Chipolino "PIXIE L User manual

This stroller is manufactured according to
the requirements of the Product Safety Directive 2001/95/EU of
the European Parliament and The Council and with European
standard EN 1888-1:2018+A1:2022 Child use and care articles. Wheeled
child conveyances. Part 1: Pushchairs and prams, EN 1888-2:2018
+A1:2022 “Child care articles. Wheeled child conveyances.
Part 2: Baby strollers from 15 up to 22 kg, as well as the National
Consumer Protection Law and national legislation.
IMPORTANT! READ CAREFULLY AND KEEP
THIS USER’S MANUAL IN A SAFE PLACE
FOR FUTURE REFERENCE!
INSTRUCTION MANUAL FOR
BABY STROLLER “PIXIE”

1
FOLLOW ALL WARNINGS, INSTRUCTIONS AND
RECOMMENDATIONS IN THIS MANUAL IN ORDER
TO GUARANTEE THE SAFE USE OF THIS PRODUCT!
WARNING! NEVER LEAVE YOUR CHILD UNATTENDED!
WARNING! THE SEAT OF THIS STROLLER IS NOT SUITABLE FOR
CHILDREN AGED LESS THAN 6 MONTHS!
WARNING! ALWAYS USE THE RESTRAINT SYSTEM (SAFETY BELTS)!
WARNING! MAKE SURE YOUR CHILD IS AT SAFE DISTANCE AWAY FROM
THE STROLLER DURING ADJUSTMENTS, FOLDING OR UNFOLDING OF
THE STROLLER.
WARNING! MAKE SURE THAT ALL LOCKING MECHANISMS ARE ENGAGED
BEFORE USE.
WARNING! BEFORE EACH USE, CHECK THE STABILITY OF FIXING OF
SEPARATE PARTS!
WARNING! DO NOT ALLOW YOUR CHILDREN TO PLAY WITH
THE STROLLER!
WARNING! THIS PRODUCT IS NOT SUITABLE FOR RUNNING OR
SKATING!
DO NOT LIFT THE STROLLER BY THE FRONT BAR, BECAUSE THIS CAN
LEAD TO SERIOUS INJURIES!
KEEP AWAY FROM FIRE!
Use the stroller for a child weighing not more than 22 kg.
Initial assembly, folding and unfolding to be done only by adult!
Always engage the parking device when the stroller has stopped and is not
moving, especially when you place or take out your child from it!
 Makesurethesafetybeltsarefastenedandtwelltothechildbeforeusage.
The maximum load for the storage basket is 2 kg.
The maximum load for the accessory bag (if case there is one) is 1 kg.
Do not overload the stroller! Always balance your stroller in a way to keep
it stable and prevent the risk of tip-over!
Stroller is intended for use for one child at a time!
Do not use any spare parts or other components, which are not approved by
the producer! The producer does not take any responsibility for the safety of the
child when you have not used the proper and original spare parts, approved and
provided by the producer!
CAUTION! WARNINGS!

2
PRODUCT FEATURES
Stroller is suitable for children aged from 6 months up to 4 years or weighing
 upto22kg.(whichevercomesrst);
 Adjustablebackrest;
 Adjustablecanopy;
 Pull/pushhandle;
Adjustable leg rest.
 Do not apply any changes or modications to the stroller's construction!
Contact the dealer or an authorized repair service for advice and/or repair instead!
 Discontinuetheusage,ifyoundwornoutorloosejoints,damagedormissing
parts! There is a risk of injury of the child!
Do not allow children younger than 3 years near the stroller during the assembly
or disassembly, in order to prevent the risk of injury or swallowing of small parts!
Strings can cause strangulation! Do not place additional strings to the product
to avoid injuries!
Never use the stroller on stairs or escalators! Use extra care when going up or
down a pavement or step!
The packaging of the product must be kept out of the reach of children to avoid
the risk of strangulation!

3
MAIN PARTS
(1) Canopy
(2) Handle
(3) Folding mechanism
(4) Folding button
(5) Backrest position adjustment mechanism
(6) Front bumper
(7) Button for front bumper removal
(8) Safety belt
(9) Central buckle
(10) Leg rest
(11) Lever for leg rest adjustment
(12) Storage basket
(13) Button for front wheels release
(14) Front wheels
(15) Rear wheels
(16) Parking device

4
The assembly, disassembly and functions are numbered from 1 to 10. Use the operations descriptions
given in this manual and their matching picture.
1 – UNFOLDING THE STROLLER
1-1–Releasethexing
1-2 and 1-3 – Grab the handle and pull it upwards until you hear a click sound and stroller opens and
xesinunfoldedposition.
2 – ASSEMBLY AND REMOVAL OF FRONT WHEELS
Front wheels are only swiveling.
Align the front wheel to the front axis of the frame. Press until you hear a click sound.
Note!Makesurethewheelisxedbytryingtopullitfromtheaxis.
Press the button for removal (1) and pull the wheel out of the frame.
3 – ASSEMBLY AND REMOVAL OF FRONT BUMPER
Insert front bumper (1) into the openings at the frame of stroller and press until you hear a click sound
andbumperisxed.
To remove the bumper, press simultaneously buttons for removal (2) at both sides and pull the bumper
out of the frame.
4 – PARKING DEVICE
Press down the pedal in front part (1) to activate the parking device . Stroller should stop moving.
Press the pedal inwards (2) to release the parking devise . Stroller will move again.
IMPORTANT! Always activate the parking device while stroller is not in motion in order to avoid sudden
sliding and injuries!
5 – CANOPY FOLDING AND UNFOLDING
Pull out the canopy with your hand (1) in order to unfold it.
Push the canopy with your hand (2) in order to fold it.
6 – BACKREST RECLINE ADJUSTMENT
Press the mechanism for backrest adjustment (1) and set the backrest is lowest position – view 1.
Pull the belts (2) outwards to set the backrest in upright position – view 2.
ASSEMBLY INSTRUCTIONS AND FUNCTIONS
This stroller is supplied partially assembled. In order to complete the assembly, you do not need
any tools.
WARNING! Follow exactly the instructions given and check the pictures.
WARNING! After each operation, make sure that you have followed the instructions correctly
andthexingisstable!
WARNING! In most cases after the completion of an operation you will hear a clicking sound.

5
7 – FOOTREST
Footrest is adjustable in 2 positions – horizontal and vertical.
To set the footrest from horizontal to vertical position press simultaneously both levers (1) at both sides
and set the footrest down.
To set the footrest from vertical to horizontal position, pull it with your hand upwards.
8 – RESTRAINT SYSTEM (safety belt)
ATTENTION! USE THE SAFETY HARNESS FROM BIRTH!
8-1 – Join the endings 1 and 2 of safety belts.
8-2 – Insert the jointed belts 3 in central buckle 4.
8-3–Byxinginbuckleyoumusthearaclicksound.
8-4 - The shoulder belts are length adjustable by using the adjusters.
8-5 – Press the button at central buckle 5 to unlock the belts.
Note! Belts must be snug to child’s body and must not be twisted. Adjust the length of the belts ac-
cordingly.
WARNING! Periodically check to ensure that the seat belt is securely attached to the stroller frame as
well as securely fastened. The belts should not be worn or torn, and plastic buckles and fasteners must
be sturdy, free of damage and secure.
9 – FOLDING THE STROLLER
IMPORTANT! Before folding the stroller the parking device must be engaged and the storage basket
should be empty.
9-1 and 9-2 – Press simultaneously the buttons (1) and (2) at folding mechanism.
9-3 – Press the stroller handle forwards until stroller folds.
9-4–Youwillhearaclicksoundbylockingofxingafterfolding.
10 – PUSH/PULL HANDLE
10-1– Push/pull handle is located under the seat.
10-2–Afterfoldingpullthehandlewithyourhand.Byxingyouwillhearaclicksound.
10-3 – Use the handle to roll your stroller after folding.

6
“click”
“click”
“click”
1-1 1-2 1-3
2
(1)
(1)
(2)
(2)(1)
3
4

7
5
6
7
(1)
(1)
(1)
(1) (1)
(2)
(2) (2)
(2)

8
8
9-1
10-1 10-2 10-3
9-2 9-3 9-4
8-1 8-2
2 2
1 1 33
4
5
8-3
8-4
8-5
“click” “click”
“click”
press
(1)
(2)
(3)

9
CARE AND MAINTENANCE GUIDELINES
The brakes and wheels wear out faster than other parts. Replace them when necessary.
Regularly oil the moving parts.Use silicone oil or silicone spray for oiling.
Clean and oil all dirty metal and plastic parts regularly.
Clean the fabrics, plastic parts and metal parts with damp cotton cloth or sponge and mild soap.
Do not use aggressive detergents, solvents, bleach or spirits to clean your stroller.
Always leave the stroller to fully dry after cleaning before you use it or store it. Mold could form if
you keep your stroller moist.
Always store your stroller indoors in clean and dry place. Do not expose to direct environment
 inuence-sun,rain,moistureandhightemperatureintervals.
Fabric Composition:
Outer: 100% Polyester
Filling: 100% Polyester
L K P X 0 2 x х х х х

Bulgaria, Plovdiv, str. Golyamokonarsko shosse 1
www.chipolino.com
