CHIEF PSB-2022 User manual

INSTALLATION INSTRUCTIONS
CHIEF MANUFACTURING INC.
1-800-582-6480 952-894-6280 FAX [phone]
8401 EAGLE CREEK PKWY, STE. 700
SAVAGE, MINNESOTA 55378 USA
8804-000154 RevC
2006 Chief Manufacturing
www.chiefmfg.com
05/06
ALL COMPONENTS MUST BE SECURELY FASTENED TO A
STRUCTURAL MEMBER CAPABLE OF SUPPORTING 4
TIMES THE COMBINED WEIGHT OF ALL COMPONENTS
PLUS THE EQUIPMENT BEING MOUNTED. IF IT CANNOT
SUPPORT THIS WEIGHT, THE STRUCTURE MUST BE
REINFORCED.
THE MAXIMUM WEIGHT TO BE INSTALLED ON THE
MOUNT IS 1
75
POUNDS (
79.38
KG).
PSB-2022
PLASMA DISPLAY MOUNTING BRACKET
Prior to assembly, unpack carton completely and verify contents.
If you are missing any of the following components, please contact Customer Service at 1-800/582-6480
(2) Plasma Side Bracket (2) Plasma Top/Bottom Bracket
(4) Mounting Button - Tapped (8) 10-24 x .5 Button Head Cap Screw
(4) M8 x 40mm Button Head Cap Screw (8) 18mm x 8.3mm x 20mm Black Nylon Spacer
(4) M8 x 60mm Button Head Cap Screw (1) M5 Allen Key
(1) 1/8 Allen Key
BEFORE PROCEEDING, READ INSTALLATION INSTRUCTIONS COMPLETELY
PLASMA DISPLAYS ARE EXTREMELY FRAGILE.
1. Using a 10-24 button head cap screw inserted from back side of bracket, secure mounting button, with
chamfered hole of mounting button (larger surface) facing bracket, to top and bottom brackets (four places) (see
Figure 2 & Figure 3).
CAUTION!
Figure 1
WARNING!
Figure 2 Figure 3

2. Using four 10-24 button head cap screws, attach top and bottom to side brackets (see Figure 4 & Figure 5).
3. Place Nylon spacers over mounting holes on back of screen. Attach mounting brackets to display using the M8
screws (see Figure 6 & Figure 7). If a video board is attached to the back of the display, stack two black Nylon
spacers and attach bracket using the M8 x 60mm screws.
4. With the aid of another person, lift your display up to the Chief Mount, aligning buttons of mounting brackets
with slots in the Chief Mount.
5. Lower safety latch on the Chief Mount to secure your display, making sure latch is completely engaged.
Figure 5
Figure 7
Figure 6
If video board is attached
to back of display, stack two black
nylon spacers and attach bracket
using M8 x 60mm screws.
Figure 4
