Child Craft Universal Select F09402 User manual

1
AB20435A
AB20378_G1
Assembled 4 Drawer Chest
Foundations Worldwide, Inc.
5216 Portside Dr., Medina, OH 44256 USA • PH: 1 330.722.5033 • FAX: [phone]
www.childcraftbaby.com
Universal Select™ 4 Drawer Chest
ASSEMBLY ASSISTANCE
IMPORTANT: Retain for future reference and
read carefully.
Foundations strives for the highest quality in our
products but occasionally a missing part or
problem can occur during assembly. If any parts are
missing or broken or you need assistance with
assembly, DO NOT return the product to your
dealer. Go to our website at www.foundations.com
or call Foundations for assistance at
1-877-716-2757 (U.S. Only) or 1-330-722-5033
(Monday through Friday, 9:00 a.m.– 4:00 p.m.
Eastern Time). Please have the model number and
manufacture date available when you call or write
us at:
Foundations, 5216 Portside Dr., Medina, OH.
44256
KEEP INSTRUCTIONS FOR FUTURE USE .
FOR CUSTOMER SERVICE CALL
1-877-716-2757
(outside of U.S. 330-722-5033). DO NOT CALL
RETAILER OR RESELLER FOR SERVICE
AS THEY ARE NOT AUTHORIZED TO
RESOLVE ANY SERVICE ISSUES.
FOR WARRANTY AND FEDERAL SAFETY STANDARD
COMPLIANCE CERTIFICATES, PLEASE VISIT OUR
WEBSITE AT
www.foundations.com
Record the information for your product here:
Model number:
Manufacture date:
PO number:
• Adult assembly required.
• Read all instructions BEFORE assembly and USE
of product.
• Unpack carton, remove packing materials,
including polybag. Identify and check all parts.
ASSEMBLY INSTRUCTIONS
Model Covered: F09402

2
Hardware Package
AB20378_G3
T x 4
W x 3
DD x 8
U x 7
V x 24
X x 22 Y x 24 Z x 4
AA x 36 BB x 16
CC x 8 EE
Furniture Parts
PARTS LIST
PREPARATION
Carefully remove and lay out all hardware and parts.
Check quantities and match the parts list. Construct
furniture on an even at oor.
Note: during the assembly process whenever using
screws or bolts, check each with the parts list by letter
and size identication. Place each screw or bolt on the
diagram of the item which is sketched actual size. Be
sure to use the proper size specied in the assembly
directions. If any parts are missing or broken or you need
assistance with assembly, DO NOT return your product
to the dealer. Please identify the furniture by the model
number identication stamped on the assembly when
you call or write to Foundations. Make note of all
identification numbers and include this information with
your request.
DO NOT Substitute Parts!
SUGGESTED TOOLS
ABCD
EFG
KL
MNP
QRS
AB20378_G2
H
IJ
Part Description Part Number Qty.
A. Top 23102009 1
B. Left End Panel 23102010 1
C. Right End Panel 23102011 1
D. Back (Upper Back) 23102012 1
E. Back (Lower Back) 23102013 1
F. Top Front Rail 23102014 1
G. Front Rail 23102015 4
H. Base Assembly 23102016 1
I. Top Drawer Front 23102017 1
J. Top Drawer Side - Left 23102004 1
K. Drawer Bottom 23102018 4
L. Top Drawer Side - Right 23102005 1
M. Top Drawer Back 23102019 1
N. Drawer Support Rail 23102006 4
P. Lower Drawer Front 23102020 3
Q. Lower Drawer Side - Left 23102007 3
R. Lower Drawer Side - Right 23102008 3
S. Lower Drawer Back 23102021 3
T. Allen Head Bolt 6mm x 58mm 11201337 4
U. Lock Washer 11201191 7
V. Allen Head Bolt 6mm x 45mm 11201338 24
W. Allen Head Bolt 6mm x 25mm 11201339 3
X. Dowel Pin 8mm x 30mm 11201224 22
Y. Half Moon Connector 11201189 24
Z. Joint Connector Nut 11200330 4
AA. Flat Head Screw 11201226 36
BB. Dowel Pin 6mm x 20mm 11201193 16
CC. Drawer Knob 11201184 8
DD. Knob Machine Screw 11201194 8
EE. Allen Wrench 11201223 1
#2 Medium Striaght Screwdriver

3
STEP 1
AB20378_G4
F/G
B
FD
E
V x 9
Y x 9
X x 5
D x 1
E x 1
B x 1
G x 4
F x 1
X x 5
Y x 9
V x 9
G
x 3
x 5
STEP 2
AB20378_G5
C
C x 1
Y x 9
V x 9
X x 5
V x 9
Y x 9
X x 5

4
STEP 4
AB20378_G7
V x 3
W x 3
X x 8
Y x 3
U x 3
AA x 1
U x 3
W x 3
V x 3
Y x 3
X x 8
STEP 3
AB20378_G6
H
T x 4
U x 4
H x 1
X x 4
Z x 4
Y x 3
V x 3
T
U
U
T
X
Z
Z
Y x 3
V x 3
X

5
STEP 5
AB20378_G9
K
N
BB x 2
K x 1
N x 1
BB x 2
STEP 6
AB20378_G8
J
I
L
AA
AA
J x 1
Ix 1
L x 1
AA x 4

6
STEP 7
AB20378_G11
M
BB
AA
AA
AA
M x 1
AA x 5
BB x 2
STEP 8
AB20378_G12
CC
DD
DD x 2
CC x 2

7
AB20378_G13
AA
AA x 4
R x 1
P x 1
Q x 1
R
P
AA
Q
X3
STEP 10
AB20378_G14
BB x 2
K x 1
N x 1
BB
K
NX3
STEP 9

8
AB20378_G15
AA x 5
S x 1
BB x 2
AA
AA
AA
S
BB
X3
STEP 12
AB20378_G16
DD x 2
CC x 2
DD
CC
X3
STEP 11

9
STEP 13
AB20378_G17
WARNING
WARNING
Serious or fatal crushing injuries can occur from furniture tipover. To help prevent tipover:
•Install tipover restraint provided.
•Place heaviest items in the lower drawers.
•Do not set TVs or other heavy objects on the top of this product.
•Never allow children to climb or hang on drawers, doors, or shelves.
•Never open more than one drawer at a time.
Use of tipover restraints may only reduce, but not eliminate, the risk of tipover.

10
Maintenance Cleaning and Storage
MAINTENANCE:
Upon completion of the assembly, check to make sure all screws, bolts and connectors are tightened and
secure.
Periodically check funiture for damaged hardware, loose joints, missing parts or sharp edges before and
after assembly and frequently during use.
DO NOT use furniture if any parts are missing or broken.
If any parts are missing, broken or you need assistance DO NOT return furniture to your dealer.
Call Foundations at 330.722.5033 and include model identication numbers recorded on page 1.
DO NOT substitute parts.
CLEANING:
Mix a mild solution of gentle dishwashing soap and water, apply to surface using a clean cloth lightly
dampened in the solution. Rinse well with clear water using a soft clean cloth, then dry all surfaces with a
soft dry cloth.
DO NOT use abrasive cleaners or any cleaners with harsh chemicals that would contact a child’s
skin, scouring pads, steel wool or coarse rags. This furniture should be treated the same as any ne
furniture.
STORAGE:
When storing furniture use caution as extreme temperature or humidity changes could be harmful.
Use caution when a vaporizer is in use. Always aim vapor stream away from furniture as well as
away from any wood furniture item.
After completing the assembly the user is advised to read and be aware of
ALL WARNINGS, CAUTIONS, CLEANING, STORAGE USE AND MAINTENANCE. Please store the
complete set of assembly directions for future referral.
