Chipsee EPC/PPC-A72-070-C User manual

Industrial PC
EPC/PPC-A72-070-C
PN: CS10600R070
Content can change at anytime, check documentation website for latest information.
www.chipsee.com

Contents
31. EPC/PPC-A72-070-C
41.1. Product Overview
51.2. Ordering Options
51.2.1. Operating System
61.2.2. Optional Features
61.3. Hardware Features
71.4. Power Input
81.5. Touch Screen
91.6. Connectivity
91.6.1. RS232+RS485 Connector
111.6.2. USB Connectors
121.6.3. LAN Connectors
121.6.4. WiFi & BT Module
131.6.5. 4G/LTE Module
141.6.6. GPIO Port
161.7. TF Card Slot
171.8. Audio Connectors
171.9. HDMI Connector
181.10. Power Button
181.11. Mounting Procedure
181.11.1. EPC-A72-070-C
181.11.2. PPC-A72-070-C
191.12. Mechanical Specications
191.12.1. EPC-A72-070-C
201.12.2. PPC-A72-070-C
201.13. 3D Model
211.14. Disclaimer
211.15. Technical Support
Chipsee IPC Page 2 of 21

EPC/PPC-A72-070-C
Front View
Rear View
EPC/PPC-A72-070-C
Chipsee IPC Page 3 of 21

Side View 1
Side View 2
Product Overview
The Cortex -A72/53 series EPC/PPC-A72-070-C (PN: CS10600R070) is a high-quality
industrial panel PC. It features a 7.0” ve-point capacitive touch screen with a resolution of
1024 x 600 pixels and brightness of 500 cd/m .
Key Applications
Human Machine Interface HMI
Mobile Applications
Video Processing
®
2
•
•
•
EPC/PPC-A72-070-C Product Overview
Chipsee IPC Page 4 of 21

Machine Learning
Video Gaming
Process Control
Process Monitoring
ATM…
It is available both as an embedded solution and as a device hosed in an aluminum casing
with bezels, thus facilitating dierent installation options:
Installation on an industrial cabinet
Integration with the existing equipment
The EPC/PPC-A72-070-C Industrial Panel PC is based around the powerful CS-SOM-RK3399
System on Module (SoM), powered by the Rockchip RK3399 low-power processor which
integrates a dual-core Cortex -A72 and a quad-core Cortex -A53 with a separate NEON
coprocessor.
The RK3399 supports multi-format video decoders and has a high-performance dual-
channel external memory interface (DDR3/DDR3L/LPDDR3/LPDDR4) capable of sustaining
demanding memory bandwidths. It also provides a complete set of peripheral interfaces.
Ordering Options
Chipsee products can be customized during the ordering process. The product will be
shipped with the pre-installed factory defaults if no extra requirements are specied. The
table in the Hardware Features section provides information about the default options
bundled with the product.
Operating System
This product comes with a pre-installed OS of your choice. Please see the list below for the
supported OSes, which can be also obtained from the Software Documentation section,
along with the detailed installation instructions.
Chipsee Linux*
Android 7.1
Debian 10
•
•
•
•
•
•
•
® ®
Note
You can order The EPC/PPC-A72-070-C Industrial Panel PC from the ocial Chipsee Store or from your nearest
distributor.

•
•
•
EPC/PPC-A72-070-C Ordering Options
Chipsee IPC Page 5 of 21

*Chipsee Linux is based on buildroot that has been integrated with:
Chipsee Hardware Test Application
An initialization script for GPIO/Buzzer/Audio
Multiple libraries, such as the libQt5Sql to develop Qt application with SQL
Various packages, such as the ntfs-3g to use NTFS le system
Optional Features
The EPC/PPC-A72-070-C Industrial Panel PC does not include 4G/LTE module by default. The
module is optional and can be selected at the Chipsee store during the ordering process.
Hardware Features
The EPC/PPC-A72-070-C Industrial Panel PC oers a broad range of performance and
connectivity options for scalable integration, providing expandability to meet future needs.
Some of the key features are listed in the table below.
1.
2.
3.
4.
Warning
The Software Documentation section provides a detailed instruction on how to install dierent OSes on your own.
However, bear in mind that Chipsee can’t take the responsibility of inadequate installation procedure. If you “brick”
your device, please contact Chipsee Technical Support at [email protected] for further assistance

Warning
Installation, repair, and maintenance tasks should be performed by trained personnel only.
Chipsee does not bear any responsibility for damage caused by inadequate handling of the product.

EPC/PPC-A72-070-C
CPU Rokchip RK3399, Dual-core Cortex-A72 (1.8GHz), Quad-core Cortex-A53
(1.4GHz)
RAM 4GB DDR3
eMMC 16GB
Storage TF Card, Supports up to 32GB SDHC
Display 7.0” LCD, 1024 x 600, High Brightness: 500 cd/m
Touch 5-point capacitive touch screen
USB 1 x USB 2.0 HOST, 1 x USB 3.0 HOST, 1 x USB Type-C
LAN 1 x RJ45, GbE
Audio 3.5mm Audio In/Out Connector, 2W Internal Speaker
Buzzer Yes
2
EPC/PPC-A72-070-C Optional Features
Chipsee IPC Page 6 of 21

1(1,2)This product has 7 x UART channels in total. The default conguration is 5 x RS232 and 2 x RS485. UART can
be swapped between RS232 and RS485 modes easily, so if you need dierent RS232/RS485 conguration,
please get in touch with the Chipsee Technical Support at [email protected]
Power Input
The EPC/PPC-A72-070-C Industrial Panel PC can be powered by a wide range of input
voltages: From 12V to 36V DC. The power input connector is a 3-pin, 3.81mm terminal. The
polarity and the pinout is clearly marked on the housing of the product as shown on the
gure below.
EPC/PPC-A72-070-C
RTC Yes
RS232 4 x RS2321
RS485 2 x RS485 (1 debug port)1
GPIO 8 Channels
WiFi/BT Integrated WiFi/BT Module
HDMI 1 x HDMI
4G/LTE Not supported
Power Input From 12V to 36V
Current at 15V 800mA Max
Power Consumption 8W Typical
Working
Temperature From -20°C to +70°C
OS Android 7.1
Dimensions EPC-A72-070-C (PN: CS10600R070E): 190 x 107 x 27.7mm
PPC-A72-070-C (PN: CS10600R070P): 205.5 x 135.5 x 27.5mm
Weight EPC-A72-070-C (PN: CS10600R070E): 345g
PPC-A72-070-C (PN: CS10600R070P): 580g
Mounting EPC-A72-070-C (PN: CS10600R070E): Embedded
PPC-A72-070-C (PN: CS10600R070P): Panel
Table 80 Key Features
EPC/PPC-A72-070-C Power Input
Chipsee IPC Page 7 of 21

Figure 388: Power Input
Note that the “+” sign represents the positive power input, and it is printed both at the
casing and as a silk-screen on a PCB of the embedded version. The “-” terminal is shorted to
the ground.
Touch Screen
The EPC/PPC-A72-070-C Industrial Panel PC uses a 5-point capacitive touch screen.
Power Input Denition
Pin Number Denition Description
Pin 1 Positive Input DC Power Positive Terminal
Pin 2 Negative Input DC Power Negative Terminal
Pin 3 Ground Power System Ground
Table 81 Power Connector
Note
The system ground “G” is connected to power negative “-” on board.

EPC/PPC-A72-070-C Touch Screen
Chipsee IPC Page 8 of 21

Figure 389: Capacitive Touch Screen Connector
Connectivity
There are many connectivity options available on the EPC/PPC-A72-070-C industrial PC. It
has 1 x USB 2.0 HOST, 1 x USB 3.0 HOST, 1 x USB Type-C, 1 x network connector (RJ45)
supporting up to 1 Gbps, and 7 x UART terminals (RS232/485).
RS232+RS485 Connector
The serial communication interfaces (RS485 and RS232) are routed to a 16-pin 3.81mm
terminal, as illustrated in the gure below. Serial communication on both RS485 and RS232
interfaces can reach up to 115200 kbps.
Attention
A capacitive touch screen is susceptible to power noise and Electromagnetic Radiation (EMR). It may cause LCD ripples
or even capacitive touch malfunction. If using a capacitive multi-touch test application, you might notice the touch
points oat erratically across the display. There are several solutions to this problem:
Use a high-quality Power Adapter Unit (PSU) with low EMR. You can also provide power from a battery.
Make sure that the EPC/PPC-A72-070-C Power Input connector (pin 3) is properly connected to the Power System
Ground to provide sucient EMI shielding and eliminate the problem entirely.
Bad GND problem can also be conrmed by touching pin 3 of the Power Input connector with one hand while
operating the capacitive touch screen with the other hand. In this case, the operator’s body acts as the Power
System Ground.

1.
2.
3.
EPC/PPC-A72-070-C Connectivity
Chipsee IPC Page 9 of 21

Figure 390: Relation between serial pins on embedded vs. enclosed version
The table below oers more detailed description of every pin and its denition:
RS232 / RS485 / CAN Pin Denition:
Pin Number Denition Description
Pin 1 NULL NULL
Pin 2 NULL NULL
Pin 3 RS485_3- USB UART3, RS485 -(B) signal
Pin 4 RS485_3+ USB UART3, RS485 +(A) signal
Pin 5 RS485_2- USB UART2, RS485 -(B) signal
Pin 6 RS485_2+ USB UART2, RS485 +(A) signal
Pin 7 RS232_1_RXD USB UART1, RS232 RXD signal
Pin 8 RS232_1_TXD USB UART1, RS232 TXD signal
Pin 9 RS232_0_RXD USB UART0, RS232 RXD signal
EPC/PPC-A72-070-C RS232+RS485 Connector
Chipsee IPC Page 10 of 21

USB Connectors
There are 3 x USB HOST connectors onboard which includes 1 x USB 2.0 HOST, 1 x USB 3.0
HOST, and 1 x USB Type-C, as shown in the gures below.
Figure 391: USB 2.0 HOST and USB 3.0 HOST Connectors (embedded/enclosed PC version)
Figure 392: USB Type-C Connector (embedded/enclosed PC version)
RS232 / RS485 / CAN Pin Denition:
Pin 10 RS232_0_TXD USB UART0, RS232 TXD signal
Pin 11 CPU_RS232_4_RXD CPU UART4, CPU RS232 RXD signal
Pin 12 CPU_RS232_4_TXD CPU UART4, CPU RS232 TXD signal
Pin 13 CPU_RS232_2_RXD CPU UART2, CPU RS232 RXD signal
Pin 14 CPU_RS232_2_TXD CPU UART2, CPU RS232 TXD signal
Pin 15 GND System Ground
Pin 16 +5V System 5V output, up to 1A
Table 82 Connectivity Section
Warning
Be careful not to touch surrounding electronic components accidentally while plugging in USB devices into the
embedded IPC version.

EPC/PPC-A72-070-C USB Connectors
Chipsee IPC Page 11 of 21

LAN Connectors
LAN (RJ45) connector provides Ethernet connectivity over standardized Ethernet cables as
shown the gure below. The integrated Ethernet interface supports up to 1 Gbps data
throughput.
Figure 393: RJ45 LAN Connector
WiFi & BT Module
The EPC/PPC-A72-070-C Industrial Panel PC is equipped with the popular Realtek RTL8723
WiFi/BT module that supports BT/BLE 4.0 (with backward compatibility), as well as
802.11bgn 2.4 GHz Wireless LAN (WLAN).
Note
Use CAT5 or better cables to achieve full data throughput over maximum distance dened by the 1000BASE-T
standard (100m).

EPC/PPC-A72-070-C LAN Connectors
Chipsee IPC Page 12 of 21

Figure 394: RTL8273 WiFi/BT Module
The product includes an SMA connector for an external WiFi/BT antenna, as illustrated in
the gure below.
Figure 395: WiFi+BT Antenna
4G/LTE Module
The EPC/PPC-A72-070-C Industrial Panel PC is equipped with a mini-PCIe connector that
can connect to a 4G/LTE module. The customer will also need a SIM Card Holder and a 4G/
LTE Antenna Connector to ensure 4G/LTE works on the EPC/PPC-A72-070-C. SIM card does
NOT support hot plug. Power o before inserting or removing SIM card.
Figure 396: mini-PCIe Connector & 4G Module
Figure 397: SIM Card Holder & 4G Antenna
EPC/PPC-A72-070-C 4G/LTE Module
Chipsee IPC Page 13 of 21

SIM Card Direction
GPIO Port
The EPC/PPC-A72-070-C Industrial Panel PC has a 10 Pin 3.81mm GPIO Connector, as
shown on the gure below, that is labeled as P18 on the PCB. The table below gives details
about the denition of every Pin.
Attention
The product does not come shipped with the 4G/LTE module by default.

EPC/PPC-A72-070-C GPIO Port
Chipsee IPC Page 14 of 21

Figure 398: GPIO Connector
EPC/PPC-A72-070-C GPIO Port
Chipsee IPC Page 15 of 21

Isolated GPIO reduced schematic
TF Card Slot
The EPC/PPC-A72-070-C Industrial Panel PC features 1 x TF Card (micro SD) slot. It can
address up to 128GB of memory.
Figure 399: TF (micro SD) Card Slot
GPIO Connector Pin Denition:
Pin Number Denition Description
Pin 10 VCC_ISO Isolated Power +5V Output
Pin 9 GND_ISO Isolated Ground
Pin 8 OUT1 Isolated Output 1
Pin 7 OUT2 Isolated Output 2
Pin 6 OUT3 Isolated Output 3
Pin 5 OUT4 Isolated Output 4
Pin 4 IN1 Isolated Input 1
Pin 3 IN2 Isolated Input 2
Pin 2 IN3 Isolated Input 3
Pin 1 IN4 Isolated Input 4
Table 83 GPIO Connector Pin-out
Attention
The GPIO Connector is optional.You can Contact us if you need it.
The GPIO has been Opt-Isolated and it uses the 5V Logic by default. You can use an external isolated power input
but the power input range should be from 5V to 24V DC.
The 4 output channels can drive at most 500mA current on each channel.

•
•
•
Note

EPC/PPC-A72-070-C TF Card Slot
Chipsee IPC Page 16 of 21

Audio Connectors
The EPC/PPC-A72-070-C Industrial Panel PC features some audio peripherals, as well. It has
1 x 3.5mm audio input jack and 1 x 3.5mm audio output jack.
The pink connector is the audio input jack (line-in) and the blue connector is the audio
output jack (line-out, typically around -10 dBV) as shown on the gure below.
Figure 400: Audio I/O (embedded/enclosed PC version)
In addition, EPC/PPC-A72-070-C features a miniature 2W embedded speaker for audio
reproduction, as well as a small buzzer for alarm/notication sounds.
Figure 401: 2W Micro Speaker and Buzzer
HDMI Connector
The EPC/PPC-A72-070-C Industrial Panel PC is equipped with 1 x HDMI connector. The
HDMI connector allows connecting an additional (external) monitor. HDMI output resolution
can be congured by the software.
Figure 402: HDMI Connector
The product does not come shipped with the TF Card by default.
EPC/PPC-A72-070-C Audio Connectors
Chipsee IPC Page 17 of 21

Power Button
The EPC/PPC-A72-070-C Industrial Panel PC has a power button, as shown on the gure
below. You can use the button to power ON or OFF the industrial PC.
Figure 403: Power Button
Mounting Procedure
The EPC/PPC-A72-070-C Industrial Panel PC can be mounted with 4 x M4 screws, enabling
simplied installation onto any standard mounting xture. Other mounting options might
also be supported according to the table in the Hardware Features section.
EPC-A72-070-C
You can mount EPC-A72-070-C with the Embedded mounting method, as shown on the
gure below.
Figure 404: Embedded mounting
PPC-A72-070-C
You can mount PPC-A72-070-C with the Panel mounting methods, as shown on the gure
below.
EPC/PPC-A72-070-C Power Button
Chipsee IPC Page 18 of 21

Figure 405: Panel mounting
You can nd detailed information about mounting in the Mount IPC Guide.
Mechanical Specifications
EPC-A72-070-C
The outer mechanical dimensions of EPC-A72-070-C are 190 x 107 x 27.7mm (W x L x H).
Please refer to the technical drawing in the gure below for details related to the specic
product measurements.
Figure 406: EPC-A72-070-C Technical Drawing
Attention
Please make sure the display is not exposed to high pressure when mounting into an enclosure.

EPC/PPC-A72-070-C Mechanical Specications
Chipsee IPC Page 19 of 21

PPC-A72-070-C
For PPC-A72-070-C, the outer mechanical dimensions are 205.5 x 135.5 x 27.5mm (W x L x
H). Please refer to the technical drawing in the gure below for details related to the specic
product measurements.
Figure 407: PPC-A72-070-C Technical Drawing
3D Model
EPC/PPC-A72-070-C 3D model can be viewed in the online doc in a web browser, if you are
reading from the PDF version, please visit the online doc.
Caution
When you use product EPC-A72-070-C, you should not touch the circuit board on the back of the product if the
product is powered ON.
Also, when the product is powered OFF, please take anti-static measures before touching the circuit board.

•
•
EPC/PPC-A72-070-C PPC-A72-070-C
Chipsee IPC Page 20 of 21
