Child Craft CRIB’N’DOUBLE User manual

CCH02703:12/99 JCHEpm6.5 CRIB’N’DOUBLE BED W/DRAWER
CONVERTS TO DAYBED OR FULL
SIZE HEADBOARD
1
CHILD CRAFT INDUSTRIES, INC.
P.O. Box 444, Salem, IN USA 47167-0444
PH:812-883-3111-FAX: [phone] - http://www.childcraftind.com
ASSEMBLY DIRECTIONS AND PARTS LIST
ΦREADALLINSTRUCTIONSWITHCAREBEFORESTARTINGTHEASSEMBLYPROCEDURE.
ΦΦ
ΦΦ
ΦYOU WILL NEED A PHILLIPS SCREWDRIVER, A STANDARD SLOTTED SCREWDRIVER, A 10mm (3/8”) WRENCH,
AND THE ENCLOSED ALLEN WRENCH (UU
UU
U) AND HEXHEAD WRENCH (VV
VV
V).
PARTS ENCLOSED IN HARDWARE BAG ( NOTED WHEN SHOWN ACTUAL SIZE ) DO NOT SUBSTITUTE PARTS!
ABCDE
(4) Flathead
Phillips Wood
Screw
(4) Hexhead
Machine Screw (8) F/H Phillips Wood Screw (4) Pan Head Machine Screw (10) Pan Head
Combo Wood
Screw
(actualsize)
FG
(1)
Lower
Track
Assembly
(Right)
(1)
Lower
Track
Assembly
(Left)
H
I
J
(4) Allenhead K-D Bolts
(actualsize)
(4) Insert Locknuts
(2) Upper Tracks
K
LM
(2) PanHeadPhillips
Wood Screw
(actualsize)
(4) K-D Bolt Plugs
(4) Hole Button Covers
(actualsize)
R
Q
U
T
S(3) PanheadPhillips
Wood Screw
(actualsize)
(8) Flathead Phillips
Wood Screw
(actualsize)
(1) Allen Wrench
(actualsize)
(2) Rubber
Washers (2) R/HCombo Machine Screw
(actualsize)
W(4) Mini Blocs
child craft
V(1) Hexhead Wrench
P(2) 4-Position Spring Bracket
N
(1) Sta-Bar Bracket -Left (1) Sta-Bar Bracket -Right
O
PARTS ENCLOSED IN CARTON (CONTINUED ON PAGE TWO)
(16) Washers
(actualsize)
(1) Drawer Rail - Right AA
(1) Drawer Rail - Left BB
(1) Drawer ”Cabinet Rail” - Right Y
(1) Drawer ”Cabinet Rail” - Left Z
XX
XX
X
(actualsize)
33301.06
(actualsize) (actualsize) (actualsize)
H00106
H00109
H00120
H00132
H00133
H00164
H00171
H00190
H00211 H00248
H00251(B) H00250(W)
H00254
H00281
H00282
H00288
H00365(B) H00358(W)
H00366(B)
H00361(W)
H00367(B)
H00362(W)
H00371
H00956
H01168
H00185
(actualsize)
(actualsize)
(actualsize)

PARTS ENCLOSED IN CARTON (CONTINUED FROM PAGE ONE)CCH02703:12/99
2
(1) Headboard JJ
(1) Footboard II
(1) Stationary Side KK (1) Dropside LL
(1) Crib Spring MM
plasticpouch
(1) Stabilizing Bar NN
PREPARATION
Carefully remove and lay out all hardware and parts. Check quantities and match the Hardware List and the Parts List. NOTE: During the assembly
process whenever using screws or bolts, check each with the Hardware List by letter and size identification. Place each screw or bolt
on the diagram of the item which is sketched actual size. Be sure to use the proper size specified in the assembly directions. If a part
is missing or broken contact your Child Craft dealer or Child Craft, P.O. Box 444, Salem, IN 47167-0444 USA, 812-883-3111, [email protected]
for replacement part(s) or instructional literature. Before making this contact identify your Crib’n’Double Bed by the model identification number stamped
on the label on the inside face of Footboard II bottom rail. Make note of all identification numbers and include this information with your request. DO NOT
SUBSTITUTEPARTS!
Record your model identification number here for future identification: Model #______________________________________
STEP 1- DIAGRAM 1: INSTALL HARDWARE TO FOOTBOARD AND HEADBOARD
NOTE: All wood screws have factory bored pilot holes to start the screws (pilot holes are shown in diagrams).
(HELPFUL HINT: Hardware installation may be
easier if the Footboard II and Headboard JJ are
(2) Drawer Rails CC (2) Drawer Ends DD
(1) Drawer Partition EE
(1) Drawer Back FF
(1) Drawer Front GG
(1) Drawer Bottom HH
((Style may vary)
((Style may vary)
placed in a horizontal position on a soft surface being careful not to scratch the crib finish.) Install Upper Track J to the Footboard II and the
Headboard JJ using two Flathead Phillips Wood Screws Aas shown. Attach 4-position Spring Bracket P using three Pan Head Combo Wood
Screws E as shown. Mount Lower Track Assembly Right Fto Footboard II. Start by installing a Combo Pan Head Wood Screw E into the holes
on Lower Track Assembly Right F, through the holes in Sta-Bar Bracket - Right O, and into the pilot holes in Footboard Corner Post II. Tighten
securely. Follow the same procedure to attach Lower Track Assembly Left G and Sta-Bar Bracket Left N to Headboard Corner Post JJ. NOTE:
Open slot at top of Lower Track assembly FF
FF
F& GG
GG
G faces the inside of your crib. Install hardware exactly as illustrated.
((Style may vary)
SEEENLARGED VIEW ENLARGED VIEW
PilotHoles
PilotHoles
PilotHoles
Closed end of
Upper Track J
Slot faces
inside of crib
A
EP
J
II EFO
II

CCH02703:12/99 3
STEP 2- DIAGRAM 2:INSTALL DRAWER RAILS TO FOOTBOARD AND HEADBOARD
STEP 3 - DIAGRAM 3: ATTACH STATIONARY SIDE
Follow diagram exactly for
installing Drawer Rail CC
and Drawer “Cabinet” Rail-
Right Yto Footboard II
and Drawer Rail CC and
Drawer “Cabinet” Rail-Left
Zto Headboard JJ.
Attach Stationary Side KK to Headboard JJ and Footboard II. Insert each of
the four Allenhead K-D Bolts Hinto receiving holes located in corner posts of
StationarySide KK as shown. Place Stationary Side KK in alignment and allow K-D Bolts HH
HH
H to continue into ends of top and bottom rails of Headboard
JJ and Footboard II. Insert each of the four K-D Bolt Plugs LL
LL
L as shown. Pull out each K-D Bolt HH
HH
Hjust enough to allow the K-D Bolt Plug LL
LL
Lto
be fully inserted in hole. Tighten all four K-D Bolts HH
HH
Huntil secure using Allen Wrench UU
UU
Uwhile securing K-D Bolt Plugs LL
LL
Lwith a Standard Slotted
Screwdriver. CAUTION: DO NOT OVERTIGHTEN.
C
Match up these holes
with Wood Screws C
NOTE: See Step 7 - Install the enclosed Washers Xhere if needed,
between Drawer Rail CC and Footboard II and/or Headboard JJ.
DO NOT INSTALL WASHERS XX
XX
XDURING STEP 2. ONLY INSTALL
WASHERS IF THE DRAWER ASSEMBLY FITS TOO LOOSE IN ITS
TRACKS AFTER CRIB IS COMPLETELY ASSEMBLED.
CC
ZY
JJ II
Match up these holes
with Wood Screws C
H
L
L
L
H
JJ
JJ
JJ
KK
KK
L
U
U
Factory installed Connected View
Standard
Screwdriver

CCH02703:12/99 4
STEP 4 - DIAGRAM 4:ATTACH STABILIZING BAR STEP 5 - DIAGRAM 5: SPRING INSTALLATION
Locate “Tabs” on Spring MM and rotate Tabs upward. Position the
four Tabs on Spring MM to the desired height allowed by the threaded
holes located on the 4-Position Spring Bracket P. Install a Hexhead
Machine Screw B through each Spring Tab and into the selected threaded
receiving hole on Spring Bracket P. Tighten Screws Bwith Hexhead
Wrench Vor a 10mm (3/8”) wrench. Follow the same procedure when
changing spring heights at a later date. Periodically check Hexhead Ma-
chine Screws Band tighten if needed.
STEP 6 - DIAGRAM 6: INSTALL DROPSIDE
Align Plastic Guides
(Factory installed) on
Dropside LL with
dropside hardware
mountedonpost from
underneath. An as-
sistant is very help-
ful. Afterallfourplas-
tic guides are aligned
with the hardware,
liftDropside“UP”and
allow it to latch into
the raised position.
After Dropside LL
is installed on the
tracks and is latched
in the “UP” position,
insert a Machine
Screw R into a
Rubber Washer Q
and thread into hole
in bottom of Lower
Track Assemblies F
&G.
TO LOWER DROPSIDE LLLL
LLLL
LL:
FIRST - LIFT THE DROPSIDE,
SECOND - WITH KNEE PUSH
IN ON CENTER OF BOTTOM
RAIL OF DROPSIDE TO RE-
LEASE LATCH ON LOWER
PLASTIC LATCH. LOWER
DROPSIDE BY HAND. TO
RAISE DROPSIDE LLLL
LLLL
LL: PULL
“UP” UNTIL LOWER PLASTIC
GUIDES LATCH IN SLOT IN
LOWER TRACKS FF
FF
F& GG
GG
G.ALWAYSBESURECRIB SIDEIS“UP”AND“LATCHED”BEFORE LEAVINGCHILDIN CRIB.
Mount the Stabilizing Bar Assembly NN to Footboard II and Head-
board JJ. Insert (2) Pan Head Machine Screws Dthrough the holes
in Sta-Bar Bracket - Right O, and through the holes in Stabilizing Bar
NN. Attach (2) Insert Locknuts Ito Machine Screws D
tighten securely. See Enlarged View for the proper installation of
Locknut II
II
I. Follow the same procedure for attaching Stabilizing Bar
NN to Headboard JJ.
I
F
O
NN
D
NN
II
D
NorO
Plastic insert in
Locknut I
NOTE: Mount all 4 “Tabs” on Crib Spring MMMM
MMMM
MM
at the same vertical mattress position.
MM
Corner Post of II or JJ Highest mattress position
Lowest mattress position
Mattress side
of Spring MM B
V
“Tab”
II
O
F
LL
J
Align Upper
PlasticGuide
with Upper
Track J
Align Lower
PlasticGuide
with Lower
Track F
Align all four plastic guides with installed
tracks from underneath - then lift “UP”
until Lower Plastic Guides latch.
LOCKING MECHANISM
NOTE: It may be necessary to Flex the Locking Mechanism
toward outside of crib to engage the Lower Tracks F& G
LL
O
F
RQ
II
P

CCH02703:12/99
5
STEP 7 - DIAGRAM 7:ASSEMBLE & INSTALL DRAWER
Refer to the Diagrams and install Mini Blocs Winto each of the
Drawer Ends DD and Drawer Partition EE as shown. NOTE:
Before installing the Mini Blocs be sure that you have the two Drawer
Ends DD aligned exactly as shown in order to have a pair when
complete.
Assemble the Drawer as shown. After the Drawer is assembled,
turn the Drawer upside-down and install two Panhead Screws K
into the holes located in Drawer Bottom HH to secure it to the
Drawer Partition EE.
Install the assembled Drawer under the crib by inserting the rollers
on Drawer Rails AA & BB (attached to the drawer) into the
channel of Drawer “Cabinet” Rails Y& Z under the crib.
W
NOTE: With the drawer bottom grooves
together.....this will result in a pair.
Drawer
Bottom
Grooves
DD
SEEENLARGEDVIEW
WDD
ENLARGEDVIEW
W
EE
Laminated edge
DD
GG
WTighten the screw in Mini Bloc W
to thread into prebored pilot holes
in the Drawer Front GG
ENLARGEDVIEW2
Phillips Screwdriver
Attach Drawer Rail-Left BB to Drawer End
DD in the same manner as shown for op-
posite end. NOTE: Both roller wheels will go
toward Drawer Back FF.
DD
GG
W
SEEENLARGEDVIEW2
WDD
HH
EE
FF S
Install in pre-bored holes
on both drawer ends.
T
AA
Install extra Wood
Screws Tat
these locations.
Insert Drawer Bottom HH into groove on all four sides.
NOTE:IFTHEDRAWERFITSTOOLOOSEINITSTRACKS,
YOUCANADJUSTTHE FITBYADDINGTHEENCLOSED
WASHERSXASSHOWNINSTEP 2-DIAGRAM 2. REMOVE
THEDRAWER.CAREFULLYLAYTHECRIBONITSBACK
TO ALLOW ACCESS TO PARTS C, Y, Z, CC. RE-
MOVE THE DRAWER RAILS AND INSERT A WASHER
OVER EACH SCREW POINT CBETWEEN CC & JJ
AND/OR CC & II. REINSTALL RAIL ASSEMBLY AND
DRAWER. ADDADDITIONALWASHERSIFNECESSARY
REPEATINGTHISPROCESS. INSTALL WASHERS ONLY
IFNEEDED.
Roller
Wheel
DO NOT OVERTIGHTEN
SCREWS IN MINI BLOC WW
WW
W.

6CCH02703:12/99
DIRECTIONS FOR CONVERTING
“CRIB”TO A“DAYBED”DIRECTIONS FOR CONVERSION
TO A“FULL SIZE HEADBOARD”
When use as a crib has been completed, you have the option to
convert to a daybed for years of additional use in your child’s room.
Refer to Step 6 - Diagram 6 and follow direction is reverse order.
Store the removed parts and hardware in the event you wish to
convert your daybed back to a crib. Refer to Sketch A.
Sketch A
(style may vary)
Disassemble crib by first removing the drawer. Store the drawer
without disassembly. Perform Step 6, 5, 4 & 3 in reverse order to
remove the Stationary Side KKKK
KKKK
KK from the other crib parts.Attach
the Stationary Side to a Hollywood style full size bed frame at the
location of the mounting cleats (Hardware is not provided). See
Diagram 8 and Sketch B. Insert the Hole Button Covers M as
shown.
Sketch B
(style may vary)
DIAGRAM 8
Receiving holes for Hole Button Covers M
Receiving holes for Hole Button Covers M
KK
MountingCleats
(Cleats are flush with the face that the
purchased Hollywood Frame mounts to.)
MAINTENANCEOFYOURCHILD CRAFT CRIB/DAYBED/FULL SIZE HEADBOARD: Upon completionofassemblybesureallscrews, bolts
and fastening devices have been tightened securely. A frequent check should be made of all screws, bolts and fastening devices and
tightened if needed. Before each usage or assembly, inspect crib for damaged hardware, loose joints, missing parts or sharp edges.
DO NOT use crib if parts are missing or broken. Contact your Dealer or Child Craft [phone], [email protected] for a
replacement part or instructional literature if needed. Include Model Identification Number with your request which you recorded on
page2oftheseinstructions. DO NOT SUBSTITUTE PARTS. DO NOT MAKE ANYALTERATIONSNOT DESCRIBED IN THESE ASSEMBLY
DIRECTIONS.
CLEANING INSTRUCTIONS FOR YOUR CHILD CRAFT CRIB/DAYBED/FULL SIZE HEADBOARD: Mixtogether amild solutionof gentle
dishwashing liquid and water, apply to surface using a soft clean cloth lightly dampened in the solution. Rinse with clear water again
using a soft clean cloth, then dry all surfaces thoroughly with a soft dry cloth. NO ABRASIVE CLEANERS, SCOURING PADS, STEEL
WOOL,ORCOARSERAGSSHOULDBEUSEDTOCLEAN THISFINEFURNITURE.
STORAGEANDUSE OF YOUR CHILD CRAFTCRIB/DAYBED/FULLSIZEHEADBOARD: Aprintedplasticpouchisattachedtothecribspring
for the permanent storage of the assembly directions. After completing the assembly process you are advised to read and be aware of
allWARNINGS, CAUTIONS, CLEANING, STORAGE, USE AND MAINTENANCE noticescontainedinthissetof directionsandprinted on the
plastic pouch located on the underneath side of the crib spring. You will then place the complete set of assembly directions into the
plastic pouch for future referral by opening storage drawer. We caution you not to place excess hardware in the plastic pouch as it could
present danger to a child if retrieved. When storing crib use CAUTION as extreme temperature or humidity changes could be harmful.
Use CAUTION when a vaporizer is in use, always aim vapor stream away from crib as well as away from any wood furniture item.
(style may vary)
Assembled Crib
(style may vary)
KK
JJ
II
LL
GG DD
Purchased Mattress
(see size requirements on
page 7 under CAUTION)WHENEVER DISASSEMBLING CRIB,DONOT
REMOVE ANY ITEM ATTACHED WITH WOOD
SCREWS AA
AA
A, CC
CC
C, EE
EE
E, KK
KK
K, SS
SS
S, TT
TT
TOR WW
WW
W.

WARNING
ΦΦ
ΦΦ
ΦFAILURE TO FOLLOW THESE WARNINGS AND ASSEMBLY IN-
STRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH.
ΦΦ
ΦΦ
ΦREAD ALL INSTRUCTIONS BEFORE ASSEMBLING CRIB. KEEP
INSTRUCTIONS FOR FUTURE USE. A PLASTIC POUCH IS ATTACHED TO
CRIBSPRINGFORPERMANENTSTORAGEOFTHEINSTRUCTIONALLITERATURE.
ΦΦ
ΦΦ
ΦBEFORE EACH USAGE OR ASSEMBLY, INSPECT CRIB FOR
DAMAGED HARDWARE, LOOSE JOINTS, MISSING PARTS OR
SHARP EDGES. DO NOT USE CRIB IF ANY PARTS ARE MISSING
OR BROKEN. ASK YOUR DEALER OR WRITE TO CHILD CRAFT,
P.O. BOX 444, SALEM, IN 47167-0444 USA (812)-883-3111) FOR RE-
PLACEMENT PARTS AND INSTRUCTIONAL LITERATURE IF
NEEDED. INCLUDEMODELIDENTIFICATION NUMBERS WITH YOUR REQUEST WHICH
YOU RECORDED ON PAGE TWO. DO NOT SUBSTITUTE PARTS.
ΦΦ
ΦΦ
ΦAFTER RAISING SIDE, MAKE SURE LATCHES ARE SECURE.
ΦΦ
ΦΦ
ΦWHEN CHILD IS ABLE TO CLIMB OUT OR REACHES THE
HEIGHT OF 35 INCHES (90 CENTIMETERS) THE CRIB SHALL NO
LONGER BE USED.
ΦΦ
ΦΦ
ΦDO NOT PLACE CRIB NEAR WINDOW WHERE CORDS FROM
BLINDS OR DRAPES MAY STRANGLE A CHILD.
ΦΦ
ΦΦ
ΦIF REFINISHING, USE A NON-TOXIC FINISH SPECIFIED FOR
CHILDREN’S PRODUCTS.
ΦΦ
ΦΦ
ΦDO NOT LEAVE CHILD IN CRIB WITH SIDE LOWERED. BE SURE
SIDE IS IN RAISED AND LOCKED POSITION WHENEVER CHILD
IS IN CRIB.
ΦΦ
ΦΦ
ΦWHEN CHILD IS ABLE TO PULL TO STANDING POSITION, SET
MATTRESS TO LOWEST POSITION AND REMOVE BUMPER PADS,
LARGE TOYS AND OTHER OBJECTS THAT COULD SERVE AS
STEPS FOR CLIMBING OUT.
ΦΦ
ΦΦ
ΦNEVER USE PLASTIC SHIPPING BAGS OR OTHER PLASTIC
FILM AS MATTRESS COVERS BECAUSE THEY CAN CAUSE SUF-
FOCATION.
ΦΦ
ΦΦ
ΦDO NOT USE A WATER MATTRESS WITH THIS CRIB.
ΦΦ
ΦΦ
ΦREPLACE TEETHING RAIL(S) IF DAMAGED OR LOOSE. (IF
EQUIPPED WITH TEETHING RAILS.)
ΦΦ
ΦΦ
ΦSTRINGS CAN CAUSE STRANGULATION! DO NOT PLACE
ITEMS WITH A STRING AROUND A CHILD’S NECK, SUCH AS
HOOD STRINGS OR PACIFIER CORDS. DO NOT SUSPEND
STRINGS OVER A CRIB OR ATTACH STRINGS TO TOYS.
ΦΦ
ΦΦ
ΦREMOVE ALL CRIB TOYS WHICH ARE STRUNG ACROSS CRIB
AREA WHEN YOUR CHILD IS BEGINNING TO PUSH UP ON HANDS
AND KNEES OR IS 5 MONTHS OF AGE, WHICHEVER OCCURS
EARLIEST. THESE TOYS CAN CAUSE STRANGULATION.
ΦΦ
ΦΦ
ΦWHENDISASSEMBLINGTHISCRIB, DO NOTREMOVEANYITEM
ATTACHED WITH WOOD SCREWS.
ΦΦ
ΦΦ
ΦALWAYS ENSURE A SAFE ENVIRONMENT FOR THE CHILD BY
CHECKING REGULARLY, BEFORE PLACING THE CHILD IN THE
CRIB, THAT EVERY COMPONENT IS PROPERLY AND SECURELY
IN PLACE.
CCH02703:12/99
7CAUTION
ΦΦ
ΦΦ
ΦANY MATTRESS USED IN
THIS CRIB MUST BE AT
LEAST 27-1/4 INCHES (69
CENTIMETERS), BY 51-5/8
INCHES (131 CENTIME-
TERS), WITH A THICKNESS
NOT EXCEEDING 6 INCHES
(15 CENTIMETERS). THE
DIMENTIONS OF THE MATTRESS
SHALL BE TAKEN FROM SEAM TO
SEAMOREDGETO EDGEWHEREAP-
PROPRIATE.
ΦΦ
ΦΦ
ΦUPON COMPLETION OF
ASSEMBLY BE SURE ALL
SCREWS, BOLTS AND FAS-
TENING DEVICES HAVE
BEEN TIGHTENED SE-
CURELY. A FREQUENT
CHECK SHOULD BE MADE
OF ALL SCREWS, BOLTS
AND FASTENING DEVICES
AND TIGHTEN IF NEEDED.
CHILD CRAFT
INDUSTRIES, INC.
P.O. BOX 444
SALEM,IN47167-0444 USA
PH:812-883-3111
FAX:[phone]
http://www.childcraftind.com
CCH02703:12/99
JCHE.p65
MADE IN USA
English
▲
!
