Chauvet Vue III Manual

DMX Channel Values
CHANNEL VALUE FUNCTION
1
000 Ù199
200 Ù249
250 Ù255
Control/Operating Mode
Auto programs speed (all clusters)
Sound-active mode (for clusters in auto mode)
Stand-alone mode (for clusters in auto mode)
2
000 Ù031
032 Ù063
064 Ù095
096 Ù127
128 Ù131
132 Ù255
Cluster 1
No function
Auto mode 1
Auto mode 2
Auto mode 3
No function
Static colors (see “Static Colors” table below)
3
000 Ù031
032 Ù063
064 Ù095
096 Ù127
128 Ù131
132 Ù255
Cluster 2
No function
Auto mode 1
Auto mode 2
Auto mode 3
No function
Static colors (see “Static Colors” table below)
4
000 Ù031
032 Ù063
064 Ù095
096 Ù127
128 Ù131
132 Ù255
Cluster 3
No function
Auto mode 1
Auto mode 2
Auto mode 3
No function
Static colors (see “Static Colors” table below)
5
000 Ù031
032 Ù063
064 Ù095
096 Ù127
128 Ù131
132 Ù255
Cluster 4
No function
Auto mode 1
Auto mode 2
Auto mode 3
No function
Static colors (see “Static Colors” table below)
6
000 Ù031
032 Ù063
064 Ù095
096 Ù127
128 Ù131
132 Ù255
Cluster 5
No function
Auto mode 1
Auto mode 2
Auto mode 3
No function
Static colors (see “Static Colors” table below)
7
000 Ù031
032 Ù063
064 Ù095
096 Ù127
128 Ù131
132 Ù255
Cluster 6
No function
Auto mode 1
Auto mode 2
Auto mode 3
No function
Static colors (see “Static Colors” table below)
8
000 Ù031
032 Ù063
064 Ù095
096 Ù127
128 Ù131
132 Ù255
Cluster 7
No function
Auto mode 1
Auto mode 2
Auto mode 3
No function
Static colors (see “Static Colors” table below)
9
000 Ù009
010 Ù209
210 Ù255
Strobe
No strobe
Fast > Slow (for clusters set to static colors )
Sound-active mode (for clusters set to static colors )
Vue™ III User Manual 11 2006-12-13/15:11

LED Cluster Values
VALUE STATIC COLORS (SEE BELOW FOR LED DIAGRAM)
132 Ù135
136 Ù139
140 Ù143
144 Ù147
148 Ù151
152 Ù155
156 Ù159
160 Ù163
164 Ù167
168 Ù171
172 Ù175
176 Ù179
180 Ù183
184 Ù187
188 Ù191
192 Ù195
196 Ù199
200 Ù203
204 Ù207
208 Ù211
212 Ù215
216 Ù219
220 Ù223
224 Ù227
228 Ù231
232 Ù235
236 Ù239
240 Ù243
244 Ù247
248 Ù251
252 Ù255
Red 1
Green 1
Red 1, Green 1
Red 2
Red 1, Red 2
Red 2, Green 1
Red 1, Green 1, Red 2
Blue 1
Red 1, Blue 1
Green 1, Blue 1
Red 1, Green 1, Blue 1
Red 2, Blue 1
Red 1, Red 2, Blue 1
Green 1, Red 2, Blue 1
Red 1, Green 1, Red 2, Blue 1
Red 3
Red 1, Red 3
Green 1, Red 3
Red 1, Green 1, Red 3
Red 2, Red 3
Red 1, Red 2, Red 3
Green 1, Red 2, Red 3
Red 1, Green 1, Red 2, Red 3
Blue 1, Red 3
Red 1, Blue 1, Red 3
Green 1, Blue 1, Red 3
Red 1, Green 1, Blue 1, Red 3
Red 2, Blue 1, Red 3
Red 1, Red 2, Blue 1, Red 3
Green 1, Red 2, Blue 1, Red 3
Red 1, Green 1, Red 2, Blue 1, Red 3
Red 1
Green 1
Red 2
Blue 1
Red 3
LED Cluster Diagram
Vue™ III User Manual 12 2006-12-13/15:11
