LG-40
Scorpion Array™
USER MANUAL
CHAUVET, 3000 N 29th Ct, Hollywood, FL 33020 U.S.A
[phone] – [phone]
FAX [phone]
www.chauvetlighting.com

TABLE OF CONTENTS
BEFORE YOU BEGIN........................................................................................................................................................... 3
WHAT IS INCLUDED................................................................................................................................................................................3
UNPACKING INSTRUCTIONS....................................................................................................................................................................3
ACPOWER...........................................................................................................................................................................................3
SAFETY INSTRUCTIONS..........................................................................................................................................................................4
INTRODUCTION ................................................................................................................................................................... 5
FEATURES............................................................................................................................................................................................5
DMXCHANNEL SUMMARY.....................................................................................................................................................................5
PRODUCT OVERVIEW ............................................................................................................................................................................6
GENERAL INSTRUCTIONS .......................................................................................................................................................................8
COMPLIANCE STATEMENT................................................................................................................................................ 9
LASER SAFETY AND COMPLIANCE INFORMATION......................................................................................................................................9
PROPER USAGE..................................................................................................................................................................................10
CONTROL & FUNCTION.................................................................................................................................................... 10
DIPSWITCH CHART..............................................................................................................................................................................10
DMXMODE........................................................................................................................................................................................11
Setting the starting address ...................................................................................................................................... 11
OPERATION........................................................................................................................................................................................12
Stand-Alone Operation (Sound-Active, Auto Mode):.................................................................................................. 12
Master-Slave Operation (Master Sound, Master Auto, Slave Mode):......................................................................... 12
Universal DMX Control (DMX Mode):......................................................................................................................... 13
APPENDIX........................................................................................................................................................................... 14
DMXPRIMER .....................................................................................................................................................................................14
Fixture Linking........................................................................................................................................................... 14
DMXQUICK REFERENCE CHART .........................................................................................................................................................15
DMXCHANNEL VALUES ......................................................................................................................................................................16
TROUBLESHOOTING.............................................................................................................................................................................16
GENERAL MAINTENANCE .....................................................................................................................................................................17
RETURNS PROCEDURE........................................................................................................................................................................17
CLAIMS ..............................................................................................................................................................................................17
TECHNICAL SPECIFICATIONS ................................................................................................................................................................18
TECHNICAL SUPPORT..........................................................................................................................................................................18
LG-40 User Manual 2 1/10/2007/10:43

BEFORE YOU BEGIN
What is included
¾1 x Laser Array™
¾Power Cord
¾Warranty Card
¾User
Manual
Unpacking Instructions
Immediately upon receiving a fixture, carefully unpack the carton, check the contents to ensure that
all parts are present, and have been received in good condition. Notify the shipper immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture
must be returned to the factory, it is important that the fixture be returned in the original factory box
and packing.
AC Power
To determine the power requirements for a particular fixture, see the label affixed to the back plate of
the fixture or refer to the fixture’s specifications chart. A fixture’s listed current rating is its average
current draw under normal conditions. All fixtures must be powered directly off a switched circuit and
cannot be run off a rheostat (variable resistor) or dimmer circuit, even if the rheostat or dimmer
channel is used solely for a 0% to 100% switch. Before applying power to a
fixture, check that the source voltage matches the fixture’s requirement.
Check the fixture or device carefully to make sure that if a voltage selection
switch exists that it is set to the correct line voltage you will use.
Figure 1 - AC Voltage Switch
Warning! Verify that the voltage select switch on your unit matches the
line voltage applied. All fixtures must be connected to circuits
with a suitable Earth Ground. Not all fixtures have a voltage
select switch. Please be sure to
connect to the proper voltage.
AC Power Connection:
The unit is supplied with a power plug appropriate to its voltage and destination. Should any other
connections be required they must be carried out with the following configuration.
Earth = Green/Yellow cable
Neutral = Blue cable
Live = Brown cable
DANGER VISIBLE LASER RADIATION
AVOID DIRECT EYE EXPOSURE
CLASS 3A LASER PRODUCT
<20mW max CW Diode 532
IEC/EN 60825-1, ed 1.2
LG-40 User Manual 3 1/10/2007/10:43

Safety Instructions
Please read these instructions carefully, which includes important
information about the installation, usage and maintenance of this
product.
•Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that
they also receive this instruction booklet.
•Always make sure that you are connecting to the proper voltage, and that the line voltage you are
connecting to is not higher than that stated on the decal or rear panel of the fixture.
•This product is intended for indoor use only!
•To prevent risk of fire or shock, do not expose fixture to rain or moisture. Make sure there are no
flammable materials close to the unit while operating.
•The unit must be installed in a location with adequate ventilation, at least 50cm (20in) from adjacent
surfaces. Be sure that no ventilation slots are blocked.
•Always disconnect from power source before servicing or replacing lamp or fuse and be sure to
replace with same lamp source.
•Secure fixture to fastening device using a safety chain. Never carry the fixture solely by its head. Use
its carrying handles.
•Maximum ambient temperature (Ta) is 35°C (95°F). Do not operate fixture at temperatures higher
than this.
•In the event of a serious operating problem, stop using the unit immediately. Never try to repair the
unit by yourself. Repairs carried out by unskilled people can lead to damage or malfunction. Please
contact the nearest authorized technical assistance center. Always use the same type spare parts.
•Don’t connect the device to a dimmer pack.
•Make sure the power cord is never crimped or damaged.
•Never disconnect the power cord by pulling or tugging on the cord.
•Avoid direct eye exposure to the lamp while it is on.
•Do not daisy chain power to more than eight units.
Caution! There are no user serviceable parts inside the unit. Do not open the housing or
attempt any repairs yourself. In the unlikely event your unit may require service,
please contact CHAUVET.
LG-40 User Manual 4 1/10/2007/10:43

INTRODUCTION
Your LG-40 is very unique! You may notice that the beams coming out of the projector are larger than
the 4.95mW projectors. There is a very distinct reason for this. Unlike 4.95mW projectors, the output
of the CHAUVET laser projectors with Fatbeam™ technology outputs <20mW for each beam.
Normally outputs greater than 4.95mW require a variance from the FDA. This product has been
designed to meet a special classification of ClassIIIA. Under this classification with the Fatbeam™
technology the acceptable energy levels (AEL) have been met. Therefore the maximum potential
exposure to the unaided eye is less than 4.95mW for a static beam. Additionally the Maximum
Permissible Exposure (MPE) with this product is below acceptable levels for human ocular or tissue
exposure.
Features
CONTROL FEATURES
•2-channel DMX-512 controlled green laser
•Operating modes: auto, sound active, master/slave
•Scan and speed adjustment
•Laser on/off
ADDITIONAL FEATURES
•10mW Fat Beam™laser produces 10-14mm beams that comply with IEC safety standards under
ClassIIIA
•No variance required
•Multiple array configurations with optional mounting brackets (LAB-40V, LAB-40CT)
•Additional power output for daisy chaining units
•Built-in automated programs via master/slave or DMX
•Built-in sound activated programs via master/slave or DMX
•Sound sensitivity control
•Micro-stepping motors
•Rugged construction
•Fan cooled
DMX Channel Summary
CHANNEL FUNCTION
1 Rotation
2 Speed
LG-40 User Manual 5 1/10/2007/10:43

Product Overview
Sound Sensitivity DMX address/Mode
DMXIn
Power Out Power In
Power On/Off
DMX Out
110V 230V
12345678910
XXXXXXXX01
XXXXXXXX11
0000000000
0
DI 0=O PSWITCH CH ART FUNC TION
FF 1=ON X=0FF or ON
AUTO MODE
SOUND M ODE
SLAVE M ODE
DMX MODESE T DM X ADDR ES S
Dipswitch
settings for DMX
addressing &
other functions
Cooling
Fan
Sound Sensitivity
Knob
DMX
connectors
AC Power
Input and Fuse
*AC Power Output
(See note below)
Power Switch
Input Voltage
Selector Switch
*Note: This power link can
be used to connect up to
seven additional LG-40 units
together in a daisy chain.
This is the ONLY intended
purpose for this outlet.
LG-40 User Manual 6 1/10/2007/10:43

LG-40 User Manual 7 1/10/2007/10:43
Array configurations using
optional hardware.
LAB-40V
LAB-40CT

General Instructions
Please read the contents of this manual carefully and thoroughly before operating the Laser system.
These instructions contain important safety information regarding the use and maintenance of this
system. Please keep this manual for future reference.
•Every unit has been thoroughly tested and has been shipped in perfect operating condition.
•Check the shipping carton for damage that may have occurred during shipping.
•If the carton appears to be damaged carefully inspect your unit for any damage.
•Be sure all equipment necessary to operate the system has arrived intact.
•In the event that damage has been found or parts are missing, please contact CHAUVET customer
support for further instructions.
•Please do not return the unit to your dealer without first contacting CHAUVET customer support.
Notice!
1) Please insure the power supply has good connect with ground before operating the unit in order
to prevent electrical shock.
2) This system is intended to only be operated indoors. Avoid any direct contact with water, and
make certain the unit is firmly mounted.
3) Ensure the operating temperature is within the specified normal range of 18~300C.
4) Prolonged operation shortens the life of the laser device.
5) Over a long period of time the system may build up dust and other contaminants on the scanner
optics and/or the aperture window.
6) Do not remove any of the laser safety warning labels, manufacturing label, and warranty labels.
If the warranty labels are broken the warranty will be voided.
7) Please contact us if you experience any problems with this unit.
8) NO USER SERVICABLE PARTS INSIDE:
Warranty Void if Warranty Seals are missing or
appear tampered with.
9) Please do not discard the shipping materials. In the event you must return the unit please do so
in the original factory packaging to avoid further damage.
LG-40 User Manual 8 1/10/2007/10:43

COMPLIANCE STATEMENT
Your LG-40 complies with FDA/CDRH 21CFR1040 and Laser Notice 50 as well as IEC 60825-
1:2003. Due to a unique optic design, this product does not exceed output powers that exceed its
classification and output levels government agencies have determined to be appropriate for the
products function.
Laser Safety and Compliance Information
This product is manufactured to comply with the IEC 60825-1 and in accordance with U.S. Food and
Drug Administrations (FDA) Standards listed under FDA Document 21 CFR 1040 and subsequent
laser notices.
Product Classification and Manufacturing Label Identification
Laser Classification Class IIIa
There is only one
laser aperture on
this product.
CAUTION: AVOID EXPOSURE TO BEAM: Avoid
direct eye contact with laser light. Never intentionally
expose your eyes or others to direct laser radiation.
Non-Interlocked Housing Warning Labels. This unit
contains an embedded laser device that exceeds the output
of the intended class internally. Exposure to unsafe levels
of laser radiation when opened.
Additionally there are no user
serviceable parts inside. Tampering
or removing warranty seals will void
your products limited warranty.
CAUTION:
The use of corrective eye wear or
optics for viewing at distances such
as telescopes or binoculars within a
distance of 100mm may pose an eye
hazard.
Laser Medium DPSS YVO4 532nm
Cooling Fan Cooled
Output <20mW
Beam Diameter at aperture 10 – 14mm
Beam Divergence Optically adjusted for compliance
Radiant Exposure at
Aperture <4.95mW (7mm Human Limiting Aperture)
LG-40 User Manual 9 1/10/2007/10:43

Proper Usage
This unit has been designed to be hung. It is recommended that, for safety purposes, your
lighting effect are properly mounted using a suitable hanging clamp and safety cable.
CHAUVET offers a range of items, which are ideal for safe mounting.
It is the responsibility of the manufacturer to provide useful instruction on the proper use of
this product. According to FDA Regulations you should operate the product in the fashion
illustrated below.
CAUTION: Use of controls, adjustments, or performance of
procedures other than what is specified herein may result in
hazardous radiation exposure
CONTROL &FUNCTION
This unit uses dipswitches to assign a units function, DMX address and DMX MODE of function. Each
dipswitch represents a binary value.
Dipswitch Chart
0=OFF 1=ON X=0FF or ON
DIPSWITCH CHART FUNCTION
1 2 3 4 5 6 7 8 9 10
X X X X X X X X 0 1 AUTO MODE, MASTER AUTO
X X X X X X X X 1 1 SOUND-ACTIVE, MASTER SOUND
SET DMX ADDRESS
X X X X X X X X X 0 DMX MODE
Function chart
Dipswitch #10 is used to set the system function.
Dipswitches #1 to #9 are used to set the DMX512 address in DMX MODE.
LG-40 User Manual 10 1/10/2007/10:43

DMX Mode
In this mode you will be able to control each individual trait of the fixture independently. The LG-40
occupies 2 channels of DMX control. For detailed listing of the DMX channel values and laser
patterns refer to the Appendix section.
SETTING THE STARTING ADDRESS
This DMX mode enables the use of a universal DMX controller device. Each fixture requires a "start
address" from 1 to 511. A fixture requiring one or more channels for control begins to read the data
on the channel indicated by the start address. For example, a fixture that occupies or uses 6 channels
of DMX and was addressed to start on DMX channel 100, would read data from channels: 100, 101,
102, 103, 104, and 105. Choose start addresses so that the channels used do not overlap and notate
the start address selected for future reference.
If this is your first time addressing a fixture using the DMX-512 control protocol than I suggest jumping
to the Appendix Section and read the heading “DMX Primer”. It contains very useful information that
will help you understand its use.
Set the start address using the group of DIP switches located usually on bottom of the fixture. Each
dip switch has an associated value. Adding the value of each switch in the ON position will provide
the start address. Determining which switches to toggle ON given a specific start address can be
accomplished in the following manner. By subtracting the largest switch value possible from the
selected start address which does not cause a negative number.
EXAMPLE STARTING ADDRESS
Address 10
10987654321
ON
OFF
1
256 128
64 32 16
8 4 2
DIP
Pin # 4 = 8
Pin # 2 = 2
Total = 10
1211
10987654321
ON
OFF
1
256 128
64 32 16
8 4 2
DIP
Address 24
1211
Pin # 5 = 16
Pin # 4 = 8
Total = 24
Resolving address
using simple math.
Address 233
233 – (128) = 105, Turn ON Dip # 8
105 – (64) = 41, Turn ON Dip # 7
41 – (32) = 9, Turn ON Dip # 6
9 – (8) = 1, Turn ON Dip # 4
1 – (1) = 0, Turn ON Dip # 1
DIP SWITCH (DMX VALUE)
1
2
3
4
5
6
7
8
9
1
2
4
8
16
32
64
128
256
You will most likely use the first
available number which maybe number
1. This number was selected for
example purposes.
LG-40 User Manual 11 1/10/2007/10:43

Operation
Stand-Alone Operation (Sound-Active, Auto Mode):
This mode allows a single unit to run to the beat of the music, or the unit will auto change in Auto
Mode.
1) Set dipswitches position to Sound Active or Auto Mode.
Mode Dipswitches
Sound-Active 9 = On, 10 = On
Auto Mode 9 = Off, 10 = On
2) The unit will react to the low frequencies of music via the internal microphone in Sound Active
mode, or the unit will auto change in Auto Mode.
3) Use the audio sensitivity knob on the back of the unit to make the unit more or less sensitive in
Sound-Active mode. Turning the knob counterclockwise decreases the sensitivity; turning the
knob clockwise increases the sensitivity.
Master-Slave Operation (Master Sound, Master Auto):
This mode will allow you to link up to 32 units together without a controller.
1) Use standard DMX cables to daisy chain your units together via the DMX connector on the rear
of the units. For longer cable runs we suggest a terminator at the last fixture. For more
information about terminators, see page 14.
2) Choose a unit to function as Master mode. Turn dipswitches to the Master position on the unit.
The unit must be the first unit in line. Then simply chain the units together using DMX cable.
Mode Dipswitches
Master Sound 9 = On, 10 = On
Master Auto 9 = Off, 10 = On
3) Turn switch to the Slave position on the slave units, and they will react the same as the Master.
Mode Dipswitches
Slave 1-10 = Off
OUT IN
POWER
1: MASTER 2: SLAVE 3, 4, 5, etc.: SLAVE
OUT IN
Note! System doesn’t use a DMX controller in Master-Slave Mode.
System cannot have two Master units in Master-Slave Mode.
It is recommended that you perform a hard reset after making
changes to the dipswitches. To perform a hard reset: turn off
the power to the fixture, wait 10 seconds, and turn on the
power to the fixture.
LG-40 User Manual 12 1/10/2007/10:43

Universal DMX Control (DMX Mode):
This mode allows you to use a universal DMX-512 controller to control laser operations and effects.
1) To control your fixture in DMX Mode use standard DMX cables to daisy chain your units together
via the DMX connector on the rear of the units. For long cable runs we suggest using a
terminator on the last fixture. For more information about terminators, see page 14.
Mode Dipswitches
DMX mode 1-9 = DMX address, 10 = Off
2) Assign a DMX address to the unit according to the instructions included with your controller. Also
included is a DMX Quick Reference Chart on page 15
OUT IN
POWER
1: MASTER 2: SLAVE 3, 4, 5, etc.: SLAVE
OUT IN
DMX-512
3) Use a DMX controller to control your units.
LG-40 User Manual 13 1/10/2007/10:43

APPENDIX
DMX Primer
There are 512 channels in a DMX-512 connection. Channels may be assigned in any manner. A
fixture capable of receiving DMX 512 will require one or a number of sequential channels. The user
must assign a starting address on the fixture that indicates the first channel reserved in the controller.
There are many different types of DMX controllable fixtures and they all may vary in the total number
of channels required. Choosing a start address should be planned in advance. Channels should
never overlap. If they do, this will result in erratic operation of the fixtures whose starting address is
set incorrectly. You can however, control multiple fixtures of the same type using the same starting
address as long as the intended result is that of unison movement or operation. In other words, the
fixtures will be slaved together and all respond exactly the same.
DMX fixtures are designed to receive data through a serial Daisy Chain. A Daisy Chain connection is
where the DATA OUT of one fixture connects to the DATA IN of the next fixture. The order in which
the fixtures are connected is not important and has no effect on how a controller communicates to
each fixture. Use an order that provides for the easiest and most direct cabling. Connect fixtures
using shielded two conductor twisted pair cable with three pin XLR male to female connectors. The
shield connection is pin 1, while pin 2 is Data Negative (S-) and pin 3 is Data positive (S+). CHAUVET
carries 3-pin XLR DMX compliant cables, DMX-10 (33’), DMX-4.5 (15’) and DMX-1.5 (5’)
FIXTURE LINKING
CO
MM
O
N
DMX
+
DMX
-
INPUT OUTPUT
1
3
2
1
3
2
1
3
2
Resistance 120
ohm 1/4w between
pin 2 (DMX -) and
pin 3 (DMX +) of
the last fixture.
Termination reduces signal errors and to
avoid signal transmission problems and
interference, it is always advisable to connect
a DMX signal terminator.
Figure 2 - DMX connector configuration
Note! If you use a controller with a 5 pin DMX output connector, you will need to use a 5
pin to 3 pin adapter. CHAUVET Model No: DMX5M.
The chart below details a proper cable conversion:
3PIN TO 5PIN CONVERSION CHART
CONDUCTOR 3 Pin Female (output) 5 Pin Male (Input)
GROUND/SHIELD Pin 1 Pin 1
DATA (-)SIGNAL Pin 2 Pin 2
DATA (+)SIGNAL Pin 3 Pin 3
DO NOT USE Do not use
DO NOT USE Do not use
LG-40 User Manual 14 1/10/2007/10:43

DMX Quick Reference Chart
DMX Address Quick Reference Chart
Dip Switch Position
DMX DIP SWITCH
SET #9 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1
0=OFF #8 0 0 0 0 1 1 1 1 0 0 0 0 1 1 1 1
1=ON #7 0 0 1 1 0 0 1 1 0 0 1 1 0 0 1 1
X=OFF or ON #6 0 1 0 1 0 1 0 1 0 1 01 0 1 0 1
#1 #2 #3 #4 #5
0 0 0 0 0 32 64 96 128 160 192 224 256 288 320 352 384 416 448 480
1 0 0 0 0 1 33 65 97 129 161 193 225 257 289 321 353 385 417 449 481
0 1 0 0 0 2 34 66 98 130 162 194 226 258 290 322 354 386 418 450 482
1 1 0 0 0 3 35 67 99 131 163 195 227 259 291 323 355 387 419 451 483
0 0 1 0 0 4 36 68 100 132 164 196 228 260 292 324 356 388 420 452 484
1 0 1 0 0 5 37 69 101 133 165 197 229 261 293 325 357 389 421 453 485
0 1 1 0 0 6 38 70 102 134 166 198 230 262 294 326 358 390 422 454 486
1 1 1 0 0 7 39 71 103 135 167 199 231 263 295 327 359 391 423 455 487
0 0 0 1 0 8 40 72 104 136 168 200 232 264 296 328 360 392 424 456 488
1 0 0 1 0 9 41 73 105 137 169 201 233 265 297 329 361 393 425 457 489
0 1 0 1 0 10 42 74 106 138 170 202 234 266 298 330 362 394 426 458 490
1 1 0 1 0 11 43 75 107 139 171 203 235 267 299 331 363 395 427 459 491
0 0 1 1 0 12 44 76 108 140 172 204 236 268 300 332 364 396 428 460 492
1 0 1 1 0 13 45 77 109 141 173 205 237 269 301 333 365 397 429 461 493
0 1 1 1 0 14 46 78 110 142 174 206 238 270 302 334 366 398 430 462 494
1 1 1 1 0 15 47 79 111 143 175 207 239 271 303 335 367 399 431 463 495
0 0 0 0 1 16 48 80 112 144 176 208 240 272 304 336 368 400 432 464 496
1 0 0 0 1 17 49 81 113 145 177 209 241 273 305 337 369 401 433 465 497
0 1 0 0 1 18 50 82 114 146 178 210 242 274 306 338 370 402 434 466 498
1 1 0 0 1 19 51 83 115 147 179 211 243 275 307 339 371 403 435 467 499
0 0 1 0 1 20 52 84 116 148 180 212 244 276 308 340 372 404 436 468 500
1 0 1 0 1 21 53 85 117 149 181 213 245 277 309 341 373 405 437 469 501
0 1 1 0 1 22 54 86 118 150 182 214 246 278 310 342 374 406 438 470 502
1 1 1 0 1 23 55 87 119 151 183 215 247 279 311 343 375 407 439 471 503
0 0 0 1 1 24 56 88 120 152 184 216 248 280 312 344 376 408 440 472 504
1 0 0 1 1 25 57 89 121 153 185 217 249 281 313 345 377 409 441 473 505
0 1 0 1 1 26 58 90 122 154 186 218 250 282 314 346 378 410 442 474 506
1 1 0 1 1 27 59 91 123 155 187 219 251 283 315 347 379 411 443 475 507
0 0 1 1 1 28 60 92 124 156 188 220 252 284 316 348 380 412 444 476 508
1 0 1 1 1 29 61 93 125 157 189 221 253 285 317 349 381 413 445 477 509
0 1 1 1 1 30 62 94 126 158 190 222 254 286 318 350 382 414 446 478 510
1 1 1 1 1 31 63 95 127 159 191 223 255 287 319 351 383 415 447 479 511
Dip Switch Position DMX Address
LG-40 User Manual 15 1/10/2007/10:43

DMX Channel Values
Channel Value Function
1
000 Ù031
032 Ù067
068 Ù103
104 Ù139
140 Ù175
176 Ù201
202 Ù240
241 Ù255
Mode
Laser off
Clockwise scanning
Counter-clockwise scanning
Beam shake
Strobing
Single beam
Auto mode
Sound-active mode
2 Speed Control
Slow to fast000 Ù255
CAUTION: Use of controls, adjustments, or performance of procedures other
than what is specified herein may result in hazardous radiation exposure
Troubleshooting
1) If the power supply indicator does not light up and the laser does not work, please check if the power
supply and the corresponding parts have the right input electric current.
2) If it is in stand-alone mode operation, the power supply indicator is lit and the laser is not working,
please check if the operation system is set up in Master/Slave mode.
3) If it is in Master/Slave mode, Slave mode is not working, please check as below:
A. Make sure to set up Master mode for just one unit and all the others are set in slave mode.
B. Make sure to control the unit with a DMX controller.
C. Make sure to use a good quality power cord and connection.
4) If the unit is in DMX mode, the laser cannot be controlled by the DMX controller, and the DMX signal
Indicator is not illuminated, please check the following:
A. Make sure to set up the DMX mode.
B. Make sure the DMX cable has a good connection.
5) If it is in DMX mode and the laser cannot be controlled by the DMX controller, but the DMX signal
indicator flashes, please make sure the DMX controller and the laser have the same DMX Address.
6) If no laser outputs from the projector please restart the AC power by turning off the AC switch and
leaving off for 15 seconds and then turning the switch back to the on position.
If you still have a problem after trying the above solutions, please contact CHAUVET Technical
Support at [phone].
LG-40 User Manual 16 1/10/2007/10:43

General Maintenance
To maintain optimum performance and minimize wear fixtures should be cleaned frequently. Usage
and environment are contributing factors in determining frequency. As a general rule, fixtures should
be cleaned at least twice a month. Dust build up reduces light output performance and can cause
overheating. This can lead to reduced lamp life and increased mechanical wear. Be sure to power off
fixture before conducting maintenance.
Unplug fixture from power. Use a vacuum or air compressor and a soft brush to remove dust
collected on external vents and internal components. Clean all glass when the fixture is cold with a
mild solution of glass cleaner or Isopropyl Alcohol and a soft lint free cotton cloth or lens tissue. Apply
solution to the cloth or tissue and drag dirt and grime to the outside of the lens. Gently polish optical
surfaces until they are free of haze and lint.
The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to
optimize light output. Cleaning frequency depends on the environment in which the fixture operates:
damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s
optics. Clean with soft cloth using normal glass cleaning fluid. - Always dry the parts carefully. - Clean
the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.
Returns Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Merchandise Authorization Number (RA #). Products
returned without an RA # will be refused. Call CHAUVET and request RA # prior to shipping the
fixture. Be prepared to provide the model number, serial number and a brief description of the cause
for the return. Be sure to properly pack fixture, any shipping damage resulting from inadequate
packaging is the customer’s responsibility. CHAUVET reserves the right to use its own discretion to
repair or replace product(s). As a suggestion, proper UPS packing or double-boxing is always a safe
method to use.
Claims
Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise. It is the customer's responsibility to notify and
submit claims with the shipper in the event that a fixture is damaged due to shipping. Any other claim
for items such as missing component/part, damage not related to shipping, and concealed damage,
must be made within seven (7) days of receiving merchandise.
LG-40 User Manual 17 1/10/2007/10:43

Technical Specifications
WEIGHT & DIMENSIONS
Length.................................................................................................................................152 mm (6 in)
Width ............................................................................................................................... 279 mm (11 in)
Height.............................................................................................................................. 355 mm (14 in)
Weight ..............................................................................................................................3.18 Kg (7 lbs)
POWER
Switch-selectable power settings..............................................................120V 60Hz AC or 230V 50Hz
Fuse............................................................................................................................................2A 250V
Power Consumption..................................................................................................................30W Max
Inrush Power .................................................................................................................................... 15W
Power Output (AC Plug)..........................................................................................240W Max per array
LASER
Diode ................................................................................................................... 1 x 10mW green laser
Wavelength...................................................................................................................................532 nm
Part No ............................................................................................................................... 10mW Green
Laser Type......................................................................................................................................DPSS
Laser Output................................................................................................................................<20mW
Cooling ..................................................................................................................................Fan Cooled
CONTROL & PROGRAMMING
Data input................................................................................................locking 3-pin XLR male socket
Data output...........................................................................................locking 3-pin XLR female socket
Data pin configuration ..............................................................................pin 1 shield, pin 2 (-), pin 3 (+)
Protocols........................................................................................................................DMX-512 USITT
DMX Channels .......................................................................................................................................2
ORDERING INFORMATION
Scorpion Array................................................................................................................................LG-40
Centerpiece Hardware Mounting Kit for Laser Array (Holds 8 pieces) ...................................LAB-40CT
Vertical Hardware mounting kit for laser array .........................................................................LAB-40V
Technical Support
Address: Service Dept.
3000 N 29th Ct, Hollywood, FL 33020 (U.S.A.)
Support (Email): [email protected]
Telephone: [phone] - (Press 4)
Fax: [phone] - (Attention: Service)
Website: http://www.chauvetlighting.com
LG-40 User Manual 18 1/10/2007/10:43

NLDJ10G-FB-4LL
4 units vertical style vertical array
1. What is included
2.Assemblying steps
