Heat Detectors
Series 600
The Series 600 Heat Detector is attractive, durable and
features combination rate-of-rise and fixed temperature
operation. Heat detectors are available in 135°F and 200°F
temperatureratings.
Rate-of-rise detects heat by quickly responding to a rapid
temperature increase. Rate-of-rise units have a wide spacing
allowance of 50-foot centers. See specification table for
details.
Fixed temperature reacts to heat by responding to a specific
temperature setting.
Series 600 Detectors use the same reliable pneumatic rate-of-
rise element of former models, but offer added aesthetic
appeal.
The pneumatic rate-of-rise element responds to a rapid rise in
temperature, approximately 15°F. (8°C) per minute, by
expansion of air within the sealed chamber faster than it can
escape through a calibrated vent. The resultant increase in
pressure depresses the diaphragm, causing the electrical
contact to close the circuit.
The fixed temperature element uses a fusible alloy. When
activated, the external heat collector drops away to provide
quick visual confirmation that the element has operated.
The units protrude only 1-3/8 inch from the ceiling surface with
a junction box mounting. They have pleasing contours and an
all-white finish that conforms to ceiling aesthetics.
Installation
Each detector includes a patented reversible mounting plate.
In one position, it easily attaches to 3.25" or 4" octagonal box,
or plaster ring.
In reverse, the plate can be used for open wiring without a
junction box. A1/4" space between detector and mounting
surface allows for wire connections. All mounting screws are
concealed.
The detector attaches easily to the mounting plate with a push
and twist motion. No tools are required.
Effective November, 2001
All rights reserved (11/01).
The Heat Detectors Series 600 are supplied
with the following standard features:
• Rate-of-Rise and Fixed Temperature
• One or Two-Circuit, Normally Open
• Easy Installation
• Low Profile
• Visual Indication
• Operation Testing
Description
Mounting plate is molded of white self-extinguishing thermo-
plastic rated at 221°F (105°C). The plate is extremely strong
yet adapts to uneven mounting surfaces.
Series 600 Testing Methods
Models 601/621 and 602/622 can be tested by the quick
application of heat from any convenient source. A portable hair
dryer is recommended. However, do not apply heat that
exceeds the fixed temperature rating of the detector.
Models 603/623 and 604/624 cannot be tested. However, the
fusible alloy element used is considered so reliable that testing
is not necessary.
3-1/4" or 4"
Octagonal Box

Important Special Notes
Application: Heat detectors should be used for property
protection. Reliance should not be placed on heat detectors for
LifeSafety.
CAUTION: When life safety is involved, smoke detectors
MUST also be sed. Detectors m st not be painted.
Battery Back-Up: Heat detectors should be electronically
supervised with battery back-up at the panel.
The rate-of-rise mechanism may be subject to reduced
sensitivity over time.Annual testing of the rate-of-rise mecha-
nism is recommended.
Electrical Ratings
6-125 Volts A.C., 3.0 Amps.
6-28 Volts D.C., 1.0 Amps.
125 Volts D.C., 0.3 Amps.
250 Volts D.C., 0.1 Amps.
Listings/Approvals
• Listed by Underwriters Laboratories (UL)
• Factory Mutual Approved (FM)
• California State Fire Marshal Approval (CSFM)
• City of New York (MEA) Listing No. 188-94-E
• Listed by Underwriters’ Laboratories of Canada (ULC)
Effective: November, 2001
Screw Terminals
Model 601 and 621
No Marking
Model 601 (1 circuit)
Model 621 (dua circuit)
Rate-of-Rise and Fixed
Temperature, 135°F (57°C)
Applications: Normal
temperature fluctuations
and ceiling temperatures
not exceeding 100°F (38°C)
Maximum Spacing
Allowance* -
50 x 50 ft. - UL
30 x 30 ft. - FM
Model 602 and 622
Gray Ring
Model 602 (1 circuit)
Model 622 (dual circuit)
Rate-of-Rise and Fixed
Temperature, 200°F (94°C)
Applications: Normal tempe-
rature fluctuations and ceiling
temperatures exceeding 100°F
(38°C) but not 150°F (66°C)
Maximum Spacing
Allowance* -
50 x 50 ft. - UL
30 x 30 ft. - FM
Model 603 and 623
Gray Spot
Model 603 (1 circuit)
Model 623 (dual circuit)
Fixed Temperature only,
135°F (57°C)
Applications: Unusually violent
temperature fluctuations
and ceiling temperatures
not exceeding 100°F (38°C)
Maximum Spacing
Allowance* -
25 x 25 ft. - UL
20 x20 ft. - FM
Model 604 and 624
Gray Ring and Dot
Model 604 (1 circuit)
Model 624 (dual circuit)
Fixed Temperature only,
200°F (94°C)
Applications: Unusually violent
temperature fluctuations and
ceiling temperatures exceeding
100°F (38°C) but not 150°F (66°C)
Maximum Spacing
Allowance* -
15 x 15 ft. - UL
*Refer to National Fire Alarm Code Standard NFPA 72 for application requirements
All rights reserved (11/01).
This literature is provided for informational purposes only. CHEMETRONICS assumes no responsibility for the product’s suitability for a
particular application. The product must be properly applied to work correctly. If you need more information on this product, or if you have a
particular problem or question, contact CHEMETRONICS, Ashland, MA; Telephone [phone].
