Version Number: V2.0-EN 2014.03.06 Please note any change to the function and structure will not be advised
③
III. Dismounting Diagram
1. Take out the bracket 5 and install it
to the desired position
2. Take out the screws of the bottom
cover by screwdriver
3. Remove the outside shell
4. Solar power board
5. Outside shell shade
6. PCB board waterproof shade
IV. PCB Board and Wired Terminal
CODE button: ln standby status, press CODE
button for two seconds, the LED3 ond LED5
flash once,LED18 and LED19 turns on,and the
siren makes a beep sound. Then release the
button immediately. lt enters coding status.
This operation enables to code with wireless
sensors. (Please refer to Part five for details)
SPK+: Built-in siren positive (red wire)
SPK-: Built-in siren negative (black wire)
L-SPK+: Extra siren positive
L-SPK-: Extra siren negative
S-: Low voltage wired port
S+: High voltage wired port
POWER+: Power adaptor negative
POWER-: Power adaptor positive
Solar-: Solar power charging negative port
Solar+: Solar power charging positive port
Battery-: Built-in battery negative (black
wire)
Battery+: Built-in battery positive (red wire)
V. Operation as an Alarm Panel
1.Add Wireless Sensors
In standby status, press CODE button for two seconds,
then LED3 and LEDS flash once, LEDlB and LED19 turns
on, and the siren makes a beep sound. Then release the
button immediately. lt enters coding status. Trigger the
sensor you want to code. After receiving the wireless
signal from the sensor, the siren will make a beep which
indicates coding successfully. lf there,re two beeps, it
means the sensor has been coded before.
2.Exit Coding
ln coding status, press CODE button for 2 seconds until
all the LED flashes once and the siren makes a beep.
3.Delete Sensors
Keep pressing the CODE button, you will hear a beep;
keep pressing until you hear two beeps. After this
operation, all the sensors will be deleted.
Note: the default frequency of this siren is 31SMHz.
Please make sure all the sensors working together
should be this frequency.
Vl.Operation as a Wireless Flash Siren
Connect the transmitter with the alarm panel (if the panel
has built-in transmitter, you do not need to connect)
1.Press CODE button for two seconds until you see the
LED03 and LED05 flashes once, the LED18 and LED19
turns on, and the siren makes a beep. The siren enters
into coding status.
2.In coding status, press any button on the alarm system
panel (the panel should be in coding status, please refer
to the panel manual for details). The panel will emit
wireless signal. After receiving this signal, the siren will
make a beep which indicates coding successfully. lf
there'retwo beeps, it means the sensor has been
coded before.
3.The method of exiting coding status and deleting
is the same with the previous part (operation as an
alarm panel).
Vll.Usage Guidance
This siren can be connected with any alarm panel of our
company.
Stop alarming: The alarm sound lasts for 3 minutes
(default). lt can be stopped at any time by pressing the
disarm button on the remote controller oi the alarm
panel.
Vlll.Technical Parameters
Standby current: <10mA
Solar power recharging current: 155mA
External power supply :DC12V/1.2A
Recharging current: 310mA
Alarm current: 350mA
Wireless receivlng frequency: 315/433±0.5MHZ
Wireless receiving distance: >80M (no obstacle)
Working iemperature: +10℃~+40℃
Humidity: 90% (no fog)
