Red Smoke Alarms R10RF User manual

Specifications: Features:
SMOKE ALARM R10RF
Photoelectric Smoke Alarm with 10 Year Lithium Battery & Wireless Connection
PLEASE NOTE: READ ALL INSTRUCTIONS BEFORE INSTALLATION. NO USER SERVICEABLE PARTS INSIDE THIS SMOKEALARM.
Main Power Source
Sensing Type
Sensitivity to smoke
Operation Current
Temperature Range
Humidity Range
Interconnecting
RF Range
Pairing duration
Sound Level
Alarm Condition
Visual Indicators
Approval
• DC operated photoelectric type smoke alarm
• Photoelectric sensor for slow smouldering fires
• Wireless Interconnection
• Insect proof
• Test & Hush button
• Environmentally friendly non-radioactive
technology High and stable sensitivity
• Quick fix mounting bracket for easy installation
• Fitting and battery tamper-resist feature LED
operation indicator
• Extra loud alarm sound over 85 dB
• Low-battery and battery missing warning
indicators
• Auto reset when smoke clears
lithium 10 Year 3V Sealed-Battery
Type A Photoelectric smoke alarm
- contains NO radioactive material
0.08-0.2db/m
<20mA operation (In Alarm)
0 °C to 45 °C
0% to 95% RH
40 alarms for wireless interconnection
100 m free air
30 m indoors (line of sight)
2 min (recount after each success pairing)
85 dB at three metres minimum
Audible signal pattern (ISO 8201)
Red LED for warning and low battery indication
AS 3786:2014, Activefire
Locating and Positioning of Smoke Alarms:
Installation of Smoke Alarms:
1. From back of the smoke alarm, remove the mounting plate by
turning it counterclockwise. (To later engage tamper-resist feature,
twist out and set aside one of the pins moulded into plate. Both pins
are exactly the same).
2. Position smoke alarm to mounting plate and turn clockwise to lock
into place. To engage tamper-resist feature, insert pin into notch and
edge of smoke alarm after alarm is properly positioned in base.
3. Push test button to test smoke alarm.
WARNING: Incorrect orientation will result in a decrease in
operational effectiveness.
This smoke alarm is a single station photoelectric alarm and should NOT be connected to other smoke alarms.
If your dwelling is on a single storey, for minimum protection you should fit an alarm in the hallway between the
living areas (incl. Kitchens) and sleeping areas. Place it as near to the living areas as possible and ensure the alarm
is audible when the bedrooms are occupied.
If your dwelling is multi-storey, for minimum protection one alarm should be fitted at the bottom of the staircase
with further alarms fitted on each upstairs landing. This includes basements but excludes crawl spaces and
unfinished attics.
NOTE: For maximum protection an alarm should be fitted in every room (except kitchen, bathroom and garage).
DO NOT FIT AN ALARM IN THE KITCHEN or BATHROOM, as cooking fumes or steam may trigger the alarm.
DO NOT FIT ALARM IN A GARAGE, as exhaust fumes are likely to set it off.
Ceiling Mounting
As hot smoke rises and spread out, it is advisable to mount on a ceiling in a central position. Avoid areas where
there is no air circulation. E.g. Corners of rooms and keep away from items which may prevent the free flow of air.
Place the unit at least 300mm from and light fitting or decorative object which might obstruct smoke / heat
entering the alarm. Keep at least 300mm away from walls. See Figure 3i.
Wall Mounting
Do not mount tight into the corners. Put the top edge of your smoke alarm between 150 and 300mm below the
ceiling. Keep at least 300mm from room corners. See Figure 3i
On a Sloping Ceiling
In areas with sloping or peaked ceilings install your Smoke Alarm 900mm from the highest point measured
horizontally because “dead air” at the apex may prevent smoke from reaching the unit. See Figure 3ii.
MULTI-STOREY RESIDENCE
HALL BED
ROOM
BED
ROOM
KITCHEN
BASEMENT
LIVING
ROOM
CEILING / WALL JUNCTION
CEILING
ACCEPTABLE HERE
BEST
HERE NEVER
HERE
HEAT &
SMOKE
FROM
FIRE
DEAD AIR
SPACE
SIDE WALL
300mm min
300mm min
600mm min
APEX OF
SLOPING
CEILING
HEAT & SMOKE
FROM FIRE
DEAD
AIR SPACE
1500mm max
500mm min
500mm min
BEST
HERE
BEST
HERE
Smoke alarms for minimum protection.
Smoke alarms for additional protection.
Smoke alarms with hush features
recommended for additional
protection
SINGLE-STOREY RESIDENCE, APARTMENT, MOBILE HOME
BEDROOMBEDROOM
BEDROOM W/C
KITCHEN DINING
BATH
LOUNGE ROOM
IMPORTANT: This manual contains important information about the installation and operation of your smoke alarm. Please read carefully before installation
and keep for future reference. Please ensure that this leaflet remains in the household where the alarm is installed.
WARNING: This smoke alarm is designed to alert you to the presence of smoke. It cannot prevent a fire. There are hazards against which smoke alarms may
not be effective such as smoking in bed, explosions, etc. The ultimate responsibility for fire protection rests with you. This responsibility includes escape
planning, safety checks and an effective warning system. In case of fire, a well-placed, properly looked after smoke alarm may provide a few seconds so that
you can escape and call the fire brigade.
IMPORTANT SAFETY INFORMATION
1. The battery must be operational to operate the alarm
correctly. To test the battery press the test button on this
smoke alarm.
2. The test button accurately tests all smoke alarm
functions. DO NOT use any other test method.
3. DO NOT remove or disconnect battery to silence
unwanted alarms. This will remove your protection. Press
hush button or open windows to ventilate the smoke
alarm to silence it.
4. This smoke alarm is designed to be used inside a single
unit dwelling only. In buildings with several dwellings,
each individual living unit should have its own smoke
alarms. DO NOT install in non-residential buildings.
5. Install a smoke alarm in every room and on every level
of the home.
6. Smoke alarms can only sound their alarms when they
detect smoke. Smoke alarms detect combustion particles
in the air. They do not sense heat, flame or gas. This
smoke alarm is designed to give an audible warning of a
developing fire. However, many fires are fast burning,
explosive or intentional. Others are caused by careless-
ness or safety hazards. Smoke may not reach the smoke
alarm quickly enough to ensure safe escape.
7. Smoke alarms have limitations. This smoke alarm is
not foolproof and is not warranted to protect lives or
property from fire. Smoke alarms are not a substitute for
insurance. Homeowners and renters should insure their
lives and property. In addition, it is possible for the smoke
alarm to fail at any time. For this reason, you must test
the smoke alarm weekly and replace every 10 years.
Turn clockwise
to install
Turn counterclockwise
to uninstall
Monuting Plate
Alarm Unit
Wireless Connection Setup Guide:
1. Complete installation and turn on the mains power supply.
2. Select one of wireless bases as the MASTER unit. Place the MASTER label near the wireless pairing button.
Treat all other units as BRANCH units.
3. On the MASTER wireless base, by hand, press and hold the wireless pairing button for 5 seconds. The unit is
now in self-learn pairing mode indicated by the LED remaining on for 30 seconds.
NOTE: To exit self-learn pairing mode, press the wireless pairing button one time. The Red LED will turn off.
4. While the MASTER unit’s LED is on, press the wireless pairing button 2 times quickly (within a second) on
the BRANCH wireless base. The Subordinate unit’s LED will flash 5 times indicating successful interconnec-
tion.
NOTE: If the BRANCH units does not flash its LED 5 times but stays ON, the wireless interconnection has
failed. In this case, check the range or reduce the distance between units and make sure the MASTER unit’s
LED remains ON while operating the BRANCH unit.
5. Repeat step 4 on all other BRANCH units.
6. After all units has been paired. Press Test button and hold MASTER unit’s Test button for 2 seconds to do
the Test/Hush function.
7. Press and hold MASTER unit’s wireless Pairing button for more than 8 seconds. Check all other wireless
interconnected unit receive the RF signal and alarm sounds.
SMOKE ALARMS
INSTALLATION INSTRUCTIONS

Hush or Silence Feature
• This smoke alarm has a built-in Hush or Silence feature incorporated into
the Test/Hush button.
• If cooking or other non-hazardous sources cause the alarm to sound, it can
be temporarily silenced by pressing the Test/Hush button for 3 seconds.
• The alarm then enters a dormant period for 10 minutes. The red LED will
flash every 10 seconds to indicate the sensitivity is reduced.
• After the 10 minute dormant period, the alarm will give two short beeps, and
the alarm will resume normal operation.
NOTE: After the Test/Hush button has been pressed, wait 10 minutes before
any additional testing is conducted to avoid any abnormal responses as the
smoke alarm is not sensitive to smoke during this period.
NOTE: If a nuisance alarm occurs and if there is no sign of smoke, heat or
noise to suggest a fire you should get your family to a safe place before
investigating. Check the household carefully in case there is a small fire
smouldering out of sight, or if there is another source of smoke or fumes such
as cooking fumes being drawn past a smoke alarm by an extractor.
WARNING: If there are frequent nuisance alarms it may be necessary to
re-locate the device away from the source of the fumes. If the alarm continues
sounding nuisance alarms without smoke or heat being present; It may
require some maintenance or cleaning
THIS PRODUCT IS A SEALED UNIT AND CANNOT BE REPAIRED –
IF THE UNIT IS TAMPERED WITH IT WILL INVALIDATE THE
WARRANTY. IF THE UNIT IS FAULTY PLEASE RETURN IT TO
YOUR ORIGINAL SUPPLIER WITH YOUR PROOF OF PURCHASE.
Maintenance:
The smoke alarm is virtually maintenance free. However, under dusty or greasy
conditions, a vacuum cleanermay be used to clean the exterior of unit (including
slots on cover). Normally, the alarm can be operated up to 10 years without
replacement. See the replacing date on the bottom of the alarm unit.
DO NOT IMMERSE IN OR SPRAY WITH HOUSEHOLD CLEANERS.
If the unit gives a chirping sound every 60secthe battery may need to be replaced.
Battery:
Battery replacement is not required and the battery cannot be removed.
Low Battery
If the smoke detector emits a short ‘beep’ once every 40 seconds the battery is at
the end of its life and this detector should be replaced immediately. This low
voltage warning will be given for at least 30 days.
If the red indicator light (LED) does not flash every 40 seconds then replace the
whole smoke alarm unit.
OPERATION, TESTING AND MAINTENANCE
Operation
Normal Operation When no smoke is present, a red LED indicator will flash ONCE A
MINUTE and is an indication that the unit is operating properly.
The hush feature can mute the detector if it has been inadvertently triggered by
holding down the test/hush button for a few seconds. The smoke alarm will be muted
for 10 minutes and then reset into normal mode after this period.
NOTE: If the smoke density increases during the hush period the smoke alarm will be
triggered into sounding again.
Alarm Condition
When the unit detects smoke, the red LED indicator will flash rapidly and alarm will
sound loudly until the air is clear.
Testing the Smoke Alarm
Test the smoke alarm once a week. If the smoke alarm ever fails to test correctly,
have it replaced immediately! If the smoke alarm is not working properly, it cannot
alert you to a problem.
1. Test each smoke alarm to be sure it is installed correctly and operating properly.
2. The push-to-test button accurately tests functions. DO NOT use an open flame to
test this smoke alarm. You may ignite and damage the smoke alarm or your home.
3. Stand at arm’s length from the smoke alarm when testing.
4. To test the smoke alarm firmly press the test button, and the alarm will sound a
loud beep. The alarm will stop sounding after releasing the test button. If the alarm
does not sound please re-test the alarm.
WARNING: If the alarm sounds and the smoke alarm is not being tested, the smoke
alarm is sensing smoke. The sound of the alarm requires your immediate attention
and action.
Areas to be avoided include the following:
• Situations where the temperature may fall below 0 C or rise above 40 C
• Humid areas such as bathrooms, kitchens, shower rooms where the
relative humidity may exceed 90%
• Near a decorative object, door, light fitting, window molding etc., that may
prevent smoke or heat from entering the alarm.
• Fume filled environments such as garages. Exhaust gases may cause false
alarms.
• Adjacent to or directly above hot components such as radiators or wall vents
that can affect the direction of air currents.
• In very dusty or dirty environments such as workshops.
• Locate unit at least 1.5m and route wiring at least 1m away for fluorescent
light fittings as electrical “noise” and/or flickering may affect the unit. Do not
wire into the same circuit as fluorescent lights or dimmers.
• Do not locate in insect infested areas. Insects and contamination on the
Heat Alarm sensor can increase its response time.
o o
Warranty:
The smoke alarm is warranted to be free from defects in materials and workmanship for five (5) years from the date of purchase and is not transferable under normal
use. The warranty does not cover natural disasters such as fire, flood, hurricanes and tornados. Warranty is conditional on the smoke alarm being used in the normal
way and not being modified or subject to attempted repairs or contamination. The warranty excludes the battery, incidental and consequential damages. Your statutory
rights as a consumer are in no way compromised by this warranty. Red Smoke Alarms agrees to repair or replace, at its option, any defective smoke alarm provided it is
returned personally or by prepaid delivery with a copy of proof of purchase. This warranty does not cover damages resulting from lack of reasonable care of the product.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for
compensation for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a major failure.
Subject to those non-excluded rights and provisions and the above warranty, Red Smoke Alarms will not be liable for injury to persons, damage to property, or for any
direct or indirect or consequential damage as a result of negligence or fault on the part of Red Smoke Alarms or it’s servants, agents, suppliers and contractors or
otherwise arising out of or resulting from, whether directly or indirectly, the use, installation or maintenance of the smoke alarm and any warranties or representations
are excluded unless given by Red Smoke Alarms in writing. Please leave this document, or a copy, for the end user.
Red Smoke Alarms reserves the right to change specifications,
modify designs and discontinue items without incurring obligation
and whilst every effort is made to ensure that descriptions, specifica-
tions and other information in this catalogue are correct, no warranty
is given in respect theseof and the company shall not be liable for any
error therein.
© Red Smoke Alarms 2020
This material copyright under Australian and international laws.
Except as permitted under the relevant law, no part of this work may
be reproduced by any process without prior written permission of and
acknowledgment to Red Smoke Alarms.
MNPRG86610YRF175A0
RED SMOKE ALARMS PTY. LTD.
P O Box 9596
PACIFIC PARADISE QLD 4564
[email protected].
www.redsmokealarms.com.au
1300 316 552
SMOKE ALARMS
