Chiayo APEX EVO User manual

CHIAYO ELECTRONICS CO., LTD.
Operation manual
APEX EVO
Multifunctional Wireless Mixer Amplifier

1
APEX EVOMultifunctional Wireless Mixer Amplifier
Important safety instructions
⚫ Read all of the instructions before the product is operated.
⚫ Keep these instructions well for future reference.
⚫ Follow all of the warnings and instructions when installing, setting up and using the product.
⚫ Only clean the product when it is not connected to the power supply system. Clean only with
a dry cloth.
⚫ Keep ventilation openings unblocked and follow with the manufacturer’s instructions for
installation.
⚫ Do not immerse product in any liquid or expose to heat or moisture
⚫ Keep the complete polarized or grounding type plug without any modification. A polarized
plug has two blades with one wider than the other. A grounding type plug has two blades and
a third grounding prong. The wider blade or the third prong are provided for your safety. If the
provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.
⚫ Power supply cords should be well routed to prevent from being walked on or pinched by
items placed upon or against them, particularly at plugs, convenience receptacles, and the
point where they exit from the product.
⚫ Use only manufacturer authorized or recommended accessories.
⚫ Use only with a cart, stand, tripod or accessories specified or provided by Chiayo. Be careful
when using a cart to avoid injury from tip-over.
⚫ Unplug the product during an electrical storm or when unused for long periods of time.
⚫ Never disassemble, modify or service the product. Any unauthorized modifications may result
in personal injury and/or product failure. Additionally, your warranty will be void.
⚫ Operation Temperature: 35 Degree Celsius Maximum.

2
Operation manual
INDEX
1. Instruction .................................................................................................................................3
1-1 In the box ...........................................................................................................................3
1-2 Optional related products ..................................................................................................3
1-3 Parts and functions ............................................................................................................4
1-4 Charging the battery ..........................................................................................................4
1-5 Control panel .....................................................................................................................5
1-6 Menu instruction ................................................................................................................5
1-6-1 INPUT volume page ..................................................................................................5
1-6-2 MUSIC volume page .................................................................................................6
1-6-3 EQUALIZER page .....................................................................................................7
1-6-4 EFFECT and language page .....................................................................................8
1-7 Module compartment .........................................................................................................9
1-8 Connection with external audio sources ............................................................................9
2. Settings and Operations ......................................................................................................... 10
2-1 Using the wired microphone (MIC 1, MIC 2) .................................................................... 10
2-2 Using the wireless microphone ........................................................................................ 11
2-2-1 Parts and functions .................................................................................................. 11
2-2-2 Channel synchronization of the receiver and transmitter ......................................... 11
2-2-3 Channel scanning .................................................................................................... 12
2-2-4 Squelch (SQ) setting ............................................................................................... 12
2-2-5 Volume and other settings ....................................................................................... 13
2-3 Using the electronic instrument (LINE IN ❶) ................................................................... 14
2-4 Music audio input (LINE IN ❷) - Smart phone / tablet / MP3 player ................................ 15
2-5 Music audio input (LINE IN ❸) - DVD player ................................................................... 16
2-6 Operating BLUETOOTH receiver (BT) ............................................................................ 17
2-7 EQUALIZER for WIRED and WIRELESS MICROPHONE and MUSIC........................... 18
2-8 VOICE PRIORITY ........................................................................................................... 19
2-9 CONTROL for vocal effect ............................................................................................... 19
2-9-1 REVERB .................................................................................................................. 19
2-9-2 DELAY ..................................................................................................................... 20
3. Application .............................................................................................................................. 21
3-1 Active audio link: APEX EVO to APEX EVO ................................................................... 21
3-2 Active audio link: APEX EVO to APEX SLAVE ............................................................... 23
3-3 Wireless audio link: repeat all audio to linked APEX EVO / APEX SLAVE ...................... 25
3-3-1 Parts and functions of RP-5100M ............................................................................ 25
3-3-2 Changing channels .................................................................................................. 26
3-3-3 Music audio input (AUX IN)- Smart phone / tablet / MP3 player .............................. 26
3-3-4 Adjust internal audio gain level ................................................................................ 26
3-3-5 Output power setting ............................................................................................... 26
3-4 More extension ................................................................................................................ 28
3-5 Connecting a passive companion speaker ...................................................................... 29
4. Installing or replacing a receiver/repeater/MP3 module ......................................................... 30
5. Operation of the storage for transmitters and accessories ..................................................... 31
6. FAQ & useful operation tips.................................................................................................... 32
7. Maintenance-free Lead-acid and Lithium batteries ................................................................. 34

3
APEX EVOMultifunctional Wireless Mixer Amplifier
1. Instruction
Congratulations and thank you for purchasing this all-in-one portable
sound system. To ensure a trouble-free operation, please read the
manual thoroughly to fully understand its controls and functions.
The rear panel of these portable sound systems is divided into 3
sections:
1. Module compartment
2. Control panel
3. Input / output compartment
4. Battery compartment
The Modules Compartment can be user configurable and user
can access the battery compartment to change battery.
1-1 In the box
APEX EVO amplifier
0-4 handheld / beltpack
transmitters (optional)
switching power supply
(plug varies from country to country)
operation manual
.
1-2 Optional related products
▍Modules & transmitters
SDR-8200M IrDA
Ture diversity receiver module
SQ-6100 IrDA
SQ-5100 IrDA
Handheld microphone
SDR-8100M IrDA
Diversity receiver module
SM-7100 IrDA
SM-6100 IrDA
Belt-pack transmitter
DWR-5410M
2.4G digital receiver module
DH-5400
Handheld digital microphone
DB-5400
Belt-pack digital transmitter
RP-5100M
Repeater module
DPR-500m
MP3 recorder module
▍Speakers
APEX SLAVE
Active companion powered
speaker
APEX SP
Passive companion speaker
▍Accessories
ST-50
Tripod stand: standard
ST-51
Tripod stand: height adjustable
DC-55
Weather proof dust cover
DM-series
Wired microphone, please refer
to CHIAYO website.
Module
compartment
Control panel
Input / output
compartment
Battery
compartment

4
Instruction
1-3 Parts and functions
1-4 Charging the battery
This amplifier uses either two lead-acid batteries or one lithium battery which can be identified
by LEAD-ACID and LI-ION on the panel top. The battery power can be identified by the meter
after the battery type. If the meter reads below 25%, the battery might not be sustainable for
long operation and need recharging.
charging indicator
Charging indicator
Condition
Flashes RED
During recharging
Solid GREEN
Fully charged
Solid YELLOW
Error or no battery detected
LI-ION
22
08
control panel
MIC input ②
(combo)
LINE IN socket
(6.3mm, 3.5mm)
LINE IN socket
(RCA R/L)
audio link
input
audio link
output
LINE OUT socket
(6.3mm)
battery power
battery type
BLUETOOTH
power push button
charging indicator
power switch
DC input jack
(30-32V/4A)
Volume control
BLUETOOTH
pairing indicator
MIC input ①
(combo)
EXTERNAL SPEAKER
socket (4-8Ω)

5
APEX EVOMultifunctional Wireless Mixer Amplifier
1-5 Control panel
1-6 Menu instruction
1-6-1 INPUT volume page
1. Press INPUT to enter the volume control for wireless / wired microphones and line inputs.
Category
VOICE
MUSIC
Tab
WR1 ~ WR4
MIC 1 ~ MIC 2
LINE IN ❶
LINE IN ❷
LINE IN ❸
Input
Wireless mic 1 ~ 4
Wired mic 1 ~ 2
6.3mm
3.5mm
RCA R/L

2. These audio sources can be individually adjusted from 0 (min) to 30 (max) by either of below
methods.

Press “＋” and “－” buttons
Slide granular bar
Select target audio and rotate jog wheel knob
LI-ION
22
08
LI-ION
22
08
14 24 06 14 24 06 14 24 06
14 24 06 14 24 06 14 24 06
14 24 06 14 24 06 14 24 06
INPUT volume page
battery type
battery power
MUSIC volume page
Master speaker volume
LEVEL: 0 (min) –30 (max)
SWITCH: ON↔OFF
Slave speaker volume
LEVEL: 0 (min) –30 (max)
SWITCH: ON↔OFF
LCD brightness control
LEVEL: 1 (min) –10 (max)
VOICE PRIORITY
SWITCH: ON↔OFF
Equalizer
display bar
EQ page
REVERB / DELAY
page
After idling for 3 minutes, the brightness
automatically turns to level 1 for power saving. It
will return to previous level after touching again.

6
Instruction
1-6-2 MUSIC volume page
1. Press MUSIC to enter the volume control for CD / DVD player, BLUETOOTH and
companion powered speaker (ACTIVE IN).
Tab
CD、BT、Digital Player
Active in
Input
CD, BLUETOOTH, MP3
companion powered speaker

2. These audio sources can be individually adjusted from 0 (min) to 30 (max) by either of below
methods.

Press “＋” and “－” buttons
Slide granular bar
Select target audio and rotate jog wheel knob
LI-ION
22
08
02
02
14 24 06 14 24 06 14 24 06
02
02

7
APEX EVOMultifunctional Wireless Mixer Amplifier
1-6-3 EQUALIZER page
1. Press EQ to enter the EQUALIZER control for wireless / wired microphones and line
inputs.
Category
VOICE
MUSIC
Input
Wireless mic
1 ~ 4
Wired mic
1 ~ 2
LINE IN ❶
(6.3mm)
LINE IN ❷
(3.5mm)
LINE IN ❸
(RCA R/L)
CD, BLUETOOTH, MP3
ACTIVE IN

2. There are nine individual controls for frequency bands ranging from 63 Hz to 16 KHz. Each
can be adjusted from -12 (min) to 12 (max) by either of below methods.

Press “＋” and “－” buttons
Slide granular bar
Select target audio and rotate jog wheel knob
3. Equalized audio only goes to master speaker, slave speaker (from SPEAKER OUT jack)
and active speaker (from ACTIVE OUT jack). It won’t apply to:
(1). Output from LINE OUT ❶~❸to the amplifier or mixer.
(2). Recording via DPR-500m module.
(3). Interlinking via RP-5100m module to the active speaker.
LI-ION
22
08
0 0 0 0 0 0 0 0 0
14 24 06 14 24 06 14 24 06
11 11 11 11 11 11 11 11 11

8
Instruction
1-6-4 EFFECT and language page
1. Press CONTROL to enter the RREVERB and DELAY control for wireless / wired
microphones and language setting.
Category
REVERB
DELAY
Sector
Reverb out
Diffusion
Decay factor
Pre-delay
Out
Time

2. There are four child effects for REVERB and two for DELAY. Each can be adjusted by either
of below methods.

Press “＋” and “－” buttons
Slide granular bar
Select target audio and rotate jog wheel knob
3. This system includes two languages of control panel interface for selection, English
(default) and traditional Chinese. The options are located at top-right of the screen.
4. Reset: After pressing RESET till the screen flashes once, all settings will return to default.
LI-ION
22
08
CHDRUS
AMBIENCE
ROOM
DELAY
DEFAULT
PHASER
& PEVE RB
14 24 06 14 24 06 14 24 06
11 11 11 11 11 11 11 11 11
CHDRUS
AMBIENCE
ROOM
DELAY
DEFAULT
P H A S E R
& PEVE RB
CHDRUS
AMBIENCE
ROOM
DELAY
DEFAULT
P H A S E R
& PEVE RB

9
APEX EVOMultifunctional Wireless Mixer Amplifier
1-7 Module compartment
1-8 Connection with external audio sources
For receiver module
For receiver module
For receiver /
repeater module
For receiver / MP3
module
For module bracket MB-50 for installing an MP3
module.
WIRED MIC
INSTRUMENT
ACTIVE SPEAKER
AMPLIFIER
Volume control of audio output
from APEX EVO is only
operated on this external
amplifier.
TABLET / PHONE
DVD PLAYER
ACTIVE SPEAKER
PASSIVE SPEAKER

10
Settings and Operations
2. Settings and Operations
2-1 Using the wired microphone (MIC 1, MIC 2)
1 Plug a wired microphone with a 6.3mm or XLR connector to MIC 1 or MIC 2.
2 Turn on master POWER and adjust Master Speaker volume to 15, and then adjust MIC
1 or MIC 2 volume to a desired level.

3 EQUALIZER (refer to P.18) and REVERB / DELAY (refer to P.19) levels can be
adjusted individually.
EQUALIZER   
REVERB / DELAY  
LI-ION
15
15
LI-ION
22
08
14 24 06 14 24 06 14 24 06
LI-ION
22
08
0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0
LI-ION
22
08
CHORUS
AMBIENCE
ROOM
DELAY
DEFAULT
PHASER
& PEVE RB
or

11
APEX EVOMultifunctional Wireless Mixer Amplifier
2-2 Using the wireless microphone
2-2-1 Parts and functions
2-2-2 Channel synchronization of the receiver and transmitter
Align infrared areas of the receiver and transmitter within 10~30cm.
■Changing receiver’s channel
1 Press the synchronization
button of the transmitter.
►
2 The transmitter's LED will
grow to denote
synchronization signal
transmitted.
3 The channel number on
the receiver’s LED will
become the same as the
transmitter’s, which
means the receiver has
been successfully
synchronized.
■Changing transmitter’s channel
1 Press the SYNC button of
the receiver.
►
2 The transmitter's LED will
grow to denote
synchronization signal
received.
3 The channel number on
the transmitter’s LCD will
become the same as the
receiver’s, which means
the transmitter has been
successfully
synchronized.
If it doesn’t work check that you have the IR sensor panels aligned, that they are facing each
other, devices are within 10~30cm of each other, and try again.
SET SYNC
MIN
PWR/VOL
CH
RF AF
AB
0 10
652.250
AF
RF signal meter
Channel
Diversity A/B
antenna
Transmitter battery
power
Frequency
DOWN button
UP button
SET button
IrDA synchronization
button
IR sensor area
Power switch /
volume control
LCD
Audio signal
meter
10~30cm

12
Settings and Operations
2-2-3 Channel scanning
For an interference- free operation, a cleaner channel might be necessary if the current one
receives too much interference. To operate the scanning:
1 Press ▼(down) or ▲(up) button to make
the frequency icon appear on the
bottom.
2 Hold SET button until this icon
flashes to denote readiness for setting.
3 Press ▼(down) or ▲(up) button to find
and locate a clear, interference- free
channel.
4 After a channel is chosen, press SET
button or wait 5 seconds to store the
setting.
2-2-4 Squelch (SQ) setting
When interference is encountered try reducing the sensitivity of the receiver, thus less
susceptible to interference. To operate the squelch setting:
1 Press ▼(down) or ▲(up) button to turn to
the squelch setting page.
2 Hold SET button until this icon
flashes to denote readiness for setting.
3 Press ▼(down) or ▲(up) button to select
a new squelch level between 01 and 10.
The default level is 01.
4 After a level is chosen, press SET button
or wait 5 seconds to store the setting.
Since increasing the squelch level will also reduce the reception distance, it’s recommended to
choose the lowest level that can eliminate the interference.
If this still does not solve the problem it means this frequency is not suitable. Adjust the squelch
back to its default level (LE-01) and use the scan function to locate a clear, interference-free
channel.
RF
CH
FREQ
RF AF
AB
099
674.500
CH
FREQ
RF AF
AB
099
674.500
RF
CH
FREQ
RF AF
A B
089
672.000
RF
SQ
le-01
SQ
le-01
RF
SQ
le- 03

13
APEX EVOMultifunctional Wireless Mixer Amplifier
2-2-5 Volume and other settings
1 Turn on master POWER and then adjust the volume control on the module to max
level.
2 Adjust Master Speaker volume to 15, and then adjust its individual volume control to a
desired level.
 
3 EQUALIZER (refer to P.18) and REVERB / DELAY (refer to P.19) levels can be
adjusted individually.
EEQUALIZER   
REVERB / DELAY  
SET SYNC
MIN
PWR/VOL
LI-ION
15
15
LI-ION
22
08
14 24 06 14 24 06 14 24 06
WR1 WR2
WR3 WR4
LI-ION
22
08
0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0
LI-ION
22
08
CHORUS
AMBIENCE
ROOM
DELAY
DEFAULT
PHASER
& PEVE RB

14
Settings and Operations
2-3 Using the electronic instrument (LINE IN ❶)
1 Plug an electronic guitar / keyboard with a 6.3mm connector to the LINE IN ❶6.3Ø
jack.
2 Turn on master POWER and adjust Master Speaker volume to 15, and then adjust
LINE 1 volume to a desired level.

3 EQUALIZER levels can be adjusted individually. (refer to P.18)
EQUALIZER   
LI-ION
15
15
LI-ION
22
08
14 24 06 14 24 06 14 24 06
LI-ION
22
08
0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0
or

15
APEX EVOMultifunctional Wireless Mixer Amplifier
2-4 Music audio input (LINE IN ❷) - Smart phone / tablet / MP3 player
1 Connect your device to the LINE IN ❷3.5Ø jack with a 3.5mm 3-pole stereo audio
cable.
2 Turn on master POWER and adjust Master Speaker volume to 15, and then adjust
LINE 2 volume to a desired level.

3 EQUALIZER levels can be adjusted individually. (refer to P.18)
EQUALIZER   
LI-ION
15
15
LI-ION
22
08
14 24 06 14 24 06 14 24 06
LI-ION
22
08
0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0

16
Settings and Operations
2-5 Music audio input (LINE IN ❸) - DVD player
1 Plug the audio cable with RCA R/L plugs to the LINE IN ❸○R○L jacks.
2 Turn on master POWER and adjust Master Speaker volume to 15, and then adjust
LINE 3 volume to a desired level.

3 EQUALIZER levels can be adjusted individually. (refer to P.18)
EQUALIZER   
LI-ION
15
15
LI-ION
22
08
14 24 06 14 24 06 14 24 06
LI-ION
22
08
0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0

17
APEX EVOMultifunctional Wireless Mixer Amplifier
2-6 Operating BLUETOOTH receiver (BT)
1 Turn on master POWER and then press the SWITCH button 3 seconds to turn on the
BLUETOOTH receiver. The pairing indicator will flash green.
Approximately 9 seconds later, the pairing indicator flashes green and red, which
means it is ready for pairing.
2 Activate BLUETOOTH on your device (phone, tablet, PC., etc) and pair with external
BLUETOOTH device named “BT AUDIO”. After successful linking, the pairing indicator
will be solid green and you can play your music on APEX EVO.
3 Turn on master POWER and then adjust CD、BT、Digital Player volume control to a
desired level.

4 EQUALIZER levels can be adjusted individually. (refer to P.18)
EQUALIZER   
Settings Bluetooth
Bluetooth
DEVICES
BT AUDIO
Now Discoverable
...
LI-ION
22
08
02
02
LI-ION
22
08
0 0 0 0 0 0 0 0 0
0 0 0 0 0 0 0 0 0
flash
RED
flash
GREEN
flash
GREEN
solid
GREEN
solid
GREEN

18
Settings and Operations
Important
◼ The BLUETOOTH automatically turns off after no pairing for 5 minutes.
◼ Press SWITCH button for disconnection and getting ready for new pairing.
◼ The BLUETOOTH can memorize and automatically connect to last-paired device.
2-7 EQUALIZER for WIRED and WIRELESS MICROPHONE and MUSIC
EQUALIZER adjustment is actually used to increase or reduce the high (4KHz│8KHz│16KHz)
/ medium (500Hz│1KHz│2KHz) / low frequency (63Hz│125Hz│250Hz) component of the
sound. It is so-called raising or attenuating TREBLE / MIDDLE / BASS to improve human voices
or make musical instruments’ sound more prominent. According to the scale marks on the
panel, sliding up is to increase and boost and opposite direction to decrease and attenuate.
Adjust the level of high frequency (4KHz│8KHz│16KHz), middle frequency (500Hz│1KHz│
2KHz), and low frequency (63Hz│125Hz│250Hz) respectively. All signals have been balanced
by the high and low sounds after entering the amplifier so it is not necessary to adjust the
EQUALIZER during the output to the speaker. It is recommended to maintain the position of all
frequency bands at 0.
BASS
MIDDLE
TREBLE
Frequency
63
125
250
500
1K
2K
4K
8K
16K
FUNCTION
increase or reduce the low
frequency component of the
sound
increase or reduce the
medium frequency
component of the sound
increase or reduce the high
frequency component of the
sound
RANGE
-12 dB～+12 dB
DEFAULT
0
Adjustment reference:
◼ BASS: It is the basic part of the sound. It accounts for 70% of the entire audio energy and is
an important component to display the music style. When appropriate, the BASS is relaxed
and the sound is full and soft. If you feel the sound is thin, you can moderately increase the
BASS. If you feel the sound is muffled, not clear, or too nasal, you can moderately reduce the
BASS.
◼ MIDDLE: Containing the low harmonics and overtones of most musical instruments. It is the
characteristic sound of snare drums and percussion instruments. The sound is clear and
bright when appropriate. If you feel the sound is blurred, you can moderately increase the
MIDDLE. If a phone-like sound appears, you can moderately reduce the MIDDLE.
◼ TREBLE: It’s the frequency that affects the sound layering. If you feel that the sounds of
instruments such as Piccolo and Flute are too prominent, or the tooth sound of the voice is
too heavy and the tone is sharp, you can moderately reduce the TREBLE.

19
APEX EVOMultifunctional Wireless Mixer Amplifier
2-8 VOICE PRIORITY
Voice Priority operation is only necessary when CD/USB/MP3 is playing.
When the Voice Priority switch is ON, the ducking function will be activated. While the music is
playing, a voice input from either a WIRED or WIRELESS MICROPHONE will temporarily
override and lower the volume of the background music and voice could be heard more clearly.
Background music will return to its original setting when no audio input is entering the
microphone after certain seconds. However, if the microphone is not switch off, the reentering of
music into the microphone will also activate the voice priority function.
2-9 CONTROL for vocal effect
APEX EVO has two major sound effects especially for WIRED and WIRELESS microphones,
REVERB and DELAY. After entering the CONTROL page, you will see six factory-preset
modes on the left for selection. Each mode comprises of specific values of REVERB and
DELAY and is not changeable. The DEFAULT mode sets both REVERB and DELAY at OFF
status.
For advanced setting, REVERB has four child effects and DELAY has two that may be adjusted
to match expected effects.

2-9-1 REVERB
This function can add extra depth to the sound of WIRED or WIRELESS microphones to create
a realistic acoustic ambience. You can control the reverb on the REVERB area which includes
four child effects for adjustment. REVERB can be turned on / off by the ON/OFF button.
LI-ION
22
08
LI-ION
22
08
LI-ION
22
08
CHORUS
AMBIENCE
ROOM
DELAY
DEFAULT
PHASER
& PEVE RB
CHDRUS
AMBIENCE
ROOM
DELAY
DEFAULT
PHASER
& PEVE RB
REVERB ON/OFF
