1. BEFORE YOU BEGIN
What is included
¾2 x PAR56CUL™
¾2 x MFL 300W Lamps
¾2 x CH-05 Safety Cables
¾2 x CLP-03 Hanging Clamps
¾2 x CH GEL
¾Warranty Card
¾User Manual
Unpacking Instructions
Immediately upon receiving a fixture, carefully unpack the carton, check the contents to ensure that
all parts are present, and have been received in good condition. Notify the shipper immediately and
retain packing material for inspection if any parts appear damaged from shipping or the carton itself
shows signs of mishandling. Save the carton and all packing materials. In the event that a fixture
must be returned to the factory, it is important that the fixture be returned in the original factory box
and packing.
AC Power
To determine the power requirements for a particular fixture, see the label affixed to the back plate of
the fixture or refer to the fixture’s specifications chart. A fixture’s listed current rating is its average
current draw under normal conditions. Before applying power to a fixture, check that the source
voltage matches the fixture’s requirement.
Warning! Verify that the lamp’s rated voltage matches the line voltage applied. All fixtures
must be connected to circuits with a suitable Earth Ground.
Contact Us
World Wide
General Information Chauvet Lighting
3000 North 29th Court
Hollywood, FL 33020
voice: 954.929.1115
fax: [phone]
toll free: 800.762.1084
Technical Support Chauvet Lighting
3000 North 29th Court
Hollywood, FL 33020
voice: 954.929.1115 (Press 4)
fax: [phone] (Attention: Service)
World Wide Web www.chauvetlighting.com
PK Par56C User Manual 3 2006-12-08/12:16

Safety Instructions
Please read these instructions carefully, which includes important
information about the installation, usage and maintenance of this
product.
xPlease keep this User Guide for future consultation. If you sell the unit to another user, be sure that
they also receive this instruction booklet.
xAlways make sure that you are connecting to the proper voltage, and that the line voltage you are
connecting to is not higher than that stated on the decal or rear panel of the fixture.
xThis product is intended for indoor use only!
xTo prevent risk of fire or shock, do not expose fixture to rain or moisture. Make sure there are no
flammable materials close to the unit while operating.
xThe unit must be installed in a location with adequate ventilation, at least 20in (50cm) from adjacent
surfaces. Be sure that no ventilation slots are blocked.
xAlways disconnect from power source before servicing or replacing lamp or fuse and be sure to
replace with same lamp source.
xSecure fixture to fastening device using a safety chain. Never carry the fixture solely by its head. Use
its carrying handles.
xMaximum ambient temperature (Ta) is 95°F (35°C). Do not operate fixture at temperatures higher
than this.
xIn the event of a serious operating problem, stop using the unit immediately. Never try to repair the
unit by yourself. Repairs carried out by unskilled people can lead to damage or malfunction. Please
contact the nearest authorized technical assistance center. Always use the same type spare parts.
xMake sure the power cord is never crimped or damaged.
xNever disconnect the power cord by pulling or tugging on the cord.
xAvoid direct eye exposure to the lamp while it is on.
Caution! There are no user serviceable parts inside the unit. Do not open the housing or
attempt any repairs yourself. In the unlikely event your unit may require service,
please contact CHAUVET at: 954-929-1115.
PK Par56C User Manual 4 2006-12-08/12:16

2. INTRODUCTION
Features
xPolished parcan system
xReady to go
xIncludes:
2 x PAR56CUL parcans
2 x MFL 300W lamps
2 x CH-05 safety cables
2 x CLP-03 clamps
2 x CH GEL
x1 year limited warranty
Note: These fixtures can operate at 230V with optional 230V lamps. If you wish to run this fixture at
230V, you must purchase a compatible 230V lamp from your Chauvet dealer.
Product Overview
Lamp Access
Thumbscrew
Tilt
Adjustment
Knob
Hanging
Bracket
Gel Frame
Clamp
Octagonal
Gel Frame
PK Par56C User Manual 5 2006-12-08/12:16

3. SETUP
Lamp
You will need to install a lamp prior to the initial operation of the fixture. A 300W lamp is included. Up
to a 500W lamp may be used in this fixture. See page 8 for a list of compatible lamps which you can
order from any Chauvet dealer.
Warning! When replacing the lamp, please wait 15 minutes after powering down to allow the
unit to cool down! Always disconnect from main power prior to lamp replacement.
Do not touch the envelope (glass area) of the bulb with bare hands. If this happens, clean the lamp
with alcohol and wipe it with a lint free cloth before installation.
Lamp Replacement
Included Hanging Clamp
Lamp Access
Thumbscrew
1) Pull the thumbscrew directly out with one hand until it
stops.
2) With your other hand, pull the back of the fixture away
from the thumbscrew.
3) Squeeze the retaining spring together and remove it.
4) Remove the lamp socket from the lamp by pulling it
away from the lamp.
5) Remove the lamp from the fixture.
6) Install a new lamp.
7) Replace the retaining spring.
8) Replace the lamp socket.
9) Replace the top cover.
Mounting
ORIENTATION
This fixture may be mounted in any position provided there is adequate room for ventilation.
RIGGING
It is important never to obstruct the fan or vents pathway. Mount the
fixture using, a suitable “C” or “O” type clamp. Adjust the angle of the
fixture by loosening both knobs and tilting the fixture. After finding the
desired position, retighten both knobs.
xWhen selecting installation location, take into consideration lamp
replacement access and routine maintenance.
xSafety cables should always be used.
xNever mount in places where the fixture will be exposed to rain, high humidity, extreme temperature
changes or restricted ventilation.
PK Par56C User Manual 6 2006-12-08/12:16

4. APPENDIX
General Maintenance
To maintain optimum performance and minimize wear fixtures should be cleaned frequently. Usage
and environment are contributing factors in determining frequency. As a general rule, fixtures should
be cleaned at least twice a month. Dust build up reduces light output performance and can cause
overheating. This can lead to reduced lamp life and increased mechanical wear. Be sure to power off
fixture before conducting maintenance.
Unplug fixture from power. Use a vacuum or air compressor and a soft brush to remove dust
collected on external vents and internal components. Clean all glass when the fixture is cold with a
mild solution of glass cleaner or Isopropyl Alcohol and a soft lint free cotton cloth or lens tissue. Apply
solution to the cloth or tissue and drag dirt and grime to the outside of the lens. Gently polish optical
surfaces until they are free of haze and lint.
The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to
optimize light output. Cleaning frequency depends on the environment in which the fixture operates:
damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s
optics. Clean with soft cloth using normal glass cleaning fluid. - Always dry the parts carefully. - Clean
the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.
Troubleshooting
Lamp is dim, or burns out immediately.
1) Check to make sure that you have installed the correct voltage bulb. If a 220V bulb is plugged
into 110V, the bulb will be very dim. If a 110V bulb is plugged into 220V, the bulb will overheat
and burn out immediately.
Lamp won’t turn on.
1) Check to make sure the lamp socket is plugged into the lamp.
2) Check to make sure the fixture is plugged into an active power circuit.
If you still have a problem after trying the above solutions, please contact CHAUVET Technical
Support at the location below.
Technical Support
Address: Service Dept.
3000 N 29th Ct, Hollywood, FL 33020 (U.S.A.)
Support (Email): [email protected]
Telephone: [phone] - (Press 4)
Fax: [phone] - (Attention: Service)
Website: http://www.chauvetlighting.com
PK Par56C User Manual 7 2006-12-08/12:16

Returns Procedure
Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued.
Package must be clearly labeled with a Return Merchandise Authorization Number (RA #). Products
returned without an RA # will be refused. Call CHAUVET and request RA # prior to shipping the
fixture. Be prepared to provide the model number, serial number and a brief description of the cause
for the return. Be sure to properly pack fixture, any shipping damage resulting from inadequate
packaging is the customer’s responsibility. CHAUVET reserves the right to use its own discretion to
repair or replace product(s). As a suggestion, proper UPS packing or double-boxing is always a safe
method to use.
Note: If you are given an RA #, please include the following information on a piece of paper
inside the box:
1) Your name
2) Your address
3) Your phone number
4) The RA #
5) A brief description of the symptoms
Claims
Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be
reported to the carrier upon receipt of merchandise. It is the customer's responsibility to notify and
submit claims with the shipper in the event that a fixture is damaged due to shipping. Any other claim
for items such as missing component/part, damage not related to shipping, and concealed damage,
must be made within seven (7) days of receiving merchandise.
Technical Specifications
WEIGHT & DIMENSIONS
Length........................................................................................................................... 14.5 in (368 mm)
Width ............................................................................................................................... 10 in (254 mm)
Height .............................................................................................................................. 10 in (254 mm)
Weight ...............................................................................................................................4 lbs (1.82 kg)
POWER
Voltage .......................................................................120V 60Hz AC or 230V 50Hz (depends on lamp)
Power Consumption ........................................................................... 300W at 120V with included lamp
ORDERING INFORMATION
PK Par56C............................................................................................................................PK PAR56C
APPROVED LAMPS
300W Narrow Spot ....................................................................................................US-300PAR56NSP
300W Medium Flood .................................................................................................US-300PAR56MFL
300W Wide Flood..................................................................................................... US-300PAR56WFL
500W Medium Flood .................................................................................................US-500PAR56MFL
