures, logos, trademarks, and resources.
© Copyright 2015 Chauvet. All rights reserved.
Electronically published by Chauvet in the United States of America.
Manual Usage
Chauvet authorizes its customers to download and print this manual for professional
information purposes only. Chauvet expressly prohibits the us
age, copy, storage,
distribution, modification, or printing of this manual or its content for any other
purpose without written consent from Chauvet.
Document Printing
For better results, print this document in color, on letter size paper (8.5 x 11 in),
double-
sided. If using A4 paper (210 x 297 mm), configure your printer to scale the
content accordingly.
Intended Audience
Any person in charge of installing, operating, and/or maintaining this product should
completely read through the guide that shipped with the product, as well as this
manual, before installing, operating, or maintaining this product.
Disclaimer
Chauvet believes that the information contained in this manual is accurate in all
respects. However, Chauvet assumes no responsibility for any errors or omissions
in this document. Chauvet reserves the right to revise and make changes to the
content of this document without obligation that Chauvet
notify any person or
company of such revision or changes. This does not in any way constitute a
commitment by Chauvet to make such changes. Chauvet may issue a revision of
this manual or a new edition to incorporate such changes.
Document Revision
The COLORado™ Batten 144 Tour User Manual Rev. 6
supersedes all previous
versions of this manual. Discard any older versions of this manual,
whether in
printed or electronic format, and replace with this version.
Author Date Editor Date
D. Couppe 6/26/15 M. Trouard 4/9/15

Table of Contents
COLORado™ Batten 144 Tour User Manual Rev. 6 -i-
Table of Contents
1. Before You Begin...............................................................................................1
What Is Included .................................................................................................................1
Unpacking Instructions........................................................................................................1
Claims .........................................................................................................................................1
Typographic Conventions ...................................................................................................1
Icon Indications...................................................................................................................1
Safety Notes........................................................................................................................2
Personal Safety...........................................................................................................................2
Mounting and Rigging..................................................................................................................2
Power and Wiring........................................................................................................................2
Operation.....................................................................................................................................2
Expected LED Lifespan ......................................................................................................2
2. Introduction........................................................................................................3
Product Description.............................................................................................................3
Features..............................................................................................................................3
Additional Features......................................................................................................................3
Product Overview................................................................................................................4
3. Setup...................................................................................................................5
AC Power............................................................................................................................5
AC Plug .......................................................................................................................................5
Power Linking..............................................................................................................................5
Fuse Replacement ......................................................................................................................5
DMX Linking........................................................................................................................6
DMX Modes.................................................................................................................................6
Master/Slave Connectivity...........................................................................................................6
Glare Shield ........................................................................................................................6
Mounting .............................................................................................................................7
Orientation...................................................................................................................................7
Rigging........................................................................................................................................7

Table of Contents
-ii- COLORado™ Batten 144 Tour User Manual Rev. 6
4. Operation............................................................................................................8
Control Panel Description ...................................................................................................8
Control Options...................................................................................................................8
Programming.......................................................................................................................8
DMX Personality..........................................................................................................................8
DMX Control................................................................................................................................8
Static Color..................................................................................................................................9
Auto Programs.............................................................................................................................9
Edit Customs...............................................................................................................................9
Master/Slave................................................................................................................................9
Color Settings..............................................................................................................................9
Dimmer Curves..........................................................................................................................10
Control Panel Lock....................................................................................................................10
Program Upload ........................................................................................................................10
Reset.........................................................................................................................................11
Whites Setting ...........................................................................................................................11
RGBW to White Setting.............................................................................................................11
Fan Setting................................................................................................................................11
TOUR Notes......................................................................................................................11
Master Dimmer..........................................................................................................................11
Red, Green, Blue White, and Amber Color Selection...............................................................11
Color Macros.............................................................................................................................11
Strobe........................................................................................................................................12
Auto/Custom/Fan.......................................................................................................................12
Dimmer Speed...........................................................................................................................12
Menu Map.........................................................................................................................13
DMX Values......................................................................................................................14
TOUR ........................................................................................................................................14
TOUR (Cont.) ............................................................................................................................15
BLOCK1 ....................................................................................................................................16
BLOCK2 ....................................................................................................................................16
ARC1.........................................................................................................................................16
ARC1 + D.................................................................................................................................16
ARC3.........................................................................................................................................17
ARC3 + D..................................................................................................................................17
ARC3 + S ..................................................................................................................................17
HSV...........................................................................................................................................17
5. Technical Information......................................................................................18
Product Maintenance........................................................................................................18
Troubleshooting Guide......................................................................................................19
Returns Procedure............................................................................................................20
Technical Specifications ...................................................................................................21
Contact Us............................................................................................................22

Before You Begin
COLORado™ Batten 144 Tour User Manual Rev. 6 -1-
1. Before You Begin
What Is
Included
•One COLORado™ Batten 144 Tour
•One Glare Shield
•One Power Cord
•One Warranty Card
•One Quick Reference Guide
Unpacking
Instructions
Upon receipt, carefully unpack the items and inspect the box. Make sure
you have
received all the parts in good condition.
Claims
If the box or the contents (the product and included
accessories) appear damaged from
shipping, or show signs of mishandling, notify the carrier immediately upon receipt
, not
Chauvet. Failure to notify the carrier in a timely manner may invalidate your claim
. In
addition, keep the container and all the packing material for inspection.
For other issues such as missing components or parts, damage not related to shipping, or
concealed damage, file a claim with Chauvet within 7 days of receiving the merchandise.
Refer to the Contact Us section in this manual for addresses and phone numbers.
Typographic
Conventions
Convention Meaning
1~512
A range of values in the text
50/60
A set of mutually exclusive values in the text
Claims A new term, another document reference, or section or chapter in
this document
<SET>
A button on the product’s control panel
Settings
A product function or a menu option
MENU > Settings
A sequence of menu options
1~10
A range of menu values from which to choose in a menu
Yes/No
A set of two mutually exclusive menu options in a menu
ON
A unique value to be entered or selected in a menu
Icon Indications
Icon
This icon indicates
Critical installation, configuration, or operation information. Failure
to comply with this information may render the product partially or
completely inoperative, damage third-party equipment, or cause
harm to the user.
Important installation or configuration information. Failure to
comply with this information may prevent the product from
functioning correctly.
Useful information.
The term “DMX” used throughout this manual refers to the USITT DMX512-A digital
data transmission protocol.

Before You Begin
-2- COLORado™ Batten 144 Tour User Manual Rev. 6
Safety Notes
Read all the following Safety Notes before working with this product. These notes include
important information about the installation, usage, and maintenance of this product.
There are no user-serviceable parts in this product. Any reference to servicing in
this User Manual applies only to properly certified Chauvet
technicians. Do not
open the housing or attempt any repairs unless you are certified by Chauvet.
Please refer to all applicable local codes and regulations for proper installation of
this product.
Personal Safety
•Avoid direct eye exposure to the light source while the product is on.
•Always disconnect this product from its power source before servicing.
•Always connect this product to a grounded circuit to avoid the risk of electrocution.
•Do not touch this product’s housing during operation because it may be very hot.
Mounting and
Rigging
•This product is for indoor use only! To prevent risk of fire or shock, do not expose this
product to rain or moisture.
•Make sure there are no flammable materials close to this product while it is operating.
•When hanging this product, always secure to a fastening device using a safety cable.
Power and Wiring
•Always make sure you are connecting this product to the proper voltage in accordance
with the specifications in this manual or on the product’s specification label.
•CAUTION: When transferring product from extreme temperature environments, (e.g.
cold truck to warm humid ballroom) condensation may form on the internal electronics
of the product. To avoid causing a failure, allow product to fully acclimate to the
surrounding environment before connecting it to power.
•Never connect this product to a dimmer pack or rheostat.
•Never disconnect this product by pulling or tugging on the power cable.
Operation
•Do not operate this product if you see damage on the housing, lenses, or cables. Have
the damaged parts replaced by an authorized technician at once.
•Do not cover the ventilation slots when operating to avoid internal overheating.
•To eliminate unnecessary wear and improve its lifespan, during periods of non-use
completely disconnect the product from power via breaker or by unplugging it.
•The maximum ambient temperature is 104 °F (40 °C). Do not operate this product at a
higher temperature.
•In case of a serious operating problem, stop using this product immediately!
In the unlikely event that your Chauvet product may require service, contact
Chauvet Technical Support.
Expected LED
Lifespan
LEDs gradually decline in brightness over time, mostly because of heat. Packaged in
clusters, LEDs exhibit higher operating temperatures than in ideal, single-LED conditions.
For this reason, using clustered
LEDs at their fullest intensity significantly reduces the
LEDs’ lifespan. Under normal conditions, this lifespan can be 40,000 to 50,000 hours. If
extending this lifespan is vital, lower the operating temperature by improving the
ventilation around the product and reducing the ambient temperature
to an optimal
operating range
. In addition, limiting the overall projection intensity may also help to
extend the LEDs’ lifespan.

Introduction
COLORado™ Batten 144 Tour User Manual Rev. 6 -3-
2. Introduction
Product
Description
The COLORado™ Batten 144 Tour is an RGBWA linear LED wash light. It consists of a
single module that accommodates the internal power supply, the main control, the control
panel, the LED drivers, the LED boards and lenses as well as the power and signal
connectors.
The product features two mounting brackets that double as floor mount feet and hanging
support brackets. These brackets have tilt adjust knobs to simplify mounting.
Features
•3, 4, 5, 6, 7, 9, 12, or 15-channel RGBWA LED linear wash light with ID Addressing
•Operating modes:
3-channel: HSV control
3-channel: RGB control
4-channel: RGB, dimmer
5-channel: RGBWA
6-channel: RGBWA, dimmer
7-channel: RGBWA, dimmer, strobe
9-channel: RGB control per block
12-channel: RGBWA, dimmer, dimmer speed, strobe, macro, auto/custom, and
module select
15-channel: RGBWA control per block
•Built-in automated programs via DMX
•Recall custom programs via DMX
•User-configurable programs
•
RGBWA color mixing with or without DMX control
Additional
Features
•Five distinct dimming curves
•Additional power output: max 3products @ 120 V
•Neutrik® powerCON® connectors
•3- and 5-pin DMX input and output connectors
•LCD display with passcode protection
•
Adjustable double-bracketed yoke for floor or overhead mounting

Introduction
-4- COLORado™ Batten 144 Tour User Manual Rev. 6
Product Overview
Control Panel-
Fuse
5-Pin DMX In/Out
3-Pin DMX In/Out
Safety Eye Bolt
Power Out
Power In

Setup
COLORado™ Batten 144 Tour User Manual Rev. 6 -5-
3. Setup
AC Power
The COLORado™ Batten 144 Tour has an auto-ranging power supply that works
with an
input voltage range of 100~240 VAC, 50/60 Hz.
Make sure that you are connecting this product to the proper voltage.
To determine the
power requirements for the COLORado™ Batten 144 Tour, refer to the spe
cification label
affixed to the product or the specifications in this manual.
Refer to the Technical Specifications chart.
•Always connect this product to a protected circuit with an appropriate
electrical
ground to avoid the risk of electrocution or fire.
•To eliminate unnecessary wear and improve its lifespan, during periods of non-
use completely disconnect the product from power via breaker or by unplugging
it.
The listed current rating indicates the maximum current draw during normal operation.
For
more information, download the document Sizing Circuit Breakers from the Chauvet
website: www.chauvetprofessional.com.
Never connect this product to a rheostat (variable resistor) or dimmer circuit, even if
the rheostat or dimmer channel serves only as a 0% to 100% switch.
AC Plug
The COLORado™ Batten 144 Tour
comes with a power input cord terminated with a
Neutrik® powerCON® A connector on one end and an Edison plug on the other end (U.S.
market). If the power input cord that came with your product has no plug, or if
you need to
change the Edison plug, use the table below to wire the new plug.
Connection
Wire (U.S.)
Wire (Europe)
IPXX Pin
Screw Color
AC Live Black Brown 1 Yellow or Brass
AC Neutral White Blue 2 Silver
AC Ground Green/Yellow Green/Yellow 3 Green
Power Linking
The COLORado™ Batten 144 Tour supports power linking. You can power link up to 3
products at 120 VAC or 5 products at 230 VAC.
This product comes with a power input cord. This product does not come with
a power
linking cable; however, a power linking cable is available as an option.
Fuse Replacement
1. Disconnect this product from the power outlet.
2. Using a Phillips #2 head screwdriver, unscrew the fuse
holder cap from the housing.
3. Remove the blown fuse and replace with a good fuse of
the same type and rating.
4. Screw the fuse holder cap back in place and reconnect
power.

Setup
-6- COLORado™ Batten 144 Tour User Manual Rev. 6
DMX Linking
You can link the COLORado™ Batten 144 Tour to a DMX controller using a standard DMX
serial connection. If using other DMX compatible products with the
COLORado™ Batten
144 Tour, you can control each individually with a single DMX controller.
DMX Modes
The COLORado™ Batten 144 Tour uses the standard DMX data connection for the TOUR,
BLOCK1, BLOCK2, ARC1, ARC1 +D, ARC3, ARC3 + D, ARC3 + S, and HSV DMX
modes.
Refer to the Introduction chapter for a brief description of these modes.
Refer to the Operation chapter to learn how to configure the COLORado™ Batten 144 Tour
to work in these modes.
The DMX Values
section will provide you with detailed information regarding the DMX
modes.
Master/Slave
Connectivity
The Master/Slave mode allows a COLORado™ Batten 144 Tour (the “master product”) to
control one or more COLORado™ Batten 144 Tours (the “slave products”)
without a DMX
controller. One COLORado™ Batten 144 Tour becomes the master product
when running
an Auto or Custom program, or by being in STATIC mode.
You must configure each slave product’s control panel to operate in SLAVE mode
. During
Master/Slave operation, the slave products will operate in unison with the master product.
If you are not familiar with or need more information about DMX standards, Master/Slave
connectivity, or the DMX cables needed to link this product to a DMX controller, download
the DMX Primer from the Chauvet website: www.chauvetprofessional.com.
DO NOT connect a DMX controller to products operating in Master/Slave mode. The
DMX controller signals may interfere with the signals from the master product.
The Operation chapter of this manual provides detailed instructions on how to
configure the Master and Slave products.
Glare Shield
The COLORado™ Batten 144 Tour comes with a glare shield already mounted on the side
of the unit. Please refer to the Product Overview diagram for reference.
To extend the glare shield, do the following:
1. Loosen the glare shield screw on the front of the fixture.
2. Slide the glare shield on either direction until it is free.
3. Turn over and reinsert the glare shield into either slot so it projects itself over the
LEDs lens cover, as shown below.
4. Adjust the angle of the glare shied and tighten the glare shield screw.
Extending the Glare
Shield

Setup
COLORado™ Batten 144 Tour User Manual Rev. 6 -7-
Mounting
Before mounting this product, read and follow the Safety Notes
. For our CHAUVET®
Professional line of mounting clamps, go to http://trusst.com/products/.
Orientation
Always mount this product in a safe position and make sure there is adequate room
for
ventilation, configuration, and maintenance.
Rigging
Chauvet recommends using the following general guidelines when mounting this product.
•When selecting an installation location, consider easy access to this product for
operation, programming adjustments, and routine maintenance.
•Make sure to mount this product away from any flammable material as indicated in the
Safety Notes.
•Never mount in places where rain, high humidity, extreme temperature changes, or
restricted ventilation may affect the product.
•If hanging this product, make sure that the mounting location can support the product’s
weight. Refer to the Technical Specifications chart for the weight-bearing requirements
of this product.
•When hanging this product, always secure to a fastening device using a safety
chain/cable.
Procedure
The COLORado™ Batten 144 Tour comes with
two adjustable feet that double as hanging
bracket to which you can attach clamps. These brackets also serve as floor stands or wall-
mount supports. You must supply your own clamps and make sure the clamps
are capable
of supporting the weight of this product. You must use two mounting points per product.
Mounting Diagram
Overhead Mounting
Floor Mounting

Operation
-8- COLORado™ Batten 144 Tour User Manual Rev. 6
4. Operation
Control Panel
Description
Button Function
<MENU> Exits from the current menu or function
<ENTER> Enables the currently displayed menu or sets the currently selected value in to the
current function
<UP> Navigates upward through the menu list and increases the numeric value when in a
function
<DOWN> Navigates downward through the menu list and decreases the numeric value when in a
function
Control
Options
You can set the COLORado™ Batten 144 Tour
start address in the 001~512 DMX range.
This enables control of up to 42 products in the 12-channel TOUR personality.
Programming
Refer to the Menu Map to understand the menu options. The menu map shows the main
level and a variable number of programming levels for each option.
•To go to the desired main level, press <MENU> repeatedly until the option shows on the
display. Press <ENTER> to select. This will take you to the first programming level for
that option.
•To select an option or value within the current programming level, press <UP> or
<DOWN> until the option shows on the display. Press <ENTER> to select. In this case,
if there is another programming level, you will see that first option, or you will see the
selected value.
•Press <MENU> repeatedly to exit to the previous main level.
DMX Personality
This setting allows you to choose a particular DMX personality.
1. Go to the PERSON main level.
2. Select the desired personality (TOUR, ARC1, ARC1 + D, ARC3, ARC3 + D,
ARC3 + S, HSV, BLOCK1, or BLOCK2).
•See the DMX Values section for the highest starting address you can select for
each personality.
•Make sure that the starting addresses on the various products do not overlap due
to the new personality setting.
DMX Control
In this mode, each product
will respond to a unique starting address from the DMX
controller. All products with the same starting address will respond in unison.
Select the TOUR personality as shown in DMX Personality.
1. Set the running mode:
a. Go to the RUN main level.
b. Select the DMX programming level.
2. Set the starting address:
a. Go to ADDRESS.
b. Select the starting address (001~512).
The highest recommended starting address for each DMX mode are as follows:
DMX Mode DMX Address DMX Mode DMX Address DMX Mode DMX Address
TOUR
501
ARC3
508
HSV
510
ARC1
510
ARC3+D
507
BLOCK1
504
ARC1+D
509
ARC3+S
506
BLOCK2
498

Operation
COLORado™ Batten 144 Tour User Manual Rev. 6 -9-
Static Color
The Static Color mode allows for permanent RGBWA color mixing without a DMX controller.
1. Go to the STATIC main level.
2. Select the desired color (RED, GREN, BLUE, WHIT, or AMBE).
3. Select the desired color value (000~255).
4. Repeat for the other colors.
5. Select STRB.
6. Select the desired frequency (00~20).
Auto Programs
Auto programs allow for dynamic RGBWA color mixing without a DMX controller.
1. Go to AUTO.
2. Select the desired auto (AUTO 01~10)or custom program (CUSTOM 01~10).
3. When selecting an auto program, you can also select the auto playing speed
(SP000~255).
You cannot edit any of the auto programs (AUTO 01~10). However, you can edit the
custom programs (CUSTOM 01~10). See Edit Customs below for details.
Edit Customs
This setting allows the programming of up to 30 scenes for each of the 10 customizable
programs, including colors and effects.
1. Go to the EDIT main level.
2. Select the desired auto program (CUSTOM 01~10).
3. Select the desired scene (SCENE 01~30).
4. Select the desired color or effect (RED, GREN, BLUE, WHIT, AMBE, STRB, TIME, or
FADE).
5. Select the color or effect value (000~255 for colors and timers, or 00~20 for strobe).
6. Repeat for the other colors or effects.
7. Return to the SCENE level (step “3”).
8. Repeat the settings of colors and effects for the other scenes.
Master/Slave
The Master/Slave mode allows a group of COLORado™ Batten 144 Tours (the slave
products) to simultaneously duplicate the output of another COLORado™ Batten 144 Tour
(the master product) without a DMX controller.
1. Set each of the slave products:
a. Go to RUN.
b. Select SLAVE.
2. Set the master product:
a. Set the running mode to DMX as explained in DMX Control.
b. Select an auto or custom program as explained in Auto Programs, or a static mix
of colors.
•The master product is the one that runs a program (whether Auto or Custom) or
Static Color mode.
•Do not connect a DMX controller to the products configured for Master/Slave
operation.
The DMX controller may interfere with signals from the master
product.
•The master product should be the first product in the daisy chain.
Color Settings
The COLOR setting determines how the COLORado™ Batten 144 Tour generates the white
color based on various RGB settings.
1. Go to the SETTINGS main level.
2. Select COLOR.
3. Select OFF, RGB TO W, or UC.

Operation
-10- COLORado™ Batten 144 Tour User Manual Rev. 6
OFF: When all the RGB faders are set to 255, the output is maximum, although
the resulting white color may not be balanced.
RGB TO W: When all the RGB faders are set to 255, the resulting output is defined by
the configured White color (see Whites Settings).
UC: When all the RGB faders are set to 255, the output matches that of less
efficient products (Universal Color).
Dimmer Curves
This setting determines how fast the output of the COLORado™ Batten 144 Tour changes
when you modify the values of the Red, Green, Blue, White, Amber, and Dimmer faders.
This setting provides four different options to simulate the dimming curve of an incandescent
lighting product.
1. Go to the SETTINGS main level.
2. Select DIMMER.
3. Select a dimmer function (OFF, DIM1, DIM2, DIM3, or DIM4).
OFF: The output is proportional (linear) to the Dimmer and RGBWA channel
values.
DIM1~4: The output follows the Dimmer and RGBWA channel values based on the
corresponding dimmer curve, being DIM1 the fastest and DIM4 the slowest.
Control Panel
Lock
This setting enables you to activate or disable the control panel lock, which keeps non-
authorized personnel from changing the product’s settings.
1. Go to the KEYLOCK main level.
2. Select ON or OFF.
When the control panel lock is active, the product will prompt you to enter the
passcode after 30 seconds of control panel inactivity or after turning on the product.
After being prompted to enter the passcode:
Press <UP>, <DOWN>, <UP>, <DOWN>, <ENTER>
Program Upload
This option allows you to copy the custom programs of one COLORado™ Batten 144 Tour
onto other COLORado™ Batten 144 Tours by using the Master/Slave mode.
1. Configure and connect the products in a Master/Slave arrangement, where the master
product has the custom programs you want to transfer to the slave products.
2. From the master product, go to the SETTINGS main level.
3. Select UPLOAD, press <ENTER>.
4. When PASSCODE shows, enter the master access passcode (see above).
5. When SEND shows, press <ENTER> to start the upload.
6. Wait for the upload process to finish (the display will show END/MAIN) before
continuing or turning the products off.
The Master/Slave products will provide the status of the process by lighting up as
follows:
•Yellow indicates that the upload running.
•Green indicates that the upload completed successfully.
•Red indicates that the upload
failed due to an error. Recheck all cable
connections and restart.
DO NOT upload the data from a COLORado™ Batten 144 Tour to a different product.
The other product may become inoperative.

Operation
COLORado™ Batten 144 Tour User Manual Rev. 6 -11-
Reset
This setting allows you to reset the COLORado™ Batten 144 Tour to the
default values,
including the custom programs.
1. Go to the SETTINGS main level.
2. Select RESET.
3. When PASSCODE shows, press <ENTER>.
4. Enter the master access passcode as described in Control Panel Lock.
5. Wait for the reset process to finish.
Whites Setting
This setting allows you to select and edit the temperature of the white colors used in channel
7 (Macros) when in the TOUR mode.
1. Go to CALIB1.
2. Select a white color (WHITE1~11).
3. Select (RED, GREN, BLUE, WHIT, or AMBE).
4. Select a color value (000~255).
5. Repeat for the other colors.
RGBW to White
Setting
This setting allows the user to define the maximum RGB values when RGB to White (RGB
TO W) is active.
1) Go to CALIB2.
2) Press <ENTER> when you see RGB TO W on the display.
3) Select a color (RED, GREN, or BLUE).
4) Select a color value (000~255).
5) Repeat for the other colors.
When selecting RGB TO W, you will only be able to define the values of RED, GREN
(green), and BLUE.
The values of RED, GREN, and BLUE configured from CALIB > RGB TO W will define
the color temperature shown when the RGB faders are set to 255 if SETTING > COLOR
> RGB TO W is active.
Fan Setting
1. Press <MENU> repeatedly until FANS shows, and press <ENTER> to accept.
2. Use <UP> or <DOWN> to select a setting (OFF, LOW, NORMAL, HIGH, or AUTO).
3. Press <MENU> to exit once done.
•When in AUTO, the fan speed automatically changes so the product’s temperature
does not exceed the maximum allowed value.
•When in the other settings, the fan speed follows the predefined values.
•The internal controller will override any manual setting if the internal temperature
rises above a certain level.
TOUR Notes
These notes clarify how the TOUR DMX personality works.
Master Dimmer
•Channel 1 controls the intensity of the currently projected color.
•When the slider is at the highest position (100%), the intensity of the output is at
maximum.
Red, Green, Blue
White, and
Amber Color
Selection
•Channels 2 through 6 control the intensity ratio of each of the Red, Green, Blue, White,
and Amber LEDs.
•When these channels are at the highest position (100%), the intensity of each color is at
maximum if SETTINGS > COLOR is OFF.
•
You can combine channels 2 through 6 to create over one trillion colors.
Color Macros
•Channel 7 selects the required Color Macro.
•Channel 7 has priority over channels 2 through 6.
•
Channel 1 controls the intensity of the Color Macro.

Operation
-12- COLORado™ Batten 144 Tour User Manual Rev. 6
Strobe
•Channel 8 controls the strobe frequency (not the intensity) of channels 2 through 7.
•Channel 8 can strobe channels 2 through 6 when not running macros, allowing the
individual faders (R, G. B, W, and A), as well as channel 1 (D), to control the output
intensity.
•Channel 8 can strobe channel 7 when running macros, allowing channel 7 to select the
macro and channel 1 to control the output intensity.
Auto/Custom/Fan
•Channel 9 selects the preset auto programs AUTO01~10 or the custom programs
CUSTOM01~10,as well as the fan speed.
•When activating the custom programs CUSTOM01~10, you can control the Step Time and
Fade Time using channels 2 and 3, respectively.
•Channel 9 has priority over channels 2 through 8.
•
Channel 10 controls the speed at which each auto program plays.
Dimmer Speed
•Channel 11 selects the Dimmer mode and speed. Dimmer mode provides four different
options to simulate the dimming curve of an incandescent lighting product.
•When DIMMER is set to OFF,the changes in the RGBWA and Master Dimmer faders are
linear.
•When DIMMER is set to DIM1~DIM4, DIM1 is the fastest dimmer curve and DIM4 is the
slowest.

Operation
COLORado™ Batten 144 Tour User Manual Rev. 6 -13-
Menu Map
Main Level Program Levels Description
STATIC
RED
000~255 User can combine red, green, blue, white, and
amber to generate a custom color
GREN
BLUE
WHIT
AMBE
STRB
00~20
Select a strobe frequency
AUTO
AUTO
01~10 SP 000~255
Choose from 10 automatic programs
CUSTOM
Choose from 10 customizable programs
ADDRESS
ADDR:
001~512
Sets the DMX starting address
RUN
DMX
Selects the DMX or SLAVE mode
SLAVE
PERSON
TOUR
12-channel: RGBWA, dimmer, dimmer speed,
strobe, macro, auto/custom, and module select
BLOCK1
9-channel: RGB for individual block control
BLOCK2
15-channel: RGBWA for individual block control
ARC1
3-channel: RGB control
ARC1 + D
4-channel: RGB, dimmer
ARC3
5-channel: RGBWA control
ARC3+ D
6-channel: RGBWA, dimmer
ARC3+ S
7-channel: RGBWA, dimmer, strobe
HSV
3-channel: HSV control (hue, saturation, and value)
SETTINGS
UPLOAD
PASSWORD
****
Uploads custom programs
RESET
PASSWORD
****
Resets the product to the factory settings
DIMMER
OFF
No dimmer
DIM1
Dimmer curve
DIM2
DIM3
DIM4
COLOR
OFF
RGB set to “255”= max. output
RGB TO W
RGB set to “255” = balanced white
UC
Universal color balance
DERR SAVE
All LEDs stay on the last command used when the
DMX signal is lost
BLAK
All LEDs turn off when DMX signal is lost
EDIT CUSTOM 01~10 SCENE 01~30
RED
000~255 User can combine red, green, blue, amber and
white to generate a custom color
GREN
BLUE
WHIT
AMBE
STRB
00~20
Selects the strobe frequency
TIME
000~255
Defines the step duration
FADE
Defines the fade duration
CALIB1 WHITE 01~11
RED
000~255 Modifies the color macros used in the TOUR
personality
BLUE
GREN
WHIT
AMBE
CALIB2 RGB TO W
RED
000~255 Defines the color temperature used when COLO is
set to RGbw
GREN
BLUE
FANS
OFF
Selects fan speed
LOW
NORMAL
HIGH
AUTO
KEYLOCK
ON
Turns the passcode on or off
OFF

Operation
-14- COLORado™ Batten 144 Tour User Manual Rev. 6
DMX Values
TOUR
Channel Function Value Percent/Setting
1
Master Dimmer
000 ó255
000~100%
2 Red 000 ó255
000~100%
(Step Time when playing custom 01~10)
3 Green 000 ó255
000~100%
(Fade Time when playing custom 01~10)
4
Blue
000 ó255
000~100%
5
White
000 ó255
000~100%
6
Amber
000 ó255
000~100%
7 Color Macro + White
Balance
000 ó010
011 ó030
031 ó050
051 ó070
071 ó090
091 ó110
111 ó130
131 ó150
151 ó170
171 ó200
201 ó205
206 ó210
211 ó215
216 ó220
221 ó225
226 ó230
231 ó235
236 ó240
241 ó245
246 ó250
251 ó255
No Function
R: 100% G: 0~100% B: 0%
R: 100~0 G: 100% B: 0%
R: 0 G: 100% B: 0~100%
R: 0 G: 100~0 B: 100%
R: 0~100% G: 0% B: 100%
R: 100% G: 0% B: 100~0
R: 100% G: 0~100% B: 0~100%
R: 100~0 G: 100~0 B: 100%
All LEDs: 100%
White 1
White 2
White 3
White 4
White 5
White 6
White 7
White 8
White 9
White 10
White 11
8 Strobe
000
ó
009
010 ó255
No function
01~20 Hz
Continues on next page

Operation
COLORado™ Batten 144 Tour User Manual Rev. 6 -15-
TOUR
(Cont.)
Channel Function Value Percent/Setting
9 Auto + Custom Programs + Fan
Control
000 ó010
011 ó020
021 ó025
026 ó030
031 ó040
041 ó050
051 ó060
061 ó070
071 ó080
081 ó090
091 ó100
101 ó110
111 ó120
121 ó130
131 ó140
141 ó150
151 ó160
161 ó170
171 ó180
181 ó190
191 ó200
201 ó210
211 ó220
221 ó230
231 ó255
No Function
Fans Off
Fans Low
Fans High
Fans Auto
Auto 1
Auto 2
Auto 3
Auto 4
Auto 5
Auto 6
Auto 7
Auto 8
Auto 9
Auto 10
Custom 1
Custom 2
Custom 3
Custom 4
Custom 5
Custom 6
Custom 7
Custom 8
Custom 9
Custom 10
10
Auto Speed
000 ó255
0~100%
11 Dim Speed
000
ó
009
010 ó029
030 ó069
070 ó129
130 ó189
190 ó255
Dimmer speed as per Control Panel
Linear dimmer
Non-linear dimmer 1 (fastest)
Non-linear dimmer 2
Non-linear dimmer 3
Non-linear dimmer 4 (slowest)
12 Module Select
000
ó
010
005 ó034
035 ó064
065 ó094
095 ó124
125 ó154
155 ó184
185 ó214
215 ó255
Blocks 1, 2 & 3
Block 1
Block 2
Block 3
Blocks 1 & 2
Blocks 2 & 3
Blocks 1 & 3
Blocks 1, 2 & 3
No Function

Operation
-16- COLORado™ Batten 144 Tour User Manual Rev. 6
BLOCK1
Channel Function Value Percent/Setting
1
Block 1 Red
000 ó255
0~100%
2
Block 1 Green
000 ó255
0~100%
3
Block 1 Blue
000 ó255
0~100%
4
Block 2 Red
000 ó255
0~100%
5
Block 2 Green
000 ó255
0~100%
6
Block 2 Blue
000 ó255
0~100%
7
Block 3 Red
000 ó255
0~100%
8
Block 3 Green
000 ó255
0~100%
9
Block 3 Blue
000 ó255
0~100%
BLOCK2
Channel Function Value Percent/Setting
1
Block 1 Red
000 ó255
0~100%
2
Block 1 Green
000 ó255
0~100%
3
Block 1 Blue
000 ó255
0~100%
4
Block 1 White
000 ó255
0~100%
5
Block 1 Amber
000 ó255
0~100%
6
Block 2 Red
000 ó255
0~100%
7
Block 2 Green
000 ó255
0~100%
8
Block 2 Blue
000 ó255
0~100%
9
Block 2 White
000 ó255
0~100%
10
Block 2 Amber
000 ó255
0~100%
11
Block 3 Red
000 ó255
0~100%
12
Block 3 Green
000 ó255
0~100%
13
Block 3 Blue
000 ó255
0~100%
14
Block 3 White
000 ó255
0~100%
15
Block 3 Amber
000 ó255
0~100%
ARC1
Channel Function Value Percent/Setting
1
Red
000 ó255
0~100%
2
Green
000 ó255
0~100%
3
Blue
000 ó255
0~100%
ARC1 + D
Channel Function Value Percent/Setting
1
Master Dimmer
000 ó255
0~100%
2
Red
000 ó255
0~100%
3
Green
000 ó255
0~100%
4
Blue
000 ó255
0~100%
