ENGLISH VERSION
1GENERAL INFORMATION
1.1 Purpose, content and target audience
This manual is intended to provide the necessary information to permit a proper use of the equipment
and to be able to use it independently and safely.
This manual contains information relating to the technical, operation, maintenance, spare parts and
safety. This book is also intended for technicians in charge of maintenance equipment.
This Instruction Booklet should always follow the equipment and must be carefully preserved in order
not to compromise its readability.
In case of transfer to third parties this manual has to be transmitted with other documents as required
by European Directive 93/42 EEC.
1.2 Manufacturer
CHINESPORT S.P.A, Via Croazia, 2-33100 Udine - Italy
tel. [phone]–fax[phone] –website: www.chinesport.com.
The company produces according to a quality system by standard UNI EN ISO 13485:2012.
1.3 Intended use and equipment description
Tables for use in static therapy for supine standing by gradually tilting the board. Movement assisted
by a low voltage electric motor or gas springs, depending on the version chosen.
The equipment comes complete with padded board, postural adjustments and accessories for patient
comfort and support. All models are easy to handle thanks to the swivel wheels, full brake and
directional lock provided for rectilinear movements.
1.4 Application Environment
Medical devices covered by this manual are in conformity according to attached VII of the directive
93/42/EEC amended by 2007/47/CE
In particular according to UNICEI EN60601-2-52:
ENVIRONMENTOF APPLICATION 5-outpatient care administered in a hospital or other medical
center under medical supervision, in which the EM devices are provided for the needs of sick people
who have suffered injuries or are carriers of disability, for the treatment, diagnosis and monitoring.
1.5 Products insights
Further documentation can be found on our website www.chinesport.com.
Specially, you can read the QR code on the cover of this manual to quickly connect to the website.
Where provided QR code can also be found on the product.
You can download the declaration of conformity and other product documents in their latest version
and in color format directly from the website.
1.6 Storage
The following conditions must be ensured when the equipment is to be stored:
1. Environmental –relative humidity 10% / 90 % - temperature -10°C / +50°C.
2. Recharge batteries at least every six months (see “Recharging the equipment’s batteries” –
battery models only).
1.7 Symbols
The symbols found in this manual and on the machine are used to draw the user’s attention to
important safety warnings and useful information. Observe all warning, caution and danger
messages.

CHINESPORT Spa - ITALIA
mod.14-2014.03.17-14.30-001-ml.docx 5/ 44
GB
WARNING
This symbol identifies operating/maintenance instructions or procedures which, if not
observed, could result in injury or danger to the user.
ELECTRIC SHOCK HAZARD
This symbol identifies operating/maintenance instructions or procedures which, if not
observed, could result in a risk of electric shock.
CAUTION
This symbol is used to warn the user that not to observe a certain operating or
maintenance procedure, general rule or condition, could result in damage to the
equipment.
2SPECIAL WARNINGS AND USE RESTRICTIONS
This equipment must not be used:
by inadequately trained operators;
when having been tampered with and/or if the original product has undergone
changes;
on unstable and/or uneven surfaces (e.g.: stairway, steps, etc.);
with a patient inadequately secured to the supporting straps and footboards;
with loads greater than those declared to be safe by the manufacturer;
in an improper configuration or when it is thought to be harmful for the patient;
in association with other devices that may interfere with the equipment;
in an explosive and/or corrosive atmosphere or exposed weather conditions.
In addition:
Keep body parts away from moving parts and/or adjustments. These areas are
marked by labels.
Three, four or more people are required to carry the equipment.
Set the bed in its lower and horizontal position when it is not supervised.
Do not connect to an electric system that does not comply with the
current safety regulations.
Disconnect power supply before moving and carrying out any service on
the equipment circuits.
Pull out the plug (not the cable) to disconnect the power supply and/or
battery charger.
Make sure that the patient cannot accidentally operate the controls.
Make sure that during equipment operation any moving parts do not knock against
adjacent masses.
Keep a proper distance from moving mechanical parts.
Before operating the release levers of the sections, make sure their weight can be
supported.
Do not let the equipment come in touch with open flames.
Protect the padding in treatments involving heat sources.
Periodically disinfect the table’s leatherette.
Do not spill any liquids over the equipment.
Record any significant safety-related intervention/defect/damage in the attached
form.
For operations not covered in the maintenance list, please contact Chinesport
Service Centre.
Only the manufacturer can repair the actuators, gearcases, controls and battery
chargers, which on no account must be opened or tampered with. Otherwise the
manufacturer will be no longer responsible for the equipment, whose warranty will
cease to be valid.
When safety is clearly in danger, immediately switch off the equipment and do not
use it until the danger has been eliminated.

CHINESPORT Spa - ITALIA
6/ 44 mod.14-2014.03.17-14.30-001-ml.docx
GB
2.1 Emergency functions
2.1.1 Emergency stop
All battery-powered versions have a mushroom pushbutton on the gearcase to stop in case of an
emergency.
2.1.2 Electrical emergency lowering
All battery-powered versions can enable lowering in case of handswitch and / or gearcase failure.
2.1.3 Mechanical emergency descent
The “Plus” versions type-approved up to 180kg are designed to allow the manual lowering from
verticalization in case of failure.
2.1.4 Anti-crushing
The “Plus” versions type-approved up to 180kg stop lowering from verticalization when a foreign body
hinders movement.
2.1.5 Improper use
The LT2 version (two motors) have limit switches that prevent the board “verticalization / lifting” if it is
“not at the minimum height” / “not in horizontal position”.
2.1.6 Braking wheels
All versions have 3 independent wheels complete with parking brake.
WARNING
WHEN THE EQUIPMENT IS NOT IN USE, PRESS THE EMERGENCY STOP PUSHBUTTON TO SAVE THE BATTERY CHARGE
THE SAFETY LIMIT SWITCHES MUST NOT BE TAMPERED WITH OR OPERATED MANUALLY
LT1B- LT2B
LT PLUS
LT2
Emergency stop: press the
mushrooom pushbutton to
enable, rotate to stop.
Electric emergency lowering:
to enable, press the small
pushbutton with a pointed
object.
Lever for manual
repositioning.
Pull and bring the board down
to the horizontal position.
The “clutched movement”
function during lowering
protects against crushing.
Safety pushbuttons to control
verticalization and lifting.
This automatic device must
not be touched or tampered
with.
2.2 Collateral effects and contraindications
There is no collateral effects or contraindications during proper use, is recommended knowledge of
this instruction manual.

CHINESPORT Spa - ITALIA
mod.14-2014.03.17-14.30-001-ml.docx 7/ 44
GB
3CONFIGURATED ITEM CODE
Product code
L
T
1
*
*
*
*
*
*
L
T
2
*
*
*
*
*
*
L
T
3
*
*
*
*
*
*
Variable code position
1
2
3
4
5
6
7
8
9
Position
Meaning variable code
Possible values
1-2
Fixed value
3
TYPE OF ADJUSTEMENT
1no height adjustement
2electric height adjustement
3servo-assisted tilt adjustment with gas spring
4
TYPE OF SUPPLY
E AC Power Supply
BPower supply with rechargeable batteries
GServo-assisted by gas springs
5
MAXIMUM LOAD
1Normal version - max weight 140 kg
2Plus version –max weight 180 kg
6
SECTIONS NUMBER –POSITION
TYPE
1three section table (without head) for static exercise in supine pos.
2four section table (with head) for static exercise in supine pos.a
3one ection table for static exercise in supine pos.
4 four section table for static exercise in prone pos.
7
FIXED VALUE
8
FINISHING PADDING
W
9
COLOR SETUP
REFERENCE TO CATALOGUE
4USE
4.1 Unpacking
The product is consigned already assembled. And then simply remove it from the package and
proceed as provided in the following paragraphs.
4.2 Starting
The bed is delivered packaged to protect it from possible damage that may occur during transport.
Never use cutters to open box to prevent padding damages
After unpacking, remove the protective packaging materials. See chapter “Disposal of waste electrical
or electronic equipment and packaging” for disposal instructions. The carrier and the supplier must be
immediately notified of any damage that may have occurred during transport. Damaged equipment
cannot be used.
4.2.1 Electric models
The table is supplied with the footboards upside-down. Before using the equipment, bring the
footboards in working position by operating the spring plunger. The motorized versions must be
properly connected to the mains, while the models powered by a removable battery must be fully
recharged before use; see the relevant chapter.
WARNING
DUE TO ITS WEIGHT, MORE PEOPLE ARE REQUIRED TO TRANSFER AND SET THE EQUIPMENT UP FOR USE.
VERTICALIZATION MUST BE PERFORMED ONLY AFTER PLACING THE FOOTBOARDS IN THE APPROPRIATE POSITION.

CHINESPORT Spa - ITALIA
8/ 44 mod.14-2014.03.17-14.30-001-ml.docx
GB
PULL THE SPRING PLUNGER AND REVERSE THE
FOOTBOARDS IN WORKING POSITION
FOOTBOARDS IN WORKING POSITION
4.2.2 LT3G33 gas model
The table is supplied with the footboard upside-down. Before using it, bring the footboard in working
position as follows:
PULL OUT THE FOOTBOARD BY UNSCREWING
THE TWO LOCKING SCREWS WITH THE KEY
SUPPLIED.
PLACE THE FOOTBOARD IN THE CORRECT
POSITION AND LOCK IT BY FIRMLY TIGHTENING
THE SCREWS.
4.3 Tilt adjustment
4.3.1 Electric models
The worktop can be electrically adjusted from 0° to 85° by using the handswitch. For safety reasons,
the LT2B12 and LT2E12 table versions allows static verticalization only with the board at the lowest
height from the floor.
WARNING
MAKE SURE THAT THE PATIENT IS ADEQUATELY SECURED TO THE SUPPORTING STRAPS AND FOOTBOARDS
MAKE SURE THAT DURING EQUIPMENT OPERATION ANY MOVING PARTS DO NOT KNOCK AGAINST ADJACENT MASSES
MAKE SURE THAT THE PATIENT CANNOT ACCIDENTALLY OPERATE THE CONTROLS
KEEP A PROPER DISTANCE FROM MOVING MECHANICAL PARTS
DO NOT KEEP YOUR FEET UNDER THE FOOTBOARDS

CHINESPORT Spa - ITALIA
mod.14-2014.03.17-14.30-001-ml.docx 9/ 44
GB
LT1
LT2
HANDSWITCH FOR TILT
ADJUSTMENT
PUSHBUTTONS FOR TILT
ADJUSTMENT
FOR SAFETY REASONS,
VERTICALIZATION IS POSSIBLE
ONLY IF THE TABLE IS AT
MINIMUM HEIGHT.
4.3.2 LT3G33 gas model
This model allows the worktop to be tilted manually via a servo-system operating with gas springs.
WARNING
MAKE SURE THAT THE PATIENT IS ADEQUATELY SECURED TO THE SUPPORTING STRAPS AND FOOTBOARDS
MAKE SURE THAT DURING EQUIPMENT OPERATION ANY MOVING PARTS DO NOT KNOCK AGAINST ADJACENT PEOPLE
OR MASSES
AVOID OPERATING THE TILT CONTROL WITHOUT THE PATIENT ON THE TABLE SO THAT THE REPOSITIONING OF THE
UNLOADED BOARD IS LESS DIFFICULT. IN CASE OF NEED, EXERT A PRESSURE ON THE END OF THE BOARD TO APPLY
THE GREATEST LEVER POSSIBILE
Hold in your hands the handle
indicated, simultaneously press the
gas spring control lever and
gradually tilt the board.
Stop at the desired tilt angle and
release the lever to lock it in place.
To reach the maximum tilt, the front
wheels must be aligned.
To carry out the reverse operation,
apply a lever with your foot as well.
4.4 Height adjustment
The LT2B12 and LTE12 versions also allows the board height from the floor to be electrically adjusted
so as to make patient transfers and / or examinations and manipulation therapy easier.
For safety reasons, height adjustment is possible only with the table board in horizontal position.
WARNING
KEEP A PROPER DISTANCE FROM MOVING MECHANICAL PARTS.
MAKE SURE THAT DURING EQUIPMENT OPERATION ANY MOVING PARTS DO NOT KNOCK AGAINST ADJACENT MASSES.
MAKE SURE THAT THE PATIENT CANNOT ACCIDENTALLY OPERATE THE CONTROLS

CHINESPORT Spa - ITALIA
10 / 44 mod.14-2014.03.17-14.30-001-ml.docx
GB
PUSHBUTTONS FOR HEIGHT ADJUSTMENT.
FOR SAFETY REASONS, HEIGHT ADJUSTMENT IS
POSSIBLE ONLY WITH THE TABLE BOARD IN
HORIZONTAL POSITION.
4.5 Head, footboard and strap adjustment
The versions fitted with a head section can be tilted from -20° to +80° by gas spring.
The electric versions have split wooden footboards that can be independently adjusted from -20° to
+20°; in case of need, they can be folded up completely for comfort of the therapist.
WARNING
DO NOT SIT AND DO NOT CONCENTRATE THE LOAD ON THE HEAD SECTION
DO NOT VERTICALIZE THE BOARD WHEN THE FOOTBOARDS ARE TURNED UPSIDE-DOWN TOWARDS THE WHEELS
DO NOT ADJUST THE FOOTBOARDS WITH THE PATIENT FULLY LOADED. IN CASE OF NEED, CHOOSE A TILT ANGLE THAT
IS MORE COMFORTABLE FOR YOU
KEEP AWAY FROM THE MOVING FOOTBOARDS, DO NOT KEEP YOUR FEET UNDER THEM
MANUAL HEAD ADJUSTMENT
TILTING FOOTBOARD
ADJUSTMENT (except for LT3)
STRAP ADJUSTMENT
Pull the lever up and bring the section
to the position desired.
Pull the spring plunger and
reposition it into the appropriate
hole.
Each snap corresponds to 10°.
The straps are essential for safe
verticalization. They must be slipped
into the two lateral loops and the
central loop for a snugger fit and
greater restraint.

CHINESPORT Spa - ITALIA
mod.14-2014.03.17-14.30-001-ml.docx 11 / 44
GB
4.6 Adjusting sections and main dimensions
MODEL
DIMENSIONS SINGLE PLATFORM
OPERATING ADJUSTMENT
LT1E11
LT1E21
LT1B11
LT1B21
LT1E12
LT1E22
LT1B12
LT1B22
LT2B12
LT2E12
LT3G33
LT1E14
LT1B14
WARNING
DO NOT SIT AND DO NOT CONCENTRATE THE LOAD ON THE ENDS OF THE TABLE, ESPECIALLY ON THE HEAD SECTION
85°

CHINESPORT Spa - ITALIA
12 / 44 mod.14-2014.03.17-14.30-001-ml.docx
GB
4.7 Battery installation (only B versions)
BATTERY RELEASE: pull the release handle and remove the battery.
BATTERY PLACEMENT: place the battery lengthwise on the steel slides.
WARNING
MAKE SURE THAT THE BATTERY FITS SNUGLY INTO ITS SEAT –YOU WILL HEAR A “CLICK” WHEN IT IS IN PLACE
4.8 Charging batteries (only B versions)
When the batteries are flat, you will hear a “low battery warning”
during use; you will need to recharge the batteries as follows:
Release the battery from the bracket of the gearcase –22- by pulling
the release handle –25-and the battery -21-upwards. Connect the
battery charger -23-to the mains.
Connect to the battery by inserting the recharging pin -20- into the
appropriate socket.
When charging is completed, after 8 hours approx., attach the battery
again to the gearcase unit
on the lift.
Battery life can be
significantly extended if
you avoid discharging the
batteries completely.
We recommend you buy
a spare battery for
continued table efficiency.
The battery charger
automatically adapts to a
voltage / frequency range of 100-240V~ / 50-60Hz. It can also be used in different countries as it can
be adapted to different power sockets through a set of replaceable PLUGS (optional).
The battery charger is equipped with an automatic safety limiting system.
The batteries don’t need maintenance (only recharging).
WARNING
CHECK THAT THE MAINS VOLTAGE MATCHES THE VOLTAGE SPECIFIED IN THE BATTERY CHARGER SPECIFICATIONS
DO NOT CONNECT TO AN ELECTRIC SYSTEM WHICH IS NOT COMPLIANT WITH THE RELATED REGULATIONS
ONLY USE THE BATTERY CHARGER SUPPLIED
BATTERIES CAN GO FLAT IF NOT USED FOR A LONG PERIOD OF TIME
REPLACE THE BATTERIES WITH BATTERIES OF THE SAME TYPE AND CHARACTERISTICS; DISPOSE OF THE BATTERIES
AT AUTHORIZED COLLECTION POINTS ONLY, INDICATED BY THE OFFICIAL RECYCLING ASSOCIATION FOR SPENT LEAD
BATTERIES AND LEAD WASTE (COBAT, ITALY), TOLL FREE NUMBER 800-869120
MANIGLIA DI
SGANCIO
RELEASE
HANDLE
26
22
28
27
29
21
23
25
24
INDICATOR
PLUG

CHINESPORT Spa - ITALIA
mod.14-2014.03.17-14.30-001-ml.docx 13 / 44
GB
4.9 Transport, brakes and locks
All the tables have swivel casters that allow movement in small environments; one wheel is also
equipped with a “directional lock” mechanism that makes rectilinear movements easier, while the
others come with a full parking brake (to prevent sliding and rotation).
WARNING
APPLYING THE PARKING BRAKES PREVENTS UNINTENTIONAL MOVEMENTS AND STABILISES THE TABLE DURING
PATIENT TRANSFERS AND TREATMENTS
THE DIRECTIONAL LOCK HAS NO BRAKING EFFECT. APPLY THE PARKING BRAKES TO PREVENT THE TABLE FROM
MOVING
BRAKES AND LOCKS
LT3G33
Foot-operated wheel control.
Grey lever down: parking brake ON (prevents the
wheels from rotating and swiveling)
Blue lever down: directional lock ON. When
pushing the table, the wheel will position itself on
the feed axis, putting on the directional lock.
To carry this model with the board on a static vertical
plane, reduce tilt to a degree that allows the wheels to
freely move.
5MAINTENANCE
Only qualified personnel may carry out maintenance on the equipment. Technicians must be familiar
with the model, use and maintenance of the equipment.
Check the equipment whenever it has undergone a "rough treatment" (e.g.: fall, liquid spill, etc.) and
whenever any doubts arise concerning its safety.
5.1 Routine maintenance
Regular maintenance must be carried out at least once every 12 months, following the table below:
WARNING
WHEN SAFETY IS AT RISK, IMMEDIATELY TURN OFF THE EQUIPMENT AND DO NOT USE IT UNTIL THE DANGER HAS BEEN
ELIMINATED
ANY SIGNIFICANT WORK CARRIED OUT TO ENSURE THE COUCH IS SAFE FOR USE MUST BE RECORDED IN THE RELEVANT
FORM (ATTACHED)

CHINESPORT Spa - ITALIA
14 / 44 mod.14-2014.03.17-14.30-001-ml.docx
GB
FREQUENCY
OPERATION
Yearly
General cleaning of the equipment
Visual and functional inspection of the equipment
Frame and mechanical parts: check screws and bolts to ensure they are tight; pin
and bushing clearance; check for any damage or deformation
Check that the adjustable sections are stable and do not collapse when the control
lever is released
Check spring control cables and respective sheaths
Check the wheels are firmly secured and free to rotate; clean the tread
Check control box, actuators and controls to see if connectors are fully plugged in
(electric versions)
Check insulation o electrical cables for damage (electric versions)
Make sure that during electric operation no unusual vibrations or sounds are
produced that may signal defects in the actuators and/ or mechanisms.
AFTER THE ABOVE OPERATIONS, COMPLETE INSPECTION BY CARRYING OUT A FULL
LIFTING CYCLE USING THE MAXIMUM SAFETY WORKING LOAD.
WARNING
FOR OPERATIONS NOT COVERED IN THE MAINTENANCE LIST, PLEASE CONTACT CHINESPORT SERVICE CENTRE
ONLY THE MANUFACTURER CAN REPAIR THE ACTUATORS, GEARCASES, CONTROLS AND BATTERY CHARGERS, WHICH
ON NO ACCOUNT MUST BE OPENED OR TAMPERED WITH. OTHERWISE THE MANUFACTER WILL BE NO LONGER
RESPONSIBLE FOR THE EQUIPMENT, WHOSE WARRANTY WILL CEASE TO BE VALID
5.2 Non-routine maintenance
The extraordinary maintenance must be performed by skilled technicians with knowledge of the
contents of this instruction booklet.
Contact Chinesport service for all operations not mentioned in the maintenance list.
5.3 Preventive or planned maintenance
It’s recommended a complete overhaul of the equipment every 3 years, performed by Chinesport or
by an authorized service center
5.4 Spare Parts List
Please contact Chinesport or an authorized service center to request the updated spare parts list.

CHINESPORT Spa - ITALIA
mod.14-2014.03.17-14.30-001-ml.docx 15 / 44
GB
6TROUBLESHOOTING
The equipment has undergone heavy-duty tests; no significant breaks and/or failures were reported. If
the equipment does not work, refer to the troubleshooting table below.
Problem
Cause
Solution
VERTICALIZATION –LIFTING
(electric version)
Verticalization not working
Lift not working (LT2)
Connectors disconnected or improperly
plugged in
Check the connections
Overload shutdown
Do not exceed maximum capacity
No power
Check the connection to the mains/power
voltage
Flat battery
Use the battery charger supplied
Emergency button ON
Rotate the emergency button to disable it
Handswitch –Footswicth actuator failure
Replace
Main protection fuse burnt out
Contact the service centre
Verticalization actuator or gearcase or
handswitch not working
Contact the service centre
In LT2 model the board or the table
lifting unit are not in the position
recommended for a safe use
See the section 4.3.1 in this booklet
VERTICALIZATION
(gas version)
Verticalization not working
Gas springs not working or out of
calibration
Contact the service centre
Control or cables faulty or out of
calibration
In case the troubleshooting table does not solve your fail, you can open a service ticket means website
www.chinesport.com customer service section.
ATTENTION:
Before calling our technical support, be sure to have your SERIAL NUMBER or the “Code”and “Article”
to hand: you can find it on the product label located on the equipment (as shown in the facsimile below);
or the transport document / invoice number. This identification number helps reduce waiting times and
improves service quality.
NOTE:
The equipment in need of repair at Chinesport premises must carry the “AUTHORIZATION
NUMBER” on the package. This identification number, to be required from the Technical
Assistance Service, helps reduce waiting times and improves service quality.
Alternatively, you can contact the technical support by email ([e-mail]), for
users without internet connection it’s possible to send a fax [phone]) or phone [phone]
699), but the timing of response could be longer.
SERIAL NUMBER

CHINESPORT Spa - ITALIA
16 / 44 mod.14-2014.03.17-14.30-001-ml.docx
GB
7CLEANING AND DISINFECTION
Electrical equipment must be disconnected from mains power before cleaning.
Sky is the flame retardant fabric made for residential and contract upholstery. Its resistant structure
and the easy cleaning make sky particularly suitable for hospitals, nursing homes, spas, rehabilitation
centers and gyms. Sky has a leather-effect surface with a brilliant finishing, in a wide range of colors
all available on stock. Sky contains Vinyzene, an anti-microbial agent added in the first steps of
production process. This creates a defensive barrier against mites, bacteria and fungus, avoiding
smells and allergies.
7.1 Washing
Dust gently and in case of light stains pass the surface with a damp cloth or a neutral detergent, rinse
with water without squeezing. Let the fabric dry avoiding direct exposure to the sunlight. The following
instructions are recommended for small located and more obstinate stains (oil, fat, cosmetics, ink,
coffee, liquor, chewing-gum etc.):
dissolve immediately with clear ethylic
alcohol diluted in water to 20%, dab and
then treat with a neutral detergent
solution. Rinse abundantly.
7.2 Disinfection
It is recommended to use AMUCHINA® 10% or equivalent with sodium hypochlorite at 0,1% for the
disinfection of equipment, specially sky, handcontrol, frames, etc with following action spectrum:
bactericidal in the presence of interfering substances according to EN 1276:1997;
fungicide in the presence of interfering substances according to EN 1650:1997;
battericidal test according EN 13697:2001;
fungicide test according EN 13697:2001;
active on Salmonella tiphymurium according EN 13697:2001;
active on HIV, HAV - HBV, HCV;
virucidal according EN14476:2005;
virucidal influenza H1N1 according EN14476:2005.
Before use is recommended to read specific flyer.
WARNING
REGULARLY DISINFECT THE SYNTHETIC LEATHER AND USE DISPOSABLE PAPER ROLL TO KEEP THE COUCH CLEAN
AGGRESSIVE PRODUCTS CAN DAMAGE SURFACES
BEFORE USING THE EQUIPMENT CHECK THAT ALL COMPONENTS ARE COMPLETELY DRY
TO AVOID PERMANENT STAINS, THE LIGHTER COLORS OF THE ARTICLE SHOULD NOT BE BROUGHT INTO CONTACT WITH
TEXTILES AND CLOTHING COLORED WITH UNFIXED DYES. WE CANNOT GUARANTEE THE ABILITY TO REMOVE UNKNOWN
DYES FROM LIGHT COLORED PRODUCT
8REUSE OF THE PRODUCT
These products have been designed so as to be suitable for reuse by another user after execution of
some works and the overcoming of controls for its release.
To prepare the products at re-use by another user must be done the following:
cleaning and disinfection carefully with adequate means;
maintenance according to the maintenance plan and control;
granting permission for reuse, which must accompany the product.
The above transactions must be carried out by the manufacturer or authorized dealer.

CHINESPORT Spa - ITALIA
mod.14-2014.03.17-14.30-001-ml.docx 17 / 44
GB
9TECHNICAL SHEET
LT1E11
LT1E21
LT1E12
LT1E22
LT2E12
LT1E14
LT1B11
LT1B21
LT1B12
LT1B22
LT2B12
LT1B14
LT2G33
Number of sections
3
3
4
4
4
4
3
3
4
4
4
4
1
Weight (kg)
65
65
65
65
100
65
65
65
65
65
100
65
60
Safe working load (kg)
140
180
140
180
140
140
140
180
140
180
140
140
120
Height table
fixed or adjustable (cm)
56
56
56
56
56-106
56
56
56
56
56
56-106
60
85
IP protection
IP 54
IP 43
-
Elecrtical safety
Class 2
internal supply 24V/max 10AT
-
Power supply
220 V 50 Hz / 24 V 70 VA
Battery charger 110/220V –50/60 Hz –
500 mA
-
Part applied type
B
Max user height (cm)
200
190
200
190
200
Use
temporary: 10% 2’ minutes max work/18 pause
continous
Upholstery / Padding fabric
See catalogue / 1IM Class
Castors
Wide-diameter, twinned, with one direction castor

CHINESPORT Spa - ITALIA
18 / 44 mod.14-2014.03.17-14.30-001-ml.docx
GB
10 ELECTRIC DIAGRAM
Main power
control
Connection cable
motor-CB
Mechanical
connection screw
motor-frame
motor
CB
(control box)
Lock
screw
motor-CB
Mechanical
connection screw
motor-frame

CHINESPORT Spa - ITALIA
mod.14-2014.03.17-14.30-001-ml.docx 19 / 44
GB
11 RELATED ITEMS AND ACCESSORIES
When installing the accessories for the first time, unscrew the upper fixing
screw to remove the lateral sliding rods in order to insert the adjusting “box-
like” elements.
AC0081 TABLE TRAY
Maximum load allowed: 30 Kg
Attach the wooden table tray to the adjusting rods with
the screws supplied.
The levers can be operated to adjust the table tray for:
height adjustment
depth adjustment
tilt adjustment
AC0001 TABLE TRAY with padding patient side
Maximum load allowed: 30 Kg
As AC0081 but with padding patient side
Attach the wooden table tray to the adjusting rods with
the screws supplied.
The levers can be operated to adjust the table tray for:
height adjustment
depth adjustment
tilt adjustment
WARNING
DO NOT USE THE TABLE TRAY AS THE ONLY WAY TO RESTRAIN THE PATIENT, ALWAYS USE THE STRAPS AS WELL

CHINESPORT Spa - ITALIA
20 / 44 mod.14-2014.03.17-14.30-001-ml.docx
GB
AC0002 INTRA-EXTRA SANDALS
Attachment to the adjustable footboards.
Place the “T”-plug inside the lateral slot of the
footboard, adjust the sandal and lock with the lever
(press downwards and simultaneously rotate).
Attachment to the fixed footboard.
Place the “T”-plug into the central hole of the
footboard, adjust the sandal and lock with the lever
(press downwards and simultaneously rotate).
AC0003 - TRUNK SUPPORTS
AC0004 - FOREARM SUPPORTS
AC0005 - STRAP
Maximum load allowed:
Kg.45 on each support
Maximum load allowed:
Kg.45 on each support
AC0006 - STRAP PILLOW
12277 - BREATHING HOLE PLUG
01132 - SPARE BATTERY
(battery-powered versions only)
AC0309 TABLE SERVICE -
STATIC PRONO
(only models LT1E14 and LT1B14)
AC0310 SECTION FOR STATIC
SUPINE
(only models LT1E14 and LT1B14)
AC0311 LEGSRETRACTOR
(only models LT1E14 and
LT1B14)
AC0312 FIXING BAND GUIDE
(only models LT1E14 and LT1B14)
AC0087 CUSHION FOR HEAD
RESTRAINMENT
AC0560 TRUNK STRAPS
(2 pieces)
