AESCULAP®3D EinsteinVision® 3.0
Quick System Guide
32” 3D
Monitor
21” 2D
Monitor
Keyboard
50L Insufflator
LED Light Source
3D / 2D CCU
Digital Documentation
3D Scope / Camera Holder
2D Camera Holder
CO2
Gas Cylinder
Storage
A4 Thermal Sublimation
Printer

AESCULAP®3D EinsteinVision® 3.0
System Set Up
Pre Surgery Preparation
•Switch on central power supply, at back of the stack (1)
•Ensure individual component switches are on (bottom left corner of each unit) :
- Insufflator, Light Source, CCU, Digital Documentation (2)
(On status is indicated by green light and user interfaces will be illuminated, or display menu options)
•Ensure 32” 3D monitor is switched on (Right side of monitor, underneath) (3)
•Ensure 21” touch screen monitor is on
(Circular push/rotate switch on right side of 21” monitor. At the bottom of the monitor) (4)
•Plug in integrated 3D light lead (5) [if using 3D scope]
•Plug in 3D camera head (6) [if using 3D scope]
•Set Insufflator to desired pressure (7) and flow rate (8)
•
(1)
(2)
(3)
(4)
Start of procedure
•Apply sterile sleeve to 3D Endoscope
•Plug in light lead (5)[if using standard 2D scope]
•Plug in 2D camera (6) [if using standard 2D scope]
•Attach standard endoscope [if using standard 2D scope]
•Press light source control to activate (9)
(5)
(7)
(9)
(12)
•White balance camera head (3D or 2D*) (11)
•Start insufflator to commence insufflation (12)
* Attach scope with light lead, if
using standard camera head, prior
to White balance
•Adjust light level (rotate Rt / Lt to increase / decrease) (10)
(10)
(11)
(8)
(6)

AESCULAP®3D EinsteinVision® 3.0
Flow 50 Insufflator
•On start-up - First screen offers surgical specialties
•Select appropriate “Indication” - followed by ”Veress” or “High Flow” to move to main screen.
(Cardiac mode has 2 functions - “Vessel Harvesting” or “Field Flooding” (Field flooding is flow only)
•Pre-set pressure can be set up to 30 mmHg
Nb. 15 mmHg is set as the Safety Threshold “Safety Threshold” will flash repeatedly
Press +when the safety threshold message has gone off, to take pressure beyond 15 mmHg
•Press and hold the Flow +or –buttons to go between “Low Flow”, Medium Flow” and “High Flow”
Low Flow = 3 L/min Medium Flow = 20 L/min High Flow = 40 L/min
•Insufflation is started and stopped using the “Start” button (Bottom Right)
(When insufflation is active, button displays “Stop”. Insufflation is stopped by pressing “Stop”
•CO2volume delivered is reset by pressing the reset button
Optional Smoke
Evacuation Filter
Housing
Active Smoke Evacuation
Actual
Actual
Volume
& Reset
System Settings
Insufflation
Gas Outlet
Heated Gas
Element
(Optional)
Start / Stop
Insufflation
Smoke Evacuation
Footswitch
(Optional)
Pressure & Flow
Pre-sets
On / Off

AESCULAP®3D EinsteinVision® 3.0
LED Light Source
On / Off
On / Standby
(Push)
Increase / Decrease
(Rotate)
Optional Light
Lead Tester
Display Window
Light
Aperture
Push light lead firmly into light aperture
(Do not rotate cable release)
Rotate clockwise to increase light output
Press light source control to
activate / Deactivate light output
Rotate anti-clockwise to decrease light output
Rotate cable release clockwise and pull
light lead, to remove from light source
Light source illuminates with green ring around the rotation switch when activated (On)

AESCULAP®3D EinsteinVision® 3.0
2D/3DCamera Control Unit (CCU)
Camera Port
White Balance
Camera Controls
Camera Control Buttons
replicate the remote buttons on the camera
heads
Buttons can be programmed in camera
profile settings
CCU buttons always replicate, exactly the
same configuration of the respective
camera heads
Camera White Balance can be performed from camera
head remote button (Rt) or from CCU WB button
Camera head button : Long press white button (> 2sec)
CCU WB Button : Short press (< 2sec)
Long press of CCU white (Rt) CCU control button can also be
used to white balance (same as camera head)
3D camera head and standard 2D camera head are
easily located into CCU camera portal
Camera heads can be hot plugged, swapping
seamlessly between the different camera types,
and without the need to make any system changes,
or monitor changes

AESCULAP®3D EinsteinVision® 3.0
2D/3DCamera Heads
3D Integrated Camera Head : Button Configuration
2D Camera Head : Button Configuration

AESCULAP®3D EinsteinVision® 3.0
32” 3D Monitor
•32” monitor delivers 3D images and 2D images, according to the signal sent to it, without
any need to change any settings on the monitor itself
•There is no need to make any changes to the monitor
•DO NOT MAKE ANY CHANGES TO THE MONITOR SETTINGS
There is a 3D/2D button on the monitor : DO NOT USE THIS BUTTON to swap between 3D and 2D
•Using the 3D/2D button on the monitor to select 2D
effectively renders the monitor a 2D only monitor,
and regardless what you do on the CCU or the
camera head, it will not be possible to view 3D images
on the monitor
ONLY USE THE CAMERA HEAD TO SWAP BETWEEN 3D And 2D
DO NOT MAKE ANY CHANGES TO THE MONITOR SETTINGS !!
